Panasonic KX-FL501 Quick reference guide

©2000 Kyushu Matsushita Electric Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
KX-FL501
(for U.S.A.)
Compact Laser Plain Paper FAX
ORDER NO. KMF0002391C1
F7

1 INTRODUCTION 4
1.1. SAFETY PRECAUTIONS 4
1.2. INSULATION RESISTANCE TEST 4
1.3. FOR SERVICE TECHNICIANS 4
1.4. BATTERY CAUTION 4
1.5. AC CAUTION 5
1.6. PERSONAL SAFETY PRECAUTIONS 5
1.7. SERVICE PRECAUTIONS 6
1.8. FEATURES 7
1.9. SPECIFICATIONS 8
1.10. OPTIONAL ACCESSORIES 8
1.11. TEST CHART 9
1.12. LOCATION OF CONTROLS 11
1.13. CONNECTIONS 13
1.14. INSTALLATION 14
1.15. MAINTENANCE ITEMS AND COMPONENT LOCATIONS
22
2 TROUBLESHOOTING GUIDE 27
2.1. TROUBLESHOOTING SUMMARY 27
2.2. USER RECOVERABLE ERRORS 28
2.3. TROUBLESHOOTING DETAILS 33
2.4. PROGRAMMING AND LISTS 101
2.5. TEST FUNCTIONS 114
3 ADJUSTMENTS 120
3.1. ADJUSTING THE FEEDER PRESSURE 120
4 DISASSEMBLY INSTRUCTIONS 121
4.1. HOW TO REMOVE THE BOTTOM PLATE 121
4.2. HOW TO REMOVE THE OPERATION PANEL BLOCK
122
4.3. HOW TO REMOVE THE OPERATION PANEL BLOCK
123
4.4. HOW TO REMOVE THE TRANSFER ROLLER AND
IMAGE SENSOR 124
4.5. HOW TO REMOVE THE SEPERATION RUBBUR AND
DOCUMENT FEED ROLLERROLLER 124
4.6. HOW TO REMOVE THE ANALOG BOARD, LASER
SCANNING UNIT AND SPEAKER 125
4.7. HOW TO REMOVE THE AC INLET AND POWER
SUPPLY BOARD 126
4.8. HOW TO REMOVE THE DIGITAL BOARD AND MOTOR
DRIVE BOARD 127
4.9. HOW TO REMOVE THE BACK COVER SECTION 128
4.10. HOW TO REMOVE THE FUSER UNIT AND HANDSET
CRADLE 129
4.11. HOW TO REMOVE THE MAIN FRAME 129
4.12. HOW TO REMOVE THE H.V.P.S.BOARD 130
4.13. HOW TO REMOVE THE HEAT ROLLER AND EXIT
ROLLER 131
4.14. HOW TO REMOVE THE PRESSURE ROLLER 132
4.15. HOW TO REMOVE THE MOTOR BLOCK1 133
4.16. HOW TO REMOVE THE MOTOR BLOCK2 134
4.17. HOW TO REMOVE THE MOTOR BLOCK3 135
4.18. INSTALLATION POSITION OF THE LEAD (1) 136
4.19. INSTALLATION POSITION OF THE LEAD (2) 137
4.20. INSTALLATION POSITION OF THE LEAD (3) 138
4.21. INSTALLATION POSITION OF THE LEAD (4) 139
5 HOW TO REPLACE THE FLAT PACKAGE IC 140
5.1. PREPARATION 140
5.2. FLAT PACKAGE IC REMOVAL PROCEDURE 140
5.3. FLAT PACKAGE IC INSTALLATION PROCEDURE 141
5.4. BRIDGE MODIFICATION PROCEDURE 141
6 PRINTING OPERATION PRINCIPLE 142
6.1. FL501 Process chart and Process Bias 142
6.2. CHARGING 142
6.3. EXPOSING 143
6.4. LASER SCANNING UNIT LOCATIONS 143
6.5. DEVELOPING AND TRANSCRIPTION 144
6.6. CLEANING 145
6.7. FIXING 146
6.8. TIMING CHART (When Printing Two Sheets of Paper)
147
6.9. IMAGE READING 148
6.10. DOCUMENT TRANSMISSION 149
6.11. PRINTING 150
6.12. PAPER PICKUP 151
6.13. INITIALIZATION 152
6.14. Timing Chart [Initialising (Short)] 153
6.15. Timing Chart [Initialising (Long)] 153
6.16. Timing Chart (when the registration sensor is turned OFF
then ON during initialising) 154
7 CIRCUIT OPERATIONS 155
7.1. CONNECTION DIAGRAM 155
7.2. GENERAL BLOCK DIAGRAM 158
7.3. FACSIMILE SECTION 160
7.4. CIS CONTROL SECTION 186
7.5. STEPPING MOTOR DRIVE SECTION 187
7.6. FAN MOTOR SECTION 190
7.7. LSU (Laser Scanning Unit) SECTION 191
7.8. SENSORS AND SWITCHES SECTION 193
7.9. OPERATION BOARD SECTION 200
7.10. LCD SECTION 201
7.11. HVPS (High Voltage Power Supply) SECTION 202
7.12. POWER SUPPLY BOARD SECTION 205
8 TERMINAL GUIDE OF THE IC STRANSISTORS AND DIODES
211
9 FIXTURES AND TOOLS 212
10 CABINET, MECHANICAL AND ELECTRICAL PARTS
LOCATION 213
10.1. GENERAL SECTON 213
10.2. OPERATION PANEL SECTION 214
10.3. CABINET/P.C.B. BLOCK 216
10.4. PICK UP BLOCK 217
10.5. CABINET BLOCK 218
CONTENTS
Page Page
2
KX-FL501

