Ozito Power x change px5pak-005 User manual

SPECIFICATIONS

Voltage: 18V

No Load Speed: 8500/min

Disc Diameter: 115mm (41/2”)

Spindle: M14

Charge Time: 40mins (2.0Ah)

80mins (4.0Ah)

Weight: 1.8kg

CORDLESS

ANGLE GRINDER

INSTRUCTION MANUAL

ozito.com.au

PX5PAK-005

Cordless Drill Driver

& Impact Driver

Cordless Angle Grinder

Cordless Circular Saw

& LED Torch

2.0Ah, 4.0Ah Battery & Fast

Charger

WHAT’S IN THE BOX

IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU

MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS

WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO

RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE

OUR CUSTOMER SERVICE HELPLINE:

Australia 1800 069 486

New Zealand 0508 069 486

WARRANTY

TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL

NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER

SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND

ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE

WARRANTY POLICY OR PROCEDURE.

OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.

The benets provided under this warranty are in addition to other rights and

remedies which are available to you at law.

Our goods come with guarantees that cannot be excluded at law. You are entitled to

a replacement or refund for a major failure and for compensation for any other

reasonably foreseeable loss or damage. You are also entitled to have the goods

repaired or replaced if the goods fail to be of acceptable quality and the failure

does not amount to a major failure.

Generally you will be responsible for all costs associated with a claim under this

warranty, however, where you have suffered any additional direct loss as a result of

a defective product you may be able to claim such expenses by contacting our

customer service helpline above.

0317

WARNING

The following actions will result in the warranty being

void.

• If the tool has been operated on a supply voltage other than that specied

on the tool.

• If the tool shows signs of damage or defects caused by or resulting from

abuse, accidents or alterations.

• Failure to perform maintenance as set out within the instruction manual.

• If the tool is disassembled or tampered with in any way.

5 YEAR REPLACEMENT WARRANTY

Your Product is guaranteed for a period of 60 months from the original date of

purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it

will be replaced in accordance with the terms of this warranty. Lithium Ion

batteries and chargers are covered by a 36 month

warranty and are excluded from the warranty extension. Warranty excludes

consumable parts.

KNOW YOUR PRODUCT SETUP & PREPARATION

1. ASSEMBLY

CORDLESS ANGLE GRINDER (PXAGS-500)

1 2 3 4 5 6

1 Spindle Lock

2 Guard Locking Lever

3 Side Handle

4 Lock On Slide Switch

5 Sure Grip Handle

6 Battery Seating

7 Pin Wrech

Inserting & Removing the Battery

1 Align the ribs of the battery with

the recess at the back of the

angle grinder & push in until it

clicks into place.

2 To remove, press and hold the

battery release tab and then

slide out.

1 Loosen the safety guard locking

lever to allow it to spin.

1 To t, screw the side handle

clockwise into 1 of 3 handle

positions.

2 Rotate the guard into the desired

position & secure in place with

the locking lever.

2 To remove, screw the handle

anti-clockwise.

Fitting and Removing the Side Handle

Adjusting the Safety Guard

WARNING! ENSURE THE TOOL IS SWITCHED OFF AND

THE BATTERY IS REMOVED BEFORE PERFORMING ANY

OF THE FOLLOWING TASKS.

WARNING! DO NOT OPERATE THE ANGLE GRINDER

WITHOUT THE SAFETY GUARD FITTED AS POSSIBLE

INJURIES COULD OCCUR.

ONLINE MANUAL

Scan this QR Code with your

mobile device to take you to the

online manual.

8 2.0Ah Battery

9 4.0Ah Battery

10 Fast Charger

BATTERY & CHARGER

8 9 10

CAUTION: THE CHARGER FOR THIS PRODUCT SHOULD

BE PROTECTED BY A RESIDUAL CURRENT DEVICE

(RATED AT 30MA OR LESS).

1 Connect the charger into a mains power outlet.

4 The charger LED will illuminate

red signifying that the battery is

charging.

3 With the charger sitting on a at

surface, align the raised ribs on

the battery with the recess in the

charger and slide onto the charger

ensuring a rm connection.

2 The charger LED will ash green

showing power is being supplied

to the charger.

5 The charger LED will illuminate

green once the battery is fully

charged.

Charging your lithium ion battery - Fast Charger

Charger LED Indicator

LED Indicator Situation

GREEN (Flashing) Stand By (no battery pack is inserted)

RED (Flashing) Battery is charging (low charge)

RED (Illuminated) Battery is charging (mid charge)

GREEN (Illuminated) Battery is fully charged

BOTH(Illuminated) Battery pack is too hot or too cold (charging will begin

automatically when battery reaches correct charging

temperature).

