Panasonic CQ-DP975 User manual

Panasonic.
Removable Full Front High-Power CD Player/Receiver with Changer Control
Récepteur/lecteur CD à puissance élevée avec commande de changeur CD et panneau avant amovible
CQ-DP975/DFX85EUC
Operating Instructions
Manuel d'utilisation
Please read these instructions completely before operating this unit.
I| est recommandé de lire attentivement ce manuel avant d'utiliser l'appareil.

Panasonic welcomes you to our ever growing family of electronic product owners. We know that this
product will bring you many hours of enjoyment. Our reputation is built on precise electronic and
mechanical engineering, manufactured with carefully selected components and assembled by people who
take pride in their work. Once you discover the quality, reliability and value we have built into this product,
you too will be proud to be a member of our family.
O Use This Equipment Safely
When Driving
Keep the volume level low enough to be aware of road and traffic conditions.
When Car Washing
Do not expose the equipment, including the speakers and CDs, to water or excessive moisture. This
could cause electrica! shorts, fire or other damage.
When Parked
Parking in direct sunlight can produce very high temperatures inside your vehicle. Give the interior a
chance to cool down before switching the unit on.
Use the Proper Power Supply
This equipment is designed to operate off a 12 volt, negative ground battery system (the normal system in
a North American car.)
Protect the Compact Disc Mechanism
Avoid insertion any foreign matters to the slot of the compact disc.
Failure to observe this may cause malfunction due to precise mechanism of this unit.
Use Authorized Servicenters
Do not attempt to disassemble or adjust this precision equipment. Please refer to the Servicenter list
included with this product for service assistance.
For Installation
Unit should be installed in a horizontal position with the front end up at a convenient angle, but not more
than 30º.
Note:
This operating instruction manual is for 2 models CQ-DP975EUC, DFX85EUC. All illustrations throughout
this manual represent model CO-DP975EUC unless otherwise specified. The following table describes
the differences between 2 models.
Operating
Controls
zd
CQ-DP975EUC
|
CQ-DFX85EUC
Pre-Out Level
Find the model number and serial number on either the back or bottom of the unit. Please record them in
the space below and retain this booklet as a permanent record of your purchase to aid in identification in
case of theft.
MODEL NUMBER CQ-DP975/DFX85EUC SERIAL NUMBER
DATE PURCHASED FROM
CQ-DP975/DF X85EUC

Contents
Use This Equipment Safely Fr EC Page 2
J Power and Sound Controls ss. 7
How to adjust the volume, Tone Enhancement, Attenator, balance,
and tone for best listening
O Radio Basics ......-.. eere rene erre rere nee re eene eene e ren rn 10
Manual and automatic tuning, band selection, preset stations
o Compact Disc Player BABES YET OIDI LLLI 12
Mode selection, play repeat, random and scan
O CD Changer Basics ces isanda casa tuças adia dedo UL ILLI T 14
Play, repeat, random and scan
Note:
CD changer controls are applicable to units with optional CD changer unit
(sold separately).
O Sound Design Memory .....-- MM HH 16
Operating Procedures, Battery Replacement
O Clock Basics: --+:.0.0.-:ssccsccsccssecaccecssvnsctnacaaveaaccoassecscosssonancecesoncccovenacess 17
Setting the time, selecting the clock display
€ Remote Control Basics —©essesessssrsserrarererssssuaannsrnuuarennsrnuuenaaaruuasiseoores 18
Battery replacement, notes and Operating procedure
O Installation Guide... 20
Step-by-step procedures, anti-theft system, electrical connections
m) Troubleshooting.-------- HM ee 28
Troubleshooting tips,where to get service help, Error messages
g Special Notes --—nnnnnene enne nenne nenne nennen 30
Notes on compact discs, a caution on new discs
Specifications ""———————————————————Ó——Ó ——ÁÁ—À 31
IrIO0-raozm
3
CQ-DP975/DFX85EUC

