Ozito SAC-2110 User manual

0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 24L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 24L SILENT
LOWMAINTENANCE
OIL FREE
TECHNOLOGY
SILENT
OIL FREE AIR
COMPRESSOR
24L 1.0HP
INSTRUCTION MANUAL
SPECIFICATIONS
Power Supply: 230–240V ~ 50Hz
Motor: 750W (1.0HP) S3 50%
Tank Capacity: 24L
No Load Speed: 1,400/min
Max. Pressure: 116psi / 8bar (0.8 MPa)
Max. Air Delivery: 143L/min
Free Air Delivery: 50L/min
IP Rating: IP20
Weight: 21.0kg
SAC-2110
STANDARD EQUIPMENT
3 YEAR REPLACEMENT WARRANTY*
Your product is guaranteed for a period of 36 months from the original date of purchase. If
a product is defective it will be replaced in accordance with the terms of this warranty. Warranty
excludes consumable parts, for example: valve adapters and accessories.
*This product is intended for DIY use only and replacement warranty covers domestic use.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other than that specified on the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse, accidents
or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
Ozito Industries Pty. Ltd. 25 Fox Drive, Dandenong South, Victoria, Australia 3175.
ozito.com.au
24L Silent Air Compressor
2 x Wheels, 2 x Large Bolts, 4 x
Large Washers, 2 x Large Spring
Washers & 2 x Large Nuts
Air Filter, Support Foot, Small Bolt, 2
x Washers, Spring Washer & Nut
0822
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY
YOU MUST RETURN THE PRODUCT TO YOUR NEAREST
BUNNINGS WAREHOUSE WITH YOUR BUNNINGS
REGISTER RECEIPT. PRIOR TO RETURNING YOUR
PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR
CUSTOMER SERVICE HELPLINE:
Australia: 1800 069 486
New Zealand: 0508 069 486
The benefits provided under this warranty are in addition to other rights and remedies which
are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this warranty,
however, where you have suffered any additional direct loss as a result of a defective product
you may be able to claim such expenses by contacting our customer service helpline above.
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE
THE MODEL NUMBER AND DATE OF PURCHASE
AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE
WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.

0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 24L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
AIR COMPRESSOR
1.0HP 24L SILENT
1. Safety Valve
2. Air Filter
3. Motor
4. On/Off Switch
5. Tank Pressure Gauge
6. Pressure Regulator
7. Carry Handle
8. Regulated Pressure Outlet
9. Output Pressure Gauge
10. Support Foot
11. Drain Valve
12. Pressure Tank
13. Wheel
24L SILENT OIL FREE AIR COMPRESSOR
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
2
1
3 4 5 6 7
89101113 12
ONLINE MANUAL
Scan this QR Code with your mobile
device to take you to the online manual.
The compressor is intended to be used for pneumatic tools with
low air consumption, such as tyre pump nozzles, blower nozzles
and paint guns. The compressor is not suitable for tools with a
high air consumption, such as grinders or impact wrenches.
Pre-Setup Checks
• Examine the machine for signs of transit damage. If damaged,
do not use, return to place of purchase
• The compressor should be set up near to the user.
• Avoid long air lines and long supply lines (extensions).
• Make sure the intake air is dry and dust-free.
• Do not set up the compressor in damp or wet rooms. The
compressor is designed to be used in dry rooms. It is prohibited
to use the compressor in areas where work is conducted with
sprayed water.
• Before you use the machine, make sure that the mains voltage
complies with the specifications on the rating plate.
• The compressor may only be used in suitable areas (with good
ventilation and an ambient temperature from 5°C to 40°C).
There must be no dust, acids, vapours, explosive or flammable
gases in the room.
WARNING! ENSURE THE TOOL IS TURNED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING OPERATIONS.

Attaching The Support Foot
A #3 Phillips Screwdriver, 10mm & 17mm Spanners are required
to assemble the support foot and wheels.
1. Place the supporting foot and then a small washer onto the
small bolt. Thread this through the hole in the foot bracket.
2. Thread the other small
washer and then the spring
washer onto the bolt. Secure
the assembly with the small
nut.
Attaching The Wheels
1. Place the large bolt through
the wheel and a large washer. Then slide this through the hole
in the wheel bracket. Place a large washer then a spring washer
onto the bolt and secure this with a large nut.
2. Repeat step 1 to fit the second wheel on the opposite side of
the tank.
Fitting The Air Filter
1. Attach the supplied air filter
by screwing it in clockwise.
Connecting An Air Hose to the Compressor
1. Pull back the sleeve on the
regulated pressure outlet of
the compressor and insert
the male Nitto end of a
suitably rated air hose (not
supplied).
2. Release the sleeve; the Nitto
coupling should click into
place.
3. Check that the fitting is secure by tugging gently on the
connector. If the hose detaches, repeat steps 2 & 3, pushing the
Nitto connector firmly into the outlet.
Disconnecting Air Tools
WARNING! ENSURE YOU HAVE A FIRM GRIP ON THE
AIR HOSE WHEN DISCONNECTING IT FROM THE AIR
COMPRESSOR, AS PRESSURISED AIR IN THE TANK
MAY CAUSE IT TO WHIP AROUND AND INFLICT INJURY
OR DAMAGE.
1. To remove an air tool from
the unit, retract the sleeve
on the female Nitto fitting
and disconnect the air hose
from the air compressor.
2. Repeat the same procedure with the air tool and air hose.
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY

