１．Outline
   Electricchargewillgeneratewhenanumberofcorpusclecontainedingaspassthroughand/or
getintouchwithprobeofdustmonitorequippedwithduct,plumbingpipe,etc.
Thedustmonitoramplifiesthis"Displacementofthecharge"withthesensor,andsendsthe
amplifiedslightsignaltotheoutputunit.
Thiselectricsignal"Displacementofthecharge"isbothfilteredandamplifiedandthenoutput
instrumentationsignalof4〜20mAinproportiontodustamountandcontactsignalaswell.
Important：ViewfordensityofdustmonitorperFrictionElectrificationMechanism
OutputvalueofFrictionElectricChargeMechanicdustmonitorwillbevariabledueto
variousenvironmentalfactorssuchas「kindofparticle」「particlediameter」「specificgravity
「currentspeed」throughmeasureprinciple.
   Underaregularenvironment,however,linearcharacteristicwillnotofcoursevaryunderthat
environment.
AstoconsideringdensityregardingtoDustMonitorofFrictionElectricChargeMechanism,
itrequiresyoutoconsiderinfluenceduetovariationofparticlecharacteristicsasafore
mentionedanditdoesnotalwaysmeetdensityspecified.
   Densityindicatedonspecificationisfordesigndevelopmentofmachineryandispublicized
foryoucustomerstouseasaguidelineindecidingtherange.
   Whenyoucustomersdecidetherange,youpleasefindtherangeandsetitinwhichalarmlevel
iseasytosetstrictlyfrom0−100％signalandbecomespulsesignal.
   Bydoingso,youcanrealizeyourmanagementofexhaustdrift.
   Ifthereisaneedherebytoexecutedensitymanagement,youarerecommendedtodecidedensity
equivalentto0-100％.
   Ondecidingabove,youpleaseinvestigatedensityofpulseandyoucanreadsignalasdensity
fromcurrentsignalofmachinerybyjointlyutilizingintegralfunction,etctogettherange
acquiringsignalnearesttoactualdensityof0−100％.
（Thevalueyoucangetiscompensatedandisarelativeconversionvaluebutnotabsolute.）
!

-
3
-
２．Specification
2-1．Powersupply
2-1-1．Powerpressure  AC110Vor220V-15％/+10%（specifyondemand）50/60Hz
2-1-2．Powerconsumed  7VA
 2-2．Materialtomeasure    Solidparticleingas
 2-3．Qualityofparticle    Allkindofsolidparticle
 2-4．Particlesize       ≧0.3μm
 2-5．Densityofparticle    0.1mg/m３〜1000mg/m３
 2-6．Measureprinciple     Frictionelectricchargedetectionmethod
 2-7．Measurecondition（processcondition）
 2-7-1．Temperature     ≦250℃(PFM-M11PT:≦400℃)
2-7-2．Pressure     ≦200kPa
2-7-3.Speed     ≧4m/s
2-7-4．Humidity   ≦40vol％
 2-8．Environmentalcondition
 2-8-1．Temperature-20〜65℃（Transducer:50℃）※1
   2-8-2.Humidity  ≦95％RH(Condition:Stateofcasesealingup）
 2-9．Keepingcondition
 2-9-1．Temperature  -20〜65℃
 2-9-2．Humidity   ≦95％RH
 2-10．Outputsignal
 2-10-1．Currentoutput  DC4〜20mA（isolatedoutput，loadresistance：500Ω）
                    （max.23.3mA）
2-10-2．Contactoutput Alarmcontactoutput×1（250VAC,2A／30VDC,2A）
 Upperlimitcontact（limit）output×2（250VAC,2A／30VDC,2A）
2-11．Fittingmethod        R1fitscrew(1"socket),(option：flangefitting)
 2-12．Sensitivityswitch     9stepsswitchcando
 2-13．Protectionstructure     IP65（cover,inaconditionofcableglandtightening）
      IP20(Transducer)
※1:Themaximumtemperatureisdifferentaccordingtothemeasuringrange.
(Pleaserefertothechart.)
Range
PFM-M11P PFM-M11PT
Fig.1.Graphoftemperatureandhumidity