Panasonic est heureuse de vous compter parmi les utilisateurs de ses appareils électroniques.
Nous pouvons vous assurer que cet appareil vous procurera de longues heures d'agrément. Notre
réputation est fondée sur une ingénierie électronique et mécanique de haute précision laquelle préside à
fa fabrication d'appareils ne comportant que des composants de choix assemblés par un personnel
soucieux de la bonne réputation acquise par la qualité de son travail. Aprés avoir découvert la qualité, la
valeur et la fiabilité de cet appareil, vous aussi serez fier d'étre un client Panasonic.
J Précautions à prendre
Au volant
Régler le volume à un niveau qui ne risque pas de masquer les bruits ambiants.
Lavage de la voiture
Afin de prévenir tout risque de court-circuit ou d'incendie, ne pas exposer l'équipement, y compris les
haut-parleurs et les disques, à l'eau ni à une humidité excessive.
Voiture stationnée |
L'habitacle d'une voiture immobile exposée au soleil toutes vitres fermées devient rapidement trés chaud.
Laisser rafraichir l'intérieur du véhicule avant d'utiliser l'appareil.
Source d'alimentation
Cet appareil est conçu pour fonctionner sur un système d'alimentation avec batterie de 12V avec négatif à
la masse (systême standard sur les voitures de construction nord-américaine).
Mécanisme du lecteur audionumérique
Ne pas insérer d'objet dans le logement du disque. Autrement, le mécanisme ultra-précis du lecteur
pourrait être irrémédiablement endommagé.
Réparation
Ne pas tenter de démonter ou d'ajuster l'appareil soi-méme. Confier toute réparation à un centre de
service agréé. (Voir la liste incluse)
En l'installation
L'appareil doit étre installé en position horizontale avec son extrémité avant inclinée vers le haut à un
angle conventionnel et jamais supérieur à 30?.
Remarque:
Ce manuel a été concu pour les modéles CQ-DP975EUC, CQ-DFX85EUC. Toutes les illustrations du
présent manuel mettent en présence le modéle CQ-DP975EUC à moins d'indication contraire. Le tableau
ci-dessous décrit les différences entre les 2 modéles.
Modéle
CQ-DP975EUC CQ-DFX85EUC
Commande
ll est recommandé de noter, dans l'espace prévu ci-dessous, les numéros de modêle et de série inscrits
soit à l'arriére soit sous le fond de l'appareil, et de conserver ce manuel comme mémorandum de l'achat
afin de permettre l'identification de l'appareil en cas de vol.
Numéro de modele: CQ-DP975/DFX85EUC Numéro de série:
|
Date de l'achat: Vendeur:
CQ-DP975/DFX85EUC

Table des matiéres
Précautions à prendre... 4
O Interrupteur et commandes de réglage de la sonorité -ee 33
Comment régler le volume sonore, la fonction d'enrichissement tonal,
l'atténuateur et la commande d'équilibre pour une meilleure écoute
O Fonctionnement de la radio... 36
Syntonisation manuelle et automatique, sélection de la bande et stations
en mémoire
O Fonctionnement du lecteur audionumérique-.-........- eee eee 38
Sélection de mode, lecture, lecture en reprise, lecture aléatoire et
balayage des plages.
D Fonctionnement du lecteur-changeur audionumérique----------------- 40
Lecture, lecture én reprise, lecture aléatoire et balayage des
plages/disques
Remarque: Les commandes pour changeur de disques ne s'appliquent
qu'aux autoradios auxquels un lecteur-changeur (vendu séparément) est
raccordé.
O Mémoire des réglages SONOFBS -cceccscscocsereesersecenconcncosercossorsesessenentoos 42
O Fonctionnement de l'horloge —————— 43
Réglage de l'heure, sélection de l'affichage de l'horloge
O) Fonctionnement de la télécommande --................ cen 44
Remplacement de la pile, remarques et fonctionnement
O Guide d'installation irri rara t rrr n ao nha vane nno dan anu renun 46
Marche à suivre, systéme antivol, raccordements électriques
O En cas de difficulté «erre rere cere rena nera aera nere pano sue 54
Guide de dépannage, service aprés-vente, messages d'erreur
O Généralités ss... exssdeesaee Ee Eve aA EYE OVI ER IENE ETETEN AENEA ER Er 56
Remarques sur les disques audionumériques, précautions à prendre
Données techniques... 57
QE)
DDD
DDD
CQ-DP975/DFX85EUC

