Panasonic SF-C10 Series User manual

2022.5
Exclusive Control Unit for Safety Light Curtain
SF-C10 SERIES
* The contents of this catalog are as of October 2017.
For the latest information, please visit our company website.
The control category differs depending on the configuration and wiring of the external circuit.
Category 4 PLe SIL3

2
Exclusive Control Unit for Safety Light Curtain
SF-C10 SERIES
Less setup time for safety circuits
Quick-connection Easy setup requiring no torque control
A spring method is used for the
terminal blocks for connections
other than to the safety light
curtain. There is no need to control
tightening
torques for
these
terminal
blocks.
Connecting to the safety light curtain
is done using plug-in connections,
which shortens setup and
replacement time.
Removable terminal blocks
reduce maintenance time
Removable terminal blocks are
used. This reduces the work
required for reconnecting wiring
during maintenance.
Lead wire
Flat-tipped screwdriver
Release button
Lead wire insertion hole
Ferrule (sleeve) terminal
(Please arrange separately.)
Uses a
spring method!
Metal enclosure with a IP65 protective structure
The strong metal enclosure has a built-in safety relay. It
has an IP65 protective structure, so that it can be set up
individually without needing to be inserted into a control
panel.
Slim design
22.5 mm 0.886 in thickness, so can be inserted even
into narrow spaces inside panels.
Removable!
IP65
Metal enclosure
The wiring with the safety light
curtain is connector connection.
Slim
22.5 mm
0.886 in
Spring-type terminal block
No torque control needed
Plug-in type control unit SF-C11 /SF-C14EX(-01)
Robust type control unit SF-C12 Slim type control unit SF-C13
Certified
Listing
Certified
(SF-C11/C13 only)
Category 4 PLe SIL3
The control category differs depending on the conguration and wiring of the external circuit.

Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
3
The method used to build the safety circuit is selectable
It is possible to build muting control circuits using a stand-alone safety light curtain from the SF4B /SF4B-G series.
The SF-C14EX(-01)application expansion unit allows the safety light curtain, muting sensors and muting lamps to be
connected together directly, so that muting control circuits can be built very easily.
Building
method
Using SF4B series functions
Motor, etc.
External devices
(Force-guided relay, etc.)
Muting
sensors
Muting
lamps
Low cost!
Saves space!
No safety relay unit needed
Muting control
Safety output
Terminal blocks
SF4B
series
Safety light curtain connector connection.
Terminal blocks for peripheral circuits available.
Muting
sensors
Muting
lamps
Building
method
Using the SF-C14EX(-01) internal circuits
Motor, etc.
External devices
(Force-guided relay, etc.)
Less wiring!
Reduced maintenance!
SF-C14EX(-01)
Exclusive mating
cable for
SF-C14EX(-01)
SF4B
series
Muting control
Safety output
Three safety circuit systems packaged into a single unit!
Three safety circuit systems
1
Safety light curtain output
circuit,
2
Muting control circuit, and
3
Emergency stop
circuit are packaged into a single unit. Functions that
require multiple safety relay units and muting control
units can be concentrated into a single unit, which
results in large space savings, less wiring and less
installation work.
High-speed response 14 ms (Including safety light curtain)
High-speed response has been achieved due to the
adoption of the semiconductor output. Avoids the
response delays that occur when using more than one
safety relay unit, and greatly reduces the safety light
curtain safety distance and improves ease of working.
Of course, it is not necessary to exchange the safety
relays within the unit anymore, which contributes to the
reduction of running cost.
20 ms 35 ms10 ms14 ms
SF-C14EX(-01) Previous model
SF-C14EX(-01)
Previous model
Including safety light curtain response time
High response speed of 14 ms!
Greatly reduced safety distance!
Muting sensor Muting sensor Emergency stop button Safety light curtain Emergency stop button SF4B series
SF-C14EX(-01)
Customer's logical connection circuit
Motor Motor
Saves space!
Less wiring!
Less construction!
Furthermore, due to the
semiconductor output,
Safety light curtain output circuit
Emergency stop circuit
Safety relay
unit
Muting unit Safety relay
unit
Total 14 ms!
Relay replacement is not required!
Customer's
logical
connection
circuit
External contactor
(Force-guided relay, etc.)
External contactor
(Force-guided relay, etc.)
1
2
3
Muting control circuit
1
1
1
1
1
1
2
2
2
2
2
2
3
3
3
3
3
3
Building of muting control circuits is easy SF-C14EX(-01)
Both safety and productivity can be obtained by stopping only one part of the device SF-C14EX(-01)

4
Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
Motors that use muting control and those that do not use it can be controlled independently!
Controls the motors that use muting control
(robots) and the motors that do not use muting
control (turntables) with a single unit.
When the workpiece comes in, the turntable
can be stopped and the robot can keep
operating condition, to protect the safety of the
operator and to maintain productivity.
output systems using only a single unit!
SF-C14EX(-01) controls three safety
Emergency stop button
Turntable
Motor not using muting
SF4B series
Limit switch
For muting input
Robot
Motor using muting
1
3 2
Robot
Motor using muting
Safety circuit
1
: Linked to safety light curtain beam
received / interrupted status (partial stop)
When the safety light curtain is interrupted
(when an workpiece enters or a person
intrudes), this circuit switches off (open) the
safety output and stops the turntable.
Safety circuit
2
: Linked to muting control (partial stop)
If an workpiece enters when the turntable
has stopped normally, (muting conditions
are achieved), this circuit allows the robot to
operate.
If an workpiece enters while the turntable is
turning (muting conditions are not achieved),
this circuit switches off (open) the safety output
and stops the robot.
Safety circuit
3
: Linked to emergency stop input (all stop)
When the emergency stop button is pressed,
this circuit switches off (open) the safety output
and stops all equipment (turntable and robot).
Equipped with blown lamp output for muting lamp
If a lamp in one of the two muting lamps that are
connected to the unit blows, a warning is output. It is
possible to replace the lamp before both lamps blow and
the equipment stops. In addition, auxiliary output that
is linked to the muting function, override function and
safety light curtain control output is also available.
Equipped with a digital indicator so that error
details can be understood at a glance!
