Panasonic HL-PF685SEPG Product guide

Operating / Installation Instructions
Built-in Electric Oven
FOR DOMESTIC USE ONLY
Model No. HL-PF685S
HL-PF685B
HL-PF685S

IMPORTANT SAFETY INSTRUCTIONS: Before operating this appliance, please read these
instructions carefully and keep for future reference.

3
English
Thank you for purchasing this Panasonic appliance.
Contents
Operating Instructions �������������������������4-49
Safety Instructions ....................................4-7
Disposal of Waste Products ........................ 8
Energy Saving Tips ..................................... 8
Before Using Your Oven .............................. 9
Features and Functions ........................10-11
Oven Equipment and Accessories ............ 12
General Controls ....................................... 13
Using the Appliance ..............................14-28
• Setting the Clock ................................ 14
• Cooking Modes .................................. 15
• Auto Mode .....................................16-17
• Manual Mode ................................18-19
• Operation Modes ................................ 20
• Delayed start ....................................... 21
• Multi-stage Cooking ........................... 22
• Starting the Cooking Process ............. 23
• End of Cooking ................................... 23
• Saving to Memory .............................. 24
• Extras and Additional Functions ....25-27
• Pyro clean ...................................... 25
• Warming ......................................... 25
• Defrost ............................................ 25
• Fast Preheat ................................... 26
• Plate Warming ................................ 26
• Child Lock ....................................... 27
• Oven Lighting ................................. 27
• Kitchen Timer ................................. 27
• General Settings ................................ 28
• Language ....................................... 28
• Time ............................................... 28
• Display ............................................ 28
• Sound ............................................. 28
• Other Settings ................................ 28
Cooking Charts .....................................29-40
• Upper / Lower Heater ....................30-31
• Full Grill / Half Grill ........................32-33
• Fan Grill .............................................. 34
• Convection and Lower Heater ............ 35
• Convection ....................................36-37
• Eco Cooking ....................................... 38
• Lower Heater and Fan ..................38-39
• Auto Roast Mode ............................... 40
Maintenance and Cleaning ...................41-48
Troubleshooting ......................................... 49
Installation Instructions ���������������������50-53
Specications ������������������������������������������ 54

4
nThis appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
nWARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years of
age shall be kept away unless continuously supervised.
nWARNING: Danger of re: do not store items on the
cooking surfaces.
nDo not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
nDo not use steam cleaners or high-pressure cleaners
to clean the cooking appliance, as this may result in an
electric shock.
nWARNING: Before replacing the light bulb, make sure
the appliance has been disconnected from the mains
power, in order to prevent an electric shock.
nThe appliance is not intended to be controlled with
external timers or special control systems.
Safety Instructions
Operating Instructions

5
English
nThe appliance is intended for household use. Do not use it for
any other purpose, such as room heating, the drying of paper
or fabrics, etc. as this may lead to injury or re hazard.
nTampering with the appliance or non-professional repair thereof
may result in risk of severe injury or damage to the product.
nIf the power cord is damaged, it should be replaced by the
manufacturer or an authorised service technician, in order to
avoid hazard.
nDo not line the oven walls with aluminium foil and do not
place baking trays or other cookware on the base of the oven.
Aluminium foil could prevent air circulation in the oven, hinder
the cooking process, and damage the enamel coating.
nThe appliance becomes very hot during use. Suitable
heat-proof gloves should be worn.
nOven door hinges may be damaged when under excessive
load. Do not place heavy pans on open oven door and do not
lean against open oven door when cleaning the oven cavity.
Never stand on the open oven door and do not let children sit
on it.
nMake sure the vents are never covered or obstructed in any
way.
nSpray canisters, areosols and other inammable substances
can ignite when heated. Do not store or use these items near
the oven.
nDo not use sealed tins or containers in the appliance.
nTake care when cooking with fats and oils.
Safety Instructions