E
N
G
L
|
S
H
g Laser Products (This page describes the standard in only United States.)
Caution:
This product utilizes a laser.
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
Laser products:
Wave length 780 nm
Laser Power No hazardous radiation is emitted with safety protection.
* Label indications and their locations
Certification Label
Identification Label
Certification Label Identification Labe!
Product complies with DHHS Rules 21
CFR, Subchapter J in effect as of date
of manufacture.
Matsushita Communication Industrial Co., Ltd.
Model No.
Nº De Modèle CQ-DP975EUC
Yokohama, Japan
MANUFACTURED
Manufactured by Matsushita Communication
Industrial Co., Ltd.
Yokohama, Japan Made in Japan
CQ-DP975/DFX85EUC

Power and Sound Controls
Power
If the car is not already running, turn the key in the ignition until the
accessory indicator lights.
Press PWR to switch on the power.
Press PWR again to switch off the power.
Note: When power is switched on for the first time, greeting words
display. To cancel this display, press "D" button once.
When a CD is inserted with all power connected, the unit power will
automatically turn on and CD loading begins and plays.
Volume
Press “VOLA” or “V VOL’ to increase or decrease volume.
Volume Level
O to 40
Press “VOLA” or ^v VOL” for more than a half second to change
sequentially numeric levels on the display.
S-HDB (Super High Definition Bass)
Especially for rock music, the bass-sound will be more powerful.
* Press HDB to be able to listen to high-definition bass. :
* Press HDB again to return to the normal tone.
Note: This unit is equipped with an anti-volume-blast circuit which serves as an automatic volume
level adjuster so that you will not be deafened sudden loud volume.
This system operates as follows. When PWR is switched on, the volume level is low. After that, the
volume level gradually returns to its previous level prior to switching off the unit.
7
CQ-DP975/DFX85EUC

Power and Sound Controls continued
Attenuator
* Press ATT to decrease volume to about 1/10 of the previous level.
e Press ATT again to cancel.
Changing Audio Modes
Press SEL to switch the audio mode in the following order.
Normal Mode * vO ME - BASS = TREBLE - SANE
L.——————— SUB-N e FADER +
Bass and Treble
* Press SEL to select the BASS (TREBLE) mode. Press "VOL^" or
"V VOL" to increase or decrease the bass (treble) response.
JAS+ dd TRE- 3d3
| |
-12 to +12 -12 to +12
4 * Press "VOL^" or “v VOL” for more than a half second to change
numeric levels on the display rapidly.
Balance
* Press SEL to select the BALANCE mode. Press "VOL^" or
"v VOL" to shift the sound volume to the right or left speakers.
1 to 15 1 to 15
Balance Center
* Press “VOLA” or ^v VOL" for more than a half second to change
numeric levels on the display rapidly.
Fader
* Press SEL to select the FADER mode. Press “VOLA” or ^" VOL"
to shift the sound volume to the front or rear speakers.
1 to 15 Fader Center 1to 15
* Press “VOLA” or ^v VOL" for more than a half second to change
numeric levels on the display rapidly.
Note: When an Audio control mode (BAS/TRE/BAL/FAD/SUB) is selected but no operation is made
within 5 seconds(2 seconds at VOL mode), the display will return to the normal operation mode. In
such a case, press SEL again to select the control mode.
8
CO-DP975/DFX85EUC

