P.I.T. PHG2000-C User manual

PHG2000-C
HOT AIR GUN
ТЕРМОПИСТОЛЕТ

1
HOT AIR GUN

2
HOT AIR GUN
INTENDED USE
The function of the construction, technical hot air gun is to create a jet of hot air, the temperature
of which: 600 degrees Celsius.
EXPLANATION OF P.I.T.
TRADEMARK
P.I.T. Progressive Innovational
Technology
Currently, 10 kinds of mechanical and
electrical equipment are produced under the
P.I.T. trademark. In terms of sales, hot air
guns occupy one of the leading positions.
Each letter and number in the model
designation has the meaning.
For example, PHG2000-C
PHG – hot air gun
2000 –engine power
C–modification series
OPERATION PRINCIPLE
The air heated by the heating element is driven by an electromotor, and then through the gun is fed
directly into the working area.
PRODUCT SPECIFICATIONS
PHG2000-C
Rated voltage 220 V
Rated frequency 50 Hz
Rated output capacity 2,000 W
Operational temperature 500C-6000C
Air stream I-250/II-250/III-500 l/min.
Weight 0.9 kg
Model PHG2000-C

3
HOT AIR GUN
FUNCTIONAL CAPABILITIES AND FEATURES OF THE
HOT AIR GUN
Functional capabilities
Removing of old paint coatings, melting of plastics, drying of various sealants, adhesives and
mixtures, as well as defrosting.
Note: ■ – available □ – not available
MODEL
DOUBLE
INSULATION
TEMPERATURE
DISPLAY
AIR STREAM
CONTROL
TEMPERATURE
MODE
CONTROLLER
HEAD PIECES
PHG2000-C ■□■■■
HOT AIR GUN PHYSICAL FORM
1. On/off control / mode switch 5. Round head piece
2. Air outlet 6. Glass head piece
3. Temperature controller 7. Scraper
4. Flat head piece with baffler
-D

4
HOT AIR GUN
RULES OF OPERATION
On / off
Turn on the tool by putting the on/off control 1 in one of the positions:
- I position – flow rate 250 l / min, air temperature 50°C;
- II position – flow rate 350 l / min, air flow temperature can be adjusted from 350 to 6000C;
- III position – flow rate 500 l / min, air flow temperature can be adjusted from 350 to 600°C;
The first time you use it, it is possible to release a certain amount of smoke from the tool - this is normal
and will stop soon. Turn off the tool by setting theon/off control 1 to (“0” OFF) position.
Installing and removing of head pieces
- put the head piece on the air outlet 2;
- remove the head piece by pulling the head piece forward after cooling.
Install / remove head pieces only when the air outlet is cooled down, when on/off control 1 is in the (“0”
OFF) position and the plug is unplugged.
Paint / varnish removal
- use a clean sharp scraper;
- when the paint softens, scrape it with force;
- experiment to set the required heat exposure time for optimal results;
- immediately scrape off the softened paint, otherwise it will harden again;
- maintain an angle of 30-40 degrees between the tool and the workpiece;
- immediately remove paint and debris from the scraper to prevent them from igniting;
- scrape off wherever possible to fibers;
- do not direct the hot air flow to the same surface for too long.
Attention! Be careful when removing paint layers in the old buildings, as old paint may contain
lead, which is a highly toxic substance.
Paint / varnish removal from windows
- always use the glass protection head piece 7 when working near glass;
- remove paint with a manual scraper.
Attention! Do not use paint remover on windows in metal frames; metal is heat conductive, and this
can lead to the destruction of glass.
Removal of stickers
- use a flat head piece 5;
- many adhesive substances are softened by heating, which allows you to separate the adhesive and
remove excess adhesive;
- heat the sticker on the outside;
- every time make sure not to overheat the underlying surface
Shrink fit
- use the tapering head piece 4;
- select a pipe for shrink fit with a diameter corresponding to the diameter of the workpiece;
- evenly heat the pipe for shrink fir and, until it has cooled, put on the workpiece

5
HOT AIR GUN
MAINTENANCE
Maintenance of the power tool must be performed only by qualified personnel of authorized
technical service centers. Maintenance performed by unskilled personnel can cause tool breakage
and injury. For example: internal wires may be incorrectly stacked or clamped.
When servicing a power tool, use only specified replacement of consumable parts, head pieces,
accessories. The use of non-recommended consumable parts, head pieces or accessories may
cause damage to the power tool or personal injury. The use of some cleaning agents such as
gasoline, ammonia, etc.lead to damage to the plastic parts.
Attention! Be careful when removing paint in old rooms. Maybe the lower layers contain lead
paint. It is forbidden to remove old paint with the content of lead by the hot air gun.
Use safety glasses and respirator.

