Ozito AGG100A User manual

Angle Grinder
100mm - 850 Watt
Operation Manual
3 Year Replacement Warranty
AGG100A
CAUTION: Read this operation manual before using this tool.
To view the full range visit: www.ozito.com.au
0609

SPECIFICATIONS - MODEL NO. AGG100A
2
Motor Size: 850W
Cutting Diameter: 100mm
Input: 230-240V~50Hz
No Load Speed: 12,000/min
Weight: 2.2kg
Spindle: M10
Bore: 16mm
Features: Spindle Lock
Two Position Side Handle
This Angle Grinder has been designed to comply with the following Australian/New
Zealand Standards and any other applicable standards referenced therein:
AS/NZS 60745-1 Hand held motor operated electric tools - Safety general requirements.
AS/NZS 60745-2-3 Particular requirements for grinders, polishers and disc-type sanders.
1. Alloy gear case
2. Spindle lock button
3. Lock-on slide switch
4. 2 Position side handle
5. Adjustable safety guard
6. 100mm Grinding disc
7. Safety guard adjustment bolt
8. Pin spanner
9. Allen key (for safety guard)
10. Outer flange
11. Inner flange
1
3
65
2
7
4
9
8
10 11

TABLE OF CONTENTS
3
SPECIFICATIONS…………………………………………
TABLE OF CONTENTS…………………………………..
INTRODUCTION……………………………………….…
GENERAL SAFETY INSTRUCTIONS…………………....
GENERAL SAFETY RULES……………………………….
ASSEMBLY/ADJUSTMENTS……………………….……
OPERATION………………………………………………
ON/OFF SWITCH…………………………………………
SAFETY GUARD…………………………………………..
BASIC ABRASIVE CUTTING PROCEDURE ……………
MAINTENANCE…………….…………………………….
DESCRIPTION OF SYMBOLS……………………………
CONTENTS……...………………………………………..
WARRANTY……………….………………………………
Page 2
Page 3
Page 4
Page 4
Page 5
Page 10
Page 11
Page 11
Page 11
Page 12
Page 12
Page 13
Page 13
Page 15

INTRODUCTION
4
Congratulations on purchasing an Ozito Angle Grinder.
We aim to provide quality tools at an affordable price.
We hope you will enjoy using this tool for many years.
Your Ozito Angle Grinder AGG100A has been designed
for cutting and grinding metal and is intended for DIY
use only.
Warning! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of fire, electric shock, personal
injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off,
in an emergency, before operating the tool.
Save these instructions and other documents supplied with this machine for
future reference.
The electric motor has been designed for 230V and 240V only. Always check that the
power supply corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia
and New Zealand.
This tool is double insulated in accordance with AS/NZS 60745-1:2002;
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by a qualified electrician or a power
tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when
operating this tool. The insulation system is for added protection against injury resulting
from a possible electrical insulation failure within the tool.
Using an extension lead
Always use an approved extension lead suitable for the power input of this tool. Before
use, inspect the extension lead for signs of damage, wear and ageing. Replace the
extension lead if damaged or defective. When using an extension lead on a reel, always
unwind the lead completely. Use of an extension lead not suitable for the power input
of the tool or which is damaged or defective may result in a risk of fire and electric shock.
SAFETY INSTRUCTIONS
GENERAL SAFETY INSTRUCTIONS

GENERAL SAFETY RULES
5
Warning! Read all instructions. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury. The term "power tool" in
all of the warnings listed below refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
Save these instructions
1) Work area
a) Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock
b) Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
e) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Avoid accidental starting. Ensure the switch is in the off-position before
plugging in. Carrying power tools with your finger on the switch or plugging in
power tools that have the switch on invites accidents.