-
4
-
３．Shape（roughdrawing）
L2(※2)
80
66
60
68
(85)(30)
φ18
φ10
(90)(57)L1(※2,3)
※1
146
35
DINRail
Railsocket
4-φ5
Mtg.Holes
Signalcable
LeadoutletG1/2(※6)
Earthterminal:M4screw(※4)
Housing:ADC
M5Bolt,Nut(※5)
Mtg.BossR1
1-socketL=43mm
Insulator:PTFE
Probe:SUS316L(※3)
160
Transducer：PFM-KCU11 Sensor：PFM-M11P
80
66
60
68
146
35
DINRail
Railsocket
4-φ5
Mtg.Holes
Signalcable
160
φ18
φ10
(90)(122)L2(※2)L1(※2,3)
※1
Earthterminal
:
M4screw(※4)
Housing:ADC
M5Bolt,Nut(※5)
Mtg.BossR1
1-socket
L=43mm
Insulator:
Ceramic
Probe:SUS316L(※3)
Radiationfin:
Alminium
φ98
(30) (85)
LeadoutletG1/2(※6)
Transducer：PFM-KCU11 Sensor：PFM-M11PT
※1）PleasedetachAbetweensocketandinsulator10mmormore.
※2)RefertothespecificationsforlengthL1,L2.
※3)Theprobeshouldbetoucheddirectlybyhandwithoutgrounding
whilebeingenergized.
※4)Pleasebesuretoconnectearthterminal.
※5)PleasetightentheBoltandNutwhenyouinstallit.
※6)Pleasemakesurethattheleadoutletisfirmlyclosedsothat
theoutsideairdoesnotinvadeinsidetheunit.
Whereitisconnectedbypipingconstructionsuchasconduitsystem,
pleaseapplyputtyandsoontotheleadcableentrysothatthe
outsideairdoesnotinvadeinsidetheunit.
Fig.2.Shape(roughdrawing)

-
5
-
D
ustmonitor
４．Mountingmethod
    TomountDustMonitor,1-socketisprovidedwith.
    Weldthesocketontothepipe.Installthedustmonitorsoitishorizontalorvertical.
Weldingshouldexecuteallaroundthepipetoshutoffgas.
  4-1．Precautionformounting
    DustMonitormaymal-functioninanenvironmentaslistedhereunder.
MountingMonitorinsuchenvironmentshouldberefrainedfrom,please.
(1) Plumbingpipetobeextremelysqueezedorclosetoaplacebending.
(2) Mountingpositionwithindiameterofductor1.5ofverticaldimension.
(3) Nearafan
(4) Fittingplumbingpipe・shortpipe・ductarenonconductive.
(5) Measureenvironmentandconditionsareoutofspecification.
(6) Incaseraisingbulkupwithshortpipeinaplacewheredustsaccumulatebetweenshort
pipeandprobe.
(7) Placewheretipofprobeiswithin20mmfromplumbingpipe.
Important:Wiringofpowerandsignalshouldbeindependent,please.
 Capisfortransportprotectionandisnotaraincoat.
Attention:・Exclusivecableistransmittingveryweaksignal.
Cableshouldbeprotectedwith,byallmeans,steelmadeelectricwirepipe
independentlysothatinductivenoiseformambientareadoesnotbothersignal.
・Securelyclosetheleadoutlettopreventoutsideairfromenteringinthemain
unit.
DonotremovetheaccessorySilicagel.(fordehumidification)
・Whereusingconduitpipingandsooninsteadofcablegrand,besuretoapply
puttyorlikeatcableentrysothatambientairdoesnotcomeintotheunit.
・Isolatetheevaluationunitfromtheouternoisesourcesandtakeanymeasure
againstnoiseiftheremaybeanynoisefrompowersupply/signallines.
!
!
※ClearanceA≧10mm
※
Clearance
B
≧
2
0mm
Important:
ForinstallationofSensor,
PlaceR1Attachmentscrew,
theninsertProbeandtighten
M5boltandnutonthesideof
R1Attachmentscrew.
Formaintenance, by loosening
boltandnut,youcanpullout
Sensor.
!
Insulation Probe
Probe
Directionofflow
Probe
Exhaustgas
R1Attachmentscrew
Direction
offlow
Fig.4.Example)Installationnotgood
Fig.3.Installation
Fig.5.Installationreferencefigure

