Panasonic FP7 CPU Unit User manual

WUME-FP7LAN-01
2013.3 panasonic.net/id/pidsx/global
PROGRAMMABLE CONTROLLER
FP7 CPU Unit
User's Manual
LAN port communication

Safety Precautions
Observe the following notices to ensure personal safety or to prevent accidents.
To ensure that you use this product correctly, read this User’s Manual thoroughly before use.
Make sure that you fully understand the product and information on safety.
This manual uses two safety flags to indicate different levels of danger.
If critical situations that could lead to user’s death or serious injury is assumed by
mishandling of the product.
WARNING
-Always take precautions to ensure the overall safety of your system, so that the whole
system remains safe in the event of failure of this product or other external factor.
-Do not use this product in areas with inflammable gas. It could lead to an explosion.
-Exposing this product to excessive heat or open flames could cause damage to the lithium
battery or other electronic parts.
If critical situations that could lead to user’s injury or only property damage is
assumed by mishandling of the product.
CAUTION
-To prevent excessive exothermic heat or smoke generation, use this product at the values
less than the maximum of the characteristics and performance that are assured in these
specifications.
-Do not dismantle or remodel the product. It could cause excessive exothermic heat or smoke
generation.
-Do not touch the terminal while turning on electricity. It could lead to an electric shock.
-Use the external devices to function the emergency stop and interlock circuit.
-Connect the wires or connectors securely.
The loose connection could cause excessive exothermic heat or smoke generation.
-Do not allow foreign matters such as liquid, flammable materials, metals to go into the inside
of the product. It could cause excessive exothermic heat or smoke generation.
-Do not undertake construction (such as connection and disconnection) while the power
supply is on. It could lead to an electric shock.
Copyright / Trademarks
-This manual and its contents are copyrighted.
-You may not copy this manual, in whole or part, without written consent of Panasonic
Industrial Devices SUNX Co., Ltd.
-Windows is a registered trademark of Microsoft Corporation in the United States and other
countries.
-Ethernet is a registered trademark of Fuji Xerox Co., Ltd. and Xerox Corp.
-All other company names and product names are trademarks or registered trademarks of
their respective owners.
PLC_ORG_ET

Introduction
Thank you for buying a Panasonic product. Before you use the product, please carefully read
the installation instructions and the users manual, and understand their contents in detail to
use the product properly.
Types of Manual
•There are different types of users manual for the FP7 series, as listed below. Please refer to
a relevant manual for the unit and purpose of your use.
•The manuals can be downloaded on our website:
http://industrial.panasonic.com/ac/e/dl_center/manual/ .
Unit name or purpose of
use
Manual name Manual code
FP7 Power Supply Unit FP7 CPU Unit Users Manual
(Hardware) WUME-FP7CPUH
FP7 CPU Unit
Instructions for Built-in
COM Port
FP7 Extension
(Communication)
Cassette
FP7 CPU Unit Users Manual
(COM Port Communication) WUME- FP7COM
Instructions for Built-in
LAN Port
FP7 CPU Unit Users Manual
(LAN Port Communication) WUME-FP7LAN
FP7 Digital Input/Output Unit FP7 Digital Input/Output Unit Users Manual WUME-FP7DIO
FP7 Analog Input Unit FP7 Analog Input Unit Users Manual WUME-FP7AIH
FP7 Analog Output Unit FP7 Analog Output Unit Users Manual WUME-FP7AOH
FP7 Positioning Unit FP7 Positioning Unit Users Manual WUME-FP7POSP
PHLS System PHLS System Users Manual WUME-PHLS
Programming Software
FPWIN GR7 FPWIN GR7 Introduction Guidance WUME-FPWINGR7

Table of Contents
Table of Contents
1. Communication Functions of CPU Unit............................ 1-1
1.1 Communication Ports of CPU Unit ......................................................... 1-2
1.1.1 Types and Purposes of Communication Ports........................................1-2
1.1.2 LAN Port Specifications...........................................................................1-3
1.2 Functions of LAN Port ............................................................................ 1-4
1.2.1 Communication Functions of FP7 CPU Unit...........................................1-4
1.2.2 System Connection .................................................................................1-4
1.2.3 User Connection......................................................................................1-5
1.3 Overview of Communication Functions.................................................. 1-6
1.3.1 MEWTOCOL-DAT Master/Slave Communication (Binary
Communication) ......................................................................................1-6
1.3.2 MEWTOCOL-COM Master/Slave Communication (ASCII
Communication) ......................................................................................1-7
1.3.3 MODBUS TCP Master/Slave Communication ........................................1-8
1.3.4 General-Purpose Communication...........................................................1-9
1.4 Terms ................................................................................................... 1-10
2. Installation and Wiring........................................................ 2-1
2.1 Installation Environment and Wiring for LAN Ports ................................ 2-2
2.1.1 Before Installation and Wiring .................................................................2-2
2.1.2 Installation Environment and Noise Control Measures ...........................2-2
2.2 Wiring the LAN Port................................................................................ 2-3
2.3 Noise Control Measures......................................................................... 2-4
2.3.1 Guidelines to Noise Generation ..............................................................2-4
2.3.2 Taking Corrective Measures through the Application .............................2-4
ii

