Palmgren TU 1503V User manual

GB
Operating manual
Version 1.0.3
Lathe
Item no:9684495
Shown with
Optional Stand

Version 1.0.3 dated 2014-05-14Page 2 Original operating instructions
TU1503VGB
Table of contents
1 Safety
1.1 Safety instructions (warning notes)...........................................................................................................7
1.1.1 Classification of hazards...........................................................................................................................7
1.1.2 Other pictograms......................................................................................................................................8
1.2 Intended use.............................................................................................................................................8
1.3 Reasonably foreseeable misuses.............................................................................................................9
1.3.1 Avoiding misuses......................................................................................................................................9
1.4 Possible dangers caused by the machine ................................................................................................9
1.5 Qualification of personnel.......................................................................................................................10
1.5.1 Target group...........................................................................................................................................10
1.5.2 Authorized personnel..............................................................................................................................11
1.5.3 Obligations of the operating company....................................................................................................11
1.5.4 Obligations of the operator .....................................................................................................................11
1.5.5 Additional requirements regarding the qualification................................................................................11
1.6 Operators positions.................................................................................................................................12
1.7 Safety measures during operation..........................................................................................................12
1.8 Safety devices ........................................................................................................................................12
1.9 EMERGENCY-STOP button...................................................................................................................13
1.9.1 Protective cover with safety switch.........................................................................................................13
1.9.2 Lathe chuck protection with position switch............................................................................................13
1.9.3 Lathe chuck key......................................................................................................................................13
1.10 Safety check...........................................................................................................................................14
1.11 Personnel protective equipment .............................................................................................................14
1.12 For your own safety during operation.....................................................................................................14
1.13 Disconnecting and securing the lathe.....................................................................................................15
1.14 Mechanical maintenance work ...............................................................................................................15
2 Technical data
2.1 Emissions ...............................................................................................................................................17
2.2 Dimensions, installation plan..................................................................................................................18
3 Unpacking and connecting
3.1 Scope of delivery....................................................................................................................................19
3.2 Storage...................................................................................................................................................19
3.3 Installation and assembly .......................................................................................................................20
3.3.1 Requirements regarding the installation site...........................................................................................20
3.3.2 Assembling.............................................................................................................................................20
3.4 First commissioning................................................................................................................................20
3.4.1 Warming up the machine........................................................................................................................21
3.4.2 Cleaning and lubricating.........................................................................................................................21
3.4.3 Functional test ........................................................................................................................................21
3.4.4 Functional check.....................................................................................................................................21
4 Assembly and function
4.1 Construction features..............................................................................................................................22
4.2 Spindle stock with feed gear...................................................................................................................22
4.2.1 Gear........................................................................................................................................................23
4.2.2 Feed gear ...............................................................................................................................................23
4.3 Lathe saddle...........................................................................................................................................23
4.4 Top slide.................................................................................................................................................23
4.5 Cross slide..............................................................................................................................................24
4.6 Tailstock..................................................................................................................................................24
5Handling
5.1 Safety......................................................................................................................................................25
5.2 Control and indicating elements .............................................................................................................25

