Ozito VWD-1212 User manual

WET & DRY
VACUUM
1250W 12L
INSTRUCTION MANUAL
SPECIFICATIONS
Input Power: 1250W
Suction Power Max.: 140 mbar
Air Flow: 27 l/s
Tank Capacity: 12 l
Hose Length: 1.5m
Hose Diameter: 35mm
IP Rating: IPX4
Product weight: 2.7 kg
VWD-1212
WHAT’S IN THE BOX
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: Filters and dust
bag.
WARNING
The following actions will result in the warranty being void.
•If the tool has been operated on a supply voltage other
than that specied on the tool.
•If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
•Failure to perform maintenance as set out within the
instruction manual.
•If the tool is disassembled or tampered with in any way.
•Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benets provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
0716
Suction Hose Ø35mm x 1.5m
Extension Tubes x 3
Crevice Tool
Castors x 4
Adapter
Floor Tool
Foam
Filter
Dust Bag
Filter Bag

3
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1. Handle
2. Motor
3. Suction Hose
4. Extension Tubes
5. Filter Basket
6. Safety Float (hidden)
7. On/Off Switch
8. Tank Securing Clips
9. Vaccum Inlet
10.Tank
11. Floor Tool
12.Adaptor
13.Blow Outlet
14.Castors
WET & DRY VACUUM
ACCESSORIES
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
Assembling the Castors
1. Turn the container upside down.
2. Insert the castor assemblies into
the base of the tank.
Fitting the Motor
1. Whenttingthemotortothetank,
position it so that the tank securing
clips on the motor align with the
fastening points on the tank.
2. Fasten the tank securing clips to the
tank,makingsurethatthey
lock into place correctly.
3. Toremovethemotor,openthe
tank securing clips and lift the motor out
of the tank.
Fitting the Handle
1. Align the handle with the holes in the
top side of the motor. Fit the handle by
pressing it into the holes.
15.Filter Bag
16.Dust Bag
17.Foam Filter
18.Crevice Tool
1
2
3
4
5
6
7
8
9
10
11 13 1412
15 16 17 18

Fitting the Dust Bag
1. Forvacuumingne,drydirtitis
recommendedthatyoutthedust
bag. The dust bag is suitable for dry
vacuuming only. Using the dust bag
makes it easier to dispose of the
dust that has been collected.
2. Toattach,slipthedustbagover
the vacuum inlet.
Fitting the Foam Filter -
Vacuuming Liquid
Forwet-vacuuming,slipthesupplied
foamlteroverthelterbasket.
NOTE: Do not use the lter bag and/
or dust bag when vacuuming liquid.
Fitting the Filter Bag -
Vacuuming Dry Matter
For dry vacuum cleaning always use the
lterbag.Mountthelterbag,sothat
noairissuckedthroughtheltercage
withoutbeingltered.
NOTE: Do not use the foam lter
when vacuuming dry matter.
2. FITTING THE FILTER
IMPORTANT! NEVER USE THE WET AND DRY VACUUM
CLEANER WITHOUT A FILTER! ALWAYS ENSURE THAT
THE FILTERS ARE PERFECTLY SECURE!