10.6. FUSER BLOCK 219
10.7. MAIN FRAME BLOCK 220
10.8. MOTOR BLOCK 221
10.9. ACTUAL SIZE OF SCREWS AND WASHER 222
11 ACCESSORIES AND PACKING MATERIALS 223
12 REPLACEMENT PARTS LIST 224
12.1. CABINET AND ELECTRICAL PARTS 224
12.2. ACCESORIES AND PACKING MATERIALS 226
12.3. DIGITAL BOARD PARTS 226
12.4. ANALOG BOARD PARTS 229
12.5. OPERATION BOARD PARTS 230
12.6. HIGH VOLTAGE POWER SUPPLY BOARD PARTS 230
12.7. LOW VOLTAGE POWER SUPPLY BOARD PARTS 231
12.8. MOTOR DRIVE BOARD PARTS 232
12.9. SENSOR BOARD PARTS 232
12.10. VARISTOR BOARD PARTS 232
12.11. FIXTURES AND TOOLS 232
13 FOR THE SCHEMATIC DIAGRAMS 233
14 PRINTED CIRCUIT BOARD 235
14.1. DIGITAL BOARD 235
14.2. ANALOG BOARD 237
14.3. POWER SUPPLY BOARD 239
14.4. OPERATION BOARD 240
14.5. SENSOR BOARD 242
14.6. VARISTOR BOARD 242
14.7. MOTOR DRIVE BOARD 242
15 SCHEMATIC DIAGRAM 243
15.1. DIGITAL BOARD (NO. 1) 243
15.2. DIGITAL BOARD (NO. 2) 244
15.3. ANALOG BOARD 245
15.4. POWER SUPPLY BOARD 246
15.5. OPERATION BOARD 248
15.6. SENSOR BOARD 249
15.7. VARISTOR BOARD 249
15.8. MOTOR DRIVE BOARD 249
3
KX-FL501

