ENGLISH Contents
Contents
Read this rst! E-1
Before using the camera E-5
Features E-6
Accessories E-6
Description of Parts E-7
Lamp display E-8
Adjusting the viewnder E-9
Attaching E-9
Left-right positioning adjustment E-10
Front-back positioning adjustment E-10
Visibility adjustment E-11
Screen adjustment E-11
Cleaning the eye cup E-12
Removing E-12
Attaching the microphone E-13
Cautions for storing E-13
Specications E-14
fVarious names, company names, product names, etc., described in this document are trademark or
registered trademark of the respective companies.
How to read this document
rIllustrations
fIllustrations of the camera, viewnder, etc., may vary from the actual items.
rConventions used in this manual
fWords and phrases in [ ] brackets indicate the content displayed in the viewnder.
fWords and phrases in < > brackets indicate design text used on this camera, such as button names.
rReference pages
fReference pages in this document are indicated by (page 00).

Before using the camera ENGLISH
E-5
Before using the camera
rSupported camera
This viewnder supports the following cameras.
fCamera recorder
AJ-PX5000, AJ-PX800, AJ-PX380, AJ-HPX3100, AG-HPX600, AG-HPX610
fSystem camera
AK-HC3800, AK-HC3500A, AK-UC3000, AK-HC5000
For details on other supported models, consult your dealer.
The initial setting of the viewnder output may be set to monochrome depending on the model.
For the method to switch the output to color video, refer to the Operating Instructions of each camera.
rUsing in low temperature environment
The hue may look shifted in the low temperature environment, but this is not a malfunction.
rBright spot and dark spot in the LCD screen
The LCD section is manufactured with high precision technology. The transmissive LCD panel with
effective pixel count of 99.99% or higher is used, but there may be black or white spots visible in the
screen. It may also generate newly after using the panel for a long time due to the characteristics of the
panel. These are not malfunction. Also, these spots are not recorded.
rColor at the contour of the image
It may look like there is a color at the contour of the image in the following cases when the viewnder is
used in color mode. This is not a malfunction.
fWhen the line of sight is moved rapidly within the viewnder
fWhen the image is moved rapidly

E-6
ENGLISH Features
Features
rThe viewnder supports the multi-format (1080i/720P).
rThe precise image is displayed in the high-resolution color LCD panel making it easy to
focus.
rBy using 1.5-inch RLCOS panel, it has realized fast response and high resolution
equivalent to CRT.
rThe display panel of this viewnder is approximately same size as the conventional
Panasonic monochrome HD viewnder. This viewnder can be used similarly as the
conventional Panasonic monochrome HD viewnder even if the eye point is moved from
the lens barrel.
rSwitching between color and monochrome is easily performed by using the <CHROMA>
switch.
Accessories
fEye cup (already attached to the viewnder)
fEye piece lter (already attached to the viewnder)
@@NOTE
tAfter unpacking the product, dispose of the packing material properly.

Description of Parts ENGLISH
E-7
Description of Parts
1 2 3 4
14
15
16
5 6 7
8 9 10 11 12 13
1 2
3
4 5
Lamp display
1 <PEAKING> (peaking) dial
Adjusts the contour of the video in the viewnder to make it easier to focus. This does not affect the
output signals from the camera.
2 <CHROMA> (color) dial
Adjusts the density of the color of the image displayed in the viewnder.
This does not affect the output signals from the camera.
@@NOTE
tThe color of the image may be pale right after turning on the camera at the low temperature.
3 <CONTRAST> (contrast) dial
Adjusts the contrast of the screen in the viewnder. This does not affect the output signals from the
camera.
4 <BRIGHT> (brightness) dial
Adjusts the brightness of the screen in the viewnder. This does not affect the output signals from the
camera.
5 <CHROMA> switch
Switches the image to display in the viewnder.
<ON>: Displays the color image.
<OFF>: Displays the monochrome image.

E-8
ENGLISH Description of Parts
6 <ZEBRA> (zebra pattern) switch
Displays the zebra pattern in the viewnder.
<ON>: Displays zebra patterns.
<OFF>: Does not display zebra patterns.
The display contents such as types of the zebra patterns differ depending on the connected camera.
For details, refer to the Operating Instructions of the camera.
7 <TALLY> switch
Controls the front tally lamp.
<HIGH>: Makes the front tally lamp brighter.
<OFF>: Turns out the front tally lamp.
<LOW>: Makes the front tally lamp darker.
8 Microphone holder
9 Front tally lamp
Operates and lights during shooting when the <TALLY> switch is set to <HIGH> or <LOW> position. It
also ashes and displays the warning in the same way as the REC lamp in the viewnder.
The brightness when it is lit can be switched by the <TALLY> switch (<HIGH> or <LOW>).
10 Viewnder stopper
Used for attaching and detaching the viewnder.
11 Connector plug
12 Slide rail
13 Eye cup
Do not leave the eye cup pointed directly to the sun. Doing so might damage the internal device.
14 Visibility adjusting ring
Adjusts so that the image on the viewnder screen appears the sharpest in accordance with the
visibility of the camera operator. For details on the eyepiece for presbyopia, consult your dealer.
15 Lock ring
16 Back tally lamp
Lights during the shooting. It also ashes and displays the warning in the same way as the REC lamp
in the viewnder. The back tally lamp is hidden when the lever is pushed towards the <OFF> side.
Lamp display
For details, refer to the Operating Instructions of the camera.
1 Green tally lamp
Lights in green when a green tally signal is received from the camera control unit.
2 TALLY/REC (recording) lamp
Lights in red when recording or a red tally signal is received from the camera control unit. Flashes in
red when an error has occurred.
3 (Irregular operation status warning) lamp
The lighting condition can be set with the [!LED] in the menu of the camera. This can be used to
prevent an erroneous operation.
4 BATT (battery) lamp
Flashes or lights up depending on the battery condition. The condition to ash or light differs depending
on the camera setting.
5 SAVE lamp
Flashes or lights up depending on the camera setting. The condition to ash or light differs depending
on the camera setting.
