Palmgren TU 2506 User manual

US
Item No. 9684509
Operating manual
Version 2.2.2
Lathe

Page 2
TU2506 ǀTU2807VUS
Table of contents
1 Safety
1.1 Type plates...............................................................................................................................................6
1.2 Safety warnings (warning notes) ..............................................................................................................7
1.2.1 Classification of hazards...........................................................................................................................7
1.2.2 Other pictograms......................................................................................................................................8
1.3 Proper use................................................................................................................................................8
1.4 Possible dangers caused by the machine................................................................................................9
1.5 Qualification of personnel.........................................................................................................................9
1.5.1 Target group.............................................................................................................................................9
1.5.2 Authorized personnel..............................................................................................................................10
1.5.3 Obligations of the operator .....................................................................................................................10
1.5.4 Obligations of the user............................................................................................................................10
1.5.5 Additional qualification requirements......................................................................................................10
1.6 User positions.........................................................................................................................................10
1.7 Safety measures during operation..........................................................................................................10
1.8 Safety devices ........................................................................................................................................11
1.9 EMERGENCY-STOP..............................................................................................................................11
1.9.1 Lockable main switch..............................................................................................................................12
1.9.2 Protective cover with safety switch.........................................................................................................12
1.9.3 Lathe chuck guard..................................................................................................................................12
1.9.4 Lathe chuck key......................................................................................................................................13
1.10 Safety check...........................................................................................................................................13
1.11 Individual protection gear........................................................................................................................14
1.12 Safety during operation...........................................................................................................................14
1.13 Disconnecting the lathe and making it safe............................................................................................15
1.14 Using lifting equipment ...........................................................................................................................15
1.15 Mechanical maintenance work ...............................................................................................................15
2 Technical data
2.1 Power connection...................................................................................................................................16
2.2 Machine specifications............................................................................................................................16
2.6 Emissions ...............................................................................................................................................17
2.3 Work area...............................................................................................................................................17
2.4 Environmental conditions........................................................................................................................17
2.5 Operating material..................................................................................................................................17
2.7 Dimensions, installation plan TU2506 ....................................................................................................19
2.8 Dimensions, installation plan TU2807V..................................................................................................20
2.9 Distance between centres, height of centres TU2506............................................................................21
2.10 Distance between centres, height of centres TU2807V..........................................................................22
3 Assembly
3.1 Extent of supply......................................................................................................................................23
3.2 Transport ................................................................................................................................................23
3.3 Storage...................................................................................................................................................24
3.4 Installation and assembly .......................................................................................................................24
3.4.1 Requirements of the installation site.......................................................................................................24
3.4.2 Load suspension point............................................................................................................................25
3.4.3 Installation...............................................................................................................................................25
3.5 First use..................................................................................................................................................25
3.5.1 Cleaning and greasing............................................................................................................................26
3.5.2 Visual inspection.....................................................................................................................................26
3.5.3 Run test ..................................................................................................................................................26
3.5.4 Power supply..........................................................................................................................................26
3.5.5 Functional test ........................................................................................................................................26