6
HOT AIR GUN
TERMS OF WARRANTY SERVICE
1. This Warranty Certificate is the only document that confirms your right to free warranty service. Without
presenting this certificate, no claims are accepted. In case of loss or damage, the warranty certificate is not restored.
2. The warranty period for the electric machine is 12 months from the date of sale, during the warranty period the
service department eliminates manufacturing defects and replaces parts that have failed due to the fault of the
manufacturer free of charge. In the warranty repair, an equivalent operable product is not provided. Replaceable
parts become property of service providers.
P.I.T is not liable for any damage that may be caused by operation of the electric machine.
3. Only clean tool accompanied with the following duly executed documents: this Warranty Certificate, Warranty
Card, with all fields filled out, bearing the stamp of the trade organization and the signature of the buyer, shall be
accepted for warranty repair.
4. Warranty repair is not performed in the following cases:
- in the absence of a Warranty Certificate and a Warranty Card or their incorrect execution;
- with failure of both a rotor and a stator of the electric engine, charring or melting of primary winding of the
welding machine transformer, charging or starting-charging device, with internal parts melting, burn down of
electronic circuit boards;
- if a Warranty Certificate or a Warranty Card does not correspond to this electric machine or to the form established
by the supplier;
- upon expiration of the warranty period;
- at attempts of opening or repair of the electric machine outside the warranty workshop; making constructive
changes and lubrication of the tool during the warranty period, as evidenced, for example, by the creases on the
spline parts of the fasteners of non-rotational parts.
- when using electric tools for production or other purposes connected with making a profit, as well as in case of
malfunctions related to instability of the power network parameters exceeding the norms established by GOST;
- in the events of improper operation (use the electric machine for other than intended purposes, attachments to the
electric machine of attachments, accessories, etc. not provided by the manufacturer);
- with mechanical damage to the case, power cord and in case of damages caused by aggressive agents and high and
low temperatures, ingress of foreign objects in the ventilation grids of the electric machine, as well as in case of
damage resulting from improper storage (corrosion of metal parts);
- natural wear and tear on the parts of the electric machine, as a result of long-term operation (determined on the
basis of the signs of full or partial depletion of the specified mean life, great contamination, presence of rust outside
and inside the electric machine, waste lubricant in the gearbox);
- use of the tool the purposes for other than specified in the operating instructions.
- mechanical damages to the tool;
- in the event of damages due to non-observance of the operating conditions specified in the instruction (see chapter
“Safety Precautions” of the Manual).
- damage to the product due to non-observance of the rules of storage and transportation.
Preventive maintenance of electric machines (cleaning, washing, lubrication, replacement of anthers, piston and
sealing rings) during the warranty period is a paid service.
The service life of the product is determined by the manufacturer and is 2 years from the date of manufacture.
The owner is notified of any possible violations of the above terms of warranty service upon completion of
diagnostics in the service center.
The owner of the tool entrusts the diagnostic procedure to be conducted in the service center in his absence.
Do not operate the electric machine when there are signs of excessive heat, sparking, or noise in the gearbox. To
determine the cause of the malfunction, the buyer should contact the warranty service center.
Malfunctions caused by late replacement of carbon brushes of the engine are eliminated at the expense of the buyer.
5. The warranty does not cover:
- replacement accessories (accessories and components), for example: batteries, discs, blades, drill bits, borers,
chucks, chains, sprockets, collet clamps, guide rails, tension and fastening elements, trimming device heads, base of
grinding and belt sander machines, filters, etc.,
- fast wearing parts, for example: carbon brushes, drive belts, seals, protective covers, guiding rollers, guides, rubber
seals, bearings, toothed belts and wheels, shanks, brake belts, starter ratchets and ropes, piston rings, etc. Their
replacement during the warranty period is a paid service;
- power cords, in case of damage to the insulation, power cords are subject to mandatory replacement without the
consent of the owner (paid service);
- tool case.
