FP Modem-EU Technical Manual Table of Contents
Table of Contents
1. Overview.................................................................................1
1.1 Advantages of the FP Modem-EU............................................................. 2
1.2 Important Functions of the FP Modem-EU ................................................ 3
1.3 Product Names and Numbers ................................................................... 4
1.4 Version-Up History..................................................................................... 5
1.5 Compatibility to the FP-Modem 14.4 ......................................................... 7
2. Hardware Installation ............................................................9
2.1 FP Modem-EU Unit Package................................................................... 10
2.2 Part Names, Functions and Dimensions ................................................. 11
2.3 DIP Switches ........................................................................................... 12
2.4 Technical Data......................................................................................... 14
2.5 Important Notes ....................................................................................... 16
2.6 Mechanical Installation ............................................................................ 19
2.7 Wiring....................................................................................................... 24
2.7.1 Power Supply and Operating Voltage...................................................... 24
2.7.2 DCD (Data Carrier Detect) Output ........................................................... 25
2.7.3 RS232C Cables ....................................................................................... 26
2.7.4 Connection to the Telephone Line ........................................................... 28
2.7.5 Cable Length/Installation for Leased Line/Multipoint Systems ................ 29
i
Table of Contents FP Modem-EU Technical Manual
3. Modem Control/Dial-up Connections ................................ 31
3.1 Modem Control and RS232C Interface ....................................................32
3.2 Input of AT Commands ............................................................................33
3.3 Syntax ......................................................................................................34
3.4 Steps for Establishing and Terminating a Connection .............................35
3.4.1 Establishing a Connection........................................................................35
3.4.2 Terminating a Connection ........................................................................36
3.5 User Profiles and Factory Settings...........................................................37
3.6 Password Protection and Call Back Function ..........................................39
3.7 DTMF Alarm and DTMF Telecontrol ........................................................40
3.7.1 Sending a DTMF Alarm............................................................................40
3.7.2 Decoding DTMF Tones for Remote Control.............................................41
3.8 ASCII-Fax Function ..................................................................................42
3.8.1 Fax Characters (HEX) ..............................................................................43
3.8.2 ASCII-Fax Error Messages ......................................................................44
3.9 CLIP Function...........................................................................................46
3.9.1 Operation Modes......................................................................................46
3.9.2 Example Setups .......................................................................................47
ii
FP Modem-EU Technical Manual Table of Contents
3.10 Transmission Modes................................................................................ 48
3.11 Terminating the Handshaking Phase....................................................... 49
3.12 Disconnection with the Break Signal ....................................................... 50
3.13 Communication Methods and Protocols.................................................. 51
3.14 Error Correction and Data Compression ................................................. 52
3.15 Modem Self-Diagnostic Function............................................................. 53
3.16 PLC Remote Programming with FPWIN Pro ........................................... 54
3.17 Modem Library for FPWIN Pro ................................................................ 55
4. Cable Networks/Permanent Connections..........................57
4.1 Leased Line Mode ................................................................................... 58
4.1.1 Usage on Leased Line or Private Cable .................................................. 58
4.1.2 Enable Leased Line Mode with DIP Switches ......................................... 58
4.1.3 Recommendations for Leased Line Mode ...............................................59
4.1.4 Maximum Line Length.............................................................................. 60
4.2 Multipoint Operation................................................................................. 61
4.2.1 Enable Multipoint Mode with DIP Switches.............................................. 62
4.2.2 Description of Multipoint Operation .......................................................... 63
4.2.3 Error Correction in Multipoint Mode ......................................................... 64
4.2.4 Terminating Resistor ................................................................................ 64
4.2.5 Maximum Line Length.............................................................................. 66
iii
Table of Contents FP Modem-EU Technical Manual
5. AT Commands/Registers/Modem Messages.................... 67
5.1 Command Tables.....................................................................................68
5.2 Register Settings ......................................................................................75
5.3 Modem Messages ....................................................................................78
6. Remote Networking with Windows.................................... 81
6.1 Modem Setup for FP Web-Server and Windows .....................................82
6.2 Server’s Side: FP Web-Server and PLC Setup........................................83
6.3 Client’s Side: Windows Dial-up Networking Setup ...................................85
6.4 Client’s Side: Windows Dialing Procedures .............................................94
7. Glossary............................................................................... 97
7.1 Technical Terms.......................................................................................98
8. Index................................................................................... 105
iv
Chapter 1
Overview
Overview FP Modem-EU Technical Manual
1.1 Advantages of the FP Modem-EU
The FP Modem-EU was mainly designed for data exchange between programmable logic
controllers (PLCs) in an industrial environment via analog telephone network connections.