Table of Contents
3. Configuration.......................................................................3-1
3.1 Procedure for Setting Communication Conditions.................................. 3-2
3.1.1 Setup Procedure .....................................................................................3-2
3.2 Setting Basic Communication Information.............................................. 3-3
3.2.1 List of Setting Items.................................................................................3-3
3.2.2 Setting Each Timer Value And Timeout Value........................................3-4
3.3 Settings for SNTP server ........................................................................ 3-5
3.4 Settings for FTP server........................................................................... 3-6
3.5 Setting of System Connection ................................................................ 3-7
3.5.1 List of Setting Items.................................................................................3-7
3.5.2 Setting on the Programming Tool Side ...................................................3-9
3.6 Setting of User Connection................................................................... 3-10
3.6.1 List of Setting Items...............................................................................3-10
3.6.2 Specifying Port Number ........................................................................3-12
4. Setting and Operation of User Connection.......................4-1
4.1 Configuration Concerning Open Process ............................................... 4-2
4.1.1 Connection of the FP7 CPU Unit ............................................................4-2
4.1.2 Specifying Use of Connection.................................................................4-2
4.1.3 Open Method (Server/Client) ..................................................................4-2
4.1.4 Open Method (Auto/Manual)...................................................................4-2
4.1.5 Instructions for Specifying Connection Conditions..................................4-3
4.2 Communication Processing.................................................................... 4-4
4.2.1 Communication Operation ......................................................................4-4
4.3 Input/Output Signals Used for Communication....................................... 4-5
4.3.1 I/O Allocation ...........................................................................................4-5
iii

Table of Contents
5. MEWTOCOL Master/Slave Communication...................... 5-1
5.1 Types of MEWTOCOL Communication ................................................. 5-2
5.1.1 MEWTOCOL-DAT (Binary Communication)...........................................5-2
5.1.2 MEWTOCOL-COM (ASCII Communication)...........................................5-2
5.2 List of MEWTOCOL Supporting Commands.......................................... 5-3
5.2.1 MEWTOCOL-DAT...................................................................................5-3
5.2.2 MEWTOCOL-COM..................................................................................5-3
5.2.3 MEWTOCOL7-COM................................................................................5-3
5.3 MEWTOCOL Master Communication (RECV)....................................... 5-4
5.3.1 Read Data From an External Device ......................................................5-4
5.3.2 RECV Command (When MEWTOCOL is Used).....................................5-6
5.4 MEWTOCOL Master Communication (SEND)....................................... 5-7
5.4.1 Write Data into an External Device .........................................................5-7
5.4.2 SEND Command (When MEWTOCOL is Used).....................................5-9
6. MODBUS TCP Master/Slave Communication................... 6-1
6.1 MODBUS TCP Format ........................................................................... 6-2
6.1.1 MODBUS TCP ........................................................................................6-2
6.2 List of MODBUS TCP Supported Commands........................................ 6-3
6.2.1 List of MODBUS Function Codes............................................................6-3
6.3 MODBUS TCP Master Communication (RECV) .................................... 6-4
6.3.1 Read Data from an External Device........................................................6-4
6.3.2 RECV Command (MODBUS Function Code Specified Type)................6-7
6.3.3 RECV Command (MODBUS Function Code Unspecified Type)............6-8
6.4 MODBUS TCP Master Communication (SEND) .................................... 6-9
6.4.1 Write Data into an External Device .........................................................6-9
6.4.2 SEND Command (MODBUS Function Code Specified Type)..............6-11
6.4.3 SEND Command (MODBUS Function Code Unspecified Type)..........6-12
iv