Page 3
TU2506 ǀTU2807V US
3.6 Optional machine accessories ...............................................................................................................27
3.7 Mounting instructions .............................................................................................................................27
3.7.1 Mounting instruction chuck flange..........................................................................................................27
3.7.2 Chuck flange TU2506 / TU2807V ..........................................................................................................28
3.7.3 Mounting instruction of collet chuck holder ............................................................................................29
3.7.4 Mounting of movable rest - TU2506.......................................................................................................30
3.7.5 Mounting of movable rest - TU2807V.....................................................................................................30
3.7.6 Mounting of steady rest - TU2506..........................................................................................................31
3.7.7 Mounting of steady rest - TU2807V........................................................................................................31
4Operation
4.1 Safety.....................................................................................................................................................32
4.2 General working advice - coolant...........................................................................................................32
4.3 Operation TU2506..................................................................................................................................33
4.3.1 Control and indicating elements.............................................................................................................33
4.3.2 Switching elements ................................................................................................................................34
4.3.3 Turning ON the machine ........................................................................................................................34
4.3.4 Turning OFF the machine ......................................................................................................................34
4.4 Operation TU2807V ...............................................................................................................................35
4.4.1 Control and indicating elements.............................................................................................................35
4.4.2 Switching elements ................................................................................................................................36
4.4.3 Turning ON the machine ........................................................................................................................36
4.4.4 Turning OFF the machine ......................................................................................................................36
4.5 Operating elements for infeed................................................................................................................37
4.6 Toolholder ..............................................................................................................................................37
4.7 Lathe chuck............................................................................................................................................37
4.8 Adjusting the speed................................................................................................................................38
4.8.1 Changing the speed range.....................................................................................................................39
4.8.2 Speed table TU2506 ..............................................................................................................................39
4.8.3 Speed table TU2807V............................................................................................................................39
4.9 Adjusting the feed...................................................................................................................................40
4.9.1 Selector switches ...................................................................................................................................40
4.9.2 Changing the change gears ...................................................................................................................40
4.10 Assembly of the change gears...............................................................................................................41
4.10.1 Gear threading tables.............................................................................................................................43
4.10.2 Example - assembly of gear wheels for thread 14 TPI, 28 TPI and 56 TPI on TU2506.........................44
4.11 Engaging lever .......................................................................................................................................44
4.12 Immobilising the lathe saddle.................................................................................................................45
4.12.1 Turning tapers with the top slide ............................................................................................................45
4.12.2 Cross-adjustment of the tailstock...........................................................................................................45
4.13 Tailstock sleeve......................................................................................................................................46
4.14 Clamping a workpiece into the lathe chuck............................................................................................46
4.15 Replacing the clamping jaws on the lathe chuck....................................................................................47
4.16 Turning Speeds & Feeds........................................................................................................................48
4.17 Recommended Cutting Speeds in Feet per Minute for Turning Ferrous and Nonferrous Metals*.........48
4.18 Calculating RPM.....................................................................................................................................50
4.18.1 Selecting Feed per Revolution ..............................................................................................................51
4.18.2 Recommended Feed Rate Selection in Inches Per Revolution for Turning...........................................52
5 Maintenance
5.1 Safety.....................................................................................................................................................54
5.1.1 Preparation.............................................................................................................................................54
5.1.2 Restarting...............................................................................................................................................54
5.2 Inspection and maintenance ..................................................................................................................54
5.3 Repair.....................................................................................................................................................56

Page 4
TU2506 ǀTU2807VUS
6 Spare parts - TU2506
6.1 Top slide.................................................................................................................................................57
6.2 Cross slide..............................................................................................................................................58
6.3 Bed slide.................................................................................................................................................59
6.4 Tailstock..................................................................................................................................................60
6.5 Machine bed...........................................................................................................................................61
6.6 Feed gear 1 of 2 .....................................................................................................................................62
6.7 Feed gear 2 of 2 .....................................................................................................................................63
6.8 Headstock 1 of 2.....................................................................................................................................64
6.9 Headstock 2 of 2.....................................................................................................................................65
6.10 Change gear...........................................................................................................................................66
6.11 Operating panel......................................................................................................................................67
6.12 Spare parts list TU2506..........................................................................................................................68
7 Spare parts - TU2807V
7.1 Top slide.................................................................................................................................................75
7.2 Cross slide..............................................................................................................................................76
7.3 Bed slide.................................................................................................................................................77
7.4 Tailstock..................................................................................................................................................78
7.5 Machine bed...........................................................................................................................................79
7.6 Feed gear 1 of 2 .....................................................................................................................................80
7.7 Feed gear 2 of 2 .....................................................................................................................................81
7.8 Headstock 1 of 2.....................................................................................................................................82
7.9 Headstock 2 of 2.....................................................................................................................................83
7.10 Change gear...........................................................................................................................................84
7.11 Spare parts list TU2807V........................................................................................................................85
8 Wiring diagrams
8.1 TU2506...................................................................................................................................................92
8.2 TU2807V (230V).....................................................................................................................................93
9 Troubleshooting
9.1 Troubleshooting in the lathe ...................................................................................................................94
10 Appendix
10.1 Copyright ................................................................................................................................................95
10.2 Terminology/glossary..............................................................................................................................95
10.3 LIMITED WARRANTY ...........................................................................................................................96
10.4 EC - declaration of conformity ................................................................................................................97
10.5 EC - declaration of conformity ................................................................................................................98