Version 1.0.3 dated 2014-05-14 Page 3Original operating instructions
TU1503V GB
5.2.1 Switching elements ................................................................................................................................26
5.2.2 Switching on the machine ......................................................................................................................26
5.2.3 Switching off the machine ......................................................................................................................27
5.3 Clamping a tool ......................................................................................................................................27
5.3.1 Tool height..............................................................................................................................................27
5.4 Speed adjustment ..................................................................................................................................28
5.4.1 Changing the speed range.....................................................................................................................28
5.5 Straight turning.......................................................................................................................................29
5.5.1 Manually.................................................................................................................................................29
5.5.2 About self-acting feed.............................................................................................................................29
5.6 Turning short tapers with the top slide ...................................................................................................29
5.7 Clamping a workpiece into the three jaw chuck .....................................................................................30
5.7.1 Replacing the clamping jaws on the lathe chuck....................................................................................30
5.8 Adjusting feeds and thread pitches ........................................................................................................31
5.9 Feed table / Table for thread cutting ......................................................................................................31
5.10 Changing the change gears ...................................................................................................................32
5.10.1 Switching on the feed.............................................................................................................................32
5.11 General working advice - coolant...........................................................................................................32
6 Appendix turning
6.1 ISO-designation system for tool holder, inside machining .....................................................................34
6.2 ISO-designation system for tool holder, outside machining...................................................................35
6.3 Cutter with hard metal reversible carbide tip soldered on ......................................................................36
6.4 Cut the first chips....................................................................................................................................36
6.5 Outside machining, longitudinal turning and facing................................................................................37
6.6 Inside machining, drilling and longitudinal turning..................................................................................38
6.7 Tapping of external and internal threads................................................................................................38
6.7.1 Thread types ..........................................................................................................................................39
6.8 Metric threads (60° flank angle) .............................................................................................................41
6.8.1 British thread (55° flank angle)...............................................................................................................42
6.8.2 Indexable inserts....................................................................................................................................44
6.8.3 Examples for thread cutting....................................................................................................................45
6.9 Recessing, cutting off and turning off.....................................................................................................47
6.10 Turning of cones with high precision......................................................................................................48
6.11 Cutting materials ....................................................................................................................................51
6.12 Standard values for cutting data when turning.......................................................................................52
6.13 Cutting speed table ................................................................................................................................53
6.14 Grinding or regrinding of cutting edge geometries of turning tools.........................................................53
6.14.1 Terms for the rotating tool......................................................................................................................54
6.14.2 Cutting edge geometry for turning tools.................................................................................................55
6.14.3 Types of cutting form levels....................................................................................................................55
6.15 Lifetime and wear characteristics...........................................................................................................57
7 Maintenance
7.1 Safety.....................................................................................................................................................58
7.2 Inspection and maintenance ..................................................................................................................58
7.3 Repair.....................................................................................................................................................59
8 Ersatzteile - Spare parts
8.1 Ersatzteilzeichnung Antrieb - Drawing spare parts actuation.................................................................61
8.2 Ersatzteilzeichnung Spindelstock - Drawing spare parts headstock......................................................62
8.3 Ersatzteilzeichnung Abdeckungen - Drawing spare parts covers ..........................................................63
8.3.1 Ersatzteilliste Antrieb, Spindestock - Spare parts list actuation, headstock...........................................64
8.4 Ersatzteilzeichnung Planschlitten, Oberschlitten- Drawing spare parts cross slide, top slide................65
8.4.1 Ersatzteile Planschlitten, Oberschlitten - Spare parts list cross slide, top slide .....................................66
8.5 Ersatzteilzeichnung Maschinenbett - Drawing spare parts machine bed...............................................67
8.5.1 Ersatzteile Maschinenbett - Spare parts list machine bed .....................................................................68

Version 1.0.3 dated 2014-05-14Page 4 Original operating instructions
TU1503VGB
8.6 Ersatzteilzeichnung Reitstock - Drawing spare parts tailstock ..............................................................69
8.6.1 Ersatzteile Reitstock - Spare parts tailstock ..........................................................................................70
8.7 Ersatzteilzeichnung Wechselradgetriebe - Drawing spare parts change gear.......................................71
8.7.1 Ersatzteile Wechselradgetriebe - Spare parts change gear...................................................................72
8.8 Maschinenschilder - Machine labels.......................................................................................................73
8.8.1 Maschinenschilder - Machine labels.......................................................................................................73
8.9 Schaltplan - Wiring diagram....................................................................................................................74
8.9.1 Ersatzteile elektrische Bauteile - Spare parts electrical components....................................................75
9 Malfunctions
9.1 Malfunctions on the lathe........................................................................................................................76
10 Appendix
10.1 Copyright ................................................................................................................................................77
10.2 Terminology/Glossary.............................................................................................................................77
10.3 Change information operating manual....................................................................................................77
10.4 Liability claims for defects / warranty......................................................................................................78
10.5 Note regarding disposal / options to reuse:............................................................................................78
10.5.1 Decommissioning ...................................................................................................................................79
10.5.2 Disposal of the packaging of new devices..............................................................................................79
10.5.3 Disposing of the old device.....................................................................................................................79
10.5.4 Disposal of electrical and electronic components...................................................................................79
10.6 Disposal via municipal collection............................................................................................................80
10.7 RoHS, 2002/95/EC.................................................................................................................................80
10.8 Product follow-up....................................................................................................................................80

