General
Description
5
General
Description
General Description
The PCL Printer Driver is required to send print data from a Windows computer to your machine.
The properties window of the PCL Printer Driver can be used to specify print settings such as the print
orientation and page size. The PCL Printer Driver also provides a range of easy-to-use layout functions that
allow you to setup printing to suit your requirements.
The PCL Printer Driver is the base software required to send print data to your machine as a network printer or
local printer.
The driver can also output data to a remote machine on the Internet using the Internet Printing Protocol (IPP)
(Windows 2000, Windows XP, and Windows Server 2003 only).
NOTE
The DP-C262/C322 supports both the PCL and PostScript (PS) printing. The Printer Contoroller
Module (for Adobe® PostScript® 3™) is required if using as a PostScript printer.

4
General
Description
5
General
Description
Memo

6
System
Requirements
7
System
Requirements
System Requirements
Personal Computer : IBM PC/AT and compatibles (CPU Pentium II or greater is required, Pentium 4 or greater
is recommended)
System Memory : The minimum recommended Memory for each OS is as follows:
Operating System : Windows 98*1, Windows Me*2, Windows NT 4.0*3 (With Service Pack 3 or later is required),
Windows 2000*4, Windows XP*5, Windows Server 2003*6
Windows 98, Windows Me : 128 MB or greater
Interface : 10Base-T/100Base-TX Ethernet Port/USB Port.
Free Disk Space : 40 MB or greater
CD-ROM Drive : Used for installing the software and utilities from the CD-ROM.
Windows 2000, Windows XP,
Windows NT 4.0,
Windows Server 2003 : 256 MB or greater
*1 Microsoft® Windows® 98 operating system (hereafter Windows 98)
*2 Microsoft® Windows® Millennium Edition operating system (hereafter Windows Me)
*3 Microsoft® Windows NT® operating system Version 4.0 (hereafter Windows NT 4.0)
*4 Microsoft® Windows® 2000 operating system (hereafter Windows 2000)
*5 Microsoft® Windows® XP operating system (hereafter Windows XP)
*6 Microsoft® Windows Server ™ 2003 operating system (hereafter Windows Server 2003)

6
System
Requirements
7
System
Requirements
Memo
System
Requirements

8
9
Conguring
the Printer Driver
Settings
Conguring
the Printer Driver
Settings
Opening the Printer Properties Dialog Box
Windows 98/Windows Me
To change the printer settings, open the dialog box for the printer properties by performing the following steps.
Click the Start button, select Settings, and then click Printers.
Right-click on the printer icon in the Printers folder, and then select Properties in the pop-up menu.

8
9
Conguring
the Printer Driver
Settings
Conguring
the Printer Driver
Settings
The following printer properties dialog box appears. Click the desired tab(s) and congure the properties as
necessary.
General/Details/Color Management/Sharing Tab:
These tabs are Windows specic settings. Refer to Windows manuals, Windows pop-up help topics, and/or
Online Support.
Note:
To open Windows pop-up help topics:
Click the
?
icon at top right corner of the printer properties dialog box. The "?" mark will appear on your mouse cursor.
Then click on unfamiliar object in the dialog box, the topic opens in a pop-up window. When you nish reading the
information in the pop-up window, you can close it by clicking anywhere in the window.
Device Tab
Support Tab
Prole Tab
Effects Tab
Quality Tab
Output Tab
Basic Tab
Job Type Tab : see page 29
: see page 16
: see page 26
: see page 31
: see page 39
: see page 44
: see page 46
: see page 48
Basic/Output/Job Type/Quality/Effects/Prole/Support/Device Tab:
These tabs are Panasonic Printing System associated settings. For additional details, refer to the page(s)
relevant to the subject you are interested in.

10
11
Conguring
the Printer Driver
Settings
Conguring
the Printer Driver
Settings
Opening the Printer Properties Dialog Box
Windows NT 4.0 (Administrator)
To change the printer settings, open the dialog box for the printer properties by performing the following steps.
Note:
In Windows NT 4.0, setting of the properties depends on the logon account. This section describes properties to be
specied by the administrator (system manager). See page 12 for details on user properties.
Logon to the computer/network using an account with administrator rights.
Click the Start button, select Settings, and then click the Printers icon.
Right-click on the desired printer icon in the Printers folder, and then select Properties in the pop-up menu.

10
11
Conguring
the Printer Driver
Settings
Conguring
the Printer Driver
Settings
The following printer properties dialog box appears. Click the desired tab(s) and congure the properties as
necessary.
General/Ports/Scheduling/Sharing/Security Tab:
These tabs are Windows specic settings. Refer to Windows manuals, Windows pop-up help topics, and/or
Online Support.
Note:
To open Windows pop-up help topics:
Click the
?
icon at top right corner of the printer properties dialog box. The "?" mark will appear on your mouse cursor.
Then click on unfamiliar object in the dialog box, the topic opens in a pop-up window. When you nish reading the
information in the pop-up window, you can close it by clicking anywhere in the window.
Form/Tray/Device Tab:
These tabs are Panasonic Printing System associated settings. For additional details, refer to the page(s)
relevant to the subject you are interested in.
Form/Tray Tab
Device Tab : see page 48
: see page 47

12
Conguring
the Printer Driver
Settings
Opening the Printer Properties Dialog Box
Windows NT 4.0 (User)
To change the printer settings, open the dialog box for the printer properties by performing the following steps.
Select Print in the File menu of the application. (i.e. Microsoft® WordPad)
Select the printer model in the name list box.
Basic Tab
Output Tab
Job Type Tab
Quality Tab
Effects Tab
Support Tab
Prole Tab : see page 44
: see page 46
: see page 39
: see page 31
: see page 29
: see page 26
: see page 16
Click the
Properties
button in the Print dialog box.
The printer properties dialog box appears. Click the desired tab(s) and congure the properties as
necessary.

