Panasonic KX-TCD320E User manual

This unit is compatible with Caller ID and SMS. To use these
features, you must subscribe to the appropriate service of your
service provider.
Charge the batteries for about 7 hours before initial use.
Please read these operating instructions before using the unit and save them for
future reference.
Operating Instructions
Model No. KX-TCD320E
Digital Cordless Answering System
TCD320E(e).book Page 1 Friday, January 7, 2005 10:01 AM

Introduction
2Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Introduction
Thank you for purchasing a new Panasonic digital cordless phone.
For your future reference
Attach or keep original receipt to assist with any repair under warranty.
Note:
LThis equipment is designed for use on the UK and Republic of Ireland analogue telephone
network.
LIn the event of problems, you should contact your equipment supplier in the first instance.
Declaration of Conformity:
LPanasonic Communications Co., Ltd. declares that this equipment is in compliance with the
essential requirements and other relevant provisions of Radio & Telecommunications
Terminal Equipment (R&TTE) Directive 1999/5/EC.
Declarations of Conformity for the relevant Panasonic products described in this manual
are available for download by visiting:
http://www.doc.panasonic.de
Contact:
Panasonic Services Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, F.R. Germany
Trademarks:
LEatoni and LetterWise are trademarks of Eatoni Ergonomics, Inc.
Serial No. (found on the bottom of the base unit)
Date of purchase
Name and address of dealer
TCD320E(e).book Page 2 Friday, January 7, 2005 10:01 AM

Feature highlights
3
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Feature highlights
Colour display
The handset’s colour display allows you to customise the handset to your
liking. You can customise the handset by selecting the “wallpaper” pattern
shown on the display in standby mode (page 28). If you set the wallpaper
to “Off”, the display colour (page 28) setting will be used instead.
Phonebooks
This unit provides the handset phonebook (200 names and phone
numbers; page 19) and the shared phonebook (20 names and phone
numbers; page 22). These phonebooks allow you to make calls without
having to dial manually. For handset phonebook, you can assign each
handset phonebook entry to the desired category, and search for handset
phonebook entries by name or category.
Handset phonebook category
If you subscribe to Caller ID service, handset phonebook categories (page
19) can help you identify who is calling by using different display colours
and ringtones for different categories of callers (page 36).
Audible call for shared phonebook
Audible call allows you to know who is calling without looking at the display.
If you record an audible call announcement for a shared phonebook entry
(page 22), the audible call recording will be announced when you receive
a call from that person.
Audible call is available only after subscribing to Caller ID service (page
37).
Night mode
Night mode allows you to select a block of time during which the
handset/base unit will not ring, useful if you do not want to be disturbed, for
example, while sleeping.
Night mode can be set independently for the handset (page 27) and base
unit (page 32).
Digital answering system
Digital answering system allows the unit to answer and record calls for you
when you are unavailable to answer the phone (page 47).
Tom
Tom
TCD320E(e).book Page 3 Friday, January 7, 2005 10:01 AM

Feature highlights
4Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
SMS (Short Message Service)
SMS allows you to send and receive text messages between other fixed-
line and mobile phones that support compatible SMS networks and
features. SMS features are available only after subscribing to Caller ID
and/or appropriate service (page 39).
Polyphonic ringtones for handset
You can change the ringtone heard when the handset rings for outside
calls and intercom calls. You can choose from 6 ringtones and 14 melody
tones (page 26).
TCD320E(e).book Page 4 Friday, January 7, 2005 10:01 AM