Page 5
TU2506 ǀTU2807V US
Preface
Dear customer,
Thank you very much for purchasing a product made by company.
Company metal working machines offer a maximum of quality, technically company solutions and convince
by an outstanding price performance ratio. Continuous enhancements and product innovations guarantee
state-of-the-art products and safety at any time.
Before commissioning the machine please thoroughly read these operating instructions and get familiar with
the machine. Please also make sure that all persons operating the machine have read and understood the
operating instructions beforehand.
Keep these operating instructions in a safe place nearby the machine.
Information
The operating instructions include indications for safety-relevant and proper installation, operation and main-
tenance of the machine. The continuous observance of all notes included in this manual guarantee the safety
of persons and of the machine.
The manual determines the intended use of the machine and includes all necessary information for its eco-
nomic operation as well as its long service life.
In the paragraph "Maintenance" all maintenance works and functional tests are described which the operator
must perform in regular intervals.
The illustration and information included in the present manual can possibly deviate from the current state of
construction ofyour machine. Being the manufacturer we are continuously seeking for improvements and
renewal of the products. Therefore, changes might be performed without prior notice. The illustrations of the
machine may be different from the illustrations in these instructions with regard to a fewdetails. However,
this does not have any influence on the operability of the machine.
Therefore, no claims may be derived from the indications and descriptions. Changes and errors are reserved!
Your suggestion with regard to these operating instructions are an important contribution to optimising our
work which we offer to our customers. For any questions or suggestions for improvement, please do not hesi-
tate to contact us.
If you have any further questions after reading these operating instructions and you are not able to
solve your problem with a help of these operating instructions, please contact your specialised
dealer or
C.H.HANSON
2000 North Aurora Rd.
Naperville,IL 60563
Call 800-827-3398

Page 6
TU2506 ǀTU2807VUS
1 Safety
Glossary of symbols
This part of the operating manual
explains the meaning and use of the warning references contained in the operating manual,
explains how to use the lathe properly,
highlights the dangers that might arise for you or others if these instructions are not obeyed,
tells you how to avoid dangers.
In addition to this operating manual please observe
applicable laws and regulations,
legal regulations for accident prevention,
the prohibition, warning and mandatory signs as well as the warning notes on the lathe.
Consult OSHA, state and local regulations in order to determine compliance, danger and risks
to the operator.
Always keep this documentation close to the lathe.
If you would like to order another operating manual for your machine, please indicate the serial
number of your machine. Please find the serial number on the type plate.
1.1 Type plates
INFORMATION
If you are unable to solve a problem using this manual, please contact us for advice:
Exclusive USA Agent
C.H.HANSON
2000 North Aurora Rd.
Naperville,IL 60563
Call 800-827-3398
gives additional indications
calls on you to act
Enumerations

Page 7
TU2506 ǀTU2807V US
1.2 Safety warnings (warning notes)
1.2.1 Classification of hazards
We classify the safety warnings into various levels. The table below gives an overview of the
classification of symbols (pictograms) and warnings for the specific danger and its possible con-
sequences.
Pictogram Alarm
expression Definition/Consequences
DANGER! Imminent danger that will cause serious injury or death to personnel.
WARNING! Risk: A danger that might cause serious injury or death to personnel.
CAUTION! Danger or unsafe procedure that might cause injury to personnel or dam-
age to property.
ATTENTION!
Situation that could cause damage to the machine and product and other
types of damage.
No risk of injury to personnel.
INFORMATION
Application tips and other important or useful information and notes.
No dangerous or harmful consequences for personnel or objects.
In the case of specific dangers, we replace the pictogram
or
General danger with a warning of injuries to hands, hazardous
electrical voltage,rotating parts.