Table of Contents
7. General-Purpose Communication .....................................7-1
7.1 Operation of General-Purpose Communication...................................... 7-2
7.1.1 Read Data from an External Device .......................................................7-2
7.1.2 Write Data into an External Device .........................................................7-2
7.1.3 Sending Format in General-Purpose Communication ............................7-3
7.2 Sending Operation.................................................................................. 7-4
7.2.1 Overview of Sending Operation ..............................................................7-4
7.2.2 Contents of Sent Data.............................................................................7-6
7.2.3 GPSEND (General-Purpose Communication Sending Command)........7-7
7.3 Receiving Operation ...............................................................................7-8
7.3.1 Overview of Receiving Operation............................................................7-8
7.3.2 Contents of Received Data ...................................................................7-10
7.3.3 GPRECV (General-Purpose Communication Receiving Command) ...7-11
8. Specifications ......................................................................8-1
8.1 Specifications of CPU Unit LAN Port Communication Function ............. 8-2
8.2 MEWTOCOL-DAT Format...................................................................... 8-3
8.2.1 MEWTOCOL-DAT Command Format in LAN Command Format ..........8-3
8.2.2 MEWTOCOL-DAT Command/Response Format ...................................8-4
8.3 MEWTOCOL-COM Format..................................................................... 8-6
8.3.1 MEWTOCOL-COM Command Format in LAN Communication .............8-6
8.3.2 MEWTOCOL-COM Command Format ...................................................8-7
8.3.3 MEWTOCOL-COM Response Format....................................................8-9
8.4 MEWTOCOL7-COM Format................................................................. 8-11
8.4.1 MEWTOCOL7-COM Command Format ...............................................8-11
8.4.2 MEWTOCOL7 Response Format .........................................................8-13
v

Table of Contents
vi

1
Communication Functions of
CPU Unit

Communication Functions of CPU Unit
1.1 Communication Ports of CPU Unit
1.1.1 Types and Purposes of Communication Ports
Communication ports of CPU unit
Functions of Ports
(1) COM1 and COM2 Ports
Attach a separately sold communication cassette to use these ports. You can select from five
types of communication cassettes.
(2) COM0 Port
This is an RS-232C port that is equipped to a standard model of CPU unit. It is equipped with
power supply terminals (5V DC and 24V DC) to which a GT series display can be connected.
(3) LAN Port
This is equipped to a standard model of CPU unit. It is used for connection to Ethernet. It can
also be connected with a programming tool. The MAC address is printed on the side of the
unit. It supports the Ethernet communication interfaces 100BASE-TX and 10BASE-T.
100BASE-TX and 10BASE-T are automatically switched by the auto negotiation function.
(4) USB Port
This is equipped to a standard model of CPU unit. This is used when connecting tool software.
REFERENCE
•For communication using the COM port, please see the CPU Unit Users
Manual (COM Port Communication).
1-2

1.1 Communication Ports of CPU Unit
1.1.2 LAN Port Specifications
100BASE-TX / 10BASE-T connector (RJ45)
This connector connects the ET-LAN Unit and the Hub in Ethernet (100BASE-TX, 10BASE-T)
and UTP Cable.
Pin no. Signal name
1 TX+
2 TX-
3 RX+
4 Not used
5 Not used
6 RX-
7 Not used
8 Not used
Functions of LED lamps
(1) LINK
Turns on when connection is established between the FP7 CPU unit and a device on Ethernet.
(2) ACK
Flashes when some communication is in progress with a connected device (e.g.
sending/receiving a command or response).
1-3

Communication Functions of CPU Unit
1.2 Functions of LAN Port
1.2.1 Communication Functions of FP7 CPU Unit
Configuration chart
Communication functions of FP7 CPU Unit
•The FP7 CPU Unit can open a virtual communication line with an Ethernet-supporting device
connected to LAN, and send/receive data.
•IP address of the FP7 CPU unit, protocol (TCP/UDP), connection method with devices, port
numbers, etc. should be specified in the configuration menu of the programming tool FPWIN
GR7.
•In master communication commands SEND/RECV, messages in accordance with the
protocol are automatically generated by PLC. In the user program, reading and writing can
be done simply by specifying the station no. and memory address and executing commands.
•Communication functions can be selected depending on the partner device to be connected.
1.2.2 System Connection
Functions of system connection
•System connection is used when using a programming tool via LAN port.
•Four connections are available per CPU unit.
1-4

