Panasonic CQ-VD6503U User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Current Consumption Less than 10A (During Disc Playback)
Maximum Power Output 50W×4ch
Compatible Speaker
Impedance 4Ω
Video Input Signal Composite Video Signal,
1.0 Vp-p (75Ω)
Audio Input Sensitivity 2 Vrms
Video Output Signal Composite Video Signal,
1.0 Vp-p (75Ω)
Pre-Amp Output Voltage 2 Vrms
Pre-Amp Output Impedance Less than 600Ω
FM Stereo Radio
Frequency Range 87.9 - 107.9MHz
Usable Sensitivity 12.2dBf
Stereo Separation 40dB (1kHz)
S/N Ratio 63dB
AM Radio
Frequency Range 530 - 1710kHz
Usable Sensitivity 25 dB/µV
Image Rejection Ratio 50 dB
Audio Section
Output voltage/Impedance 2 Vrms/600 Ω
Frequency Characteristics
(When “LARGE” is Selected)
Front L/R, Center,
Rear (Surround) L/R 20Hz - 20kHz (±1 dB)
© 2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-VD6503U
Dual DIN In-Dash 6.5” Widescreen
Color LCD Monitor/DVD Receiver
Delay Time
Dolby Digital
Center 0-5ms
Rear (Surround) L/R 0 -15 ms
Dolby Pro Logic
Rear (Surround) L/R 15-30 ms
Distortion
Front L/R 0.01% (1kHz,0dB,PCM Input)
Dynamic Range 96dB (During CD Playback)
S/N Ratio 100dB (During CD Playback)
Monitor
Storage temperature range -20°C -80°C (-4°F to -176°F)
Liquid Crystal Panel 6.5” wide
Screen Dimensions (W×H×D) 5-1/4” × 3-1/8” × 6-7/16”
(134 × 79 × 164mm)
Number of Pixels 280,880 pixels
(234 vertical × 400 horizontal × 3)
Valid Pixel Ratio Over 99.99%
Display Method Transparent color filter format
Drive Method TFT (Thin Film Transistor)
active matrix format
Light Source Internal light
(Built-in small fluorescent lamp)
Dimensions** (W × H × D) 7” × 3-15/16” × 6-1/2”
(178 × 100 × 165 mm)
Weight** 5lbs. 8oz. (2.5 kg)
AUTOMOTIVE AFTERMARKET
Specifications*
ORDER No.ACED060330C1
C7

* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
· Above specifications comply with EIA standards.
1 ABOUT LEAD FREE SOLDER (PbF) 3
2 FEATUERS 3
3 REPLACING THE FUSE 3
4 MAINTENANCE 3
5 LASER PRODUCTS 3
6 DIMENSIONS 3
7 WIRING CONNECTION 4
8 DISASSEMBLY INSTRUCTIONS 5
9 TERMINALS DESCRIPTION 7
10 PACKAGE AND IC BLOCK DIARAM 11
11 PACKING PARTS LIST 17
12 REPLACEMENT PARTS LIST 18
13 EXPLODED VIEW (Unit) 32
14 DVD PLAYER PARTS LIST 33
15 EXPLODED VIEW [DVD Deck] 37
16 WIRING DIAGRAM 38
17 SCHEMATIC DIAGRAM-1 48
18 SCHEMATIC DIAGRAM-2 51
19 BLOCK DIAGRAM 59
CONTENTS
Page Page
2
CQ-VD6503U

1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
· Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
· Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
· This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATUERS
· Simultanous Multi-Device Connection (with Expansion
Module (hub unit)
· Expansion Module (The optional Hub unit: CY-EM100U)
· Connectable devices
− − −
− The optional adapter allows you to connect the optional
Panasonic DVD changer unit (CX-DH801U).
− − −
− The optional adapter allows you to connect the optional
Panasonic CD changer unit (CX-DP880).
− − −
− TV Tuner (The optional Panasonic TV tuner unit: CY-
TUN153U).
− − −
− The optional adapter allows you to connect the optional
iPod®series.
<Controllable iPod/software version>
3rd generation iPod/ver.2.3
4rd generation iPod/ver.3.1
iPod Photo/ver. 1.2
iPod mini/ver. 1.4
iPod nano/ver. 1.0
− − −
− XM Satellite Radio. (The optional XM receiver: XMD-
1000)
− − −
− Sirius Satellite Radio. (The optional Sirius Satellite
receiver: SIR-PAN1)
− − −
− Hands-Free Phone System (The optional Bluetooth
hands-free kit: CY-BT100U).
· Integration of the monitor, FM/AM radio, DVD Video, Video
CD player and CD/MP3/WMA player
· Built-in AV Input/Output Terminals.
· Built-in Dolby Digital decoder, DTS decoder.
· Built-in DSP.
· GUI (Graphic User Interface).
· CS Auto (Circle Surround Automotive).
· Touch Panel Operation.
· DVD-R, DVD-RW, Playback.
· ID code.
3 REPLACING THE FUSE
Use fuses of the same specified rating (15A). Using different
substitutes or fuses with higher ratings, or connecting the unit
directly without a fuse, could cause fire or damage to this unit.
4 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvent.
5 LASER PRODUCTS
6 DIMENSIONS
3
CQ-VD6503U

