Getting Started
OPERATING INSTRUCTIONS
Personal Computer
Model No. CF-30 series
Introduction................................................................. 2
Read Me First............................................................. 3
Description of Parts ..................................................10
Appendix
Specications ...........................................................13
Please read these instructions carefully before using this product and save this manual for future use.
Getting StartedAppendix

2
Getting Started
Introduction
Thank you for purchasing this Panasonic computer. For optimum performance and safety, please read these instruc-
tions carefully.
nTerms and illustrations in these instructions
CAUTION : Conditions that may result in minor or moderate injury.
NOTE : Useful and helpful information.
Enter
: Press [Enter] key.
Fn
+
F5
: Press and hold [Fn] key, and then press [F5] key.
(Start) - [All Programs] : Click (Start), and then click [All Programs].
è: Page in these Operating Instructions or in the Reference Manual.
: Reference to the on-screen manuals.
l Someillustrationsaresimpliedtohelpyourunderstandingandmaylookdifferentfromtheactualunit.
lIf you do not log on as an administrator, you cannot use some functions or cannot display some screens.
lRefer for the latest information about optional products to the catalogs, etc.
lIn these instructions, the names and terms are referred as follows.
“Windows Vista®Business” as “Windows” or “Windows Vista”
DVD-ROM & CD-R/RW drive and DVD MULTI drive as “CD/DVD drive”
Circular media including DVD-ROM and CD-ROM as “discs”
lThe display modes are referred as follows. ( ) indicates the terms in [Intel®Graphics Media Accelerator Driver for
Mobile] screen. To display the screen, right-click the desktop and click [Graphics Properties].
Internal LCD (Notebook): The computer’s display
External display (Monitor): External display
Simultaneous display (Intel® Dual Display Clone): The same screen is displayed on the internal LCD and the
external display.
Extended desktop: The extended working area across the internal LCD and the external display.
nDisclaimer
Computerspecicationsandmanualsaresubjecttochangewithoutnotice.PanasonicCorporationassumesnoli-
ability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the
manuals.
nTrademarks
Microsoft®, Windows®, Windows Vista, the Windows logo,and IntelliMouse are registered trademarks of Microsoft Cor-
poration of the United States and/or other countries.
Intel, Core, Centrino and PROSet are either registered trademarks or trademarks of Intel Corporation.
SDHC Logo is a trademark.
Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorpo-
rated in the United States and/or other countries.
Computrace®is a registered trademark of Absolute®Software Corp.
PhoenixBIOS is a trademark and/or registered trademark of Phoenix Technologies Ltd.
Bluetooth ™ is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Panasonic Corporation.
Panasonic®is a registered trademark of Panasonic Corporation.
Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective
own companies.

3
Getting Started
Read Me First
Models for U.S.A.
Federal Communications Commission Radio Fre-
quency Interference Statement
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separation between the equipment and
receiver.
lConnect the equipment into an outlet on a circuit dif-
ferent from that to which the receiver is connected.
lConsult the Panasonic Service Center or an experi-
enced radio/TV technician for help.
Warning
To assure continued compliance, use only shielded in-
terface cables when connecting to a computer or periph-
eral.Also,anychangesormodicationsnotexpressly
approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
FCC RF Exposure Warning:
l
This equipment is provided with PC Card slot that could
beusedwithwirelesstransmitters,whichwillbespeci-
cally recommended when they become available.
Other third-party wireless transmitters have not been RF
exposure evaluated for use with this computer and may
not comply with FCC RF exposure requirements.
<Only for model with wireless LAN/wireless WAN/Bluetooth>
lThis equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
l
This equipment has been approved for mobile operation,
and unless otherwise advised in separate supplemental
instructions for individual wireless transmitter(s), requires
minimum 20 cm spacing be provided between antenna(s)
and all person’s body (excluding extremities of hands,
wrist and feet) during wireless modes of operation.
l
This equipment may use multiple installed transmitters,
which may be capable of simultaneous transmission.
l
This equipment is provided with external antenna
connector(s) for connection to optional Car Mounter or
Port Replicator for mobile external mounted antenna(s).
External antenna(s) must be professionally installed and
cannot exceed recommended maximum antenna gain as
described in individual provided supplement instructions
for wireless transmitters. Also, user must maintain mini-
mum 20 cm spacing between external antenna(s) and all
person’s body (excluding extremities of hands, wrist and
feet) during wireless modes of operation.
25-M-3-3
<Only for model with wireless LAN>
This product is restricted to indoor use due to its operation in the
5.15 to 5.25 GHz frequency range. FCC requires this product to be
used indoors for the frequency range 5.15 to 5.25 GHz to reduce
the potential for harmful interference to co-channel Mobile Satellite
systems. High power radars are allocated as primary users of the
5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar sta-
tions can cause interference with and/or damage this product.
25-M-W-1
This device complies with Part 15 of the FCC Rules. Op-
eration is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired op-
eration.
Responsible Party: Panasonic Corporation of North America
One Panasonic Way
Secaucus, NJ 07094
Tel No:1-800-LAPTOP5 (1-800-527-8675)
6-M-1
FCC Regulation Notice for modem
This equipment contains a FCC approved modem.
1. This equipment complies with CFR47 Part 68 rules.
On the computer is a label that contains, among other
information, the FCC registration number and ringer
equivalence number (REN) for this equipment. If re-
quired, this information must be provided to the tele-
phone company.
2. An FCC compliant telephone cord and modular plug
is provided with this equipment. This equipment is
designed to be connected to the telephone network
or premises wiring using a compatible modular jack
which is Part 68 compliant. See Installation Instruc-
tions for details.
3. The REN is used to determine the quantity of devices
which may be connected to the telephone line. Ex-
cessive RENs on the telephone line may result in the
devices not ringing in response to an incoming call. In
most, but not all area, the sum of RENs should not ex-
ceedve(5.0).Tobecertainofthenumberofdevices
that may be connected to a line, as determined by the
total RENs, contact the local telephone company.
4. If your telephone equipment cause harm to the tele-
phone network, the telephone company will notify you
in advice that temporary discontinuance of service
may be required. But if advice notice isn’t practical, the
telephone company will notify the customer as soon
as possible. Also, you will be advised of your right to
leacomplaintwiththeFCCifyoubelieveitisneces-
sary.
5. The telephone company may take changes in its facili-
ties, equipment, operations or procedures that could
affect the operation of the equipment. If this happens
the telephone company will provide advance notice
inorderforyoutomakenecessarymodicationsto
maintain uninterrupted service.
6. If trouble is experienced with this equipment, for repair
or warranty information, please contact Panasonic
Corporation of North America at DIAL TOLL FREE
1-800-LAPTOP5 (1-800-527-8675). If the equipment is
causing harm to the telephone network, the telephone
company may request that you disconnect the equip-
ment until the problem is resolved.
7. There are no user serviceable parts contained in this
equipment.
8. This equipment may not be used on coin service pro-
vided by the telephone company. Connection to party
lines is subject to state tariffs.