Function Operation
Auxiliary
output 1 Muting output ON when the muting
function is invalid
Auxiliary
output 2 Override output ON when the override
function is invalid
Auxiliary
output 3 Blown lamp output ON when the muting
lamp is normal
Auxiliary
output 4
Safety light curtain
auxiliary output
ON when the safety light curtain
is in light interrupted condition
If a problem should occur, the same output (OFF signal)
as when the object was detected is maintained in order
to ensure safety, and the details of the error appear on
the digital display.
NPN
PNP
NPN
PNP
Polarity selection
switch
Supports both PNP and NPN polarities
A single model can be used for PNP/NPN input switching, reducing the number
of parts that need to be registered.
All Models
Three safety circuit systems can be controlled independently so that equipment can be stopped all together or partially
SF-C14EX(-01)

Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
5
ORDER GUIDE
Note: Refer to SF4B / SF4B-G series and SF2B series for the applicable cable.
SF-C12 spare relay set
A set of spare relays (2 safety relays and 1 removal tool) is available for the safety relay that is built into the SF-C12.
Model No.: SF-C12-RY
Designation Appearance Model No. Applicable cable (Note) Description
Connector
connection type
control unit
SF-C11
Safety light curtain connection cable:
SFB-CB□
(For SF4B series)
SF2B-CB□
(For SF2B series)
Extension cable: SFB-CCJ10□
Use 8-core cable with connector to connect to the safety
light curtain.
Compatible with up to Control Category 4.
Interference prevention wires and muting function cannot
be used.
Robust type
control unit SF-C12
Safety light curtain connection cable:
SFB-CB05-MU
Extension cable: SFB-CCJ10□-MU
Use 12-core cable with connector to connect to the safety
light curtain. Interference prevention wires can be used.
Compatible with up to Control Category 4.
Muting function cannot be used.
Slim type
control unit SF-C13
Safety light curtain connection cable:
SFB-CCB□(-MU)
(For SF4B series)
SF2B-CCB□
(For SF2B series)
Extension cable:
SFB-CC□(-MU)
Use a discrete wire cable to connect to the safety light
curtain. Muting function and interference prevention wires
can be used.
Compatible with up to Control Category 4.
Application
expansion
unit for
SF4B /
SF4B-G
series
SF-C14EX
Safety light curtain connection cable:
SFB-CB□-EX
Extension cable:
SFB-CCJ10□
The muting control function and emergency stop input
expand the applications of the safety light curtains.
Use exclusive cable to connect to the safety light curtain.
Compatible with up to Control Category 4.
The handy-controller SFB-HC (optional) cannot be used
with SF-C14EX-01.
Handy-controller non-compatible type
SF-C14EX-01

6
Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
SPECIFICATIONS
Model No.
Item SF-C11 SF-C12 SF-C13
Connectable safety light curtains SF4D /SF4B /SF4B-G / SF2B series SF4B /SF4B-G series Safety light curtain manufactured by Panasonic Industrial Devices SUNX
Applicable standards
EN 61496-1 (Type 4), EN 55011, EN ISO 13849-1 (Category 4, PLe), IEC 61496-1 (Type 4), ISO 13849-1 (Category 4, PLe),
JIS B 9704-1 (Type 4), JIS B 9705-1(Category 4), ANSI/UL 61496-1 (Type 4), UL 1998 (Class 2) (Note 2)
CE marking directive compliance Machinery Directive, Low Voltage (SF-C11/C13 only) Directive, EMC Directive, RoHS Directive
Control category ISO 13849-1 (EN ISO 13849-1, JIS B 9705-1) compliance up to Category 4, PLe standards
Supply voltage / Current consumption 24 V DC ±10 % Ripple P-P 10 % or less / 100 mA or less (without safety light curtain)
Fuse rating Built-in electronic fuse, Triggering current: 0.5 A or more, Reset after power down
Safety output NO contact × 3 (13-14, 23-24, 33-34) NO contact × 2 (13-14, 23-24) NO contact × 3 (13-14, 23-24, 33-34)
Utilization AC-15, DC-13 (IEC 60947-5-1)
Rated operation voltage (Ue) /
Rated operation current (le)
30 V DC / 6 A, 230 V AC / 6 A, resistive load
(For inductive load, during contact protection)
Min. applicable load: 10 mA (at 24 V DC) (Note 3)
24 V DC / 1 A, resistive load
(For inductive load, during contact protection)
Min. applicable load: 15 mA (at 24 V DC)
30 V DC / 4 A, 230 V AC / 4 A, resistive load
(For inductive load, during contact protection)
Min. applicable load: 10 mA (at 24 V DC) (Note 3)
Contact material / contacts AgSnO, self cleaning, positively driven AgNiO + 0.2 µm 0.008 mil Au plating, self cleaning, positively driven AgSnO, self cleaning, positively driven
Contact resistance 100 mΩ or less (initial value) 50 mΩ or less (initial value) 100 mΩ or less (initial value)
Contact protection fuse rating 6 A (slow blow) 3 A (slow blow) 4 A (slow blow)
Mechanical lifetime 10,000,000 times or more (open/close frequency of 180 times/min) (Note 4)
Electrical lifetime 100,000 times or more (open/close frequency of 20 times/min, 230 V AC, 3 A, using resistance load) (Note 4)
Pick-up delay (Auto reset/Manual reset) 80 ms or less / 90 ms or less 30 ms or less / 30 ms or less 80 ms or less / 90 ms or less
Response time 10 ms or less 14 ms or less 10 ms or less
Auxiliary output
Safety relay contact (NC contact) ×1 (41-42) (Related to enabling path) Safety relay contact (NC contact) × 1 (31-32) (Related to enabling path) Safety relay contact (NC contact) × 1 (41-42) (Related to enabling path)
Rated operation voltage/current 24 V DC / 2 A, Min. applicable load: 10 mA (at 24 V DC) 30 V DC / 3 A, Min. applicable load: 15 mA (at 24 V DC) 24 V DC / 2 A, Min. applicable load: 10 mA (at 24 V DC)
Contact protection fuse rating 2 A (slow blow) 3 A (slow blow) 2 A (slow blow)
Semiconductor auxiliary output
(AUX)
<Minus ground (Setting for PNP)>
PNP open-collector transistor
• Max. source current: 60 mA
• Applied voltage: same
as supply voltage
between the semiconducto r
auxiliary output and +V
• Residual voltage: 2.3 V or less
(at source current 60 mA)
• Leakage current: 2 mA or less
<Plus ground (Setting for NPN)>