7 WIRING CONNECTION
4
CQ-VD6503U

8 DISASSEMBLY INSTRUCTIONS
8.1. How to Remove the Flexible PCB(AP1)
5
CQ-VD6503U

8.2. How to Disassemble & assemble
6
CQ-VD6503U

9.1. Main Block
IC601 : C2DBLK000114
Pin
No. Port Description I/O Vol (V)
1 AVREF0 Reference voltage for A/D
converter - 3.2
2 AVSS Ground for A/D converter - 0
3 ANT CNT Antenna control O 3.2
4 RCA SW Voice change of DVD-CH and
HUB. H: HUB L:VTR2 O 0
5 AVREF1 Reference voltage for A/D
converter - 3.2
6 Touch RESET Touch Panel reset O 3.2
7 HUB CNT HUB control. L: HUB CPU
Communication O 3.2
8 IC/FLMD0 Flash memory update control - 0
9 VDD +3V power supply - 3.2
10 REGC Bypass capacitor terminal for
voltage reg. - 2.5
11 VSS Ground - 0
12 X1 Crystal osillator terminal I 1.1
13 X2 Crystal osillator terminal - 1.2
14 /RESET System reset I 3.2
15 XT1 (Connecting to ground) - 0
16 XT2 No Connection - -
17 EVENT EVENT input (for HUB) I 0
18 CH STB/XM
DET2 Changer data strobe I 5.0
19 RDS DATA RDS data I 3.3
20 RDS CLK RDS clock I 0
21 MAIN CNT Main_Control (for HUB) O 5.0
22 OSD CS OSD chip select O 1.0
23 OSD DO OSD control data O 0.6
24 OSD CLK OSD data shift clock O 2.2
25 XM TX(MO) XM data O 5.0
26 CH DATA/XM
RX Changer data I 0
27 CH CLK/XM
DET1 Changer clock / XM detection signal I 3.1
28 REMO DATA Ext. remote control signal I 5.0
29 CHC REM
OUT Changer remote control code O 5.1
30 I2C CLK I2C bus clock O 5.1
31 I2C DATA I2C bus data O 5.1
32 OSD RESET OSD reset O 3.2
33 EVSS Ground for ext. unit - 0
34 EVDD +3V power supply for ext. unit - 3.2
35 DVD TX(MO) DVD deck TX data O 3.2
36 DVD RX(MI) DVD deck RX data I 3.2
37 BEEP Beep signal O 0
38 AMP CNT Ext. AMP control O 3.2
39 AMP STB Ext. AMP stand-by O 5.0
40 TFT SI(MI) TFT unit communication data I 0
41 TFT SO(MO) TFT unit communication data O 0.5
42 TFT CLK TFT unit communication clock O 5.0
43 AMP MUTE Internal power AMP mute O 0
44 SYS ON System power (5V) control for SW
PCB O 0
45 NAVI REMO
OUT NAVI remote control data O 0
46 ENTER ENTER key I 3.3
47 FRONT MUTE Audio signal (BEEP NAVI) mute O 5.0
48 VD COUNT Vertical drive signal count I 5.0
49 REAR MUTE Video out mute O 5.0
50 SYSID1 Connected equipment recognition
(for HUB) I 5.0
Pin
No. Port Description I/O Vol (V)
51 SYSID2 Connected equipment recognition
(for HUB) I 5.0
52 SYS MUTE
(F) System mute (FRONT) O 5.0
53 SYS MUTE
(S) System mute (SURROUND) O 5.0
54 SYS MUTE
(C) System mute (CENTER) O 5.0
55 SYS
MUTE(SW) System mute (SW) O 5.0
56 BATT SENS Battery level detection I 5.0
57 ACC SENS ACC level detection I 5.0
58 PULSE Monitor position detection pulse I 5.0
59 SYS PWR System power control O 5.0
60 MAIN PWR Main power control O 3.2
61 MONI PWR Monitor power control O 3.2
62 NAVI RM CH NAVI remote control output
change O 0
63 SEC LED LED blinking function for
CodeSecurity emphasis O 3.2
64 EJECT LED
(NC) No Connection - -
65 NAVI LED NAVI LED on/off O 0
66 MA Drive mechanism control signal O 3.2
67 MB Drive mechanism control signal O 3.2
68 MC Drive mechanism control signal O 3.2
69 BVSS Ground for bus I/F - 0
70 BVDD Power supply for bus I/F - 3.2
71 FAN CNT Fan motor power control O 3.2
72 ROTARY.1 Rotary encoder signal (VOL
DOWN) I 0
73 ROTARY.2 Rotary encoder signal (VOL UP) I 3.3
74 INIT DET 2 Destination detection I 0
75 RADIO CNT Radio power control O 3.2
76 DVD MUTE DVD mute request / Flash
memory update cnt. I 3.3
77 DSP SCK Shift clock for DSP communication
data O 2.8
78 DSP SDA DSP communication data O 3.1
79 DSP RESET DSP reset O 3.2
80 DVD CNT DVD deck power control O 3.2
81 DVD RESET Reset signal for DVD deck control
MPU O 3.2
82 FRAM HOLD F-RAM hold O 0
83 FRAM CLK Shift clock for F-RAM data O 0
84 FRAM DO F-RAM serial data O 0
85 FRAM CS F-RAM chip select O 3.2