4
Getting Started
Read Me First
9. The Telephone Consumer Protection Act of 1991 makes
it unlawful for any person to use a computer or other
electronic device to send any message via a telephone
fax machine unless such message clearly contains in a
margin at the top or bottom of each transmitted page or
ontherstpageofthetransmission,thedateandtime
itissentandanidenticationofthebusinessorother
entry, or other individual sending the message and
the telephone number of the sending machine or such
business, other entity, or individual. In order to program
this information into your fax software, you should refer
to the manual of the Fax software being used.
10.According to the FCC’s electrical safety advisory, we
recommend that you may install an AC surge arrestor
in the AC outlet to which this equipment is connected.
Telephone companies report that electrical surges,
typically lightning transients, are very destructive to
customer terminal equipment connected to AC power
sources and that this is a major nationwide problem.
 “Caution:Toreducetheriskofre,useonlyNo.26AWGor
larger telecommunication line cord.”
“ATTENTION : Pour réduire le risque d’incendie, utiliser
uniquement des conducteurs de télécommunications 26
AWG ou de section supérieure.”
16-M-1
NOTICE for the products using LCD
Thisproducthasauorescentlampthatcontainsmercury.
Disposal may be regulated in your community due to envi-
ronmental considerations.
For disposal or recycling information, please contact your
local authorities, or the Electronic Industries Alliance:
<http://www.eiae.org/>
24-M-2
Models for Canada
Industry Canada (IC) Notice for modem
This equipment contains an Industry Canada approved
modem unit.
TheIndustryCanadalabelisafxedonthemodemunit.
EQUIPMENT ATTACHEMENT LIMITATIONS
“NOTICE:TheIndustryCanadalabelidentiescertied
equipment.Thiscerticationmeansthattheequipment
meets telecommunications network protective, opera-
tional and safety requirements as prescribed in the ap-
propriate Terminal Equipment Technical Requirements
document(s). The Department does not guarantee the
equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that
it is permissible to be connected to the facilities of the
local telecommunications company. The equipment must
also be installed using an acceptable method of connec-
tion. The customer should be aware that compliance with
the above conditions may not prevent degradation of
service in some situations.
Repairstocertiedequipmentshouldbecoordinatedbya
representative designated by the supplier. Any repairs or
alterations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company
cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the elec-
trical ground connections of the power utility, telephone
lines and internal metallic water pipe system, if present,
are connected together. This precaution may be par-
ticularly important in rural areas. Caution: Users should
not attempt to make such connections themselves, but
should contact the appropriate electric inspection author-
ity, or electrician, as appropriate.”
“NOTICE: The Ringer Equivalence Number (REN) assigned
to each terminal device provides an indication of the maxi-
mum number of terminals allowed to be connected to a tele-
phone interface. The termination on an interface may consist
of any combination of devices subject only to the require-
ment that the sum of the Ringer Equivalence Numbers of all
the devices does not exceed 5.”
REN: See bottom of the computer
RESTRICTIONS CONCERNANT LE RACCORDEMENT
DE MATÉRIEL
“AVIS:L’étiquetted’IndustrieCanadaidentielematériel
homologué.Cetteétiquettecertiequelematérielest
conforme aux normes de protection, d’exploitation et de
sécurité des réseaux de télécommunications, comme
le prescrivent les documents concernant les exigences
techniques relatives au matériel terminal. Le Ministère
n’assure toutefois pas que le matériel fonctionnera à la
satisfaction de l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est
permis de le raccorder aux installations de l’entreprise locale
de télécommunication. Le matériel doit également être installé
en suivant une méthode acceptée de raccordement.
L’abonné ne doit pas oublier qu’il est possible que la con-
formité aux conditions énoncées ci-dessus n’empêche
pas la dégradation du service dans certaines situations.
Les réparations de matériel homologué doivent être
coordonnées par un représentant désigné par le fournis-
seur.
L’entreprise de télécommunications peut demander à
l’utilisateur de débrancher un appareil à la suite de répa-
rationsoudemodicationseffectuéesparl’utilisateurou
à cause de mauvais fonctionnement.
Pour sa propre protection, l’utilisateur doit s’assurer que
tousleslsdemiseàlaterredelasourced’énergie
électrique, des lignes téléphoniques et des canalisations
d’eau métalliques, s’il y en a, sont raccordés ensemble.
Cette précaution est particulièrement importante dans les
régions rurales. Avertissement: L’utilisateur ne doit pas
tenter de faire ces raccordements lui-même; il doit avoir
recours à un service d’inspection des installations élec-
triques, ou à un électricien, selon le cas.”
“AVIS: L’indice d’équivalence de la sonnerie (IES) assigné
à chaque dispositif terminal indique le nombre maximal de
terminaux qui peuvent être raccordés à une interface. La
terminaison d’une interface téléphonique peut consister en
une combinaison de quelques dispositifs, à la seule condi-
tion que la somme d’indices d’équivalence de la sonnerie de
touts les dispositifs n’excède pas 5.”
IES: Voir sous le fond de l’ordinateur 17-Ca-1