NPN open-collector transistor
• Max. sink current: 60 mA
• Applied voltage: same
as supply voltage
between the semiconductor
auxiliary output and 0 V
• Residual voltage: 1.5 V or less
(at sink current 60 mA)
• Leakage current: 2 mA or less
–
PNP open-collector transistor
• Max. source current: 60 mA
• Applied voltage: same as supply voltage
between the semiconductor
auxiliary output and +V
• Residual voltage: 2.3 V or less
(at source current 60 mA)
• Leakage current: 2 mA or less
Output operation
Related to auxiliary output of safety light curtain
–
On when the safety light curtain is interrupted
Excess voltage category ll lll ll
Indicators
Power supply (Ui) Green LED (lights up when the power is ON)
Safety output [OUT (Note 5)] Green LED (lights up when safety output is closed)
Interlock (INTER_LOCK)
Yellow LED (lights up when safety output is opened)
–
Yellow LED (lights up when enabling contacts are opened)
Fault (FAULT) Yellow LED (blinks when fault occurs)
Orange LED (lights up when two safety light curtain
input polarity selection switch settings are different)
Yellow LED (blinks when fault occurs)
External relay monitor function Incorporated Incorporated (Note 6) Incorporated
Trailing edge function Incorporated
Polarity selection
function (Note 7)
Incorporated (Sliding switch allows selection of plus/minus ground)
Minus ground: Correspond to PNP output safety light curtain
Plus ground: Correspond to NPN output safety light curtain
Incorporated (Cable connection allows selection of plus/minus ground)
Minus ground: Correspond to PNP output safety light curtain
Plus ground: Correspond to NPN output safety light curtain
Pollution degree 2
Environmental resistance
Protection Enclosure: IP40, Terminal: IP20 IP65 Enclosure: IP40, Terminal: IP20
Ambient temperature –10 to +55 °C +14 to +131 °F (No dew condensation or icing allowed), Storage: –25 to +70 °C –13 to +158 °F
Ambient humidity 30 to 85 % RH, Storage: 30 to 95 % RH 35 to 85 % RH, Storage: 35 to 85 % RH 30 to 85 % RH, Storage: 30 to 95 % RH
Vibration resistance
Resistance / malfunction 10 to 55 Hz frequency, 0.35 mm 0.014 in
amplitude in X, Y, and Z directions for twenty times each
Resistance 10 to 55 Hz frequency, 0.75 mm 0.030 in
amplitude in X, Y, and Z directions for two hours each
Resistance / malfunction 10 to 55 Hz frequency, 0.35 mm 0.014 in
amplitude in X, Y, and Z directions for twenty times each
Connection terminal Detachable spring-cage terminal European terminal Spring-cage terminal
Enclosure material ABS Die-cast aluminum ABS
Weight Net weight: 320 g approx. Net weight: 1 kg approx. Net weight: 200 g approx.
Notes: 1) Where measurement conditions have not been specied precisely, the
conditions used were an ambient temperature of +20 °C +68 °F.
2) SF-C11 and SF-C13 comply with UL 1998 (Class 2).
3) If several SF-C11 or SF-C13 units are being used in line together, leave a
space of 5 mm 0.197 in or more between each unit. If the units are touching
each other, reduce the rated operating current for safety output in accordance
with the ambient operating temperature as shown in the graphs at right.
4) The life expectancy of the relay varies depending on the type of load, open /
close frequency, ambient conditions and others.
5)
The operation indicator is marked as “Enabling” on the unit for SF-C12.
6) Terminals for utilizing the functions of the SF4B /SF4B-G series are available.
7) Please switch the sliding switch to the PNP side for minus ground and to the
NPN side for plus ground.
Ambient temperature (°C °F)
0
32
1
2
3
4
5
6
35
95
40
104
45
113
50
122
55
131
Rated operation current (A)
1
2
3
4
5
6
Ambient temperature (°C °F)
0
32
35
95
40
104
45
113
50
122
55
131
Rated operation current (A)
Dilating when SF-C11 units
are mounted close together
Dilating when SF-C13 units
are mounted close together

Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
7
Model No.
Item SF-C14EX(-01) (Note 2)
Connectable safety light curtains SF4B /SF4B-G series
Applicable standards IEC 61496-1 (Type 4), EN 55011, EN ISO 13849-1 (Category 4, PLe), IEC 61496 (Type 4), ISO 13849-1 (Category 4, PLe),
JIS B 9704-1 (Type 4), JIS B 9705-1 (Category 4, PLe), ANSI/UL 61496-1 (Type 4), UL 1998 (Class 2)
CE marking directive compliance Machinery Directive, EMC Directive, RoHS Directive
Control category ISO 13849-1 (EN ISO 13849-1, JIS B 9705-1) compliance up to Category 4, PLe standards
Supply voltage 24 V DC ±10 % Ripple P-P 10 % or less
Current consumption 0.2 A or less (Excluding safety light curtain and other external connecting device)
Safety outputs
Safety output 1
Safety output 2
Safety output 3
PNP open-collector transistor 2 outputs × 3 or NPN open-collector transistor 2 outputs × 3 (selectable using a slider switch)
<When PNP output is selected>
• Maximum source current: 200 mA
• Applied voltage: same as supply voltage
(between the safety output and +V)
• Residual voltage: 2 V or less (at 200 mA source current)
<When NPN output is selected>
• Maximum sink current: 200 mA
• Applied voltage: same as supply voltage
(between the safety output and 0 V)
• Residual voltage: 2 V or less (at 200 mA sink current)
Operation mode
(Output operation)
Safety output 1: ON when the safety light curtain is in light receiving condition, OFF when the safety light curtain is in light interrupted condition (Note 3)
Safety output 2: ON when the safety light curtain is in light receiving condition or the muting function is valid
OFF when the safety light curtain is in light interrupted condition and the muting function is invalid (Note 3)
Safety output 3: ON when the emergency stop is invalid, OFF when the emergency stop is valid
Protection circuit
(Short-circuit protection) Incorporated
Response time OFF response: 14 ms or less (Safety output 1 and 2: including the response time of the safety light curtain)
ON response: 90 ms or less (auto-reset) / 140 ms or less (manual reset) (Note 4)
