Panasonic HDC-SDT750PP User manual

Pa.aso.ic
Operating Instructions
High Definition Video Camera
Mo_e,No.HDC'SDT750PP
Before connecting, operating or adjusting this product, please read the instructions completely.
ZXVCH iE) _. F17DOLBY LEICA _,T.
O,G'TAL] OlcOMAR_'_"
5.1 CREATOR
H ml V TM
VQT3 B18

Dubbing with a Blu-ray
disc recorder, video, etc.
mm
IvIDE0I_
You can dub using a Panasonic Blu-ray disc recorder or high-definition (AVCHD)
compatible DVD recorder.
• Depending on the recorders or the media to be copied to, you may not be able to
copy in high-definition (AVCHD) picture quality. For further details, see the
operating instructions of your recorder.
•Note that the equipment described may not be available in certain countries and
regions.
About dubbing of scenes recorded in 1080/60p
The scenes recorded in 1080/60p cannot be dubbed to a disc with 1080/60p picture quality.
They are dubbed after be ng converted to AVCHD p cture qua ty. (As of Aug. 2010)
•Dubbing directly from inserted SD card
•Dubbing with a USB cable
• Use the AC adaptor to free you from worrying about the battery running down.
•Turn on the unit (This function is available in all modes).
t
O USB cable (supplied)
1Connect the unit to the Blu-ray disc recorder or high-definition
(AVCHD) compatible DVD recorder.
• The USB function selection screen will appear on the screen of the unit.
120
VQT3B18

2Touch [RECORDER] on the screen of this unit.
•When you select an option other than [RECORDER], reconnect the USB cable.
• When using the battery, the LCD monitor turns off after about 5 seconds. Touch the screen
to turn the LCD monitor on.
3Dubbing through operations on the Blu-ray disc recorder or high-
definition (AVCHD) compatible DVD recorder.
• When the unit is accessing the SD card, card access icon ( _ ) appears on the unit
screen or the access lamp is on.
• Be careful not to disconnect the USB cable, AC adapto[ o[ battery while the unit is
accessing the SD card, as this may result in the loss of recorded content.
• Dubbing scenes recorded in 3D
When dubbing with high-definition (AVCHD) picture quality, you can store 3D video. The
v dee s recorded una tered n s de-by-s de format.
• If the dubbed video does not change to 3D video, make the necessary settings on the TV.
(For further details, please read the operating instructions for the TV.)
• insert the USB cable securely all the way. It will not operate properly if it is not inserted all
the way.
• Do not use any other USB cables except the supplied one. (Operation is not guaranteed
with any other USB cables.)
• For details on dubbing and playback methods, read the operating instructions of the
Blu-ray disc recorder or DVD recorder.
• When you connect the unit to a Blu-ray disc recorder, a dubbing operations screen may
appear on the television connected to the Blu-ray disc recorder. In this case as well,
perform the operations of steps 1 to 3.
• You cannot change the mode of the unit or turn off the unit while it is connected to a Blu-ray
disc recorder or DVD recorder. Disconnect the USB cable before performing either of these
operations.
• If the battery runs down during dubbing, a message will appear. Operate the Blu-ray disc
recorder to cancel the dubbing.
121
VQT3B18

ImagesplayedbackonthisunitcanbedubbedontoaDVDrecorderorvideodevice.
•Images are dubbed in standard quality.
• Use the AC adaptor to free you from worrying about the battery running down.
Change the video input on the video
device and TV that this unit is
connected to.
•The channel set will differ depending on the
terminal to which the unit is connected.
• See the operating instructions of the video
device for details.
• Insert the plugs as far as they will go.
• Do not use any other AV mJlti cables except
the supplied one.
O AV multi cable (supplied)
1Connect this unit to a video device and then change the mode to
[].
2start playback on this unit.
3start recording on the connected device.
• To stop recording (dubbing), stop playback on this unit after stopping recording on the
recorder.
122
VQT3B18