5
Getting Started
Canadian ICES-003
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada. 7-M-2
<Only for model with wireless LAN/Bluetooth>
Industry Canada
This product complies with RSS210 Industry Canada.
Operation is subject to the following two conditions;
(1) this device may not cause interference, and
(2) this device must accept any interference, including in-
terference that may cause undesired operation of the
device. 30-Ca-1-1
<Only for model with wireless LAN>
This product (local network devices) for the band
5150-5250 MHz is only indoor usage to reduce potential
for harmful interference to co-channel Mobile Satellite
systems.
High power radars are allocated as primary users (mean-
ing they have priority) of 5250-5350 MHz and 5650-5850
MHz and these radars could cause interference and/or
damage to LELAN devices. 30-Ca-2-1
This device has been designed to operate with an anten-
na having a maximum gain of 2.15 dB. Antenna having a
higher gain is strictly prohibited per regulations of Industry
Canada. The Required antenna impedance is 50 ohms.
To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (EIRP) is not more
than that required for successful communication. 25-Ca-1-1
<Only for model with wireless LAN>
RF Exposure Warning
This equipment has been approved for mobile operation,
and unless otherwise advised in separate supplemental
instructions for individual wireless transmitter(s), requires
minimum 20 cm spacing be proved between antenna(s)
and all person’s body (excluding extremities of hands,
wrist and feet) during wireless modes of operation.
<Pour modèlesLANsansluniquement>
Mise en garde concernant l’exposition à l’énergie
radiofréquence
Cet équipement a été homologué pour un fonctionnement
sanslet,saufaviscontraireinclusdanslanoticed’utili-
sationd’unautreémetteursansl,unedistanceminimale
de 20 cm doit être assurée entre l’antenne et le corps
de toute personne (à l’exclusion des mains, poignets et
pieds) pendant le fonctionnementsansl. 25-M-5-1
Models for Europe
<Only for model with a “CE” mark on the bottom of the computer>
Declaration of Conformity (DoC)
“Hereby, we declare that this Personal Computer is in compliance with the essential requirements
and other relevant provisions of the Directive 1999/5/EC.”
Hint:
If you want to get a copy of the original DoC of our products which relates to the R&TTE, please con-
tact our web address: http://www.doc.panasonic.de
Contact and Pursuant to at the directive 2004/108/EC, article 9(2)
Panasonic Testing Centre
Panasonic Service Europe, a division of
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, F.R. Germany
Network connection.
The terminal equipment is intended for connection to the following public network;
In all the countries of European Economical Area;
- Public Switched Telephony Networks
Technical Features.
The terminal equipment includes the following features;
- DTMF dialing
- Maximum bitrate receiving mode: 56 kbit/s
- Maximum bitrate sending mode: 33.6 kbit/s
This product is designed to interwork with the Public Switched Telecommunication Networks in UK, Ireland, Nether-
lands, Sweden, Denmark, Finland, Switzerland, Luxembourg, Belgium, France, Germany, Spain, Portugal, Iceland,
Greece, Italy, Norway and Austria. 18-E-2