-
6
-
５．Howtoconnect
①
②
② AttachingScrewCover
AttachingScrewCover
Upper：Mainblockpart
Lower：Terminalblockpart
ThereareAttachingScrewCoversatupperandlower
portionsofasurfaceofaTransducer.
Pleaseremovethecoverswithanegativedriverorthe
like.
Pleasekeepthecoverswhichyouremoved.
Pleaseattachthecoverwhichyoukeptafterwiring.
Fig.6.Removingcover
Aterminalblockpartisjoinedtoamainblockpart
withfourpointsofscrewsandconnectors.
Youcanseeascrewjoiningtotheterminalblockpart
underholesforTransducerattachingwhenyouremove
theattachingscrewcovers.
Pleaseloosenthesejoiningscrewsofthe
terminalblockpartwithaPhillipsdriver.
YoucanseetheterminalblockoftheTransducerwhen
youremovethemainblockpartfromtheterminalblock
partafterhavingloosenedtheseJoiningScrews.
Joining
Screws
Mtg.Hole
Mtg.Hole
Mtg.Hole
Mtg.Hole
Fig.7.Joiningscrewsofterminalandmainblockpart
Fig.8.Terminalpart
Board(Terminal)
Powerterminal
DC4-20mterminal
Sensorterminal
Connector
(mainblockpart)
Relayterminal
Whenyouwiretheterminalblockoftheconverter,you
mustnotmakeanyfalsewiring.
Afterwiring,pleaseattachthemainblockpartwith
theprocedurethereverseofhowtoremovethemain
blockpart.

-
7
-
Important:EMC-cableglandisusedforSensor.
Again,whenwiring. Figure.10.becomespointsofwiring. 
Sensor
Substratefixing
screw
COMNONC
(1)Powersupply
(2)Alarmcontact(SPDT）
(3)Upperlimit1contact(SPDT）
(4)Upperlimit2contact(SPDT)
(5)4-20mA(Analogoutputsignal)
※PleaseearththeterminalFG.
（
3
）（
2
）
（
1
）（
4
）（
5
）
Tocablegrand
White/Brown/Black/Green/Yellow
Exclusiveline
Shildedcable
Transducer
Line-connectingterminal：
 Max.1.5mm2Fig.9.Connection
!
(Componentpart)
Packing Body
Shield-ring
Rubberbush
Clampingmember
Cap
(
2
)
Completiondrawing
(1)
85
(
3
)
5
(
4
)
Packing
(1)
PleasepassCap,Clampingmember,andRubber
bushthroughthecable.
Pleasepeeloffthecablecoveringfrom
thevergebythelengthof85mm.
(2)
Pleasemaketheshieldlineasunder.
Pleasewrapanasundershieldline
asshowninleftfigure.
(3)
PleasepassShield-ringthroughthecable.
Pleasepeeloffthecoverofthecorewireby5mm.
Please use solderless terminal with insulating
coatingofStick-typebythree(brown,yellow,and
white)corewires.
Agreencorewiremustusethepressureterminalof
Rtype(R1.25-4).
(4)
PleasepassBodyandPackingthroughthecable,and
installitsothattheshieldlinemaysurelycome
incontactwiththeShield-ring.
Fig.10.becomespointsofwiring.

-
8
-
６．Partnamesandfunctions
     (1) RANGE： measurerange（１、２、３、４、５、６、７、８、９）set
     (2) L1ON: setＯＮpointoflimit1（setrange：０〜１００％）
     (3) L1OFF: setＯＦＦpointoflimit1（setrange：０〜１００％）
     (4) L2ON: setＯＮpointoflimit2（setrange：０〜１００％）
     (5) L2OFF: setＯＦＦpointoflimit2（setrange：０〜１００％）
                             MinimumrangeofHysteresisisstill１％.
     (6) INTEGRATIONTIME： Integraltimeset（setrange：０〜３０seconds）
【forindication】
POWER LED:Lightonaspoweron
FAULT LED:CPUonwhenabnormal
L1ONLED:Lightonoverlimit１set
L2ONLED:Lightonoverlimit１set
4beamsindicateLED:detectiondensity
willindicateper0-100%complyingwith
setup.
【forbutton】
→：  use when changing beam of
number/value.
↑： usewhenincreasingnumber/value.
ＭＯＤ
： usewhenswitchingparameterset
modeandmeasuremode.
     Pushingaftersetchangewill
memorizeparameterandreturntomeasure
mode.
ＳＥＬＥＣＴ
：
     Usewhenswitchingsetitems.
Ｆ−ＲＥＳＥＴ
：
     Usewhensettingmeasureagain.
％
MatsushimaMeasureTechCo.,Ltd.
MADEINJAPAN
Fig.11.FrontpanelofOutputunit