13
Conguring
the Printer Driver
Settings
Opening the Printer Properties Dialog Box
Windows 2000/Windows XP/Windows Server 2003 (Administrator)
To change the printer settings, open the dialog box for the printer properties by performing the following steps.
Note:
In Windows 2000/Windows XP/Windows Server 2003, setting of the properties depends on the logon
account. This section describes properties to be specied by the administrator (system manager). See
"Windows2000/Windows XP/Windows Server 2003 (User)" on page 15 for details on user properties.
Logon to the computer/network using an account with administrator rights.
Click the Start button, select Printers and Faxes icon. (for Windows 2000: Click the
Start button, select Settings, and then click the Printers icon)
Right-click on the desired printer icon in the Printer and Faxes folder, and then select Properties in the
pop-up menu.

14
Conguring
the Printer Driver
Settings
The following printer properties dialog box appears. Click the desired tab(s) and congure the properties as
necessary.
General/Sharing/Ports/Advanced/Color Management/Security Tab:
These tabs are Windows specic settings. Refer to Windows manuals, Windows pop-up help topics, and/or
Online Support.
Note:
To open Windows pop-up help topics:
Click the
?
icon at top right corner of the printer properties dialog box. The "?" mark will appear on your mouse cursor.
Then click on unfamiliar object in the dialog box, the topic opens in a pop-up window. When you nish reading the
information in the pop-up window, you can close it by clicking anywhere in the window.
Form/Tray/Device Tab:
These tabs are Panasonic Printing System associated settings. For additional details, refer to the page(s)
relevant to the subject you are interested in.
Form/Tray Tab
Device Tab : see page 48
: see page 47

15
Conguring
the Printer Driver
Settings
Opening the Printer Properties Dialog Box
Windows 2000/Windows XP/Windows Server 2003 (User)
To change the printer settings, open the dialog box for the printer properties by performing the following steps.
Click the
Preferences
button in the Print dialog box.
Select Print in the File menu of the application. (i.e. Microsoft® WordPad)
Select the printer model in the name list box.
The printer properties dialog box appears. Click the desired tab(s) and congure the properties as necessary.
Support Tab
Prole Tab
Effects Tab
Quality Tab
Job Type Tab
Output Tab
Basic Tab : see page 16
: see page 26
: see page 29
: see page 31
: see page 39
: see page 44
: see page 46

16
17
Conguring
the Printer Driver
Settings
Conguring
the Printer Driver
Settings
Basic Tab
Basic tab is used for conguring basic printing settings.
1
6
2
3
4
5
7
11
12
13
14
8
9
10
1. Paper Size
Displays the current Paper Size and Output
Paper Size settings.
2. Paper Image
Represents the current settings, along with the
icons shown below.
3. Icons
Represent the current settings, along with the
paper image shown above.
4.
Printer Status...
button
Used to check the printer status, launch the
Device Monitor, which displays the status.
This feature is only available when the printer is
connected over a TCP/IP network.
5.
Restore All Defaults
button
Restores all the settings to the default value.
6. Paper Size/Output Paper Size
There are two settings for paper size. They are
Paper Size and Output Paper Size.
Paper Size denotes the document size created
by the software applications.
Output Paper Size denotes the size of paper
used by the printer.
Custom paper sizes can be selected in the
Paper Size and Output Paper Size settings.
Note:
Choosing envelope paper sizes, automatically
switches the
Media Type
to
Envelope
.
The
Media Type
and
Paper Source
settings defer
depending on the
Paper Size
setting.
7.
Custom Paper...
button
You can create, edit and delete custom papers.
Up to 50 custom papers can be registered.
Note:
Custom paper size is saved for individual users who
are logged on.
The saved Custom Papers will not be delated when
the PCL Driver is uninstalled. The Custom Paper
les will automatically be recognized if the PCL
Driver is installed again.
Use Long Paper
Creates Long Paper as a custom paper size.
Choose from the following paper sizes for long paper.
Width: 8.27 - 11.69 in.(210.0 - 297.0 mm)
Length: 18.01 - 35.43 in.(457.3 - 900.0 mm)