6
Getting Started
Read Me First
When using your telephone equipment, basic safety
precautions should always be followed to reduce the risk
ofre,electricshockandinjurytopersons,includingthe
following:
1. Do not use this product near water, for example, near
a bath tub, wash bowl, kitchen sink or laundry tub, in a
wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote risk
of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the
vicinity of the leak.
4. Use only the power cord and batteries indicated in this
manual.Donotdisposeofbatteriesinare.Theymay
explode. Check with local codes for possible special
disposal instructions.
SAVE THESE INSTRUCTIONS
19-E-1
Certaines mesures de sécurité doivent être prises pen-
dantl’utilisationdematérialtéléphoniqueanderéduire
les risques d’incendie, de choc électrique et de blessures.
En voici quelquesunes:
1. Ne pas utiliser l’appareil près de l’eau, p.ex., près
d’une baignoire, d’un lavabo, d’un évier de cuisine,
d’un bac à laver, dans un sous-sol humide ou près
d’une piscine.
2. Éviter d’utiliser le téléphone (sauf s’il s’agit d’un ap-
pareilsansl)pendantunorageélectrique.Cecipeut
présenter un risque de choc électrique causé par la
foudre.
3. Ne pas utiliser l’appareil téléphonique pour signaler
une fuite de gaz s’il est situé près de la fuite.
4. Utiliser seulement le cordon d’alimentation et le type
de piles indiqués dans ce manual. Ne pas jeter les
piles dans le feu: elles peuvent exploser. Se conform-
er aux règlements pertinents quant à l’élimination des
piles.
CONSERVER CES INSTRUCTIONS
19-F-1
Information to the User
<Only for model with wireless LAN/Bluetooth>
This product and your Health
This product, like other radio devices, emits radio fre-
quency electromagnetic energy. The level of energy
emitted by this product however is far much less than the
electromagnetic energy emitted by wireless devices like
for example mobile phones.
Because this product operates within the guidelines found
in radio frequency safety standards and recommenda-
tions, we believe this product is safe for use by consum-
ers.Thesestandardsandrecommendationsreectthe
consensusofthescienticcommunityandresultfrom
deliberations of panels and committees of scientists who
continually review and interpret the extensive research
literature.
In some situations or environments, the use of this prod-
uct may be restricted by the proprietor of the building or
responsible representatives of the organization. These
situations may for example include:
lUsing this product on board of airplanes, or
lIn any other environment where the risk of interference
tootherdevicesorservicesisperceivedoridentied
as harmful.
If you are uncertain of the policy that applies on the use
ofwirelessdevicesinaspecicorganizationorenviron-
ment (e.g. airports), you are encouraged to ask for autho-
rization to use this product prior to turning on the product.
Regulatory Information
We are not responsible for any radio or television interfer-
encecausedbyunauthorizedmodicationofthisproduct.
The correction of interference caused by such unauthor-
izedmodicationwillbetheresponsibilityoftheuser.We
and its authorized resellers or distributors are not liable
for damage or violation of government regulations that
may arise from failing to comply with these guidelines.
26-M-1
Lithium Battery / Pile au lithium
Lithium Battery!
This computer contains a lithium battery to enable the
date, time, and other data to be stored. The battery
should only be exchanged by authorized service person-
nel.
Warning!
A risk of explosion from incorrect installation or misappli-
cation may possibly occur.
15-E-1
Pile au lithium!
Le micro-ordinateur renferme une pile au lithium qui
permet de sauvegarder certaines données, notamment la
date et l’heure. La pile ne doit être remplacée que par un
technicienqualié.
Danger ! Risque d’explosion en cas de non respect de
cette mise en garde!
15-F-1
Important Safety Instructions / Importantes Mesures De Sécurité

7
Getting Started
For Used in Motor Vehicle /Pour L’utilisation Dans Un Véhicule Motorisé
Warning: Notebook Computer may be installed in a mo-
tor vehicle and visible to the driver only if used to support
vehicle related functions such as vehicle information,
system control, rear or side observation and navigation.
If used for entertainment purpose, such as television
reception or video play, it must be installed to the rear
of the driver’s seat where it will not be visible, directly or
indirectly, to the operator of the motor vehicle. Check with
individual state/provincial laws to determine lawful use of
this product while operating within a motor vehicle.
Information on Disposal in other Countries outside the European Union
These symbols are only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask
for the correc method of disposal.
36-M-1
Avertissement : L’ordinateur bloc-notes peut être installé
dans un véhicule motorisé et dans le champ de vision du
conducteur uniquement en tant que dispositif d’aide aux
fonctions du véhicule, comme par exemple pour fournir
des informations sur le véhicule, comme dispositif de
contrôle de système, pour l’observation à l’arrière ou sur
les côtés du véhicule, ainsi que pour fournir de l’informa-
tionroutière.Pourtouteutilisationàndedivertissement,
comme par exemple pour regarder la télévision ou jouer
à des jeux vidéo, il doit être installé à l’arrière du siège du
conducteur, en un emplacement où il ne sera pas visible,
ni directement ni indirectement, pour le conducteur du
véhiculemotorisé.Vériezlesloisfédéralesetnationales
qui régissent l’utilisation légale de cet appareil à l’intérieur
d’un véhicule motorisé.
35-M-1

