PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
PA168V MGCP FXS Gateway
Telnet Setup Guide
¾ Telnet Configuration ........................................................................................................ 2
¾ PA168V Telnet Commands Explanation ...................................................................... 2
¾ Command ? ................................................................................................................... 3
¾ Command get .................................................................................................................. 4
¾ Command set................................................................................................................... 5
¾ Command store ............................................................................................................. 14
¾ Command load .............................................................................................................. 14
¾ Command default .......................................................................................................... 14
¾ Command exit................................................................................................................ 15
¾ Command write.............................................................................................................. 15

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
2
When PA168V MGCP FXS gateway is properly installed, you can set each
parameter through PC and Telnet commands.
Details please refer to《PA168V MGCP FXS gateway Spec and Install》
¾Telnet Configuration
●On the PC choose Start>Run, type telnet 192.168.1.100 into Run field
in popuping Run dialog. Or input telnet 192.168.1.100 in the DOS
window. Then the following information will be displayed.
PA168X V1.49 settings
Password :
Then please type password. With debug set as 0[disable], if you type ordinary
password (default one is 1234), after Retun, you will see：
Password : ****
P:\>
If you type super password, then you will see:
Password : ********
P:\>
The above information indicates that PA168V FXS gateway is under setting
mode, and then you can set the PA168V FXS gateway by using the telnet
commands.
¾PA168V Telnet Commands Explanation
Command Function

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
3
? Supply command name and parameters
get Display basic parameters of the PA168V FXS gateway
set Set parameters of the PA168V FXS gateway
store Save current settings to designated position
load Load designated settings to current position
default Restore to manufactory defaults parameters
exit Exit from the setting mode without saving the configuration
write Exit with saving all configurations and restart PA168V
¾Command ?
Syntax description: No optional parameter
Usage: Type command name and parameters by following P:\> . Be
used as the keyword to supply keyword and parameters of the relevant
commands.
Relevant usage: None
Detailed description:
？List help of all commands
For example:
P:\>?
set
get listsettings
store x store current to xth settings
load x load xth settings to current
default
exit
write save settings

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
4
¾Command get
Syntax description: No optional parameter of keywords
Usage: Display basic parameters of the PA168V FXS gateway
Relevant usage: None
Detailed description:
get Display basic running parameters of the PA168V FXS
gateway. Input ordinary password without debug being set as 0[disable],
or input super password with debug set as 0[disable], then following
parameters of PA168V FXS gateway will be displayed:
PA168X V1.49 settings
Password: ********
P:\>get
***************Network Settings***************
iptype 0[static]
ip 192.168.1.100 subnetmask 255.255.255.0 router 192.168.1.254
dns 202.106.46.151 dns2 202.96.128.68 mac 00-0d-ea-00-00-03
***************Audio Settings***************
codec1 0[g729] codec2 3[g711a] codec3 2[g711u]
codec4 4[gsm] codec5 6[null] codec6 6[null]
vad 1[enable] agc 0[disable] aec 1[enable]
audioframes2 6.3k1[enable] ilbcpayload98
jittersize0 handsetin15 handsetout20
dualmode 1[pstn first] dualmodeprefix 30
***************Protocol Settings***************
servicetype 0[`common ]
caaddr 203.93.9.57 registerttl 60
nattraversal 1[enable]
nataddr [empty] natttl 0
phonenumber 82378801 endpointid [empty] domain [empty]
registerport 1732 rtpport 1734 tos 0
dtmfpayload 101 localtype 0[normal] dtmf 0[inband audio]
***************Other Settings***************
superpassword 12345678 debug 1[output ]
password 1234 upgradetype 0[disable]

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
5
upgradeaddr [empty]
sntpip 0.0.0.0 daylight 0[disable]
timezone 55[(GMT+08:00)Beijing,Hong Kong,Urumqi]
Input ordinary password with debug set as 0[disable], and the following
information will be seen:
PA168X V1.49 settings
Password:****
P:\>get
***************Network Settings***************
iptype 0[static]
ip 192.168.1.100 subnetmask 255.255.255.0 router 192.168.1.254
dns 202.106.46.151 dns2 202.96.128.68 mac 00-0d-ea-00-00-03
***************Audio Settings***************
codec1 0[g729] codec2 3[g711a] codec3 2[g711u]
codec4 4[gsm] codec5 6[null] codec6 6[null]
vad 1[enable] agc 0[disable] aec 1[enable]
audioframes2 6.3k1[enable] ilbcpayload98
jittersize0 handsetin15 handsetout20
dualmode 1[pstn first] dualmodeprefix 30
***************Other Settings***************
password 1234 upgradetype 0[disable]
upgradeaddr [empty]
sntpip 0.0.0.0 daylight 0[disable]
timezone 55[(GMT+08:00)Beijing,Hong Kong,Urumqi]
¾Command set
Syntax description: set keywords value
Usage: It is to configure password and other running parameters of
PA168V FXS gateway.
Detailed description:

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
6
set iptype X
Set how PA168V FXS gateway gets relevant network parameters.
X ranges from 0 through 3. 0: authorize users to set IP address,
subnet mask and router IP address of PA168V manually; 1: use
DHCP mode. With this system, 2: use PPPoE mode. Those ADSL
and Cable Modem users please select this item. 3: use modem
mode. Those who use PA168V with modem please set the value
as 3.
set pppid XXX
With iptype set as 2, use this command to set user name of
PPPoE; with iptype set as 3, use this command to set user name
of dial-up network.
set ppppin XXX
With iptype set as 2, use this command to set user name of
PPPoE; with iptype set as 3, use this command to set user name
of dial-up network.
set ip XXX.XXX.XXX.XXX
With iptype set as 0, use this command to set IP address of
PA168V FXS gateway.
set subnetmask XXX.XXX.XXX.XXX
With iptype set as 0, use this command to set subnet mask of
PA168V FXS gateway.

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
7
set router XXX.XXX.XXX.XXX
With iptype set as 0, use this command to set router IP of
network.
set dns XXX.XXX.XXX.XXX
With iptype set as 0, use this command to set IP address of DNS
server.
set dns2 XXX.XXX.XXX.XXX
With iptype set as 0, use this command to set IP of backup DNS
server.
set mac XX-XX-XX-XX-XX-XX
Set MAC address of the PA168V FXS gateway. Parameter
xx-xx-xx-xx-xx-xx must be an HEX number.
set codec1 X
Set the priority 1of the audio compression algorithm. X ranges
from 0 through 6: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm; 5:
ilbc; 6: null.
set codec2 X
Set the priority 2 of the audio compression algorithm. X ranges
from 0 through 6: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm; 5:
ilbc; 6: null.
set codec3 X

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
8
Set the priority 3 of the audio compression algorithm. X ranges
from 0 through 6: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm; 5:
ilbc; 6: null.
set codec4 X
Set the priority 4 of the audio compression algorithm. X ranges
from 0 through 6: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm; 5:
ilbc; 6: null.
set codec5 X
Set the priority 5 of the audio compression algorithm. X ranges
from 0 through 6: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm; 5:
ilbc; 6: null.
set codec6 X
Set the priority 6 of the audio compression algorithm. X ranges
from 0 through 6: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm; 5:
ilbc; 6: null.
set vad X
Enable/disable VAD. X ranges from 0 through 1: 0: disable VAD; 1:
enable VAD.
set agc X
Enable/disable AGC. X ranges from 0 through 1: 0: disable AGC; 1:
enable AGC.
set aec X

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
9
Enable/disable AEC. X ranges from 0 through 1: 0: disable AEC;
1: disable AEC.
set audioframes X
Set audio frames in RTP package. X is Arabic numerals between 0
and 7.
set 6.3k X
With G.7231 codec selected; set PA168V FXS gateway to use
6.3K rate or not. X ranges from 0 through 1: 0: use 6.3K rate; 1:
use 5.3K rate.
set jittersize X
Set buffer size of RTP package. X ranges from 0 to 32.
set ilbcpayload X
Set the payload type of RTP package whne ILBC codec selected
to DTMF delay.X is range from 96-255.
set handsetin X
Set initial volume of handset. X ranges from 0 through 15.
set handsetout X
Set initial volume of handout. X ranges from 0 through 31.
set dualmode X
Set to enable or disable the PSTN line. X ranges from 0 through 2.
0: do not use PSTN line; 1: use PSTN line first. 1: use IP side call
first.