Version 1.0.3 dated 2014-05-14 Page 5Original operating instructions
TU1503V GB
Preface
Dear customer,
Thank you very much for purchasing a product made by company.
Company metal working machines offer a maximum of quality, technically company solutions and convince
by an outstanding price performance ratio. Continuous enhancements and product innovations guarantee
state-of-the-art products and safety at any time.
Before commissioning the machine please thoroughly read these operating instructions and get familiar with
the machine. Please also make sure that all persons operating the machine have read and understood the
operating instructions beforehand.
Keep these operating instructions in a safe place nearby the machine.
Information
The operating instructions include indications for safety-relevant and proper installation, operation and main-
tenance of the machine. The continuous observance of all notes included in this manual guarantee the safety
of persons and of the machine.
The manual determines the intended use of the machine and includes all necessary information for its eco-
nomic operation as well as its long service life.
In the paragraph "Maintenance" all maintenance works and functional tests are described which the operator
must perform in regular intervals.
The illustration and information included in the present manual can possibly deviate from the current state of
construction ofyour machine. Being the manufacturer we are continuously seeking for improvements and
renewal of the products. Therefore, changes might be performed without prior notice. The illustrations of the
machine may be different from the illustrations in these instructions with regard to a fewdetails. However,
this does not have any influence on the operability of the machine.
Therefore, no claims may be derived from the indications and descriptions. Changes and errors are reserved!
Your suggestion with regard to these operating instructions are an important contribution to optimising our
work which we offer to our customers. For any questions or suggestions for improvement, please do not hesi-
tate to contact our service department.
If you have any further questions after reading these operating instructions and you are not able to
solve your problem with a help of these operating instructions, please contact your specialised
dealer or
C.H.HANSON
2000 North Aurora Rd.
Naperville,IL 60563
Call 800-827-3398

Version 1.0.3 dated 2014-05-14Page 6 Original operating instructions
TU1503VGB
1 Safety
Glossary of symbols
This part of the operating instructions
explains the meaning and use of the warning notices included in these operating instruc-
tions,
defines the intended use of the lathe,
points out the dangers that might arise for you or others if these instructions are not
observed,
informs you about how to avoid dangers.
In addition to these operation instructions, please observe
the applicable laws and regulations,
the legal regulations for accident prevention,
the prohibition, warning and mandatory signs as well as the warning notes on the lathe .
European standards must be kept during installation, operation, maintenance and repair of the
lathe.
If European standards are not applied at the national legislation of the country of destination,
the specific applicable regulations of each country are to beobserved.
If necessary, the required measures must be taken to comply with the specific regulations of
each country before the lathe is used for the first time.
Always keep this documentation close to the lathe.
INFORMATION
If you are unable to solve a problem using these operating instructions, please contact us for
advice:
C.H.HANSON
2000 North Aurora Rd.
Naperville,IL 60563
Call 800-827-3398
gives further advice
calls on you to act
enumerations

Version 1.0.3 dated 2014-05-14 Page 7Original operating instructions
TU1503V GB
1.1 Safety instructions (warning notes)
1.1.1 Classification of hazards
We classify the safety warnings into various levels. The table below gives an overview of the
classification of symbols (ideogram) and the warning signs for each specific danger and its
(possible) consequences.
Ideogram Warning alert Definition / consequence
DANGER! Threatening danger that will cause serious injury or death to people.
WARNING! A danger that might cause severe injury to the personnel or can lead to
death.
CAUTION! Danger or unsafe procedure that might cause injury to people or dam-
age to property.
ATTENTION!
Situation that could cause damage to the machine and product and
other types of damage.
No risk of injury to people.
INFORMATION
Application tips and other important or useful information and notes.
No dangerous or harmful consequences for people or objects.
In case of specific dangers, we replace the pictogram by
or
general danger by a warning of injury of hands, hazardous electri-
cal voltage, rotating parts.