86 FRAM WP F-RAM write protect O 0
87 SW PWR Switching power supply frequency
change O 0
88 MODE MODE key detection I 3.2
89 JOY A/D ADC input terminal for joy stic
signal I 3.3
90 NAVI DISP NAVI display activity detection I 3.3
91 NAVI SENS NAVI system connection detection I 3.3
92 SIDE BRAKE Side break detection I 3.3
93 INIT DET Destination detection I 0
94 POSI SENS ADC input terminal for monitor
position signal I 2.4
95 NAVI MUTE NAVI mute I 0
96 OFFSET DET Power IC abnormality detection I 0
97 AD KEY ADC input terminal for AD key
signal I 3.3
98 REVERSE REVERSE signal detection I 3.3
99 FRAM DI F-RAM serial data I 0
100 V_NAVI NAVI RGB signal change O 0
9 TERMINALS DESCRIPTION
7
CQ-VD6503U

IC401 : C2BBYY000199
Pin
No. Port Description I/O Vol (V)
1 MONI CNT TFT monitor power supply
control output O 4.9
2 BL CNT Backlight control output O 4.9
3 TILT LED
(NC) TILT button LED control - -
4 ASPECT LED
(NC) LED control of ASPECT button - -
5 EJECT LED EJECT_LED control O -
6 NAVI LED NAVI LED control O -
7 SRC LED SOURCE button LED control O -
8 NC NC(GND connection) I 0
9 SELF WRITE Self writing switch output O 0
10 TFT RESET System reset input - 5.0
11 NC NC(GND connection) I 0
12 NC NC(GND connection) I 0
13 IC/ Vpp Internal connection and flash
memory programming mode
drawing in
- 0
14 X2 Crystal oscillator clock I 2.7
15 X1 Crystal oscillator clock I 2.4
16 REGC Regulator output stability
capacity connection - 2.5
17 VSS Grand potential for in - 0
18 EVSS Grand potential for external - 0
19 VDD Positive power supply for in - 4.9
20 EVDD Positive power supply for
external - 4.9
21 SCL I2C bus clock output for DAC O 4.9
22 SDA I2C bus data output for DAC O 4.9
23 NC NC(OPEN) - -
24 NC NC(OPEN) - -
25 NC NC(OPEN) - -
26 NC NC(OPEN) - -
27 NC NC(OPEN) - -
28 NC NC(OPEN) - -
29 NC NC(OPEN) - -
30 NC NC(OPEN) - -
31 NC NC(OPEN) - -
32 NC NC(OPEN) - -
33 NC NC(OPEN) - -
34 NC NC(OPEN) - -
35 NC NC(OPEN) - -
36 NC NC(OPEN) - -
37 NC NC(OPEN) - -
38 HD IN HD signal input I 4.4
39 VD IN PAL N/PALM judgment VD
signal input I 4.7
40 NC NC(OPEN) - -
41 NC NC(OPEN) - -
42 NC NC(OPEN) - -
43 NC NC(OPEN) - -
44 NC NC(OPEN) - -
45 OSD CSEL
(NC) NC(OPEN) - -
46 X- Transistor SW output for touch
panel side X ( - pole) O 0
47 Y- Transistor SW output for touch
panel side Y ( - pole) O 0
48 X+ Transistor SW output for touch
panel side X ( + pole) O 4.9
49 Y+ Transistor SW output for touch
panel side Y ( + pole) O 4.9
50 RX For Flash rewriting I 0.5
51 TX For Flash rewriting O 0
52 IP SO IP Serial data output O 0
53 IP SI IP Serial data input I 0
Pin
No. Port Description I/O Vol (V)
54 IP SCK IP Serial clock output O 0
55 IP STR IP STR control O 0
56 IP RESET IP RESET output O 0
57 NC NC(OPEN) - -
58 NC NC(OPEN) - -
59 AVREF Reference voltage input 0 of
A/D converter - 4.9
60 AVSS A/D converter grand potential - 0
61 XG Touch panel side X with respect
to - pole I 0
62 YG Touch panel side Y with respect
to - pole I 1.2
63 XR Touch panel side X with respect
to + pole I 0
64 YR Touch panel side Y with respect
to - pole I 1.2
65 LIGHT SENS DIMMER input I 3.9
66 A/D KEY A/D key input for TILT and
OPEN/CLOSE I 4.9
67 A/D KEY GND connection I 0
68 A/D KEY GND connection I 4.9
69 NC NC(OPEN) - -
70 TFT CLK Serial communications clock for
the main CPU I 4.9
71 TFT SO/ TFT
COM Serial communications data input for the main CPU I 0.6
72 TFT SI/ TFT
DATA Serial communications data output for the main CPU O 0.4
73 Touch SW Switch output for touch panel
SW detection O 4.1
74 NC NC(OPEN) - -
75 NC NC(OPEN) - -
76 NC NC(OPEN) - -
77 NC NC(OPEN) - -
78 NC NC(OPEN) - -
79 NC NC(OPEN) - -
80 BUS KILL For connected confirmation of
self adjustment treatment
device
I 0
9.2. TFT Block
8
CQ-VD6503U