1 INTRODUCTION
1.1. SAFETY PRECAUTIONS
1.Before servicing, unplug the AC power cord to prevent an electric shock.
2.When replacing parts, use only the manufacturer´s recommended components.
3.Check the condition of the power cord. Replace if wear or damage is evident.
4.After servicing, be sure to restore the lead dress, insulation barriers, insulation papers, shields, etc.
5.Before returning the serviced equipment to the customer, be sure to perform the following insulation resistance test to prevent
the customer from being exposed to shock hazards.
1.2. INSULATION RESISTANCE TEST
1.Unplug the power cord and short the two prongs of the plug with a jumper wire.
2.Turn on the power switch.
3.Measure the resistance value with an ohmmeter between the jumpered AC plug and each exposed metal cabinet part
(screw heads, control shafts, bottom frame, etc.).
Note: Some exposed parts may be isolated from the chassis by design. These will read infinity.
4.If the measurement is outside the specified limits, there is a possibility of a shock hazard.
1.3. FOR SERVICE TECHNICIANS
ICs and LSIs are vulnerable to static electricity.
When repairing, the following precautions will help prevent recurring malfunctions.
1.Cover the plastic part´s boxes with aluminum foil.
2.Ground the soldering irons.
3.Use a conductive mat on the worktable.
4.Do not touch the IC or LSI pins with bare fingers.
1.4. BATTERY CAUTION
CAUTION
Danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the
manufacturer. Discard used batteries according to following caution:
Disposal of lithium batteries should be performed by permitted, professional disposal firms knowledgeable in state government
federal and local hazardous materials and hazardous waste transportation and disposal requirements.
A battery continues to have no transportation limitations as long as it is separated to prevent short circuits and packed in strong
packaging.
Commercial firms that dispose of any quantity of lithium cells should have a mechanism in place to account for their ultimate
disposition. This is a good practice for all types of commercial or industrial waste.
Recommend Type Number:
CR2032 (BAT501) Manufactured by MATSUSHITA
CR2032 (BAT501) Manufactured by SONY
4
KX-FL501

1.5. AC CAUTION
For safety, before closing the lower cabinet, please make sure of the following precautions.
1.The earth lead is fixed with the screw.
2.The AC connector is connected properly.
3.Wind the earth lead around the core 5 times.
4.Wind the earth AC around the core 4 times.
1.6. PERSONAL SAFETY PRECAUTIONS
1.6.1. MOVING SECTIONS OF THE UNIT
Be careful not to let your hair, clothes, fingers, accessories, etc., become caught in any moving sections of the unit.
The moving sections of the unit are the rollers and a gear. There is a separation roller and a document feed roller which are rotated
by the document feed motor. A gear rotates the two rollers. Be careful not to touch them with your hands, especially when the unit
is operating.
5
KX-FL501

1.6.2. LIVE ELECTRICAL SECTIONS
All the electrical sections of the unit supplied with AC power by the AC power cord are live.
Never disassemble the unit for service with the AC power supply plugged in.
CAUTION:
AC voltage is supplied to the primary side of the power supply unit. Therefore, always unplug the AC power cord before
disassembling for service.
1.7. SERVICE PRECAUTIONS
1.7.1. PRECAUTIONS TO PREVENT DAMAGE FROM STATIC ELECTRICITY
Electrical charges accumulate on a person. For instance, clothes rubbing together can damage electric elements or change their
electrical characteristics. In order to prevent static electricity, touch a metallic part that is grounded to release the static electricity.
Never touch the electrical sections such as the power supply unit, etc.
6
KX-FL501