GENERAL SAFETY RULES (cont.)
6
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of these devices
can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tools
operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions and in the manner intended for the particular type of power tool,
taking into account the working conditions and the work to be performed.
Use of the power tool for operations different from those intended could result in a
hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
Safety Warnings Common for Grinding:
a) This power tool is intended to function as a grinder. Read all safety warnings,
instructions, illustrations and specifications provided with this power tool.
Failure to follow all instructions listed below may result in electric shock, fire and/or
serious injury.
b) Operations such as sanding, wire brushing, polishing or cutting-off are not
recommended to be performed with this power tool. Operations for which the
power tool was not designed may create a hazard and cause personal injury.

GENERAL SAFETY RULES (cont.)
7
c) Do not use accessories which are not specifically designed and
recommended by the tool manufacturer. Just because the accessory can be
attached to your power tool, it does not assure safe operation.
d) The rated speed of the accessory must be at least equal to the maximum
speed marked on the power tool. Accessories running faster than their rated
speed can break and fly apart.
e) The outside diameter and the thickness of your accessory must be within
the capacity rating of your power tool. Incorrectly sized accessories cannot
be adequately guarded or controlled.
f) The arbour size of wheels, flanges, backing pads or any other accessory
must properly fit the spindle of the power tool. Accessories with arbour
holes that do not match the mounting hardware of the power tool will run out
of balance, vibrate excessively and may cause loss of control.
g) Do not use a damaged accessory. Before each use inspect the accessory
such as abrasive wheels for chips and cracks, backing pad for cracks, tear or
excess wear, wire brush for loose or cracked wires. If power tool or
accessory is dropped, inspect for damage or install an undamaged
accessory. After inspecting and installing an accessory, position yourself
and bystanders away from the plane of the rotating accessory and run the
power tool at maximum no-load speed for one minute. Damaged accessories
will normally break apart during this test time.
h) Wear personal protective equipment. Depending on application, use face
shield, safety goggles or safety glasses. As appropriate, wear dust mask,
hearing protectors, gloves and workshop apron capable of stopping small
abrasive or work piece fragments. The eye protection must be capable of
stopping flying debris generated by various operations. The dust mask or
respirator must be capable of filtrating particles generated by your operation.
Prolonged exposure to high intensity noise may cause hearing loss.
i) Keep bystanders a safe distance away from work area. Anyone entering
the work area must wear personal protective equipment. Fragments of
work piece or of a broken accessory may fly away and cause injury beyond
immediate area of operation.
j) Hold power tool by insulated gripping surfaces only, when performing an
operation where the cutting accessory may contact hidden wiring or its
own cord. Cutting accessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and shock the operator.
k) Position the cord clear of the spinning accessory. If you lose control, the
cord may be cut or snagged and your hand or arm may be pulled into the
spinning accessory.
l) Never lay the power tool down until the accessory has come to a
complete stop. The spinning accessory may grab the surface and pull the
power tool out of your control.
m) Do not run the power tool while carrying it at your side. Accidental contact
with the spinning accessory could snag your clothing, pulling the accessory into
your body.

8
n) Regularly clean the power tool's air vents. The motor's fan will draw the dust
inside the housing and excessive accumulation of powdered metal may cause
electrical hazards.
o) Do not operate the power tool near flammable materials. Sparks could ignite
these materials.
p) Do not use accessories that require liquid coolants. Using water or other liquid
coolants may result in electrocution or shock.
Further safety instructions for all operations:
a) Maintain a firm grip on the power tool and position your body and arm to
allow you to resist kickback forces. Always use auxiliary handle, if provided,
for maximum control over kickback or torque reaction during start-up. The
operator can control torque reactions or kickback forces, if proper precautions
are taken.
b) Never place your hand near the rotating accessory. Accessory may kickback
over your hand.
c) Do not position your body in the area where power tool will move if kickback
occurs. Kickback will propel the tool in direction opposite to the wheel's
movement at the point of snagging.
d) Use special care when working corners, sharp edges etc. Avoid bouncing and
snagging the accessory. Corners, sharp edges or bouncing have a tendency to
snag the rotating accessory and cause loss of control or kickback.
e) Do not attach a saw chain woodcarving blade or toothed saw blade. Such
blades create frequent kickback and loss of control.
Austral different parts
Recommendation for the use of a residual current device with a rated residual current
of 30 mA or less.
GENERAL SAFETY RULES (cont.)

