Operating Instructions
(Household use) Rechargeable Shaver
Model No. ES‑LV67
ES-LV67_EU.indb 1 2019/06/05 19:10:14
2
GB English����������������� 5
DDeutsch ������������� 25
FFrançais������������� 45
IItaliano��������������� 67
NL Nederlands�������� 87
EEspañol������������ 109
DK Dansk��������������� 131
PPortuguês�������� 151
NNorsk ��������������� 173
SSvenska����������� 193
FIN Suomi����������������211
PL Polski��������������� 229
CZ ��������������� 249
SK �������� 269
H������������� 289
RO ����������� 309
TR Türkçe�������������� 329
ES-LV67_EU.indb 2 2019/06/05 19:10:14
3
Operating Instructions
(Household use) Rechargeable Shaver
Model No. ES-LV67
a
c
b
d
Back
ES-LV67_EU.indb 3 2019/06/05 19:10:15
4
ES-LV67_EU.indb 4 2019/06/05 19:10:15
5
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
Thank you for purchasing this Panasonic product.
Operating Instructions
(Household use) Rechargeable Shaver
Model No. ES‑LV67
Safety precautions..................... 8
Important information �����������������������12
����������������������������13
Preparation�����������������������������������������13
How to use �����������������������������������������14
Cleaning the shaver ��������������������������16
the inner blades���������������������������������18
FAQ �����������������������������������������������������18
Troubleshooting ��������������������������������19
Service������������������������������������������������21
For environmental protection and
������������������������22
������������������������������������23
Contents
ES-LV67_EU.indb 5 2019/06/05 19:10:15
6
Warning
•This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
•The supply cord cannot be replaced. If the cord is
damaged, the AC adaptor should be scrapped.
ES-LV67_EU.indb 6 2019/06/05 19:10:15
7
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
•This WET/DRY shaver can be used for wet shaving
using shaving lather or for dry shaving. You can use this
watertight shaver in the shower and clean with water.
The following symbol means suitable for use in a bath
or shower.
•Do not use anything other than the supplied AC adaptor
for any purpose. Also, do not use any other product with
the supplied AC adaptor. (See page 13.)
•
power supply unit is required for connecting the electrical
appliance to the supply mains. The type reference of
power supply unit is marked near the symbol.
ES-LV67_EU.indb 7 2019/06/05 19:10:15
8
To reduce the risk of injury, loss of life, electric shock,
following safety precautions.
The following symbols are used to classify and
describe the level of hazard, injury, and property
damage caused when the denotation is disregarded
and improper use is performed.
DANGER
Denotes a potential
hazard that will result in
serious injury or death.
WARNING
Denotes a potential
hazard that could
result in serious
injury or death.
CAUTION
Denotes a hazard
that could result in
minor injury or
property damage.
The following symbols are used to classify and
describe the type of instructions to be observed.
operating procedure that must not be performed.
operating procedure that must be followed in
order to operate the unit safely.
WARNING
This product
use, or leave in a high temperature environment�
‑ Doing so may cause overheating, ignition, or
explosion.
‑
injury.
Contact an authorized service centre for repair
(battery change etc).
Never disassemble except when disposing of
the product�
‑
ES-LV67_EU.indb 8 2019/06/05 19:10:16
9
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
WARNING
‑
or injury.
•The main unit, adaptor or cord is deformed
•The main unit, adaptor or cord smells of burning�
•There is an abnormal sound during use or
charging of the main unit, adaptor or cord�
‑ Immediately request inspection or repair at an
authorized service centre.
Do not connect or disconnect the adaptor to
a household outlet with a wet hand�
‑ Doing so may cause electric shock or injury.
Do not immerse the AC adaptor in water or
wash with water�
Do not place the AC adaptor over or near
Never use the appliance if the AC adaptor is
household outlet�
Do not damage the cord or the power plug�
•
pull the cord or the power plug� Also, do
the cord�
‑
to a short circuit.
the household outlet or the wiring�
‑ Exceeding the rating by connecting too many
due to overheating.
an electric power source matched to the
rated voltage indicated on the AC adaptor�
‑
Disconnect the AC adaptor when cleaning the
‑
Failure to do so may cause electric shock or injury.