The following important features distinguish the FP Modem-EU from other standard modems for
personal computers:
•very small size
•operating voltage 24V DC
•attachable to a 35mm DIN rail
•password protection and call back function
•leased line mode (pier-to-pier) with adjustable transmission level
•multidrop-leased line mode according to V.23 at 1200 bps
•DCD output for connection to the digital input of a PLC
•DTMF-send function and DTMF-receive function for simplified telecontrolling
•ASCII fax mode
•CLIP decoder (FP Modem-EU V1.2) (see "Version-Up History" on page 5). Also see
Glossary.
2
FP Modem-EU Technical Manual 1.2 Important Functions of the FP Modem-EU
1.2 Important Functions of the FP Modem-EU
•Dialing method: pulse and tone dialing (see "Steps for Establishing and Terminating a
Connection" on page 35)
•Transmission standards V.17, V.21, V.22, V.22bis, V.23, V.27ter, V.29, V.32, V.32bis
(see "Communication Methods and Protocols" on page 51)
•Error correction methods: V.42, LAPM, MNP4 (see "Error Correction and Data
Compression" on page 52)
•Data compression methods: MNP5, V.42bis (see "Error Correction and Data
Compression" on page 52)
•RS232C baud rate 600 to 115200 bps, automatic baud rate detection and fixed
communication settings (see "Transmission Modes" on page 48)
•Automatic baud rate detection can be disabled for PLC (tool port) connections with
AT*W (see "Command Tables" on page 68).
•Hayes compatible, extended AT command set (see "Command Tables" on page 68)
•PLC <-> PC communication: You can use the modem for remote programming and
monitoring (dial-up and leased line mode ) with Panasonic PLCs of the FP-Series.
•PLC <-> PLC communication: Communication can also be carried out via COM-Port
with the help of the FPWIN Pro Library "Modem". This library contains a multitude of
function blocks and examples with various purposes.
•The modem is tested according to CTR21 (dialing modem) and CTR15
(leased line mode). CTR21 and CTR15 are identical with TBR21 and TBR15.
See CE mark. The modem can be used in the following countries:
Belgium, Denmark, Germany, Finland, France, Greece, Ireland, Iceland, Italy,
Luxembourg, Netherlands, Norway, Austria, Portugal, Sweden, Switzerland,
Spain, United Kingdom (UK). The modem is not licensed for the US!
•The connection for the framing ground (FG with green cable) has to be
connected! There is no guarantee on defects resulting from non-compliance!
•Furthermore, there is no guarantee on damages resulting from lightning
strikes (also the indirect consequences thereof). Appropriate lightning
protection is recommended.
•An RJ12-RJ12 cable is included in the FP Modem-EU unit package. To
connect to the country-specific telephone jack you have to get a national
adapter. You can purchase a national adapter in one of your local telephone
shops.
3
Overview FP Modem-EU Technical Manual
1.3 Product Names and Numbers
Product name Product number
FP Modem-EU Unit FPMODEMEU
FPWIN Pro Library "Modem" NCL-CMEU-LIB
FP Modem-EU RS232C Cable for FP0 COM Port CABMODPLC111
FP Modem-EU RS232C Cable for FP1/FP-M/FP2/FP10SH COM Port CABMODPLC211
FP Modem-EU Technical Manual ACGM0138V13END
PLC-Modem Communication Manual ACGM0136V20END
4
FP Modem-EU Technical Manual 1.4 Version-Up History
1.4 Version-Up History
Version 1.21
In April 2005 the FP-Modem-EU Version 1.21 was introduced (see label) with firmware version
1.38 (see ATi3 (see "Command Tables" on page 68)). It includes the following enhancements:
•A new transparent multipoint mode (see "Multipoint Operation" on page 61):
The modem collects all data received via RS232C and sends it after a specified idle time
is exceeded. The idle time can be defined in the new register S95. The multipoint
transparent mode can be selected with the following, new DIP switch settings:
DIP Setting Function
ON DIP
1234
Transparent mode with S95=3 (10ms), RS232C with 19200 8o1
ON DIP
1234
Transparent mode with S95=3 (10ms), RS232C with selectable baud rate
ON DIP
1234
Transparent mode with S95=1...255, baud rate set via terminal
•The FP Modem-EU was produced with lead free (RoHS conformity) technology.
•Minor bug fixes
Version 1.2
In February 2004 the FP-Modem-EU Version 1.2 was introduced (see label) with firmware
version 1.29 (ATi3 (see "Command Tables" on page 68)). It includes the following
enhancements:
•If the PLC/Multipoint mode is selected (DIP2=ON, DIP3=ON) and DIP4=OFF, the baud
rate last used is fixed for multipoint communication. This change was necessary
because the FP-Sigma cannot be set up for 1200 bps.
•If the PLC/Multipoint mode is selected (DIP2=ON, DIP3=ON) and DIP4=ON, a fixed
baud rate of 19200 bps (8 data bits, odd parity, 1 stop bit) is used.