Version 1.0.3 dated 2014-05-14Page 8 Original operating instructions
TU1503VGB
1.1.2 Other pictograms
1.2 Intended use
WARNING!
In the event of improper use, the lathe
will endanger personnel,
the machine and other material property of the operating company will be endan-
gered,
the correct function of the machine may be affected.
The machine is designed and manufactured to be used in environments where there is no po-
tential danger of explosion.
The lathe is designed and manufactured for straight turning and facing round and regular
formed three-, six- or twelve-square workpieces in cold metal, castings and plastics or similar
materials that do not constitute a health hazard or do not create dust, such as wood, Teflon®.
The lathe must only be installed and operated in a dry and ventilated place. Theclamping
workpieces in the feed may only be effected with the supplied the special key for chucks.
If the lathe is used in any way other than described above, modified without authorization of
company, then the lathe is being used improperly.
We will not be held liable for any damages resulting from any operation which is not in accord-
ance with the intended use.
We expressly point out that the guarantee or CE conformity will expire due to any constructive
technical or procedural changes which had not been performed by the company.
It is also part of intended use that you
the operating manual is constantly observed,
the inspection and maintenance instructions are observed.
observe the limits of the lathe.
 "Technical data“ on page 16
Warning danger of
slipping! Caution, danger of explosive substances! Warning of automatic start-up! Warning hot surface! Warning biological hazard!
Switching on
forbidden! Pull the main plug! Use safety glasses! protection Use ear protection! Use protective gloves!
Use protective boots! Use protective suit! Protect the
environment! Contact address

Version 1.0.3 dated 2014-05-14 Page 9Original operating instructions
TU1503V GB
In order to achieve company cutting performance, it is essential to choose the right turning tool,
feed, tool pressure, cutting speed and coolant.
 "Appendix turning“ on page 33
WARNING!
Heaviest injuries through improper use.
It is forbidden to makeany modifications or alternations to the operation values of the
lathe. They could endanger the staff and cause damage to the lathe.
INFORMATION
The lathe TU1503V is built according to the standard DIN EN 55011 class B.
WARNING!
The class B (machine tools) is intended to be used in residential facilities, where the
power is supplied via a public low voltage supply system.
ATTENTION!
If the lathe is not used as intended or if the safety directives or the operating instructions
are ignored the liability of the manufacturer for any damages to persons or objects
resulting hereof is excluded and the claim under guarantee is becoming null and void!
1.3 Reasonably foreseeable misuses
Any other use as the one determined under the "Intended use" or any use beyond the
described use shall be deemed as not in conformity and is forbidden.
Any other use has to be discussed with the manufacturer.
It is only allowed to process metal, cold and non-inflammable materials with the lathe.
In order to avoid misuse, it is necessary to read and understand theoperating instructions
before the first commissioning.
The operators must be qualified.
1.3.1 Avoiding misuses
Use of suitable cutting tools.
Adapting the speed adjustment and feed to the material and workpiece.
Clamp workpieces firmly and vibration-free.
1.4 Possible dangers caused by the machine
The lathe has undergone a safety inspection (analysis of danger with assessment of risks). It
has been designed and built on the basis of this analysis using the latest technological advanc-
es.
Nonetheless, there remains a residual risk, since the machine operates with
high revolutions,
rotating parts,
with electrical voltages and currents.
We have used construction resources and safety techniques to minimize the health risk to per-
sonnel resulting from these hazards.
If the lathe is used and maintained by the staff who are not duly qualified, there may be a risk
resulting from incorrect or unsuitable maintenance of the lathe.