BOTH (Flashing) Defective battery. Never charge a defective battery

pack!

Remove battery pack from charger.

3. BATTERY & CHARGING2. REPLACING A GRINDING DISC

2 Using the pin wrech loosen

the ange by rotating it anti

-clockwise.

4 Screw the ange back onto the spindle and tighten using the pin wrech

while holding the spindle lock down.

1 Depress and hold the

spindle lock to prevent

the spindle spinning.

3 Remove the ange and

replace the grinding disc

on the spindle.

Battery Charge Indicator

The purchased battery is equipped with a

battery charge indicator to show the state of

the battery charge.

Press the charge indicator button and look to

see which LED lights.

Battery requires

immediate charging

Low state of charge, requires charging soon.

Mid state of charge

Full state of charge.

Note: The battery needs to be removed from the tool to check the state of charge.

1 Connect the charger into a mains power outlet.

4 The charger LED will illuminate red signifying that the battery is charging.

3 With the battery sitting on a at

surface, align the raised ribs on the

battery with the recess in the charger

and slide onto the battery ensuring a

rm connection.

2 The charger LED will ash green

showing power is being supplied

to the charger.

5 When removing the charger from the

battery, rst press the battery release

tab, then slide the charger from its

position.

Charging your lithium ion battery - Eco Charger

Charger LED Indicator

LED Indicator Situation

GREEN (Flashing) Stand By (no battery pack is inserted)

RED (Illuminated) Battery is charging (low charge)

GREEN (Illuminated) Battery is fully charged

RED (Flashing) Battery or Charger fault

RED & GREEN (Flashing) Battery pack is too hot or too cold (remove battery from

charger and store at room temperature 20ºC. Insert

battery again when at correct charging temperature). If

this happens again, the battery is defective and needs

to be replaced.

OPERATION

1 To turn on, slide the lock-on

switch across to the right and

then forward.

1 Ensure the workpiece is securely

held down.

2 To turn off, slide the lock-on

switch back and to the left.

2 Hold the angle grinder

rmly with both handles

and switch on.

3 Begin grinding your workpiece. The optimum grinding angle is 10-150to

the workpiece.

Note: Do not apply excessive pressure. Allow the tool to do the work, this

will prevent deep gouging.

10-150

4. GRINDING

Turning On and Off

Grinding Procedure

PX5PAK-005

Power tools that are no longer usable should not be disposed of with

household waste but in an environmentally friendly way. Please recycle

where facilities exist. Check with your local council authority for

recycling advice.

Recycling packaging reduces the need for landll and raw materials.

Reuse of recycled material decreases pollution in the environment.

Please recycle packaging where facilities exist. Check with your local

council authority for recycling advice.

DESCRIPTION OF SYMBOLS

CARING FOR THE ENVIRONMENT

BATTERY & CHARGER SAFETY WARNINGS

TROUBLESHOOTING

Spare parts can be ordered from the Special Orders

Desk at your local Bunnings Warehouse.

For further information, or any parts not listed here,

visit www.ozito.com.au or contact Ozito Customer

Service:

Australia 1800 069 486

New Zealand 0508 069 486

E-mail: [email protected]

SPARE PARTS

THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR

YOUR BATTERY CHARGER.

1. Before using the charger read all instructions and cautionary markings on the charger, battery pack

and the product using the battery pack.

2. This charger is not intended for any uses other than charging rechargeable batteries. Any other use

may result in risk of re, electric shock or electrocution.

3. Do not place any object on top of the charger or place the charger on a soft surface that may result

in excessive internal heat. Place the charger in a position away from any heat source.

4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when

disconnecting the charger.

5. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected

to damage or stress.

6. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord

could result in the risk of re, electric shock or electrocution.

7. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in

any way. Have it checked by an electrician or power tool repairer.

8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is

required. Incorrect reassembly may result in a risk of electric shock, electrocution or re.

9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning.

Removing the battery pack will not reduce this risk.

10. Never attempt to connect 2 chargers together.

11. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed

40ºC (such as inside sheds or metal buildings in summer).

12. The charger is designed to operate on standard household electrical power (240 volts). Do not

attempt to use it on any other voltage!

13. The battery pack is not fully charged out of the carton. First read the safety instructions and then

follow the charging notes and procedures.

14. The longest life and best performance can be obtained if the battery pack is charged when the air

temperature is between 18 - 24ºC. Do not charge the battery pack in an air temperature below 10ºC

or above 40ºC. This is important and will prevent damage to the battery pack.

15. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery

can explode in a re.

16. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or

cracks, immediately discontinue use and do not recharge.

17. During charging, the battery must be placed in a well ventilated area.

LED lights do not illuminate on charger

Check the charging adaptor is securely plugged into the wall out let.