IC501 C1AB00002402
Pin No. Port Descriptions I/O Vol
(V)
1 VDDIO I/O pad power (3.3V) - 3.3
2 MD10 SDRAM data bus I/O 0
3 MD11 SDRAM data bus I/O 0.6
4 VDD Core power (1.8V) - 1.8
5 MD12 SDRAM data bus I/O 0
6 VSSIO I/O pad ground - 0
7 MD13 SDRAM data bus I/O 0.7
8 MD14 SDRAM data bus I/O 0.5
9 MD15 SDRAM data bus I/O 0
10 VDDIO I/O pad power (3.3V) - 3.3
11 /DQM1 SDRAM data byte enable O 0
12 MA9 SDRAM address bus O 0
13 MA8 SDRAM address bus O 0
14 VSSIO I/O pad ground - 0
15 MA7 SDRAM address bus O 2.3
16 MA6 SDRAM address bus O 1.9
17 VSS Core ground - 0
18 MA5 SDRAM address bus O 1.1
19 VDDIO I/O pad power (3.3V) - 3.3
20 MA4 SDRAM address bus O 2.0
21 MA3 SDRAM address bus O 2.3
22 MCLK SDRAM clock O 1.7
23 VSSIO I/O pad ground - 0
24 CKE SDRAM clock enable O 3.3
25 MA2 SDRAM address bus O 2.3
26 MA1 SDRAM address bus O 1.0
27 VDDIO I/O pad power (3.3V) - 3.3
28 MA0 SDRAM address bus O 1.0
29 MA10 SDRAM address bus O 0
30 MA11 Not used - -
31 VSSIO I/O pad ground - 0
32 MA12 SDRAM address bus O 2.1
33 MA13 SDRAM address bus O 2.1
34 VDD Core power (1.8V) - 1.8
35 /CS0 SDRAM primary bank chip select O 2.7
36 VDDIO I/O pad power (3.3V) - 3.3
37 /RAS SDRAM command bit O 3.1
38 /CAS SDRAM command bit O 2.9
39 /WE SDRAM command bit O 3.2
40 VSSIO I/O pad ground - 0
41 /DQM0 SDRAM data byte enable O 0
42 /DQM2 SDRAM data byte enable O 0
43 MD16 SDRAM data bus I/O 0.5
44 VDDIO I/O pad power (3.3V) - 3.3
45 MD17 SDRAM data bus I/O 0.5
46 MD18 SDRAM data bus I/O 0.5
47 VSS Core ground - 0
48 MD19 SDRAM data bus I/O 0.7
49 VSSIO I/O pad ground - 0
50 MD20 SDRAM data bus I/O 0
51 MD21 SDRAM data bus I/O 1.5
52 MD22 SDRAM data bus I/O 1.0
53 VDDIO I/O pad power (3.3V) - 3.3
54 MD23 SDRAM data bus I/O 0
55 MD24 SDRAM data bus I/O 0.5
56 MD25 SDRAM data bus I/O 0.5
57 VSSIO I/O pad ground - 0
58 MD26 SDRAM data bus I/O 0.5
59 MD27 SDRAM data bus I/O 0.8
60 MD28 SDRAM data bus I/O 0
61 MD29 SDRAM data bus I/O 1.0
62 VDDIO I/O pad power (3.3V) - 3.3
63 MD30 SDRAM data bus I/O 0.7
64 MD31 SDRAM data bus I/O 0.5
65 /DQM3 SDRAM data byte enable O 0
66 /CS1 Not used O -
67 VSSIO I/O pad ground - 0
68 SPDIF S/PDIF digital audio output O 1.3
69 VSS Core ground - 0
Pin No. Port Descriptions I/O Vol
(V)
70 AIN Digital audio input for digital micro I 3.3
71 AOUT3 Serial audio data (Left/Right CH) O 0
72 AOUT2 Serial audio data (Center/LFE CH) O 0
73 AOUT1 Serial audio data (Sound Left/Right CH) O 0
74 AOUT0 Serial audio data (Left/Right CH) O 0
75 VDDIO I/O pad power (3.3V) - 3.3
76 PCMCLK Audio DAC PCM sampling clock O 1.8
77 VDD Core power (1.8V) - 1.8
78 ACLK Audio interface serial data clock O 1.7
79 LRCLK Left/Right channel clock O 1.7
80 /SRST Reset signal O 3.3
81 /RSTP Power on reset I 3.3
82 VSSIO I/O pad ground - 0
83 RXD1 Not used - -
84 SSPIN1 SSP1 data in / UART1 16X clock I/O 15
85 VSS Core ground - 0
86 SSPOUT1 SSP1 sata out / UART1 DTR I/O 0
87 SSPCLK1 SSP1 clock / UART1 CTS I/O 3.3
88 SSPCLK0 Not used - -
89 VDD Core power (1.8V) - 1.8
90 SSIN0 Not used - -
91 VDDIO I/O pad power (3.3V) - 3.3
92 SSPOUT0 Not used - -
93 TXD0 UART0 serial data O 3.2
94 RXD0 UART0 serial data I 3.0
95 /CTS0 Not used - -
96 /RTS0 Not used - -
97 VSSIO I/O pad ground - 0
98 CXI Crystal Oscillator terminal I 1.6
99 CXO Not used - -
100 OSCVSS Oscillator ground - 0
101 OSCVDD Oscillator power (1.8V) - 1.8
102 MVCLVDD Main/Video clock PLL power (3.3V) - 3.3
103 SCEN Not used - -
104 MVCKVSS Main/Video clock PLL Ground - 0
105 ACLKVSS Audio clock PLL ground - 0
106 SCMD Not used - -
107 ACLKVDD Audio clock PLL power - 3.3
108 VDDDAC DAC digital power (1.8V) - 1.8
109 VSSDAC DAC digital ground - 0
110 CVBS2/CR/R Composite Cr/Component Cr/SCART
Red O 0.5
111 IOM Cascaded DAC differential output O 1.0
112 C/CB/B Chrominance/Component Cb/SCART Cb O 0.7
113 VAA3 DAC analog power (3.3V) - 3.3
114 Y/G Luminance/SCART G O 0.4
115 VSSA DAC analog ground - 0
116 VREF Not used - -
117 VAA - - 1.8
118 CVBS/C Composite/S-Video Chrominance O 0.5
119 RSET Current setting resistor connection O 1.4
120 COMP Compensation capacitor connection O 2.0
121 VSS Core ground - 0
122 VCLK Not used - -
123 VSYNC Not used - -
124 HSYNC Not used - -
125 VDDIO I/O pad power (3.3V) - 3.4
126-131 VI07-02 Not used - -
132 VSSIO I/O pad ground - 0
133 Not used - -
134 Not used - -
135 VDD Core power (1.8V) - 1.9
136-139 AD31-28 Not used - -
140 VDDIO I/O pad power (3.3V) - 3.4
141-144 AD27-24 Not used - -
145 /PWE3 Not used - -
146 AD23 Not used - -
147 VSSIO I/O pad ground - 0
148-150 AD22-20 Not used - -
151-153 AD19-17 Address/Data bus I/O 0
154 VDDIO I/O pad power (3.3V) - 3.4
9.3. DVD Servo Block
9
CQ-VD6503U

