Ozito BGRT-121 User manual

BENCH GRINDER &
FLEXIBLE DRIVE
120W 75mm
INSTRUCTION MANUAL
BGRT-121
WHAT’S IN THE BOX
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: grinding &
polishing wheels, carbon brushes etc..
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
thanthatspeciedonthetool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/NewZealand(HeadOfce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
Thebenetsprovidedunderthiswarrantyareinaddition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
1016
SPECIFICATIONS
Voltage: 230-240V ~ 50Hz
Input Power: 120W
No Load Speed: 0 – 9,900/min
Wheel: Ø 75 x 20mm
Wheel Bore: Ø 10mm
Wheel Max. Speed: 40 m/s
Weight: 2.5 kg
Safety Eye Shields Assy.
Adjustable Tool Rest Assy.
Flexible Drive
Bench Grinder
Spanner & Locking Pin

3
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
The Bench Grinder is a combination tool for the grinding and polishing
of metals, plastics and other materials.
Securing the Grinder
Before operating the Bench Grinder,
it should be rmly secured to a
workbench, or a stable base.
Insert screws through the two
mounting holes at either side of the
base and use a screwdriver to x the
grinder to the surface.
Fitting the Safety Shield
Brackets
NOTE: All covers and safety devices
must be properly tted correctly before
the equipment is switched on.
1. Safety shields must be tted to each
wheel guard covers of the Bench
Grinder prior to operation.
2. Attach safety shields to the wheel
guard cover by inserting two adjusting
screws through the slots in the safety
shield bracket and the corresponding
holes in the safety hood.
3. Position the safety shield bracket so
that the distance between the grinding
wheel and the safety shield bracket
is as small as possible and does not
exceed 2 mm.
4. Hold the nut at the rear of the safety
shield bracket in place with a spanner,
while tightening the front adjusting
screws with a screwdriver.
NOTE: Adjust the safety shield bracket
periodically to compensate for wear
on the grinding wheel.
1. Safety Eye Shield
2. Wheel Guard Cover
3. Grinding Wheel
4. Safety Shield Bracket
5. Tool Rest Adjusting Knob
6. On/Off Switch
7. Variable Speed Dial
8. Mounting Holes
9. Safety Shield
Adjusting Screw
10.Polishing Wheel
11.Tool Res
BENCH GRINDER
KNOW YOUR PRODUCT
12 13
14
SETUP & PREPARATION
IMPORTANT! BEFORE ASSEMBLING YOUR BENCH
GRINDER, MAKE SURE THAT THE MOTOR IS OFF AND THE
TOOL DISCONNECTED FROM THE POWER SUPPLY TO
PREVENT ACCIDENTAL STARTING.
IMPORTANT! THE EQUIPMENT AND PACKAGING MATERIAL
ARE NOT TOYS. DO NOT LET CHILDREN PLAY WITH
PLASTIC BAGS, FOILS OR SMALL PARTS. THERE IS A
DANGER OF SWALLOWING OR SUFFOCATING!
3 4 5 6 7 8 9 10 112
12.Spanner
13.Locking Pin
14. Flexible Drive
ACCESSORIES
2 mm
Max.
1. ASSEMBLY

Fitting the Adjustable Tool Rest
The Bench Grinder comes with two adjustable tool rests that aid
the user in holding items steady as they are being applied to the
grinding wheels.
1. Align the slot in the tool rest
with the hole in the bottom of
the wheel guard cover.
2. Place the washers on the
threaded end of the star
screw.
3. Secure the adjustable tool rest
to the grinder using the star
screw. Do not fully tighten until
the nal adjustments have
been made.
4. Adjust the tool rest so that the
distance between the grinding
wheel and the tool rest is as
small as possible and does
not exceed 2 mm. Tighten the
star screw.
NOTE: Adjust the tool rest
periodically to compensate for
wear on the grinding wheel.
Fitting the Safety Eye Shields
1. Position the safety eye shields
between the vertical braces at the top
of the safety shield brackets.
2. Insert a long screw
through a washer,
then through the
safety shield bracket
and safety eye shield
(screws and washers
supplied).
3. Place a washer on the end of the
screw and fasten the assembly in
place with a nut.
4. Hold the nut in place with a spanner,
while tightening the screw with a
screwdriver. Do not overtighten.
2 mm
Max.