Sub-woofer Volume
* Press SEL to select the Sub-woofer Volume mode.
* When Sub-Woofer is activated, press “VOLA” or “V VOL” to
Increase or decrease the Sub-Woofer Volume level.
Sug 3
Sub-Woofer Volume Level MUTE (0) to 8
TITLE Level Meter
SUES. 2-3 When power is ON, the level of sound sources, such as radio and
CD, is displayed.
Display Controls
Press
and
Hold
===
Dimmer
Switching
Press and hold DIMMER for more than 2 seconds to change the
brightness of the LCD from one level to another in a cycle of 3 levels
as follows:
Dimmer 1 > Dimmer 2 —+ Dimmer 3
(Bright) (Medium) (Dark)
j ba e RC TARNEN T
Level Meter Display Switching
Press DIMMER to change the Level Meter display from one level to
another in a total of 6 kinds display mode.
LEVEL DISPLAY 1 + LEVEL DISPLAY 2 -» LEVEL DISPLAY3 —> LEVEL DISPLAY 4
p LEVEL DISPLAY 6 *- LEVEL DISPLAY 5 _ ca]
LEVEL DISPLAY 2
LEVEL DISPLAY 4
LEVEL DISPLAY 6
rr er
CQ-DP975/DFX85EUC
E
N
G
L
!
S
H
3

Radio Basics
E
N
G
L
|
S
H
4
To change Tuner Mode
Press MODE to switch the operation mode in the following order.
Tuner * CD player * CD Changer Control
$ (When a disc is inserted) ¥ (When a CD changer is connected)
= EM 4719
Selecting a Band
Press BAND to select the bands in the following order.
“STEREO” indicator lights if the station is broadcasting in stereo.
FM1—> FM2 — FM3 — AM
Manual Tuning
Press "TUNE?" or “<TUNE” to move to a higher or lower frequency.
FM: HS
Hold and Release Ez Seek Tuning
‘kg
Al LE - ; Press and hold “TUNE>” or "CTUNE" for more than a half second,
then release. The radio automatically stops on the next station.
10
CQ-DP975/DFX85EUC

MONO/LOCAL Selection
* Much interference is reduced during a weak FM stereo broadcasts
when MONO is ON. (Only for FM mode) >
* Searching stops automatically at a strong signal station only when
LOCAL is ON.
Press MONO to switch between stereo and MONO mode as follows.
MONO OFF ~t—» MONO ON
Press LOCAL to switch on or off the LOC mode as follows. `
LOCAL OFF «tp LOCAL ON
on cro0-r-ozm
Preset Station Setting
Up to 24 stations can be preset in the station memory as follows;
me [ re | A
[Gstaions | 6 stations | stations | 6 stations
Manual Station Preset
(D Press BAND to select adesired band.
@ Use manual or seek tuning to find a station that you want to
program into memory.
(3) Press and hold one of the station selector buttons 1 through 6 for
more than 2 seconds until the display blinks.
Repeat the process to set other stations for the FM1 to AM bands.
"3EM3 ID 15
P-3
Note: You can change the memory setting by repeating the
above procedure.
Tuning in a Preset Station
Press any of the buttons 1 through 6 to tune in the station preset by
the above steps @ to ©.
Auto Station Preset
Select a band, press APM.
* The 6 strongest available stations will be automatically set in
memory on preset buttons 1 through 6.
* Once set, the preset stations are sequentially scanned for 5
seconds each.
* Press the appropriate preset button for the station you want to
hear.
Caution: For safety reasons, do not attempt to program while driving.
11
CQ-DP975/DFX85EUC