Check the battery is rmly connected to the charging cradle.

Check that the charging jack is securely connected to the charging cradle.

The battery has a short run time

Ensure the battery is properly charged. It will take 4-5 charging cycles before the battery

reaches optimum charge and run time. On the initial charge, the battery requires 5 hours

of charging. Subsequent charging only requires 3-5 hours.

Sparking visible through the housing vents

A small amount of sparking may be visible through the housing vents.

This is normal and does not indicate a problem.

Spindle locking button will not depress

The spindle will need to be rotated until the lock can engage. Simply rotate the spindle

while applying a small amount of pressure on the spindle lock.

MAINTENANCE

• After each use, blow air through the tool housing to ensure it is free from all dust,

dirt, etc. Build up of dust, dirt particles may cause the tool to overheat and shorten

the life of the tool.

• If the housing of the angle grinder requires cleaning, do not use solvents but a moist

soft cloth or soft brush only.

• Never let any liquid get inside the tool, never immerse any part of the tool into liquid.

• When not in use, the angle grinder should be stored in a dry, frost free location not

within the reach of children.

WARNING! ALWAYS ENSURE THE TOOL HAS

COMPLETELY STOPPED AND THE BATTERY IS

REMOVED PRIOR TO ANY MAINTENANCE.

Note: Ozito Industries will not be responsible for any damage or injuries caused by

the repair of the angle grinder by an unauthorised person or by mishandling of the

angle grinder.

Warning

Read instruction manual

Milliamperes

Ah Amp hour

No load speed

VVolts Hz Hertz

ac/~ Alternating current

Direct current

dc/

/min

Always wear ear, eye and

a safety mask

Revolutions or

reciprocation per minute

Always wear gloves

Wear eye protection

Regulatory Compliance

Mark (RCM)

Battery protection system

The tool is equipped with the battery protection system, which helps to ensure a long service

life.

The output power automatically cuts off during operation when the tool and/or battery are

placed under the following situations:

• When the tool is overloaded:

If this occurs, release the trigger switch and remove causes of overload, then pull the

switch trigger again to restart.

• When the remaining battery capacity becomes low:

Recharge the battery pack.

Note: The battery protection system does not in any way damage the tool.

Note: The indicated capacity may be lower than the actual level during use or immediately

after using the tool.

WARNING! When using mains-powered tools, basic safety precautions, including the

following, should always be followed to reduce risk of ﬁre, electric shock, personal injury

and material damage.

Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.

Save these instructions and other documents supplied with this tool for future reference.

The charger has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating

plate.

Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.

This tools charger is double insulated in accordance with AS/NZS 60745-1;

therefore no earth wire is required.

If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.

Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for

added protection against injury resulting from a possible electrical insulation failure within the tool.

The power supply for this products charger should be protected by a residual current device (rated at 30mA

or less). A residual current device reduces the risk of electric shock.

GENERAL POWER TOOL SAFETY WARNINGS

ELECTRICAL SAFETY

WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and

instructions may result in electric shock, re and/or serious injury.

Save all warnings and instructions for future reference. The term “power tool” in the

warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power

tool.

1. Work area safety

a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.

b. Do not operate power tools in explosive atmospheres, such as in the presence of ﬂammable

liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose

control.

2. Electrical safety

a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will reduce risk

of electric shock.

b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and

refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of

electric shock.

d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the

risk of electric shock.

e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of

a cord suitable for outdoor use reduces the risk of electric shock.

f. If operating a power tool in a damp location is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces the risk of electric shock.

3. Personal safety

a. Stay alert, watch what you are doing and use common sense when operating a power tool.

Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol or

medication. A moment of inattention while operating power tools may result in serious personal injury.

b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust

mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.

c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to

power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your

nger on the switch or energising power tools that have the switch on invites accidents.

d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may result in personal injury.

e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the

power tool in unexpected situations.

f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves

away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

g. If devices are provided for the connection of dust extraction and collection facilities, ensure

these are connected and properly used. Use of dust collection can reduce dust-related hazards.

4. Power tool use and care

a. Do not force the power tool. Use the correct power tool for your application. The correct power

tool will do the job better and safer at the rate for which it was designed.

b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be

controlled with the switch is dangerous and must be repaired.

c. Disconnect the plug from the power source and/or the battery pack from the power tool

before making any adjustments, changing accessories, or storing power tools. Such preventive

safety measures reduce the risk of starting the power tool accidentally.

d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with

the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands

of untrained users.

e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts

and any other condition that may affect the power tool’s operation. If damaged, have the

power tool repaired before use. Many accidents are caused by poorly maintained power tools.

f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to

bind and are easier to control.

g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,

taking into account the working conditions and the work to be performed. Use of the power tool for

operations different from those intended could result in a hazardous situation.

