Panasonic Projector RS-232C Control Specifications
PT-FW300NT/FW300/F300NT/F300

2/49
Using the Serial Terminal
1. Basic Format
Transmission from the computer begins with STX, then the command, parameter and ETX are sent in this
order.
Add parameters according to the details of control.
Basic control command (without parameter)
Start (STX) Command End (ETX)
1 byte 3 bytes 1 byte
Basic control command (with parameters)
Start (STX) Command Separator
(colon)
Parameters End (ETX)
1 byte 3 bytes 1 byte Undefined length 1 byte
Response (Callback) of the basic control command
In the period when the command can be accepted
Differs according to each command.
In the period when commands cannot be accepted or the command does not exist
Hexadecimal 02h 45h 52h 34h 30h 31h 03h
Character E R 4 0 1
In case of the parameter error
Hexadecimal 02h 45h 52h 34h 30h 32h 03h
Character E R 4 0 2
Notes:
• When sending several commands, be sure to wait for a response from the projector, and send the next
command after 0.5 seconds or more pass.
• It might take time by the time the response returns because the command is processed in the
projector. Set the time-out to 10 seconds or longer.

3/49
2. Basic Control Command
Explanatory notes
○: Yes (Enable)
×: No (Disable)
△: Case by case (Refer to the note.)
2.1. Power ON (Lamp ON)
Hexadecimal 02h 50h 4Fh 4Eh 03h
Character P O N
Response (Callback)
In the period when the command can be accepted (This command in power-on condition is included.)
Hexadecimal 02h 50h 4Fh 4Eh 03h
Character P O N
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○○○○△
Notes:
• When you confirm whether to have succeeded in power-on, confirm it by QPW (Query Power) command after
receiving the callback of PON command.
• When REMOTE is effective, ER401 is returned as a response (callback).
2.2. Power OFF (Standby)
Hexadecimal 02h 50h 4Fh 46h 03h
Character P O F
Response (Callback)
In the period when the command can be accepted (This command in power-off condition is included.)
Hexadecimal 02h 50h 4Fh 46h 03h
Character P O F
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○○○○△
Notes:
• When you confirm whether to have succeeded in power-off, confirm it by QPW (Query Power) command after
receiving the callback of POF command.
• When REMOTE is effective, ER401 is returned as a response (callback).
2.3. AUTO SETUP
Hexadecimal 02h 4Fh 41h 53h 03h
Character O A S
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 41h 53h 03h
Character O A S
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××△×○
Note:
• During NO SIGNAL, this command is available only when SIGNAL SEARCH is ON.
2.4. AV MUTE
Hexadecimal 02h 4Fh 53h 48h
3Ah
*1 03h
Character O S H : *2
Parameters (*1, *2)
AV MUTE OFF AV MUTE ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 48h 3Ah *1 03h
Character O S H : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××○○○

4/49
2.5. FREEZE
Hexadecimal 02h 4Fh 46h 5Ah
3Ah
*1 03h
Character O F Z : *2
Parameters (*1, *2)
FREEZE OFF FREEZE ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 46h 5Ah 3Ah *1 03h
Character O F Z : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.6. INPUT SELECT
Hexadecimal 02h 49h 49h 53h 3Ah
*1 *3 *5 03h
Character I I S : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
COMPUTER1 COMPUTER2
Hexadecimal 52h 47h 31h 52h 47h 32h
Character R G 1 R G 2
VIDEO S-VIDEO
Hexadecimal 56h 49h 44h 53h 56h 44h
Character V I D S V D
DVI NETWORK
Hexadecimal 44h 56h 49h 4Eh 57h 50h
Character ＤV I N W P
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 49h 49h 53h 3Ah *1 *3 *5 03h
Character I I S : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×△○○△
Notes:
• During STANDBY, this command is available only when IN STANDBY MODE is ON.
• REMOTE is given to priority. Calls back ER402 if INPUT SELECT by REMOTE is effective.
2.7. MENU
Hexadecimal 02h 4Fh 4Dh 4Eh 03h
Character O M N
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Dh 4Eh 03h
Character O M N
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○×○×○
2.8. ENTER
Hexadecimal 02h 4Fh 45h 4Eh 03h
Character O E N
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 45h 4Eh 03h
Character O E N
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○×○×○