Table of Contents
5
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Preparation
Accessory information . . . . . . . . . . . . . . .6
Important information . . . . . . . . . . . . . . . .8
Controls and displays. . . . . . . . . . . . . . . .9
Connections . . . . . . . . . . . . . . . . . . . . . . 11
Battery installation . . . . . . . . . . . . . . . . .12
Battery charge . . . . . . . . . . . . . . . . . . . .12
Screen saver mode . . . . . . . . . . . . . . . .13
Battery replacement. . . . . . . . . . . . . . . . 13
Turning the power on/off . . . . . . . . . . . .13
Setting the date and time . . . . . . . . . . . .14
Making/Answering Calls
Making calls . . . . . . . . . . . . . . . . . . . . . .15
Answering calls . . . . . . . . . . . . . . . . . . .17
Phonebooks
Handset phonebook. . . . . . . . . . . . . . . .19
Shared phonebook. . . . . . . . . . . . . . . . .22
Copying phonebook entries . . . . . . . . . .24
Handset Settings
Guide to handset settings . . . . . . . . . . .25
Time settings . . . . . . . . . . . . . . . . . . . . .26
Ringer setup. . . . . . . . . . . . . . . . . . . . . .26
Night mode. . . . . . . . . . . . . . . . . . . . . . .27
Display setup . . . . . . . . . . . . . . . . . . . . .28
Call options . . . . . . . . . . . . . . . . . . . . . .29
Other options . . . . . . . . . . . . . . . . . . . . .29
Base Unit Settings
Guide to base unit settings. . . . . . . . . . .31
Ringer setup. . . . . . . . . . . . . . . . . . . . . .32
Call options . . . . . . . . . . . . . . . . . . . . . .33
Other options . . . . . . . . . . . . . . . . . . . . .34
Caller ID Service
Using Caller ID service. . . . . . . . . . . . . .36
Caller list . . . . . . . . . . . . . . . . . . . . . . . .37
SMS (Short Message
Service)
Using SMS (Short Message Service) . . 39
Turning SMS on/off . . . . . . . . . . . . . . . . 39
Changing SMS message centre
numbers. . . . . . . . . . . . . . . . . . . . . . . . . 39
Registering mailboxes . . . . . . . . . . . . . . 40
Sending a message . . . . . . . . . . . . . . . . 40
Receiving a message . . . . . . . . . . . . . . 42
Guide to SMS settings . . . . . . . . . . . . . . 43
Available character entries for SMS. . . . 45
Answering System Features
Answering system . . . . . . . . . . . . . . . . . 47
Turning the answering system on/off . . . 47
Greeting message . . . . . . . . . . . . . . . . . 47
Listening to messages . . . . . . . . . . . . . . 48
Recording a voice memo . . . . . . . . . . . . 49
Memory capacity . . . . . . . . . . . . . . . . . . 49
Using direct commands . . . . . . . . . . . . . 50
Remote operation . . . . . . . . . . . . . . . . . 50
Guide to answering system settings . . . 52
Multi-unit Operation
Operating additional units . . . . . . . . . . . 54
Registering a handset to a base unit . . . 54
Intercom between handsets. . . . . . . . . . 56
Transferring calls between handsets,
conference calls. . . . . . . . . . . . . . . . . . . 56
Useful Information
Wall mounting . . . . . . . . . . . . . . . . . . . . 58
Available character entries. . . . . . . . . . . 59
Troubleshooting . . . . . . . . . . . . . . . . . . . 62
Specifications. . . . . . . . . . . . . . . . . . . . . 67
Conditions of guarantee. . . . . . . . . . . . . 68
Index
Index . . . . . . . . . . . . . . . . . . . . . . . . . . 69
TCD320E(e).book Page 5 Friday, January 7, 2005 10:01 AM