Version 1.0.3 dated 2014-05-14Page 10 Original operating instructions
TU1503VGB
INFORMATION
Everyone involved in the assembly, commissioning, operation and maintenance must
be duly qualified,
strictly follow these operating instructions.
In the event of improper use
there may be a risk to the personnel,
there may be a risk to the machine and other material values,
the correct function of the lathe may be affected.
Always disconnect the lathe if cleaning or maintenance work is being carried out, or is no longer
in use.
WARNING!
The lathe may only be used with the safety devices activated.
Disconnect the lathe immediately whenever you detect a failure in the safety devices or
when they are not mounted!
All additional installations carried out by the operator must incorporate the prescribed
safety devices.
This is your responsibility being the operating company!
 "Safety measures during operation“ on page 12
1.5 Qualification of personnel
1.5.1 Target group
This manual is addressed to
the operating companies,
the operators,
the personnel for maintenance works.
Therefore, the warning notes refer to both operation and maintenance of the machine.
Always disconnect the machine plug from the mains. This will prevent it from being used by un-
authorized persons.
The qualifications of the personnel for the different tasks are mentioned below:
Operator
The operator is instructed by the operating company about the assigned tasks and possible
risks in case of improper behaviour. Any tasks which need to be performed beyond the opera-
tion in the standard mode must only be performed by the operator if it is indicated in these
instructions and if the operating company expressively commissioned the operator.
Electrical specialist
Due to his professional training, knowledge and experience as well as his knowledge of respec-
tive standards and regulations the electrical specialist is able to perform works on the electrical
system and to recognise and avoid any possible dangers himself.
The electrical specialist is specially trained for the working environment in which he is working
and knows the relevant standards and regulations.
Qualified personnel
Due to their professional training, knowledge and experience as well as their knowledge of rele-
vant regulations the qualified personnel is able to perform the assigned tasks and to recognise
and avoid any possible dangers themselves.

Version 1.0.3 dated 2014-05-14 Page 11Original operating instructions
TU1503V GB
Instructed person
Instructed personnel were instructed by the operating company about the assigned tasks and
any possible risks in case of improper behaviour.
INFORMATION
Everyone involved in the assembly, commissioning, operation and maintenance must
be duly qualified,
strictly follow these operating instructions.
In the event of improper use
there may be a risk to the personnel,
there may be a risk to the machine and other material values,
the correct function of the lathe may be affected.
1.5.2 Authorized personnel
WARNING!
Inappropriate operation and maintenance of the machine constitutes a danger for the
staff, objects and the environment.
Only authorized personnel may operate the machine!
Persons authorized to operate and maintain should be trained technical personnel and instruct-
ed by the ones who are working for the operating company and for the manufacturer.
1.5.3 Obligations of the operating company
The operator must instruct the staff at least once per year regarding
all safety standards that apply to the machine.
the operation,
accredited technical guidelines.
The operator must also
check personnel‘s state of knowledge,
document the trainings/instructions,
require personnel to confirm participation in training/instructions by means of a signature,
check whether the personnel is working safety- and risk-conscious and observe the operat-
ing instructions.
1.5.4 Obligations of the operator
The operator must
have read and understood the operating manual,
be familiar with all safety devices and regulations,
be able to operate the machine.
1.5.5 Additional requirements regarding the qualification
For work on electrical components or equipment, there are additional requirements:
Must only be performed by a qualified electrician or person working under the instructions
and supervision of a qualifiedelectrician.
Before carrying out work on electrical components or operating units, the following meas-
ures must be taken, in the order given.
disconnect all poles.
Secure against switching on.
Check if the machine is zero potential.