5/49
2.9. Navigation Up (↑)
Hexadecimal 02h 4Fh 43h 55h 03h
Character O C U
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 55h 03h
Character O C U
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○×○×○
2.10. Navigation Down (↓)
Hexadecimal 02h 4Fh 43h 44h 03h
Character O C D
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 44h 03h
Character O C D
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○×○×○
2.11. Navigation Left (←)
Hexadecimal 02h 4Fh 43h 4Ch 03h
Character O C L
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 4Ch 03h
Character O C L
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○×○×○
2.12. Navigation Right (→)
Hexadecimal 02h 4Fh 43h 52h 03h
Character O C R
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 52h 03h
Character O C R
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○×○×○
2.13. DEFAULT
Hexadecimal 02h 4Fh 53h 54h 03h
Character O S T
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 54h 03h
Character O S T
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○×○×○
2.14. RETURN
Hexadecimal 02h 4Fh 42h 4Bh 03h
Character O B K
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 42h 4Bh 03h
Character O B K
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
○×○×○

6/49
2.15. VOLUME +
Hexadecimal 02h 41h 55h 55h 03h
Character A U U
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 41h 55h 55h 03h
Character A U U
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×△××○
Note:
• During STANDBY, this command is available only when IN STANDBY MODE is ON.
2.16. VOLUME -
Hexadecimal 02h 41h 55h 44h 03h
Character A U D
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 41h 55h 44h 03h
Character A U D
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×△××○
Note:
• During STANDBY, this command is available only when IN STANDBY MODE is ON.
2.17. INDEX-window
Hexadecimal 02h 4Fh 49h 58h 03h
Character O I X
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 49h 58h 03h
Character O I X
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.18. DIGITAL ZOOM +
Hexadecimal 02h 44h 5Ah 55h 03h
Character D Z U
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 44h 5Ah 55h 03h
Character D Z U
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.19. DIGITAL ZOOM -
Hexadecimal 02h 44h 5Ah 44h 03h
Character D Z D
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 44h 5Ah 44h 03h
Character D Z D
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○

7/49
2.20. COMPUTER SEARCH
Hexadecimal 02h 4Fh 50h 43h 03h
Character O P C
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 50h 43h 03h
Character O P C
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××○×○
Note:
• This command is available only for PT-FW300NT**/F300NT**.
2.21. PAGE Up (↑)
Hexadecimal 02h 4Fh 55h 50h 03h
Character O U P
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 55h 50h 03h
Character O U P
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.22. PAGE Down (↓)
Hexadecimal 02h 4Fh 44h 50h 03h
Character O D P
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 44h 50h 03h
Character O D P
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.23. MULTI-LIVE
Hexadecimal 02h 4Fh 4Dh 4Ch 03h
Character O M L
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Dh 4Ch 03h
Character O M L
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○