5. Battery tool use and care

a. Recharge only with the charger speciﬁed by the manufacturer. A charger that is suitable for one type of

battery pack may create a risk of re when used with another battery pack.

b. Use power tools only with speciﬁcally designated battery packs. Use of any other battery packs may

create a risk of injury and re.

c. When battery pack is not in use, keep it away from other metal objects, like paper clips,

coins, keys, nails, screws or other small metal objects, that can make a connection from one

terminal to another. Shorting the battery terminals together may cause burns or a re.

d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact

accidentally occurs, ﬂush with water. If liquid contacts eyes, additionally seek medical help.

Liquid ejected from the battery may cause irritation or burns.

6. Service

a. Have your power tool serviced by a qualiﬁed repair person using only identical replacement

parts. This will ensure that the safety of the power tool is maintained.

ANGLE GRINDER SAFETY WARNINGS

WARNING! a) This power tool is intended to function as a grinder, sanding or cut-off

tool. Read all safety warnings, instructions, illustrations and speciﬁcations provided with

this power tool.

Failure to follow all instructions listed below may result in electric shock, ﬁr and/or serious injury.

b) Operations such as wire brushing, or polishing are not recommended to be performed with this

power tool. Operations for which the power tool was not designed may create a hazard and cause personal injury.

c) Do not use accessories which are not speciﬁcally designed and recommended by the tool

manufacturer. Just because the accessory can be attached to your power tool, it does not assure safe operation.

d) The rated speed of the accessory must be at least equal to the maximum speed marked on the

power tool. Accessories running faster than their rated speed can break and y apart

e) The outside diameter and the thickness of your accessory must be within the capacity rating of

your power tool. Incorrectly sized accessories cannot be adequately guarded or controlled.

f) The arbour size of wheels, ﬂanges, backing pads or any other accessory must properly ﬁt the

spindle of the power tool. Accessories with arbour holes that do not match the mounting hardware of the power tool will run out

of balance, vibrate excessively and may cause loss of control.

g) Do not use a damaged accessory. Before each use inspect the accessory such as abrasive wheels for chips and cracks,

backing pad for cracks, tear or excess wear, wire brush for loose or cracked wires. If power tool or accessory is dropped, inspect for

damage or install an undamaged accessory. After inspecting and installing an accessory, position yourself and bystanders away from the

plane of the rotating accessory and run the power tool at maximum no-load speed for one minute. Damaged accessories will normally

break apart during this test time.

h) Wear personal protective equipment. Depending on application, use face shield, safety goggles or safety glasses. As

appropriate, wear dust mask, hearing protectors, gloves and workshop apron capable of stopping small abrasive or work piece fragments.

The eye protection must be capable of stopping ying debris generated by various operations . The dust mask or respirator must be

capable of ltrating particles generated by your operation. Prolonged exposure to high intensity noise may cause hearing loss.

i) Keep bystanders a safe distance away from work area. Anyone entering the work area must wear personal

protective equipment. Fragments away and cause injury beyond immediate area of operation.

j) Hold power tool by insulated gripping surfaces only, when performing an operation where the

cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a “live” wire may make

exposed metal parts of the power tool “live” and shock the operator.

k) Never lay the power tool down until the accessory has come to a complete stop. The spinning accessory

may grab the surface and pull the power tool out of your control.

l) Do not run the power tool while carrying it at your side. Accidental contact with the spinning accessory could snag

your clothing, pulling the accessory into your body.

m) Regularly clean the power tool’s air vents. The motor’s fan will draw the dust inside the housing and excessive

accumulation of powdered metal may cause electrical hazards.

n) Do not operate the power tool near ﬂammable materials. Sparks could ignite these materials.

o) Do not use accessories that require liquid coolants. Using water or other liquid coolants may result in electrocution or shock.

Kickback and related warnings

Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or any other accessory. Pinching or snagging

causes rapid stalling of the rotating accessory which in turn causes the uncontrolled power tool to be forced in the direction opposite of

the accessory’s rotation at the point of the binding.