Pin No. Port Descriptions I/O Vol
(V)
155 AD16 Address/Data bus I/O 0
156 /PWE2 Not used - -
157,
158 AD15, 14 Address/Data bus I/O 0
159 VDD Core power (1.8V) - 1.9
160 SCLK External bus clock O 2.1
161 ACK Programmable WAIT/ACK/RDY control I 3.4
162 VSSIO I/O pad ground - 0
163-168 AD13-08 Address/Data bus I/O 0
169 VDDIO I/O pad power (3.3V) - 3.4
170 /PWE1 Not used - -
171 VSS Core ground - 0
172-176 AD7-3 Address/Data bus I/O 0
177 VSSIO I/O pad ground - 0
178-180 AD02-00 Address/Data bus I/O 0
181 VDDIO I/O pad power (3.3V) - 3.4
182 /PWE0 Byte write enable O 0
183 ALE Address latch enable O 0
184-187 LA0-3 Latch address O 3.3
188 VSSIO I/O pad ground - 0
189 RD Read signal O 3.4
190 LHLDA Not used - -
191 LHLD Not used - -
192 VDD Core power (1.8V) - 1.9
193 /PCS0 Peripheral chip select 0 O 3.4
194 XI01 Not used - -
195 DACCS2 DAC output select 2 O 3.4
196 VDDIO I/O pad power (3.3V) - 3.4
197 DACCS1 DAC output select 1 O 3.4
198 NINTCPPM Not used - -
199 CPPMCS Not used - -
200 XI06 Not used - -
201 VSS Core ground - 0
202 FRAMCS FRAM chip selection O 0
203 DACRST DAC reset O 0
204 VSSIO I/O pad ground - 0
205 FEPCS Front End Pro. LSI chip select O 3.4
206 FEPRST Front End Pro. reset O 3.4
207 SODCCS SODC LSI chip selection O 3.4
208 NINTHOST HOST interrupt I 3.4
209 NINTDDC DDC interrupt I 3.2
210 VDDIO I/O pad power (3.3V) - 3.4
211 NINTDSC DSC interrupt I 3.5
212 VDD Core power (1.8V) - 1.9
213 DSYNV DVD parallel mode sector SYNC I 3.4
214 DREQ DVD parallel mode data request O 3.4
215 DCLK Data sampling clock I 3.4
216 DSTB Parallel mode data valid/Serial mode
clock I 0.7
217 DVD0 DVD drive parallel data port I 0
218 VSSIO I/O pad ground - 0
219 DVD1 DVD drive parallel data port I 0
220 DVD2 DVD drive parallel data port I 0
221 DVD3 DVD drive parallel data port I 3.4
222 DVD4 DVD drive parallel data port I 0.8
223 DVD5 DVD drive parallel data port I 0.8
224 VDDIO I/O pad power (3.3V) - 3.4
225 DVD6 DVD drive parallel data port I 3.4
226 DVD7 DVD drive parallel data port I 3.4
227 MD0 SDRAM data bus I/O 0.5
228 VSSIO I/O pad ground - 0
229 MD1 SDRAM data bus I/O 0
230 VSS Core ground - 0
231 MD2 SDRAM data bus I/O 0.8
232 MD3 SDRAM data bus I/O 0.8
233 VDDIO I/O pad power (3.3V) - 3.3
234 MD4 SDRAM data bus I/O 3.3
235 MD5 SDRAM data bus I/O 0
236 MD6 SDRAM data bus I/O 0.8
237 VSSIO I/O pad ground - 0
238 MD7 SDRAM data bus I/O 0
239 MD8 SDRAM data bus I/O 0
240 MD9 SDRAM data bus I/O 0
10
CQ-VD6503U

10.1. Main Block
IC151 : C0JBAA000115
IC200 : C1ZAZ0001450
IC610 :
C0JBAZ001166
IC203, IC301, IC302 : C0ABBB000105
IC608 : C0JBAB000255
IC611 : C0JBAZ000525
10 PACKAGE AND IC BLOCK DIARAM
IC303 : C0ZBZ0000770
11
CQ-VD6503U

IC612 : C0FBBD000065
IC754 : C0DBAMG00015
12
CQ-VD6503U

IC602 : C3GBCY000001
IC710 : C0CBCYG00004
IC711 : C0GBG0000032
IC751 : AN8065S-E1V
10.2. Sub Block
IC101 : C0ABBB000090
IC102 : C0JBAA000102
IC252 : C0ABBB000105
IC253 : C0JBAS000081
IC351 : C1AB00001604
13
CQ-VD6503U