8
Getting Started
Read Me First
THIS PRODUCT IS NOT INTENDED FOR USE AS, OR AS
PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAF-
FIC CONTROL EQUIPMENT/SYSTEMS, OR AIRCRAFT
COCKPIT EQUIPMENT/SYSTEMS*1. PANASONIC WILL
NOT BE RESPONSIBLE FOR ANY LIABILITY RESULT-
ING FROM THE USE OF THIS PRODUCT ARISING OUT
OF THE FOREGOING USES.
*1 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include
Class2 Electrical Flight Bag (EFB) Systems and Class1
EFBSystemswhenusedduringcriticalphasesofight
(e.g., during take-off and landing) and/or mounted on to
the aircraft. Class1 EFB Systems and 2 EFB Systems are
denedbyFAA:AC(AdvisoryCircular)120-76AorJAA:
JAATGL(TemporaryGuidanceLeaets)No.36.
Panasoniccannotguaranteeanyspecications,technolo-
gies, reliability, safety (e.g. Flammability/Smoke/Toxic-
ity/Radio Frequency Emission, etc) requirements related
toaviationstandardsthatexceedthespecicationsofour
COTS (Commercial-Off-The-Shelf) products. 39-E-1
This computer is not intended for use in medical equipment
includinglife-supportsystems,airtrafccontrolsystems,or
other equipment, devices or systems that are involved with
ensuring human life or safety. Panasonic cannot be held re-
sponsible in any way for any damages or loss resulting from
the use of this unit in these types of equipment, devices or
systems, etc.
The CF-30 was developed based on thorough research into
the real-world portable computing environments. Exhaustive
pursuit of usability and reliability under harsh conditions led
to innovations such has the magnesium alloy exterior, vibra-
tiondampedharddiskdriveandoppydiskdrive,exible
internal connections. The CF-30’s outstanding engineering
has been tested using the strict MIL-STD- 810F (for vibra-
tion and shock) and IP (for dust and water) based proce-
dures.
As with any portable computer device precautions should be
taken to avoid any damage. The following usage and han-
dling procedures are recommended.
Before putting the computer away, be sure to wipe off any
moisture.
If a Malfunction Occurs, Immediately Unplug the AC
Plug and the Battery Pack
This product is damaged
Foreign object inside this product
Smoke emitted
Unusual smell emitted
Unusually hot
Continuing to use this product while any of the above condi-
tionsarepresentmayresultinreorelectricshock.
If a malfunction occurs, immediately turn the power off
and unplug the AC plug, and then remove the battery
pack.Then,contactyourtechnicalsupportofce.
Do Not Touch This Product and Cable When It Starts
Thundering
Electric shock may result.
Do Not Connect the AC Adaptor to a Power Source
Other Than a Standard Household AC Outlet
Otherwise,areduetooverheatingmayresult.Connecting
to a DC/AC converter (inverter) may damage the AC adap-
tor. On an airplane, only connect the AC adaptor/charger to
anACoutletspecicallyapprovedforsuchuse.
Do Not Do Anything That May Damage the AC Cord, the
AC Plug, or the AC Adaptor
Do not damage or modify the cord, place it near hot tools,
bend, twist, or pull it forcefully, place heavy objects on it, or
bundle it tightly.
Continuingtouseadamagedcordmayresultinre,short
circuit, or electric shock.
Do Not Pull or Insert the AC Plug If Your Hands Are Wet
Electric shock may result.
Clean Dust and Other Debris of the AC Plug Regularly
If dust or other debris accumulates on the plug, humidity,
etc. may cause a defect in the insulation, which may result in
are.
Pull the plug, and wipe it with a dry cloth.
Pull the plug if the computer is not being used for a long
period of time.
Insert the AC Plug Completely
Iftheplugisnotinsertedcompletely,reduetooverheating
or electric shock may result.
Do not use a damaged plug or loose AC outlet.
Close the Connector Cover Tightly When Using This
Product Where Is a Lot of Water, Moisture, Steam, Dust,
Oily Vapors, etc.
Theentryofforeignmattermaycauseareorelectric
shocks.
If foreign matter has found its way inside, immediately turn
the power off and unplug the AC cord, and then remove
the battery pack. Then contact your technical support of-
ce.
Do Not Disassemble This Product
There are high-voltage areas inside which may give you an
electric shock if you should touch them. Do not touch the
pins and circuit boards inside, and do not allow foreign mat-
ter to enter inside.
Also,remodelingordisassemblymaycauseare.
Keep SD Memory Cards Away from Infants and Small
Children
Accidental swallowing will result in bodily injury.
In the event of accidental swallowing, see a doctor immedi-
ately.
Do Not Place This Product on Unstable Surface
If balance is lost, this product may fall over or drop, resulting
in an injury.
Avoid Stacking
If balance is lost, this product may fall over or drop, resulting
in an injury.
Do Not Leave This Product in High Temperature Envi-
ronment Such as in a Sun-Heated Car, for a Long Period
of Time
Leaving this product where it will be exposed to extremely
high temperatures such as in a sun-heated car or in direct
sunlight may deform the cabinet and/or cause trouble in the
internal parts. Continued use in such a resulting condition
may lead to short-circuiting or insulation defects, etc. which
mayinturnleadtoareorelectricshocks.
Hold the Plug When Unplugging the AC Plug
Pullingonthecordmaydamagethecord,resultinginare
or electric shock.
Do Not Move This Product While the AC Plug Is Con-
nected
TheACcordmaybedamaged,resultinginreorelectric
shock.
If the AC cord is damaged, unplug the AC plug immedi-
ately.
Use Only the Specied AC Adaptor With This Product
Using an AC adaptor other than the one supplied (attached
to your product or supplied by Panasonic) may result in a
re.
Do Not Subject the AC Adaptor to Any Strong Impact
Using the AC adaptor after a strong impact such as being
droppedmayresultinelectricshock,shortcircuit,orre.
Take a Break of 10-15 Minutes Every Hour
Using this product for long periods of time may have detri-
mental health effects on the eyes or hands.
Precautions