8/49
2.24. PICTURE MODE
Hexadecimal 02h 56h 50h 4Dh 3Ah *1 *3 *5 03h
Character V P M : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
DYNAMIC NATURAL STANDARD BLACKBOARD
Hexadecimal 44h 59h 4Eh 4Eh
41h
54h
53h
54h
44h 42h 42h 44h
Character D Y N N A T S T D B B D
CINEMA
Hexadecimal 43h 49h 4Eh
Character C I N
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 50h 4Dh
3Ah
*1 *3 *5 03h
Character V P M : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• Parameters "NAT" is available when still image is displayed and "CIN" is available when moving image is
displayed.
2.25. CONTRAST
Hexadecimal 02h 56h 43h 4Eh
3Ah
*1 *3 *5 03h
Character V C N : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－32 －31 －30
Hexadecimal 2Dh 33h 32h 2Dh
33h 31h 2Dh
33h 30h
Character －3 2 －3 1 －3 0
30 31 32
Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h
Character 0 3 0 0 3 1 0 3 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 43h 4Eh 3Ah *1 *3 *5 03h
Character V C N : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.26. BRIGHTNESS
Hexadecimal 02h 56h 42h 52h
3Ah
*1 *3 *5 03h
Character V B R : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－32 －31 －30
Hexadecimal 2Dh 33h 32h 2Dh
33h 31h 2Dh
33h 30h
Character －3 2 －3 1 －3 0
30 31 32
Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h
Character 0 3 0 0 3 1 0 3 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 42h 52h 3Ah *1 *3 *5 03h
Character V B R : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○

9/49
2.27. COLOR
Hexadecimal 02h 56h 43h 4Fh
3Ah
*1 *3 *5 03h
Character V C O : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－32 －31 －30
Hexadecimal 2Dh 33h 32h 2Dh
33h 31h 2Dh
33h 30h
Character －3 2 －3 1 －3 0
30 31 32
Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h
Character 0 3 0 0 3 1 0 3 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 43h 4Fh 3Ah *1 *3 *5 03h
Character V C O : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• This command is acceptable only when moving image is displayed. In other cases, ER401 is returned.
2.28. TINT
Hexadecimal 02h 56h 54h 4Eh
3Ah
*1 *3 *5 03h
Character V T N : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－32 －31 －30
Hexadecimal 2Dh 33h 32h 2Dh
33h 31h 2Dh
33h 30h
Character －3 2 －3 1 －3 0
30 31 32
Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h
Character 0 3 0 0 3 1 0 3 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 4Eh 3Ah *1 *3 *5 03h
Character V T N : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• This command is acceptable only when moving image is displayed. In other cases, ER401 is returned.
2.29. SHARPNESS
Hexadecimal 02h 56h 53h 52h
3Ah
*1 *3 *5 03h
Character V S R : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
13 14 15
Hexadecimal 30h 31h 33h 30h 31h 34h 30h 31h 35h
Character 0 1 3 0 1 4 0 1 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 53h 52h 3Ah *1 *3 *5 03h
Character V S R : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○

10/49
2.30. COLOR TEMPERATURE
Hexadecimal 02h 4Fh 54h 45h
3Ah
*1 03h
Character O T E : *2
Parameters (*1, *2)
LOW DEFAULT HIGH
Hexadecimal 30h 31h 32h
Character 0 1 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 54h 45h 3Ah *1 03h
Character O T E : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.31. DAYLIGHT VIEW
Hexadecimal 02h 56h 58h 58h
3Ah
44h
4Ch
56h
49h
Character V X X : D L V I
Hexadecimal 30h 3Dh 2Dh *1 *3 *5 *7 *9 03h
Character 0 = + *2 *4 *6 *8 *10
Parameters (*1, *2, *3, *4, *5, *6, *7, *8, *9, *10)
FRONT INSTALLATION
OFF
Hexadecimal 30h 30h 30h 30h 30h
Character 0 0 0 0 0
AUTO
Hexadecimal 30h 30h 30h 30h 31h
Character 0 0 0 0 1
ON
Hexadecimal 30h 30h 30h 30h 32h
Character 0 0 0 0 2
REAR INSTALLATION
OFF
Hexadecimal 30h 30h 30h 30h 30h
Character 0 0 0 0 0
ON
Hexadecimal 30h 30h 30h 30h 31h
Character 0 0 0 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 44h 4Ch 56h 49h
Character V X X : D L V I
Hexadecimal 30h 3Dh 2Dh *1 *3 *5 *7 *9 03h
Character 0 = + *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○