IC752, IC753, IC755 : C0DBEKG00001
IC1 : B3MBZ0000006
IC402 : C0FBBD000065
IC501 : C0DBAZA00017
IC352 : C1AB00000164
IC403,405-408 : C0JBAA000115
IC502 : C0DBAZC00010
IC503 : C0CBAAF00009
IC504 : C0DBEKG00001
10.3. TFT/SW-R/SW-L Block
14
CQ-VD6503U

IC805 : C1AB00001604
IC101 : AN8703FH-V
IC806 : C1ABBB000069
IC311 : C0GBY0000012
IC271 : C0JBAA000372
10.4. DVD Deck Block
15
CQ-VD6503U

IC275, IC561 : C0JBAZ001014
IC321 : C0GBH0000006
IC411 : C0CBADC00084
IC441 : MN13821JP
IC631, IC641 : C0JBAH000082
IC651 : C3GBCA000001
IC652 : C0JBAB000255
16
CQ-VD6503U

11 PACKING PARTS LIST
· Item numbers listed below should not order regular spare parts. (not available)
Item
No. Part No. Part Name & Description Q’ty Remarks
1 - Inner Carton 1 Not available
2 - Packing Pad (Left) 1 Not available
3 - Packing Pad (Right) 1 Not available
4 - Packing Pad (A) 1 Not available
5 - Packing Pad (B) 1 Not available
6 EUR7641060 Remote Control Unit (includes a battery) 1
CR2025/1F Lithium Battery (CR2025) 1
7 YEFX9991793 Wiping Cloth 1
8 - Operating Instructions (1) Not available
- System Upgrade Guidebook (1) Not available
- Installation Instructions (1) Not available
9 YFC054C088ZA Trim Plate 1
10 YFX214C437ZA Mounting Collar 1
11 YFX994C134ZA Lock Cancel Plate 1
12 ZZBISVD7001A Bis kit (Mounting Bolt, Tapping Screw, Hex. Nut) 1
13 YEFG044C002 Rear Support Strap 1
14 ZZBISVD6503 Screw kit (Round Head Screw, Flat-Head Screw) 1
15 YEAJ012890 Power Connector, Reverse Extension Cord, Clip Connector 1
17
CQ-VD6503U

12 REPLACEMENT PARTS
LIST
Notes :
1.Be sure to make your orders of replacement parts
according to this list.
2.Important safety notice: Components, identified by mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3.Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4.The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
· Order intake period is basically six months after the first
shipment.
5.“T” marks in remarks colum are indicated supply parts of
PTW.
6.Reference materials of parts with the “TSN“ mark in the
remarks column are uploaded in the TSN (Technical
Service Navigation) system website. Please download from
that website for references.
Ref. No. Part No. Part Name & Description Remarks
[E-9788A] Main/IF Block
IC´s AND TRANSISTORs
IC151 C0JBAA000115 IC T
IC200 C1ZAZ0001450 IC T
IC201 C0ABCB000051 IC T
IC202 C0ABCB000051 IC T
IC203 C0ABBB000105 IC T
IC301 C0ABBB000105 IC T
IC302 C0ABBB000105 IC T
IC303 C0ZBZ0000770 IC T
IC601 C2DBLK000114 IC T
IC602 C3GBCY000001 IC T
IC608 C0JBAB000255 IC T
IC610 C0JBAZ001166 IC T
IC611 C0JBAZ000525 IC T
IC612 C0FBBD000065 IC T
IC710 C0CBCYG00004 IC T
IC711 C0GBG0000032 IC T
IC751 AN8065S-E1V IC T
IC754 C0DBAMG00015 IC T
IC756 C0CBABC00160 IC T
Q151 B1GBCFJN0009 Transistor T
Q152 B1GBCFJN0009 Transistor T
Q153 B1GBNCBC0001 Transistor T
Q154 B1BDEL000001 Transistor T
Q155 B1GBCFJN0009 Transistor T
Q201 XN0F26100L Transistor T
Q202 B1GBHBEA0003 Transistor T
Q203 XN0F26100L Transistor T
Q204 B1GBHBEA0003 Transistor T
Q205 B1GBHBEA0003 Transistor T
Q206 B1GBHBEA0003 Transistor T
Q281 B1GDCFJJ0008 Transistor T
Q282 B1GDCFLL0012 Transistor T
Q283 B1GDCFJJ0008 Transistor T
Q284 B1GDCFLL0012 Transistor T
Q285 B1GDCFJJ0008 Transistor T
Ref. No. Part No. Part Name & Description Remarks
Q286 B1GDCFLL0012 Transistor T
Q287 B1GDCFJJ0008 Transistor T
Q288 B1GDCFLL0012 Transistor T
Q289 B1GDCFLL0012 Transistor T
Q290 B1GDCFJJ0008 Transistor T
Q291 B1GDCFLL0012 Transistor T
Q292 B1GDCFJJ0008 Transistor T
Q293 B1GDCFJJ0008 Transistor T
Q301 XN0F26100L Transistor T
Q302 B1GBHBEA0003 Transistor T
Q303 XN0F26100L Transistor T
Q304 B1GBHBEA0003 Transistor T
Q305 B1GBHBEA0003 Transistor T
Q306 B1GBHBEA0003 Transistor T
Q601 B1GBHBJJ0001 Transistor T
Q602 B1GBHBJJ0001 Transistor T
Q603 B1GBHBJJ0001 Transistor T
Q604 B1GBCFNN0009 Transistor T
Q605 B1GBCFNN0009 Transistor T
Q606 B1GBCFJN0009 Transistor T
Q607 B1GBCFJN0009 Transistor T
Q608 XN0438100L Transistor T
Q611 B1GBNCEJ0001 Transistor T
Q617 B1GBCFJN0009 Transistor T
Q618 B1GBCFJN0009 Transistor T
Q619 B1GBCFJN0009 Transistor T
Q620 B1GBCFNN0009 Transistor T
Q621 B1GBCFJN0009 Transistor T
Q622 B1GBCFJN0009 Transistor T
Q623 B1GBCFJN0009 Transistor T
Q624 B1GBCFJN0009 Transistor T
Q625 B1GDCFNN0007 Transistor T
Q626 B1GDCFNN0007 Transistor T
Q702 XN0438100L Transistor T
Q703 B1GBNCEJ0001 Transistor T
Q704 B1GBNCEJ0001 Transistor T
Q711 B1GBNCEJ0001 Transistor T
Q751 B1BBCG000002 Transistor T
Q753 B1GBCFJN0009 Transistor T
Q754 B1GDCFJJ0008 Transistor T
Q755 B1GBCFJN0009 Transistor T
Q756 B1DFFD000013 Transistor T
Q757 B1DFFD000013 Transistor T
Q759 B1DFFD000013 Transistor T
Q760 B1GBCFJN0009 Transistor T
DIODEs
D151 B0JCRC000002 Diode T
D201 B0ADCJ000025 Diode T
D202 B0ACCK000005 Diode T
D203 B0ADCJ000025 Diode T
D204 MA2Q73600L Diode T
D205 MA2Q73600L Diode T
D206 MA2Q73600L Diode T
D207 MA2Q73600L Diode T
D301 B0ADCJ000025 Diode T
D302 B0ACCK000005 Diode T
D303 B0ADCJ000025 Diode T
D304 MA2Q73600L Diode T
D305 MA2Q73600L Diode T
D306 MA2Q73600L Diode T
D307 MA2Q73600L Diode T
D601 B0ADCJ000025 Diode T
D603 B0BC5R600010 Zener Diode T
D604 B0BC4R300003 Zener Diode T
D605 YEADRD22MBT1 Zener Diode T
D606 B0ACCK000005 Diode T
D607 B0ACCK000005 Diode T
D608 B0BC5R000009 Zener Diode T
D609 MA2J72900L Diode T
D610 YEADRD22MBT1 Zener Diode T
D701 B0BA04700003 Diode T
D702 B0ECKL000001 Diode T
18
CQ-VD6503U