1.2 Functions of LAN Port
1.2.3 User Connection
Functions of user connection
•The FP7 CPU Unit can open virtual communication lines for up to 16 connections with
Ethernet-supporting devices connected to LAN, and send/receive data.
•It can open multiple connections between the FP7 CPU unit and multiple nodes or a single
node, and execute communication.
•Operation mode, open method, protocol, etc. can be selected for each connection.
IP XXXXXX
FP7 CPU
1
Port
8000
External
device
IP XXXX
Port XXXX
2
Port
8001
16
Port
8015
Ethernet LAN
Select a desired communication
method for each connection
IP XXXX
Port XXXX
IP XXXX
Port XXXX
FP7 CPU
1
Port
8000
External
device
2
Port
8001
16
Port
8015
Ethernet LAN
Select a desired communication
method for each connection
IP XXXXXX
Port
XXXX
Port
XXXX
Port
XXXX
IP XXXXXX
Note) Circled numbers in the figure above indicate examples of allocation of connection numbers.
Connection operation
•Connection is opened from either the FP7 CPU unit side or the external device side.
•The open method should be selected from server connection (unspecified partner), server
connection (specified partner), and client connection, in the configuration menu of FPWIN
GR7.
•Once connection is established, communication by a user program becomes possible in
accordance with the operation mode.
Supported operation mode
Communication
port
MEWTOCOL-DAT MEWTOCOL7-COM
MEWTOCOL-COM
MODBUS-TCP General-
purpose
communication
Master
Slave
Master
Slave
Master
Slave
LAN port ●●○ (Note) ●●●●
(Note) MEWTOCOL7-COM does not support master functions.
1-5

Communication Functions of CPU Unit
1.3 Overview of Communication Functions
1.3.1 MEWTOCOL-DAT Master/Slave Communication
(Binary Communication)
Overview of function
•Execute communication using MEWTOCOL-DAT, a communication protocol usd by our PLC.
•One of the PLC has the sending right, and executes communication by sending commands
to PLCs that support MEWTOCOL-DAT, and receiving responses.
•The slave-side PLC responds automatically, so no program concerning communication is
necessary.
•Also on the master-side PLC, messages in accordance with the protocol are automatically
generated by PLC. In the user program, reading and writing can be done between PLCs
simply by specifying the station no. and memory address and executing SEND/RECV
commands.
•This is suitable for sending/receiving data between PLCs, because the data size that can be
transmitted in a single communication is larger, and the transmission format is simpler and
shorter, than the MEWTOCOL-COM communication (ASCII communication).
•The data size that can be sent or received in a single communication is up to 2038 words for
register transmission and 1 bit for bit transmission.
(Note) In the case of connection with our PLC FP2 ET-LAN unit, the maximum size is 1020 words.
FP7 CPU Our PLC supporting
MEWTOCOL-DAT
Ethernet LAN
IP XXXXXX IP XXXXXX
Send/receive data using
MEWTOCOL-DAT
Command
Master
communication
Slave
communication
Response
Command
Response
Purpose of MEWTOCOL-DAT communication
This is used for sending data with our PLC that supports MEWTOCOL-DAT via Ethernet.
•Programmable controller FP series
KEY POINTS
•When MEWTOCOL-DAT master/slave communication is used, select
"TCP/IP" for the communication protocol in order to guarantee the reliability
of communication.
1-6

1.3 Overview of Communication Functions
1.3.2 MEWTOCOL-COM Master/Slave Communication
(ASCII Communication)
Overview of function
• Execute communication using MEWTOCOL-COM, a communication protocol used by our PLC.
•One of the device has the sending right, and executes communication by sending
commands to devices that support MEWTOCOL-COM, and receiving responses.
•The slave-side PLC responds automatically, so no program concerning communication is
necessary.
•Also on the master-side PLC, messages in accordance with the protocol are automatically
generated by PLC. In the user program, reading and writing can be done simply by
specifying the station no. and memory address and executing SEND/RECV commands.
•Because MEWTOCOL-COM communication is on an ASCII basis, it is suitable for
sending/receiving text data.
•The data size that can be sent or received in a single communication is up to 507 words for
register transmission and 1 bit for bit transmission.
FP7 CPU Device supporting
MEWTOCOL-COM
Ethernet LAN
IP XXXXXX IP XXXXXX
Send/receive data using
MEWTOCOL-COM
Command
Master
communication
Slave
communication
Response
Command
Response
Applications of MEWTOCOL-COM communication
This is used for sending text data between our devices that support MEWTOCOL-COM via
Ethernet. This method can also be used for connecting a programming tool.
•Programmable controller FP series
1-7

