PacLights FCPG Series Assembly instructions
CAUTION: PLEASE FOLLOW THIS INSTRUCTION MANUAL CAREFULLY TO
PREVENT ANY INJURIES OR COMPLICATIONS THAT MAY ARISE.
WARNING: Before installing or maintaining the luminary, make sure all powers are
TURNED OFF.
Verify that supply voltage is correct by comparing it with the label information on all
fixtures.
Make all connections in accordance with the NEC requirements, and make sure all
luminaries are properly secured to prevent any wire complications. This luminary is
to always be installed with the lens facing down and its not to exceed the maximum
ambient temperature rating noted on the specification sheet.
Includes: FCPG040, FCPG055, FCPG075, FCPG100
FCPG Series LED Garage Light Installation Sheet
Copyright © 2017 PacLights All Rights Reserved
(B) INSTALLATION STEPS FOR SURFACE MOUNT
The FCPG fixture has two cables attached to it.
The First cable consists of 3 coductors: ACL (black),
ACN (white), and a ground (green). These conductors
are to be connected to a 120v AC Power Supply Cable.
The second cable consists of two conductors: Dim+
(purple) and a Dim- (gray). These cables are used if the
customer is installing a 0-10v dimmer to the FCPG
fixture. The dimmer is optional, please consult with a
Sales representative for more information.
* LED DRIVER Input Ground (green) wire only available for selected fixtures.
If the Ground Wire is missing and the Power Supply includes a ground wire, connect the power supply ground wire to the fixture.
02-00030-022318-1
Note: Instructionsare subject to change at any time without notice
CAUTION: PLEASE FOLLOW THIS INSTRUCTION MANUAL CAREFULLY TO
PREVENT ANY INJURIES OR COMPLICATIONS THAT MAY ARISE.
WARNING: Before installing or maintaining the luminary, make sure all powers are
TURNED OFF.
Verify that supply voltage is correct by comparing it with the label information on all
fixtures.
Make all connections in accordance with the NEC requirements, and make sure all
luminaries are properly secured to prevent any wire complications. This luminary is
to always be installed with the lens facing down and its not to exceed the maximum
ambient temperature rating noted on the specification sheet.
Includes: F2SB048, F2SB080, F2SB100, F2SB150, F2SB200, F2SB300
F2SB Series LED Area Light Installation Sheet
0200015-170815-1
Copyright © 2017 PacLights All Rights Reserved Note: Instructionsare subject to change at any time without notice
(F2SB048)
STANDARD INSTALLATION STEPS
MOUNTING METHODS:
Please select the installation instructions based on proper mounting method:
SKU Description
AC2SBF Slipfitter Mount for 2 3/8 inch OD (2” Pipe
Bracket) Tenon (0º to 90º Vertical Aiming Angle)
AC2SBTM Trunnion Mount
AC2SBAM1 6” Arm Mount for Square Pole
AC2SBAM2 6” Arm Mount for Round Pole
LED DRIVER
V(-)
[BLACK]
V(+)
[RED]
TO LOAD
[LED BOARD]
[WHITE]
[BLACK]
ACN [BLUE/WHITE]
ACL [BROWN/BLACK]
GROUND [GREEN]
NEUTRAL [WHITE]
GROUND [GREEN]
HOT [BLACK]
INPUT
OUTPUT
DIM
WHITE (-)
BLUE(+)
Inside Junction Box
(Not Included) PRE-CONNECTED
(DO NOT DISCONNECT)
1. Connect the ACL and the ACN from the driver to the conduit with the AC Power Supply cords.Follow the Wiring Diagram provided.
* LED DRIVER Input Ground (green) wire only available for selected fixtures.
If the Ground Wire is missing and the Power Supply includes a ground wire, connect the power supply ground wire to the fixture.
(FOR DIMMABLE VERSION)
AC2SBF
AC2SBAM1 AC2SBAM2
AC2SBTM
TROUBLESHOOTING
1) Make sure the Power Outlet matches the Voltage on the driver. It is very
important for the Power Outlet and the driver to match. If these values do not match,
this can cause the LED fixture to not turn on or damage the driver.
2) Check the LED Driver Input Connections. Make sure the ACL on the driver is
connected to the hot power outlet cable and the ACN on the driver is connected to the
Neutral wire on the power outlet.
3) Check the LED Driver Output Connections. These connections will already come
installed when the fixture is purchased. However, if the Input Connections are double-
checked and the lumen is not turning on. It might be a good idea to make sure there are
no cuts in the wires and everything is properly connected.
Please select the installation instructions based on proper mounting method:
SKU Description
AC2SBPS Photocell,Twist Lock, 1.5 FC, 120-277 vAC, Instant On, 2-5 sec
OFF Delay
AC2SBPS480 Photocell,Twist Lock, 1.5 FC, 480 vAC, Instant On, 2-5 sec
OFF Delay
AC2SBSU Surge Protector. VMAX AC: 277v, maximum Lightning Surge
Current: 20,000A
AC2SBSU480 Surge Protector. VMAX AC: 277v, maximum Lightning Surge
Current: 20,000A
OPTIONAL ADDONS
3a. Open the canopy light and use the Wiring
Diagram at the bottom of the page in order
to connect the LED Driver to the Power
Supply Cables that are inside the conduit.
All connections must be compliant with
NEC standards and must be
performed by a certified electrician.