•Dubbing scenes recorded in 3D
Copying unaltered as 3D video
When [3D PLAYBACK] is [3D], the 3D video is recorded in side-by-side format.
: [SETUP] _[3D PLAYBACK] _[3D]
•If the dubbed video does not change to 3D video, make the necessary settings on the TV.
(For further details, please read the operating instructions for the TV.)
Copying after conversion to 2D video
Set [3D PLAYBACK] to [2D].
:[SETUP] _[3D PLAYBACK] _[2D]
• If the date and time display and function indication are not wanted, cancel them before
dubbing. (-) 43, 106)
If the dubbed images are played back on a wide-screen TV, the images may be stretched
vertically.
In this case, refer to the operating instruction for the device you are connecting to or read
the operating instructions of the wide-screen TV and set the aspect ratio to 16:9.
123
VQT3B18

What you can do with a
PC
HD Writer AE 2.6T
You can copy the motion/still picture data to the HDD of PCs or write to media like Blu-ray
discs (BD), DVD discs or SD cards using HD Writer AE 2.6T, the software installed in the
supplied CD-ROM.
Refer to the operating instructions of HD Writer AE 2.6T (PDF file) for details on how to use it.
•Smart wizard
The Smart wizard screen is automatically displayed when you connect this unit to a PC with
HD Writer AE 2.6T installed. (-) 133)
Copy to PC:
You can copy motion/still picture data to the HDD of PCs.
Copy to disc:
You can copy to disc in high definition picture quality or conventional standard picture quality
(MPEG2 format).
• Select the function you wish to use and follow the on-screen instructions for easy copying.
124
VQT3B18

iii!!!iii!!i!ii!i!!i!!i!!i!!i!!i!!ili i!it !!
Copying data to a PC CD-ROM (supplied):
• Scenes recorded in 3D will be copied unaltered HD Writer AE 2.6T
as 3D video.
Copying in BD/AVCHD format
• Scenes recorded in 3D will be copied unaltered
as 3D video.
Copying in DVD-Video format:
• Converted to conventional standard quality
(M PEG2 format).
• Scenes recorded in 3D will be converted to 2D
video when copied.
Editing:
Editing motion picture data copied on an HDD of a PC
• Title, Transition, Delete partially, Divide Scene
(The only types of editing possible on scenes
recorded in 3D are Delete partially and Divide
Scene.)
• Converting the motion picture data to MPEG2
• Converting part of motion picture into still picture
Online sharing:
You can upload motion pictures on the Internet and
share them with your family and friends.
• Convert the scenes recorded in 3D to 2D video
when uploading.
Playing back on a PC:
Play back the motion picture data in high definition
picture quality on a PC.
• 3D video is played back as 2D video.
Formatting discs:
Depending on the type of disc that you use,
formatting is necessary.
Motion
and still
Motion
! o,
i¸_ _ _i_ _ _ _
i ..................
When writing scenes
recorded in 3D to a
Blu-ray disc, DVD or
SD card, a black
frame is displayed
around the thumbnail.
125
VQT3B18

PlayingbackonaPC HDWriterAE2.6Tor
StandardWindows
pictureviewerora
Still commercially
picture availablepicture
viewer
WindowsExplorerCopyingstillpicturestoaPC(-)135)
Refertopage137ifusingaMac.
Important Notice
• When using an SDXC Memory Card, check the following support site.
http:llpanasonic.net/avc/sdcardlinformation/SDXC.html
•Do not insert a disc recorded in AVCHD format with HD Writer AE 2.6T in a device
that does not support the AVCH D format. In some cases the disc may get stuck in
the device. The disc will not play back on devices that do not support the AVCHD
format.
• When inserting a disc containing recorded motion pictures into other devices, a
message prompting you to format the disc may be displayed. Do not format the
disc, since deleted data cannot be restored later.
•Motion pictures that have been recorded on another device cannot be written to the
software supplied with this unit. To write motion picture data recorded with the
Panasonic High Definition Video Camera sold previously, use the HD Writer supplied
with the unit.
• We cannot guarantee operation if you use software other than that supplied to read/write
motion picture.
• Do not start the software supplied with this unit and other software at the same time. Close
any other software if you start the software supplied with this unit and close the software
supplied with this unit if you start any other software.
•About Conversion Assist Function
When you want to convert the recording quality and write to media, the "Conversion Assist
Function", which is a linking function between this unit and the HD Writer AE 2.6T, is
activated by connecting this unit to the PC with the USB cable. When the "Conversion Assist
Function" is used, it is possible to write to media faster than when operating only on PC.
• Please refer to page 133 for details about the connection of this unit and a PC.
• Refer to the operating instructions of the software for details. (-) 136)
126
VQT3B18