Compact Disc Player Basics
E
N
G
L
|
S
H
6
Loading a Disc
(D Press OPEN to open the front panel.
© Insert the disc.
(9 Close the front panel by hand.
Notes:
. When you insert a disc and the mode is switched to the CD mode,
ATT will be automatically enabled.
+ ATT will be automatically disabled when you close the front panel.
Ejecting the Disc
Press OPEN to open the front panel. Press 4 to eject the disc for
removal, and close the front pane! by hand, the previous mode of
operation will be resumed.
Note:
The disc should always be removed from the unit when not in use.
Selecting a Track
* Press "TRACK ** " once to go to the next track. Press repeatedly
to step forward through ali the tracks.
+ Press "*««TRACK" once to play from the beginning of the track you
are listening to. Press twice to play the previous track.
Press repeatedly to step backward through all the tracks.
Hold and Rele ES H
Ua Searching a Track
1 | i e Press and hold "TRACK Pr " or " *«TRACK" for more than a half
second to activate fast forward or reverse through a track.
* Release “TRACK > " or "«« TRACK" to resume the normal CD
play from that position.
12
CQ-DP975/DFX85EUC

Repeating a Track
Press R/R to repeat the current selection. “REPEAT” indicator will
light.
f^i mm &
REPEAT
Lf
cJ
ct
-
:
tite
The current selection will continue to repeat until you press R/R œ again.
Random Selection
Press and hold R/RP for more than 2 seconds. “RANDOM” indicator
will light. A random selection of music is played from all available
tracks.
mL 145938
RANDOM AI 1 i RR :j
To turn it off, press and hold R/R for more than 2 seconds again.
Scanning Tracks
Press SCAN. The display will blink and the first 10 seconds of each
track on the discs play in order.
To stop scanning and continue with the current track, press SCAN
again.
Selecting by Track Number
(Direct track access)
* Press a number from "1" to "6" then the corresponding track will
start.
e Press and hold a number from "7" to “12” ("1" to "6") for more than
one second and the corresponding track will start.
Note:When POWER or ACC is off you can press 4 to eject the
disc.
13
CQ-DP975/DFX85EUC

14
CD Changer Basics
Note:
CD changer functions are applicable to units with optional
CD changer unit. (sold separately)
"
EM
E À
CQ-DP975/DFX85EUC
To start the CD Changer
While a disc magazine inserted in the CD Changer, press MODE to
play starts from first track.
TT mm!
LuUL JV IG
Selecting a Disc
(Direct Disc access)
* Press a number from "1" to "6" then the corresponding disc will
start.
* Press and hold a number from "7" to "12" ("1" to "6") for more than
one second and the corresponding disc will start.
Selecting a Track
+ Press "TRACK »*" once to go to the next track. Press repeatedly
to step forward through all the tracks.
* Press "««TRACK" once to play from the beginning of the current
track. Press twice to play the previous track.
Press repeatedly to step backward through all the tracks.
Searching a Track
* Press and hold "TRACK **" or " «« TRACK" for more than a half
second to activate fast forward or reverse through a track.
e Release "TRACK ** " or “«« TRACK" to resume the normal CD
changer play from that position.
Repeating a Track
Press R/R to repeat the current selection. “REPEAT” indicator will
light.
The current selection will continue to repeat until you press R/R
again.

os | Random Selection
Press and hold R/R» for more than 2 seconds. A random selection
of music is played from all available tracks.
To turn it off, press and hold R/R® for more than 2 seconds again.
Note:
+ If R/R is pressed during random play, the track now in play
automatically returns to beginning upon coming to the end plays
back again. (Random repeat)
e When R/R® is pressed again, repeat play stops and returns to
random play.
* Press and hold R/R» for more than 2 seconds again, random play
stops.
Scanning Tracks
Press SCAN. The display blinks and the first 10 seconds of each
track on the discs play in order.
To stop scanning and continue with the current track, press SCAN
again.
Scanning Discs
Press and hold SCAN for more than 2 seconds. The 1st track of all
the discs in the magazine is played for 10 seconds each.
To stop scanning and continue with the current track, press SCAN
again.
Changing the Display
Press DISP for less than 2 seconds to switch the display in sequence
in the following order.
(Upper Display) Disk/Track Number Track Play Time
(Lower Display) No Display SN No Display
1 l
Track Play Time Disk/Track Number
Clock EE Clock
Note:You cannot change the current display while Random or
Scan plays in CD or CD- C.
15
CQ-DP975/DFX85EUC

