Pablo Uma Mini User manual

UMA
MINI
SETUP GUIDE & OWNERS MANUAL
PABLO DESIGNS
888 MARIN STREET
SAN FRANCISCO, CA
94124
PABLODESIGNS.COM
UMA SUPPORT: 888-355-0636
[e-mail]

UMA MINI UMA MINI
pg. 1 pg. 2
UMA MINI INDICATOR OVERVIEW
INDICATOR LIGHT FUNCTIONS:
BLUETOOTH
BUTTON
USBC PORT
AUX INPUT
POWER BUTTON
POWER INDICATOR LIGHT
POWER INDICATOR LIGHT ILLUMINATED WHITE POWER IS ON / BATTERY CHARGE 10%-90%
BREATHING GREEN POWER IS ON / BATTERY CHARGE 90%-99%
ILLUMINATED GREEN POWER IS ON / BATTERY CHARGE 100%
BREATHING RED POWER IS ON / BATTERY CHARGE LOW
UNLIT POWER IS OFF
BREATHING BLUE BLUETOOTH PAIRING MODE ACTIVATED
ILLUMINATED BLUE UNIT IS IN PARTY HOST MODE
CHARGING UMA MINI
UMA MINI USES AN INTERNAL RECHARGEABLE
LITHIUM POLYMER BATTERY THAT WILL LAST THE
LIFETIME OF THE DEVICE. FULLY CHARGE UMA
MINI’S BATTERY PRIOR TO FIRST USE. TO CHARGE
THE BATTERY, CONNECT THE INCLUDED USBC
CABLE TO UMA MINI THEN TO A POWER SUPPLY
NOT PROVIDED
ANY USB CHARGER WILL WORK WITH UMA MINI.
WE RECOMMEND A 10WATT 5V  2.1A USB
CHARGER.
KEEP UMA MINI CONNECTED TO THE POWER
SOURCE UNTIL POWER INDICATOR LIGHT TURNS
SOLID GREEN TO INDICATE A FULL CHARGE.
IT MAY TAKE UP TO 2.5 HOURS FROM ZERO
TO FULLY CHARGE UMA MINI WITH A 10WATT
CHARGER.
6.5 FT 2M USBC
CABLE PROVIDED

UMA MINI UMA MINI
pg. 3 pg. 4
UMA MINI LIGHT FUNCTION
NOTE:
CONTROLS
TO TURN UMA MINI ON, PRESS & HOLD POWER
BUTTON FOR 2 SECONDS. POWER INDICATOR
LIGHT WILL ILLUMINATE, AND LIGHT WILL TURN
ON AT HIGH BRIGHTNESS.
PRESS POWER BUTTON AGAIN BUT BRIEFLY TO
CYCLE THROUGH HIGH LIGHT, LOW LIGHT, AND
LIGHT OFF.
TO TURN POWER OFF, PRESS & HOLD POWER
BUTTON FOR 2 SECONDS.
UMA MINI WILL TURN OFF AUTOMATICALLY AFTER 15 MINS OF INACTIVITY.
INACTIVITY = LIGHT IS OFF & NO SOUND IS PLAYING
 PRESS & HOLD FOR POWER ON.
 PRESS BRIEFLY TO CYCLE LIGHT INTENSITY.
 PRESS & HOLD TO POWER OFF.
POWER BUTTON
POWER INDICATOR LIGHT
UMA MINI SOUND FUNCTION
NOTE:
CONTROLS
VOLUME IS CONTROLLED THROUGH A TOUCH
CAPACITIVE PAD ON THE TOP OF UMA MINI.
USING YOUR FINGER, SLIDE CLOCKWISE
TO TURN VOLUME UP, SLIDE COUNTER
CLOCKWISE TO TURN VOLUME DOWN.
NOTE: MAKE SURE THE CONNECTED DEVICE’S
VOLUME IS TURNED UP.
UMA MINI WILL TURN OFF AUTOMATICALLY AFTER 15 MINS OF INACTIVITY.
INACTIVITY = LIGHT IS OFF & NO SOUND IS PLAYING





TOUCH INTERFACE.
