2020.3 panasonic.net/id/pidsx

Communication Module for the

SF4D Series

SF4D-TM1

User’s Manual

WUME-SF4DTM1-5

(MEMO)

Thank you for purchasing an SF4D-TM1 communication module for the SF4D series.

Before using this product, read and understand this User's Manual and the manual for the light

curtain. Use the product correctly and in the optimum manner.

Keep this manual in a convenient place for quick reference.

This manual is for the following persons who have received appropriate training and have a

knowledge of optoelectronic safety sensors and safety.

●Those who are in charge of installation of this device.

●Those who incorporate this device into systems or design them.

●Those who install and/or connect this device

●Those who manage or perform work at sites where this device is used.

●Those who have the qualications, authority, and responsibility to ensure safety in the phases

of machinery design, manufacture, installation, operation, maintenance, and disposal.

Read and understand "Safety Standards" in the Light Curtain manual. Exercise su󰀩cient caution

with respect to safety, and handle the product correctly.

Please note

1) Unauthorized reproduction of part or all of this manual is prohibited.

2) The contents of this manual are subject to change without notice.

3) This manual has undergone strict quality control procedures; however, in the event that you

discover any problems or points of concern, please contact your local dealer.

4) This manual (Japanese and English) is the original edition.

Windows®is a registered trademark of Microsoft Corporation in the U.S.A. and other countries.

6) Other company names and product names are trademarks or registered trademarks of their

respective owners.

Contents

Chapter 1 Introduction ······································································ 7

1-1 Safety Cautions ···········································································8

1-2 Contents of Package ·································································· 10

Chapter 2 Before Using The Device····················································11

2-1 Features··················································································· 12

2-2 Description of parts ···································································· 14

2-3 Connections·············································································· 15

2-3-1 Connecting to the light curtain ···················································15

2-3-2 Disconnecting from the light curtain············································16

2-3-3 Connecting to a PC·································································17

2-3-4 Disconnecting from the light curtain············································18

2-3-5 Connecting to the light curtain and PC ········································19

2-3-6 Disconnecting from the light curtain and PC ·································20

Chapter 3 Procedures for Operation ···················································21

3-1 Procedures for operating the device··············································· 22

3-2 Copy functions ·········································································· 23

3-2-1 Copy functions: READ function ·················································23

3-2-2 Copy functions: WRITE function ················································24

3-2-3 Saved data initialization function················································25

Chapter 4 Software Tool···································································27

4-1 System conguration ·································································· 28

4-2 System requirements ·································································· 29

4-2-1 Operating system ···································································29

4-2-2 PC specications····································································29

4-3 Installation ················································································ 29

4-4 Uninstallation ············································································ 29

4-5 Connection and disconnection procedures ······································ 30

4-6 Starting and exiting the software tool·············································· 31

4-6-1 Starting the software tool ·························································31

4-6-2 Start screen···········································································31

4-7 Creating a new le ····································································· 32

4-8 Opening an existing le ······························································· 33

4-9 Reading data from the light curtain ················································ 35

4-10 Reading data from the communication module ······························· 37

4-11 Monitoring light curtain operation ················································· 39

4-12 Opening a le from the "Recently opened les" list ·························· 40

4-13 Exiting the software tool····························································· 40

4-14 Function settings / conguration settings ······································· 41

4-15 Muting function ········································································ 42

4-15-1 Timing settings ·····································································42

4-15-2 Each beam axis setting ··························································43

4-16 Blanking function······································································ 44

4-17 Interlock / external device monitor function ···································· 45

4-18 Application indicator function and interrupt display function ··············· 46

4-18-1 How to set the application indicator function ·······························46

4-18-2 How to set the interrupt display function ····································47

4-19 Light curtain conguration function ··············································· 48

4-20 Input / output wire setting function················································ 49

Chapter 5 Functions ········································································51

5-1 Input / output wire settings ··························································· 54

5-1-1 Auxiliary output function assignment (12-core cable, 8-core cable)····55

5-2 Input / output specications ·························································· 56

5-2-1 Standard specication (12-core cable) ········································56

5-2-2 Parallel interference prevention specication (12-core cable)···········59

5-2-3 Optical synchronization / standard specication (12-core cable) ·······63

5-2-4

Optical synchronization / muting specication / PNP output (12-core cable)

·66

5-2-5

Optical synchronization / muting specication / NPN output (12-core cable)

·68

5-2-6 Standard specication (8-core cable)··········································70

5-2-7 Optical synchronization / standard specication (5-core cable)·········72

5-2-8 Optical synchronization / application indicator based specication /

PNP output (5-core cable)························································73

5-2-9 Optical synchronization / application indicator based specication /

NPN output (5-core cable)························································74

5-3 Muting function (12-core cable) ····················································· 75

5-3-1 Muting input A / B wire and override function ································75

5-3-2 Muting mode ·········································································76

5-3-3

Muting sensor input order (parallel 4-sensor, invalid when rising, exit only)

·76

5-3-4 Muting sensor output operation setting········································76

5-3-5 Muting input time limit value······················································76

5-3-6 Muting maximum continuous valid time ·······································77

5-3-7 Muting indicator disconnection detection ·····································77

5-3-8 Override setting······································································77

5-3-9 Each beam axis setting····························································77

5-4 Blanking function ······································································· 78

5-4-1 Fixed Blanking Function···························································78

5-4-2 Floating Blanking Function ·······················································79

5-5 Interlock Function······································································· 80

5-5-1 Interlock setting······································································80

5-5-2 Interlock setting input wire and manual reset setting ······················80

5-5-3 Interlock mode ·······································································81

5-6 External device monitor setting (8-core cable, 12-core cable) ·············· 81

5-7 Application Indicator Function ······················································· 82