16
Sound Design Memory
CQ-DP975/DFX85EUC
Sound Design Memory Mode
A re sound setting (except for VOL and ATT) can be memorized
and recalled.
Purina kh
LILJIN L
Sound Design Memory Input
* Press SDM to select to the sound design memory mode.
* To preset sound setting, press the corresponding preset memory
button (1 to 4) for more than 2 seconds in Sound Design Memory
mode until the display blinks.
Comuna
x TM ty
* The preset memory buttons 5 and 6 are not valid for set sound
design memory. (call only)
Recall Programmed Sound
Design Memory
* When a desired preset memory button is pressed in sound
memory mode, the corresponding sound setting is called.
ii Preset number
* The preset memory button 5 is recommended for setting.
* The preset memory button 6 is used to release all sound settings.
To change to normal mode
Press SDM or DISP to change to the normal mode.
Note: When the sound design memory mode is selected but no
operation is made within 5 seconds, the mode will return to the
normal mode.

Clock Basics (The clock system is 12-hours.)
Initial Time Setting
The DISP key is inoperative while Random or Scan plays in CD or
CD:C. To cancel Random or Scan plays before using the DISP key.
(D Press DISP. “ADJ” is displayed. PEN
— € A
(2 Press and hold DISP again for
more than 2 seconds. “12” blinks
indicating the time setting mode
is activated.
@ To set hours, press “< TUNE" or “TUNE >”.
@ Press DISP again for minute setting.
© To set minutes, press “< TUNE” or “TUNES” .
Hold “< TUNE” or “TUNE >” to change numbers rapidly.
© When you have set the time, press DISP.
Resetting the Time
When you want to reset the time, press and hold DISP for more than
2 seconds to activate the time setting mode. Then, repeat step O to
€ above.
Selecting the Clock Display
Press DISP for clock display.
Press DISP once again, and the clock display disappears.
In Tuner Mode Presets «— Clock
In CD Mode No Display (Clock Off) «—— Clock
When power is tumed off while the time is displayed, the clock mode
remains on. When the PWR is pressed again, the system is completely
off.
Note: Before you leave your car that has no ACC, be sure to switch
power off.
17
CQ-DP975/DFX85EUC

Remote Control Unit Basics
Battery Replacement (Remote Control Unit)
1.Remove the battery holder.
Pull the holder by the Position B while pushing Position A in the
direction indicated by the arrow. @Lithium battery
Rear view of remote
2.Replace the battery. control
Set a new battery properly with the (+) side up as illustrated.
3. Insert the battery holder. )
Push in the holder to the full. Position B
Notes on Batteries A
Old batteries must immediately be removed and disposed. Battery holder Position A
Battery Information:
* Designated Battery: Panasonic Lithium Battery (CR2025)
* Battery Life: 6 months with normal use (in normal room temperature)
Caution:
improper use of batteries may cause overheating, explosion or ignition, resulting in injury or fire.
Battery leakage may cause damage to the unit.
* Do not disassemble or short the batteries. Do not throw the batteries into the fire.
* To avoid the risk of accident, keep the batteries out of reach of children.
® Power Button
@BAND/DISC UP Button
@ATT Button
@TUNE/TRACK Button
® Volume Control Button
& Mode Button
Please refer Battery Replacement before using
remote control.
O
pe
rati
n
g
p
ro
ced
ures
m
aren
controller
toward
the
sensor
of
Attenuator
@ATT {ATT Button)
* Press ATT to immediately decrease
volume to about 1/10 of its previous level.
* Press ATT again to cancel.
Power
O POWER (Power Button)
Press POWER to switch on the power.
Press POWER again to switch off the power.
Mode Selection
6 MODE (Mode Button)
Press MODE to switch the operation
mode in the following order.
Radio — CD Player —> [UD “hanger
Control
ES
Volume
@VVOLA (Volume Control Button)
Press "^" or ^v" to increase or decrease
volume level.
1
: CQ-DP975/DFX85EUC