2. THE FLEXIBLE SHAFT 3. OPERATION
OPERATION
On/Off Switch
1. To switch ON the equipment set the On/Off
switch to the “I” position.
2. After switching ON, wait for the equipment to
reach its maximum speed of rotation. Only then
should you begin with the grinding.
3. Move the On/Off switch to the “O” position to
switch OFF the equipment.
Variable Speed Dial
The required speed can be set with
the variable speed dial.
Speed of the exible Drive
The correct speed depends on the tool used
and the type of material being processed.
• Small cutters/grinding stones:
High speed (not included).
Using the exible Drive
• Precision work/
engraving: hold the
drive unit like a pen.
IMPORTANT! WHEN YOU WORK WITH THE FLEXIBLE
DRIVE, THE SAFETY SHIELD MUST BE PLACED RIGHT UP
AGAINST THE ADJUSTABLE TOOL REST IN ORDER TO
PREVENT ACCIDENTAL TOUCHING OF THE WHEELS.
Installing the Flexible Drive
NOTE: Fitting the accessory exible drive shaft is optional and should
only be tted when required.
The exible drive is designed for the grinding, deburring, polishing,
engraving, cutting, milling and cleaning of wood, metal and plastic in
model making, in workshops and in the home. Use the tool and its
accessories only for the applications
described.
1. Insert the internal shaft of the exible
drive into the guide shaft on the right
hand side of the grinder.
2. Secure the fastening nut of the exible
drive to the equipment thread by hand
(left-hand thread).
Inserting the accessories
into the Flexible Drive
1. Press the supplied locking pin into the
hole in the exible drive and turn the
shaft until the pin latches in place.
2. Undo the collet chuck nut with the
supplied spanner.
3. Insert the required accessory
into the sleeve and tighten
the collet chuck nut.
IMPORTANT! ALWAYS DETACH THE FLEXIBLE DRIVE FROM
THE GRINDER WHEN NOT IN USE. AN ATTACHED FLEXIBLE
DRIVE MAY WHIP ABOUT UNCONTROLLABLY IF IT IS NOT
BEING HELD.
• Large cutters/grinding stones:
Low speed (not included)
• Rough work: hold the
drive unit like the handle
of a hammer.
LOW HIGH
CAUTION: TO REDUCE THE RISK OF ELECTRICAL
SHOCK, A RESIDUAL CURRENT DEVICE (RATED 30mA
OR LESS) SHOULD BE USED.

BGRT-121
4. GRINDING
1. Place the workpiece onto the tool
rest.
2. Slowly guide the workpiece towards
the grinding wheel, ensuring that the
workpiece is at the desired angle
when it makes contact.
NOTE: Exert only light pressure on
the workpiece so that it can be ground
at constant speed. Instead of forcing
your work, high pressure will cause the
drive unit to slow down, even stop and
overloading the motor.
3. Move the workpiece from side to side
to produce an optimal grinding result.
This way the grinding wheel will be
evenly worn. Allow the workpiece to
cool down occasionally.
IMPORTANT! IF THE GRINDING WHEEL BECOMES JAMMED
DURING OPERATION, REMOVE THE WORKPIECE AND WAIT
UNTIL THE TOOL REACHES ITS TOP SPEED AGAIN.
IMPORTANT! FOR YOUR OWN SAFETY, IT IS ESSENTIAL
TO SECURE SMALL WORKPIECES WITH A CLAMP OR
VISE.
5. POLISHING
1. Apply a thin coating of polishing
paste (supplied) to the surface of
the Polishing wheel.
2. Press the workpiece onto the wheel
and move it back and forth across
the surface of the wheel.
3. Always carry out polishing work in the
direction of rotation of the polishing
wheel.
IMPORTANT! POLISHING IN THE OPPOSITE DIRECTION TO
THE DIRECTION OF ROTATION OF THE GRINDING WHEELS
CAN CAUSE DAMAGE TO THE WHEEL, WHICH IN TURN
CAN RESULT IN INJURIES.