Page 8
TU2506 ǀTU2807VUS
1.2.2 Other pictograms
1.3 Proper use
WARNING!
Improper use of the lathe
will endanger personnel,
will endanger the machine and other material property of the operator,
may affect proper operation of the machine.
The machine is designed and manufactured to be used in environments where there is no
potential danger of explosion.
The lathe is designed and manufactured for straight turning and facing round or regularly
formed three-, six- or twelve-square workpieces in cold metal, castings and plastics or similar
materials that do not constitute a health hazard or do not create dust, such as wood, Teflon®,
etc. The lathe must only be installed and operated in a dry and well-ventilated place. The work-
pieces may only be clamped in the lathe chuck using self ejecting chuck-key provided.
If the lathe is used in any way other than described above, or modified without authorization,
then the lathe- is being used improperly.
We do not take liability for damage caused by improper use.
We would like to stress that any modifications to the construction, or technical or technological
modifications that have not been authorized will also render the warranty null and void.
It is also part of proper use that
the maximum values for the lathe are complied with,
the operating manual is observed,
inspection and maintenance instructions are observed.
 "Technical data“ on page 16
In order to achieve company cutting performance, it is essential to choose the right turning tool,
feed, tool pressure, cutting speed and coolant.
WARNING!
Very serious injury due to improper use.
It is forbidden to make any modifications or alterations to the operating values of the
machine. These could endanger personnel and cause damage to the machine.
Be aware of
slipping! Activation forbidden! Pull the mains plug! Use protective gog- gles! Use ear protection!
Use protective
gloves! Use protective boots! Wear a safety suit! Protect the environ- ment! Contact address

Page 9
TU2506 ǀTU2807V US
1.4 Possible dangers caused by the machine
The lathe has undergone a safety inspection (analysis of danger with assessment of risks). It
has been designed and built on the basis of this analysis using the latest technological
advances.
Nonetheless, there remains a residual risk, since the machine operates with
high revolutions,
rotating parts,
electrical voltage and currents.
We have used construction resources and safety techniques to minimise the health risk to per-
sonnel resulting from these hazards.
If the lathe is used and maintained by personnel who are not duly qualified, there may be a risk
resulting from incorrect operation or unsuitable maintenance.
INFORMATION
All personnel involved in assembly, commissioning, operation and maintenance must
be duly qualified,
follow this operating manual.
Disconnect the machine from main power source whenever cleaning or maintenance work is
being carried out.
WARNING!
The lathe may only be used with the safety devices activated.
Disconnect the lathe from main power source whenever you detect a failure in the safety
devices or when they are not fitted!
All additional installations carried out by the operator must incorporate the prescribed
safety devices.
As the machine operator, this will be your responsibility!
 "Safety devices“ on page 11
1.5 Qualification of personnel
1.5.1 Target group
This manual is addressed to
operators,
users,
maintenance stuff.
The warning notes therefore refer to both operation and maintenance of the machine.
Always disconnect the machine plug from the from main power source. This will prevent it being
used by unauthorized personnel.
INFORMATION
All personnel involved in assembly, commissioning, operation and maintenance must
be duly qualified,
follow this operating manual.
In the event of improper use
there may be a risk to personnel,
there may be a risk to the machine and other material property,
correct functioning of the lathe may be affected.

Page 10
TU2506 ǀTU2807VUS
1.5.2 Authorized personnel
WARNING!
Incorrect use and maintenance of the machine constitutes a danger for personnel,
objects and the environment.
Only authorized personnel may operate the machine!
The only personnel authorized to use this machine and perform maintenance on it are trained
and instructed technical staff working for the operator and manufacturer.
1.5.3 Obligations of the operator
The operator must instruct staff at least once a year on
all safety standards that apply to the machine,
operation,
accredited technical guidelines.
The operator must also
check staff's understanding,
document training/instruction,
require staff to confirm participation in training/instruction by means of a signature,
check whether the staff are aware of safety and of dangers in the workplace and whether
they observe the operating manual.
1.5.4 Obligations of the user
The user must
have read and understood the operating manual,
be familiar with all safety devices and regulations,
be able to manipulate the machine.
1.5.5 Additional qualification requirements
For work on electrical components or equipment there are additional requirements:
This work must only be carried out by a qualified electrician or person working under the
instructions and supervision of a qualified electrician.
Before carrying out work on electric components or operating units the following measures
must be taken, in the order given.
Disconnect all main electrical power.
Ensure that the machine cannot be turned on again.
Check that there is no voltage.
1.6 User positions
The user must stand in front of the machine.
1.7 Safety measures during operation
CAUTION!
Risk due to inhaling health hazardous dusts and mist.
Depending on the material being processed and any additional dusts and mist in the
work area, conditions might impair your health.
Make sure that the generated health hazardous dusts and mist are safely removed at the
point of origin and are collected and/or filtered from the working area. Use an
appropriate dust collection/filter unit.