BeforeopeningtheCD-ROMpackage,pleasereadthefollowing.
You("Licensee")aregrantedalicensefor
theSoftwaredefinedinthisEndUser
LicenseAgreement("Agreement")on
conditionthatyouagreetothetermsand
conditionsofthisAgreement.IfLicensee
doesnotagreetothetermsandconditions
ofthisAgreement,promptlyreturnthe
SoftwaretoPanasonicCorporation
("Panasonic"),itsdistributorsordealersfrom
whichyoumadethepurchase.
Article1 License
Licenseeisgrantedtherighttousethe
software,includingtheinformationrecorded
ordescribedontheCD-ROM,instruction
manuals,andanyothermediaprovidedto
Licensee(collectively"Software"),butall
applicablerightstopatents,copyrights,
trademarksandtradesecretsinthe
SoftwarearenottransferredtoLicensee.
Article2 UsebyaThirdParty
Licenseemaynotuse,copy,modify,transfer
orallowanythirdparty,whetherfreeof
chargeornot,touse,copyormodifythe
Software,exceptasexpresslyprovidedfor
inthisAgreement.
Article3 RestrictionsonCopyingthe
Software
Licenseemaymakeasinglecopyofthe
Softwareinwholeorapartsolelyforback-
uppurposes.
Article4 Computer
LicenseemayusetheSoftwareonlyonone
computer,andmaynotuseitonmorethan
onecomputer.
permittedunderlaworregulationofthe
countrywhereLicenseeresides.Panasonic
anditsdistributorswillnotberesponsiblefor
anydefectsintheSoftwareordamageto
LicenseecausedbyLicensee'sreverse
engineering,decompiling,ordisassemblyof
theSoftware.
Article6 Indemnification
TheSoftwareisprovided"AS-IS"without
warrantyofanykind,eitherexpressedor
implied,including,butnotlimitedto,
warrantiesofnon-infringement,
merchantabilityand/orfitnessforaparticular
purpose.Further,Panasonicdoesnot
warrantthattheoperationoftheSoftware
willbeuninterruptedorerrorfree.Panasonic
oranyofitsdistributorswillnotbeliablefor
anydamagesufferedbyLicenseearising
fromorinconnectionwithLicensee'suseof
theSoftware.
Article7 ExportControl
Licenseeagreesnottoexportorre-exportto
anycountrytheSoftwareinanyformwithout
theappropriateexportlicensesunder
regulationsofthecountrywhereLicensee
resides,ifnecessary.
Article8 TerminationofLicense
TherightgrantedtoLicenseehereunderwill
beautomaticallyterminatedifLicensee
contravenesanyofthetermsandconditions
ofthisAgreement.Inthisevent,Licensee
mustdestroytheSoftwareandrelated
documentationtogetherwithallthecopies
thereofatLicensee'sownexpense.
Article5 ReverseEngineering,
DecompilingorDisassembly
Licenseemaynotreverseengineer,
decompile,ordisassembletheSoftware,
excepttotheextenteitherofthemis
127
VQT3B18

