PAASCHE F900- Series Automatic Humidier
HUMIDIFIER INSTALLATION
1. Mount Humidier Unit in convenient location using
Mounting Bracket (not shown).
2. Connect air supply to HF-1/4” Air Inlet Valve.
3. Connect water supply to HF-1/4” Water Inlet Valve.
4. Open air inlet valve and water supply valve under air
supply valve check for leaks. Tighten connections if
required.
5. Turn humidistat control dial on item #1 counter-
clockwise to off position before plugging cord into
grounded outlet.
6. Reduce water ow by turning U-3670 needle stop
adjustment knob at back of spray gun. Do not use to
shut off spray. If tightened too much needle can be
pushed through tip.
7. Set Regulator item #2, between 45 & 60. Start at 45 PSI
and increase until you get a nice atomization. Shop air
must be 80 PSI or higher.
8. Plug unit into properly grounded Outlet (115V., 60cy).
9. Turn Humidistat control dial to on position and desired
humidity. You will hear a “click” when activated.
10. Water ow rate may be adjusted using Item #13 for
Fluid Adjusting on back of each Spray Gun. Mist
should always be absorbed into the surrounding
air without settling out onto the oor under the unit.
CAUTION: DO NOT AIM DIRECTLY AT CEILING,
WALL, MERCHANDISE OR MACHINERY.
SAFETY NOTE: Do Not allow water vapor to
condense or leaks to drip onto oor or unit, if this
condition exists, check for:
a. Water leaks from connections or Spray Gun nozzles.
b. Insufcient atomization. Correct by increasing air
pressure and/or decreasing uid ow.
c. Humidistat setting too high. Lower setting if necessary.
d. Open drain valve on R-76 Regulator/Condenser item #2
periodically to drain airline moisture buildup.
CAUTION: Guard Face and Eyes so escaping air and
moisture do not cause injury.
WARNING: Humidier must never be used to create
a fog condition in which water may collect on the unit
and produce an electrical hazard.
F910-2 UNIT
Air Inlet
1
3
4
2
11
10
Water Inlet
No. Part No. Description
1. AR-15-1 Aircap
2. AU-12 Aircap Nut
3. AU-1 Fluid Tip
4. A-AU-2-29/32 Needle
5. AU-7B Fluid Body
6. U-3632 Small O-ring
7. U-3633 Large O-ring
8. U-3045 Cylinder Shell
9. U-3664 PTFE Piston Assembly
Located behind
Humidistat
12
6
7
8
9
345
Do Not Use as a Shutoff by
turning all the way Down, It will
split the Tip.
Needle Lock
Screw
12 13
11
10
MAJOR COMPONENTS FOR F900-SERIES HUMIDIFIERS
No. Part No. Description
1. 845 Humidistat
2. R-76 Regulator & Moisture Trap
3. AH-JUR-1 2 Spray Gun Heads
4. T-04-10 Water Tubing (10 Inches)
5. F9-90-1/8 Air Fitting to Regulator
6. F9-90-1/4 Fitting to Mount 90° (3)
7. 1/4 AHPP Pipe Plug
8. F9-1-1/4 Fluid Inlet
9. T-04-4.5 AirTubing (4 1/2 Inches)
10. SM-880 Solenoid Valve
11. HF-1/4 Valve Assembly (1)Water & (1) Air
7
6
6
6
14
15
10. U-2500 Piston Spring
11. U-3669 Rear Cap
12. H-153 Set Screw
13. U-3670 Needle Stop Adjustment Knob
14. U-1432A Ball Stud
15. U-1399 Swivel Nut
16. U-3687 Packing Set
9
5
Located in mounting
block behind regulator
8
Located behind
regulator
16