ES-LV67_EU.indb 9 2019/06/05 19:10:16
10
WARNING
plug to prevent dust from accumulating�
‑
failure caused by humidity.
Preventing accidents
Do not place within reach of children or
infants� Do not let them use it�
‑ Putting parts or accessories in the mouth may
cause an accident or injury.
vomiting, drink a large amount of water and
‑ Failure to follow these instructions may result in
physical problems.
CAUTION
Protecting the skin
blemishes or injured skin�
Do not touch the blade section (metallic
section) of the inner blade�
‑ Doing so may cause injury to skin or hand.
Do not use this product for hair on head or
‑ Doing so may cause injury to skin or reduce the
life of the system outer foil.
deformations before use�
‑ Failure to do so may cause injury to the skin.
Be sure to place the protective cap on the
‑ Failure to do so may cause injury to skin or
reduce the life of the system outer foil.
ES-LV67_EU.indb 10 2019/06/05 19:10:16
11
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
CAUTION
Note the following precautions
Do not wrap the cord around the adaptor
when storing�
‑ Doing so may cause the wire in the cord to
a short circuit.
Do not allow metal objects or trash to adhere
to the power plug or the appliance plug�
‑
to a short circuit.
Do not disconnect the adaptor or the
‑ Doing so may cause electric shock or injury.
other people�
‑
Do not drop or hit against other objects�
‑ Doing so may cause injury.
Disconnect the adaptor from the household
outlet when not charging�
‑
due to electrical leakage resulting from
insulation deterioration.
DANGER
•
use with this appliance� Do not use the
•
removed from the product�
•
•
with a nail�
•Do not let the positive and negative
each other through metallic objects�
•
and hairpins�
•
be exposed to high temperatures, such as
under direct sunlight or near other sources
of heat�
•Never peel off the tube�
‑ Doing so may cause overheating, ignition, or
explosion.
ES-LV67_EU.indb 11 2019/06/05 19:10:16
12
WARNING
not keep it within reach of children and infants�
‑
The battery will harm the body if accidentally
swallowed.
If this happens, consult a physician immediately.
as tap water�
‑ Failure to do so may cause eye injury.
Consult a physician immediately.
CAUTION
contact with the skin or clothes, rinse off with
clean water, such as tap water�
‑
Important information
• Treat yourself to wet lather shaves for at least three
weeks and notice the difference. Your Panasonic
WET/DRY shaver requires a little time to get used to
because your skin and beard need about a month to
adjust to any new shaving method.
• Do not bring the system outer foil into contact with
hard objects.
Doing so may damage the blades as they are very
thin and deform easily.
• Do not dry the main unit with a dryer or a fan heater.
Doing so may cause malfunction or deformation of the
parts.
• Do not leave the shaver exposed to direct sunlight
with the foil frame detached.
Doing so may deteriorate the waterproof rubber and
degrade waterproof function, which may cause to
malfunction.
• Store the shaver in a place with low humidity after
use.
Failure to do so may cause malfunction due to
condensation or rust.
• Keep both the inner blades inserted. If only one of the
inner blades is inserted, the shaver may be damaged.
• If you clean the shaver with water, do not use salt
water or hot water. Do not soak the shaver in water for
a long period of time.
ES-LV67_EU.indb 12 2019/06/05 19:10:16
13
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
A
1Protective cap
2System outer foil
3Foil frame
4Foil frame release
buttons
5Power switch
6Lamp display
a. Shaving sensor
lamp ( )
b. Battery capacity
lamp
c. Switch lock lamp
()
d. Charge status
lamp ( )
7Appliance socket
8Outer foil section
9System outer foil
release buttons
Inner blades
Trimmer
Trimmer handle
BAC adaptor (RE7‑87)
Adaptor
Power plug
Cord
Appliance plug
Accessories
CTravel case
DCleaning brush
EOil
F
Operating Instructions
GGuarantee Card
Preparation
Charging the shaver
• Turn the shaver off.
