Panamax M8-HT User manual

M8-HT
LOOKING FOR CRYSTAL CLEAR PICTURE AND SOUND?
M8-HT
www.panamax.com
The M8-HT’s Power Cleaning and Filtration eliminate common
symptoms of contaminated power (including loss of detail, pops,
hisses, hums and visual artifacts) and allows yourA/V equipment to
perform up to its full capability.
1
2Panamax’s patent pendingAVM™ circuitry continuously
monitors the incoming line voltage and disconnects
your equipment in the event of an over voltage or under
voltage (brownout). Power is automatically reconnected
when voltage returns to a safe level, eliminating service
calls or system downtime.
Improves Picture and Sound Quality
Monitors Incoming Line Voltage
•Telephone Line Protection
Protects equipment from electrical surges that
travel over telephone lines.
•AVM (Automatic Voltage Monitoring)
Protects equipment against prolonged over/
under voltages by disconnecting the power
and reconnecting it when safe power returns.
•8 Outlets
8 filtered and surge protected outlets.
•Cable/Sat Protection
Protects equipment from electrical surges that
travel over Cable, Satellite, andAntenna lines.
•Surge Protection
Exclusive Protect or Disconnect™ circuitry.
In the event of a catastophic surge such as
lightning, it completely disconnectsAC power
to connected equipment.
•Hi Def Ready
Hi-Def Designed to work with your High
Definition system.
HOME THEATER POWER MANAGEMENT

M8-HT FEATURES
2. One In Telco Connector
Telco Connector RJ-11 4. Unsafe Voltage LED
(red) Normally OFF; flashes when lit,
indicates that incoming voltages are
unsafe and the surge protector has
disconnected the power to connected
equipment.
1. CATV/Satellite Connectors
3 sets of IN /OUT, universal coaxial
connectors
M8-HT SPECIFICATIONS
UPC’S, QUANTITIES, WEIGHTS & MEASUREMENTS FOR ORDERING & SHIPPING
General________________________________________________________________
Dimensions:................................ 12 in. L x 5 in. W x 1.75 in H (12.5 in. LIncluding brackets)
Weight......................................................................................................................... 3.5 lbs.
AC Power_______________________________________________________________
Protect or Disconnect™ Circuitry:.................................................................................... Yes
Patented Power Management Circuit:...............................................................................Yes
Auto-resetting Over voltage shutoff:...................................................................... 144V ± 8V
Auto-resetting Under voltage shutoff:.......................................................................90V ± 6V
Thermal Fusing:................................................................................................................ Yes
Line Voltage:.............................................................................................. 120VAC, 50/60Hz
Initial Clamping Level:....................................................................... 200V Peak, 141V RMS
UL1449 Suppression Rating:......................................................................................... 330V
Protection Modes:.............................................................................................L-N, L-G, N-G
Maximum Current Rating:..................................................................................15A (1800W)
EMI/RFI Noise Filtration:.................................................................. 50 dB(100 KHz - 1MHz)
Response Time:............................................................................................................. < 1ns
Single Pulse Energy Dissipation:........................................................................ 1650 Joules
Peak Impulse Current:....................................................................................... 52,000Amps
Telco Protection ________________________________________________________
Fuseless/Auto-Resettable:...............................................................................................Yes
Clamping Level:.............................................................................................................260V
Capacitance:....................................................................................................30pf (approx.)
Suppression Modes:......................................................................... Metallic & Longitudinal
Wires Protected:...................................................................................... 2 wire, 1 pair (3,4)
Connectors:................................................................................................................. RJ-11
Universal Cable / Satellite Protection _________________________________________
HD Ready:....................................................................................................................... Yes
Bi-Directional......................................................................................................................Yes
Shielded:...........................................................................................................................Yes
Clamping Level:............................................................................................................... 75V
Frequency Range:........................................................................................ 0MHz - 2.2 GHz
Insertion Loss............................................................................................................< 0.5 dB
Connections......................................................................................Female “F”, Gold Plated
MODEL M8-HT MASTER CARTON
UNIT CARTON
Dimensions Weight Dimensions Weight UPC Qty Dimensions Weight UPC
12” x 5” x 1.75” 3.5 lbs 13.25” x 9.5” x 2.5” 4 Lbs 0 50616 00826 6 6 17.25” x 8.5” x 14” 20 Lbs 5 0050616 00826 1
w/brackets 12.5” x 5” x 1.75”
1690 Corporate Circle, Petaluma, CA. 94954 800-472-5555 or 707-283-5900 Fax [phone] www.panamax.com
© 2007 Panamax, Inc. Panamax, MAX, and the Panamax logo are registered US trademarks of Panamax
Design and specifications subject to change without notice due to product improvement.
L588 REV B 08/07
9. ON/OFF Switch
Power Switch and
Circuit Breaker Combo
8. 8 ft. AC Power Cord
RightAngle with
45 Degree Offset Plug
5. Power ON/Protection OK LED
(green) Normally ON; indicates
that the surge protector is
functioning properly and that all
connected equipment is protected.
6. Ground OK LED
(green) Normally ON; indicates
that the wall outlet is properly
wired and grounded.
10. 8 AC Outlets
8 Outlets with transformer spacing
between outlets.
7. Signal Line Modules
Accepts add-on signal line
modules (sold separately).
3. Two Out Telco Connectors
Telco Connectors RJ-11