Preparation
6Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Accessory information
Sales and support information
Customer Care Centre
LFor UK customers: 08700 100 076
LFor Republic of Ireland customers: 01289 8333
LVisit our website for product information: www.panasonic.co.uk
LE-mail: [e-mail]
Direct Sales at Panasonic UK
LOrder accessory and consumable items for your product with ease and confidence by
phoning our Customer Care Centre Monday - Friday, 9:00 am - 5:30 pm. (Excluding public
holidays)
LOr go on line through our Internet Accessory ordering application at
www.panasonic.co.uk
LMost major credit and debit cards accepted.
LAll enquiries transactions and distribution facilities are provided directly by Panasonic UK
Ltd.
LIt couldn’t be simpler!
LAlso available through our Internet is direct shopping for a wide range of finished products,
take a browse on our website for further details.
Additional/replacement accessories
Model No. Description
P03P 2 rechargeable nickel metal hydride (Ni-MH) batteries
KX-TCA130E Additional handset
KX-A272 DECT repeater
TCD320E(e).book Page 6 Friday, January 7, 2005 10:01 AM

Preparation
7
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Included accessories
AC adaptor
Part No. PQLV19EZ
(PQLV19E)
Telephone line cord
Part No. PQJA87S (for UK)
Rechargeable batteries
AAA (R03) size
Part No. HHR-4EPT
Handset cover
Part No.
PQYNTCD320E
Operating instructions Quick guide
SMS guide
TCD320E(e).book Page 7 Friday, January 7, 2005 10:01 AM

Preparation
8Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Important information
General
LUse only the AC adaptor included with this
product, noted on page 7.
LDo not connect the AC adaptor to any AC
outlet other than a standard 220–240 V
AC outlet.
LThis product is unable to make calls when:
– The portable handset battery(ies) need
recharging or have failed.
– There is a power failure.
– The key lock feature is turned on.
– The call bar feature is turned on (only
phone numbers stored in the unit as
emergency numbers can be called).
LDo not open the base unit or handset
other than to replace the battery(ies).
LThis product should not be used near
emergency/intensive care medical
equipment and should not be used by
people with pacemakers.
LCare should be taken that objects do not
fall onto, and liquids are not spilled into,
the unit. Do not subject this product to
excessive smoke, dust, mechanical
vibration or shock.
Environment
LDo not use this product near water.
LThis product should be kept away from
heat sources such as radiators, cookers,
etc. It should also not be placed in rooms
where the temperature is less than 5 °C or
greater than 40 °C.
LThe AC adaptor is used as the main
disconnect device. Ensure that the AC
outlet is installed near the unit and is
easily accessible.
Warning:
LTo prevent the risk of electrical shock, do
not expose this product to rain or any
other type of moisture.
Location
LFor maximum distance and noise-free
operation, place your base unit:
– Away from electrical appliances such as
TVs, radios, personal computers or
other phones.
– In a convenient, high and central
location.
Battery caution
LWe recommend using the battery(ies)
noted on page 6. Use only rechargeable
battery(ies).
LDo not mix old and new batteries.
LDo not dispose of the battery(ies) in a fire,
as they may explode. Check local waste
management codes for special disposal
instructions.
LDo not open or mutilate the battery(ies).
Released electrolyte from the battery(ies)
is corrosive and may cause burns or injury
to the eyes or skin. The electrolyte may be
toxic if swallowed.
LExercise care when handling the
battery(ies). Do not allow conductive
materials such as rings, bracelets or keys
to touch the battery(ies), otherwise a short
circuit may cause the battery(ies) and/or
the conductive material to overheat and
cause burns.
LCharge the battery(ies) in accordance
with the information provided in these
operating instructions.
LOnly use the included base unit (or
charger) to charge the battery(ies). Do not
tamper with the base unit (or charger).
Failure to follow these instructions may
cause the battery(ies) to swell or explode.
TCD320E(e).book Page 8 Friday, January 7, 2005 10:01 AM