6. MAINTENANCE
Changing the Wheels
1. Remove the 3 screws that
hold the side section of the
safety hood and remove the
wheel guard cover.
2. With a spanner, hold the
wheel nut on the opposite
side in position, while
loosening the wheel nut of
the wheel you wish to change
with another spanner.
NOTE: The grinding wheel on the left is fastened with a left handed
thread and the wheel on the right with a right-handed thread.
3. Remove the ange and
replace the grinding wheel.
4. To assemble, proceed in
the reverse order.
5. Manually spin the newly
mounted wheel to check
that it rotates freely prior
to operation.
Carbon brushes
Carbon brushes will wear out after
many uses, causing the Bench
Grinder to spark and/or stop.
The brushes are a wearing component
of the Bench Grinder and should be
replaced prior to the carbon wearing
out completely.
Take the Bench Grinder to a suitably
qualied electrician or power tool repairer for replacement.
Always replace both brushes at the same time.
NOTE: Ozito Industries will not be responsible for any damage or
injuries caused by the repair of the Bench Grinder by an unauthorised
person or by mishandling of the Bench Grinder.
Replacing the power cable
If the power cable for this equipment is damaged, it must be replaced
by the manufacturer or its after-sales service or similarly trained
personnel to avoid danger.
Cleaning
• Keep all safety devices, air vents and the motor housing free of
dirt and dust as far as possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low pressure.
• We recommend that you clean the device immediately each time
you have nished using it.
• Clean the equipment regularly with a moist cloth and some soft
soap. Do not use cleaning agents or solvents; these could attack
the plastic parts of the equipment. Ensure that no water can seep
into the device. The ingress of water into an electric tool increases
the risk of an electric shock.
Storage
Store the equipment and accessories out of children’s reach in a
dark and dry place at above freezing temperature. The ideal storage
temperature is between 5 and 30 °C. Store the electric tool in its
original packaging.
IMPORTANT! BEFORE CLEANING YOUR BENCH GRINDER
OR CARRYING OUT ANY MAINTENANCE PROCEDURE,
MAKE SURE THAT THE MOTOR IS OFF AND THE TOOL
DISCONNECTED FROM THE POWER SUPPLY TO
PREVENT ACCIDENTAL STARTING.
MAINTENANCE

DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
Polishing Wheel 4412620
Grinding Wheel 4412625
Carbon Brush (Pair) 441256001021
Safety Shield 441256001013
Safety Shield Bracket 441256001011
Adjustable Tool Rest-Left 441256001049
Adjustable Tool Rest-Right 441256001037
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
6. MAINTENANCE VVolts Hz Hertz
~Alternating current WWatts
/min Revolutions or
reciprocation per minute noNo load speed
Regulator compliance
mark Wear gloves
Read instruction manual Wear eye protection
Wear ear protection Double insulated

