Paccar MX Series Operating instructions

PEC017
5/3/2018
Programming Guide
EPA 2017

PEC017
5/3/2018 Page 2of 105
Table of Contents
1.0 Introduction.......................................................................................................................... 3
2.0 References .......................................................................................................................... 3
3.0 How to Read This Document............................................................................................... 3
4.0 Engine Ratings .................................................................................................................... 5
5.0 General Settings................................................................................................................ 12
6.0 Idle Settings....................................................................................................................... 14
Engine Idle Speed...................................................................................................................... 14
Engine Idle Shutdown Timer (EIST) .......................................................................................... 14
Fast Idle Control (FIC) ............................................................................................................... 22
7.0 Fan Clutch Control............................................................................................................. 24
8.0 Cruise Control (CC) ........................................................................................................... 25
9.0 Vehicle Speed Limiter........................................................................................................ 29
10.0 Engine Protection System ................................................................................................. 32
11.0 PACCAR Engine Brake..................................................................................................... 37
12.0 Power Take-Off (PTO) Mode Engine Speed Control........................................................ 45
13.0 Application Road Speed Limiter ........................................................................................ 65
14.0 Driveline Protection............................................................................................................ 66
15.0 Speed Control Management (SCM) .................................................................................. 67
16.0 Engine Recorder................................................................................................................ 74
17.0 Driver Shift Aid (DSA)........................................................................................................ 76
18.0 Driver Reward.................................................................................................................... 79
19.0Ether Starting Aid............................................................................................................... 85
20.0 Manual HC Desorb............................................................................................................ 86
21.0 Automatic HC Desorb........................................................................................................ 87
22.0 Parameters ........................................................................................................................ 90
23.0 Troubleshooting Errors in PACCAR Vehicle Pro............................................................. 103
24.0 Document Change Notes ................................................................................................ 105

PEC017
5/3/2018 Page 3of 105
1.0 Introduction
The purpose of this guide is to help dealers assist customers in making informed
decisions regarding the programming of their 2017 model year engine.
2.0 References
PACCAR Vehicle Pro (PVP) is a North American software application used for
making changes or adjusting engine parameters.
3.0 How to Read This Document
The programming guide is divided into several sections; each section represents a
programmable feature offered with the engine. The sections are divided into
subsections to organize the details of each feature: Overview, Standard Feature,
Feature Options, Orderable Feature & Options, Programmable Parameters,
Nonprogrammable Parameters, ON/OFF Requirements, Activate/Deactivate
Requirements, and Additional Information.
Overview
The feature is summarized focusing on the customer benefits, options, and
functionality.
Standard Feature
This subsection provides details of the stock or standard feature available with the
engine.
Feature Options
This subsection provides details of the optional features available with the engine.
Orderable Feature Options & Sales Codes
Features and options that require action during the ordering or the aftermarket
parameter setting change processes are detailed in a reference table. The table is
divided into three columns: Feature and Peterbilt/Kenworth Sales Codes. The
“Feature” column identifies the feature. The “Sales Code” columns provide the
division-specific sales code used to identify a feature option during the ordering
process.
Feature
Feature Name
Kenworth Sales Code
Peterbilt Sales Code

PEC017
5/3/2018 Page 4of 105
Programmable Parameters
Some features have individual parameters that are customizable; the details of these
programmable parameters are given in a reference table. The reference table is
divided into three columns: “Parameter Name,” “Number,” and
“Min/Max/Default/Unit”. The “Number” column references a code number to identify
the parameter during the ordering or the aftermarket parameter setting change
processes. The “Min/Max/Default/Unit” column defines the minimum and maximum
values of the parameter setting. If the parameter is not altered during specification of
the vehicle, the default setting is delivered from the factory. The units associated with
a parameter are labeled after the value of the parameter.
N-Code
Page Number
Min
Default
Max
Units
Parameter Name
Minimum
Default
Maximum
Units
* Explanatory notes or potential programming conflicts/requirements
Nonprogrammable Parameters
Unchangeable parameters, also known as nonprogrammable parameters, are used
to assist in the explanation of a feature. A reference table is provided which is
divided into two columns: “Parameter Name” and “Default/Unit”. The “Parameter
Name” column identifies the parameter. The “Default/Unit” column defines the default
or standard value and unit associated with it.
Parameter Name
Default/Units
Parameter Name
DEFAULT = Value (Unit)
ON/OFF Requirements
To define when a feature is enabled/ON or disabled/OFF, a reference table is used
to detail the required conditions. The table is divided into two columns: ON and OFF.
In each column, there is a list of conditions that must be met for the feature to be ON
or OFF. In addition, both columns include a stipulation of “All” or “Any” in
parentheses. “All” indicates that every condition listed in the column is required to
turn the feature ON or OFF. “Any” indicates that only one of the conditions listed in
the column is required to turn the feature ON or OFF.
ON (All/Any)
OFF (All/Any)
Setting
Setting