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
10
set dual modes prefix XX
When IP first is set in the dual modes setting, setting switches to
PSTN prefix；XX ranges from 0 through 99.
set service type X
Enable/disable the prepaid and service system .choose the repaid
server provider. Parameter x ranged from 0 through 6:
0: common: disable repaid card;
1: use huawei’s system;
2: use ZTE’s system;
3: use harbour’s system;
4: use utstarcom’s system;
5: use uptech system;
6: use kaiman system;
set caaddr XXXX
Set IP address or domain name of Call Agent.
set registerttl X
Set register TTL. X is range from 10 through 65535 Sec. default
value is 60 Sec.
set nattraversal X
X ranged from 0 through 1: 0: do not use NAT traversal. When

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
11
the log in server and IP phone in the same LAN, or the log in
system supports the IP phone working behind the LAN; 1: Use
NAT traversal. When the login system does not support IP
phone working behind the LAN, With this item selected, please
make port mapping on NAT device
set nataddr XXXXX
When “nattraversal” is set to “1”; set IP address of NAT device
wan port or URI of free assistant service (Such as
www.showmyip.com etc.) in Internet.
NOTE The free service list of Internet：www.ip-calculator.com; www.ipchicken.com;
www.ipchicken.com;www.showmyip.com;www.whatismyip.com;
www.myipaddress.com; www.whatismyipaddress.com; ip.sbbs.net;
www.whatismyipaddress.net;checkip.dyndns.org
set natttl XX
Set NAT TTL XX is an integer between 10 and 65535 sec. default
value is 20 sec.
set phonenumber XXXXXXXX
Set a local ID of PA168X IP phone. Value xxxxx must be an Arabic
numeral and no longer than 16 characters.
set endpointid XXXXXX
Set the endpoint id; Value xxxxxx must be an Arabic numeral and
no longer than 32 characters.

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
12
set domain XXXXXXXXXX
Set the domain name; Value xxxxxx must be an Arabic numeral
and no longer than 32 characters.
set registerport XXXX
Set register port. XXXX is range from 1024 through 65535. default
value is 2427.
set rtpport XXXX
RTP port is the port transferring and receiving voice flow using
UDP protocol. XXXX is range from 1024 through 65535.
set tos X
Set TOS segment of IP head package in RTP digital follow. X is
range from 0 through 224.
set dtmf payload X
When dtmf X select 1(rfc 2833).This parameter can be used
indicating type of RTP payload type. The value can be use integer
96-101.
set localtype X
X is set 0 to 1:0: normal; 1: use CNC special authentication
system.
set dtmf X
Set DTMF relay type. X is ranged form 0 through 1: 0:inband
audio；1:rfc 2833.

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
13
set superpassword XXXX
Set super password of the PA168V FXS gateway. XXX must be
ASCII characters.
set debug X
Set open debugging message output grade for special tool. X
ranges from 0 through 5: 0: close debugging output; 1: output the
operation information to the window; 2: output all the bug
information and data in test window; 3: save the bug information
into SDRAM; 4: disable checking the mark.
set password XXXX
Set password of the PA168V FXS gateway. XXX must be ASCII
characters.
set upgradetype X
Set auto-upgrade matching type，X ranges from 0 through 5，
0------disable；1------all ；2------ mac；3------ppp id; 4------ account;
5------ phone number。
set upgradeaddr HTTP://XXX.XXX.XXX.XXX:PORT
FTP://XXX.XXX.XXX.XXX: PORT
TFTP://XXX.XXX.XXX.XXX: PORT
Set IP address or domain name of upgrade server supplying
upgraded program and configurations of PA168X IP phone.
set sntpip XXX.XXX.XXX.XXX

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
14
Set IP address of time server.
set daylight X
Set to use daylight or not. X ranges from 0 through 1: 0: do not use
daylight; 1: use daylight.
set timezone XX
Set time zone.
¾Command store
Syntax description: no keyword. Parameter ranges from 0 through 4.
Usage: Save the current settings to the designated position.
Relevant Usage: store 1
¾Command load
Syntax description: no keyword. Parameter ranges from 0 through 4.
Usage: Load the designated settings to the current position.
Relevant Usage: load 1
¾Command default
Syntax description: no keyword and parameter
Usage: Restore to manufactory defaults parameters.
Relevant usage: None

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
15
¾Command exit
Syntax description: no keyword and parameter
Usage: Exit from Telnet command window without saving the
configuration.
Relevant usage: None
¾Command write
Syntax description: No keyword and parameter
Usage: Save the configuration and restart the PA168V FXS gateway.
Relevant usage: None
Note All the Telnet commands of PA168V FXS gateway should be written in low case
and the password is case sensitive.

PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
16
Reserves the right to make changes in technical and product specification
without prior notice.
PA168V MGCP FXS Gateway Telnet Setup Guide (V1.49)
Copyright© 2003---2005
All rights reserved
