Ozito PXHVS-250 User manual

SPECIFICATIONS
Input: 18V
Air Flow: 8 L/sec
Dust Canister Capacity: 540ml
Weight: 0.85kg
CORDLESS
HAND VACUUM
INSTRUCTION MANUAL
ozito.com.au
WHAT’S IN THE BOX
Cordless Vacuum
Brush Tool
Crevice Tool
Mounting Bracket
PXHVS-250
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
0818
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts, for example: crevice tool.

1. FITTING THE BATTERY
Inserting & Removing The Battery
1 Align the ribs of the battery with the recess at the rear of the vacuum and
push in until it clicks into place.
2 To remove, press and hold the battery release tab and pull the battery
away from the vacuum.
a
b
KNOW YOUR PRODUCT SETUP & PREPARATION
CORDLESS HAND VACUUM
ACCESSORIES
1 2 3 4
7
5
8 9
6
1 Nozzle
2 Dust Canister
3 Dust Canister Release Button
4 On/Off Switch
5 Sure Grip Handle
6 Battery Seating
7 Brush Tool
8 Crevice Tool
9 Mounting Bracket
CAUTION: THE CHARGER FOR THIS PRODUCT
SHOULD BE PROTECTED BY A RESIDUAL CURRENT
DEVICE (RATED AT 30mA OR LESS).
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
BATTERY & CHARGER
This tool is compatible with all battery and chargers from the Ozito
Power X Change Range.

Using The Wall Mount
1 Place the mounting bracket against a wall and use screws to fasten it to
the wall.
Note: Use the appropriate screw type for the surface you are attaching the
bracket to. The recommended screw size is 4mm in diameter and at least
50mm long.
2 To store the vacuum, place the handle on the mounting bracket securely.
2. ASSEMBLY
Attaching Accessories
2 To remove simply pull the
accessory away from the
vacuum nozzle.
1 Align the accessory with the
vacuum nozzle and push into
place.
WARNING! ENSURE THE TOOL IS SWITCHED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.

PXHVS-250
4. OPERATION
Vacuuming
The vacuum is ideal for dirt, clippings and other debris.
WARNING! ENSURE THE VACUUM INLET IS NOT
BLOCKED DURING USE.
2 Move the vacuum slowly to
allow the dust or debris to be
lifted.
Note: Forcing the vacuum to move too fast over the dust and debris will
clog the nozzle of the dust canister.
1 Hold the vacuum rmly and
switch the vacuum on.
3. CONTROLS
OPERATION
Switching On and Off
WARNING! DO NOT PUT PART OF YOUR BODY SUCH
AS HANDS AND FINGERS NEAR THE INLET OPENING.
2 To stop the vacuum push the
on/off switch backward into
the off position.
1 To start the vacuum push the
on/off switch forward into the
on position.
WARNING! ENSURE THE TOOL IS SWITCHED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.

CARING FOR THE ENVIRONMENT
TROUBLESHOOTING
Power tools that are no longer usable should not be disposed of with household
waste but in an environmentally friendly way. Please recycle where facilities exist.
Check with your local council authority for recycling advice.
Recycling packaging reduces the need for landll and raw materials. Reuse of
recycled material decreases pollution in the environment. Please recycle packaging
where facilities exist. Check with your local council authority for recycling advice.
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse.
For further information, or any parts not listed here,
visit www.ozito.com.au or contact Ozito Customer
Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
• Keep air intake clean and air vents free of debris to avoid overheating the motor.
• Do not use cleaning agents to clean the plastic parts of the tool.
A mild detergent on a damp cloth is recommended. Water must never come into contact with
the tool.
• If the vacuum vibrates abnormally, stop motor immediately. Abnormal vibration usually
indicates a mechanical problem continued operation could lead to injury or damage.
WARNING! ALWAYS ENSURE THE TOOL HAS
COMPLETELY STOPPED AND THE BATTERY IS
REMOVED PRIOR TO ANY MAINTENANCE.
Problem Cause Remedy
Vacuum is not
starting
Battery is low in charge Charge battery
Battery not inserted
properly
Insert battery pack correctly
Possible clogging Clean the dust canister and lter cartridge.
Vacuum is not
operating at
full capacity
Possible clogging Clean the dust canister and lter cartridge.
Motor
stops while
vacuuming
Battery has no power Charge battery
Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the
vacuum by an unauthorised person or by mishandling of the vacuum. This tool is designed for DIY
use - use in commercial or industrial environments will void the warranty.
DESCRIPTION OF SYMBOLS
MAINTENANCE
Read instruction manual
Do not use in the rain or leave the blower outdoors while raining.
Wear eye and ear protection.
For best performance, empty the dust canister and clean the lter after each
use.
2 Remove the dust canister by
pulling the top of the container
away from the vacuum
housing.
1 Press and hold the dust
canister release button.
3 Pull the lter cartridge out
from the dust canister. Empty
the debris into a bin and rinse
the lter with cold water and
allow to air dry.
4 Place the lter back into the
dust canister, then ret the
dust canister by rst placing
the lower edge onto the
locating recess and then push
the top in until it clicks into
place.
Cleaning the Filter Cartridge

WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of fire, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The charger has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating
plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for
added protection against injury resulting from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the extension lead for signs of
damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power
input of the tool or which is damaged or defective may result in a risk of re and electric shock.
The power supply for this products charger should be protected by a residual current device (rated at 30mA
or less). A residual current device reduces the risk of electric shock.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will reduce risk
of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
5. Service
a. Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
VACUUM SAFETY WARNINGS
WARNING!
When using the equipment, a few safety precautions must be observed to avoid injuries and damage. Please read the
complete operating manual with due care. Keep this manual in a safe place so that the information is available at all times.
If you give the equipment to any other person, give them these operating instructions as well.
We cannot accept any liability for damage or accidents which arise due to a failure to follow these instructions and the
safety information.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
• Do not aim the hose at other persons or animals.
• Never pick up asbestos or asbestos dust.
• Wood dust and shavings in a confined area can give rise to fire or an explosion.
• Guard against possible ignition sources.
• Do not pick up any material that is burning or smouldering such as metal grinding dust,
cigarette ends, matches etc.
• Do not vacuum dry matter without the cartridge filter assembled.
• Always switch the unit off before changing attachments, filters and emptying the tank.
• Always check that the filter is clear and not blocked. Keep all openings clear of any
blockages.
• The equipment is to be used only for its prescribed purpose. Any other use is deemed to
be a case of misuse. The user / operator and not the manufacturer will be liable for any
damage or injuries of any kind caused as a result of this.
