Panasonic TY-S42PX700W User manual

©2007 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
TY-S42PX700W
TY-S50PX700W
Stand for Plasma TV
Specifications
TY-S42P
X
700
W
Dimensions (W × D × H)
4251/64” (1087 mm) × 19 13/32” (493 mm) × 2411/64” (614 mm)
47 51/64” (1214 mm) × 23 5/64” (586 mm) × 9 59/64” (252 mm)
main bod
y
with packing
Mass (weight)
main bod
y
44.1lb (20 kg)
with packing 59.5lb (27 kg)
TY-S50P
X
700
W
Dimensions (W × D × H)
5013/64” (1275 mm) × 19 13/32” (493 mm) × 2411/64” (614 mm)
5345/64” (1364 mm) × 227/8” (581 mm) × 929/64” (240 mm)
main bod
y
with packing
Mass (weight)
main bod
y
56.2lb (25.5 kg)
with packing 72.8lb (33 kg)
ORDER NO. ITD0703008CE

1 Precautions with regard to setting up 3
2 Assembling illustration of main parts 4
2.1. Please assemble the following in numerical order. 4
3 Replacement Parts List 6
3.1. Parts List 6
3.2. Exploded View 7
3.3. Packing summary 9
4 External dimensions drawing 11
CONTENTS
Page Page
2

1 Precautions with regard to setting up
3

2 Assembling illustration of main parts
2.1. Please assemble the following in numerical order.
4

5

3 Replacement Parts List
3.1. Parts List
TY-S42PX700W
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
1 TBLA0275 TOP CROSSPIECE 1
2 TBLB0064 SIDE PANEL(LEFT) 1
3 TBLB0065 SIDE PANEL(RIGHT) 1
4 TBLB0078 BOTTOM BOARD ASSY 1
5 TBLB3241 GLASS CABLE COVER 2
6 TXFKG01JJTW GLASS SHELF (TOP) 1
8 TXFKG02JJTW GLASS SHELF
(BOTTOM)
1
10 TBLA0314 GLASS HOLDER (LEFT) 2
11 TBLA0315 GLASS HOLDER
(RIGHT)
2
12 TBLA3279 STAND POLE (A) 1
13 TBLA3280 STAND POLE (B) 1
14 TBLB0061 CASTER (ø30) 6
15 XTB4+20AFJ SCREW (HOLDER) 4
16 TBLB3184-1 REAR CABLE COVER 1
17 TBLB3234 CABLE STORAGE COVER 2
18 THEA173C SCREW (GLASS SHELF) 8
19 XTT5+40AFJ SCREW
(TOP CROSSPIECE)
4
20 XYN5+F65FJK SCREW (BLACK) 4
21 XST5+12FJ SCREW
(POLE FASTENING)
4
22 XTB4+15BFJK SCREW
(REAR CABLE COVER/
SIDE PANEL)
5
23 TQZH819-1 INSTRUCTION SHEET 1
24 TPCC12401 CARTON BOX 1
25 TPDA1496 CUSHION 1
26 TPDF1875 PROTECT PAD (GLASS) 1
27 TPDF1877 FIXED PAD
(SIDE PANEL)
2
28 TPDF1878 PROTECT PAD
(BOTTOM)
1
29 TPDF1880 PROTECT PAD (TOP) 1
30 TPEB264 PROTECT SHEET
(TOP CROSSPIECE)
1
31 TPEB267 PROTECT SHEET
(BOTTOM)
1
32 TPEB319 PROTECT SHEET
(GLASS HOLDER)
1
33 TPEB320 PROTECT SHEET
(SIDE PANEL)
2
34 XZB13X100C06 POLY BAG (REAR
CABLE COVER)
1
35 XZB13X45C06 POLY BAG
(GLASS CABLE COVER)
2
36 XZB7X10C03 POLY BAG
(ACCESSORY)
1
37 XZB7X35C03 POLY BAG
(CABLE COVER)
1
38 TBLB3199 BLISTER PACK
(STAND POLE)
1
39 TBLB3243 BLISTER PACK
(GLASS HOLDER)
1
40 TPDF1834 ACCESSORY BOX 1
41 TPDF1836 GLASS SHELF BOX 1
45 TPDF1953 PARTITION
(ACCESSORY BOX)
1
TY-S50PX700W
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
1 TBLA0274 TOP CROSSPIECE 1
2 TBLB0064 SIDE PANEL(LEFT) 1
3 TBLB0065 SIDE PANEL(RIGHT) 1
4 TBLH0644 BOTTOM PANEL 1
5 TBLB3240 CABLE COVER(GLASS) 2
7 TXFKG01JHTW GLASS SHELF
(UPPER SECTION)
1
9 TXFKG02JHTW GLASS SHELF
(LOWER SECTION)
1
10 TBLA0309 GLASS HOLDER (LEFT) 2
11 TBLA0310 GLASS HOLDER
(RIGHT)
2
12 TBLA3279 STAND POLE (RIGHT) 1
13 TBLA3280 STAND POLE (LEFT) 1
14 TBLB3074-1 CASTER (ø30) 4
15 XTB4+20AFJ SCREW (HOLDER) 4
16 TBLB3133-2 REAR CABLE COVER 1
17 TBLB3234 CABLE COVER 2
18 THEA178N SCREW (GLASS SHELF) 8
19 XTT5+40AFJ SCREW
(TOP CROSSPIECE)
4
20 XYN5+F65FJK SCREW (TV/FASTENING
BLACK)
4
21 XST5+12FJ SCREW
(POLE FASTENING)
4
22 XTB4+15BFJK SCREW
(REAR CABLE COVER/
SIDE PANEL)
5
23 TQZH818-1 INSTRUCTION SHEET 1
24 TPCC12301 CARTON BOX 1
25 TPDA1500 CUSHION
(FOUR CORNER)
1
26 TPDF1955 FIXED PAD (GLASS) 1
27 TPDF1877 FIXED PAD
(SIDE PANEL)
2
28 TPDF1956 PROTECT PAD
(BOTTOM)
1
29 TPDF1957 PROTECT PAD (TOP) 1
30 TPEB314 PROTECT SHEET (TOP) 1
31 TPEB312 PROTECT SHEET
(BOTTOM)
1
32 TPEB316 PROTECT SHEET
(GLASS HOLDER)
1
33 TPEB313 PROTECT SHEET
(SIDE PANEL)
2
34 TPDF1958 PROTECT BOX
(CABLE COVER)
1
35 XZB13X63C06 POLY BAG
(GLASS CABLE COVER)
2
36 XZB17X19C03 POLY BAG
(ACCESSORY)
1
37 XZB7X35C03 POLY BAG
(CABLE COVER)
1
38 TBLB3199 BLISTER PACK
(STAND POLE)
1
39 TBLB3246 BLISTER PACK
(GLASS HOLDER)
1
40 TPDF1959 ACCESSORY BOX 1
41 TPDF1954 PROTECT BOX (GLASS) 1
42 TPDF1960 PROTECT PAD
(SIDE PANEL)
2
43 TPDA1534 PROTECT CUSHION
(BOTTOM)
2
44 TPEB180 REAR CABLE COVER
SHEET
1
6

3.2. Exploded View
TY-S42PX700W
7

TY-S50PX700W
8

3.3. Packing summary
TY-S42PX700W
9

TY-S50PX700W
10

4 External dimensions drawing
TY-S42PX700W
11

TY-S50PX700W
12