General
·Help function
Please refer to .(P.27) to print below features.
Display:
1.QUICK SET UP
2.FEATURE LIST
3.JOG-DIAL
4.FAX SND/RCV
5.COPIER
6.Q and A
7.ERRORS
8.REPORTS
9.CALLER ID
·LCD (Liquid Crystal Display) readout
·TAM (Telephone answering machine) interface
·IQ-FAXTM (for U.S.A. only)
This feature can only be used by those who apply to the
FaxSav service.
IQ-FAX is intelligent faxing which allows you to send faxes
via the internet by using the IQ-FAX button.
Behind the IQ-FAX button is the FaxSav Global Fax
Network which manages the delivery of your fax to any fax
machine in the world. It routes your fax via the best and
most time efficient route and will automatically resend your
fax for you, if the receiving fax machine is unavailable.
This "fax-only" network has the added advantage of cost
efficiency due to the internet being integrated into the net
work. Every fax is secure since the FaxSav net work utilizes
the highest encryption legally allowed, ensuring that your
documents stay secure. You get the benefits of carefree
faxing with savings associated with the use of the internet.
It is simple, quick, and secure.
Plain Paper Facsimile Machine
·8 second transmission speed *
·Letter/Legal, G3 compatible
·Automatic document feeder (15 sheets)
·Fax pager call
·Quick scan
·Resolution: /Fine/Super fine/Photo/Photo with text (64 level)
·Broad cast with Jog-Dial
·150-sheet paper capacity (16lb~20 lb.)
·Automatic fax/phone switching
·Distinctive ring detection **
* The 8 second speed is based upon the ITU-T No. 1 Test
Chart on the condition that memory transmission is performed.
** Subscription to distinctive ring services is required.
Large Memory (24 pages)... Performed by DRAM
Approx. 170 pages of memory reception
Approx. 120 pages of memory transmission
Integrated Telephone System
·On-hook dialing
·Monitor speaker
·Voice muting
·Redialing function
·100-Station telephone directory with Jog Dial
Enhanced Copier Function
·Multi-copy function (up to 99 copies)
·Enlargement and reduction
·Collate
·64-Level halftone
1.8. FEATURES
7
KX-FL501

1.9. SPECIFICATIONS
Applicable Lines: Public Switched Telephone Network
Document Size: Max. 216 mm (8 1/2") in width
Max. 600 mm (23 5/8") in length
Effective Scanning Width: 208 mm (8 3/16")
Recording Paper Size: Letter: 216×279 mm (8 1/2"×11")
Legal: 216×356 mm (8 1/2"×14")
Effective Printing Width: 208 mm (8 3/16")
Transmission Time*: Approx. 8 s/page (ECM-MMR)**
Scanning Density: Horizontal:
8 pels/mm (203 pels/inch)
Vertical:
3.85 lines/mm (98 lines/inch)—STANDARD mode
7.7 lines/mm (196 lines/inch)—FINE/PHOTO/PHOTO WITH TEXT mode
15.4 lines/mm (392 lines/inch)—SUPER FINE Mode
Halftone Level: 64-level
Scanner Type: Contact Image Sensor (CIS)
Printer Type: Laser beam printer
Data Compression System: Modified Huffman (MH), Modified READ (MR), Modified Modified READ (MMR)
Modem Speed: 14,400/12,000/9,600/7,200/4,800/2,400 bps; Automatic Fallback
Operating Environment: 10°C—32.5°C (50°F—90.5°F), 20—80% RH (Relative Humidity)
Dimensions (H×W×D): 190 mm × 417 mm × 345 mm (7 1/2"×16 2/5"×13 3/5")
Mass (Weight): Approx. 6.5 kg (14.3 lb.)
Power Consumption: Standby: Approx. 5 W
Transmission: Approx. 25 W
Reception: Approx. 200 W
Copy: Approx. 200 W
Maximum: Approx. 560 W (When the fuser unit turns on)
Power Supply: 120 V AC, 60 Hz
Memory Capacity: Approx. 120 pages of memory transmission
Approx. 170 pages of memory reception
(Based on ITU-T No. 1 Test Chart in standard resolution.)
Laser diode properities: Laser output: Max. 5 mW
Wave length: 760 nm—800 nm
Emission duration: Contiuous
Print Speed: 10 ppm (page per minute)
Printing Resolution: 600 × 600 dpi
* Transmission speed depends upon the contents of the pages, resolution, telephone line conditions and capability of the other
party’s machine.
** Transmission speed is based upon the ITU-T No. 1 Test Chart and original mode. (Refer to "1.11. ITU-T No. 1 Test Chart".) If
the capability of the other party´s machine is inferior to your unit, the transmission time may be longer.
Note:
·Any details given in these instructions are subject to change without notice.
·The pictures and illustrations in these instructions may vary slightly from the actual product.
Design and specifications are subject to change without notice.
1.10. OPTIONAL ACCESSORIES
Model No. Description Specifications
KX-FA76 Toner cartridge 1 toner cartridge
KX-FA77 Drum unit 1 drum unit
8
KX-FL501