Operating environment
• Even if the system requirements mentioned in these operating instructions are fulfilled,
some PCs cannot be used.
• A CD-ROM drive is necessary to install the supplied software applications. (A compatible
BD/DVD writer drive and media are necessary for writing to a BD/DVD.)
• Operation is not guaranteed in the following cases.
When 2 or more USB devices are connected to a PC, or when devices are connected
through USB hubs or by using extension cables.
Operation on an upgraded OS.
Operation on an OS other than the one pre-installed.
• This software is not compatible with Microsoft Windows 3.1, Windows 95, Windows 98,
Windows 98SE, Windows Me, Windows NT and Windows 2000.
•Operating environment for HD Writer AE 2.6T
_ii iiiiiiiii
RAM
IBM PC/AT compatible PC
Microsoft Windows XP (32 bit) Home Edition Service Pack 2/Service Pack 3
Microsoft Windows XP (32 bit) Professional Service Pack 2/Service Pack 3
Microsoft Windows Vista (32 bit) Home Basic Service Pack l/Service Pack 2
Microsoft Windows Vista (32 bit) HomePremium Service Pack l/Service Pack 2
Microsoft Windows Vista (32 bit) Business Service Pack l/Service Pack 2
Microsoft Windows Vista (32 bit) Ultimate Service Pack l/Service Pack 2
Microsoft Windows 7 (32 bit) Starter
Microsoft Windows 7 (32 bit/64 bit) Home Basic
Microsoft Windows 7 (32 bit/64 bit) Home Premium
Microsoft Windows 7 (32 bit/64 bit) Professional
Microsoft Windows 7 (32 bit/64 bit) Ultimate
Intel Pentium 4 2.8 GHz or higher (including compatible CPU)
• Intel Core 2 Duo 2.16 GHz or higher or
AMD Athlon 64 X2 Dual-Core 5200+ or higher is recommended
when using playback function or MPEG2 output function.
• Intel Core 2 Quad 2.6 GHz or higher is recommended when
using editing or Continuous Photo Playback function.
• Intel Core i7 2.8 GHz or higher is recommended when playing
back or using the editing function for 1080/60p
Windows 7:1 GB or more (32 bit)/2 GB or more (64 bit)
Windows Vista: 1 GB or more
Windows XP: 512 MB or more (1 GB or more recommended)
128
VQT3B18

_ii iiiiiiiii
HighColor(16bit)ormore(32bitormorerecommended)
Desktopresolutionof1024x768pixelsormore(1280x1024
pixelsormorerecommended)
WindowsVista/Windows7:DirectX9.0ccompatiblevideocard
(DirectX10recommended)
WindowsXP:DirectX9.0ccompatiblevideocard
CompatiblewithDirectDrawoverlay
PCIExpressTM×16compatiblerecommended
Free hard disk Ultra DMA -- 100 or more
450 MB or more (for installing the software)
•When writing to a DVD/BD/SD, more than double the amount of
free space as the disc being created is necessary.
Sound DirectSound Support
Interface USB port [Hi-Speed USB (USB 2.0)]
requirements Mouse or equivalent pointing device
Internet connection
• Supplied CD-ROM is available for Windows only.
• input is not supported in languages other than English, German, French and Simplified
Chinese.
• Operation cannot be guaranteed on all BD/DVD drives.
• Operation is not guaranteed on Microsoft Windows Vista Enterprise, Windows XP
Media Center Edition, Tablet PC Edition and Windows 7 Enterprise.
• This software is not compatible with a multi-boot environment.
• This software is not compatible with a multi-monitor environment.
• If using Windows XP, an administrative account user only can use this software. If using
Windows Vista/Windows 7, administrative account and standard account users only can
use this software. (An administrative account user should install and uninstall this
software.)
•To use the HD Writer AE 2.6T
You will need a high performance PC depending on the functions to be used. It may not
properly play back or properly operate depending on the environment of the PC used. Refer
to the operating environment and notes.
• Operation during the playback may become slow if the CPU or memory is not fulfilling the
requirements of the operating environment.
• Always use the most current driver for the video card.
• Always make sure there is enough capacity on the HDD in the PC. It may become
inoperable or the operation may stop suddenly if the capacity gets low.
129
VQT3B18

