Ozone OZ100 User manual

USER MANUAL EN
USER MANUAL
Ozone generator
OZ100 / OZ200 / OZ400
The OZ series is a compact, robust ozone generator for odor removal in
houses, apartments, garbage rooms, wardrobes, basements, cabins, cars,
boats, caravans, trucks, motorhomes, workwear, hunting clothes, odors in
textiles, odors from animals etc.
Examples of odors that can be removed with ozone:
Smoke odor, waste odor, diesel odor, sewage odor, food odor, mold odor,
dog odor, fish odor, barn odor, basement odor, refrigerator odor, trapped
odor, paint odor, solvent odor and more.
Page 1
Ozone treatment:
Important! The ozone generator should only be used in confined spaces,
where no humans or animals are present.
1. When ozonating confined spaces, it is important to keep all windows,
doors and vents closed. If necessary, you can tape around doors,
windows and vents to avoid gas leakage to other parts of the building.
2. For best results, it is recommended that the room in question is cleaned
thoroughly before the ozone treatment starts.
3. The ozone generator is placed on a stable surface, or can be mounted
on a wall, preferably a little high up from the floor. By placing the
generator above floor level (e.g. 1/2 of the room height - or higher) you
get a better distribution of the ozone gas in the room (ozone is a little
heavier than air). Make sure that textiles do not overlap (curtains,
pillows), as the ozone gas must be able to penetrate to get the full
effect.
4. Turn on the machine and check that it produces ozone (without inhaling
directly from the air stream flowing out of the machine) - chlorine-like
odor and a blue, faint glow from the ceramic element. You will hear that
the fan starts and that there is a faint "dure sound" coming from the
generator.
5. Leave the room and lock.
6. When the ozone treatment ends, turn off the ozone generator and open
windows (or doors) to let in fresh air. Air well. Avoid breathing the
ozone gas in the room. Tip: Use an extra-long (earthed) extension cord
to connect the generator to a socket near the door you use to enter /
exit, to avoid exposure time in the room during ozonation.
7. Leave the room locked and air out for a minimum of 30 minutes. When
ozonating, for example, a basement or boat with limited ventilation
options, a longer ventilation time is required: 60-90 min. Make sure that
no people can enter the room during ventilation.
8. Repeat ozone treatment, if necessary. Page 2

USER MANUAL EN
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OZONE
GENERATOR.
This ozone generator produces ozone gas. Ozone gas is toxic and hazardous to human and
animal health in concentrations that exceed the OSHA (Occupational Safety and Health
Administration) set exposure limits.
During ozone treatment, the ozone concentration may under certain conditions, quickly
exceed these set limits. Read section 1 to section 8 on the following pages to perform a
safe ozone treatment.
Safety regulations
Check the product before use. The ozone generator must not be used if the
appliance, the power cable, or the insulation seems damaged. If in doubt, contact
the manufacturer. The generator contains electrical components and must
therefore always be placed dry, never to be exposed to excess humidity, water
splashes or running water. For all types of service or maintenance, the generator
must always be disconnected from power. Ozone gas is toxic, so be aware of
recommended room sizes.
Recommended room sizes
Ozone has a characteristic chlorine-like odor. The gas is toxic and will, in high
concentrations, irritate the eyes and respiratory tract. The limit value for ozone
gas is set at 0.1PPM for exposure up to 8 hours per day, or 0.3PPM for a
maximum of 15 minutes. If the generator is used in a room that has a volume of
less than 40 m3 and poor ventilation, the ozone concentration may exceed the
mentioned limit values. Then it is important to make sure that the room is well
ventilated before it can be reoccupied. If people or animals are in a room at the
same time as it is ozonated, an ozone sensor must be installed which
automatically switches off the power to the ozone generator if the ozone
concentration in the room gets too high (above 0.1PPM).
Odor removal –Approach
The generator is placed on a stable surface or hung on a wall (fig. 3) in a dry place,
preferably about 1.5 meters above the floor. Check that air supply to the
generator and exhaust from the generator remains uncovered / open. Close all
windows and valves. Empty the room of people, animals, and live plants.
Page 3
Connect the generator to power and start the generator with the red main switch
(fig. 1). You will hear the fan start and a faint hum from the ceramic item. A green
LED will indicate that the generator is producing high voltage (Fig. 1). You can also
see through the exhaust grille that the ceramic element gives off a faint blue
glare. The odor remediation effect is a function depending on time. The generator
can run continuously for a week without any problem. For longer operation, we
recommend that you use a simple timer and run the generator at shorter
intervals. This will also reduce future need for maintenance.
Service and maintenance
Service-Kit can be ordered through your dealer or manufacturer.
Make sure that the generator is not connected to power before starting work.
Filter: The thin particle filter in front of the fan should be cleaned regularly. The
filter cover is only clamped and can be loosened gently with your nails or a small
screwdriver. Vacuum and / or wash it in mild soap and dry well before putting it
back (fig. 4).
Ceramic element
This is a consumable part. Estimated service life ›3500 hours, depending on air
quality / humidity. As long as it emits a blue glare, it produces ozone gas. For best
effect, we recommend regular cleaning.
Cleaning: Wipe the item with a q-tip or fine cloth dampened with window cleaner
or rubbing alcohol (Fig. 5). Wipe with a dry cloth afterwards. The appliance must
be completely dry before it can be restarted.
Replacing the ceramic element: Loosen the 4 screws that hold the element.
Loosen the quick connectors of the 2 red wires (fig. 6). Release the red wire from
the green LED that is attached with 2 cable strips to one of the element's red
wires. Fit the new element, remember the 4 spacer sleeves under the element
when you fasten the 4 screws carefully. Connect the 2 quick connectors - then
fasten one wire from the green LED lamp carefully along one of the element's red
wires with 2 new cable strips.
Other components: All other service must be performed by the manufacturer.

USER MANUAL EN
Page 4
Fig.1 –Operating Fig.2 –Fuse
Fig.3 –Wall Mounting
Page 5
Fig.4 –Filter Cleaning Fig.5 –Cleaning Ceramic Cell
Fig.6 –Replacing the Ceramic Cell

USER MANUAL EN
Page 6
TECHNICAL DATA:
1) Ozone production decreases at higher temperature –
best temperature is + 15oC
Manufactured by:
www.ozone.no - Ozone Scandinavia AS, Norway
Model
OZ 100
OZ 200
OZ 400
Ozone technology
CD - Ceramic
CD - Ceramic
CD - Ceramic
Ozone production
100 mg/h
200 mg/h
400 mg/h
Fan capacity
50 m3/h
50 m3/h
50 m3/h
Dimensions
(WxDxH) mm
235x90x160
235x90x160
235x90x160
Weight
1,4 kg
1,4 kg
1,5 kg
Consumption
15W
15W
20W
Voltage
230V
230V
230V
Power cable
2,0m
2,0m
2,0m
Top Cover
Stainless steel
Stainless steel
Stainless steel
Ambient temp.1)
0oC to +35oC
0oC to +35oC
0oC to +35oC
Humidity
<60% rH
<60% rH
<60% rH
CE-approved
Yes
Yes
Yes