REQUIRES 540 DEGREES OF TOUCH ROTATION
TO TRAVEL FROM 0%100% VOLUME.
SLIDE FINGER CLOCKWISE TO INCREASE
VOLUME.
SLIDE FINGER COUNTER CLOCKWISE TO
DECREASE VOLUME.
VOLUME IS CONTROLLED BY DIRECTION AND
DISTANCE OF SLIDE REGARDLESS OF POSITION.
VOLUME UP
CLOCKWISE
VOLUME DOWN
COUNTER CLOCKWISE

UMA MINI UMA MINI
pg. 5 pg. 6
CONNECTING UMA MINI TO A BLUETOOTH® WIRELESS TECHNOLOGY ENABLED DEVICE
PAIRING:
WHEN CONNECTING A BLUETOOTH DEVICE TO UMA MINI
FOR THE FIRST TIME, THE DEVICE MUST BE REGISTERED
WITH UMA MINI. THIS IS CALLED PAIRING. ONCE PAIRING IS
COMPLETED, UMA MINI WILL REMEMBER YOUR DEVICE AND
CONNECT AUTOMATICALLY. UMA MINI CAN REMEMBER
UP TO 8 DEVICES. TO PAIR YOUR DEVICE WITH UMA MINI,
FOLLOW THESE STEPS:
BLUETOOTH
BUTTON
PRESS & HOLD POWER SWITCH TO TURN UMA MINI ON.
POWER INDICATOR LIGHT WILL ILLUMINATE.
PRESS & HOLD THE BLUETOOTH PAIRING BUTTON ON
UMA MINI FOR 1.5 SECONDS TO PUT UMA MINI INTO
PAIRING MODE, INDICATED BY A BREATHING BLUE LIGHT.
UMA MINI WILL REMAIN IN PAIRING MODE UNTIL A
CONNECTION IS MADE, OR FOR UP TO ONE MINUTE.
TURN ON THE BLUETOOTH FUNCTION ON YOUR DEVICE.
IN THE BLUETOOTH SETTINGS OF THE DEVICE, SELECT
“UMA MINI” FROM THE LIST OF AVAILABLE CONNECTIONS.
INDICATOR LIGHT ON UMA MINI WILL CHANGE TO WHITE
WHEN THE CONNECTION IS SUCCESSFUL.
PLAY MUSIC ON YOUR DEVICE. ENSURE VOLUME ON
YOUR DEVICE IS NOT SET TO MUTE.
AFTER YOUR DEVICE HAS PAIRED WITH UMA MINI, IT WILL
CONNECT AUTOMATICALLY TO THE MOST RECENTLY
CONNECTED DEVICE. IF IT DOES NOT CONNECT
AUTOMATICALLY, REPEAT THE PAIRING PROCESS TO
REGISTER YOUR DEVICE.
IF YOU HAVE DIFFICULTY CONNECTING TO UMA MINI,
PLEASE REFER TO THE TROUBLESHOOTING GUIDE IN THIS
INSTRUCTION MANUAL.
1.
2.
3.
4.
5.
6.
7.
CONNECTING UMA MINI TO A DEVICE VIA PROVIDED AUXILIARY CABLE
UMA MINI CAN PLAY MUSIC FROM AN AUDIO DEVICE BY CONNECTING THE
AUXIN CABLE NOT PROVIDED. TO CONNECT YOUR DEVICE TO UMA MINI
WITH AUXILIARY CABLE, FOLLOW THESE STEPS:
1.
2.
3.
4.
PRESS POWER SWITCH FOR 2 SECONDS TO TURN UMA MINI ON. POWER
INDICATOR LIGHT WILL ILLUMINATE.
PLUG AUXILIARY CABLE INTO UMA MINI’S AUDIOIN PORT. BLUETOOTH
WIRELESS TECHNOLOGY WILL BE DISABLED AND ALL WIRELESS
CONNECTIONS WILL BE DISCONNECTED, EXCEPT FOR PARTY MODE
CONNECTIONS.
PLUG THE OTHER END OF THE AUXILIARY CABLE INTO THE AUDIOOUT
HEADPHONE PORT ON YOUR DEVICE.
