Pablo CLAMP Programming manual

ASSEMBLY & INSTALLATION INSTRUCTIONS
pg. 1
CLAMP

INSTALLATION
LOCKING
CLAMP
pg. 2
2
3
ALIGN THE FRONT SURFACE OF THE
CLAMP TO THE EDGE OF THE TABLE
SLIDE CLAMP FORWARD UNTIL THE
EDGE OF TABLE MEETS POST
USE INCLUDED HEX TOOL TO
TIGHTEN SET SCREW AND LOCK
TOP CLAMP IN POSITION
NOTE: CLAMP CAN ONLY BE APPLIED
TO SURFACES UP TO 3” THICK
1
3
22
3MM HEX KEY

ASSEMBLY
CLAMP
pg. 3
LIFT ARM TO ADJUST HEIGHT AND
ROTATE LIGHT SOURCE TO DESIRED POSITION
ADJUSTMENT
4
5
SLIDE ARM ONTO STEM
CONNECTOR LOCK
ABC D
PLUG TYPES:
POWER
SUPPLY
LOCK
1. SLIDE PLUG INTO POWER SUPPLY
2. ALIGN CONNECTOR/POWER
SUPPLY LOCKING FEATURES
3. INSERT CONNECTOR
4. TURN CONNECTOR 90 DEGREES
TO LOCK
A. N AMERICA B. UK C. EU D. AU
NOTE: CONTACT MANUFACTURER FOR
ADDITIONAL PLUG TYPE REQUIREMENTS.

ASSEMBLY & INSTALLATION INSTRUCTIONS
pg. 1
CLAMP FS

ASSEMBLY
CLAMP FS
pg. 2
REMOVE BASE FROM PACKAGING AND PLACE VERTICALLY IN
BOX SLOT AS SHOWN TO ASSIST WITH ASSEMBLY PROCEDURE
REMOVE EXISTING TOP
CLAMP FROM STEM
SLIDE BOTTOM OF CLAMP LAMP
INTO BASE CAVITY AS SHOWN
1
3
22
BOX SLOT

ASSEMBLY
CLAMP FS
pg. 3
2X SCREWS
AND WASHERS
SECURE CLAMP LAMP INTO BASE WITH
SUPPLIED WASHERS AND SCREWS
4
5SLIDE ARM ONTO STEM
CONNECTOR LOCK
ABCD
PLUG TYPES:
POWER
SUPPLY
LOCK
1. SLIDE PLUG INTO POWER SUPPLY
2. ALIGN CONNECTOR/POWER
SUPPLY LOCKING FEATURES
3. INSERT CONNECTOR
4. TURN CONNECTOR 90 DEGREES
TO LOCK
A. N AMERICA B. UK C. EU D. AU
NOTE: CONTACT MANUFACTURER FOR
ADDITIONAL PLUG TYPE REQUIREMENTS.

pg. 4
[e-mail]
888 MARIN STREET
SAN FRANCISCO, CA
94124
PABLODESIGNS.COM
CLAMP FS
ADJUSTMENT
LIFT ARM TO ADJUST HEIGHT AND
ROTATE LIGHT SOURCE TO DESIRED POSITION
6

pg. 1
CLAMP
MINI
ASSEMBLY & INSTALLATION INSTRUCTIONS

ASSEMBLY
CLAMP MINI
pg. 2
INSERT POST INTO BASE AS SHOWN
1
MAKE SURE THAT ARROW ON ORIENTATION
STICKER IS POINTING TO FRONT OF BASE.
REMOVE STICKER.
2
INSERT PROVIDED SCREW INTO HOLE IN BACK OF BASE.
USING HEX KEY SUPPLIED, TIGHTEN UNTIL POST IS SECURE.
3
HEX KEY AND SCREW
ORIENTATION
STICKER

ASSEMBLY
CLAMP MINI
pg. 3
SLIDE ARM ONTO POST
4
CONNECTOR LOCK
ABCD
PLUG TYPES:
POWER
SUPPLY
LOCK
1. SLIDE PLUG INTO POWER SUPPLY
2. ALIGN CONNECTOR/POWER
SUPPLY LOCKING FEATURES
3. INSERT CONNECTOR
4. TURN CONNECTOR 90 DEGREES
TO LOCK
A. N AMERICA B. UK C. EU D. AU
NOTE: CONTACT MANUFACTURER FOR
ADDITIONAL PLUG TYPE REQUIREMENTS.
ADJUSTMENT
LIFT ARM TO ADJUST HEIGHT AND
ROTATE LIGHT SOURCE TO DESIRED POSITION
5
HI-LOW SWITCH

CLAMP
FLOOR
ASSEMBLY & INSTALLATION INSTRUCTIONS
pg. 1

ASSEMBLY
CLAMP FLOOR
pg. 2
ASSEMBLE BASE BY JOINING TOP LEG TO
BOTTOM LEG AS SHOWN
1
SLIDE BOTTOM POST INTO HOLE ON TOP
OF BASE
2
USE SUPPLIED HEX KEY TO SECURE
BOTTOM POST WITH WASHER AND
SCREW PROVIDED. TIGHTEN UNTIL
POST IS SECURE BUT CAN STILL ROTATE.
3
HEX KEY, SCREW
AND WASHER
MAKE SURE METAL
INSERT IS AT TOP

ASSEMBLY
CLAMP FLOOR
pg. 3
SCREW TOP POST INTO
BOTTOM POST
45ROTATE POST ASSEMBLY SO THAT ARROW ON
ORIENTATION STICKER IS CENTERED BETWEEN LEGS.
REMOVE STICKER.
USE HEX KEY TO FIRMLY TIGHTEN POST
IN BASE
6
ORIENTATION
STICKER

pg. 4
CLAMP FLOOR
ASSEMBLY
ADJUSTMENT
LIFT ARM TO ADJUST HEIGHT AND
ROTATE LIGHT SOURCE TO DESIRED POSITION
8
7SLIDE ARM ONTO POST
CONNECTOR LOCK
ABCD
PLUG TYPES:
POWER
SUPPLY
LOCK
1. SLIDE PLUG INTO POWER SUPPLY
2. ALIGN CONNECTOR/POWER
SUPPLY LOCKING FEATURES
3. INSERT CONNECTOR
4. TURN CONNECTOR 90 DEGREES
TO LOCK
A. N AMERICA B. UK C. EU D. AU
NOTE: CONTACT MANUFACTURER FOR
ADDITIONAL PLUG TYPE REQUIREMENTS.
HI-LOW SWITCH