Ref. No. Part No. Part Name & Description Remarks
D703 B0BC5R600010 Zener Diode T
D753 B0ECKL000001 Diode T
D755 B0ACCK000005 Diode T
D759 B0BC5R600004 Diode T
D764 B0JCRC000002 Diode T
D765 MA2J72900L Diode T
D766 MA2J72900L Diode T
D767 MA2J72900L Diode T
D769 B0JCQD000002 Diode T
D770 B0JCQD000002 Diode T
D771 B0JCQD000002 Diode T
D772 MA2J72900L Diode T
CAPACITORs
C151 F1K1C225A069 Chip, 2.2µF 16WV T
C152 EEUFC1C471LB Electrolytic, 470PF 16WV T
C153 F1K1C225A069 Chip, 2.2µF 16WV T
C154 1HEC-BS2R2M Electrolytic, 2.2µF 50WV T
C155 F2A1C222A715 Electrolytic, 2200PF 16WV T
C156 F1H1C104A107 Chip, 0.1µF 16WV T
C160 1EEC-FS220M Electrolytic, 22µF 25WV T
C207 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
C208 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
C209 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
C210 F1H1H560A841 Chip, 56PF 50WV T
C211 F1H1H560A841 Chip, 56PF 50WV T
C212 F1H1H560A841 Chip, 56PF 50WV T
C213 1CEC-BS470M Electrolytic, 47µF 16WV T
C214 F1J1C104A148 Chip, 0.1µF 16WV T
C215 1CEC-BS100M Electrolytic, 10µF 16WV T
C216 1CEC-BS100M Electrolytic, 10µF 16WV T
C217 1CEC-BS100M Electrolytic, 10µF 16WV T
C218 F1H1H221A841 Chip, 220PF 50WV T
C219 F1H1H221A841 Chip, 220PF 50WV T
C220 F1H1H221A841 Chip, 220PF 50WV T
C221 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
C222 F1H1H560A841 Chip, 56PF 50WV T
C223 F1H1H560A841 Chip, 56PF 50WV T
C224 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
C225 F1H1H560A841 Chip, 56PF 50WV T
C226 1CEC-BS470M Electrolytic, 47µF 16WV T
C227 F1J1C104A148 Chip, 0.1µF 16WV T
C228 F1K1C1060001 Ceramic, 10µF 16WV T
C229 F1K1C1060001 Ceramic, 10µF 16WV T
C230 ECPU1C105MA5 Film, 1µF 16WV T
C231 ECPU1C105MA5 Film, 1µF 16WV T
C232 F1H1H122A219 Ceramic, 1200PF 50WV T
C233 F1H1H122A219 Ceramic, 1200PF 50WV T
C234 1CEC-BS101M Electrolytic, 100µF 16WV T
C235 1CEC-BS100M Electrolytic, 10µF 16WV T
C236 F1H1C104A107 Chip, 0.1µF 16WV T
C237 1CEC-BS470M Electrolytic, 47µF 16WV T
C238 F1J1C104A148 Chip, 0.1µF 16WV T
C239 F1J1C105A173 Chip, 1µF 16WV T
C240 F1H1H101A737 Chip, 100PF 50WV T
C241 F1J1C105A173 Chip, 1µF 16WV T
C242 F1J1C105A173 Chip, 1µF 16WV T
C243 F1H1H101A737 Chip, 100PF 50WV T
C244 1CEC-BS100M Electrolytic, 10µF 16WV T
C245 F1J1H681A732 Chip, 680PF 50WV T
C246 F1J1H681A732 Chip, 680PF 50WV T
C247 F1J1H681A732 Chip, 680PF 50WV T
C248 F1J1H681A732 Chip, 680PF 50WV T
C249 F1H1H391A841 Chip, 390PF 50WV T
C281 1CEC-C100M Electrolytic, 10µF 16WV T
C282 1CEC-C100M Electrolytic, 10µF 16WV T
C283 1CEC-C100M Electrolytic, 10µF 16WV T
C284 1CEC-C100M Electrolytic, 10µF 16WV T
C285 1CEC-C100M Electrolytic, 10µF 16WV T
C286 1CEC-C100M Electrolytic, 10µF 16WV T
C307 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
C308 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
C309 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
Ref. No. Part No. Part Name & Description Remarks
C310 F1H1H560A841 Chip, 56PF 50WV T
C311 F1H1H560A841 Chip, 56PF 50WV T
C312 F1H1H560A841 Chip, 56PF 50WV T
C313 1CEC-BS470M Electrolytic, 47µF 16WV T
C314 F1J1C104A148 Chip, 0.1µF 16WV T
C315 1CEC-BS100M Electrolytic, 10µF 16WV T
C316 1CEC-BS100M Electrolytic, 10µF 16WV T
C317 1CEC-BS100M Electrolytic, 10µF 16WV T
C318 F1H1H221A841 Chip, 220PF 50WV T
C319 F1H1H221A841 Chip, 220PF 50WV T
C320 F1H1H221A841 Chip, 220PF 50WV T
C321 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
C322 F1H1H560A841 Chip, 56PF 50WV T
C323 F1H1H560A841 Chip, 56PF 50WV T
C324 1HEC-BS3R3M Electrolytic, 3.3µF 50WV T
C325 F1H1H560A841 Chip, 56PF 50WV T
C326 1CEC-BS470M Electrolytic, 47µF 16WV T
C327 F1J1C104A148 Chip, 0.1µF 16WV T
C328 F1K1C1060001 Ceramic, 10µF 16WV T
C329 F1K1C1060001 Ceramic, 10µF 16WV T
C330 ECPU1C105MA5 Film, 1µF 16WV T
C331 ECPU1C105MA5 Film, 1µF 16WV T
C332 F1H1H122A219 Ceramic, 1200PF 50WV T
C333 F1H1H122A219 Ceramic, 1200PF 50WV T
C334 1HEC-BS2R2M Electrolytic, 2.2µF 50WV T
C335 1CEC-BS100M Electrolytic, 10µF 16WV T
C336 F1H1C104A107 Chip, 0.1µF 16WV T
C337 1CEC-BS470M Electrolytic, 47µF 16WV T
C338 F1J1C104A148 Chip, 0.1µF 16WV T
C339 F1J1C105A173 Chip, 1µF 16WV T
C340 F1H1H101A737 Chip, 100PF 50WV T
C341 F1J1C105A173 Chip, 1µF 16WV T
C342 F1J1C105A173 Chip, 1µF 16WV T
C343 F1H1H101A737 Chip, 100PF 50WV T
C344 1HEC-BS010M Electrolytic, 1µF 50WV T
C345 F1J1H681A732 Chip, 680PF 50WV T
C346 F1J1H681A732 Chip, 680PF 50WV T
C347 F1J1H681A732 Chip, 680PF 50WV T
C348 F1J1H681A732 Chip, 680PF 50WV T
C349 F1H1H391A841 Chip, 390PF 50WV T
C390 F1K1C105A026 Ceramic, 1µF 16WV T
C601 0JEC-FS101M Electrolytic, 100µF 6.3WV T
C602 F1H1C104A107 Chip, 0.1µF 16WV T
C603 F1H1C104A107 Chip, 0.1µF 16WV T
C604 F1K1C1060001 Ceramic, 10µF 16WV T
C605 F1H1C104A107 Chip, 0.1µF 16WV T
C606 1CEC-C100M Electrolytic, 10µF 16WV T
C607 F1K0J4750001 Ceramic, 4.7µF 6.3WV T
C608 F1H1H150A841 Chip, 15PF 50WV T
C609 F1H1H120A841 Chip, 12PF 50WV T
C610 F1H1C104A107 Chip, 0.1µF 16WV T
C611 F1H1C104A107 Chip, 0.1µF 16WV T
C612 F1H0J1050010 Chip, 1µF 6.3WV T
C613 F1H1C104A107 Chip, 0.1µF 16WV T
C614 F1H0J1050010 Chip, 1µF 6.3WV T
C615 F1H1C104A107 Chip, 0.1µF 16WV T
C616 1CEC-C100M Electrolytic, 10µF 16WV T
C621 F1H1C104A107 Chip, 0.1µF 16WV T
C622 F1K1C1060001 Ceramic, 10µF 16WV T
C623 F1J1C104A148 Chip, 0.1µF 16WV T
C633 F1H1C104A107 Chip, 0.1µF 16WV T
C634 F1H1C104A107 Chip, 0.1µF 16WV T
C635 F1H1H330A841 Chip, 33PF 50WV T
C637 F1H1C104A107 Chip, 0.1µF 16WV T
C640 F1H1C104A107 Chip, 0.1µF 16WV T
C641 F1H1C104A107 Chip, 0.1µF 16WV T
C642 F1H1C104A107 Chip, 0.1µF 16WV T
C643 1CEC-BS100M Electrolytic, 10µF 16WV T
C654 1CEC-C100M Electrolytic, 10µF 16WV T
C657 F1J1C105A173 Chip, 1µF 16WV T
C660 1CEC-BS100M Electrolytic, 10µF 16WV T
C661 1HEC-BS010M Electrolytic, 1µF 50WV T
C662 F1H1H470A841 Chip, 47PF 50WV T
C663 F1J1C104A148 Chip, 0.1µF 16WV T
19
CQ-VD6503U