3. FITTING HOSES & NOZZLES 4. OPERATION
Connect the suction hose to the
corresponding connector on the
wetanddryvacuum,dependingon
the application required:
Vacuuming
Connect the suction hose to
the vacuum inlet.
Blowing
Connect the suction hose to
the blow outlet.
Extension Tube and Adaptor
1. The suction hose can be extended by attaching one or more sections
of the 3 part extension tubes.
2. The adapter must be inserted between
the extension tube and whichever of the
nozzles is required.
Suction Tools
Floor Tool
Theoortoolisforvacuumingsolidsandliquids
over medium to large areas.
Crevice Tool
The crevice tool is designed for cleaning crevices
and edges.
OPERATION
IMPORTANT! SWITCH OFF THE EQUIPMENT IF LIQUID
OR FOAM IS EMITTED WITH THE EXHAUST AIR WHEN
WET VACUUM CLEANING.
IMPORTANT! WHEN WET VACUUMING, THE SAFETY
FLOAT TURNS OFF THE WET AND DRY VACUUM
CLEANER AUTOMATICALLY WHEN THE MAXIMUM
LEVEL IS REACHED.
IMPORTANT! THE WET AND DRY VACUUM CLEANER
IS NOT SUITABLE FOR THE VACUUMING OF
COMBUSTIBLE LIQUIDS.
VWD-1212
On/Off Switch
Switch position 0: OFF
Switch position I: ON
Dry Vacuuming
Usethedustbagandthelterbag
for dry vacuuming (see 2. Fitting the
Filter).
Checkthatthelterissecurelyttedat
all times.
Wet Vacuuming
Forwet-vacuuming,usethefoamlter
(see 2. Fitting the Filter).
Checkthatthelterissecurelytted
at all times.
NOTE: The tank will collect 8.5 Litres
maxofuidandtheoatswitchwillturn
off the vac.
Blowing
Connect the suction hose to the blow
outlet on the wet and dry vacuum
cleaner.
This vacuum must be used with a residual current device
with a rated residual current of 30mA or less.

Cleaning
Keepallsafetydevices,airventsandthemotorhousingfree
of dirt and dust as far as possible.
We recommend that you clean the equipment immediately after
you use it.
Cleaning the motor housing
Clean the appliance regularly with a damp cloth and some soft soap.
Do not use cleaning agents or solvents; these may be aggressive to the
plastic parts in the appliance.
Cleaning the tank
The tank can be cleaned with a damp cloth and some soft soap or under
runningwater,dependingontheamountofdirt.
Cleaning the foam lter
Cleanthefoamlterwithalittlesoftsoapunderrunningwaterandallow
it to air-dry.
Storing
Ensure the Wet & Dry Vac has been fully emptied of any dry matter or
liquid before it is stored.
Wrap the power cable around the cable hook.
Keep all the accessories with the unit to avoid losing them.
Keep in a dry place out of reach of children.
MAINTENANCE DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recyclingpackagingreducestheneedforlandllandrawmaterials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
Dust Bag (Pkt 5) VWDA-002
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
5. CLEANING & STORING
VVolts Hz Hertz
~Alternating current WWatts
ILitres Double insulated
Regulator compliance
mark l/s Litres per second
Read instruction manual Warning
IPX4 Ingress protection from
water mbar Pressure rating (millibar)
IMPORTANT! BEFORE CLEANING YOUR WET & DRY VAC
OR CARRYING OUT ANY MAINTENANCE PROCEDURE,
MAKE SURE THAT THE MOTOR IS OFF AND THE VAC
DISCONNECTED FROM THE POWER SUPPLY TO
PREVENT ACCIDENTAL STARTING.