PEC017
5/3/2018 Page 5of 105
4.0 Engine Ratings
Overview
The engine rating states the peak power and torque of the engine. The engine is
available with several power ratings, allowing the engine to provide the correct
amount of power to complete the job while limiting the torque within driveline
component limitations. Increasing the power rating may put main driveline
components at risk for premature wear or damage.
Two MX-13 ratings and one MX-11 rating are available with Multi-Torque; these
ratings are identified by the MT in the option name. Multi-Torque engine ratings
provide an increased maximum torque output in the top two gears of rated
transmissions. The increased torque delivery from Multi-Torque is represented in
Graph 4.2 and Graph 4.4 as dashed lines.
Two refuse engine configurations are available for the MX-11, which provide specific
turbocharger and engine brake control strategies to allow for quieter operation.
MX-13 Standard Feature
Maximum Horsepower
Maximum Torque
405 HP @ 1,600 RPM
1,450 lbf-ft @ 900 RPM
MX-13 Feature Options
Maximum Horsepower
Maximum Torque
405 HP @ 1,600 RPM
1,450 lbf-ft @ 900 RPM
MT 430 HP @ 1,600 RPM
1,450 - 1,650 lbf-ft @ 900 RPM
430 HP @ 1,600 RPM
1,550 lbf-ft @ 900 RPM
MT 455 HP @ 1,600 RPM
1,550 / 1,750 lbf-ft @ 900 RPM
455 HP @ 1,600 RPM
1,650 lbf-ft @ 900 RPM
485 HP @ 1,600 RPM
1,650 lbf-ft @ 1,000 RPM
510 HP @ 1,600 RPM
1,850 lbf-ft @ 1,000 RPM
Note: Due to differences in engine hardware on the MX-13, re-rating engine
horsepower cannot be performed between engines with ratings of 455 HP or
less and engines of 485 HP or more.

PEC017
5/3/2018 Page 6of 105
MX-11 Standard Feature
Maximum Horsepower
Maximum Torque
385 HP @ 1600 RPM
1,450 lbf-ft @ 1000 RPM
MX-11 Feature Options
Maximum Horsepower
Maximum Torque
335 HP @ 1,600 RPM
1,150 lbf-ft @ 900 RPM
355 HP @ 1,600 RPM
1,250 lbf-ft @ 900 RPM
REFUSE 355 HP @ 1,600 RPM
1,250 lbf-ft @ 900 RPM
375 HP @ 1,600 RPM
1,350 lbf-ft @ 900 RPM
400 HP @ 1,600 RPM
1,450 lbf-ft @ 900 RPM
REFUSE 400 HP @ 1,600 RPM
1,450 lbf-ft @ 900 RPM
415 HP @ 1,600 RPM
1,550 lbf-ft @ 900 RPM
MT 430 HP @ 1,600 RPM
1,450 - 1,650 lbf-ft @ 900 RPM
430 HP @ 1,600 RPM
1,650 lbf-ft @ 900 RPM

PEC017
5/3/2018 Page 7of 105
MX-13 Orderable Options & Sales Codes
Feature
405 HP / 1,450 lbf-ft
0700607
2072717
MT 430 HP / 1,450-1,650 lbf-ft
0700633
2072718
430 HP / 1,550 lbf-ft
0700632
2072719
MT 455 HP / 1,550-1,750 lbf-ft
0700657
2072822
455 HP / 1,650 lbf-ft
0700656
2072820
485 HP / 1,650 lbf-ft
0700686
2072823
510 HP / 1,850 lbf-ft
0700701
2072824
MX-11 Orderable Options & Sales Codes
Feature
355 HP / 1,150 lbf-ft
0700191
2072404
355 HP / 1,250 lbf-ft
0700192
2072504
REFUSE 355 HP / 1,250 lbf-ft
0700198
2072503
375 HP / 1,350 lbf-ft
0700193
2072607
400 HP / 1,450 lbf-ft
0700194
2072610
REFUSE 400 HP / 1,450 lbf-ft
0700199
2072608
415 HP / 1,550 lbf-ft
0700195
2072720
MT 430 HP / 1,450 - 1,650 lbf-ft
0700196
2072722
430 HP / 1,650 lbf-ft
0700197
2072723

PEC017
5/3/2018 Page 8of 105
Additional Information
Graph 4.1 and Graph 4.2 show power and torque curves of the MX-13 engine.
Graph 4.1 –MX-13 Power and Torque Curves for Standard Ratings

PEC017
5/3/2018 Page 9of 105
Graph 4.2 - MX-13 Power and Torque Curves for Multi-Torque Ratings

PEC017
5/3/2018 Page 10 of 105
Graph 4.3 and Graph 4.4 show power and torque curves of the MX-11 engine.
Graph 4.3 –MX-11 Power and Torque Curves