Preparation
9
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Controls and displays
Controls
Handset
ASpeaker
BCharge contact
CDisplay
DSoft keys
E{C} (Talk)
FNavigator key
L {e}{v}: To search for the desired
item in menus.
L{>}: To select the desired item or
move the cursor to the right.
L{<}: To return to the previous screen
or move the cursor to the left.
G{s} (Speakerphone)
HDial keypad
LThe icons printed below the dial keys
shown in the illustration (g, d, ■etc.)
indicate answering system operations.
I{R}(Recall)
JReceiver
K{ih} (Off/Power)
L{C/T}(Clear/Mute)
M{INT}(Intercom)
NMicrophone
Note:
LUp to 3 menu items can be displayed at a
time. To select a menu item not shown on
the current page, scroll up or down by
pressing the navigator key, {e} or {v},
respectively.
Base unit
AAnswer on indicator
B{x} (Page)
CCharge contact
Displays
Display icons
Various icons appear on the handset display
to indicate the current status of the unit.
C
s
i
h
T
M
N
C
E
F
G
H
I
DK
J
L
B
A
N
a
HG
g
LN
gd
n
n
Display
icon
Meaning
wWithin range of a base unit
LWhen flashing: Handset
is searching for base unit.
(out of range of base unit,
handset is not registered
to base unit, no power on
base unit)
B
A
C
TCD320E(e).book Page 9 Friday, January 7, 2005 10:01 AM

Preparation
10 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Menu icons
When in standby mode, pressing the middle
soft key reveals the handset’s main menu.
From here you can access various features
and settings.
Soft keys
The handset features 3 soft keys. By
pressing a soft key, you can select the
feature or operation indicated by the soft key
icon shown directly above it.
LPressing the left, middle, or right soft key
selects the leftmost, centre, or rightmost
soft key icon respectively.
LThe icons shown will vary depending on
how you are using the unit.
xHandset is accessing base
unit. (intercom, paging,
changing base unit settings,
etc.)
kHandset is on an outside
call.
xCall bar is on. (page 29)
yMissed call (Caller ID
subscribers only; page 36)
uAnswering system is on
(page 47) and/or new
messages have been
recorded. (page 48)
nAnswering system is full.
dAnswering system will
answer calls with a greeting
message and caller
message will not be
recorded. (page 53)
iBatteries are charging.
1Battery strength
eAlarm is on. (page 26)
dVoice enhancer is set to
high or low tone. (page 16)
URinger volume is off. (page
26)
fNight mode is on. (page 27)
[2] Handset number: The left
icon shows handset 2
example. (page 28)
-2- Base unit number: The left
icon shows base unit 2
example. (page 28)
hNew SMS message
received (SMS users only;
page 42)
jYour written SMS message
is over 160 characters.
(SMS users only; page 41)
Display
icon
Meaning
mSMS memory is full. (SMS
users only)
Line is being used by
another handset.
Menu
icon
Menu/feature
WCaller List
XSMS (Short Message Service)
uAnswer System
YHandset Setup
ZBase Unit Setup
aDisplay Setup
Display
icon
Meaning
C
s
i
h
T
TCD320E(e).book Page 10 Friday, January 7, 2005 10:01 AM

Preparation
11
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Soft key icons Connections
When the AC adaptor is connected, a short
beep will be heard. If it is not heard, check
the connections.
Important:
LUse only the AC adaptor and telephone
line cord supplied with this unit.
Note:
LIf the AC outlet is connected to a switch,
make sure the switch is on.
LAfter connection, you must charge the
batteries to make or answer calls (page
12).
LNever install telephone wiring during a
lightning storm.
LThe AC adaptor must remain connected
at all times. (It is normal for the adaptor to
feel warm during use.)
LThe AC adaptor should be connected to a
vertically oriented or floor-mounted AC
outlet. Do not connect the AC adaptor to a
ceiling-mounted AC outlet, as the weight
Soft
key
icon
Action
vReturns to the previous
screen.
$Displays the main menu.
,Accepts the current selection.
qDisplays a previously dialled
phone number.
UOpens the phonebook and
switches between handset
phonebook and shared
phonebook.
rDisplays the phonebook
search menu.
"Turns the key lock feature off.
(page 16)
pDisplayed when adding or
editing a phonebook entry, or
when writing an SMS
message.
ZStops recording or playback.
sInserts a dialling pause. (page
17)
wErases the selected item.
tDisplayed when the soft key
has no function.
(220–240 V, 50 Hz)
To telephone
network
Hooks
TCD320E(e).book Page 11 Friday, January 7, 2005 10:01 AM