1.11. TEST CHART
1.11.1. ITU-T No.1 TEST CHART
9
KX-FL501

1.11.2. ITU-T No.2 TEST CHART
10
KX-FL501

1.12. LOCATION OF CONTROLS
1.12.1. OVERVIEW
Note:
*The document stacker and paper stacker may not be shown in all illustrations.
11
KX-FL501

1.12.2. CONTROL PANEL
12
KX-FL501

1.13. CONNECTIONS
(1) Connect the handset cord.
(2) Connect the telephone line cord.
(3) Connect the power cord.
·When the power is turned on for the first time, the unit will print some basic information.
Note:
·For additional equipment protection, we recommend the use of a surge protector. The following types are available;
TELESPIKE BLOK MODEL TSB (TRIPPE MFG. CO.), SPIKE BLOK MODEL SK6-0 (TRIPPE MFG. CO.), SUPER MAX
(PANAMAX) or MP1 (ITW LINX).
The warranty does not cover damage due to power line surges or lightning.
·When you operate this product, the power outlet should be near the product and easily accessible.
·If you want to connect an answering machine to the unit.
13
KX-FL501

1.14. INSTALLATION
1.14.1. INSTALLATION SPACE
The space required to install the unit is shown below.
The dimensions given are necessary for the unit to operate efficiently.
Note:
·Avoid excessive heat or humidity.
·Use the unit within the following ranges of temperature and humidity.
·Ambient temperature: 5°C to 35°C
·Relative humidity: 20% to 80% (without condensation)
·Power cord length should be less than 5 meters (16.4 feet). Using a longer cord may reduce the voltage or cause
malfunctions.
·Avoid direct sunlight.
·Do not install near devices which contain magnets or generate magnetic fields.
·Do not subject the unit to strong physical shock or vibration.
·Keep the unit clean. Dust accumulation can prevent the unit from functioning properly.
·To protect the unit from damage, hold both sides when you move it.
1.14.2. INSTALLING THE PAPER TRAY
Install the paper tray into the two slots on the back of the unit firmly unit
(). Let it lean back until it clicks into place ( ).
Note:
·Do not place the unit in areas where the paper tray may be
obstructed by a wall, etc.
14
KX-FL501

1.14.3. INSTALLING THE RECORDING PAPER
Letter* or legal** size recording paper can be loaded. The unit can hold up to 150 sheets of 60 g/m2to 75 g/m2(16 lb. to 20lb.)
paper or 120 sheets of 90 g/m2(24 lb.) paper.
*Letter=216 mm × 279 mm (8 1/2” × 11”)
**Legal=216 mm × 356 mm (8 1/2" × 14")
The unit is set for letter size paper by default. If you want to use legal size paper, change the setting (feature # 16).
1. Fan the stack of paper to prevent a paper jam.
2. Insert the paper into the recording paper entrance.
·The paper should not be over the tab.
·If the paper is not inserted correctly, readjust the paper
or the paper may jam.
Note for recording paper:
·Avoid using paper with a cotton and/or fiber content that is over 20%, such as letterhead paper or paper used for
resumes.
·Do not use different types or thicknesses of paper at the same time. This may cause a paper jam.
·Avoid extremely smooth or shiny paper that is highly textured.
·Avoid paper that is coated, damaged or wrinkled.
Note:
·Avoid double-sided printing
·Do not use paper printed from this unit for double-sided printing with other copiers or printers, or the paper may jam.
·Some paper only accepts print on one side. Try using the other side of paper if you are not happy with the print quality.
15
KX-FL501

