Pablo LIM360 Programming manual

ASSEMBLY & INSTALLATION INSTRUCTIONS
pg. 1
LIM360
[e-mail]
888 MARIN STREET
SAN FRANCISCO, CA
94124
PABLODESIGNS.COM

ASSEMBLY
LIM360
pg. 2
1SLIDE ARM ONTO POST
CONNECT LAMP CORD
TO POWER SUPPLY
22
PLUG TYPES AVAILABLE:
N. AMERICA UK EU AU

LIM360 USB CHARGING
LIM360
HIGHLIGHTS
SINGLE 5.0V USB OUTPUT SUPPORTS CHARGING FOR SMARTPHONES AND OTHER SIMILAR MOBILE DEVICES.
SPECIFICATIONS
USB 2.0 OR 1.1 STANDARD CORD REQUIRED
OUTPUT VOLTAGE: 5VDC + - 5%
OUTPUT CURRENT: 1A MAX
NOTE
LIM360 WILL CONTINUE TO CHARGE YOUR MOBILE DEVICE EVEN WHEN LAMP IS IN THE “OFF” POSITION.
PLEASE REFER TO YOUR MOBILE DEVICE’S USER MANUAL FOR COMPATIBILITY AND CHARGING TIME. PLEASE REFRAIN
FROM LEAVING YOUR DEVICE PLUGGED IN FOR LONGER THAN THE RECOMMENDED TIME, OTHERWISE IT MAY
RESULT IN OVER CHARGING.
pg. 3
3
USB CHARGING PORT
23

BASE INSERT REMOVAL
LIM360
pg. 4
4REMOVE ARM FROM BASE
5
5INSERT PAPER CLIP INTO
HOLE ON BOTTOM OF BASE
6PUSH UP ON BASE INSERT WITH PAPER
CLIP. GRAB EDGE OF INSERT AND LIFT
NOTE: REMOVAL OF INSERT IS INTENDED FOR CLEANING AND REPLACEMENT PURPOSES.
CONTACT MANUFACTURER TO ORDER REPLACEMENT INSERTS.
BASE INSERT
NOTE: BASE INSERT IS MAGNETICALLY ATTACHED FOR EASY REPLACEMENT