• Wipe off any water droplets on the appliance socket.
1 Insert the appliance plug
[B] into the shaver�
2 Plug the adaptor [B] into
a household outlet�
• Check that the charge status
lamp ( ) is glowing.
• Charging is completed after
approx. 1 hour.
3
Disconnect the adaptor
after charging is completed�
1
2
Note
You cannot operate the shaver while charging.
While charging
After charging is completed
glows.
The number of the battery
capacity lamp will increase
as charging progresses.
All the battery capacity
lamp and will glow and
then turn off after
5 seconds.
Notes
•
has not been in use for more than 6 months, the
charging time may change or the charge status lamp
() may not glow for a few minutes. It will eventually
glow if kept connected.
ES-LV67_EU.indb 13 2019/06/05 19:10:16
14
• Recommended ambient temperature for charging is
10 °C – 35 °C. It may take longer to charge, or the
charge status lamp ( ) will blink quickly and the
battery may fail to charge properly in extremely high
or low temperatures.
• The shaver can be used for approximately 2 weeks
with a full charge.
(Based on one 3‑minute dry‑shave usages per day in
an ambient temperature range of 20 °C – 30 °C.)
The number of usable days varies depending on the
following conditions.
‑ Beard thickness
‑ Pressure applied to the skin
‑
Usage frequency of the sonic vibration cleaning mode
• If there is noise from the radio or other sources while
using or charging the appliance, move to a different
location to use the appliance.
How to use
Shaving beard
1 Press and shave�
• The “shaving sensor”, which
automatically adjusts the power
depending on the beard thickness,
will operate.
It will shave with high power on areas
where the beard is heavy, and reduce
the power on areas where the beard
is thin, to reduce burden on the skin.
Tips for better shaving
Apply the whole system outer foil
perpendicularly against the skin
and shave by slowly gliding the
shaver over the face against the
grain of the beard.
• The beard under the chin and
around the throat can be shaved
better by stretching the skin so
the beard will stand.
• To prevent damaging the system
outer foil, do not shave with only
a part of the system outer foil.
2 Press
ES-LV67_EU.indb 14 2019/06/05 19:10:17
15
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
While using After use
The remaining battery
capacity are shown and
then turn off after
5 seconds.
• Approximate amount of
battery capacity is
displayed as 20 – 100.
• The shaving sensor
lamp ( ) blinks.
The remaining battery
capacity blink and then
turn off after 5 seconds.
When the battery capacity is low
“20” blinks when operating the shaver.
• You can shave 2 to 3 times after “20” blinks.
(This will differ depending on usage.)
Notes
• The appliance may not operate in an ambient
temperature lower than approximately 5 °C.
• The shaving sensor may not respond depending on the
type and quantity of the shaving gel. This is not abnormal.
• Depending on the beard thickness or the amount of
beard trimmings in the shaver head, the shaving
sensor may not react and the driving sound may not
change. This is not abnormal.
•
• The sonic vibration cleaning mode is activated when
the power switch is pressed for more than 2 seconds
while the shaver is not operating. (See page 16.)
You cannot shave in this mode.
Locking the power switch
1.
Press once
and then release.
• The shaver
starts
operating.
2.
Press for more
than 2 seconds
until the switch
lock lamp ( )
turns on.
• The shaver will
stop operating.
3.
Release .
• The switch
lock lamp
() will
light up for
5 seconds
and turn off.
Unlocking the power switch
1.Press for more than
2 seconds until the
switch lock lamp ( )
turns off.
2.Once the shaver starts
operating, release .
• The switch lock lamp
() will turn off.
ES-LV67_EU.indb 15 2019/06/05 19:10:17
16
• The power switch is locked when the switch lock lamp
() blinks for 5 seconds and the shaver does not
operate even though the power switch is pressed.
Switching the shaver head
You can change the pivot action.
