Pablo Corner Office Programming manual

CORNER
OFFICE

FREE STANDING LAMP ASSEMBLY
CORNER OFFICE
OPTICAL SWITCH: TAP FOR HIGH &
MEDIUM. PRESS AND HOLD FOR
FULL RANGE DIM
NOTE: BASE ASSEMBLY IS ONLY
NEEDED FOR FREE STANDING
ASSEBLY, NOT PANEL ASSEMBLY.
TWO 10-WATT USB PORTS (TYPE A)
SCREW BASE TO TOWER WITH PROVIDED ALLEN KEY.
35-WATT USB PORT (TYPE C)
1
1
FIRMLY INSERT LAMP HEAD INTO TOWER.
2
2
TOWER – WIPE WITH A DRY, LINT FREE CLOTH.
PANELS – TO REMOVE DUST AND SMALL DEBRIS: CLEAN WITH A SOFT HAIR BRUSH OR USE A VACUUM.
TO REMOVE OTHER SUBSTANCES: USE A DAMP CLOTH AND IF NEEDED A MILD DETERGENT.

CORNER OFFICE
CONNECT LAMP
TO POWER SUPPLY
LENGTH OF CORD SUPPLIED: 9 FT (274 CM)
CONNECT PLUG TO
POWER SUPPLY AND
PLUG INTO WALL

CORNER OFFICE
PANEL ASSMBLY
HARDWARE PLACEMENT
MATCHES HOLE PLACEMENT
ON BACK OF LAMP TOWER.
HARDWARE COMES PRE
MOUNTED TO PANELS.
SPACER
HARDWARE (x4)
SCREW

CORNER OFFICE
LINE HARDWARE UP WITH BOTTOM HOLE.
ON REVERSE SIDE USE PROVIDED ALLEN KEY
TO SCREW IN. DO NOT OVER TIGHTEN.
REPEAT STEPS 1-2. IN ORDER:
1) BOTTOM RIGHT HARDWARE
2) TOP RIGHT HARDWARE
3) BOTTOM LEFT HARDWARE
4) TOP LEFT HARDWARE
TO CHANGE PANEL ORIENTATION:
USE PROVIDED ALLEN KEY TO SEPERATE
SPACER AND SCREW FROM THE PANEL AND
REVERSE DIRECTION.
NOTE: STEPS ARE THE SAME FOR ALL
PANEL SIZES
EITHER SIDE OF PANEL CAN BE USED.
3
1
2

CORNER OFFICE
CORNER OFFICE POCKET AND ADJUSTMENTS
SLIDE POCKET ONTO
PANEL
POCKET ACCESSORY COMES STANDARD WITH 30” PANEL
LARGE PANEL CAN BE ATTACHED
FACING RIGHT OR LEFT
45°

CORNER OFFICE
CORNER OFFICE CONFIGURATION OPTIONS