9
ADDITIONAL SAFETY INSTRUCTIONS FOR ANGLE GRINDERS
a) Use only wheel (disc) types that are recommended for your power tool
and the specific guard designed for the selected wheel. Wheels for which
the power tool was not designed cannot be adequately guarded and are unsafe.
b) The guard must be securely attached to the power tool and positioned for
maximum safety, so the least amount of wheel (disc) is exposed towards
the operator. The guard helps to protect operator from broken wheel
fragments and accidental contact with wheel.
c) Wheels (discs) must be used only for recommended applications. For
example: do not grind with the side of a cut-off wheel. Abrasive cut-off
wheels are intended for peripheral grinding, side forces applied to these
wheels may cause them to shatter.
d) Always use undamaged wheel (disc) flanges that are of correct size and
shape for your selected wheel. Proper wheel flanges support the wheel thus
reducing the possibility of wheel breakage. Flanges for cut-off wheels may be
different from grinding wheel flanges.
e) Do not use worn down wheels from larger power tools. Wheels intended
for larger power tools are not suitable for the higher speed of a smaller tool
and may burst.
f) Make sure the wheel (disc) is not contacting the work piece before the
tool is turned on. Having the wheel resting on the work piece before starting
the tool could result in the tool kicking as it grips the work piece, this could
cause potential personal harm and/or material damage.
g) Check the wheel (disc) carefully for cracks or damage before operation.
Replace cracked or damaged wheels immediately.
h) Before operation of the tool an actual work piece, let it run for a few
moments. Watch for vibration or wobbling that could indicate poor installation
of the wheel (disc) or a poorly balanced wheel.
i) Watch out for flying sparks. Hold the tool at an angle of approximately 15 -
30°to the work piece surface.
j) Use only wheels (discs) having a maximum operating speed at least as
high as the “No load speed” marked on the rating label of this tool. Using
a wheel with a lower maximum speed rating than the tool is dangerous and
could result in the wheel breaking during use causing potential personal harm
and/or material damage.
k) It should never be necessary to force the tool. If rotational speed drops
abnormally, the pressure should be released immediately. Little more than the
weight of the tool should be applied. Applying (forcing) excessive pressure can
cause dangerous wheel breakage or burn out of the tools motor.
Always wear eye protection
Wear goggles
Wear hearing protection
Wear a breathing mask

10
BE SURE TO DISCONNECT THE ANGLE GRINDER FROM THE POWER
SUPPLY BEFORE ATTACHING OR REMOVING A DISC OR ATTACHMENT.
Make sure the grinding or cutting disc is mounted with the label on top (facing
the angle grinder). If you are fitting any other kind of attachment, refer to
attachment fitting instructions. Ozito Industries P/L will not be responsible for
any damage or injury caused due to the incorrect fitting of grinding or cutting
discs or any other kind of attachment. Incorrect attachments can cause the motor
to burn out, generally damage the tool and/or cause injury.
Assembling the side handle
The side handle (4) can be fitted on either the left or the right hand side of your
grinder. Choose the most appropriate position considering user comfort (preferred
hand) and the task at hand.
Attaching and removing the grinding disc
• Inspect the grinding disc (6) before fitting and during use to ensure it is not
deformed or cracked.
• Do not fit or use a grinding disc (6) for cutting applications - For cutting, use a
cutting disc and ask your hardware retailer for advice regarding the type of cutting
disc you require for the material you wish to cut. Grinding discs are used for
grinding metal only.
• The grinding disc (6) is not solid. It is made from grit which is bonded together
with reinforcement and adhesives. It is always possible that a part of the disc can
dislodge and fly away from the tool at high speed. This is why you must wear the
appropriate safety equipment (glasses, gloves and protective clothing) described
herein and follow all safety instructions also described herein.
• Do not use any kind of attachment (discs or otherwise) that has a diameter greater
than 100mm (4”).
Warning! Removing the safety guard (5) is a serious safety concern, this action will
also void your warranty.
• Remove the outer flange (10) by hand if loose. If tight, depress the spindle lock
button (2) at the top of the alloy gear case (1); rotate the spindle (or disc if
attached) to locate the lock position. Once the spindle is locked and cannot be
rotated, use the pin spanner (8) supplied to loosen the outer flange (10).
•Never press the spindle lock button (2) when the disc or attachment is still rotating.
Always wait until the disc or attachment has stopped rotating before pressing the
spindle lock button (2). Pressing the spindle lock button (2) will cause damage to the
spindlle lock mechanism which will not be covered under warranty.
•Holding the angle grinder with the spindle facing upwards, ensure the inner flange
(11) is on the spindle and located correctly. The two machined flat sections on one
side of the inner flange (11) must face the angle grinder and locate in the
appropriate position on the spindle.
• Insert the hole in the grinding disc (6) over the angle grinder spindle with the disc
label facing the angle grinder. The hole in the disc should be located onto the
spindle. Ensure the hole in the disc locates and fits firmly into the ring section of
the inner flange (11).
ASSEMBLY/ADJUSTMENTS