-
9
-
７．Startup
 7-1．Warmupoperation
DustMonitorrequireswarmupoperationforabout1hourafterswitchon.
   7-2．Measurerangeset
Afterfinishingwarmupoperation,youpleasesetmostappropriatemeasurerange.
Youpleasesettherangeat1-4iftheconditioninwhichnormalflowspeedisregular,
filteriscorrectandmeasureenvironmentisappropriate.
Incaserequiringobservationofsmallerchange,youpleasesettherangeat5〜9so
thatyoucanobservesmallerchange.
(Incasedensityishighhowever,youmaygetoverrange.）
           4mA(0%) 20mA(100%)     4mA(0%)  20mA(100%)
Measurerange１ ： 0.1 〜 1000mg/m3Measurerange６ ： 0.1 〜 20mg/m3
Measurerange２ ： 0.1 〜 500mg/m3Measurerange７ ： 0.1 〜 10mg/m3
Measurerange３ ： 0.1 〜 200mg/m3Measurerange８ ： 0.1 〜 5mg/m3
      Measurerange４ ： 0.1 〜 100mg/m3Measurerange９ ： 0.1 〜 2mg/m3
Measurerange５ ： 0.1 〜  50mg/m3
Thisrange（density）,utilizing「Talc」asstandardpowder,isdesignedtoget20mAoutput
underanenvironmentofflowspeedof10m/sandthemaximumrangeof1000mg/m３.
Astootherranges,themaximumvalueof20mAofeachrangeisdesignedtooutputdue
toitsoutputlinear.
    【Reference：Talc】
(Ｔaｌｃ)isnonorganicpowdermadefromorecalledTalcbeingcrushedinto
graywhiteparticleandsmoothpowder.
Talc,withitschemicalname：hydrousmagnesiumsilicate(Mg3Si4O10(OH))containing
mainingredientofSiO2approx60％,MgOapprox30％andcombinedwaterof4.88％.
Asitsphysicalnature,Talcoftruespecificgravity2.7〜2.8isasubstancehaving
lowesthardness,superiorinheatresistanceinadditiontochemically stablenature
amongnonorganicmineral.
   7-3．Integralset
      Integrationwillevenoffmeasuresignalpertimefixednumberuptomaximum30seconds.
（optionalset）
   ※ Troubleoffiltersystemwillindicatethroughsuddenriseofoutputsignal.
       Whendoinganalysisoffiltersystem,setintegralat0second,please.
       Bysettingintegralat0second,youcanmonitorsuddenchangeofdustdensity.
      Asmeasureexample,bagfilterobservationexampleisindicatedforyouinFig.5
inwhichDustMonitorisusedfor13lines.
       Dustexhaustisindicatingitsrespectiveamounttotransactas1〜6lines,and12，
13linesarelowbut7〜11linesprettyhighpeak.
       Youcandecidewhenyouchangefilterbasedonyourobservation.
Density
of
dust
Time
Warning
point
Filter No.
Fig.12.Filterobservationpicture(example)

