Zoom CableModem 5031 User manual

The Zoom CableModem Model 5031 has a USB interface to support a
wide range of operating systems, and applications. The modem is easily
installed using the software provided. In addition, Zoom's unique Cable
Modem Monitor Software provides user-friendly troubleshooting if
problems are encountered on the network.
The Model 5031 has been CableLabs®certified and is approved as fully
compliant with the Data Over Cable System Interface Specification 1.0
(DOCSIS 1.0), ensuring interoperability and a high level of performance
with industry-standard cable systems. It is software upgradeable to
DOCSIS 1.1, with the necessary hardware, software and Digital Certifi-
cates built into the modem to support 1.1 enhancements. Data over
cable service providers are supported further with remote and local
diagnostic capability, remote firmware downloads and SNMP support.
The cable modem supports up to fifteen PCs and a data rate of up to 42
Mbps downstream from the service provider and 10.2 Mbps upstream.
The package includes ZoneLabs' ZoneAlarm™personal firewall software,
AdSubtract™ ad blocker/cookie filter software, a user's manual and
Ethernet cable.
Model 5031
■Access the Internet at speeds
up to 100 times faster than
dial-up modems
■Provides an always-on Internet
connection for instant access
■Eliminates Internet traffic on
your phone line
■DOCSIS 1.0 tested and certi-
fied for operation with industry
-standard cable networks
■Can be upgraded to DOCSIS
1.1 automatically by your cable
service provider
■Easy-to-read status display
■Stylish, design with vertical and
horizontal options
■Easy installation with USB
support for Windows XP, Me,
2000 and 98
■Unique Zoom Cable Modem
Monitor provides network
troubleshooting software
■Includes ZoneAlarm™ personal
firewall and AdSubtract™ad
blocker software
■Includes USB cable
External Cable Modem
with USB Connection
Zoom®CableModem™

Cable Modem Operating ParametersDownstream Upstream
Frequency 91 to 857 MHz 5 to 42 MHz
Data Rate Up to 42 Mbps Up to 10.2 Mbps
Modulation 64QAM / 256 QAM QPSK / 16QAM
Error Correction Reed-Solomon decoding Reed-Solomon encoding
(ITU J.38 Annex B)
Channel Bandwidth 6 MHz 200/400/800/1600/3200 KHz
Signal Level -15 to +15 dBmV +8 t0 +58 dBmV (QPSK)
+8 to +55 dBmV (16QAM)
Features
•Easy installation USB connection
•Support for Windows 98, 2000, Me and
XP operatinng systems
•CableLabs Certified
•56 bit encryption provides privacy
and security
•Highly integrated design for
superior reliability
External Cable Modem
with USB Connection
Model 5031
Technical Specifications
•Experienced technical support
for both consumers and service
providers
•SNMP and DOCSIS MIB support
allowing remote software upgrades
•Includes encrypted security key for
DOCSIS 1.1 field upgrades
•Advanced diagnostic software and
firmware
•Backed by over twenty years of
experience in computer
communications
Operating and Environmental Parameters
Power Requirements 12V, 600mA nominal
Power Consumption 7W nominal
Operating Temperature 0˚ to 40˚ C
Dimensions 8.9”” (22.6 cm) Width x 1.6” (4.1 cm) Height x 6.5” (16.5 cm) Depth
Weight 1.8 lb (0.81 Kg)
Regulatory FCC Part 15, Class B; UL, C-UL; EN 55022, Class B; EN 55024; EN 60950
System Requirements • DOCSIS cable data service and coaxial cable connection
• Computer with USB port
Supplied with • 4’ USB Cable
• Power Supply and Cord (110VAC / 60 Hz or 230VAC / 50 Hz)
• User’s Manual
• CD-ROM with software including ZoneLabs ZoneAlarm personal firewall,
AdSubtract ad blocker / cookie filter, and Zoom Cable Modem Monitor installation
and troubleshooting software tool
