Ozito PXC PXBRDS-018 User manual

STANDARD EQUIPMENT
PXBRDS-018
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
AM Frequency: 522-1620 KHz
FM Frequency: 87.5-108 MHz
Power Consumption: 15W
Speaker Output: 10W
Weight: 0.89kg
ozito.com.au
0223
Cordless Bluetooth Radio
2 X AAA Batteries
BLUETOOTH
RADIO
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO INDUSTRIES PTY. LTD. 25 Fox Drive, Dandenong South, VIC 3175, Australia.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts.

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
Note:
The AAA batteries are used for clock and channel memory only. An
18V PXC Battery is required for use of the main radio functions.
Installing the 2 X AAA Batteries (for clock and memory
function)
1. AAA Batteries sit in a
compartment at the base of radio
housing. AAA batteries must be
installed whilst there is no 18V
battery pack tted.
Note:
Must be installed whilst there is no 18V battery pack tted.
2. Open AAA battery compartment
housing.
3. Install AAA batteries.
Installing the 18V Battery Pack
1. Holding the radio housing, slide
the battery into the base of the
radio until it clicks into place.
Removing the Battery Pack
1. Press down on the battery
release button.
2. Holding the radio housing, slide
the battery pack out.
1. On/Off Switch
2. Control Panel
3. LCD Display Screen
4. Antenna (not shown)
5. Carry Handle
6. Speaker
This tool is compatible with all batteries & chargers from the Ozito PXC range.
CORDLESS BLUETOOTH RADIO
BATTERY & CHARGER
ACCESSORIES
KNOW YOUR PRODUCT
1. POWERING THE DEVICE
SETUP & PREPARATION
3
4
5
61
2
8 7
7. Battery Seating
8. AAA Battery Compartment
9. 2 x AAA Batteries
10. Strap for Smartphone (not
shown)
9

Connecting the Bluetooth to your Smartphone
The radio will automatically go into Bluetooth pairing mode when Bluetooth
mode is selected.
1. Select the Bluetooth pairing
mode.
2. The Bluetooth sign will ash
when Bluetooth mode is
selected.
3. Turn on Bluetooth functionality
on your media device and search for
the ‘PXC Cordless Radio’ to connect
to the radio.
Note:
Only 1 device can be paired via Bluetooth at any time. Turn off Bluetooth on
the rst connected device to pair a new device with the speaker.
On/Off Switch
1. To turn the radio on, ick the on/
off switch up and display will
illuminate.
2. To turn off, ick the on/off switch
down.
Note:
The time will still be shown on the LCD display even when radio is switched
off if the AAA batteries are inserted
Volume
1. To increase the volume, press
the Volume + button until desired
volume is reached.
2. To decrease the volume, press
the Volume - button until desired
volume is reached.
3. To mute the sound, press Mute
button
4. To return sound to previous
volume, press Mute button again
or any other button on the display
panel
Mode and Tuning
1. To alternate between AM or FM
frequencies, press the Mode
button.
2. To nd a station, scroll through a
frequency by pressing the Seek
buttons.
2. CONNECTING AUDIO DEVICES 3. CONTROLS
OPERATION
FM AM
FM AM
FM AM
FM AM
FM AM
FM AM

Setting up Favourite Stations
You can program this product to remember up to ten radio stations on both
the AM and FM modes using the Channel memory system.
1. Turn the radio on,
2.
Press the Channel button once to
open the rst memory setting - Mem
1.
3. Using the Seek buttons, nd a radio
station you would like to save.
4. Press and hold the Channel button
until the memory number ashes.
5. Press the Channel button again to
save the radio station as this memory
number.
6. To save the next station, press
Channel button once until next
memory number shows on LCD
display screen.
7. Using the Seek buttons, nd the next
radio station to save.
8. Press and hold the Channel button
until the memory number ashes.
Press Channel button again to save
this station.
Note:
Up to 10 radio stations can be saved on both the AM and FM modes.
Repeat steps 6 to 8 as necessary to program more stations to the radio’s
memory.
9. After programming stations to memory, press the Channel button to search through
the saved radio stations.
Note:
The radio is able to automatically search and save radio stations to memory.
Press and hold the Mode button.
1. Turn the radio off.
Note:
For the time to be saved the AAA batteries must be inserted prior to setting
the time.
2. Press and hold the Clock button
until the time starts ashing on
the LCD display screen.
3. Use the Hour
(or Volume -) button to change
the hour.
4. Use the Minutes
(or Volume +) button to change
the minutes.
5. Once desired time is reached,
press the Clock button again to
save.
5.PROGRAMMING4.SETTING THE TIME
FM AM
FM AM
FM AM
FM AM
FM AM
FM AM
FM AM
FM AM
FM AM
PXBRDS-018