Auxiliary outputs
Auxiliary output 1
Auxiliary output 2
Auxiliary output 3
Auxiliary output 4 (Note 5)
PNP open-collector transistor × 3 or NPN open-collector transistor × 3 (selectable using a slider switch)
<When PNP output is selected>
• Maximum source current: 60 mA
• Applied voltage: same as supply voltage
(between the auxiliary output and +V)
• Residual voltage: 2 V or less (at 60 mA source current)
<When NPN output is selected>
• Maximum sink current: 60 mA
• Applied voltage: same as supply voltage
(between the auxiliary output and 0 V)
• Residual voltage: 2 V or less (at 60 mA sink current)
Operation mode
(Output operation)
Auxiliary output 1: ON when the muting function is invalid, OFF when the muting function is valid
Auxiliary output 2: ON when the override function is invalid, OFF when the override function is valid
Auxiliary output 3: ON when the muting lamp is normal, OFF when the muting lamp is error
Auxiliary output 4: ON when the safety light curtain is in light interrupted condition, OFF when the safety light curtain is in light
receiving condition (Note 5)
Protection circuit
(Short-circuit protection) Incorporated
Muting lamp output Applicable muting lamp: 24 V DC, 3.6 to 30 W (L1, L2 of each unit)
Protection circuit
(Short-circuit protection) Incorporated
PFHD(Note 6) 1.66 × 10-10
MTTFD(Note 6) 100 years or more
Environmental resistance
Protection Enclosure: IP40, Terminal: IP20
Ambient temperature –10 to +55 °C +14 to +131 °F (No dew condensation or icing allowed), Storage: –25 to +70 °C –13 to +158 °F
Ambient humidity 30 to 85 % RH, Storage: 30 to 95 % RH
Dielectric strength voltage 1,000 V AC for one min. between all supply terminals connected together and enclosure
Insulation resistance 20 MΩ, or more, with 500 V DC megger between all supply terminals connected together and enclosure
Vibration resistance 10 to 55 Hz frequency, 0.35 mm 0.014 in double amplitude in X, Y and Z directions for two hours each
Shock resistance 30 G acceleration in X, Y and Z directions three times each
Material Enclosure: ABS
Connection terminal Detachable spring-cage terminal
Weight Net weight: 250 g approx.
SPECIFICATIONS
Notes: 1) Where measurement conditions have not been specied precisely, the conditions used were an ambient temperature of +20 °C +68 °F.
2) The handy-controller SFB-HC (optional) cannot be used with SF-C14EX-01.
3) Both safety output 1 and 2 are OFF when the emergency stop is valid regardless of whether the safety light curtain is in the light receiving or light
interrupted condition.
4) The auto-reset cannot be used with safety output 3.
5) The auxiliary output incorporated in the SF4B
/SF4B-G series is output.
6) PFHD: Probability of dangerous failure per hour, MTTFD: Mean time to dangerous failure (in years)

8
Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
SAFETY LIGHT CURTAIN WIRING DIAGRAMS
Wiring diagram of SF-C11 and SF4B / SF4B-G series or SF2B series (Control Category 4 or 2)
For PNP output (minus ground)
• Set the safety light curtain input polarity selection switch
to the PNP side and ground the 0 V line.
3
M
+24 V DC
F
A1
A2
0 V
F.G.
T2 T1
K1
K2
KB
KB
KA
KA
N
14 24 34 42
L1 L2 L3
13 23 33 41X1 X2 A B
AUX
L1
NPN
PNP
SF-C11 control circuit
Receiver side
connector
Emitter side
connector
Ui
OUT FAULT INTER_LOCK
FUSE1 FUSE2
RESET
(Note 1)
(Note 2)
TEST
(Note 3)
Safety light curtain input polarity selection switch
KA, KB: Magnet contactor
X3
(Note 1)
Notes: 1) The above diagram is when using manual reset. If automatic reset is
used, disconnect the lead from X2 and connect it to X3. In this case, a
reset (RESET) button is not needed.
2) Use a momentary-type switch as the reset (RESET) button.
3)
Emission halt occurs when the test (TEST) button is open, and emission occurs
when the test (TEST) button is short-circuited. If not using the test (TEST)
button, short-circuit T1 and T2. However, in case of SF2B series, use a test rod
or similar to interrupt the light in order to carry out self-diagnosis separately.
For NPN output (plus ground)
• In the above
diagram, set
the safety light
curtain input
polarity selection
switch to the NPN
side and ground
the + side.
Wiring diagram of SF-C12 and SF4B / SF4B-G series (Control Category 4)
For PNP output (minus ground)
• Set the two safety light curtain input polarity selection switches
to the PNP side and connect the F.G. terminal to the 0 V line.
Interference
prevention wire
Safety output
Power input
24 V DC ±10 %
Auxiliary
output
Emitter side connector
Receiver side connector
Safety light curtain input
polarity selection switches
Emission halt input switch
(Note)
X1
X2
T1
T2
E–
E+
R–
R+
FB1
FB2
FB3
FB4
32
31
24
23
14
13
A1
A2
FG
PNP
NPN
MPCE1
MPCE2
FUSE
FUSE
(Note)
Note: The above diagram is when using manual reset. If automatic reset is
used, connect a normal close-type pushbutton switch between T1 and
T2 and leave between X1 and X2 open.
For NPN output (plus ground)
• In the above diagram, set the two safety light curtain
input polarity selection switches to the NPN side and
connect the F.G. terminal to the + side.
When connecting the SF-C11 to the safety light curtains, make
sure to use the 8-core connection cable with a connector. Refer
to the SF4B / SF4B-G series and SF2B series for details.
SFB-CB□, SF2B-CB□, SFB-CCJ10□
+24 V DC
F
A1
A2
0 V
F.G. X1 X2 X3 A B
NPN
PNP
SF-C11 control circuit
Receiver side
connector
Emitter side
connector
Ui
FAULT INTER_LOCK
RESET
Safety light curtain input
polarity selection switch
T2 T1 AUX
OUT
TEST
Terminal arrangement diagram
Terminal Function
A1 +24 V DC
A2 0 V
13-14, 23-24, 33-34
Safety output (NO contact × 3)
41-42
Auxiliary output (NC contact × 1)
X1 Reset output terminal
X2
Reset input terminal (Manual)
X3 Reset input terminal (Automatic)
ANot used
B
T1 Test output terminal
T2 Test input terminal
AUX
Semiconductor auxiliary output
Pin layout for safety light curtain connectors
1
8
7
6
5
4
3
2
Connector
pin No.