Safety
Version 2.2.2 dated 2015-04-02
CAUTION!
Risk of fire and explosion by using flammable materials or cooling lubricants.
Take additional preventive measures in order to safely avoid health hazards before
processing flammable materials (e.g. aluminum, magnesium) or before using flammable
additives (e.g. alcohol).
CAUTION!
Risk of winding-up or cutting damages when using hand tools.
The machine is not designed for the use of hand tools (e.g. emery cloth or files). It is
forbidden to use any hand tools on this machine.
1.8 Safety devices
Use the lathe only with properly functioning safety devices.
Stop the lathe immediately if there is a failure in the safety device or if it is not functioning for
any reason.
It is your responsibility!
If a safety device has been activated or has failed, the lathe must only be used when
the cause of the failure has been removed,
it has been verified that there is no resulting danger for personnel or objects.
WARNING!
If you bypass, remove or override a safety device in any other way, you are endangering
yourself and other personnel working with the machine. The possible consequences are
damage as a result of components or parts of components flying off at high speed,
contact with rotating parts,
fatal electrocution.
WARNING!
The separating protective equipment which is made available and delivered together
with the machine is designed to reduce the risk of injury from workpieces or fractions of
them which being expelled, but not to remove the risk completely.
The lathe includes the following safety devices:
self-latching, lockable EMERGENCY STOP button,
a protective cover on the headstock with interlock switch,
a self-ejecting key for the lathe chuck,
a lathe chuck guard with position switch.
1.9 EMERGENCY-STOP
The EMERGENCY-STOP turns the lathe
off.
Pushing the emergency stop device trig-
gers an emergency stop.
After actuating the switch, turn it to the
right, in order to reset it.
Fig.1-1: EMERGENCY-STOP
EMERGENCY-
STOP

Page 12
TU2506 ǀTU2807VUS
1.9.1 Lockable main switch
It is possible to secure the lockable main
switch with a padlock at the position "0"
against switching on by mistake or unau-
thorized switching on.
When the main switch is switched off, the
power supply to the machine is com-
pletely interrupted.
Fig.1-2: Lockable main switch
1.9.2 Protective cover with safety switch
The spindle head of the lathe is equipped
with a fixed, separating protective cover.
The locked position is monitored by
means of an interlock switch.
INFORMATION
It is not possible to start the machine until
the protective cover is completely closed.
Fig.1-3: Protective cover of spindle head
1.9.3 Lathe chuck guard
The lathe is provided with chuck guard.
The lathe can only be turned on when the
chuck guard is closed.
Fig.1-4: Integrated position switch
lockable
main switch
Protective cover
Interlock switch
Lathe chuck
guard closed
Lathe chuck
guard opened
Integrated
position switch

Page 13
TU2506 ǀTU2807V US
1.9.4 Lathe chuck key
The lathe is equipped with self-ejecting
key for chucks. Once the chuck key has
been released, it will be ejected from the
lathe chuck by its spring.
CAUTION!
Exclusively use the supplied chuck key to
adjust the lathe chuck.
Fig.1-5: Lathe chuck key
1.10 Safety check
Check the lathe at least once per shift. Inform the person responsible immediately of any dam-
age, defect or change in operating function.
Check all safety devices
at the beginning of each shift (with the machine stopped)
once a week (with the machine in operation)
after every maintenance and repair operation
Lathe chuck key
General check
Equipment Check OK
Lathe chuck guard Fitted, firmly bolted and not damaged
Labels, markings Installed and legible
Date: Checked by (signature):
Run test
Equipment Check OK
EMERGENCY-STOP
switch When the EMERGENCY-STOP switch is activated, the lathe should switch off automatically.
Lathe chuck key After releasing the lathe chuck key it has to eject out of the lathe chuck by
itself.
Lathe chuck guard/ Protec-
tive cover headstock You may only switch on with the button "ON" after closing the lathe chuck guard/ Protective cover headstock
Date: Checked by (signature):