16
17
Conguring
the Printer Driver
Settings
Conguring
the Printer Driver
Settings
8. Orientation
Species the direction of the image to be printed.
10. Paper Source
Species the tray to be used for printing.
Automatically Select Paper is supplied from the tray that is loaded with the specied paper. If the
specied paper is loaded in multiple trays, it is supplied from the upper tray rst.
If a tray runs out of paper, paper is supplied from the next tray containing the
specied paper, and continues in this sequence.
Multi-Purpose Tray
(Sheet Bypass)
As its name suggest, this tray is used for all supported sizes and media types that
can t in this tray.
Tray 1/Tray 2 This is the standard paper tray, and the rst tray the specied paper is fed from.
Tray 3/Tray 4 These trays are the second paper source tier and optional trays thereafter.
The optional trays are only displayed if they are installed on the machine.
Note:
Be sure to specify on the printer what paper is loaded in the trays.
If the settings are wrong, paper will not be supplied correctly when the printer driver is set to
Automatically Select
.
Furthermore, be sure to set the paper on the Sheet Bypass properly when
Multi-Purpose Tray
is selected.
After installing the optional paper feeders, you must change the
Number of Paper Tray
on the
Device
tab of the
printer driver. For details, see "
Device
" on page 48.
11.
Cover Page...
button
You can congure the settings for cover pages.
To use a cover page, select Front Cover or Back
Cover.
Specify the Cover Type either Blank or Printed.
In Other Pages section, species the media type and
paper source used for pages other than the Front and
Back covers. Congure the same way as carried out
for Media Type and Paper Source in the Basic tab.
Note:
Cover pages are not available with
Reverse Page Order
.
Cover pages are not available with
Poster
.
Back Cover Page
is not available with
Booklet
.
Blank : Produces a blank cover page from the
specied paper source.
Printed : Prints the rst or last page as the cover
page from the specied paper source.
Continued on the next page...
9. Media Type
Species the type of paper.
Note:
Verify that the media type selection in the control panel matches the media loaded on the trays. (Ex: Select
"Transparency" when Transparencies are loaded in the Sheet Bypass)
Transparency
is only available if the selected
Paper Size
is
A4
or
Letter
.
Envelope
is only available if one of the envelope paper sizes is selected.
If the
Media Type
is other than
Plain Paper
,
Glossy/Photo Paper
or
Recycled Paper
, then the
Multi-Purpose Tray
is
the only selectable
Paper Source
.

18
Conguring
the Printer Driver
Settings
12. Duplex
Duplex (double-sided) is the process of printing on both sides of a piece of paper.
None
Select this for single-sided printing. The default is None.
Flip on Long Edge
Perform double-sided printing, ipping the paper
along its long edge (sometimes called Long Edge
Binding).
Flip on Short Edge
Perform double-sided printing, ipping the paper
along its short edge (sometimes called Short Edge
Binding).
Note:
Duplex printing is available if
Media Type
is set to
Plain
,
Glossy/Photo Paper
,
Recycle
.
Portrait format Landscape format Portrait format Landscape format
13. Duplex Margin
Species the gutter for duplex printing.
Set the gutter in a range of 0.0-2.0 in (0-50 mm).
14. Layout Print
Allows printing of documents in a variety of layouts.
Pages per Sheet Save paper by printing several pages reduced onto a single sheet.
Booklet
This feature is handy for creating your own booklets. After printing, fold sheets
in half to create booklets.
Fit to Output
Paper Size
Scales the source document to t it onto the specied paper.
Zoom Prints documents at the specied magnication.
Poster
Enlarges single-page documents for printing on several sheets. Assemble the
printed documents to make posters.
Note:
Windows NT 4.0:
This feature cannot be used when sending print jobs to a shared network printer.
Windows 2000/Windows XP/Windows Server 2003:
This feature is unavailable if the Windows NT 4.0 printer driver is installed. Be sure to install the driver that matches
your operating system.

19
Continued on the next page...
Conguring
the Printer Driver
Settings
Basic Tab
Pages per Sheet
Several pages are reduced in size and printed next to each other on single sheets. This feature is convenient for
printing test sheets and conserving paper.
1. Paper Size
Displays the current Paper Size and Output
Paper Size settings.
2. Paper Image
Represents the current settings, along with the
icons shown below.
3. Icons
Represent the current settings, along with the
paper image shown above.
4. Pages per Sheet
Species how many pages to reduce and print
on single sheets.
Choose from 2 up, 4 up, 6 up, 8 up, 9 up or
16 up.

20
Conguring
the Printer Driver
Settings
:Right, then Down
:Down, then Right
:Left, then Down
:Down, then Left
6. Page Border
Select this option to print a border around each
page.
Solid Print a solid line around each page.
Rotate Left 90 Rotates the printed image
counter-clockwise 90°
Rotate Right 90 Rotates the printed image
clockwise 90°
Not Rotate Do not rotate the image.
None Do not print page borders.
7. Style for Mixed Orientation (Except for
Windows 98/Windows Me)
In print jobs with different paper orientations, this
option species in which direction the printed
image is rotated.
8. Output Paper Size
Specify the size of paper used by the printer.
The settings are the same as for Output Paper
Size congured in the Basic tab.
:Left to Right
:Right to Left
:Up to Down
:Down to Up
5. Page Order
Species the order in which multiple pages are arranged on single sheets.
2 up Portrait 2 up Landscape 4, 6, 8, 9, 16 up