PLAY MUSIC ON YOUR DEVICE. ENSURE VOLUME ON YOUR DEVICE
IS NOT MUTED.
NOTE: AUXILIARY CABLE IS NONDIRECTIONAL.

UMA MINI UMA MINI
pg. 7 pg. 8
PARTY MODE ON UMA MINI
“PARTY MODE” REFERS TO CONNECTING MORE THAN ONE UMA MINI TO A SINGLE PHONE OR OTHER
SOURCE OF MUSICSOUND
PARTY MODE HOST: IS THE FIRST UMA MINI THAT CONNECTS TO THE PHONE OR OTHER SOURCE OF
MUSICSOUND. THE HOST STREAMS MUSIC TO ALL CONNECTED SATELLITES.
PARTY MODE SATELLITES: ARE THE ADDITIONAL UNITS THAT CONNECT TO THE HOST. THE SATELLITES
DO NOT CONNECT DIRECTLY TO THE PHONE WHEN IN PARTY MODE. EACH OF THE SATELLITES
CONNECTS TO THE HOST, LIKE SPOKES TO A HUB. THIS IS AN IMPORTANT CONSIDERATION FOR RANGE
AND FOR HOW THE CONNECTIONS ARE MADE. THE VOLUME ON SATELLITES CANNOT BE INDIVIDUALLY
CONTROLLED WHILE IN PARTY MODE; VOLUME CAN ONLY BE CONTROLLED BY THE HOST OR THE
PHONE.
NOTE: THE HOST CAN BE CONNECTED TO THE PHONE OR OTHER SOURCE OF MUSICSOUND VIA
BLUETOOTH OR AUX CABLE.
BLUETOOTH
BUTTON
HOST
SATELLITE SATELLITE
SETTING UP PARTY MODE ON UMA MINI
THIS FEATURE REQUIRES MORE THAN ONE UMA MINI. YOU CAN CONNECT THE HOST UP TO 23
SATELLITE UMA MINIS FOR PARTY MODE.
NOTE: THE VOLUME ON SATELLITES CANNOT BE INDIVIDUALLY CONTROLLED WHILE IN PARTY MODE;
VOLUME CAN ONLY BE CONTROLLED BY THE HOST OR THE PHONE.
1.
2.
3.
4.
5.
6.
CONNECT ONE UMA MINI TO A PHONE OR OTHER SOURCE OF MUSICSOUND VIA BLUETOOTH OR
AUX CABLE. REFER TO PAGES 5 & 6 FOR STEPS. THIS UMA MINI WILL BE THE HOST.
ON THE SAME UMA MINI THE HOST, PRESS & HOLD BLUETOOTH BUTTON FOR 5 SECONDS TO
ACTIVATE PARTY MODE HOST. DISREGARD THE PAIRING TONE AFTER 1.5 SECONDS AND CONTINUE
HOLDING THE BLUETOOTH BUTTON UNTIL HEARING “PARTY MODE HOST.” THE UNIT IS NOW
SEARCHING FOR A SATELLITE AND WILL STOP AFTER 1 MINUTE IF NO CONNECTION IS MADE.
ON A DIFFERENT UMA MINI, QUICKLY DOUBLE PRESS THE BLUETOOTH BUTTON TO ACTIVATE PARTY
MODE SATELLITE. THE UNIT SHOULD SAY “PARTY MODE SATELLITE” AFTER PRESSING THE BUTTON
AND IS NOW SEARCHING FOR THE HOST AND WILL STOP AFTER 1 MINUTE IF NO CONNECTION IS
MADE.
WHILE BOTH UNITS ARE SEARCHING, SHORT PRESS THE BLUETOOTH BUTTON ON EACH UNIT
TO COMPLETE THE CONNECTION. BOTH UNITS WILL MAKE A SOUND INDICATING THEY ARE
CONNECTED. NOTE: THIS STEP IS ONLY NECESSARY AT INITIAL SETUP, NOT EVERY TIME THE UNITS
CONNECT. THE INDICATOR LIGHT ON THE HOST WILL TURN SOLID BLUE, AND REMAIN BLUE THE
ENTIRE TIME THE UNIT IS IN HOST MODE. THE INDICATOR LIGHT ON THE SATELLITE WILL TURN SOLID
BLUE FOR 1 MINUTE AFTER STARTUP, THEN RETURN TO NORMAL WHITE COLOR.