Emitter side
connector
Receiver side
connector
1
Interlock (Note) OSSD2
2
+24 V DC +24 V DC
3
Emission halt OSSD1
4
Auxiliary output EDM (External relay monitor)
5
Synchronization wire +
Synchronization wire +
6
Synchronization wire –
Synchronization wire –
7
0 V 0 V
8
Shielded wire Shielded wire
Note: It is not used with the SF2B series.
When connecting the SF-C12 to the safety light curtains, make
sure to use the 12-core connection cable with a connector.
Refer to the SF4B / SF4B-G series for details.
SFB-CB05-MU (Cable length: 0.5 m 1.640 ft)
SFB-CCJ10E-MU (Extension cable for emitter, cable length: 10 m 32.808 ft)
SFB-CCJ10D-MU (Extension cable for receiver, cable length: 10 m 32.808 ft)
Terminal arrangement diagram
X1
X2 T1 T2 E
-
E+ R
-
R+
FB1 FB2 FB3 FB4
32 31 24 23 14 13 A1 A2
FG
Pin layout for safety light curtain connectors
110 2
3
11
4
5
6
7
8
12
9
Note: Input and
output for pin
Nos.
11
and
12
are not
used by this
product
Terminal Function
FG
Frame ground (F.G.) terminal
A2 0 V
A1 +24 V DC
13-14, 23-24
Safety output (NO contact × 2)
31-32
Auxiliary output (NC contact × 1)
FB4
External relay monitor
terminal 2
FB3
FB2
External relay monitor
terminal 1
FB1
Terminal Function
R+
Interference prevention wire – (Receiver side)
R –
Interference prevention wire + (Receiver side)
E+
Interference prevention wire – (Emitter side)
E –
Interference prevention wire + (Emitter side)
T2 Emission halt input
terminal
T1
X2
Automatic reset/manual reset selection terminal
Manual reset: X1 – X2 short-circuited
X1
Connector
pin No.
Emitter side
connector
Receiver side
connector
1
Interlock OSSD2
2
+24 V DC +24 V DC
3
Emission halt OSSD1
4
Auxiliary output EDM (External relay monitor)
5
Synchronization wire + Synchronization wire +
6
Synchronization wire – Synchronization wire –
7
0 V 0 V
8
Shielded wire Shielded wire
9
Interference prevention wire + Interference prevention wire +
10
Interference prevention wire – Interference prevention wire –
11
(Override input) (Muting input 1)
12
(Muting lamp output) (Muting input 2)

Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
9
SAFETY LIGHT CURTAIN WIRING DIAGRAMS
Wiring diagram of SF-C13 and SF4B / SF4B-G series or SF2B series (Control Category 4 or 2)
• Connect the safety light curtain control outputs OSSD1
and OSSD2 to S1 and S2 respectively.
For PNP output (minus ground)
• Connect the safety light curtain control outputs OSSD1 and
OSSD2 to S4 and S2 respectively and ground the + side.
For NPN output (plus ground)
0 V
Open
KA, KB: Magnet contactor
3
M
F
A1
A2 AUX
F.G.
K1
K2
KB
KA
N
14 24 34 42
13 23 33 41
L1
SF-C13 control circuit
Ui
OUT FAULT INTER_LOCK
FUSE1 FUSE2
X1 X2 X3S1 S4S2 S3
RESET
(Note 1, 2)
KB
KA
L1L2L3
Emitter Receiver
OSSD1 (Black)
OSSD2 (White)
External device monitoring input (Yellow-green)
Output
polarity
setting wire
(Shield) (Note 5)
0 V (Blue)
(Note 1)
Interlock setting input
(Pale purple) (Note 4)
Auxiliary output
(Yellow-green /
Black)
Emission halt
input / Reset input
(Pink) (Note 3)
Output
polarity
setting wire
(Shield) (Note 5)
+V (Brown)
+V
(Brown)
(Orange / Black) Synchronization –
(Orange)
Synchronization +
+24 V DC
Load
0 V
(Blue)
Cable color: Gray
Cable color: Gray with black lin
e
F
A1
A2 AUX
0 V
K1
K2
KB
KB
KA
KA
N
14 24 34 42
L1L2L3
13 23 33 41
L1
SF-C13 control circuit
Ui
OUT FAULT INTER_LOCK
FUSE1 FUSE2
X1 X2 X3S1 S4S2 S3
RESET
(Note 1, 2)
Emitter Receiver
OSSD2 (White)
OSSD1 (Black)
External device monitoring input (Yellow-green)
Output
polarity
setting wire
(Shield)
(Note 5)
0 V
(Blue)
Interlock setting input
(Pale purple) (Note 4)
Open
Auxiliary output
(Yellow-green /
Black)
Emission halt
input / Reset input
(Pink) (Note 3)
Output
polarity
setting wire
(Shield) (Note 5)
0 V
(Blue)
+V (Brown)
Cable color: Gray
+V (Brown)
(Orange / Black) Synchronization –
(Orange)
Synchronization +
KA, KB: Magnet contactor
+24 V DC
(Note 1)
Load
F.G.
3
M
Cable color: Gray with black line
Notes: 1) The above diagram is when using manual reset. If automatic reset
is used, disconnect the lead from X2 and connect it to X3. In this
case, a reset (RESET) button is not needed.
2) Use a momentary-type switch as the reset (RESET) button.
3) This is a test input (pink) for the SF2B series.
4) This is not equipped on the SF2B series.
5) This is a shield for the SF2B series.
When connecting the SF-C13 to the safety light curtains, make
sure to use a discrete wire connection cable. Refer to the SF4B
/ SF4B-G series and SF2B series for details.
SFB-CCB□(-MU), SF2B-CCB□, SFB-CC□(-MU)
Notes: 1) The above diagram is when using manual reset. If automatic reset
is used, disconnect the lead from X2 and connect it to X3. In this
case, a reset (RESET) button is not needed.
2) Use a momentary-type switch as the reset (RESET) button.
3) This is a test input (pink) for the SF2B series.
4) This is not equipped on the SF2B series.
5) This is a shield for the SF2B series.
Terminal arrangement diagram
A1
A2
S1
S2
S3
S4
AUX
X1
X2
X3
13
14
23
24
33
34
41
42
Terminal Function
A1 +24 V DC
A2 0 V
S1 to S4 Safety light curtain control output
(OSSD) input terminal
AUX Semiconductor auxiliary output
X1 Reset output terminal
X2 Reset input terminal (Manual)
X3 Reset input terminal (Automatic)
13-14,
23-24,
33-34
Safety output (NO contact × 3)
41-42 Auxiliary output (NC contact × 1)
Use a separate terminal block to carry out wiring
for safety light curtains that cannot be connected
to the SF-C13.