6
nDo not attempt to tamper with or make any adjustments or
repairs to the door, control panel housing, safety interlock
switches or any other part of the oven. Repairs should only be
carried out by service technicians authorised by the appliance
manufacturer.
nAll cooking operations must take place with the door closed.
nThe appliance becomes very hot during use. Suitable heat-
proof gloves should always be worn.
nTake care when cooking foods containing high alcohol content.
Alcoholic vapours may ignite.
nThe socket the oven is plugged into must be connected to the
household main circuit board.
nThe manufacturer cannot be held liable for damage to persons
or items caused by failure to observe the above instructions,
by interference with any part of the appliance or by the use of
non-original spare parts.
Safety Instructions

7
English
nBefore activating the automatic cleaning process, remove
any cookware that is not part of the oven equipment.
nDuring the automatic cleaning process, the oven gets very
hot from the outside. Risk of burns! Keep children away
from the oven.
nBefore activating the automatic cleaning process,
carefully read and follow the instructions in the chapter
Maintenance and Cleaning (see page 41).
nDo not place anything directly onto the base of the oven.
nThe telescopic guides cannot be cleaned using Pyro
clean.
nPieces of food and grease may ignite during the
automatic pyrolytic cleaning process.
nDanger of fire! Remove larger food residue and other
impurities from the oven before using the automatic
cleaning process.
nMake sure no impurities enter the door lock latch. This
could prevent automatic locking of oven door during the
automatic cleaning procedure.
nIn case of a power outage during the pyrolytic cleaning
process, the program is terminated after two minutes and
the oven door remains locked. The door will be unlocked
approximately 30 minutes after power supply is restored,
regardless of whether the appliance has cooled down.
nWhen using the pyrolytic cleaning function the surfaces
may get hotter than usual and children should be kept
away.
Safety Instructions
Pyro cleaning

8
Information on Disposal
for Users of Waste
Electrical & Electronic
Equipment (private
households)
This symbol on the products and/or
accompanying documents means that used
electrical and electronic products should not
be mixed with general household waste.
For proper treatment, recovery and recycling,
please take these products to designated
collection points, where they will be accepted
on a free of charge basis.
Alternatively, in some countries you may be
able to return your products to your local
retailer upon the purchase of an equivalent
new product.
Disposing of this product correctly will help
to save valuable resources and prevent any
potential negative eects on human health
and the environment which could otherwise
arise from inappropriate waste handling.
Please contact your local authority for further
details of your nearest designated collection
point.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
Information on Disposal in other
Countries outside the European
Union
This symbol is only valid in the European
Union.
If you wish to discard this product, please
contact your local authorities or dealer and
ask for the correct method of disposal.
Disposal of Waste Products
• Certain foods do not need a preheated oven. Do not preheat the oven unless
necessary or stated in the recipe.
• Do not use full grill if half grill will be sucient.
• Where possible, cook multiple items at once. This will lower the amount of time
that the oven is in use.
• Plan ahead. If you will be cooking food that will keep (puddings, cakes, pastries
etc.), do so whilst the oven is still hot from cooking a meal as you will only have to
heat up the oven once. This will also save time later on.
• Remove any accessories from the oven that are not required for cooking.
• Avoid opening the door during cooking.
• Do not use the cavity lighting unless necessary.
Energy Saving Tips

9
English
This manual constitutes an integral part of the appliance. It should be kept intact and
at hand for the appliance’s entire life cycle. It is important to carefully read this manual
and all of the instructions contained herein before using the appliance.
Examine your oven
Please make sure the appliance was supplied to you undamaged. Remove all
packaging and examine the oven for any damage such as dents, broken door latches
or cracks in the door. If you nd any damage, notify your dealer immediately. Do not
install a damaged oven.
Rating plate
The Rating Plate indicating the basic information of the appliance is attached to
the inside of the oven and is visible when you open the door (see page 10). Do not
remove.
• Before using the oven for the rst time, run Convection at 250 °C for 5 minutes. A
specic odour of a 'new appliance' will be present. Make sure the room is ventilated.
• After the oven has cooled down, clean the inside and all accessories with warm
water and a conventional detergent. Do not use abrasive cleaning aids.
Before Using Your Oven
WARNING
Remove all internal and external packaging. Please ensure all internal
packaging is removed before switching the oven on.

10
Features and Functions
1. Door Lock Latch
2. Control Panel
3. Guides / Shelf Positions (1-5)
4. Oven Door
5. Door Handle
6. Rating Plate
5
2
6
4
3
1