Page 14
TU2506 ǀTU2807VUS
1.11 Individual protection gear
For certain work individual protection gear is required.
Protect your face and eyes: During all work, and specifically work during which your face and
eyes are exposed to hazards, a safety helmet with a face guard should be worn.
Use protective gloves when lifting or handling pieces with sharp edges.
Wear safety shoes when fitting, dismantling or transporting heavy components.
Use ear protection if the noise level (immission) in the workplace exceeds 80 dB(A).
Before starting work, make sure that the prescribed individual protection gear is available in the
workplace.
CAUTION!
Dirty or contaminated body protection gear can cause disease.
Clean it after every use and once a week.
1.12 Safety during operation
In the description of work with and on the machine we highlight the dangers specific to that
work.
WARNING!
Before activating the lathe, double check that this will not endanger other people and
cause damage to equipment.
Avoid unsafe working practices:
Make sure your work does not endanger anyone.
Clamp the workpiece tightly before activating the lathe.
For clamping workpieces, only use the self-ejecting chuck key supplied.
Observe the maximum chuck opening.
Use protective goggles.
Do not remove turning chips by hand. To remove turning chips, use a chip hook and/or
handbrush.
Clamp the turning tool at the correct height and with the least possible overhang.
Turn off the lathe before measuring the workpiece.
The instructions in this manual must be observed during assembly, handling, maintenance
and repair.
Do not work on the lathe if your concentration is reduced, for example, because you are
taking medication.
Observe the rules for preventing accidents issued by your association for the prevention of
occupational accidents and safety in the workplace or other inspection authorities.
Inform the inspector of any danger or failure.
Stay by the lathe until all rotating parts have come to a halt.
Use prescribed protection gear. Make sure to wear a well-fitting work suit and, where nec-
essary, a hairnet.

Page 15
TU2506 ǀTU2807V US
1.13 Disconnecting the lathe and making it safe
Disconnect the lathe from power before beginning any maintenance or repair work. All
machine components and hazardous voltages and movements must have been discon-
nected.
Secure the machine using a padlock on the lockable main switch.
Place a warning sign on the machine.
1.14 Using lifting equipment
WARNING!
Use of unstable lifting and suspension gear that might break under load can cause very
serious injuries or even death.
Check that the lifting and load suspension gear is of sufficient load capacity and in
perfect condition.
Observe the rules for preventing accidents issued by your association for the prevention
of occupational accidents and safety in the workplace or other inspection authorities.
Hold the loads properly.
Never walk under suspended loads!
1.15 Mechanical maintenance work
Remove protection and safety devices as required before beginning maintenance work and re-
install them once the work has been completed. These include:
Covers
Safety indications and warning signs
Earth (ground) connection
If you remove protection or safety devices, refit them immediately after completing the work.
Check that they are working properly!

Page 16
TU2506 ǀTU2807VUS
2 Technical data
The following information gives the dimensions and weight and is the manufacturer's authorized
machine data.
2.1 Power connection
connection TU2506 TU2807V
Motor 115V,~ 60Hz, 1Ph, 0.75 kW
(1Hp) 230V,~ 60Hz, 1Ph, 1.5 kW (2Hp)
2.2 Machine specifications TU2506 TU2807V
Diameter three-jaw chuck 125mm (4.92")
Distance between centers 550mm (21.63") 700mm (27.6")
Swing over machine bed 250mm (9.84") 266mm (10.47")
Bed width 135mm (5.31") 180mm (7.08")
Spindle speed [rpm] 150 - 2400 40 - 4000 30 - 4000
Number of speeds 6 3 steps VARIO 4 steps VARIO
Spindle taper MT 4
Spindle thru hole 26mm (1.02")
Longitudinal feed 0.003" 0.004" 0.006" 0.008"
0.012" 0.016" 0.002" 0.003" 0.004" 0.006" 0.008" 0.012"
Longitudinal Lead Screw size 3/4" Dia - 10 TPI
Longitudinal Feed Dial graduation 0.01" (1rev = 0.780") 0.02" (1rev = 1.180")
Thread Cutting Pitches - Inches [tpi] 8 9 9 10 11 12 12.5 14 16 18 20 22 24 25 28 32
36 40 44 48 50 56
Thread Cutting Pitches - Metric [mm] 0.2 0.3 0.4 0.5 0.6 0.625 0.75 0.8 0.875 1.0 1.2 1.25
1.5 1.75 2.0 2.5 3.0 3.5 4.0
Operating travel cross slide 110mm (4,33") 160mm (6.30")
Cross feed Lead Screw size 9/16" Dia - 10 TPI
Cross feed Dial graduation 0.002" (1rev = 0.2") indirect
Operating travel top slide 70mm (2.75") 60mm (2.36")
Adjustment range of the top slide + - 90°
Top slide feed Lead Screw size 5/16" Dia - 20 TPI
Top slide feed Dial graduation 0.001" (1rev = 0.050")
Distance from Turning Center to Quadruple Tool
Holder Surface 13.5mm (0.531") 13mm (0.512")
Distance from Turning Center to Top slide‘s Sur-
face 25.5mm (1.004") 25mm (0.984")
Distance from Turning Center to Cross slide‘s
Surface 75mm (2.95") 87mm (3.43")
Taper bore of tailstock sleeve MT 2