For example, if an abrasive wheel is snagged or pinched by the work piece, the edge of the wheel that is entering into the pinch point

can dig into the surface of the material causing the wheel to climb out or kick out. The wheel may either jump toward or away from

the operator, depending on direction of the wheel’s movement at the point of pinching. Abrasive wheels may also break under these

conditions. Kickback is the result of power tool misuse and/or incorrect operating procedures or conditions and can be avoided by taking

proper precautions as given below.

a)Maintain a ﬁrm grip on the power tool and position your body and arm to allow you to resist

kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or torque reaction during start-up. The

operator can control torque reactions or kickback forces, if proper precautions are taken.

b) Never place your hand near the rotating accessory. Accessory may kickback over your hand.

c) Do not position your body in the area where power tool will move if kickback occurs. Kickback will

propel the tool in direction opposite to the wheel’s movement at the point of snagging.

d) Use special care when working corners, sharp edges etc. Avoid bouncing and snagging the accessory. Corners,

sharp edges or bouncing have a tendency to snag the rotating accessory and cause loss of control or kickback.

e) Do not attach a saw chain woodcarving blade or toothed saw blade. Such blades create frequent kickback

and loss of control.

Additional safety instructions for grinding and abrasive cutting-off operations

a) Use only wheel types that are recommended for your power tool and the speciﬁc guard designed

for the selected wheel. Wheels for which the power tool was not designed cannot be adequately guarded and are unsafe.

b) The guard must be securely attached to the power tool and positioned for maximum safety, so

the least amount of wheel is exposed towards the operator. The guard helps to protect operator from broken wheel

fragments and accidental contact with wheel.

c) Wheels must be used only for recommended applications. For example: do not grind with the side of cut-off

wheel. Abrasive cut-off wheels are intended for peripheral grinding, side forces applied to these wheels may cause them to shatter.

d) Always use undamaged wheel ﬂanges that are of correct size and shape for your selected wheel.

Proper wheel anges support the wheel thus reducing the possibility of wheel breakage. Flanges for cut-off wheels may be different from

grinding wheel anges.

e) Do not use worn down wheels from larger power tools. Wheel intended for larger power tool is not suitable for

the higher speed of a smaller tool and may burst.

Additional safety instructions for abrasive cutting-off operations:

a) Do not “jam” the cut-off wheel or apply excessive pressure. Do not attempt to make an excessive depth of

cut. Overstressing the wheel increases the loading and susceptibility to twisting or binding of the wheel in the cut and the possibility of

kickback or wheel breakage.

b) Do not position your body in line with and behind the rotating wheel. When the wheel, at the point of

operation, is moving away from your body, the possible kickback may propel the spinning wheel and the power tool directly at you.

c) When wheel is binding or when interrupting a cut for any reason, switch off the power tool and

hold the power tool motionless until the wheel comes to a complete stop. Never attempt to remove the cut-off

wheel from the cut while the wheel is in motion otherwise kickback may occur. Investigate and take corrective action to eliminate the

cause of wheel binding.

d) Do not restart the cutting operation in the work piece. Let the wheel reach full speed and carefully reenter the

cut. The wheel may bind, walk up or kickback if the power tool is restarted in the work piece.

e) Support panels or any oversized work piece to minimize the risk of wheel pinching and kickback.

Large work pieces tend to sag under their own weight. Supports must be placed under the work piece near the line of cut and near the

edge of the work piece on both sides of the wheel.

f) Use extra caution when making a “pocket cut” into existing walls or other blind areas. The protruding

wheel may cut gas or water pipes,electrical wiring or objects that can cause kickback.

Additional safety instructions for sanding operations

a) Do not use excessively oversized sanding disc paper. Follow manufacturers recommendations, when selecting

sanding paper. Larger sanding paper extending beyond the sanding pad presents a laceration hazard and may cause snagging, tearing of

the disc or kickback.

We highly recommend that when using abrasive cutting wheels, that a cutting guard should be

ﬁtted to your angle grinder. These cutting guards are available as a spare part and can be ordered

through the special orders desk

SPECIFICATIONS

Voltage: 18V

No Load Speed: 4,200/min

Blade Diameter: 150mm (6”)

Blade Bore: 10mm

Depth of Cut: 48mm @ 90°

32mm @ 45°

Charge Time: 40mins (2.0Ah)

80mins (4.0Ah)

Weight: 2.4kg

CORDLESS

CIRCULAR SAW

INSTRUCTION MANUAL

ozito.com.au

WHAT’S IN THE BOX

IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU

MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS

WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO

RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE

OUR CUSTOMER SERVICE HELPLINE:

Australia 1800 069 486

New Zealand 0508 069 486

WARRANTY

TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL

NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER

SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND

ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE

WARRANTY POLICY OR PROCEDURE.

OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.

The benets provided under this warranty are in addition to other rights and

remedies which are available to you at law.

Our goods come with guarantees that cannot be excluded at law. You are entitled to

a replacement or refund for a major failure and for compensation for any other

reasonably foreseeable loss or damage. You are also entitled to have the goods

repaired or replaced if the goods fail to be of acceptable quality and the failure

does not amount to a major failure.