9
Getting Started
Do Not Turn the Volume Up To Loud When Using Head-
phones
Listening at high volumes that overstimulate the ear for long
periods of time may result in loss of hearing.
Use the Modem with a Regular Telephone Line
Connection to an internal phone line (on-premise switches)
ofacompanyorbusinessofce,etc.ortoadigitalpublic
phone or use in a country or area not supported by the com-
putermayresultinareorelectricshocks.
Do Not Connect a Telephone Line, or a Network Cable
Other Than the One Specied, into the LAN Port
If the LAN port is connected to a network such as the ones
listedright,areorelectricshockmayresult.
Precautions (Battery Pack)
Do Not Use With Any Other Product
The battery pack is rechargeable and was intended for the
speciedproduct.Ifitisusedwithaproductotherthanthe
one for which it was designed, electrolyte leakage, genera-
tion of heat, ignition or rupture may result.
Do Not Charge the Battery Using Methods Other Than
Those Specied
Ifthebatteryisnotchargedusingoneofthespecied
methods, electrolyte leakage, generation of heat, ignition or
rupture may result.
Do Not Throw the Battery Pack Into a Fire or Expose It
to Excessive Heat
Generation of heat, ignition or rupture may result.
Avoid Extreme Heat (Near the Fire, In Direct Sunlight, for
Example)
Electrolyte leakage, generation of heat, ignition or rupture
may result.
Do Not Insert Sharp Objects Into the Battery Pack, Ex-
pose It to Bumps or Shocks, Disassemble, or Modify It
Electrolyte leakage, generation of heat, ignition or rupture
may result.
Do Not Short the Positive (+) and Negative (-) Contacts
Generation of heat, ignition or rupture may result. Do not
place the battery pack together with articles such as neck-
laces or hairpins when carrying or storing.
Do Not Use This Product with a Battery Pack Other Than
the One Specied
Useonlythespeciedbatterypack(CF-VZSU46U)withyour
product. Use of battery packs other than those manufactured
and supplied by Panasonic may present a safety hazard
(generation of heat, ignition or rupture).
lDo not touch the terminals on the battery pack. The bat-
tery pack may no longer function properly if the contacts
are dirty or damaged.
lDo not expose the battery pack to water, or allow it to
become wet.
lIf the battery pack will not be used for a long period of
time (a month or more), charge or discharge (use) the
battery pack until the remaining battery level becomes
30% to 40% and store it in a cool, dry place.
lThis computer prevents overcharging of the battery by
recharging only when the remaining power is less than
approx. 95% of capacity.
lThe battery pack is not charged when the computer is
rstpurchased.Besuretochargeitbeforeusingitfor
thersttime.WhentheACadaptorisconnectedtothe
computer, charging begins automatically.
l Shouldthebatteryleakandtheuidgetintoyoureyes,
donotrubyoureyes.Immediatelyushyoureyeswith
clear water and see a doctor for medical treatment as
soon as possible.
Networks other than 1000BASE-T, 100BASE-TX, or
10BASE-T
Phone lines (IP Phone, Telephone lines, internal phone
lines (on-premise switches), digital public phones, etc.)
Do Not Use With Exposing the Skin To This Product For
a Long Period of Time
Using this product with exposing the skin to the heat source
of this product or AC adaptor for a long period of time can
cause a low-temperature burn.
lDo not place the computer near a television or radio
receiver.
lKeep the computer away from magnets. Data stored on
the hard disk may be lost.
NOTE
lThe battery pack may become warm during recharg-
ing or normal use. This is completely normal.
lRecharging will not commence if internal temperature
of the battery pack is outside of the allowable temper-
ature range (0 °C to 50 °C {32°F to 122 °F}).
(èReference Manual “Battery Power”) Once the
allowablerangerequirementissatised,charging
begins automatically. Note that the recharging time
varies based on the usage conditions. (Recharging
takes longer than usual when the temperature is
10 °C {50 °F} or below.)
lIf the temperature is low, the operating time is short-
ened. Only use the computer within the allowable
temperature range.
lThis computer has a high temperature mode function
that prevents the degradation of the battery in high
temperature environments. (èReference Manual
“Battery Power”) A level corresponding to a 100%
charge for high temperature mode is approximately
equivalent to an 80% charge level for normal tempera-
ture mode.
lThe battery pack is a consumable item. If the amount
of time the computer can be run by using a particular
battery pack becomes dramatically shorter and re-
peated recharging does not restore its performance,
the battery pack should be replaced with a new one.
lWhen transporting a spare battery inside a package,
briefcase, etc., it is recommended that it be placed in
a plastic bag so that its contacts are protected.
lAlways power off the computer when it is not in use.
Leaving the computer on when the AC adaptor is not
connected will exhaust the remaining battery capacity.

10
Getting Started
Description of Parts
EX
PC
A: Bluetooth Antenna
<Only for model with Bluetooth>
èReference Manual “Bluetooth”
B: ExpressCard Slot
èReference Manual “PC Card / ExpressCard”
C: PC Card Slot
èReference Manual “PC Card / ExpressCard”
D: Multimedia Pocket
èReference Manual “Multimedia Pocket”
E: Battery Pack
F: Wireless LAN Antenna
<Only for model with wireless LAN>
èReference Manual “Wireless LAN”
G: LCD
<Only for model with touchscreen>
èReference Manual “Touchscreen”
H: Function Key
èReference Manual “Key Combinations”
I: Keyboard
J: Touch Pad
K: LED Indicator
: Caps lock
: Numeric key (NumLk)
: Scroll lock (ScrLk)
: Multimedia pocket device status or the second
battery status
èReference Manual “Multimedia Pocket”
“Battery Power”
: Hard disk drive status
: Power status of the multimedia pocket
: Battery status
èReference Manual “Battery Power”
: Power status
(Off: Power off/Hibernation, Green: Power on,
Blinking green: Sleep)
: Wireless ready
This indicator lights when Wireless LAN, Blue-
tooth, and/or Wireless WAN are connected and
ready. It does not necessarily indicate the On/Off
condition of the wireless connection.
èReference Manual “Wireless LAN” “Blue-
tooth” “Disabling/Enabling Wireless Communi-
cation”
: Wireless WAN status
<Only for model with wireless WAN>
è
Refer to the instruction manual of the wireless device
L: Power Switch
M: Wireless Switch
èReference Manual “Disabling/Enabling Wireless
Communication”
N: Carrying Handle
O: Stylus Holder
A lithium ion battery that is recyclable powers the product you have purchased.
Please call 1-800-8-BATTERY for information on how to recycle this battery.
L’appareil que vous vous êtes procuré est alimenté par une batterie au lithium-ion.
Pour des renseignements sur le recyclage de la batterie, veuillez composer le
1-800-8-BATTERY.
48-M-1