Version 1.0.3 dated 2014-05-14Page 12 Original operating instructions
TU1503VGB
1.6 Operators positions
The operator’s position is in front of the machine.
1.7 Safety measures during operation
CAUTION!
Risk due to inhaling of health hazardous dusts and mist.
Dependent on the material which need to be processed and the used auxiliaries dusts
and mist may be caused which might impair you health.
Make sure that the generated health hazardous dusts and mist are safely sucked off at the
point of origin and is dissipated or filtered from the working area. To do so, use a suitable
extraction unit.
CAUTION!
Risk of fire and explosion by using flammable materials or cooling lubricants.
Before processing inflammable materials (e.g. aluminium, magnesium) or using
inflammable auxiliary materials (e.g. spirit) it is necessary to take additional preventive
measures in order to safely avoid health risks.
CAUTION!
Risk of winding-up or cutting damages when using hand tools.
The machine is not designed for the use of hand tools (e.g. emery cloth or files). It is
forbidden to use any hand tools on this machine.
1.8 Safety devices
Use the lathe only with properly functioning safety devices.
Stop the lathe immediately if there is a failure on the safety device or if it is not functioning for
any reason.
It is your responsibility!
If a safety device has been activated or has failed, the lathe must only be used if you
the cause of the failure has been removed,
you have made sure that there is no existing danger for personnel or objects.
WARNING!
If you bypass, remove or override a safety device in any other way, you are endangering
yourself and other persons working on the machine. The possible consequences are
injuries may occur due to workpiece or parts of workpieces flying off,
contact with rotating parts,
fatal electrocution.
WARNING!
The separating protective equipment which is made available and delivered together
with the machine is designed to reduce the risk of workpieces or fractions of them which
being expelled, but not to remove them completely.
Always work carefully and observe the limits of their machining process.
The lathe includes the following safety devices:
a EMERGENCY STOP button
a protective cover on the headstock,
a special key for the lathe chuck,
a lathe chuck protection with position switch.

Version 1.0.3 dated 2014-05-14 Page 13Original operating instructions
TU1503V GB
1.9 EMERGENCY-STOP button
The EMERGENCY-STOP button
switches the lathe off.
Knocking on the emergency stop device
triggers an emergency stop.
After actuating the switch, turn it to the
right, in order to restart the lathe.
Img.1-1: EMERGENCY-STOP button
1.9.1 Protective cover with safety switch
The spindle head of the lathe is equipped
with a fixed, separating protective cover.
The locked position is monitored by
means of an electrical limit switch.
INFORMATION
It is not possible to start the machine until
the protective cover is closed.
Img.1-2: for the protective cover of the headstock
1.9.2 Lathe chuck protection with position switch
The lathe is provided with a lathe chuck
protection. The lathe can only be
switched on if the lathe chuck protection
is closed.
Img.1-3: lathe chuck protection
1.9.3 Lathe chuck key
The lathe is equipped with a special key
for chucks. Once the lathe chuck key has
been released, it is pushed out of the
lathe chuck by a spring.
CAUTION!
Only operate the lathe using this key.
Img.1-4: Lathe chuck key
EMERGENCY-
STOP button
Protective cover
Lathe chuck pro-
tection
Safety lathe chuck
key
Lathe chuck key

Version 1.0.3 dated 2014-05-14Page 14 Original operating instructions
TU1503VGB
1.10 Safety check
Check the lathe regularly.
Check all safety devices
before starting work,
once a week,
after every maintenance and repair work.
1.11 Personnel protective equipment
For certain work personal protective equipment is required.
Protect your face and your eyes: Wear a safety helmet with facial protection when performing
works where your face and eyes are exposed to hazards.
Use protective gloves when handling pieces with sharp edges.
During operation of the lathe, the wearing of gloves is prohibited because of the risk of winding
up.
Use safety shoes when you assemble, disassemble or transport heavy components.
Use ear protection if the noise level (emission) in the workplace exceeds 80 dB (A).
Before starting work, make sure that the prescribed personal protective equipment is available
at the workplace.
CAUTION!
Dirty or contaminated personnel protective equipment can cause diseases. Clean it each
time after use and at least once a week.
1.12 For your own safety during operation
We specially point out the specific dangers when working with and on the lathe.
General check
Equipment Check OK
Protective covers,
lathe chuck protection Mounted, firmly bolted and not damaged
Signs,
Markings Installed and legible
Functional check
Equipment Check OK
EMERGENCY-STOP but-
ton When the EMERGENCY STOP push button is activated, the lathe must switch off.
Lathe chuck key Once the chuck key has been released, it should be automati-
cally pressed out of the lathe chuck.
Lathe chuck protection /
protective cover head-
stock
The lathe shall only run with the lathe chuck protection / protec-
tive cover headstock closed.