Generally you will be responsible for all costs associated with a claim under this

warranty, however, where you have suffered any additional direct loss as a result of

a defective product you may be able to claim such expenses by contacting our

customer service helpline above.

0317

WARNING

The following actions will result in the warranty being

void.

• If the tool has been operated on a supply voltage other than that specied

on the tool.

• If the tool shows signs of damage or defects caused by or resulting from

abuse, accidents or alterations.

• Failure to perform maintenance as set out within the instruction manual.

• If the tool is disassembled or tampered with in any way.

5 YEAR REPLACEMENT WARRANTY

Your Product is guaranteed for a period of 60 months from the original date of

purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it

will be replaced in accordance with the terms of this warranty. Lithium Ion

batteries and chargers are covered by a 36 month

warranty and are excluded from the warranty extension. Warranty excludes

consumable parts, for example: cutting blades.

PX5PAK-005

Cordless Drill Driver

& Impact Driver

Cordless Angle Grinder

Cordless Circular Saw

& LED Torch

2.0Ah, 4.0Ah Battery & Fast

Charger

The purchased battery will be shipped in a low charge condition, and requires charging

prior to use. Allow several cycles of charging and discharging (through use of the tool)

for the battery to reach its optimum performance / runtime.

CAUTION: THE CHARGER FOR THIS PRODUCT SHOULD

BE PROTECTED BY A RESIDUAL CURRENT DEVICE

(RATED AT 30MA OR LESS).

1 Connect the charger into a mains power outlet.

4 The charger LED will illuminate

red signifying that the battery is

charging.

3 With the charger sitting on a at

surface, align the raised ribs on

the battery with the recess in the

charger and slide onto the charger

ensuring a rm connection.

2 The charger LED will ash green

showing power is being supplied

to the charger.

5 The charger LED will illuminate

green once the battery is fully

charged.

Charging your lithium ion battery - Fast Charger

Charger LED Indicator

LED Indicator Situation

GREEN (Flashing) Stand By (no battery pack is inserted)

RED (Flashing) Battery is charging (low charge)

RED (Illuminated) Battery is charging (mid charge)

GREEN (Illuminated) Battery is fully charged

BOTH(Illuminated) Battery pack is too hot or too cold (charging will begin

automatically when battery reaches correct charging

temperature).

BOTH (Flashing) Defective battery. Never charge a defective battery

pack!

Remove battery pack from charger.

KNOW YOUR PRODUCT

1. BATTERY & CHARGING

SETUP & PREPARATION

CORDLESS CIRCULAR SAW (PXCSS-500)

10 11 12 14 1513

2 3 4 5 6 7 8 9

1 Battery Seating

2 Rear Handle

3 Dust Port

4 On/Off Trigger

5 Lock-Off Lever

6 Hex Key Holder

7 Front Handle

8 Bevel Locking Knob

9 Rip Fence Locking Knob

10 Depth Locking Lever

11 Blade Guard Lever

12 Lower Blade Guard

13 Blade

14 Upper Blade Guard

15 Cutting Guide Notch

For optimal performance, we recommend the use of a 3.0Ah battery or

higher to operate this Power X Change Circular Saw.

ONLINE MANUAL

Scan this QR Code with your

mobile device to take you to the

online manual.

16 2.0Ah Battery

17 4.0Ah Battery

18 Fast Charger

BATTERY & CHARGER

16 17 18

2. FITTING THE BATTERY & GUIDE

Battery Charge Indicator

The purchased battery is equipped with a

battery charge indicator to show the state of

the battery charge.

Press the charge indicator button and look to

see which LED lights.

Battery requires

immediate charging

Low state of charge, requires charging soon.

Mid state of charge

Full state of charge.

Note: The battery needs to be removed from the tool to check the state of charge.

1 Connect the charger into a mains power outlet.

4 The charger LED will illuminate red signifying that the battery is charging.

3 With the battery sitting on a at

surface, align the raised ribs on the

battery with the recess in the charger

and slide onto the battery ensuring a

rm connection.

2 The charger LED will ash green

showing power is being supplied

to the charger.

5 When removing the charger from the

battery, rst press the battery release

tab, then slide the charger from its

position.

Charging your lithium ion battery - Eco Charger

Charger LED Indicator

LED Indicator Situation

GREEN (Flashing) Stand By (no battery pack is inserted)

RED (Illuminated) Battery is charging (low charge)

GREEN (Illuminated) Battery is fully charged

RED (Flashing) Battery or Charger fault

RED & GREEN (Flashing) Battery pack is too hot or too cold (remove battery from

charger and store at room temperature 20ºC. Insert

battery again when at correct charging temperature). If

this happens again, the battery is defective and needs

to be replaced.