Communication Functions of CPU Unit
1.3.3 MODBUS TCP Master/Slave Communication
Overview of function
•This is used for communicating with other devices that support the MODBUS TCP protocol.
•In master communication, communication is performed when the master unit sends
instructions (command messages) to slave units and the slave unit returns responses
(response messages) according to the instructions. Messages in accordance with the
protocol are automatically generated by PLC. In the user program, reading and writing can
be done simply by specifying the station no. and memory address and executing
SEND/RECV commands.
•Slave communication is performed when the higher device connected to PLC has the
sending right, and sends commands, and PLC returns responses. In slave communication,
PLC responds automatically, so no program concerning communication is necessary on the
PLC side.
•The data size that can be sent or received in a single communication is up to 127 words for
register transmission and 2040 bit for bit transmission.
FP7 CPU MODBUS-TCP
supporting device
Ethernet LAN
IP XXXXXX IP XXXXXX
Send/receive data using
MODBUS-TCP
Command
Master
communication
Slave
communication
Response
Command
Response
1-8

1.3 Overview of Communication Functions
1.3.4 General-Purpose Communication
Overview of function
•General-purpose communication is used when PLC executes communication in accordance
with the command specifications of the partner device.
•Formulation and sending of command messages to the partner device, and reception
processing of responses from the partner device, are performed by the user program.
Sending/receiving of data with an external device is executed via given operation memory
(e.g. data register).
•Data are sent by setting message/data in a given data register in accordance with the
partner device, and executing GPSEND command.
•Data received from the partner device are temporarily saved in the buffer. Based on the
reception done flag, GPRECV command is executed and the received data are copied into a
given operation memory. The received data can be converted into numerical data, etc. as
necessary, by the user program.
•The data size that can be sent or received in a single communication is up to 16,372 bytes
per connection.
(Note 1) When a dedicated header is not attached, the size is up to 16,384 bytes.
(Note 2) In the case of connection with our PLC FP2 ET-LAN unit, the maximum size is 8,192 bytes.
FP7 CPU External device
Ethernet LAN
IP XXXXXX IP XXXXXX
Send/receive message/data
Message/data
Send
Receive
Operation
memory
Message/data
Applications of general-purpose communication
This is used for communication with devices made by differing manufacturers that have
dedicated communication protocols.
1-9

Communication Functions of CPU Unit
1.4 Terms
The following terms are used for settings on the software for connecting the FP7 CPU unit to
Ethernet LAN, and in the Users Manuals.
Server connection and client connection
•These indicate methods for connecting a virtual communication line between FP7 and an
external device.
•"Server connection" refers to a method to wait for connection from another client.
•"Client connection" refers to a method to connect a virtual communication line from the FP7
CPU unit to another external device port. Even if connection fails, repeated connection
attempts are made at a specified interval.
Master communication and slave communication
•These indicate methods for actually sending/receiving messages and data between FP7 and
an external device.
•In master communication, PLC sends commands and receives responses.
•In slave communication, commands are received from an external device, and responses
are returned.
•In a system using FP7, whether server connection or client connection is selected, once
connection is opened and a virtual communication line is connected, commands and
responses can be sent and received from both sides.
FP7 CPU
(server
connection)
External device
(client connection)
IP XXXXXX IP XXXXXX
Master
communication
Slave
communication
Ethernet
LAN
Command
Response
Command
Response
FP7 CPU
(client connection)
External device
(server
connection)
IP XXXXXX IP XXXXXX
Master
communication
Slave
communication
Ethernet
LAN
Command
Response
Command
Response
Virtual line connection
from external device
Virtual line connection
from FP7 CPU
1-10

2
Installation and Wiring

Installation and Wiring
2.1 Installation Environment and Wiring for LAN Ports
2.1.1 Before Installation and Wiring
Noise resistance of Ethernet
The Ethernet is a network used in offices and buildings, where there is comparatively little
noise. It does not have a higher resistance to noise than ordinary FA application networks.
Caution is required when installing the hub, and when laying cables.
2.1.2 Installation Environment and Noise Control Measures
Measures that can be taken in the installation environm ent
•The CPU unit, transceiver, hub, and communication cables should be installed as far as
possible from high-voltage wires, high-voltage equipment, power lines, power equipment,
equipment that generates strong breaker surges, and the wiring for any of this equipment. At
least 100 mm of clearance should be allowed when installing the equipment.
•When a device must be installed or a cable must be laid near a noise-generating device for
special reasons, take measures such as:
• install a programmable controller and a hub within a metal panel,
• laying a communication cable inside a metal duct,
• attaching a ferrite core near the CPU unit on the communication cable,
etc.
•An alternative measure is to use an optical transceiver close to the noise-generating section
of the equipment and install an optical fiber to keep the noise from affecting nearby
equipment. (This is also effective as a lightning shield for outdoor wiring.)
•Metal panels and metal ducts should be grounded at a grounding resistance of 100 Ω or less.
Also, metal panels and metal ducts should be insulated so that they do not come in contact
with communication devices or cables.
2-2