11
Getting Started
Right side
A B C D FE G H I
1394
J K M N O PLH
Q
R
Rear side Bottom
A: Hard Disk Drive
èReference Manual “Hard Disk Drive”
B: SD Memory Card Slot
èReference Manual “SD Memory Card”
C: SD Memory Card Indicator
(Blinking: During access)
èReference Manual “SD Memory Card”
D: IEEE 1394 Interface Connector
èReference Manual “IEEE 1394 Devices”
E: Smart Card Slot
<Only for model with Smart Card slot>
èReference Manual “Smart Card”
F: Modem Port
èReference Manual “Modem”
G: LAN Port
èReference Manual “LAN”
H: USB Port
èReference Manual “USB Devices”
I: DC-IN Jack
J: Security Lock
A Kensington cable can be connected.
For further information, read the manual that comes
with the cable.
K: External Antenna Connector
L: Expansion Bus Connector
èReference Manual “Port Replicator / Car
Mounter”
M: External Display Port
èReference Manual “External Display”
N: Headphone Jack
 Youcanconnectheadphonesorampliedspeakers.
When they are connected, audio from the internal
speakers is not heard.
O: Microphone Jack
A condenser microphone can be used. If other types
of microphones are used, audio input may not be pos-
sible, or malfunctions may occur as a result.

When recording in stereo using a stereo microphone:
Click (Start) - [Control Panel] - [Hardware and
Sound] - [Sound] - [Recording] - [Microphone] -
[Properties], and then add a check mark for [No Au-
dio enhancements] in [Microphone Enhancements].
When using a monaural microphone with a 2-termi-
nal plug:
Click (Start) - [Control Panel] - [Hardware and
Sound] - [Sound] - [Recording] - [Microphone] -
[Properties], and then add a check mark for [Voice
enhancements] in [Microphone Enhancements].
Otherwise, only audio on the left track will be recorded.
P: Serial Port
Q: RAM Module Slot
èReference Manual “RAM Module”
R: Speaker
èReference Manual “Key Combinations”

12
Getting Started
Description of Parts
Attaching the stylus to the computer (only for model with touchscreen)
Use the tether to attach the stylus to the computer so you will not lose it.
There are holes (A) to attach it.
1
2
3
4
To ensure waterproof integrity, close the connector covers completely. When
closingthecovers,pushthe4cornersandmakesurethatthecovertsincom-
pletely. (The illustration is an example.)

13
Appendix
Specications
Thispageprovidesthespecicationsforthebasicmodel.
Themodelnumberisdifferentaccordingtotheunitconguration.
lTo check the model number:
Check the bottom of the computer or the box the computer came in at the time of purchase.
lTo check CPU speed, memory size and the hard disk drive (HDD) size:
Run the Setup Utility (èReference Manual “Setup Utility”) and select [Information] menu.
[CPU Speed]: CPU speed, [System Memory]: Memory size, [Hard Disk]: Hard disk drive size
n Main Specications
Model No. CF-30KTMAXJM CF-30K3MAXJM
CPU Intel® Core™ 2 Duo Processor SL9300 (1.6 GHz, 6 MB*1 L2 cache, 1066 MHz FSB)
Chipset Mobile Intel® GS45 Express Chipset
Memory*1*2 2 GB (4 GB Max.)
Video Memory*1*3
UMA 285 MB Max. (When Memory is 1024 MB)/1423 MB Max. (When Memory is 4048 MB)
Hard Disk Drive*4 160 GB
Approx. 2 GB is used as a partition with recovery tools. (Users cannot use this partition.)
Display Method 13.3 XGA type (TFT) with Touchscreen 13.3 XGA type (TFT)
Internal LCD*5 65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots)
External Display*6 65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1280 × 768 dots/1280 × 1024
dots/1440 × 900 dots)
Wireless LAN èpage 35
Bluetooth™*7 èpage 35
LAN IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
Modem Data: 56 kbps (V.92) FAX: 14.4 kbps
Sound WAVEandMIDIplayback,Intel®HighDenitionAudiosubsystemsupport,Monauralspeaker
Security Chip TPM (TCG V1.2 compliant)*8
Card Slot PC Card Type I or Type II x 1 (3.3 V: 400 mA, 5 V: 400 mA)
ExpressCard ExpressCard/34 or ExpressCard/54 x 1
SD Memory Card*9 x 1, Data transfer rate = 8 MB per second*10
Smart Card*11 ISO7816 x 1
RAM Module Slot 200-pin, 1.8 V, SO-DIMM, DDR2 SDRAM, PC2-5300 Compliant
Interface USB port (4-pin, USB 2.0) x 3, Serial port (Dsub 9-pin male), Modem port (RJ-11), LAN port
(RJ-45), External display port (Mini Dsub 15-pin female), Expansion Bus Connector (Dedicated
80-pin female), External Antenna Connector (Dedicated 50 Wcoaxial connector), IEEE 1394a
Interface Connector (4-pin x 1), Microphone Jack (Miniature jack, 3.5 DIA, Stereo), Headphone
Jack (Miniature jack, 3.5 DIA, Impedance 32 W, Output Power 4 mW × 2)
Keyboard / Pointing Device 87 keys / Touch Pad / Touchscreen (Anti-
Reection,Stylus(included)touchcapable)
87 keys / Touch Pad
Power Supply AC adaptor or Battery pack
AC Adaptor*12 Input: 100 Vto 240 VAC, 50 Hz/60 Hz, Output: 15.6 VDC, 5.0 A
Battery Pack Li-ion 10.65 V, 8.55 Ah
Operating Time*13 Main Battery: Approx. 7 hours*14
Main Battery + Second Battery: Approx. 10.5 hours*14
Charging
Time*13
Power on Main Battery: Approx. 8.5 hours
Main Battery + Second Battery: Approx. 12.5 hours
Power off Main Battery: Approx. 5 hours
Main Battery + Second Battery: Approx. 8 hours
Clock Battery Coin type lithium battery 3.0 V
Power Consumption*15 Approx. 50 W*16 / Approx. 70 W(Maximum when recharging in the ON state)
Physical Dimensions (W × H × D) 302 mm × 67.5 - 69.5 mm × 292 mm {11.9" × 2.7 - 2.8" × 11.5"}
Weight Approx. 3.8 kg {Approx. 8.4 lb.}, excluding the dummy pack and dummy cards
(Approx. 50g{Approx. 1.8 oz.})
Operation Environment Temperature: 5 °C to 35 °C {41 °F to 95 °F}
Humidity: 30% to 80% RH (No condensation)