Inserting & Removing the Battery

1 Slide the battery into the seating

at the back of the saw until it

clicks into place.

2 To remove, press and

hold the battery release

tab and then slide out.

The rip fence allows you to perform straight cuts with ease.

Attaching the Rip Fence

2 Once the desired

width is set, tighten

the locking knob to

secure in place.

1 Insert the rip fence through the

rip fence slots in the front of the

baseplate.

3 To remove, loosen the locking

knob and then slide the rip fence

out.

4. CONTROLS

WARNING! ENSURE THE TOOL IS SWITCHED OFF AND

THE BATTERY IS REMOVED BEFORE PERFORMING ANY

OF THE FOLLOWING TASKS.

WARNING! AFTER USE, HOLD THE SAW AWAY FROM

YOUR BODY UNTIL THE BLADE STOPS COMPLETELY.

3. DEPTH & BEVEL ADJUSTMENT

Depth Adjustment

Bevel Adjustment

3 Tighten depth

adjustment knob to

secure in place.

1 Loosen the depth adjustment

lever.

1 Loosen bevel adjustment knob.

3 Tighten the bevel adjustment

knob.

2 Hold the baseplate down with

one hand. Raise or lower the saw

to the desired depth.

2 Align baseplate to desired angle

on bevel scale.

Depth should be adjusted so that no more than one tooth is protruding

through the timber. This helps to minimise splintering.

Turning On and Off

2 Squeeze the on/off

trigger to start the

saw.

Note: Allow the saw to reach full speed before beginning a cut.

1 Press and hold the lock-off level

in either direction.

3 To stop the saw, release the on/

off trigger.

The cutting guide will give an approximate line of cut. For a straight cut, use

the 0° notch. For a 45° cut, use the 45° notch. For higher accuracy, use the rip

fence provided.

Cutting Guide Notch

0o45o

PX5PAK-005

5. MAKING A CUT 6. BLADE FITMENT

OPERATION

2 Adjust the saw

depth and bevel

angle for the

desired cut.

4 Hold the saw

securely with both

hands and start the

tool.

1 Mark the cutting line on the work

piece.

3 Attach the rip fence for an

additional guide.

5 Move the saw through the

material to perform the cut.

Once complete, release the on/

off trigger and remove the saw

from the work piece.

Note: Allow the saw to reach full speed before beginning a cut.

Note: Never force the saw. Use light and continuous pressure.

1 Press and hold the spindle lock.

5 Fit outer blade ange and blade

bolt.

3 Retract lower blade guard fully.

4 Remove and replace blade.

Ensure arrows on the blade point

in the same direction as the

arrow on the upper blade guard.

2 Use hex key to rotate blade until

lock engages. Remove blade bolt

and outer blade ange.

6 Depress spindle lock and Tighten

blade bolt with the hex key.

The tool is recommended for wood cutting only and is not recommended

for use with abrasive wheels or masonry/diamond cutting wheels. Only use

150mm wood cutting blades.

TROUBLESHOOTING

• Keep ventilation slots of the circular saw clean at all times to ensure efcient

operation.

• After each use, blow air through the tool housing to ensure it is free from all dust,

dirt, etc. Build up of dust, dirt particles may cause the tool to overheat and shorten

the life of the tool.

• If the housing of the circular saw requires cleaning, do not use solvents but a moist

soft cloth or soft brush only.

• Never let any liquid get inside the tool, never immerse any part of the tool into liquid.

• No lubrication is necessary as the tool has sealed bearings.

• When not in use, the circular saw should be stored in a dry, frost free location not

within the reach of children.

WARNING! ALWAYS ENSURE THE TOOL HAS

COMPLETELY STOPPED AND THE BATTERY IS

REMOVED PRIOR TO ANY MAINTENANCE.

Battery protection system

The tool is equipped with the battery protection system, which helps to ensure a long service

life.

The output power automatically cuts off during operation when the tool and/or battery are

placed under the following situations:

• When the tool is overloaded:

If this occurs, release the trigger switch and remove causes of overload, then pull the

switch trigger again to restart.

• When the remaining battery capacity becomes low:

Recharge the battery pack.

Note: The battery protection system does not in any way damage the tool.

Note: The indicated capacity may be lower than the actual level during use or immediately

after using the tool.

LED lights do not illuminate on charger

Check the charging adaptor is securely plugged into the wall out let.

Check the battery is rmly connected to the charging cradle.

Check that the charging jack is securely connected to the charging cradle.

The battery has a short run time

Ensure the battery is properly charged. It will take 4-5 charging cycles before the battery

reaches optimum charge and run time. On the initial charge, the battery requires 5 hours

of charging. Subsequent charging only requires 3-5 hours.