-
10
-
   7-4．Limitset
     Limitsetcanbedone2differentupperlimits(alarm)intherangeof4〜20mA（signal
level0〜100％）
     Incasesignalchangegetsseverehowever,chatteringmightriseoften.
Insuchcaseyoumayberecommendedtouseintegralfunctionordelayfunctionat/from
higherposition(Customersexpertise)respectively.
【Limit1，2andactionchartoftroublealarm】
Limitoutput（upperlimitalarm）
PowerOFFtoopenCOM-NO
Troublealarm
             PowerOFFtocloseCOM-NO
20mA
4mA
Time
Rangetoset
c
a
n
g
Limitsetvalue（ON）
Limitsetvalue（OFF）
Hysteresis
Trouble Devicenormal
Devicenormal
COM-NO close
LEDOn
COM-NO open
LEDOff
COM-NO open
LEDOff
COM-NO close
LEDon
COM-NO open
LEDoff
COM-NO open
LEDoff
Fig.13.Operationchart（upperlimitalarm）
Fig.14.Operationchart（Troublealarm）

-
11
-
８．Setexampleofparameter
 8-1．Flowofparameterset
      Parametershouldsetaccordingtotheflowasshownhereunder.
※
Incasesettingupvalueoverinputrangeexceedingspecification,setupvalue
ofparameterwillindicate「Ｅｒｒ」onindicationLED,letyouknowsetupvalue
iswronganddonotacceptnextoperation.
※
Inthiscase,pleasechangetocorrectsetvalueagain.
   8-2．Exampleofparameterset
     Followingisasetexampletosetintegraltimeat15second.
     （Providingthatsetvaluewas0secondbeforechange.）
     (1) PushＭＯＤbutton1time・・・・・・・・・・movetoparameterwindowandLED(orange).
writtenRangeontheleftwilllighton.
     (2) PushＳＥＬbutton５times・・・・・・・・LED（orange）litgoesdowninturn
                            andINTEGRATIONTIMELEDwilllight.
     (3) Byusingboth→buttonand↑button,
       setIndicationＬＥＤat「１５」.
     (4) PushＭＯＤbutton１time・・・・・・・・・returntomeasurewindowandstartmeasure
againatintegral１５second.
     Youoperateotherparameterswithsameprocedure,please.
    Incasesettingotherparameterscontinuously,at(4)aboveinsteadofＭＯＤyoupush
ＳＥＬandcanperformbothsettingparameterandmovingtopluralitemsatthesametime.
     Reference：ParameterandlightupofcorrespondingＬＥＤ
RANGE:onlyRANGELEDlightup
L1ON     ： onlyL1ONLEDlightup
         L1OFF     ： onlyL1OFFLEDlightup
         L2ON      ： onlyL2ONLEDlightup
         L2OFF     ： onlyL2OFFLEDlightup
         INTEGRATIONTIME： onlyINTEGRATIONTIMELEDlightup
９．Maintenance 
 Measureprobeshouldregularlybewipedandcleanedwithdryrag.
Youpleasekeepitcleanedonceinevery3monthsbutmoreoftenbecauseofchangingmedia
ormeasureenvironment,yousee.
Whencleaning,youpleaseswitchoffpower.
Temperatureofpipemaybehighanddustmonitormightbeheatedaccordingly.
Becareful!Oryoumightgetyourhandsburned.
Caution:Theearthlineshouldnotberemovedevenatthemaintenanceincase
itmaycauseafault.
Measure
window Parametermode ValuesetParameterselect
MODbutton
Pressdown
(to  parameter
mode）
SELbutton
Pushdown
Respective
parameterselect
→Move beam by
button
↑ Each button
pushdownchange
value
PushdownMODbutton
(afterparameterset,tomeasure
window）
SELbuttonpushdown
（aftersetparametermove
tootherparameteritem）
!