FREE
The shaver head is moved to
prevent missed spots.
FREE
LOCK
LOCK
You can lock the shaver head.
FREE
LOCK
FREE
Using the trimmer
1.Slide the trimmer handle up to
the “ ” position so that the
trimmer stands upright.
2.Press and use.
FREE
LOCK
Press and hold the top knob (a)
and slide the trimmer handle
down to lower the trimmer.
FREE
LOCK
Tips for better usage
Apply the trimmer edge perpendicular to skin gently
and move downward slowly.
Trimming sideburns Pre‑shave of long beards
Cleaning the shaver
We recommend cleaning the shaver after each use.
Cleaning with water
• Turn the shaver off and disconnect the AC adaptor.
1
outer foil�
2
Press for more than
2 seconds to activate the sonic
vibration cleaning mode�
• Splashing of foam is suppressed.
• The battery capacity lamps blink
in order.
• After about 20 seconds, it will be
automatically turned off, or you can turn it off by
pressing the power switch.
ES-LV67_EU.indb 16 2019/06/05 19:10:19
17
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
3 Remove the outer foil
section and clean with
running water�
• See page 18 for removing the
outer foil section.
• Splashing is reduced by rinsing the shaver in sonic
vibration cleaning mode.
• After rinsing with water, shake the shaver up and
down for a few times to remove excess moisture and
then wipe off any drops of water with a dry cloth.
4
the shaver, and the
trimmer [A
• Allow the shaver to dry in the
shade, avoid direct sunlight.
5 Lubricate the shaver�
It will keep the movement of the
blade smooth and maintain a
comfort shave.
1.Apply one drop of oil to each of
the system outer foils.
2.Raise the trimmer and apply a drop of oil.
3.Switch the shaver on, and run it for approximately
4.Switch off the shaver, and wipe off any excess oil
from the system outer foil with a soft cloth.
Notes
• Be careful not to hit the main body on the sink or any
other object while draining the water. Failure to do so
may cause malfunction.
• Do not wipe with thinners, benzine, alcohol etc.
Doing so may cause malfunction, or cracking or
discoloration of the parts.
Wipe with diluted soapy water.
• Do not use any kitchen or bathroom detergents other
than hand soap.
Doing so may cause malfunction.
Cleaning with the brush
Remove the outer foil section and the inner blades.
(See page 18.)
Clean the system outer foil in the areas
indicated by the circles every time you
use the shaver.
Cleaning with the long brush
Clean the foil frame [A3],
system outer foil [A2], the
main body [A] and the
trimmer [A] using the
long brush.
Cleaning with the short brush
• Clean the inner blades [A]
using the short brush by moving
it in direction as illustrated.
• Do not move the short brush
perpendicularly against the
blades as it will damage the inner
blades and affect their sharpness.
ES-LV67_EU.indb 17 2019/06/05 19:10:20
18
the inner blades
system outer foil once every year
inner blades once every two years
Removing the outer foil section
Press the foil frame release buttons [
A4
]
and lift the outer foil section [
A8
] upwards.
Attaching the outer foil section
After turning the foil frame mark ( ) to the
front, securely attach the outer foil section
[A8] to the shaver until it clicks.
1.Press the system outer foil release
buttons [A9] and pull down the
system outer foil [A2].
• Do not press the system outer foil
release buttons with excessive force.
Doing so may bend the system outer foil, preventing
complete attachment to the foil frame.
2.
Align the foil frame mark ( ) and the system outer foil
mark ( ) and securely attach together until it clicks.
Replacing the inner blades
1.Remove the inner blades [A] one at a
time.
2.Insert the inner blades one at a time.
Note
Do not throw away the foil frame.
FAQ
Question Answer
Will the battery
deteriorate if not used
for an extended
period of time?
The battery will deteriorate if
not used for over 6 months,
so make sure to perform a
full charge at least once
every 6 months.
Can I charge the
shaver after every use?
The battery used is a
lithium‑ion, so charging after
every use will have no effect
on battery life.