Preparation
12 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
of the adaptor may cause it to become
disconnected.
LThe unit will not work during a power
failure. We therefore recommend you also
connect a standard telephone to the same
telephone line using a T-adaptor. Your
Panasonic sales shop can offer you more
information about connection possibilities.
Battery installation
1Insert the batteries negative (T)
terminal first.
2Close the handset cover.
Note:
LUse only rechargeable batteries (page 7).
Battery charge
Place the handset on the base unit for
about 7 hours before initial use.
When charging, iand battery strength
icon are alternately shown on the display.
When the batteries are fully charged, 1
flashes.
Note:
LIt is normal for the handset to feel warm
during charging.
LIt takes 7 hours to fully charge the
batteries, however, you can use the
handset before the batteries are fully
charged.
LClean the charge contacts (page 9) of the
handset and base unit with a soft, dry
cloth once a month, otherwise the
batteries may not charge properly. Clean
more often if the unit is exposed to grease,
dust or high humidity.
Battery strength
Note:
LWhen 3flashes, recharge the handset
batteries. 3will continue to flash until
the batteries have been charged for at
least 15 minutes.
Battery icon Battery strength
1High
2Medium
3Low
When flashing: Needs
to be charged.
TCD320E(e).book Page 12 Friday, January 7, 2005 10:01 AM

Preparation
13
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
LIf the handset is turned off, it will be turned
on automatically when it is placed on the
base unit.
Battery life
After your Panasonic batteries are fully
charged, you can expect the following
performance:
Ni-MH batteries (700 mAh)
Note:
LActual battery performance depends on a
combination of how often the handset is in
use (talking) and how often it is not in use
(standby).
LBattery operating time may be shortened
over time depending on usage conditions
and ambient temperature.
Screen saver mode
The backlight will turn off completely after 1
minute of inactivity if the handset is not on
the base unit. Only essential icons and the
date and time will be displayed, and they will
occasionally change position in order to
preserve the life of the display.
Example:
To use the handset when it is in screen
saver mode, first press {ih} to turn the
display on again.
Battery replacement
If 3flashes even after the handset
batteries have been charged for 7 hours, the
batteries must be replaced.
Important:
LWe recommend the use of Panasonic
rechargeable batteries noted on page 6. If
you install non-rechargeable batteries and
start charging, the batteries may leak
electrolyte.
LDo not mix old and new batteries.
1Press the notch on the handset cover
firmly and slide it in the direction of the
arrow.
2Remove the old batteries positive (S)
terminal first and install the new ones.
See page 12 for battery installation.
Turning the power on/off
Power on
Press {ih} for about 1 second.
LThe display will change to the standby
mode.
Power off
Press {ih} for about 2 seconds.
LThe display will go blank.
Operation Operating time
While in use (talking) 16 hours max.
While not in use
(standby)
170 hours max.
17 May 15:30
1
TCD320E(e).book Page 13 Friday, January 7, 2005 10:01 AM

Preparation
14 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Setting the date and time
Important:
LConfirm that the AC adaptor is connected.
LEnsure that wis not flashing. If the
handset is in screen saver mode, wis not
displayed. Press {ih} to turn the
display on.
1Press $(middle soft key).
2Select Y, then press ,.
3Select “Time Settings”, then press
,.
4Select “Set Date & Time”, then press
,.
5Enter the current day, month and year by
selecting 2 digits for each.
Example: 17 May, 2005
Press {1}{7}{0}{5}{0}{5}.
6Enter the current hour and minute by
selecting 2 digits for each.
LYou can select “AM”, “PM”or 24-hour
time entry by pressing {*} repeatedly.
Example: 3:30 PM
Press {0}{3}{3}{0}, then press {*}
repeatedly until “03:30 PM”is
displayed.
7Press ,.
8Press {ih}.
Note:
LTo correct a digit, press {<} or {>} to
move the cursor, then make the
correction.
LThe date and time may be incorrect after a
power failure. In this case, set the date
and time again.
TCD320E(e).book Page 14 Friday, January 7, 2005 10:01 AM