BENCH GRINDER SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and
New Zealand.
This tool is double insulated therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid
a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitable for the power input of the tool or which is damaged or defective may result in a risk of re and electric
shock.
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/or serious injury. Save all
warnings and instructions for future reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmodied plugs and
matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the inuence of drugs, alcohol
or medication. A moment of inattention while operating power tools may result in serious
personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power tools
with your nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the
power tool for operations different from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
This appliance is not intended for use by young or inrm persons unless supervised by a
responsible person to ensure that they can use the appliance safely. Young children should
be supervised to ensure that they do not play with the appliance.
• Always remove the plug from the mains socket before making any adjustments or
maintenance, including changing the wheel.
• Always wear eye protection and check that the safety window on the grinder are properly
adjusted.
• Always turn the grinder off when it is not in use and never leave it unattended without rst
switching off and removing the power plug. Never leave the grinder until the grinding wheels
have come to a complete stop.
• Do not let anyone under 18 years operate this tool.
• Rags, cloths, cord, string and the like should never be left around the work area.
• If you are interrupted when operating the tool, complete the process and switch off before
looking up.
• Periodically check that all nuts, bolts and other xings are properly tightened.
• Do not use a wheel that has received a blow, especially to the side of the wheel.
• Replace a cracked or suspect wheel.
• Always allow a new wheel to run for a few minutes at full speed before using it.
Stand to one side at start up.
• Check that the wheel rotates freely each time before start up.
• Do not use the grinder unless all the guards are properly tted and secure.
• Check that the tool rests are properly adjusted before commencing use.
• Do not overload the grinder. Allow the grinder to run at full speed, or close to full speed
during use.
• If possible, always use clamps or a vice to hold your work.
• Always switch off before you put the exible shaft down.
• Ensure that the lighting is adequate.
• Do not put pressure on the tool, such that it slows the motor down. Allow the attachments to
work without pressure. You will get better results and you will be taking better care of your tool.
• Make sure that the wheel is not in contact with the work when you start the grinder.
• When using the grinder, use safety equipment including safety goggles or shield,
ear protection, dust mask and protective clothing including safety gloves.
• Keep the area free of tripping hazards.
• Only use accessory bits in good condition and that are recommended by the manufacturer.
• Do not touch the attachments after operation. They may be very hot.
• Keep your hands well clear of the cutting and grinding devices.
• To prevent damage to the power cable, always lead it away from the rear of the machine.
• Use on materials containing asbestos is prohibited.
• The machine may exceed 85 db (A) at the workplace. The operator will require noise protection
measures and ear muffs if this is the case.
• Protect the mains cable from becoming damaged by oil, solvents and sharp edges.
• Make sure that the switch is turned off when connecting the tool to the power supply.
• Check that the rotating speed shown on the wheel is equal to or higher than the rated speed of
rotation for the grinder.
• Make sure that the grinding wheel is of the correct size for the grinder.
• Take precautions to ensure that ying sparks do not cause any danger, e.g. that they do not hit
anyone or cause inammable substances to ignite.
• The workpiece supports and the top adjustable safety guards must always be moved as close as
possible to the grinding wheel (max. 2 mm clearance).
• Grinding wheels are not allowed to be used without the safety device. The following clearances
must not be exceeded: - Workpiece support/grinding wheel: max. 2 mm - Safety guard/grinding
wheel: max. 2 mm
• The guard holder, workpiece support and transparent guard must be tted before the double
grinder is used.
• Before starting work, rmly screw the grinder to the workbench etc. using the mounting holes in
the base plate.
• Adjust the spark deector periodically in order to compensate the wear of the wheel. Distance
between the spark deector and the wheel should in no case exceed 2mm.
• The grinding wheel must be replaced at the latest when the spark deector and the workpiece
support can no longer be set a maximum distance of 2mm from the grinding wheel.
Keep this safety information in a safe place. If in doubt, do not plug in the tool. Using a power
source with a voltage less than the nameplate rating is harmful to the motor.
The tool must be used only for its prescribed purpose. Any use other than those mentioned in this
Manual will be considered a case of misuse. The user and not the manufacturer shall be liable for
any damage or injury resulting from such cases of misuse.
To use this tool properly, you must observe the safety regulations, the assembly instructions and the
operating instructions to be found in this manual. All persons who use and service the machine have
to be acquainted with this manual and must be informed about its potential hazards.
The manufacturer shall not be liable for any changes made to the tool nor for any damage resulting
from such changes.
Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors. The
following hazards may arise in connection with the tool’s construction and design:
• Damage to the lungs if an effective dust mask is not worn.
• Damage to hearing if effective ear defenders are not worn
Wear goggles, Wear ear protection, Wear a breathing mask