10
Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
SAFETY LIGHT CURTAIN WIRING DIAGRAMS
Wiring diagram of SF-C14EX(-01) and SF4B / SF4B-G series (Control Category 4)
For PNP output (minus ground)
• Set the output polarity selection switch to the PNP side and ground the 0 V line.
• When connecting the SF-C14EX to
the safety light curtains, make sure to
use the following connecting cable.
SFB-CB05-EX (Cable length: 0.5 m 1.640 ft)
SFB-CB5-EX (Cable length: 5 m 16.404 ft)
SFB-CB10-EX (Cable length: 10 m 32.808 ft)
• If the NO (Normally Open) contact
switch is used as a muting sensor,
wire it as shown in the gure below.
S3+S3–S4S4
+S
4– S3
• If the emergency stop switch is
not used, short-circuit between the
terminals S11 to S12 and S21 to S22
directly.
PNP
NPN
A1
S11 S21 X11S22 X12 X22 X23 AUX2AUX1 X32 IE+ IE– IR– IR+X31 AUX3 AUX4 X21X13S12
A2 S3+ S3– S4S4+ S4– O1 O2 L2– L2+L1– 34 44 6454 L1+ 14 24T2T1 S3
Receiver side
connector
Emitter side
connector
Emergency
stop switch
0 V
PLC etc.
SF-C14EX(-01) control circuit
KFKDKB
KEKCKA
0 V
+V OUT 0V +V OUT 0V
Muting sensor 1
(PNP output type)
Muting sensor 2
(NPN output type)
Output polarity
selection switch
F.G.
Muting lamp
output 2
3.6 to 30 W KA
to KF: Force-guided relay or
magnet contactors.
Override input
Muting lamp
output 1
3.6 to 30 W
+24 V DC
TEST
KE
KF
KC
KD
KA
KB
(Note 1)(Note 1)
RESET
(Note 2)
RESET
(Note 2)
RESET
(Note 2)
Notes: 1) The above diagram is when using manual reset. If automatic reset is used, disconnect the lead from X12 and X22, and connect them to X13 and X23 as
shown by the dotted lines. In this case, a reset (RESET) button is not needed. Terminals X31 to X32 are for manual reset only.
2) Use a momentary-type switch for the reset (RESET) button.
For NPN output (plus ground)
• Set the output polarity selection switch to the NPN side and ground the + side of the power supply input.
Notes: 1) The left diagram is when using manual reset. If automatic
reset is used, disconnect the lead from X12 and X22, and
connect them to X13 and X23 as shown by the dotted
lines. In this case, a reset (RESET) button is not needed.
Terminals X31 to X32 are for manual reset only.
2) Use a momentary-type switch for the reset (RESET) button.
Terminal arrangement diagram
PNP
NPN
A1
S11 S21 X11S22 X12 X22 X23 AUX2AUX1 X32 IE+ IE– IR– IR+X31 AUX3 AUX4 X21X13S12
A2 S3+ S3– S4S4+ S4– O1 O2 L2–L2+L1– 34 44 6454 L1+ 14 24T2T1 S3
Receiver side
connector
Emitter side
connector
Emergency
stop switch
+24 V DC
0 V
SF-C14EX(-01) control circuit
KFKDKB
KEKCKA
24 V
+V OUT 0V +V OUT 0V
PLC etc.
Output polarity
selection switch
F.G.
KA to KF: Force-guided relay or
magnet contactors.
Override input
Muting lamp
output 1
3.6 to 30 W
Muting lamp
output 2
3.6 to 30 W
Muting sensor 1
(PNP output type)
Muting sensor 2
(NPN output type)
TEST
KE
KF
KC
KD
KA
KB
(Note 1)(Note 1)
RESET
(Note 2)
RESET
(Note 2)
RESET
(Note 2)
1
8
7
6
5
4
3
2
Pin layout for safety light curtain connectors
Connector
pin No.
Emitter side
connector
Receiver side
connector
1
Interference
prevention wire +
Interference
prevention wire +
2
+24 V DC +24 V DC
3
Interference
prevention wire –
Interference
prevention wire –
4
Auxiliary output Not used
5
Synchronization
wire +
Synchronization
wire +
6
Synchronization
wire –
Synchronization
wire –
7
0 V 0 V
8
Shielded wire Shielded wire
Terminal Function Terminal Function
14 Safety output 1, Light received
/ Light interrupted output of
the safety light curtain
S11
Emergency stop
contact input
2 NC input
Between S11 and S12
Between S21 and S22
24
S12
34 Safety output 2, Safety light
curtain output including the
muting function
S21
44 S22
54 Safety output 3
Emergency stop output
X11
Safety output 1 reset input
X11 - X12: Manual reset
X11 - X13: Auto-reset
64
X12
S3+
Muting sensor input 1
(PNP output type)
S3+, S3–: Power supply
S3: Sensor output
X13
S3 X21
Safety output 2 reset input
X21 - X22: Manual reset
X21 - X23: Auto-reset
S3– X22
S4+
Muting sensor input 2
(NPN output type)
S4+, S4–: Power supply
S4: Sensor output
X23
S4 X31
Safety output 3 reset input
X31 - X32: Manual reset
S4– X32
T1 Test input terminal
Open: Test mode
Short-circuit: Normal operation
AUX1 Auxiliary output 1, Muting output
T2 AUX2 Auxiliary output 2, Override output
O1 Override input terminal
Open: Invalid
Short-circuit: Valid
AUX3 Auxiliary output 3, Blown lamp output
O2 AUX4 Auxiliary output 4, Safety light curtain auxiliary output
L1+
Muting lamp output 1 IE+
Interference prevention terminal, Emitter side +
L1– IE– Interference prevention terminal, Emitter side –
L2+
Muting lamp output 2 IR+
Interference prevention terminal, Receiver side +
L2– IR– Interference prevention terminal, Receiver side –
A1 +24 V DC
A2 0 V

Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
11
Part description and function [SF-C14EX(-01)]
Digital indicator (Red)
Emitter side connector
Output polarity
selection switch
Interlock 3 indicator
(INTER LOCK3)(Yellow)
Auxiliary output 3
indicator (AUX3)(Orange)
Interlock 2 indicator
(INTER LOCK2)(Y
ellow)
Auxiliary output 2
indicator (AUX2)(Orange)
Interlock 1 indicator
(INTER LOCK1)(Y
ellow)
Auxiliary output 1
indicator (AUX1)(Orange)
Receiver side connector
Test input indicator
(TEST)(Yellow)
Muting sensor 2
indicator (MU2)(Orange)
Safety output 3 indicator (OUT3)(Green)
Muting sensor 1
indicator (MU1)(Orange)
Safety output 2 indicator (OUT2)(Green)
Power indicator (Ui)
(Green)
Safety output 1 indicator
(OUT1)(Green)
1
8
3
4
5
6
7
9
10
2
15
12
11
13
16
14
17
No. Description Function
1
Emitter side connector
The emitter of SF4B /SF4B-G series is connected.