Radio
Selecting a Band
G BAND (Band select Button)
Press BAND to select bands in sequence.
FMI — FM2 —» FM3 — AM
Manual Tuning
€ v TUNE^ (Manual Tuning Button)
Press ^v" or “A” to tune the frequency
downward or upward.
Seek Tuning
GvTUNE^ (Seek Tuning Button) .
Press and hold ^v" or "^" for more than a
half second, then release. The radio will
automatically stop on the next station.
Compact Disc Player
(When a disc is inserted, playback starts.)
To starts CD Play
€ MODE (MODE Button)
* Only when a disc is inserted, press to
select CD play mode, and playback starts
automatically.
* When connecting with the CD changer,
press repeatedly to select the mode as
follows.
Radio ——> CD Player —» (vB Changer)
Control
qi ——-]
When a disc is inserted, the CD play starts
automatically regardless what mode you:
are being listened.
Selecting a Track
®VTRACKA (Track Select Button)
* Press "^" once to go to the next track.
* Press "v" once to play from the
beginning of the currently played track.
* Press repeatedly to skip forward or
backward through all the tracks.
Searching a Track
€ vTRACK^ (Track Search Button)
* Press and hold “v” or "^" for more than a
half second to activate fast forward or
reverse through a track.
Release to stop fast forward or reverse.
CD Changer Control |
(In connection with the CD changer.)
Selecting a DISC
@DISC UP (Disc Select Button)
Press to sequentially advance to the next disc.
Selecting a Track
€ vTRACK^ (Track Select Button)
Press "^" once to go to the next track.
Press "v" once to play from the
beginning of the currently played track.
Press repeatedly to skip forward or
backward through all the tracks.
Searching a Track
€ vTRACK^ (Track Search Button)
+ Press and hold ^v" or "^" for more than a
half second to activate fast forward or
reverse through the disc.
* Release to stop fast forward or reverse.
CQ-DP975/DFX85EUC 13

Io-—raozm
-b 4A
Installation Guide
ÁN WARNING
The installation information is designed for experienced installers and is not
intended for non-technical individuals. It does not contain warnings or cautions of
potential dangers in attempting to install this product.
Any attempt to install this product in a motor vehicle by anyone other than
qualified installer could cause damage to the electrical system and could result in
serious personal injury or death.
D Overview
This equipment should be installed by a
professional. However, if you plan to install this
unit yourself, your first step is to decide where to
install it. The instructions in these pages will
guide you through the remaining steps: (Please
refer to “WARNING?” statement above).
* Identify and label the vehicle wires
* Connect the vehicle wires to the wires of the
power connector
* Install the unit in the dash
e Check the operation of the unit
If you do encounter problems, please consult
your nearest professional installer.
Caution: This unit will operate with a 12 volt DC
negative ground auto battery system only. Do not
attempt to use it in any other system. Doing so
could cause serious damage.
Before you begin installation, look for the
following items included in the packing with your
unit.
+ Warranty Card .... Fill this out promptly
* PASC, Panasonic (in Canada) Servicenter
Directory ..... Keep for future reference in case
the unit needs servicing
* Installation Hardware ..... Needed for in-dash
installation
CQ-DP975/DFX85EUC
© Installation Hardware
No.| item —— Diagram [Qty]
emm [EL
(4) | Tapping Screw 7 1
(5 mmọ x 16 mm) |
a Mounting Bolt (5 mmo)
@ | Removable Face Plate SE 1
a
Case
SS)
Remote Control Unit
xy