1. Using an allen wrench, remove
the two socket head machine
screws in order to access the LED
driver inside the luminaire.
2. Using a slotted screw driver, remove the top
3/4” conduit plug from the top side of the FCPG
fixture. (This is only if the conduit is directly
above the luminaire. If the conduit is coming
from one of the sides of the luminaire, the FCPG
canopy also has conduit plugs on each side of
the fixture.)
WIRING DIAGRAM
DRAFT
(A) INSTALLATION STEPS WITH CONDUIT
4a. Once all the wires are properly
connected, close the FCPG luminaire
and fasten the two socket head
machines screws back to lock the cap
in place.
5a. Add waterproof sealant on any
possible opening that will allow fluids
to enter the back box.
3b. Once you open the back box from
the garage light, you will notice there
are filled in slots which can be used as
a guide to drill holes (depending on the
Junction Box being used, drill holes on
the necessary slots).
4b. The FCPG luminaire also comes
with a foam felt pad to prevent any
liquids from entering the fixture. Place
the felt pad in between the fixutre and
the mounting surface.
5b. Mount the Back Box to the ceiling using
mounting screws (not included). The number
and size of the mounting screws must be
calculated by a certified personnel and may
vary depending on the mounting surface and
junction box being used.
6. After all steps are properly followed, the
FCPG fixture is ready to be turned on. At this
point, provide power to the fixture.
CAUTION: PLEASE FOLLOW THIS INSTRUCTION MANUAL CAREFULLY TO
PREVENT ANY INJURIES OR COMPLICATIONS THAT MAY ARISE.
WARNING: Before installing or maintaining the luminary, make sure all powers are
TURNED OFF.
Verify that supply voltage is correct by comparing it with the label information on all
fixtures.
Make all connections in accordance with the NEC requirements, and make sure all
luminaries are properly secured to prevent any wire complications. This luminary is
to always be installed with the lens facing down and its not to exceed the maximum
ambient temperature rating noted on the specification sheet.
Copyright © 2017 PacLights All Rights Reserved
LED DRIVER
V(-)
[BLACK]
V(+)
[RED]
TO LOAD
[LED BOARD]
[WHITE]
[BLACK]
ACN [BLUE/WHITE]
ACL [BROWN/BLACK]
GROUND [GREEN]
NEUTRAL [WHITE]
GROUND [GREEN]
HOT [BLACK]
INPUT
OUTPUT
DIM
WHITE (-)
BLUE(+)
Inside F2SB
PRE-CONNECTED
(DO NOT DISCONNECT)
Using a J-Box (not included), Connect the ACL and the ACN from the driver to the conduit with the AC Power Supply cords.Follow the Wiring Diagram provided.
* LED DRIVER Input Ground (green) wire only available for selected fixtures.
If the Ground Wire is missing and the Power Supply includes a ground wire, connect the power supply ground wire to the fixture.
(FOR DIMMABLE VERSION)
7. Using an allen wrench, remove the
two socket head machine screws in
order to access the LED driver inside
the fixture.
8. Using a slotted screw driver,
remove one of the conduit plugs from
a side of the luminaire in order to run
a flexible conduit with a power supply
cable inside it.
Note: Instructionsare subject to change at any time without notice
5. Run the power cord from the
arm mount to the F2SB luminaire,
Once the cable has been inserted
inside the F2SB, connect the power
cable to the LED Driver inside the
F2SB. In order to access the LED
Driver cables, the electrician must
first remove the [6] screws from the
service door using a #2 Phillips
screw driver and make all
connections inside the luminaire.
6. Once all wiring is complete,
Close the service door and use
the M12 bolt to fasten the
Arm Mount to the F2SB.
Do not fasten completely.
02-00030-022618-2
FCPG Series LED Garage Light Installation Sheet
Includes: FCPG040, FCPG055, FCPG075, FCPG100
1. Using the provided screws, fasten the two
brackets to the top side of the FCPG fixture.
Use an allen wrench to tighten the screws to
a safe locking torch.
2. Mount the
U-Shaped bracket
to the ceiling
using mounting
screws (not
included). The
number and size
of the mounting
screws must be
determined by a
certified
personnel and
may vary
depending on
the mounting
surface.
INSTALLATION STEPS FOR SURFACE MOUNT
9. Run the flexible conduit through the opening on
the FCPG back box and lock it into the conduit
plug opening. Extend the power supply cables
inside the conduit to be connected to the LED
Driver inside the FCPG.
10. Use the wiring diagram provided to properly
connect the fixture to the power supply. All
connections must be compliant with NEC
standards and must be performed by a certified
electrician.
The FCPG fixture has two cables attached to it.
The First cable consists of 3 coductors: ACL (black),
ACN (white), and a ground (green). These conductors
are to be connected to a 120v AC Power Supply Cable.
The second cable consists of two conductors: Dim+
(purple) and a Dim- (gray). These cables are used if the
customer is installing a 0-10v dimmer to the FCPG
fixture. The dimmer is optional, please consult with a
Sales representative for more information.
3. Using the provided machine screws, carefully fasten the top
bracket to the two brackets attached to the FCPG by aligning
the holes and fastening to the desired height.
11. After all steps
are properly
followed, the
FCPG fixture is
ready to be
turned on. At this
point, provide
power to the
fixture.
AC-CPG-SB Suspended Mount Bracket