TO CONNECT MORE UMA MINI SATELLITES, PERFORM THE SAME STEPS ABOVE WITH EACH
ADDITIONAL SATELLITE AND THE SAME UMA MINI HOST. YOU CAN CONNECT THE HOST UP TO 23
SATELLITE UMA MINIS FOR PARTY MODE.
ONCE THE HOST AND SATELLITES HAVE MADE A CONNECTION, THEY WILL REMEMBER EACH OTHER
AND AUTOMATICALLY CONNECT EVERY TIME.

UMA MINI UMA MINI
pg. 9 pg. 10
BLUETOOTH© WIRELESS TECHNOLOGY CONNECTION TROUBLESHOOTING GUIDE
IF YOU HAVE DIFFICULTY CONNECTING YOUR DEVICE TO UMA MINI, FOLLOW THIS GUIDE:
PROBLEM CAUSE SOLUTION
UMA MINI CANNOT MAKE A
BLUETOOTH CONNECTION
UMA MINI IS TURNED OFF PRESS POWER SWITCH 2 SEC. TO TURN UMA MINI
ON. POWER INDICATOR LIGHT WILL ILLUMINATE.
BLUETOOTH FUNCTION IS
TURNED OFF
PRESS THE BLUETOOTH BUTTON TO ENABLE
BLUETOOTH FUNCTION.
UMA MINI HAS NOT YET
BEEN PAIRED WITH THE
BLUETOOTH DEVICE
PERFORM PAIRING PROCESS (P.5).
UMA MINI IS TOO FAR FROM
THE BLUETOOTH DEVICE
MOVE THE AUDIO SOURCE CLOSER. MAXIMUM
DISTANCE FROM DEVICE IS 30M (98 ft)
UNOBSTRUCTED.
AN AUXIN CABLE IS
CONNECTED
DISCONNECT AUXIN CABLE.
ANOTHER BLUETOOTH
DEVICE IS CONNECTED
DISCONNECT OR POWER OFF THE OTHER
BLUETOOTH DEVICE.
THE PAIRING INFORMATION
HAS BEEN DELETED. UMA
MINI CAN REMEMBER UP TO
8 DEVICE PAIRINGS. IF A 9TH
DEVICE IS PAIRED, UMA MINI
WILL FORGET THE FIRST
DEVICE
PERFORM PAIRING PROCESS AGAIN (P.5).
UMA MINI IS NOT
REGISTERED ON THE
DEVICE’S BLUETOOTH
CONNECTION LIST
PERFORM PAIRING PROCESS AGAIN (P.5).
THERE IS A DEVICE
(MICROWAVE, WIRELESS
LAN, ETC.) THAT OUTPUTS
SIGNALS IN THE 2.4 GHz
FREQUENCY BAND NEARBY
MOVE UMA MINI AWAY FROM ANY DEVICE THAT
EMITS RF SIGNALS OR INTERFERENCE.
TRANSPORTING UMA MINI
CARE INSTRUCTIONS
UMA MINI IS INTENDED TO BE TRANSPORTED IN
THE INCLUDED CLOTH BAG FOR CONVENIENT AND
PROTECTED TRAVEL.
UMA MINI CAN BE OPERATED WHILE IN THE TRAVEL
BAG, AND IS RECOMMENDED IN DAMP CONDITIONS.
WIPE UMA CLEAN WITH A SOFT DAMP CLOTH. AVOID
AMMONIA BASED CLEANERS. PROTECT UMA WITH
THE PROVIDED CARRY BAG WHEN TRANSPORTING.
DO NOT SUBMERGE OR EXPOSE TO RAINFALL OR
SPLASHING WATER.