14
Appendix
n Main Specications
Storage Environment Temperature: -20 °C to 60 °C {-4 °F to 140 °F}
Humidity: 30% to 90% RH (No condensation)
Operating System Windows Vista®Business
Utility Programs DMI Viewer, Adobe Reader, PC Information Viewer, Loupe Utility,
Bluetooth™ Stack for Windows®by TOSHIBA*7, Wireless Switch Utility, Hotkey Settings,
BatteryRecalibrationUtility,PanasonicHandWriting,InneonTPMProfessionalPackage
V3.0*17, Power Saving Utility, Wireless Connection Disable Utility*17
Setup Utility, Hard Disk Data Erase Utility*18, PC-Diagnostic Utility
nWireless LAN <Only for model with wireless LAN>
Data Transfer Rates IEEE802.11a : 54/48/36/24/18/12/9/6 Mbps (automatically switched)*19
IEEE802.11b : 11/5.5/2/1 Mbps (automatically switched)*19
IEEE802.11g : 54/48/36/24/18/12/9/6 Mbps (automatically switched)*19
IEEE802.11n : (HT20) 144.4/130/117/115.6/104/86.7/78/65/58.5/57.8/52/43.3/39/28.926/19.5/
14.4/13/6.5 Mbps (automatically switched)*19
(HT40) 300/270/243/240/216/180/162/130/120/117/108/104/90/81/78/60/54/52/
39/30/27/26/13 Mbps (automatically switched)*19
Standards Supported IEEE802.11a / IEEE802.11b / IEEE802.11g / IEEE802.11n(Draft 2.0)
Transmission method OFDM system, DSSS system
Wireless Channels Used IEEE802.11a : Channels 36/40/44/48/52/56/60/64/100/104/108/112/116/132/136/140/149/153/
157/161/165
IEEE802.11b/IEEE802.11g : Channels 1 to 11
IEEE802.11n : Channels 1-11/36/40/44/48/52/56/60/64/100/104/108/112/116/132/136/140/149/
153/157/161/165
RF Frequency Band IEEE802.11a : 5.18 GHz - 5.32 GHz, 5.5 GHz - 5.58 GHz, 5.66 GHz - 5.7 GHz, 5.745 GHz -
5.825 GHz
IEEE802.11b/IEEE802.11g : 2.412 GHz - 2.462 GHz
IEEE802.11n : 2.412 GHz - 2.462 GHz, 5.15 GHz - 5.35 GHz, 5.5 GHz - 5.58 GHz, 5.66 GHz -
5.7 GHz, 5.745 GHz - 5.85 GHz
nBluetoothTM <Only for model with Bluetooth>
Bluetooth Version 2.0 + EDR
Transmission method FHSS system
Wireless Channels Used Channels 1 to 79
RF Frequency Band 2.402-2.48 GHz
*1 1 MB = 1,048,576 bytes
*2 You can physically expand the memory up to 4096 MB, but the total amount of usable memory available will be less depending
ontheactualsystemconguration.
*3 A segment of the main memory is allotted automatically depending on the computer’s operating status. The size of the Video
Memory cannot be set by the user.
*4 1 GB = 1,000,000,000 bytes. Your operating system or some application software will report as fewer GB.
*5 A 16,777,216 color display is achieved by using the dithering function.
*6 Maximumresolutiondependsonthespecicationsoftheexternaldisplay.Displaymaybeimpossibleusingsomeconnected
external displays.
*7 Only for model with Bluetooth
*8 For information on TPM, click (Start) and input “c:\util\drivers\tpm\README.pdf” in [Start Search] and press
Enter
, and
refer to the Installation Manual of “Trusted Platform Module (TPM)”.
*9 SD Memory Cards that support high-speed transfer rates can be used. Windows ReadyBoost function is also supported.
 OperationhasbeentestedandconrmedusingPanasonicSDMemoryCardsandSDHCMemoryCardswithacapacityofup
to 8 GB.
Operation on other SD equipment is not guaranteed.
This computer is not compatible with MultiMediaCards. Do not insert these kinds of cards.
*10 The theoretical value is not the actual speed. The transfer rate does not become higher even if you use a card that supports the
higher transfer rate.
*11 Only for model with Smart Card slot
*12 <Only for North America>
The AC adaptor is compatible with power sources up to 240 VAC adaptor. The computer is supplied with a 125 VAC compat-
ible AC cord. 20-M-2-1
*13 Varies depending on the usage conditions.
*14 Measured at LCD brightness: 60 cd/m2
Varies depending on the usage conditions, or when an external device is attached.
*15 Approx. 0.9 Wwhen the battery pack is fully charged (or not being charged) and the computer is OFF.
*16 Rated power consumption 23-E-1
*17 You need to install to use the feature.

15
Appendix
*18 The Product Recovery DVD-ROM is required.
*19 ThesearespeedsspeciedinIEEE802.11a+b+g+nstandards.
Actual speeds may differ.