Making/Answering Calls
15
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Making calls
1Lift the handset and dial the phone
number.
LTo correct a digit, press {C/T}, then
enter the correct number.
2Press {C}.
3When finished talking, press {ih} or
place the handset on the base unit.
Speakerphone
The handset features a digital
speakerphone, which allows you to have
hands-free conversations.
1During a conversation, press {s} to turn
on the speakerphone.
LSpeak alternately with the caller.
2When finished talking, press {ih} or
place the handset on the base unit.
Note:
LFor best performance, please note the
following:
– Use the speakerphone in a quiet
environment.
– If you or the other party have difficulty
hearing each other, press {e} or {v}
repeatedly to adjust the speaker volume
as necessary.
LTo switch back to the receiver, press
{C}.
To adjust the receiver or speaker volume
Press {e} or {v} while talking. 4 volume
levels are available for the receiver. 6 levels
are available for the speaker.
Redial feature
Previously dialled phone numbers (each 24
digits max.) can be redialled.
To redial the last number dialled
Press q(right soft key), then press {C}
or {s}.
LIf {s} is pressed, the unit will redial
automatically if the other party’s line is
engaged.
Note:
LYou can also press {C} or {s} before
pressing q.
To make a call using the redial list
The last 10 phone numbers dialled are
stored in the redial list.
1Press q(right soft key).
LThe last number dialled will be
displayed.
2Press {e} or {v} repeatedly to select
the desired number.
LTo exit the list, press {ih}.
3Press {C} or {s}.
LIf {s} is pressed, the unit will redial
automatically if the other party’s line is
engaged.
To redial automatically
If you press {s} when redialling and the
other party’s line is engaged, the unit will
redial the phone number again
automatically. The unit will redial up to 11
times. While the handset is waiting to redial,
{s} will flash. While the handset is
redialling, mute is automatically turned on.
Note:
LAutomatic redial is cancelled when any
button (except q) is pressed.
LIf mute does not turn off after the line is
connected, press {C/T}.
To edit a number in the redial list before
calling it
1Press q(right soft key).
2Press {e} or {v} repeatedly to select
the desired number, then press $.
TCD320E(e).book Page 15 Friday, January 7, 2005 10:01 AM

Making/Answering Calls
16 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
3Select “Edit and Call”, then press
,.
4Press {<} or {>} to move the cursor,
then edit the number.
LPlace the cursor on the number you
wish to erase, then press {C/T}.
LPlace the cursor to the right of where
you want to insert a number, then
press the appropriate dial key.
5Press {C}, {s}, or ,to call.
To erase numbers in the redial list
1Press q(right soft key).
2Press {e} or {v} repeatedly to select
the desired number, then press $.
3Select “Erase”, then press ,.
LIf you want to erase all numbers in the
list, select “Erase All”, then press
,.
4Select “Yes”, then press ,.
5Press {ih}.
To store a number from the redial list into
the handset phonebook
1Press q(right soft key).
2Press {e} or {v} repeatedly to select
the desired number, then press $.
3Select “Add Phonebook”, then press
,.
4Enter a name (16 characters max.; see
page 59 for character entry), then press
,.
5Edit the phone number if necessary,
then press ,.
6Select the desired category (page 19),
then press ,.
7Select “Save”, then press ,.
8Press {ih}.
Other features
Voice enhancer
You can change the tone quality of the
receiver while you are on a call. 3 settings
are available.
1Press $(middle soft key) during a
call.
2Select “Voice Enhancer”, then press
,.
3Select the desired setting, then press
,.
Note:
LIf you select “High Tone”or “Low
Tone”, dis displayed.
Mute
You can mute your voice during a
conversation. While mute is turned on, you
will be able to hear the other party, but the
other party will not be able to hear you.
1To mute your voice, press {C/T}.
2To return to the conversation, press
{C/T}again.
Key lock
The handset can be locked so that no calls
or settings can be made. Incoming calls can
be answered, but all other functions are
disabled while key lock is on.
To turn key lock on, press $(middle soft
key) for about 2 seconds.
L"is displayed.
LTo turn key lock off, press "(middle
soft key) for about 2 seconds.
Note:
LCalls to emergency numbers (page 33)
cannot be made until key lock is turned
off.
LKey lock is turned off when the handset is
turned off.
TCD320E(e).book Page 16 Friday, January 7, 2005 10:01 AM