UMA MINI UMA MINI
pg. 11 pg. 12
LIGHT AND AUDIO FUNCTION TROUBLESHOOTING GUIDE
IF YOU HAVE DIFFICULTY PROPERLY OPERATING UMA MINI, FOLLOW THIS GUIDE
IF PROBLEMS PERSIST, PLEASE CONTACT UMA SUPPORT: 8883550636  UMASUPPORTPABLODESIGNS.COM
PROBLEM CAUSE SOLUTION
BLUETOOTH AUDIO
CONNECTION IS DISTORTED
OR DROPPING OUT
THE SOURCE DEVICE IS TOO FAR
AWAY FROM UMA
MOVE THE AUDIO SOURCE CLOSER.
MAXIMUM DISTANCE FROM DEVICE IS 30M
(98 ft) UNOBSTRUCTED.
THERE IS A DEVICE (MICROWAVE,
WIRELESS LAN, ETC.) THAT
OUTPUTS SIGNALS IN THE 2.4 GHz
FREQUENCY BAND NEARBY
MOVE UMA MINI AWAY FROM ANY DEVICE
THAT EMITS RF SIGNALS OR INTERFERENCE.
THE VOLUME ON EITHER THE
AUDIO SOURCE OR UMA MINI IS
TOO LOW
ADJUST THE VOLUME ON BOTH UMA MINI
AND THE AUDIO SOURCE.
POOR CONNECTION BETWEEN
UMA MINI AND THE SOURCE
DEVICE
RESTART BOTH THE AUDIO SOURCE AND
UMA MINI.
BLUETOOTH PAIRING FAILED REPAIR YOUR DEVICE WITH UMA MINI.
SOURCE DEVICE IS PAIRED TO A
DIFFERENT BLUETOOTH DEVICE
DISCONNECT OR POWER OFF THE OTHER
BLUETOOTH DEVICE.
3.5MM AUXILIARY AUDIO
CONNECTION IS DISTORTED
OR DROPPING OUT
3.5MM AUXILIARY CABLE IS NOT
FULLY CONNECTED TO EITHER
UMA MINI OR THE SOURCE DEVICE
CHECK THAT THE 3.5MM AUXILIARY CABLE IS
SECURELY CONNECTED TO BOTH UMA MINI
AND THE SOURCE DEVICE.
SOURCE DEVICE ISN’T WORKING
PROPERLY
TRY DIFFERENT SOURCE DEVICE TO ENSURE
THE ISSUE ISN’T THE SOURCE DEVICE.
3.5MM AUXILIARY CABLE IS FAULTY
OR DAMAGED
TRY A DIFFERENT 3.5MM AUXILIARY CABLE.
STREAMED AUDIO
CONTENT IS DISTORTED OR
DROPPING OUT
INTERNET CONNECTIVITY ISSUES FOLLOW YOUR ROUTER/ISP INSTRUCTIONS
TO ENSURE YOUR INTERNET CONNECTION IS
FUNCTIONING PROPERLY.
PARTY MODE TROUBLESHOOTING GUIDE
IF YOU HAVE DIFFICULTY PERFORMING PARTY MODE, FOLLOW THIS GUIDE:
PROBLEM CAUSE SOLUTION
UMA MINI IS NOT
ACTIVATING PARTY MODE
HOST
UNIT IS POWERED OFF MAKE SURE UMA MINI IS CHARGED AND IS
POWERED ON.
BLUETOOTH BUTTON WAS
NOT PRESSED & HELD FOR 5
SECONDS
PRESS & HOLD BLUETOOTH BUTTON FOR 5
SECONDS TO ACTIVATE PARTY MODE HOST.
CONTINUE HOLDING THE BLUETOOTH BUTTON
UNTIL HEARING “PARTY MODE HOST.”
UMA MINI IS NOT
ACTIVATING PARTY MODE
SATELLITE
UNIT IS POWERED OFF MAKE SURE UMA MINI IS CHARGED AND IS
POWERED ON.
BLUETOOTH BUTTON WAS
NOT QUICKLY DOUBLE
PRESSED
THE UNIT SHOULD SAY “PARTY MODE SATELLITE”
AFTER DOUBLE PRESSING THE BLUETOOTH
BUTTON.