•Operating environment for the card reader function (mass storage)
_ii iiiiiiiii
cpu
IBM PC/AT compatible PC
Microsoft Windows XP (32 bit) Home Edition Service Pack 2/Service Pack 3
Microsoft Windows XP (32 bit) Professional Service Pack 2/Service Pack 3
Microsoft Windows Vista (32 bit) Home Basic Service Pack l/Service Pack 2
Microsoft Windows Vista (32 bit) Home PremiumService Pack l/Service Pack 2
Microsoft Windows Vista (32 bit) Business Service Pack l/Service Pack 2
Microsoft Windows Vista (32 bit) Ultimate Service Pack l/Service Pack 2
Microsoft Windows Vista (32 bit) Enterprise Service Pack l/Service Pack 2
Microsoft Windows 7 (32 bit) Starter
Microsoft Windows 7 (32 bit/64 bit) Home Basic
Microsoft Windows 7 (32 bit/64 bit) Home Premium
Microsoft Windows 7 (32 bit/64 bit) Professional
Microsoft Windows 7 (32 bit/64 bit) Ultimate
Windows Vista/Windows 7:1.0 GHz or higher
Windows XP: Intel Pentium ]]] 450 MHz or higher or Intel Celeron
400 MHz or higher
Windows 7:1 GB or more (32 bit)/2 GB or more (64 bit)
Windows Vista Home Basic: 512 MB or more
Windows Vista Home Premium/Business/Ultimate/Enterprise:
1 GB or more
Windows XP: 128 MB or more (256 MB or more recommended)
Interface USB port
Other Mouse or equivalent pointing device
requirements
The USB equipment operates with the driver installed as standard in the OS.
130
VQT3B18

Installation
When installing the software, log on to your computer as the Administrator or with a user
name with equivalent authorization. (if you do not have authorization to do this, consult your
manager.)
• Before starting the installation, close all applications that are running.
• Do not perform any other operations on your PC while the software is being installed.
• Explanation of operations and screens is based on Windows Vista.
A
el Insert the CD-ROM into the PC.
• The following screen is displayed automatically. Click [Run setup.exe] _ [Continue].
• If Windows 7 is in use, or the following screen is not displayed automatically, select [Start]
[Computer] (or double-click on [Computer] on the desktop), and then double-click
[Panasonic].
DVD RW D_ive (_:} Palla_(i c
, .................... [] '_t::::t'_.......
)
2
3Click [Next].
Read the [End User License Agreement], then place a check beside
[I accept the terms of the license agreement] if you agree to them
and click [Next].
4Select the country or region where you
live, then click [Next].
• If the country or region cannot be selected, select
[NTSC Area].
• When the confirmation message appears, click [Yes].
131
VQT3B18

5Select where the application is to be
installed, then click [Next].
6Select [Yes] or [No] to create shortcut.
•A message regarding the playback in the environment
used may be displayed depending on the performance
of the PC used. Click [OK] after confirming.
7 When installationis complete, some noteswill appear.
Check the contents, then close the window.
8Select [Yes, I want to restart my computer
now.], then click [Finish].
The PC must be rebooted for the
application to work.
•Uninstalling HD Writer AE 2.6T
Follow the steps below to uninstall any software applications that you no longer require.
1Select [Start] --_
[Control Panel] -->
[Uninstall a Program].
2Select [HD Writer AE 2.6T], then
click [Uninstall].
• Proceed with the uninstallation by following
the on-screen instructions.
• After uninstalling the software, be sure to
reboot the PC.
132
VQT3B18