Adjusting The Output Pressure
The output pressure of the regulated pressure outlet can be
adjusted to suit the air tool connected and the task at hand.
1. To do so, first decrease the
pressure to 0psi by turning
the pressure regulator anti-
clockwise.
2. Then turn the pressure
regulator clockwise until the
desired pressure is shown
on the regulated pressure
gauge.
WARNING! DO NOT ATTEMPT TO ADJUST/MODIFY
THE SAFETY VALVE IN ANY WAY. THE SAFETY VALVE
INSTALLED ON THIS AIR COMPRESSOR IS DESIGNED
TO AUTOMATICALLY RELEASE PRESSURE IN CASE OF
EXCESS PRESSURE BUILD UP IN THE TANK.
3. CONTROLS
OPERATION
Switching The Compressor On/Off
1. To switch the compressor on,
pull the on/off switch to the
‘I’ position. Allow the motor
to run and the tank to fill up.
Note: The compressor will automatically cut off when the tank
pressure reaches 8bar and will automatically start up again when
the tank pressure drops to 6bar.
2. To switch the compressor off, press the on/off switch to the ‘0’
position.
Thermal Overload Protection
This Air Compressor is fitted with thermal protection and will shut
off to protect the compressor from overheating.
The compressor may also have shut off due to reaching max.
cut off pressure. If you are unsure, use an attached blow gun to
release some of the pressure until the tank pressure gauge drops
below 6bar. If the motor does not automatically start up, the unit
has overloaded and the thermal protection has activated.
If the thermal protection activates, switch off the compressor
and allow the compressor to cool down for 15 minutes. Before
attempting to restart the compressor, check that the air filter is not
blocked. Refer to the Maintenance section to clean the air filter.
WARNING! ALLOW THE AIR COMPRESSOR TO COOL
BEFORE ATTEMPTING ANY MAINTENANCE.
WARNING! DO NOT CONTINUE USE OF THE UNIT
IF THE THERMAL PROTECTION ACTIVATES AGAIN
IMMEDIATELY AFTER THE RESET.
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
ON
OFF
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
WARNING! THE AIR COMPRESSOR MUST BE USED
WITH A RESIDUAL CURRENT DEVICE WITH A RATED
RESIDUAL CURRENT OF 30mA OR LESS.
WARNING! DO NOT LEAVE THE AIR COMPRESSOR
UNATTENDED WHILE THE ON/OFF SWITCH IS IN THE
‘ON’ POSITION.

4. USAGE
SAC-2110
Shutting Down The Compressor
Do not turn the air compressor off by unplugging it from the mains
power as it may result in damage to the motor.
1. Turn the compressor off with the on/off
switch and then unplug the cord.
2. Attach a blow gun to the
compressor and use it to
discharge any remaining air
in the compressor tank.
3. Rotate the pressure regulator anti-
clockwise until it is fully closed; check
the regulated pressure gauge to ensure
that it reads 0psi.
4. Also turn on the air tool to
discharge any remaining
pressurised air in the air
hose.
5. Remove the air hose and any
other connected accessories.
WARNING! ALWAYS MAKE SURE THE COMPRESSOR
IS TURNED OFF AND THE TANK PRESSURE GAUGE
SHOWS 0 PSI BEFORE OPENING THE DRAIN VALVE.
TAKE CARE WHEN DISCHARGING AIR THROUGH THE
DRAIN VALVE OR AIR OUTLETS. THE DISCHARGED AIR
CAN CAUSE DUST, STONES, OR ANY OTHER FOREIGN
PARTICLES TO BE BLOWN THROUGH THE AIR AT HIGH
PRESSURE.
6. When no more air is released, open the
drain valve to release any accumulated
liquid from the tank.
7. Close the drain valve, allow the compressor to cool down, then
clean and store the unit.
Starting Up The Compressor
For best practice, the compressor should be run without any load
for 20 minutes before first use to lubricate the bearings and piston.
This procedure should also be performed if the compressor has
been stored for 6 months or more without operation.
1. Disconnect all air hoses from the outlets
and open the drain valve fully to prevent
pressurised air buildup in the tank.
2. Make sure the power switch is in the
off position. Plug the power
supply cord into a mains
outlet.
3. Switch the compressor on and allow it to run for 20 minutes
without any loads/tools
attached and allow any liquid
to drain from the tank.
4. Turn off the compressor and
close the drain valve. The
compressor is now ready for use.
5. Attach the desired tool to one end of
an air hose and the air hose to the regulated pressure outlet
depending on the tool or application.
6. Turn the compressor back on and adjust the regulated pressure
to the desired level once the
pump has shut off and the
compressor has reached cut-
off pressure (8bar).
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIR COMPRESSOR
1.0HP 21L SILENT
LOW MAINTENANCE
OIL FREE
TECHNOLOGY
WARNING! BEFORE CONNECTING THE COMPRESSOR
TO THE POWER SOURCE, CHECK FOR BROKEN
COMPONENTS AND ACCESSORIES. ALSO CHECK
FOR DAMAGE TO THE HOSE. DO NOT PROCEED IF
ANY COMPONENT OR PART SHOWS SIGN OF WEAR
OR DAMAGE. REPLACE THE PART OR TAKE IT TO AN
AUTHORISED REPAIRER.
WARNING! ALWAYS MAKE SURE THE COMPRESSOR
IS TURNED OFF AND THE TANK PRESSURE GAUGE
SHOWS 0PSI BEFORE OPENING THE DRAIN VALVE.