5-7-1 Indication by application indicator input ·······································82

5-7-2 Indication linked to control output (OSSD 1 / 2)·····························83

5-7-3 Indication linked to interlock······················································83

5-7-4 Indication linked to test function·················································83

5-7-5 Interrupt display function ··························································83

5-7-6 Synchronization method and application indication ························84

5-7-7 List of indication colors and ON / Blinking settings ·························84

5-8 Operation monitor function ··························································· 85

5-9 Protection functions ···································································· 86

5-9-1 Locking the write function·························································86

5-9-2 Locking the read function ·························································86

5-9-3 Locking the initialization function················································86

5-9-4 Locking writing of settings from a PC ··········································86

5-10 Password-based prevention function of writing to light curtain············ 87

5-11 Initialization function ·································································· 88

Chapter 6 Troubleshooting································································89

Chapter 7 Specications and Dimensions ············································91

7-1 Specications············································································ 92

7-2 Dimensions··············································································· 93

Chapter 1 Introduction

1-1 Safety Cautions ···········································································8

1-2 Contents of Package ·································································· 10

Introduction

1-1 Safety Cautions Always observe

This section explains important rules that must be observed to prevent human injury and prop-

erty damage.

■ The hazards that may occur if the product is used incorrectly are described and classied by

level of harm.

WARNING Risk of death or serious injury.

CAUTION Risk of minor injury or property damage.

<Reference> A "Reference" provides additional information for more e󰀨ective use of the

product.

■ Use this product within the specications. If the product is modied, functionality and perfor-

mance cannot be assured.

■ This product has been developed and manufactured for industrial use only.

■ This product is suitable for indoor use only.

■The product is not designed for use in the following conditions and environments. If use of

the product in any of these conditions or environments is unavoidable, consult us.

1) Use in conditions or environments not described in this manual.

2) Use for nuclear power control, railroad facilities, air navigation facilities, vehicles, combus-

tion facilities, medical systems, or space development.

■ Risk of damage if the product is dropped or otherwise subjected to strong shock.

■When disposing of the product, dispose as industrial waste.

WARNING

♦Machine designers, responsible persons for installation, responsible persons for use,

and machine users

● Machine designers, responsible persons for installation, responsible persons for use, and

machine users must observe applicable laws and regulations relating to installation and

use of the device, and follow the instructions in the manual for installation, maintenance,

and inspection.

●Whether this device functions as designed, and whether system devices, including this

one, comply with safety standards, depends on the suitability of the application, installa-

tion, maintenance, inspection, and method of operation of the device. The machine de-

signer, responsible person for installation, responsible person for use, and machine user

are responsible for these matters.

♦Expert engineer

● An expert engineer is a person such as a machine designer, responsible person for instal-

lation, or responsible person for use who has been professionally trained, has comprehen-

sive knowledge and experience, and is able to solve the various problems that may occur

as work is performed.

♦Operator

●To enable correct operation of the device, the operator should read and understand the

contents of this manual and perform work according to the procedures described therein.

●In the event that the device does not operate correctly, the operator should immediately

stop operation and report the problem to the responsible person for use. Do not operate

the machine until it has been veried that normal operation has been restored.

Introduction

WARNING

♦Fixed blanking and oating blanking functions

●When the sensing area is invalidated by the xed blanking function, set up a protective

structure that will prevent humans and physical objects from passing through the invali-

dated sensing area and reaching dangerous parts of the machine.

Risk of death or serious injury if a human body is not detected.

● The oating blanking function is used to change the size of the smallest detectable object

of the SF4D series light curtain ("light curtain" below) on which the function is set. When

setting or changing the function, recalculate and remeasure the safety distance, and verify

that the distance between the dangerous part of the machine and the sensing area of the

light curtain on which the function is set is always greater than the safety distance.

If a su󰀩cient distance is not established, the machine will not be able to stop before a hu-

man body or object arrives at a dangerous part, creating a risk of death or serious injury.

● Always ensure that applicable laws and regulations are observed when setting or chang-

ing the function.

♦Muting setting change function

●The muting setting change function temporarily invalidates the safety functions of the light

curtain. Check all applicable laws and regulations, and install and operate correctly. Risk

of serious injury to the operator if these requirements are not satised.

♦Operating environment

●Do not use a cell-phone or radio equipment near the device.

●Do not install the device in the following locations:

1) A location directly exposed to sunlight

2) A location subject to condensation due to sudden temperature changes

3) A location where corrosive or ammable gas is present in the air

4) A location with signicant dust, metal powder, or salt

5) A location where organic solvents such as benzene, thinner or alcohol, or strong alka-

lines such as ammonia or caustic soda, may splash on the product or are present in the

air

6) A location subject to vibration or shock, or where water droplets may come in contact

with the product

7) A location near (minimum distance 100mm) high-voltage lines, high-voltage equipment,

power lines, power equipment, equipment with an amateur radio or other transmitter, or

equipment that generates large switching surges

♦Wiring

● Before installing electrical wiring, be sure to turn OFF the power supply.

●All electrical wiring must installed by a qualied electrician or technician in accordance with

applicable local electrical regulations and laws.

●Do not wire in parallel with a high-voltage line or power line, or run through the same con-

duit. Risk of malfunctioning due to induction.

♦Maintenance

● When cleaning the device, use a clean cloth. Never use volatile chemicals.

♦Other matters

● Never modify the device. Risk of death or serious injury due to impaired functionality.

Introduction

1-2 Contents of Package

□Main unit: 1 pc.

□Quick Instruction Manual (Japanese, English, Chinese) 1 pc. for each language

□General Information for Safety, Compliance, and Instructions (23 languages) 1 pc.

Chapter 2 Before Using The Device
