DC Axial Fans
EMINEBEA.COM
Motor Protection:
Auto Restart/Polarity Protection
Insulation Resistance:
 10MΩoroverwithaDC500VMegger
Dielectric Withstand Voltage:AC700V1s
Allowable Ambient Temperature Range:
 -10°C~+70°C(Operating)
 -40°C~+70°C(Storage)
 (non-condensingenvironment)
Characteristic Curves
Units: inch
(mm)
Outline
Panel Cut-outs Material
Expected LifeGeneral Specications
Failure Rate: 10%
25°C 40,000Hours
Casing :Plastic(Black)94V-0
Impeller :Plastic(Black)94V-0
Bearing :BallBearing
Lead Wire :UL10368,AWG26,+Red,-Black
NAME
PLATE
1.97
(50.0 p0.3)
1.57
(40.0 p0.2)
.604
(15.35 p0.2)
.133
(
4 – F 3.4 p0.2)
1.97
(50.0 p0.3)
4.72
(120.0 p1.0)
1.57
(40.0 p0.2)
0
10
05
15
25
20
30
0 0.1 0.150.20 0.25 0.300.05
(m3/min)
Air Flow
Static Pressure
Ps
(Pa)
CFM
In H2O
.04
.02
1.7 3.5 5.2 8.87.0 10.5
.06
.08
.10
.12
1.89
(48.2)
1.89
(48.2)
1.91
(48.6)
1.91
(48.6)
1.57
(40.0)
1.57
(40.0)
1.57
(40.0)
1.57
(40.0)
2.00
(F51.0)
OUTLET SIDEINLET SIDE
.133 .133
4 – F3.4 4 – F3.4
   Rated Operating Current Input Rated  Max. Max.Static Noise Mass
MODEL  Voltage Voltage  Power Speed  AirFlow Pressure
Product (V) (V) (A)*1 (W)*1 (min-1)*1 CFM*1  (m3/min)*1 inH2O (Pa)*1 (dB)*1 (g)
No.
2006ML-04W-B20 TXX 12 7.0~13.8 0.045 0.54 3300 8.8  0.25 0.5  14.2 22.5 25
Rotation:Clockwise AirowOutlet:AirOutOverStruts *1:AverageValuesinFreeAir
2006ML (50 X 15L)