-
12
-
10．Troubleshooting
   Whenyourdevicehasanyproblem,pleaserefertothefollowingparticularsandsolveitby
yourselvesfirst. Ifthedevicedoesnotrecovertonormalafterthoseconfirmationslisted
ontherightbelowhavebeendone,pleasekindlycontactMatsushima.
Contents Causethinkable Itemstoconfirm
PowerLEDand
OtherLEDs
areoff.
・Powerisnotsupplied.
･Powerspecificationischangedfromthe
orderedspecification.
・CPUabnormal.
・Confirmpowerlineiswired
toTerminalAC.
Ifnotsupplied,supplypower.
・Confirmthevoltageon
nameplate
ofTransduceristhesameas
the
suppliedpower.
Ifitisdifferent,returnus
Transducer,thenthepowerspec.
willbechangedatoutsite.
・PowerOFF,thenON.
Output
Directionis
unstable. 
・Warmupoperationaftersetupisnotcomplete.
・Groundingisnotprovided.
・ThewiringbetweenSensorandTransduceris
eitherofforwrong.
・MaterialstickingonProbeelectrode.
・Probeelectrodehasdewcondensation.
・Atinyamountofmaterialisflowing.
・Makewarmupoperationfor1hour
andcheckoutputagain.
・ConfirmDclassgrounding
(100ohmorless)isdone.
・Confirmwiringofexclusive
cable.
(SeePage6,5.Howtoconnect.)
If wiring is wrong, rewire
correctly.
・RemoveSensorandcheckifany
stickingonProbeelectrode.
 Ifyes,power
offandwipethem
offwithmoistcloth.(SeeNOTE)
・RemoveSensorandcheckifProbe
electrodehasdewcondensation.
 Ifyes,power
offandwipeit
offwithmoistcloth.(SeeNOTE)
・Checkifanapplicableamount
isflowing.Ifnecessary,
changethemeasurementrangeand
integralsetting.
Outputindication
goesoffscaleand
doesnotrecover.
・Ductorpipeisshort-circuitedwithProbe
electrodeduetothestickingmaterial.
・Probeelectrodehasdewcondensation.
・Probeelectrodeisincontactwithpipeinside
(GND).
・ Deviceisintrouble.
・Alargeamountofmaterialisflowing.
・CPUabnormal.
・RemoveSensorandcheckifany
stickingonProbeelectrode.
 Ifyes,power
offandwipethem
offwithmoistcloth.（SeeNOTE）
・ConfirmifInsulationisinserted
morethan10mmintoDuctorPipe.
Insulationshouldbeextended
ifnecessary.(SeeNOTE)
・RemoveSensorandcheckif
Probe
electrodehasdewcondensation.
 Ifyes,poweroffandwipeit
offwithmoistcloth.(SeeNOTE)
・Measureinsidediameterand
Probeelectrodelengthandcheck
iftheyarenotincontact.
Ifyes,changeelectrodelength.
(SeeNOTE)
・ConsultwithSalesDept.to
checkthesoundnessofDevice.
・Checkifapplicableamountof
materialisflowing.
ShortenProbeelectrodeif
necessary.(SeeNOTE)
・PowerOFF,thenON.
Table1.Troubleshooting

-
13
-
Outputindication
doesnotchange.
・Powerisnotsupplied.
・ThewiringbetweenSensorandTransduceris
eitherofforwrong.
・MaterialstickingonProbeelectrode.
・Probeelectrodeisincontactwithpipeinside
(GND).
・Deviceisintrouble.
・CPUabnormal.
・Confirmpowerlineiswired
toTerminalAC.
Ifnotsupplied,supplypower.
・
Checkwiringofexclusivecable.
(SeePage6,5.Howtoconnect.)
If wiring is wrong, rewire
correctly.
・RemoveSensorandcheckifany
stickingonProbeelectrode.
Ifyes,poweroffandwipethem
offwithmoistcloth.(SeeNOTE)
・Measureinsidediameterand
Probeelectrodelengthandcheck
iftheyarenotincontact.
Ifyes,changeelectrodelength.
(SeeNOTE)
・ConsultwithSalesDept.to
checkthesoundnessofDevice.
・PowerOFF,thenON.
FaultLEDis
lighted.
・Wiringiswrong.
・Thesuppliedpowersupplyisoutofallowable
range.
・CPUabnormal.
・ Checkwiringofpower/output
signallines,exclusivecable.
(SeePage6,5.Howtoconnect.)
Ifwiringiswrong,rewire
correctly.
・
CheckpowersupplywithaTester
etc..
Ifitisoutoftheallowable
range,applytheonewithinthe
range.
・ PowerOFF,thenON.
[NOTE]
(1)WhenremovingSensor,loosenＭ５boltsandnuts.
Securelytightenthematinstallationaftercleaningit.
(2)Ifinsulationextensionisrequired,consultwithSalesDept.ofMatsushima.（non-free）
(3)Donotcutprobelengthtooshortincaseanyelectricchargemaynotbedetected.