Ref. No. Part No. Part Name & Description Remarks
C664 F1J1C104A148 Chip, 0.1µF 16WV T
C665 F1H1H470A841 Chip, 47PF 50WV T
C666 F1J1C104A148 Chip, 0.1µF 16WV T
C667 F1H1H470A841 Chip, 47PF 50WV T
C668 F1J1H472A733 Chip, 4700PF 50WV T
C669 F1H1E123A086 Chip, 0.012µF 25WV T
C670 1HEC-BS010M Electrolytic, 1µF 50WV T
C702 F1J1C104A148 Chip, 0.1µF 16WV T
C703 F1H1C104A107 Chip, 0.1µF 16WV T
C704 F1H1C104A107 Chip, 0.1µF 16WV T
C705 F1H1H103A842 Chip, 0.01µF 50WV T
C706 F1H1H103A842 Chip, 0.01µF 50WV T
C707 F1H1C104A107 Chip, 0.1µF 16WV T
C708 F1J1C104A148 Chip, 0.1µF 16WV T
C709 F1J1C104A148 Chip, 0.1µF 16WV T
C711 F1H1H103A842 Chip, 0.01µF 50WV T
C712 F1H1C104A107 Chip, 0.1µF 16WV T
C717 F4D551040007 Electrolytic, 0.1µF 5.5WV T
C718 1CUTCMZTS560M0 Electrolytic, 56µF 16WV T
C720 F1H1C104A107 Chip, 0.1µF 16WV T
C722 0JUTCMZTS121M0 Electrolytic, 120PF 6.3WV T
C732 F1H1C104A107 Chip, 0.1µF 16WV T
C734 F1H1H682A842 Chip, 6800PF 50WV T
C735 0JEC-FS101M Electrolytic, 100µF 6.3WV T
C736 F1H1C104A107 Chip, 0.1µF 16WV T
C737 F1K1C1060001 Ceramic, 10µF 16WV T
C740 F1J1C334A006 Ceramic, 0.33µF 16WV T
C741 F1J1C334A006 Ceramic, 0.33µF 16WV T
C742 0JEC-FS101M Electrolytic, 100µF 6.3WV T
C743 F1H1C104A107 Chip, 0.1µF 16WV T
C744 F1K1C1060001 Ceramic, 10µF 16WV T
C745 F1H1H682A842 Chip, 6800PF 50WV T
C746 0JEC-FS101M Electrolytic, 100µF 6.3WV T
C747 F1H1C104A107 Chip, 0.1µF 16WV T
C748 F1K1C1060001 Ceramic, 10µF 16WV T
C749 F1H1C104A107 Chip, 0.1µF 16WV T
C750 F1H1H562A842 Chip, 5600PF 50WV T
C753 F1H1H103A842 Chip, 0.01µF 50WV T
C754 1CEC-BS470M Electrolytic, 47µF 16WV T
C755 F1H1C104A107 Chip, 0.1µF 16WV T
C756 1CEC-BS220M Electrolytic, 22µF 16WV T
C757 1CEC-BS101M Electrolytic, 100µF 16WV T
C758 F1J1C474A173 Chip, 0.47µF 16WV T
C759 F1J1C334A006 Ceramic, 0.33µF 16WV T
C761 F1H1C104A107 Chip, 0.1µF 16WV T
C762 F1H1C104A107 Chip, 0.1µF 16WV T
C763 1CEC-BS470M Electrolytic, 47µF 16WV T
C764 F1H1C104A107 Chip, 0.1µF 16WV T
C765 F1H1C104A107 Chip, 0.1µF 16WV T
C766 EEFUE0G271R Electrolytic, 270PF 4WV T
C777 F2A1C222A715 Electrolytic, 2200PF 16WV T
C778 F1H1H392A842 Chip, 3900PF 50WV T
C779 F1H1H332A748 Chip, 3300PF 50WV T
C780 F1H1H110A231 Ceramic, 11PF 50WV T
C781 F1H1H330A841 Chip, 33PF 50WV T
C782 F1J1C105A173 Chip, 1µF 16WV T
C783 F1H1H103A842 Chip, 0.01µF 50WV T
C784 F1H1H103A842 Chip, 0.01µF 50WV T
C785 F1H1H103A842 Chip, 0.01µF 50WV T
C786 F1H1H103A842 Chip, 0.01µF 50WV T
C788 F1H1H103A842 Chip, 0.01µF 50WV T
C789 F1H1H332A748 Chip, 3300PF 50WV T
C791 F1H1C104A107 Chip, 0.1µF 16WV T
C792 F1K1C1060001 Ceramic, 10µF 16WV T
C793 F1K1C1060001 Ceramic, 10µF 16WV T
C794 F1K1C1060001 Ceramic, 10µF 16WV T
C795 F1H1C104A107 Chip, 0.1µF 16WV T
C796 F1H1C104A107 Chip, 0.1µF 16WV T
C797 F1H1C104A107 Chip, 0.1µF 16WV T
C798 F1H1C104A107 Chip, 0.1µF 16WV T
C799 F1H1C104A107 Chip, 0.1µF 16WV T
C701 1CUTESTS332M0 3300PF 16WV T
C751 ECA1CDT472 Electrolytic, 4700PF 16WV T
R736 F1H1C104A107 Chip, 0.1µF 16WV T
Ref. No. Part No. Part Name & Description Remarks
RESISTORs
FB752 D0GFR00JA017 Chip, 0Ω1/16W T
C787 D0GB103JA008 Chip, 10kΩT
R151 D0GDR00JA017 Chip, 0Ω1/16W T
R163 D0GB562JA008 Chip, 5.6kΩ1/10W T
R164 D0GN821JA005 Chip, 820Ω1/2W T
R168 D0GB220JA008 Chip, 22Ω1/10W T
R169 D0GB220JA008 Chip, 22Ω1/10W T
R170 D0GB220JA008 Chip, 22Ω1/10W T
R171 D0GB220JA008 Chip, 22Ω1/10W T
R207 D0GB473JA008 Chip, 47kΩ1/10W T
R208 D0GB183JA008 Chip, 18kΩ1/10W T
R209 D0GB103JA008 Chip, 10kΩT
R210 D0GB473JA008 Chip, 47kΩ1/10W T
R211 D0GB183JA008 Chip, 18kΩ1/10W T
R212 D0GB103JA008 Chip, 10kΩT
R213 D0GB273JA008 Chip, 27kΩ1/10W T
R214 D0GB153JA008 Chip, 15kΩ1/10W T
R215 D0GB123JA008 Chip, 12kΩ1/10W T
R216 D0GB561JA008 Chip, 560Ω1/10W T
R217 D0GB103JA008 Chip, 10kΩT
R218 D0GB561JA008 Chip, 560Ω1/10W T
R219 D0GB103JA008 Chip, 10kΩT
R220 D0GB561JA008 Chip, 560Ω1/10W T
R221 D0GB103JA008 Chip, 10kΩT
R222 D0GB103JA008 Chip, 10kΩT
R223 D0GB223JA008 Chip, 22kΩ1/10W T
R224 D0GBR00JA008 Chip, 0Ω1/10W T
R225 D0GBR00JA008 Chip, 0Ω1/10W T
R226 D0GB273JA008 Chip, 27kΩ1/10W T
R227 D0GB333JA008 Chip, 33kΩ1/10W T
R228 D0GB472JA008 Chip, 4.7kΩ1/10W T
R229 D0GB562JA008 Chip, 5.6kΩ1/10W T
R230 D0GB103JA008 Chip, 10kΩT
R231 D0GB393JA008 Chip, 39kΩ1/10W T
R232 D0GB102JA008 Chip, 1kΩ1/10W T
R233 D0GB562JA008 Chip, 5.6kΩ1/10W T
R234 D0GB102JA008 Chip, 1kΩ1/10W T
R235 D0GB562JA008 Chip, 5.6kΩ1/10W T
R236 D0GB103JA008 Chip, 10kΩT
R237 D0GB103JA008 Chip, 10kΩT
R238 D0GB473JA008 Chip, 47kΩ1/10W T
R239 D0GB562JA008 Chip, 5.6kΩ1/10W T
R240 D0GB473JA008 Chip, 47kΩ1/10W T
R241 D0GB473JA008 Chip, 47kΩ1/10W T
R242 D0GB562JA008 Chip, 5.6kΩ1/10W T
R243 D0GB154JA008 Chip, 150kΩ1/10W T
R244 D0GB221JA008 Chip, 220Ω1/10W T
R245 D0GBR00JA008 Chip, 0Ω1/10W T
R246 D0GBR00JA008 Chip, 0Ω1/10W T
R247 D0GBR00JA008 Chip, 0Ω1/10W T
R248 D0GBR00JA008 Chip, 0Ω1/10W T
R281 D0GB103JA008 Chip, 10kΩT
R282 D0GB102JA008 Chip, 1kΩ1/10W T
R283 D0GB103JA008 Chip, 10kΩT
R284 D0GB102JA008 Chip, 1kΩ1/10W T
R285 D0GB103JA008 Chip, 10kΩT
R286 D0GB102JA008 Chip, 1kΩ1/10W T
R287 D0GB102JA008 Chip, 1kΩ1/10W T
R288 D0GB102JA008 Chip, 1kΩ1/10W T
R289 D0GB103JA008 Chip, 10kΩT
R290 D0GB102JA008 Chip, 1kΩ1/10W T
R291 D0GB103JA008 Chip, 10kΩT
R292 D0GB103JA008 Chip, 10kΩT
R294 D0GB104JA008 Chip, 100kΩ1/10W T
R296 D0GB104JA008 Chip, 100kΩ1/10W T
R298 D0GB104JA008 Chip, 100kΩ1/10W T
R307 D0GB473JA008 Chip, 47kΩ1/10W T
R308 D0GB183JA008 Chip, 18kΩ1/10W T
R309 D0GB103JA008 Chip, 10kΩT
R310 D0GB473JA008 Chip, 47kΩ1/10W T
R311 D0GB183JA008 Chip, 18kΩ1/10W T
20
CQ-VD6503U