Why should the adaptor
be disconnected after
charge?
Charging the battery for more
than 1 hour will not affect
battery performance, but
disconnect the adaptor for
safety and to save energy.
What is the
constituent of the
dedicated oil?
Constituent of the oil is
ES-LV67_EU.indb 18 2019/06/05 19:10:20
19
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
Troubleshooting
Perform the following actions.
If the problems still cannot be solved, contact the
store where you purchased the unit or a service
centre authorized by Panasonic for repair.
Problem Action
The power switch
does not turn ON.
Unlock the switch lock. (See
page 15.)
The shaving sensor
does not respond.
Depending on the beard
thickness or the amount of
beard trimmings in the
shaver head, the shaving
sensor may not react and the
driving sound may not
change. This is not abnormal.
The shaving sensor may not
respond depending on the type
and quantity of the shaving gel.
This is not abnormal.
The shaving sensor may not
respond when the remaining
battery capacity is low. If this
happens, recharge the shaver.
Apply oil. (See page 17.)
The shaving sensor may not
respond when there is not
enough oil on the blades.
Problem Action
The shaving sensor
responds even though
the shaver is not in
contact with the skin.
Clean the beard trimmings
from the shaver.
When the shaver is
extremely dirty, remove the
foil frame and wash with
water.
(See page 16.)
Replace the system outer
foil and/or inner blades.
Expected life of system
outer foil and inner blades:
System outer foil:
Approximately 1 year
Inner blades:
Approximately 2 years
ES-LV67_EU.indb 19 2019/06/05 19:10:20
20
Problem Action
Operating time is short
even after a full charge.
Although the shaver can be
used for about 2 weeks after
a full charge (assuming
dry‑shave usages for 3
minutes per day), the usable
number of days might be
lower depending on how the
shaver is used (for
example,when used for wet
shaving).
Apply oil.
This can be improved by
cleaning every time after
shaving.
When the number of
operations per charge starts
to decrease, the battery is
nearing the end of its life.
Problem Action
Shaver does not
operate even after
charging.
Use the appliance in an
ambient temperature
approximately 5 °C or higher.
The battery has reached the
end of its life.
The shaver will not operate
with the AC adaptor
connected. Please use the
shaver after it has been
AC adaptor disconnected.
The driving sound
changes while shaving.
The shaving sensor is
operating. The sound
changes depending on the
beard thickness.
Makes a loud sound.
Apply oil.
The blades will not move
smoothly when there is no
oil on the blades, requiring
more power.
The shaver makes a high‑
pitched sound due to the
linear motor drive. This does
not indicate a problem.
properly attached.
Clean the system outer foil with
the brush. (See page 17.)
ES-LV67_EU.indb 20 2019/06/05 19:10:20
Other manuals for ES?LV67
2
This manual suits for next models
1
Table of contents
Languages:
Other Panasonic Electric Shaver manuals
Panasonic
Panasonic ER-412 User manual
Panasonic
Panasonic ES-LV9A User manual
Panasonic
Panasonic ES-LS9A-K803 User manual
Panasonic
Panasonic ES-RT77 User manual
Panasonic
Panasonic ES-MT22 User manual
Panasonic
Panasonic ES?RT51 User manual
Panasonic
Panasonic ES8116 User manual
Panasonic
Panasonic ES-2216 User manual
Panasonic
Panasonic ER-RZ10 User manual
Panasonic
Panasonic ES-LV61 User manual
Panasonic
Panasonic ER?GY50 User manual
Panasonic
Panasonic ES6850 User manual
Panasonic
Panasonic ER-SB60 User manual
Panasonic
Panasonic ES-LF70 User manual
Panasonic
Panasonic ES8026NC User manual
Panasonic
Panasonic ES-SWLT2 User manual
Panasonic
Panasonic ES-8101 User manual
Panasonic
Panasonic ER-SB60 User manual
Panasonic
Panasonic ES-RF41 User manual
Panasonic
Panasonic ES8044S User manual