Page 17
TU2506 ǀTU2807V US
2.6 Emissions
The level of noise emitted by the lathe is less than 78 dB(A).
INFORMATION
This numeric value had been measured on a new machine under conventional operating condi-
tions. Depending on the age or wear of the machine, the noise behavior of the machine might
change.
Furthermore, the extent of the noise emission is also depending on manufacturing
influence factors, such as speed, material and clamping conditions.
INFORMATION
The mentioned numerical value is an emission level and not necessarily a safe
working level.
Unless the degree of noise emission and the degree of noise disturbance are depending on
one another it is not possible to use it in order to reliably determine if it is necessary to take fur-
ther preventive measures or not.
Tailstock - sleeve diameter 30mm (1.181")
Tailstock sleeve travel 65mm (2.56") 85mm (3.35")
Tailstock cross adjustment + - 10 mm (0.39")
Tailstock feed Lead Screw size 9/16" Dia - 10 TPI
Tailstock feed Dial graduation 0.001" (1rev = 0.1")
2.3 Work area
TU2506 TU2807V
Height 2000mm (78.7") 2000mm (78.74")
Length 2200mm (86.6") 2200mm (86.61")
Depth 1900mm (74.8") 1900mm (74.8")
2.4 Environmental conditions
TU2506 TU2807V
Temperature 40 - 95 °F
Humidity 25 - 80 %
2.5 Operating material
TU2506 TU2807V
Feed gear Mobilgear 627 or equivalent oil
see also  "Lubricant“ on page 91
Bright steel parts and lubricating nipples Non-corrosive lubricating oil
Change gears Chain oil (spray)
2.2 Machine specifications TU2506 TU2807V

Page 18
TU2506 ǀTU2807VUS
The following factors influence the actual degree of the noise disturbance of the
operator:
Characteristics of the working chamber, e.g. size or damping behavior,
Other noise sources, e.g. the number of machines,
Other processes proceeding nearby and the period during which the operator is exposed to
the noise.
Furthermore, the admissible pollution level may be different from one country to another due to
the national regulations.
This information regarding the noise emission should allow the operator of the machine to per-
form a better evaluation of the endangerments and risks.
CAUTION!
The machine operator has to wear an appropriate ear protection depending on the
overall stress caused by noise and on the basic limit values.
We generally recommend using a sound and ear protection.

Page 19
TU2506 ǀTU2807V US
2.7 Dimensions, installation plan TU2506
Fig.2-1: Dimensions, installation plan TU2506
A-A
AA
1115 ( 43.9" )
1250 ( 49.2" )
475(18.7")
100 ( 4" )
520 ( 20.5" )
585 ( 23" )
520( 20.5")
117 ( 4.6" )
120 ( 4.7" )
210( 8.3")
140 ( 5.5" )
160 ( 6.3" )
660 ( 26" )
114 ( 4.5" )
764 ( 30" )
200(7.9")
300 ( 11.8" )
350 ( 13.8" )
Schwerpunkt/ Centre of gravity
15 ( 0.6" )
305( 12")
1100 ( 43.7" )

Page 20
TU2506 ǀTU2807VUS
2.8 Dimensions, installation plan TU2807V
Fig.2-2: Dimension, installation plan TU2807V
A-A
AA
1290 ( 50.8" )
1370 ( 54" )
240 ( 9.5" )
722 ( 28.4" )
180 ( 7" )
160(6.3")
425( 16.7")
160( 6.3")
130(5.1")
210 ( 8.3" ) 838 ( 33" )
1275 ( 50.2" )
440( 17.3")
120 ( 4.7" )
540 ( 21.5" )
660 ( 26" )
200(7.9")
320 ( 12.6" )
430 ( 17" )
Centre of gravity
P
12,5(0.5" )
15 ( 0.6" )
330( 13")
