PDM9
Housings:
Indoor Drop Ceiling Mount
PRODUCT FEATURES
• The model PDM9 is a discreet indoor surveillance
enclosure designed to mount into a standard
2' x 2' or 2' x 4' suspended ceiling, and can be
used alone or in conjunction with the entire
ceiling tile
• This unit completely encloses the unitized
camera, resulting in discreet viewing
• For indoor use
• Designed for the WV-CS954/WV-CS574/
WV-NS324 Series cameras
MECHANICAL SPECIFICATIONS
Size (HxWxD):
24" x 24" x 10" (610mm x 610mm x 254mm)
Weight: 13 lbs. (5.9 kg) without camera
Construction:
Metal Ceiling: Frame 18-gauge steel with an
off-white powder coat finish
Metal back box: 18- and 20-gauge steel,
w/black powder coat finish
Decorative Trim Ring: ABS Plastic, off-white
Electrical Input: (3) .875" knockouts
STANDARD ACCESSORIES
• 1 pc. PDM9 Instructions
• 4 pc. 8-32 Phillips head screws
• 4 pc. Star washers for mount camera
• 4 pc. 1" long aluminum standoffs
SHIPPING
PDM9: 16 lbs / 28" x 28" x 8"
(7.3 kg / 712mm x 712mm x 204mm)
DESCRIPTION
The PDM9 is an attractive, drop ceiling mount. The PDM9
is easy to install. Just remove the existing ceiling tile and
place the PDM9 in its place. The product works with the
WV-CS954/WV-CS574/WV-NS324 Series cameras.
Product specifications are subject to change without notice.
© Panasonic System Solutions Company. All rights reserved.
camera not included
PDM9
BID SPECIFICATIONS
The drop ceiling mount bracket shall be a
Panasonic Model PDM9 or equivalent. The
bracket shall be designed for a discreet
indoor surveillance enclosure, designed to
mount into a standard 2' x 2' or 2' x 4'
suspended ceiling. The bracket can be used
alone or in conjunction with the entire ceiling
tile. The bracket shall be designed for use
with Panasonic Unitized Surveillance Device
Series WV-CS954/WV-CS574/WV-NS324.
The bracket’s weight shall not exceed 15
lbs. (6.9 kg).
)185.4( 7.30"
)161.2( 6.34"
)8.6( .34"
)46( 1.81"
)83.5( 3.29"
)152.8( 6.02"
O)106.5( 4.19"
R
)603.2( 23.75"
)603.2( 23.75"
Panasonic System Solutions Company
Unit of Panasonic Corporation of North America
Security Systems
Executive Office: Three Panasonic Way, Secaucus, NJ 07094
Zone Offices:
Eastern: Three Panasonic Way, Secaucus, NJ 07094 (201) 392-4546
Southern: 1225 Northbrook Parkway, Suwanee, GA 30024 (770) 338-6843
Central: 1707 North Randall Road, Elgin, IL 60123 (847) 468-5211
Western: 6550 Katella Avenue, Cypress, CA 90630 (714) 373-7840
www.panasonic.com/security
DISTRIBUTED BY:
PDM9