Connecting to a PC
•Connect this unit to the PC after the software applications are installed.
• Remove the supplied CD-ROM from your PC.
O USB cable (supplied)
1Connect this unit to the AC adaptor.
• It is possible to use the unit connected to the PC with the batteries only, but you will not be
able to write data into the unit. Use the AC adaptor to free you from worrying about the
battery running down.
• Connect with the AC adaptor when using the Conversion Assist Function.
2Turn on the unit.
• This function is available in all modes.
3Connect this unit to a PC.
• The USB function selection screen will appear.
4Touch [PC] on the screen of this unit.
• The Smart wizard screen is automatically displayed when HD Writer AE 2.6T is installed.
• This unit is automatically recognized as an external drive of the PC. (-) 135)
• When you select an option other than [PC], reconnect the USB cable.
• When using the battery, the LCD monitor turns off after about 5 seconds. Touch the screen
to turn the LCD monitor on.
133
VQT3B18

• DonotuseanyotherUSBcablesexceptthesuppliedone.(Operationisnotguaranteed
withanyotherUSBcables.)
• Whenthe unit is connected to a PC, it cannot be turned off.
Disconnect the USB cable, before turning this unit off.
• Do not disconnect the USB cable or the AC adaptor while the access lamp is on or card
access icon ( _ ) appears on the unit screen.
• When performing reading/writing between a PC and an SD card, be aware that some SD
card slots built into PCs and some SD card readers are not compatible with the SDHC
Memory Card or SDXC Memory Card.
• When using an SDXC Memory Card, check the following support site.
http:flpanasonic.netlavclsdcardlinformationlSDXC.html
•To disconnect USB cable safely
1 Double click the _icon in task tray displayed on the PC.
• Depending on your PC's settings, this icon may not be displayed.
2Select [USB Mass Storage Device] and click [Stop].
3 Verify [MATSHITA HDC-SDT750/SD USB Device] is selected and click [OK].
134
VQT3B18

WhentheunitisconnectedtoaPC,itisrecognizedasanexternaldrive.
• Removabledisk(Example:_ CAMSD(G:))isdisplayedin[Computer].
WerecommendusingHDWriterAE2.6T
tocopyorwritebackmotionpicturedata.
UsingWindowsExplorerorother
programsonthePCtocopy,moveor
renamefilesandfoldersrecordedwith
thisunitwillresultinthembeingunusable
withHDWriterAE2.6T.
Example folder structure of an SD card:
_ CAM SD
100CDPFQ=======_
101CDPFR =======_
102CDPFS ======,_
c_
TE
HD
AVCH DTN===,4_
aDMV======,_
IISVPL======-_
The following data will be recorded.
O Up to 999 still pictures in JPEG
format ([S1000001 .JPG] etc.)
JPEG format still pictures recorded
in Hi-speed Burst Shooting Mode
_) JPEG format still pictures created
from the motion picture
O The DPOF setting files
_) The motion picture thumbnails
_) AVCHD format motion picture files
([00000.MTS] etc.)
OFiles for Intelligent Scene Selection
playback
• Copying your still pictures to
your PC
Card reader function (mass storage)
Still pictures recorded with this unit can be
copied to the PC with Explorer or other
programs.
1Double click the folder that contains
the still pictures, ([DCIM]
[100CDPFQ] etc.)
2 Drag and drop the still pictures onto
the destination folder (on the PC's
HDD).
• Do not delete the SD card's folders. Doing
so may make the SD card unusable in this
unit.
• When data not supported by this unit has
been recorded on a PC, it will not be
recognized by this unit.
• Always use this unit to format SD cards.
135
VQT3B18

Starting HD Writer AE 2.6T
•When using HD Writer AE 2.6T on Windows XP, log on to your computer as Administrator
(or with a Iogin name equally authorized). If you log on with a Iogin name other than
Administrator, you cannot use the applications.
• When using HD Writer AE 2.6T on Windows Vista/Windows 7, log on to your computer as
Administrator (or with a Iogin name equally authorized) or with the user name for a
standard user account. If you log on with a user name for a guest user account, the
software cannot be used.
(On the PC)
Select [Start] --_ [All Programs] --_ [Panasonic] --_ [HD Writer AE 2.6T] --_
[HD Writer AE].
• For details on how to use the software applications, read the PDF operating instructions of
the software.
• You will need Adobe Acrobat Reader 5.0 or later or Adobe Reader 7.0 or later to read the
PDF operating instructions.
Select [Start] --_ [All Programs] --_ [Panasonic] --_ [HD Writer AE 2.6T] --_
[Operating Instructions].
136
VQT3B18