2
Receiver side connector
The receiver of SF4B /SF4B-G series is connected.
3
Digital indicator (Red)
Lights up or blinks when there is a problem.
Lights up when blanking function is enabled.
4
Power indicator (Ui) (Green) Lights up when the power is ON.
5
Test input indicator (TEST) (Yellow)
Lights up when test input is enabled.
Blinks while communication with
SFB-HC (optional) handy-controller is
in progress. (Excluding SF-C14EX-01)
6
Muting sensor 1 indicator (MU1) (Orange) Lights up when muting sensor 1 is ON.
7
Muting sensor 2 indicator (MU2) (Orange) Lights up when muting sensor 2 is ON.
8
Safety output 1 indicator (OUT1) (Green) Lights up when safety output 1 is ON.
9
Safety output 2 indicator (OUT2) (Green) Lights up when safety output 2 is ON.
10
Safety output 3 indicator (OUT3) (Green) Lights up when safety output 3 is ON.
11
Output polarity selection switch
PNP (minus ground) or NPN
(plus ground) can be selected. The
factory setting is PNP (minus ground).
12
Auxiliary output 1 indicator (AUX1) (Orange) Lights up when auxiliary output 1 is ON.
13
Auxiliary output 2 indicator (AUX2) (Orange) Lights up when auxiliary output 2 is ON.
14
Auxiliary output 3 indicator (AUX3) (Orange) Lights up when auxiliary output 3 is ON.
15
Interlock 1 indicator (INTER LOCK1) (Yellow) Lights up when interlock 1 is ON.
16
Interlock 2 indicator (INTER LOCK2) (Yellow) Lights up when interlock 2 is ON.
17
Interlock 3 indicator (INTER LOCK3) (Yellow) Lights up when interlock 3 is ON.
Wiring
• The following solid wire and twisted wires (lead wire) are
recommended.
SF-C11
Power supply and output line connector: 0.2 to 2.5 mm2
(AWG24 to 12)
Signal line connector: 0.2 to 1.5 mm2(AWG24 to 16)
SF-C13
Single wire: ø0.4 to ø1.2 mm ø0.016 to ø0.047 in
(AWG26 to 16)
Twisted wire (lead wire): 0.3 to 1.25 mm2(AWG22 to 16)
SF-C14EX(-01)
Power supply line connector (A1, A2): 0.2 to 2.5 mm2
(AWG24 to 12)
Other connectors: 0.2 to 1.5 mm2(AWG24 to 16)
Output waveform (Safety output ON) [SF-C14EX(-01)]
• When safety output is ON, self-diagnosis of the output
circuit is carried out, so that the output transistor will
periodically turn OFF. (OFF pulse width: 100 µs or less)
When the OFF signal is fed back, the receiver judges the
output circuit as normal. When the OFF signal is not fed
back, the receiver judges either the output circuit or wiring
as error, and the safety output maintains OFF status.
Since the OFF signal of SF-C14EX(-01) might cause
malfunction, perform the connecting paying attention
to the input response time of the machine to be
connected to SF-C14EX(-01).
Time chart [SF-C14EX(-01)]
• The diagram shows operation with safety outputs 1 and 2
in manual-reset mode.
Light received
Light interrupted
Safety
light curtain
Invalid
Valid
Emergency stop
ON
OFF
Muting sensor 1
ON
OFF
Muting sensor 2
ON
OFF
Reset input 1
ON
OFF
Reset input 2
ON
OFF
Reset input 3
ON
OFF
Safety output 1
(14, 24)
ON
OFF
Safety output 2
(34, 44)
ON
OFF
Safety output 3
(54, 64)
ON
OFF
ON
OFF
ON
OFF
Muting lamp
output 1 / 2
0 to 3 sec.
Auxiliary output 4
(Auxiliary output of safety light curtain)
Auxiliary output 1
(Muting output)
0 to 3 sec.
• The diagram above is the timing chart of SF-C14EX(-01)
in normal operation.
• In normal operation, auxiliary output 2 (override output) is
maintained in the ON state.
• In normal operation, auxiliary output 3 (muting lamp
output) is maintained in the ON state.
Normal operation
PRECAUTIONS FOR PROPER USE

12
Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
Light received
Light interrupted
Safety
light curtain
ON
OFF
Muting
sensor 1
ON
OFF
Muting
sensor 2
ON
OFF
Safety output 2
(34, 44)
ON
OFF
ON
OFF
ON
OFF
Muting lamp
output 1
ON
OFF
Muting lamp
output 2
Blown lamp Blown lamp
Blown lamp
Auxiliary output 1
(Muting output)
Auxiliary output 3
(Blown lamp output)
• The lamps are monitored during muting state, and if
either of them breaks, auxiliary output 3 is turned OFF.
If only one lamp breaks, the muting state is maintained,
however, if both lamps break, the muting state is
canceled immediately.
• The electronic fuse is not meant to be used for equipment
that is operated continuously. Note that the specication
may not be satised by continuous operation.
• Make sure to carry out the wiring in the power supply off
condition.
• Wrong wiring will damage the product.
• Verify that the supply voltage variation is within the
rating. Note that if a voltage exceeding the rated range is
applied, or if an AC power supply is directly connected,
the unit may get burnt or damaged.
• The DC power supply unit must satisfy the conditions
given below:
1) Power supply unit authorized in the region where this
device is to be used.
2)
Power supply unit conforming to EMC Directive and Low-
voltage Directive (In case CE conformity is required.)