Version 1.0.3 dated 2014-05-14 Page 15Original operating instructions
TU1503V GB
WARNING!
Before switching on the lathe make sure that there are no
no dangers generated for persons,
not cause damage to equipment.
Avoid any risky working practices:
Make sure that nobody is endangered by your work.
Clamp the workpiece tightly before activating the lathe.
For clamping workpieces, only use the special chuck key supplied.
Mind the maximum chuck opening.
Wear safety goggles.
Do not remove the turning chips by hand. Use a chip hook and / or a hand brush to remove
turning chips.
Clamp the turning tool at the correct height and with the least possible overhang.
Turn off the lathe before measuring the workpiece.
The instructions mentioned in these operating instructions have to be strictly observed dur-
ing assembly, operation, maintenance and repair.
Do not work on the lathe, if your concentration is reduced, for example, because you are
taking medication.
Observe the accident prevention regulations issued by your Employers Liability Insurance
Association or other competent supervisory authority, responsible for your company.
Stay at the lathe until all movements have come to a complete standstill.
Use the prescribed personnel protective equipment. Make sure to wear a well-fitting work
suit and, if necessary, a hairnet.
We specially point out the specific dangers when working with and on the machine.
1.13 Disconnecting and securing the lathe
Pull the mains plug before beginning any maintenance or repair work or or switch off the
supply voltage to the lathe. All machine components and hazardous voltages and move-
ments are disconnected.
Attach a warning sign on the machine.
1.14 Mechanical maintenance work
Remove or install protection safety devices before starting any maintenance work and re-install
them once the work has been completed.This includes:
Covers,
Safety indications and warning signs,
earth (ground) connections.
If you remove protection or safety devices, refit them immediately after completing the work.
Check if they are working properly!

Version 1.0.3 dated 2014-05-14Page 16 Original operating instructions
TU1503VGB
2 Technical data
The following information are the dimensions and indications of weight and the manufacturer‘s
approved machine data..
Electrical connection
Total connection rate 110V ; 5/8HP ; 60Hz
Degree of protection IP 54
Machine data
Height of centres [mm] 70
Max. swing [mm] 140
Max. swing over
Cross slide [mm] 70
Distance between centres [mm] 250
Spindle speeds [min -1] 120 - 3000
Spindle taper MT1
Spindle hole, rod opening [mm] 11
Bed width [mm] 70
Travel of top slide [mm] 40
Travel of cross slide [mm] 55
Tailstock cone MT1 shortened
Tailstock sleeve travel [mm] 30
Longitudinal feed [mm/revolution] 0.05 - 0.1
Pitch - Metric 0.5 - 1.5
Quadruple tool holder seat height [mm] 12
Level difference between bearing surface quadruple seat
and turning centre [mm] 7.85 + 0 / - 0.3
Dimensions
Height / Length / Width [mm] 290 / 560 / 320
Total weight [kg] 22
Operating material
Slideways, lubrication nipples e.g. machines oil (Mobil Oil, Fina, ...)
We recommend the use of weapon oil, weapon oil is acid-
, stain- and resin-free.
Environmental conditions
Temperature 5 - 35 °C