If using Mac
• HD Writer AE 2.6T is not available for Mac.
• iMovie'09 supported. For details about iMovie'O9, please contact Apple Inc.
• 1080/60p scenes cannot be imported to a Mac.
• Since iMovie'09 is not compatible with 1080/60p, it cannot acquire the scenes recorded in
1080/60p. Record in normal recording mode when importing to Mac.
• Scenes recorded in 3D are not supported by iMovie'09.
•Operating environment
PC Mac
O$ Mac OS X 10.5.8
Mac OS X 10.6
CPU Intel Core Duo
Intel Core 2 Duo
RAM 1 GB or more
Interface USB port
Even if the system requirements mentioned in these operating instructions are fulfilled,
some PCs cannot be used.
• The USB equipment operates with the driver installed as standard in the OS.
• Supplied CD-ROM is available for Windows only.
•Copying still pictures on PC
1Connect this unit to a PC via the supplied USB cable.
• The USB function selection screen will appear.
2Touch [PC] on the screen of this unit.
• This unit is automatically recognized as an external drive of Mac.
• When you select an option other than [PC], reconnect the USB cable.
• When using the battery, the LCD monitor turns off after about 5 seconds. Touch the screen
to turn the LCD monitor on.
3Double-click [CAM_SD] displayed on the desktop.
• Files are stored in [100CDPFQ] or [101CDPFR] folder etc. in the [DCIM] folder.
4Using a drag-and-drop operation, move the pictures you want to
acquire or the folder storing those pictures to any different folder on
the PC.
•To disconnect USB cable safely
Drag [CAM_SD] disk icon to the [Trash], and then disconnect the USB cable.
• Do not remove the SD card from this unit when this unit is connected to the PC using a
USB cable.
137
VQT3B18

Indications
• Recording indications
Motion Picture Recording Mode
MF I_ R lh20rn [_ _ @:"
11100
OPENOdB _°/ot
_-_ ...........1,2:34PN
Still Picture Recording Mode
1/100 t.= • '=3
oP_ OdB _/01L.J
Remaining battery power
(-) 22)
Ih30m Remaining battery time
(-_ 22)
Rlh20m Remaining time for motion
picture recording (-) 32)
0h00m00s Elapsed recording time
(-) 32)
("h" is an abbreviation for hour, "m" for
minute and "s" for second.)
NOV 15 2010 Date indication (-) 29)
12:34PM Time indication (-) 29)
World time setting (_ 42)
Motion picture recording mode (-) 69)
i080i60p 1080/60p recording (-) 55)
(White) Card recording possible
status
(Green) Recognizing the card
Q/I I (Red) Recording
| | (Green) Recording pause
PRE-REC (-) 63)
[_ Interval Recording (-_ 70)
Manual Mode (-_ 86)
Intelligent Auto Mode (-_ 35)
_! /_ Operation icon is displayed/
not displayed. (-_ 62)
MF Manual Focus (-_ 89)
White Balance (-_ 87)
11100 Shutter Speed (-_ 88)
OPEN/F2.0 Iris value (-_ 88)
0dB Gain value (-_ 88)
Scene Mode (-_ 68)
1_2_,1_._111":_,11-_ _,
Power LCD (-_ 45)
Image Stabilizer (-) 52,61 )/Optical image
Stabilizer Lock (-) 53,61 )
/AF/AE tracking (-_ 54)
Zebra (-_ 80)
.:_:. Picture adjustment (-) 79)
Digital Cinema ('_ 71 )
Hi-Speed Burst Shooting
(-* 84)
Digital cinema color (-) 76)
138
VQT3B18