3) Power supply unit conforming to the Low-voltage
Directive and with an output of 100 VA or less.
4) The frame ground (F.G.) terminal must be connected
to ground when using a commercially available
switching regulator.
5) Power supply unit with an output holding time of 20 ms
or more.
6)
Use an isolation transformer for the DC power supply unit.
7) If surges are likely to occur, take countermeasures such
as connecting a surge absorber to the origin of the surge.
8) Power supply unit corresponding to CLASS 2 (In case
UL/c-UL conformity is required.)
<Additional information>
As provided in IEC 60536 (CLASS: Protection against
Electric Shook), this power supply should require no
ground earth and satisfy the insulation distance by double
insulation or reinforced insulation.
If the power supply conforms to Low-voltage Directive
and has an output of 100 VA or less, it can be used as
a suitable product.
• Do not run the wires together with high-voltage lines or
power lines or put them in the same raceway. This can
cause malfunction due to induction.
• This product is not dust-proof / splash proof. Be sure to put
this product into a control box having IP54 construction.
(Excluding SF-C12)
• Avoid dust, dirt and steam.
•Take care that the product does not come in direct contact
with oil, grease, or organic solvents, such as, thinner, etc.
• Note that this equipment is applicable only in the control
circuit grounded in accordance with IEC 60204-1 and
JIS B 9960-1, or in the control circuit in which the insulation
monitor unit (ground fault detection unit) is included.
• This unit is suitable for indoor use only.
• The seal as shown in the drawing on the below is stuck
to the engagement point of unit. If the seal is peeled off
or broken, SF-C10 series will not be certied as “Safety
equipment” and will not be covered by our guarantee.
Do not open!
If this seal is removed or damaged,
the units are not recognized as safety product.
Open
Short-circuited
Test input
Valid
Invalid
Override input
Light received
Light interrupted
Safety
light curtain
ON
OFF
Muting sensor
1 / 2
ON
OFF
Safety output 1
(14, 24)
ON
OFF
Safety output 2
(34, 44)
ON
OFF
ON
OFF
ON
OFF
Muting lamp
output 1 / 2
Override input time: Max. 60 sec.
0 to 1 sec.
Auxiliary output 1
(Muting output)
Auxiliary output
2
(Override output)
3 sec.
• Safety outputs 1 and 2 are OFF during test input.
• The override function becomes valid when all the
conditions listed below are satised:
•An incandescent lamp with 3.6 to 30 W is at least connected to
either muting lamp output 1 or 2.
• The signal is input to either muting sensor 1 or 2.
•The override input terminal O1 and O2 is short-circuited and
the test input terminal T1 / T2 is opened within 1 sec. (3 sec.
continuously)
If one of the three conditions above becomes invalid
or the timing exceeds 60 sec., the override function
becomes invalid.
Test input, Override input
• The diagram shows operation with safety outputs 1 and 2
in auto-reset mode.
Blown lamp output
• The diagram shows operation with safety outputs 1
and 2 in auto-reset mode.
Time chart [SF-C14EX(-01)]
PRECAUTIONS FOR PROPER USE
Others
• This device has been developed / produced for industrial
use only.
• When connecting this product to a product other than the
connectable input device, the system does not conform to
the control category 4 based on ISO 13849-1
(EN ISO 13849-1, JIS B 9705-1).
• The power supply unit of SF-C10 series uses the
electronic fuse which does not require any replacement.
• When the electronic fuse trips, turn off the power supply
and eliminate the cause for the overcurrent. After that,
turn the power back on.

Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES
13
Control unit
SF-C11 Control unit SF-C12
10
0.394
Suitable for 35 mm 1.378 in width DIN rail
54.1
2.130
40
1.575
25
0.984
4
0.157
80
3.150
6.5
0.256
130
5.118
67.3
2.650
( )
100
3.937
35
1.378
Emitter side
connector
46
1.811
23
0.906
11.5
0.453
13
0.512
3 × 6 = 18
3 × 0.236 = 0.709
6
0.236
48.8
1.921
Receiver
side
connector
21
0.827
3.2
0.126
6
0.236
7 0.276
8 0.315
8
0.315
19.5
0.768
22
0.866
24.5
0.965
30.5
1.201
30
1.181
2-ø10 ø0.394
2-ø6 ø0.236
36.5
1.437
36.5
1.437
67.5
2.657
81.4
3.205
130
5.118
135
5.315
( )
6
0.236
114
4.488
80
3.150
127
5.000
34.2
1.346
28
1.102
Application expansion unit
SF-C14EX(-01)
Control unit
SF-C13
13.5
0.531
10
0.394
4
0.157
6.5
0.256
80
3.150
80.8
3.181
Suitable for 35 mm 1.378 in width DIN rail
6
0.236
5
0.197
6.75
0.266
3 × 5 = 15
3 × 0.197 = 0.591
5
0.197
13
0.512 22.5
0.886
130
5.118
67.3
2.650
35
1.378
91.6
3.606
34.5
1.358
10
0.394
54.1
2.130
40
1.575
4 0.157
25
0.984
Suitable for 35 mm 1.378 in width DIN rail
6.5
0.256
Emitter side
connector
Receiver
side
connector
11
0.433
18
0.709
46
1.811
38.4 1.512
18.4
0.724
23 0.906
130
5.118
67.3
2.650
35
1.378
80
3.150
99
3.898
( )
34.1
1.343 13
0.512
31.1
1.224
DIMENSIONS (Unit: mm in)The CAD data can be downloaded from our website.

Disclaimer
Theapplicationsdescribedinthecatalogareallintendedforexamplesonly.Thepurchaseofourproductsdescribedinthecatalogshallnotbe
regardedasgrantingofalicensetouseourproductsinthedescribedapplications.WedoNOTwarrantthatwehaveobtainedsome
intellectualproperties,suchaspatentrights,withrespecttosuchapplications,orthatthedescribedapplicationsmaynotinfringeany
intellectualpropertyrights,suchaspatentrights,ofathirdparty.
PrintedinJapan
IndustrialDeviceBusinessDivision
7-1-1,Morofuku,Daito-shi,Osaka574-0044,Japan
industrial.panasonic.com/ac/e/
ⓒ PanasonicIndustryCo.,Ltd. Specificationsaresubjecttochangewithoutnotice. 2022.5
PanasonicIndustryCo.,Ltd.
