Panasonic HL-CK614S User manual

Operating Instructions
Installation Instructions
Electric Built-in Oven
IMPORTANT SAFETY INSTRUCTIONS: Before operating this oven, please read these
instructions carefully and keep for future reference.
FOR DOMESTIC USE ONLY
Model No. HL-CK614S

2

3
■This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
■WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years of
age shall be kept away unless continuously supervised.
■WARNING:Dangerofre:donotstoreitemsonthe
cooking surfaces.
■WARNING: Ensure that the appliance is switched off
before replacing lamp to avoid the possibility of electric
shock.
■Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
■Do not use steam cleaners or high-pressure cleaners
to clean the cooking appliance, as this may result in an
electric shock.

4
Contents
Thank you for purchasing a Panasonic electric oven.
Important safety instructions....................................................................................................5-7
Outline diagram .......................................................................................................................8-9
Operation modes................................................................................................................. 10-11
Before using your oven.............................................................................................................12
Using your oven...................................................................................................................13-16
Accessories .........................................................................................................................16-17
Food preparation .................................................................................................................18-27
Cleaning and maintenance..................................................................................................28-33
Questions and answers.......................................................................................................34-35
Installation and connection..................................................................................................35-38
Technical Specications ...........................................................................................................39

5
Installation and Connection
Examine your oven
Please make sure the appliance was supplied to you undamaged. Remove all packaging and
examine the oven for any damage such as dents, broken door latches or cracks in the door. If you
nd any damage, notify your dealer immediately. Do not install a damaged oven.
Identication label
The identication label indicating the basic information of the appliance is attached to the inside of
the oven and is visible when you open the door. (see page 8). Do not remove the label.
Examine your oven
Oven connection should be carried out in compliance with the instructions in the section
“Connection to the power mains” (pg 37), and the relevant effective regulations and standards.
The appliance must be properly earthed for personal safety.
Servicing and Repairs
Servicing and repairs should only be carried out by a qualied electrician. If the appliance is
defective, disconnect from mains or switch off the appliance at the circuit breaker in the fuse box.
Contact the nearest authorised dealer.
This manual constitutes an integral part of the appliance. It should be kept intact and at hand for the
appliance’s entire life cycle. It is important to carefully read this manual and all of the instructions
contained herein before using the appliance.
WARNING
Only a qualied electrician may connect the appliance.
WARNING
Remove all internal and external packaging. Please ensure all internal packaging is
removed before switching the oven on.
WARNING
You will lose your warranty entitlement in the event of any damage caused by incorrect
installation.
Important safety instructions
Sprays, areosols and inammable subtances
Spray canisters, areosols and other inammable substances can ignite when heated. Do not store
or use such item near the oven.

6
Improper Use
Do not place empty cookware inside the oven.
Never obstruct the openings and slits provided for ventilation and heat dispersal.
Do not rest any weight or sit on the open door of the appliance.
To avoid a short circuit, ensure that the power cords of appliances located near this appliance are
not caught in the oven door.
Do not use sealed tins or containers in the appliance. Overpressure may occur inside the containers
during cooking, creating a danger of explosion.
Do not leave the appliance unattended during cooking processes where fats or oils could be
released. Fats and oils may catch re.
Do not cover the bottom of the oven with aluminium or tinfoil sheets during cooking and do not place
pans or trays on it to avoid damage to the enamelled surface.
Do not attempt to tamper with or make any adjustments or repairs to the door, control panel
housing, safety interlock switches or any other part of the oven. Repairs should only be carried out
by service technicians authorised by the appliance manufacturer.
All cooking operations must take place with the door closed.
Risk of Burns
The appliance becomes very hot during use. Suitable heat-proof gloves should always be worn.
Never prepare food containing high alcohol content. Alcoholic vapours can catch re in the oven
cavity.
WARNING
The appliance is intended solely for cooking. Do not use it for any other purpose, e.g.
for room heating.
WARNING
The manufacturer cannot be held liable for damage to persons or items caused by
failure to observe the above instructions, by interference with any part of the appliance
or by the use of non-original spare parts.
Important safety instructions

7
Important safety instructions
This symbol on the products and/or accompanying documents means that used electrical and
electronic products should not be mixed with general household waste.
For proper treatment, recovery and recycling, please take these products to designated collection
points, where they will be accepted on a free of charge basis. Alternatively, in some countries you
may be able to return your products to your local retailer upon the purchase of an equivalent new
product.
Disposing of this product correctly will help to save valuable resources and prevent any potential
negative effects on human health and the environment which could otherwise arise from
inappropriate waste handling. Please contact your local authority for further details of your nearest
designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for the
correct method of disposal.
Information on Disposal for Users of Waste Electrical &
Electronic Equipment (private households)
Information on Disposal in other Countries outside the European Union

8
Outline diagram
1On/Off and function dial
2Program timer (see page 13)
3Temperature dial
4Temperature indicator light. The light is on
until the set temperature is reached.
This illustration is for reference only.
1. Grill elements
2. Oven lamp
3. Oven fan
4. Identication label
5. Door glass release
6. Control Panel
7. Air vents
8. Shelving guides
9. Shelving clips
10. Door hinge
11. Door glass
123
4
6
7
8
1
2
3
4
5
10
99
11

9
The oven is operated by the function and the temperature
dials.
• Push the dial slightly, to make it pop out of the control
panel. After use press it back into its recessed position,
ush with the control panel.
On/off and function dial. Temperature dial
Operation dials
The recessed dial may only be pushed back into its recessed postion when it is in the
“off” position.
Note: When using the Full grill or Half grill , set the temperature selection dial to the
position indicated .

10
Operation modes
Fan grill
The upper heater and the fan are activated simultaneously. It
is appropriate for grilling and browning large pieces of meat,
poultry or gratins on one shelf level.
Half grill
The inner heater is activated. This mode is appropriate for
grilling smaller quantities of toasted sandwiches, sausages
or bread.
Oven lighting
There is one interior lighting lamp: on the upper part of the
back wall. Oven lighting can be selected independently. With
all other modes of operation, the oven lighting is turned on
automatically when the operation mode is selected.
Full grill
The inner and the outer heaters are activated simultaneously.
This operation mode is appropriate for cooking smaller pieces
of meat, such as steaks, roasts, chops, ribs, etc.
Upper / lower heater
The heaters on the upper and lower side of the oven radiate
uniformly and evenly into the oven interior. Pastries, cakes
and meat can be cooked on one shelf level only.