•The reliability of PLC/Multipoint data transmission has been improved:
- Deleting of scrambled characters after the ending CR code
- Default S93 setting increased from 10 to 20, i.e. 200ms delay for start/stop sending
- Additional buffering for immediately sending after receiving
•In dial-up and leased line mode a new default break setting \K6 has been implemented.
This allows 8-bit binary zero data with even parity to be transferred. This RS232C format
is used for IEC60870-5-101communication.
•A CLIP (Calling Line Identification Presentation) decoder is included, which makes it
possible to decode the caller's telephone number. CLIP signaling is done during the first
ring tone on an incoming call. The CLIP function must be activated by the national
5
Overview FP Modem-EU Technical Manual
PSTN provider (for both the sender and the receiver). Most European PSTN providers
offer the CLIP function: Austria, Belgium, France, Germany, Greece, Italy, Luxembourg,
Norway, Poland, Spain, Turkey (Finland and Switzerland will soon follow).
The CLIP decoder (see "CLIP Function" on page 46) of the FP-Modem-EU can be
enabled with AT%G1 or AT%G3.
6
FP Modem-EU Technical Manual 1.5 Compatibility to the FP-Modem 14.4
1.5 Compatibility to the FP-Modem 14.4
We have tried to make the FP modem-EU widely compatible to the previous model, the
FP-Modem 14.4. Nevertheless there is a series of changes, both in design and concerning the
command set.
Some commands were replaced in order to more closely reflect the customary Hayes standard.
This does not have any influence on the operation with the Panasonic controllers and the
associated user and technology libraries.
What has changed? Description and change
Power supply Molex plug instead of the Phoenix clamp -> there is no danger of mixing up
the two anymore. The power supply is now located on the bottom side,
compatible to the FP0.
RS232C port Fully developed 9-pin SUB-D female plug with hardware handshakes
Design
New output DCD output for the PLC (processable via the digital input of the PLC)
ATF7 Identical with ATF6 but not compatible to the 7200 bps of the old modem
ATF9 Identical with ATF6 but not compatible to the 12000 bps of the old modem
Fax Class 1 Does not work and was replaced by class 2.
Password
protection and call
back function
It is compatible to the FP-Modem 14.4 on the caller’s side, but it is not
compatible on the side of the calling partner! The new modem outputs NO
CARRIER (3) before starting the call back. An adjustment to the new version
that makes more sense is necessary at this point. The new modem outputs
"Callback ... press ’A’ to abort" when the call back is started.
AT*P
AT*Pn
The command for entering the password works a little different now: You
can only enter one password and no call back number. This number is
stored in the telephone number register with AT&Z0= . Input: AT*P=xxxxx
instead of AT*Pn:xxxxx
The password is deleted with AT*P= and not with AT*Pn: .
AT&Qn Is not supported anymore
AT&T Is not supported anymore
AT%C3 Is not supported anymore
AT%Q Signal quality is not supported anymore
AT*B Display blacklist is not supported anymore
AT*D List of deferred numbers is not supported anymore
AT-Kn MNP10 ON/OFF is not supported anymore
AT-Qn Fallback to V.22/V.22bis is not supported anymore
AT)Mn MNP10 adjustment to line conditions is not supported anymore
AT#CLS=... Is not supported anymore
Commands
AT#REV? This command for reporting the current version is not supported anymore.
The command is replaced by the ATI3 command now. It has the same
functionality.
7
Chapter 2
Hardware Installation
Hardware Installation FP Modem-EU Technical Manual
2.1 FP Modem-EU Unit Package
The FP Modem-EU unit package contains:
•one FP Modem-EU
•a 24V DC power cable
•a leaflet providing installation instructions
•Phoenix 3-pin screw terminal
•an RJ12-RJ12 telephone cable
10
FP Modem-EU Technical Manual 2.2 Part Names, Functions and Dimensions
2.2 Part Names, Functions and Dimensions
Units: mm
1
4
5
3
2
60.0 3.5
6.025.0
1. Telephone connection jack (RJ12) for dial-up lines, leased line or multipoint lines
(middle two wires). An RJ12 to RJ12 cable is supplied with the FP Modem-EU.
2. DCD carrier detect LED lights up upon established data connection. The LED turns off
after power ON and a successful self-test.
3. DCD carrier detect output for connection to the PLC digital 24V inputs. Screw terminal
(see "DCD (Data Carrier Detect) Output" on page 25).
4. RS232C (Sub-D 9 female) data interface. See wiring schematics for PLC cable (see
"RS232C Cables" on page 26). Use standard 1:1 serial cables to connect to a IBM PC
serial port or FP Web-Server.
5. 24V DC, use AFP0581 power supply cable that comes with the unit
brown +24V DC
blue GND
green framing ground
The green wire MUST be connected to FG!
11
Other manuals for FP Series
2
This manual suits for next models
1
Table of contents
Other Panasonic Modem manuals