Making/Answering Calls
17
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Call waiting - {R}button
If a second call is received while in
conversation with the first caller, a beep tone
will be heard. Press {R}button to switch
between callers.
This service requires a subscription, consult
your service provider for details.
Note:
LIf your unit is connected to a PBX (private
branch exchange), pressing {R}can allow
you to access certain features of your host
PBX such as transferring an extension
call. Consult your PBX dealer for details.
LYou can change the recall time (page 33).
Pause button (for PBX/long distance
service users)
A pause is sometimes required when
making calls using a PBX or long distance
service.
Example: If you have to dial {0}before
dialling outside numbers manually, you will
probably pause after dialling {0}until you
hear a dial tone.
1Press {0}.
2Press s(right soft key).
3Dial the phone number, then press {C}
or {s}.
Note:
LPressing s1 time creates 1 pause.
Press srepeatedly to create longer
pauses. To change pause length, see
page 33.
Recording a telephone conversation
You can record your conversation while on
an outside call.
Important:
LBefore recording a conversation, you
should inform the other party that the
conversation will be recorded.
1Press $(middle soft key) during a
conversation.
2Select “Record Call”, then press
,.
LA beep is heard and recording starts.
LA beep sounds every 15 seconds and
can be heard by the other party, but is
not recorded.
3To stop recording, press Z.
Note:
LRecorded conversations are treated as
new messages.
LTo listen to the recorded conversation, see
page 48.
LIf message memory becomes full,
“Memory Full”is displayed and
recording stops. Erase unnecessary
messages (page 48).
LWhile recording a conversation, you
cannot change the tone quality of the
handset.
Answering calls
1Lift the handset and press {C} or {s}
when the unit rings.
LYou can also answer a call by pressing
any dial key from {0}to {9}, {*}, {#},
or {INT}. (Any key answer feature)
2When finished talking, press {ih} or
place the handset on the base unit.
Auto talk feature
You can answer calls simply by lifting the
handset off the base unit. You do not need to
press {C}. To turn this feature on, see
page 29.
To adjust the ringer volume when an
outside call comes in
Press {e} or {v} when an outside call
comes in.
Note:
LThe ringer volume cannot be adjusted if
the handset is on the base unit.
TCD320E(e).book Page 17 Friday, January 7, 2005 10:01 AM

Making/Answering Calls
18 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Other features
Handset locator
Using this feature, you can locate the
handset if it has been misplaced.
1Press {x} on the base unit.
LThe base unit will page the handset
for about 1 minute.
2To stop paging, press {x} on the base
unit or press {ih} on the handset.
TCD320E(e).book Page 18 Friday, January 7, 2005 10:01 AM