OPERATION
11
• Screw the outer flange (10) onto the spindle with the protruding ring section
facing the angle grinder. This ring section must locate with the hole in the
grinding disc (6).
• Tighten the outer flange (10) by locking the spindle (using the spindle lock
button) and then tightening the outer flange (10) with the pin spanner (8) provided.
• Removal of the disc is conducted in reverse order to the above.
•Regularly check that the outer flange has not loosened during use.
Note: When fitting a cutting disc or diamond wheel, the ring section on the outer
flange should face away from the disc / wheel in order for the face of the outer
flange (10) to sit flush against the bottom side of the disc / wheel.
Note: Disc/wheel label or marking, should face towards inner flange.
On/off switch
The angle grinder is started by pushing the lock-on slide switch (3) forward towards
the alloy gear case (1). The lock-on slide switch (3) will lock-on in the ON position.
To turn the angle grinder OFF, push down on the 'O' marking on the rear of the
lock-on slide switch (3). This will cause the switch to retract to the OFF position.
Safety guard
The safety guard (5) is assembled to your tool for your protection. The safety
guard (5) will protect you from any dislodging objects or materials that may be
ejected by the cutting/grinding discs during normal operation. This guard (5) will
protect you from any accidental contact of the disc with your hands, fingers and
any other parts of your body.
To adjust the safety guard (5), first disconnect the tool from the power supply. Now
loosen the allen key bolt (7) by using the allen key (9) supplied. Rotate the safety
guard (5) into the required position, then refasten the bolt (7). Ensure the safety
guard (5) is firmly secured prior to use.
Basic abrasive cutting procedure
First ensure the work piece is securely held down (by both sides of the work piece
if possible). Turn on the angle grinder and proceed to start the cut gently - do not
“bump” the cutting disc to start a cut. Feed the disc through the work as fast as
possible without slowing the cutting disc in the cut or labouring the machine. The
abrasive cutting operation generates a great deal of localised heat which causes
rapid expansion of the piece being cut. Discs operated at speeds significantly
below the efficient speed or if fed through the cut too slowly will generate
excessive heat. Such heat can cause rapid disc wear, fraying around the edge of
the reinforced discs and disc breakage.
Cutting discs & diamond wheels
Inner flange
Spindle
Outer flange
(raised r ing faces AW AY
fr om the disc/wheel)
Gr inding discs
Inner flange
Spindle
Outer flange (raised r ing faces
TOW ARDS and locates in the
grinding disc)
Grinding discs Cutting discs & diamond wheels