Cleaning
• Keep the ventilation slots of the tool clean at all times to ensure efcient
operation.
• After each use, blow air through the tool housing to ensure it is free from
all dust, dirt, etc. Build up of dust or dirt particles may cause the tool to
overheat and shorten the life of the tool.
• If the housing of the tool requires cleaning, do not use solvents. Use of a
cloth only is recommended.
• Never allow any liquid to get inside the tool, never immerse any part of
the tool into liquid.
• Keep ventilation slots of the radio clean at all times and prevent anything
from entering.
• If the housing of the radio requires cleaning, do not use solvents. Use of
a cloth only is recommended.
• Blow out the ventilation slots with compressed air periodically .
Storage
When not in use, the tool should be stored in a dry, frost free location, keep
out of children’s reach.
Note: Be careful not to bend the end of the magazine. If this occurs the
unit will be inoperable.
Short Battery Runtime
Ensure the battery is properly charged. It will take 4-5 charging cycles
before the battery reaches optimum charge and run time.
DESCRIPTION OF SYMBOLS
Warning
Direct Current
Volts Hertz
Read instruction manual
Ah Amp hour
Regulatory Compliance
Mark (RCM)
VHz
WattsW
Kilohertz
KHz MegahertzMHz
Power tools that are no longer usable should not be disposed
of with household waste but in an environmentally friendly
way. Please recycle where facilities exist. Check with your local
council authority for recycling advice.
Recycling packaging reduces the need for landll and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
CARING FOR THE ENVIRONMENT
SPARE PARTS
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse.
For further information, or any parts not listed here,
visit www.ozito.com.au or contact Ozito Customer
Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
WARNING! ENSURE THE TOOL IS SWITCHED
OFF AND THE BATTERY IS REMOVED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
WARNING! BEFORE CLEANING OR CARRYING OUT
ANY MAINTENANCE PROCEDURE, ENSURE THAT
THE BATTERIES HAVE BEEN REMOVED.
LED lights do not illuminate on charger
Check the charging adaptor is securely plugged into the wall outlet.
Check the battery is rmly connected to the charging cradle.
Check that the charging jack is securely connected to the charging cradle.
The battery has a short run time
Ensure the battery is properly charged. It will take 4-5 charging cycles
before the battery reaches optimum charge and run time.
MAINTENANCETROUBLESHOOTING

WARNING! Keep the radio housing and handle dry, clean and free from grease and
oil. Always use a clean cloth cleaning. Never use brake fluid, gasoline, petroleum-based
products, or any strong solvents to clean your radio.
Following this rule will reduce the risk of loss of control and deterioration of the enclosure plastic.
• Do not use radio near water.
• Do not install near any heat sources such as radiators, heat registers or other products
(including amplifiers) that produce heat.
• Only use attachments/accessories specified by the manufacturer.
• To reduce the risk of personal injury and electric shock, do not expose to water or rain.
• Do not use the radio or listen to music or other audio programs while operating machinery.
Doing so may cause distractions that could result in personal injury.
• This radio is capable of producing sound levels that can be dangerous to long-term hearing.
Listening to music at a high volume for any period of time may cause the listener noise-induced
hearing loss. The higher the volume, the less time required before your hearing may be
affected.
• This appliance is not intended for use by young or infirm persons unless supervised by a
responsible person to ensure that they can use the appliance safely. Young children should be
supervised to ensure that they do not play with the appliance.
WARNING! Read all safety warnings, instructions, illustrations and specifications
provided with this power tool. Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a
second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery pack, if detachable,
from the power tool before making any adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling and control of the tool in unexpected
situations.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connection from
one terminal to another. Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or
temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or tool outside the
temperature range specified in the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and increase the risk of fire.
6) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service of battery packs should only be performed by
the manufacturer or authorized service providers.
GENERAL POWER TOOL SAFETY WARNINGS
RADIO SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! When using electric tools basic safety precautions should always be followed
to reduce the risk of fire, electric shock and personal injury.
• Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency, before operating the tool. Save these instructions and other documents supplied
with this tool for future reference.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
• This appliance is compatible and only to be used with all batteries & chargers from the Ozito
PXC range. Refer to the PXC battery and charger manuals for information regarding charging,
use and storage.
• WARNING! Always remove the battery from the tool:
- when the batteries are to be charged,
- when the tool is left unattended,
- when the tool is being checked, cleaned, or having maintenance work done,
- when the tool is to be stored,
- or if the tool vibrates abnormally.
• Do not combine different types of batteries or new and used batteries.
• Do not use modified or damaged batteries.