Version 1.0.3 dated 2014-05-14 Page 17Original operating instructions
TU1503V GB
2.1 Emissions
The generation of noise emitted by the lathe is less than 70 dB(A).
If the lathe is installed in an area where various machines are in operation, the noise exposure
(immission) on the operator of the at the working place may exceed 80dB(A).
INFORMATION
This numerical value was measured on a new machine under proper operating conditions.
Depending on the age respectively on the wear of the machine it is possible that the noise
behaviour of the machine changes.
Furthermore, the factor of the noise emission is also depending on manufacturing influencing
factors, e.g. speed, material and clamping conditions.
INFORMATION
The mentioned numerical value is the emission level and not necessarily a safe working level.
Though there is a dependency between the degree of the noise emission and the degree of the
noise disturbance it is not possible to use it reliably to determine if further precaution measures
are required or not.
The following factors influence the actual degree of the noise exposure of the operator:
Characteristics of the working area, e.g. size or damping behaviour,
Other noise sources, e.g. the number of machines,
Other processes taking place in the proximity and the period of time during which the oper-
ator is exposed to the noise.
Furthermore, it is possible that the admissible exposure level might be different from country to
country due to national regulations.
This information about the noise emission shall allow the operator of the machine to more eas-
ily evaluate the endangering and risks.
CAUTION!
Depending on the overall noise exposure and the basic limit values the machine
operators must wear an appropriate hearing protection.
We generally recommend to use a noise protection and a hearing protection.
Humidity 25 - 80 %
Environmental conditions

Version 1.0.3 dated 2014-05-14Page 18 Original operating instructions
TU1503VGB
2.2 Dimensions, installation plan
Img.2-1: Dimensions, installation plan

Version 1.0.3 dated 2014-05-14 Page 19Original operating instructions
TU1503V GB
3 Unpacking and connecting
INFORMATION
The lathe is delivered pre-assembled. When the lathe is delivered, check immediately before
and after unpacking hat the lathe has not been damaged during shipping and that all compo-
nents are included. Also check that no fastening screws have come loose.
3.1 Scope of delivery
Compare the scope of delivery with the packing list.
3.2 Storage
ATTENTION!
In case of wrong and improper storage electrical and mechanical machine components
might get damaged and destroyed.
Store packed and unpacked parts only under the intended environmental conditions.
Follow the instructions and information on the transport case.
Consult company if the machine and accessories are stored for more than three months or
are stored under different environmental conditions than those given here .  "Information“ on
page 6
Fragile goods
(Goods require careful handling)
Protect against moisture and humid environment
 "Environmental conditions“ on page 16
Prescribed position of the packing case
(Marking of the top surface - arrows pointing to the
top)
Maximum stacking height
Example:not stackable - do not stack a second pack-
ing case on top of the first packaging case

Version 1.0.3 dated 2014-05-14Page 20 Original operating instructions
TU1503VGB
3.3 Installation and assembly
3.3.1 Requirements regarding the installation site
INFORMATION
In order to attain good functionality and a high processing accuracy as well as a long durability
of the machine the installation site should fulfil certain criteria.
Please observe the following points:
The device must only be installed and operated in a dry and well-ventilated place.
Avoid places nearby machines generating chips or dust.
The installation site must be free from vibrations also at a distance of presses, planing
machines, etc.
The substructure must be suitable for turning. Also make sure that the floor has sufficient
load bearing capacity and is level.
The substructure must be prepared in a way that possibly used coolant cannot penetrate
into the floor.
Any parts sticking out such as stops, handles, etc. have to be secured by measures taken
by the customer if necessary in order to avoid endangerment of persons.
Provide sufficient space for the staff preparing and operating the machine and transporting
the material.
Also consider that the machine is accessible for setting and maintenance works.
The mains plug and the main switch of the lathe has to be freely accessible.
Provide for sufficient illumination (Minimum value: 300 lux).
In case of little intensity of illumination provide for additional illumination i.e. by a separate
workplace illumination.
INFORMATION
The mains plug of the lathe must be freely accessible.
3.3.2 Assembling
ATTENTION!
The lathe can slip slowly during operation on the ground. Attach the machine to the
ground.
Attach the lathe to the provided through holes (2 pieces) along with the chip pan and the
intended base.
 "Dimensions, installation plan“ on page 18
ATTENTION!
Tighten the setscrews on the lathe only until it is firmly secured and can neither move
during operation nor be turned over. If the fixing screws are too tight in particular in
connection with an uneven substructure it may result in a broken stand of the machine
bed.
3.4 First commissioning
ATTENTION!
Before commissioning the machine check all screws, fixtures resp. safety devices and
tighten up the screws if necessary!
WARNING!
Risk by using improper tool holders or by operating them at inadmissible speeds.