12
OPERATION (cont.)
MAINTENANCE
Basic grinding procedure
First ensure the work piece is securely held down (by both sides of the work piece if
possible). Turn on the angle grinder and proceed to start grinding your work piece
gently - do not “bump” the grinding disc on your work piece as this may damage
your grinding disc. The optimal grinding position is to hold your grinder at
approximately 10-15º to your work piece and grind slowly. This will assist you and
prevent deep gouging.
TCT & Multi cutting blades
Warning! The use of TCT & multi cutting blades is not recommended with angle
grinders.
Using such blades with angle grinders is very dangerous when used by an inexperienced
operator. TCT and multi cutting blades can catch on the material being worked and
cause the grinder to kick back (be thrown) out of the users hands. Potentially this could
result in serious injury to the operator and/or the material being worked on. Ozito does
not recommend using these types of blades with the angle grinder.
• Keep ventilation slots of the grinder clean at all times and prevent any foreign
matter from entering.
•If the enclosure of the grinder requires cleaning do not use solvents but a moist
soft cloth only.
• The grease in the gearbox will require replacement / replenishment after extensive
use of the grinder. Please see a qualified electrical repairer to provide this service.
•Blow out the unit through the rear ventilation slots with compressed air
periodically to ensure a dust free area around the switch.
• Carbon brushes should be replaced before they wear out. Both carbon brushes
should be replaced at the same time.
•Sparking visible through the housing air vents
A small amount of sparking may be visible through the housing vents. This is
normal and does not indicate a problem.
•Excessive sparking visible through the housing air vents and/or the tool
FAILING to operate
May indicate the carbon brushes have worn down and need
to be replaced. Carbon brushes should only be replaced by a
qualified eletrician or power tool repairer.
Replacement carbon brushes can be ordered from Ozito
through your local Bunnings warehouse special orders desk.
Spare part number: SPAGG-0381
NOTE: Ozito Industries will not be responsible for any damage or injuries caused
by repair of the grinder by an unauthorised person or by mishandling of the tool.

DESCRIPTION OF SYMBOLS
13
1 x AGG100A Angle Grinder
1 x Side Handle
1 x Inner Flange (assembled)
1 x Outer Flange (assembled)
3 x Metal Grinding Discs
1 x Pin Spanner
1 x Allen Key
1 x Instruction Manual
AUSTRALIA (Head Office)
1 - 23 Letcon Drive, Bangholme, Victoria, Australia 3175
Telephone: [phone]
Facsimile: [phone]
Website: www.ozito.com.au
Email: [email protected]
Power tools that are no longer usable should not be
disposed of with household waste but in an environmentally
friendly way. Please recycle where facilities exist. Check with
your local council authority for recycling advice.
Recycling packaging reduces the need for landfill and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
VVolts Hz Hertz
~Alternating current WWatts
/min Revolutions or
reciprocation per minute
Double insulated Regulator compliance mark
Wear eye protection
n o No load speed
CARING FOR THE ENVIRONMENT
CONTENTS
OZITO INDUSTRIES PTY LTD

WARRANTY
THIS WARRANTY FORM AND CONFIRMED BUNNINGS REGISTER RECEIPT SHOULD
BE RETAINED BY THE CUSTOMER AT ALL TIMES
The warranty is only made available by returning the product to your nearest
Bunnings Warehouse with a confirmed Bunnings register receipt.
PURCHASED FROM:________________________________________________
DATE PURCHASED: ________________________________________________
3 YEAR REPLACEMENT WARRANTY
Your Ozito tool is guaranteed for a period of 36 months from the original date of
purchase and is intended for DIY (Do it yourself) use only.
WARNING
The following actions will result in the warranty being void.
•Trade, Industrial or high frequency use.
• If the tool has been operated on a supply voltage other than that specified on
the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse,
accidents or alterations.
•If the tool is disassembled or tampered with in any way.
Note: Warranty excludes consumable parts such as carbon brushes, batteries,
sanding pads, blades, discs, drill bits, collets, router bits and globes.
YOUR WARRANTY FORM SHOULD BE RETAINED
BY YOU AT ALL TIMES.
SHOULD YOU HAVE ANY QUESTIONS PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY OR
REPAIR PLEASE TELEPHONE OUR CUSTOMER
SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER
AND DATE OF PURCHASE AVAILABLE. AN OZITO CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY OR PROCEDURE.