UMA MINI IS ONLY PLAYING
MUSIC ON ONE DEVICE
BLUETOOTH BUTTON WAS
NOT PRESSED ONCE ON
EACH UNIT AFTER ACTIVATING
PARTY MODE HOST & PARTY
MODE SATELLITE
MAKE SURE TO SHORT PRESS THE BLUETOOTH
BUTTON ON EACH UMA MINI UNIT AFTER
ACTIVATING PARTY MODE HOST & PARTY MODE
SATELLITE TO COMPLETE THE CONNECTION.
PARTY MODE HAS NOT BEEN
SET UP
REFER TO PAGES 89 TO SET UP PARTY MODE.
WHICH ONE IS THE HOST? CAN’T IDENTIFY HOST THE UMA MINI HOST WILL HAVE A SOLID BLUE
INDICATOR LIGHT WHEN POWERED ON.
DON’T HAVE THE UMA MINI
HOST ANYMORE
THE UMA MINI HOST IS LOST/
NOT WORKING
PERFORM A FACTORY RESET FOR ALL UMA MINI’S
AND ESTABLISH ANOTHER UNIT AS THE HOST.
UNABLE TO CHANGE UMA
MINI PARTY MODE HOST
THERE IS ANOTHER HOST PERFORM A FACTORY RESET.
NOTE THAT THIS WILL DELETE ALL STORED
CONNECTIONS.
SATELLITES’ CONNECTIONS
ARE CUTTING OFF
UMA MINI SATELLITES ARE
TOO FAR FROM THE HOST
MOVE THEM CLOSER. MAXIMUM DISTANCE FROM
HOST IS 30M (98 ft) UNOBSTRUCTED.
CAN’T CONTROL VOLUME ADJUSTING VOLUME FROM
SATELLITE
VOLUME CAN ONLY BE CONTROLLED FROM HOST
OR PHONE WHEN IN PARTY MODE.

UMA MINI UMA MINI
pg. 13 pg. 14
PERFORMING FACTORY RESET ON UMA MINI MORE INFO
WARRANTY
FOLLOW US
SPECIFICATIONS
YOU CAN PERFORM A FACTORY RESET ON UMA MINI IF NEEDED. THIS WILL DELETE ALL PAIRED
BLUETOOTH DEVICES AND PARTY MODE CONNECTIONS.
FOR MORE INFORMATION AND PRODUCT DETAILS VISIT WWW.PABLODESIGNS.COM
1.
2.
3.
4.
5.
TURN UMA MINI ON BY PRESSING & HOLDING THE POWER BUTTON FOR 2 SECONDS.
PRESS & HOLD THE BLUETOOTH BUTTON FOR 10 SECONDS. DISREGARD THE PAIRING TONE AND
“PARTY MODE HOST.”
RELEASE THE BUTTON AFTER HEARING “FACTORY RESET.”
WAIT APPROXIMATELY 1 MINUTE AFTER RESETTING UMA MINI BEFORE RESTARTING IT.
UMA MINI IS NOW RESTORED TO FACTORY SETTINGS AND READY FOR NEW CONNECTIONS.
LIGHT OUTPUT: 100 LUMENS MAX
BATTERY RUNTIME: UP TO 20 HOURS DEPENDING ON USE
CHARGE TIME: UP TO 3 HOURS
POWER CONSUMPTION: 4W LIGHT 8W MAX SPEAKERS
SPEAKER WATTAGE: 8W MAX
BLUETOOTH VERSION: 5.0
BLUETOOTH RANGE: 30M
DIMENSIONS: 8.4” X 4” X 5.6” 21.4CM X 10CM X 14.2CM
WEIGHT: 1.54LBS 0.7KGS
PATENT PENDING
MADE IN CHINA
FOR WARRANTY AND ADDITIONAL TROUBLESHOOTING INFORMATION VISIT
WWW.PABLODESIGNS.COMPRODUCTUMAMINI
FOLLOW US ON FACEBOOK AND INSTAGRAM
WWW.FACEBOOK.COMPABLODESIGNSSF
PABLODESIGNSSF