1.14.4. ADDING PAPER TO THE PAPER TRAY
1.
2.
3.
4.
Remove all of the installed paper.
Add paper to the removed paper and straighten.
Fan the stack of paper.
Insert the paper into the recording paper entrance.
1.14.5. DOCUMENTS THE UNIT CAN FEED
Note:
·Remove chips, staples or other similar fastening objects.
·Check that ink, paste or correction fluid has dried.
·Do not send the following types of documents. Use copies for fax transmission.
— Chemically treated paper such as carbon or carbon less duplicating paper
— Electrostatically charged paper
— Heavily curled, creased or torn paper
— Paper with a coated surface
— Paper with a faint image
— Paper with printing on the opposite side that can be seen through the front (e.q. newspaper)
16
KX-FL501

1.14.6. SETTING YOUR LOGO
The logo can be your company, division or name.
1. Press .
Display:
2. Press , then .
3. Press .
4. Enter your logo, up to 30 characters, using the dial
keypad.
Example: Bill
1.Press twice.
2.Press six times.
3.Press six times.
4.Press to move the cursor to the next space and
press six times.
5. Press .
6. Press .
Note:
·You can enter your logo by rotating .
To correct a mistake
·Press or to move the cursor to the incorrect character,
then make the correction.
To insert a character
1.Press or to move the cursor to the position to the right of
where you want to insert the character.
2.Press (Insert) to insert a space and enter
the character.
To delete a character
·Move the cursor to the character you want to delete and press
.
17
KX-FL501

1.14.7. TO SELECT CHARACTERS WITH THE DIAL KEYPAD
1.14.8. TO SELECT CHARACTERS USING THE JOG DIAL
Instead of pressing the dial keys, you can select characters using the JOG DIAL.
1. Rotate unit the desired character is
displayed.
2. Press to move the cursor to the next space.
·The character displayed in step 1 is inserted.
3. Return to step 1 to enter the next character.
Display order of characters
18
KX-FL501

1.14.9. REPLACING THE TONER CARTRIDGE AND THE DRUM UNIT
When the display shows the following message, replace the toner cartridge and drum unit with new ones.
The following is available for replacement.
KX-FA76: Toner cartridge
KX-FA77: Drum unit
Caution:
·The drum unit contains a photosensitive drum. Exposing it to light may damage the drum. Once you have opened the
protection bag:
—Do not expose the drum unit to light for more than 5 minutes.
—Do not touch or scratch the green drum surface.
—Do not place the drum unit near dust or dirt, or in a high humidity area.
—Do not expose the drum unit to direct sunlight.
·Do not unplug the fax machine to prevent loss of fax documents in memory.
·Do not pour any toner into the toner cartridge.
1. Remove the new toner cartridge from the protection
bag. Peel off the seal from the toner cartridge.
2. Push the front cover open button then open the front
cover.
3. Tap on the used toner cartridge several times to
allow the remaining toner to fall into the drum unit.
Remove the drum and toner unit by holding the two
tabs.
4. Turn the two levers on the used toner cartridge
firmly.
5. Pull up the right edge of the used toner cartridge
(). Remove the cartridge from the drum unit ( ).
·The toner may stick to the cartridge and the durm unit.
Be careful in handling.
·Do not drop the toner on the green drum surface.
·Put the used toner cartridge into the protection bag.
19
KX-FL501

6. If you replace the drum unit at the same time, remove
the new drum unit from the protection bag. Remove
the protection bar from the drum unit.
With Panasonic face up on the toner cartridge, match
the red arrows on the cartridge and the drum unit.
7. Slide the tab of the toner cartridge into the slot of the
drum unit.
8a. Hold right side of the toner cartridge under the lip on
the drum unit and...
8b. Turn the two levers on the toner cartridge with film
pressure.
9. The toner cartridge is installed when the triangles
match.
10. Tap on the toner cartridge several times to allow the
toner to fall into the drum unit. Grab the tabs, and
rock the drum and toner unit from side to side
several times.
20
KX-FL501