Phonebooks
19
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Handset phonebook
The handset phonebook allows you to make
calls without having to dial manually. You
can add 200 names and phone numbers to
the handset phonebook, assign each
handset phonebook entry to the desired
category, and search for handset
phonebook entries by name or category.
Adding entries to the handset
phonebook
1Press U(left soft key), then press
$.
2Select “New Entry”, then press ,.
3Enter the party’s name (16 characters
max.; see page 59 for character entry),
then press ,.
4Enter the party’s phone number (24
digits max.), then press ,.
5Select the desired category for the entry,
then press ,.
6Select “Save”, then press ,.
7Press {ih}.
Note:
LIf there is no space to store new entries,
“Memory Full”will be displayed. Erase
unnecessary entries (page 20).
To edit/correct a mistake
Press {<} or {>} to place the cursor on the
number or character you wish to erase, then
press {C/T}. Place the cursor to the right of
where you want to insert a number or
character, then press the appropriate dial
key.
Note:
LPress and hold {C/T}to erase all
numbers or characters.
Categories
Categories can help you find entries in the
handset phonebook quickly and easily.
When adding an entry to the handset
phonebook you can assign it to the desired
category. You can change the names of
categories assigned for handset phonebook
entries (“Friends”, “Family”, etc.) and then
search for handset phonebook entries by
category. Additional category features are
available for Caller ID subscribers (page
36).
Changing category names
1Press U(left soft key), then press
$.
2Select “Category”, then press ,.
3Select the category you want to change
the name of, then press ,.
4Select “Category Name”, then press
,.
5Edit the name (10 characters max.; see
page 59 for character entry), then press
,.
6Press {ih}.
Finding and calling a handset
phonebook entry
Handset phonebook entries can be
searched for by first character, by category,
or by scrolling through all handset
phonebook entries.
Once you have found the desired entry,
press {C} or {s} to dial the phone number.
Scrolling through all entries
1Press U(left soft key).
2Press {e} or {v} repeatedly to display
the desired entry.
TCD320E(e).book Page 19 Friday, January 7, 2005 10:01 AM

Phonebooks
20 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Searching by first character (index
search)
1Press U(left soft key), then press
r.
2Select “Index Search”, then press
,.
3Select the character entry mode that
contains the character you are
searching for, and press ,.
4Press the dial key ({0}to {9}) which
contains the character you are
searching for (page 59).
LPress the same dial key repeatedly to
display the first entry corresponding to
each letter located on that dial key.
LIf there is no entry corresponding to
the letter you selected, the next entry
will be displayed.
5Press {e} or {v} repeatedly to scroll
through the handset phonebook if
necessary.
Searching by category
1Press U(left soft key), then press
r.
2Select “Category Search”, then
press ,.
3Select the category you want to search,
then press ,.
LThe first entry in that category is
displayed.
LIf you select “All”, the unit will end
the category search.
4Press {e} or {v} repeatedly to scroll
through the handset phonebook if
necessary.
Editing entries in the handset
phonebook
Handset phonebook entries can be edited
after you have saved them. You can change
the name, phone number, and category.
Changing a name, phone number,
category
1Find the desired entry (page 19), then
press $(middle soft key).
2Select “Edit”, then press ,.
3Edit the name if necessary (16
characters max.; see page 59 for
character entry), then press ,.
4Edit the phone number if necessary (24
digits max.), then press ,.
5Select the desired category, then press
,.
6Select “Save”, then press ,.
7Press {ih}.
Erasing entries from the handset
phonebook
Erasing an entry
1Find the desired entry (page 19), then
press $(middle soft key).
2Select “Erase”, then press ,.
3Select “Yes”, then press ,.
4Press {ih}.
Erasing all entries
1Press U(left soft key), then press
$.
2Select “Erase All”, then press ,.
3Select “Yes”, then press ,.
4Select “Yes”again, then press ,.
5Press {ih}.
One touch dial
Assigning an entry in the handset
phonebook to a one touch dial key
Dial keys {1}to {9}can each be used as a
one touch dial key, allowing you to dial a
TCD320E(e).book Page 20 Friday, January 7, 2005 10:01 AM