Sparking visible through the housing air vents

A small amount of sparking may be visible through the housing vents. This is normal

and does not indicate a problem.

Circular Saw Tips

Always hold the soft grip handle with one hand and the front handle with the other.

Maintain a rm grip and operate the on/off switch with a positive action.

Never force the saw. Use light and continuous pressure.

When cutting is interrupted, to resume cutting, depress the lock-off button and squeeze

the on/off switch and allow the blade to reach full speed, re-enter the cut slowly and

resume cutting.

When cutting across the grain, the bres of the wood have a tendency to tear and lift.

Advancing the saw slowly minimizes this effect. For a nished cut, a cross cut blade or

mitre blade is recommended.

Note: Ozito Industries will not be responsible for any damage or injuries

caused by the repair of the circular saw by an unauthorised person or by mishandling

of the circular saw.

MAINTENANCE

Power tools that are no longer usable should not be disposed of with

household waste but in an environmentally friendly way. Please recycle

where facilities exist. Check with your local council authority for

recycling advice.

Recycling packaging reduces the need for landll and raw materials.

Reuse of recycled material decreases pollution in the environment.

Please recycle packaging where facilities exist. Check with your local

council authority for recycling advice.

DESCRIPTION OF SYMBOLS

CARING FOR THE ENVIRONMENT

Spare parts can be ordered from the Special Orders

Desk at your local Bunnings Warehouse.

For further information, or any parts not listed here,

visit www.ozito.com.au or contact Ozito Customer

Service:

Australia 1800 069 486

New Zealand 0508 069 486

E-mail: [email protected]

SPARE PARTS

THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR

BATTERY CHARGER.

1. Before using the charger read all instructions and cautionary markings on the charger, battery pack

and the product using the battery pack.

2. This charger is not intended for any uses other than charging rechargeable batteries. Any other use

may result in risk of re, electric shock or electrocution.

3. Do not place any object on top of the charger or place the charger on a soft surface that may result in

excessive internal heat. Place the charger in a position away from any heat source.

4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when

disconnecting the charger.

5. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected

to damage or stress.

6. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord

could result in the risk of re, electric shock or electrocution.

7. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any

way. Have it checked by an electrician or power tool repairer.

8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is

required. Incorrect reassembly may result in a risk of electric shock, electrocution or re.

9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning.

Removing the battery pack will not reduce this risk.

10. Never attempt to connect 2 chargers together.

11. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed

40ºC (such as inside sheds or metal buildings in summer).

12. The charger is designed to operate on standard household electrical power (240 volts). Do not attempt

to use it on any other voltage!

13. The battery pack is not fully charged out of the carton. First read the safety instructions and then

follow the charging notes and procedures.

14. The longest life and best performance can be obtained if the battery pack is charged when the air

temperature is between 18 - 24ºC. Do not charge the battery pack in an air temperature below 10ºC or

above 40ºC. This is important and will prevent damage to the battery pack.

15. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery

can explode in a re.

16. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or

cracks, immediately discontinue use and do not recharge.

17. During charging, the battery must be placed in a well ventilated area.

BATTERY AND CHARGER SAFETY WARNINGS

Warning Read instruction manual

Diameter

mA Milliamperes

Recycle battery Do not put in the rubbish

Do not incinerate Do not get battery wet

Thermal cut-out protection

Transformer Energy

Rating (MEPS)

Double insulated

Ah Amp hour

Indoor use only

Lithium Ion battery Do not use or store battery in

temperatures exceeding 50ºC

no No load speed

VVolts Hz Hertz

ac/~ Alternating current WWatts

Direct current

dc/

Do not expose to rain.

Regulatory Compliance

Mark (RCM)

WARNING! When using mains-powered tools, basic safety precautions, including the

following, should always be followed to reduce risk of ﬁre, electric shock, personal injury

and material damage.

Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.

Save these instructions and other documents supplied with this tool for future reference.

The charger has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating

plate.

Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.

This tools charger is double insulated; therefore no earth wire is required.

If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.

Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for

added protection against injury resulting from a possible electrical insulation failure within the tool.

Using an Extension Lead

Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the extension lead for signs of

damage, wear and ageing. Replace the extension lead if damaged or defective.

When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power

input of the tool or which is damaged or defective may result in a risk of re and electric shock.

The power supply for this products charger should be protected by a residual current device (rated at 30mA or less). A residual current

device reduces the risk of electric shock.

GENERAL POWER TOOL SAFETY WARNINGS

ELECTRICAL SAFETY

WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and

instructions may result in electric shock, re and/or serious injury.

Save all warnings and instructions for future reference. The term “power tool” in the warnings

refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