IMPORTANT!
Whenusingtheequipment,afewsafetyprecautionsmustbeobservedtoavoidinjuries
and damage. Please read the complete operating manual with due care. Keep this manual
in a safe place so that the information is available at all times. If you give the equipment to any other
person,givethemtheseoperatinginstructionsaswell.
We cannot accept any liability for damage or accidents which arise due to a failure to follow these
instructions and the safety information.
• Donotleaveapplianceunattendedwhenpluggedin.Unplugfromoutletwhennotinuseand
before servicing and cleaning.
• Toavoidelectricshock,donotexposetorain.Storeindoors.
• Neveruseinthepresenceofexplosiveliquids,vapoursorexplosivedust–suchascoal
or grain.
• Neverpickupasbestosorasbestosdust.
• Wooddustandchipsinaconnedareacangiverisetoreoranexplosion.Guardagainst
possible ignition sources.
• Donotpickupanythingthatisburningorsmouldering–suchasmetalgrindingdust,cigarette
ends,hotcoals,matchesorsimilar.
• Theapplianceisnotintendedforusebyyoungchildrenorinrmpersonswithoutsupervision.
Young children should be supervised to ensure they do not play with the appliance.
• Useonlymanufacturer’srecommendedattachmentsandconsumables.
• Nevermodifythecleanerinanyway-thisisdangerousandwillinvalidatethewarranty.
• Donotusecleanerwithoutthelterinplace.
• Ifmotorsoundbecomeshigherpitchedalwayscheckforthefollowing:
- Blocked hose or accessory.
 -Blockedlter.
- Full container.
• Nevertrytomovethecleanerbypullingwiththemainslead.
• Alwayscheckthatthelterisclearandnotblocked.Keepallopeningsclearofanyblockages.
• Whenliftingtheunit,alwaysliftitwiththehandleorunderrimofbucket.Bewareofexcess
weight.
• Alwaysswitchtheunitoffbeforechangingattachmentsorconnectingdifferentpowertools.
• Alwaysdisconnectequipmentfromtheappliancewhenitisnotinuse.
• Ifthecordsetisdamagedhaveitrepairedbyanauthorisedservicecentre.
• Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,
sensoryormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeen
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
• Childrenshouldbesupervisedtoensurethattheydonotplaywiththeappliance.
• Thewetanddryvacuumcleanerisdesignedforwetanddryvacuumingusingtheappropriate
lter.Theapplianceisnotsuitableforthevacuumingofcombustible,explosiveorharmful
substances.
• Theequipmentistobeusedonlyforitsprescribedpurpose.Anyotheruseisdeemedtobea
case of misuse. The user / operator and not the manufacturer will be liable for any damage or
injuriesofanykindcausedasaresultofthis.
WET & DRY VACUUM SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of re, electric shock,
personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency,beforeoperatingthetool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 230V and 240V only. Always check that the power
supply corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and
New Zealand.
Note: The power outlet used for the vacuum must be protected by a 30mA residual current device
or earth leakage circuit breaker.
Thistoolisdoubleinsulated,thereforenoearthwireisrequired.
Ifthesupplycordisdamaged,itmustbereplacedbyanelectricianorapowertoolrepairerin
order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this
tool.Theinsulationsystemisforaddedprotectionagainstinjuryresultingfromapossibleelectrical
insulation failure within the tool.
Using an Extension Lead
Alwaysuseanapprovedextensionleadsuitableforthepowerinputofthistool.Beforeuse,
inspecttheextensionleadforsignsofdamage,wearandageing.Replacetheextensionleadif
damaged or defective.
Whenusinganextensionleadonareel,alwaysunwindtheleadcompletely.Useofanextension
lead not suitable for the power input of the tool or which is damaged or defective may result in a
riskofreandelectricshock.
WARNING! Read all safety warnings and all instructions. Failure to follow the
warningsandinstructionsmayresultinelectricshock,reand/orseriousinjury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b.
Do not operate power tools in explosive atmospheres, such as in the presence of
ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.Unmodiedplugsand
matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply with a rated residual current of 30 mA or less. Use of an RCD
reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the inuence of drugs, alcohol
or medication.
Amomentofinattentionwhileoperatingpowertoolsmayresultinseriouspersonalinjury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment
suchasdustmask,non-skidsafetyshoes,hardhat,orhearingprotectionusedforappropriate
conditionswillreducepersonalinjuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power
toolswithyourngerontheswitchorenergisingpowertoolsthathavetheswitchoninvites
accidents.
d. Remove any adjusting key or wrench before turning the power tool on.
Awrenchorakeyleftattachedtoarotatingpartofthepowertoolmayresultinpersonalinjury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts.Looseclothes,jewelleryorlonghaircanbecaughtinmovingparts.
g. If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-
related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
powertoolwilldothejobbetterandsaferattherateforwhichitwasdesigned.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the
power tool for operations different from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer,
itsserviceagentorsimilarlyqualiedpersonsinordertoavoidahazard.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
VVolts Hz Hertz
~Alternating current WWatts
ILitres Double insulated
Regulator compliance
mark l/s Litres per second
Read instruction manual Warning
IPX4 Ingress protection from
water mbar Pressure rating (millibar)