11/49
2.32. TV-SYSTEM
Hexadecimal 02h 56h 53h 47h 3Ah *1 *3 *5 03h
Character V S G : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
AUTO NTSC NTSC4.43 PAL
Hexadecimal 41h 55h 54h 4Eh
54h
53h
4Eh
34h
34h
50h 41h 4Ch
Character A U T N T S N 4 4 P A L
PAL-M PAL-N SECAM
Hexadecimal 50h 41h 4Dh 50h
41h
4Eh
53h
45h
43h
Character P A M P A N S E C
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 53h 47h 3Ah
*1 *3 *5 03h
Character V S G : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××○×○
Note:
• This command is acceptable only when the input is VIDEO or S-VIDEO. In other cases, ER401 is returned.
2.33. NOISE REDUCTION
Hexadecimal 02h 56h 4Eh 52h
3Ah
*1 03h
Character V N R : *2
Parameters (*1, *2)
OFF ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 4Eh 52h 3Ah *1 03h
Character V N R : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• This command is acceptable only when the input is VIDEO or S-VIDEO. In other cases, ER401 is returned.
2.34. WHITE BALANCE RED
Hexadecimal 02h 56h 57h 52h
3Ah
*1 *3 *5 03h
Character V W R : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－32 －31 －30
Hexadecimal 2Dh 33h 32h 2Dh
33h 31h 2Dh
33h 30h
Character －3 2 －3 1 －3 0
30 31 32
Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h
Character 0 3 0 0 3 1 0 3 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 57h 52h 3Ah *1 *3 *5 03h
Character V W R : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• Only when the input is DVI, COMPUTER1 or COMPUTER2, and still image is displayed, this command is
acceptable. In other cases, ER401 is returned.

12/49
2.35. WHITE BALANCE GREEN
Hexadecimal 02h 56h 57h 47h
3Ah
*1 *3 *5 03h
Character V W G : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－32 －31 －30
Hexadecimal 2Dh 33h 32h 2Dh
33h 31h 2Dh
33h 30h
Character －3 2 －3 1 －3 0
30 31 32
Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h
Character 0 3 0 0 3 1 0 3 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 57h 47h 3Ah *1 *3 *5 03h
Character V W G : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• Only when the input is DVI, COMPUTER1 or COMPUTER2, and still image is displayed, this command is
acceptable. In other cases, ER401 is returned.
2.36. WHITE BALANCE BLUE
Hexadecimal 02h 56h 57h 42h
3Ah
*1 *3 *5 03h
Character V W B : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－32 －31 －30
Hexadecimal 2Dh 33h 32h 2Dh
33h 31h 2Dh
33h 30h
Character －3 2 －3 1 －3 0
30 31 32
Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h
Character 0 3 0 0 3 1 0 3 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 57h 42h 3Ah *1 *3 *5 03h
Character V W B : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• Only when the input is DVI, COMPUTER1 or COMPUTER2, and still image is displayed, this command is
acceptable. In other cases, ER401 is returned.
2.37. KEYSTONE
Hexadecimal 02h 4Fh 4Bh 53h
3Ah
*1 *3 *5 03h
Character O K S : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－32 －31 －30
Hexadecimal 2Dh 33h 32h 2Dh
33h 31h 2Dh
33h 30h
Character －3 2 －3 1 －3 0
30 31 32
Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h
Character 0 3 0 0 3 1 0 3 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Bh 53h 3Ah *1 *3 *5 03h
Character O K S : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○×○

13/49
2.38. SHIFT H
Hexadecimal 02h 56h 48h 50h 3Ah
*1 *3 *5 *7 03h
Character V H P : *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6, *7, *8)
－127 －126
Hexadecimal 2Dh 33h 32h 37h 2Dh
33h 32h 36h
Character －1 2 7 －1 2 6
126 127
Hexadecimal 30h 33h 32h 36h 30h 33h 32h 37h
Character 0 1 2 6 0 1 2 7
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 48h 50h 3Ah *1 *3 *5 *7 03h
Character V H P : *2 *4 *6 *8
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• This command is not acceptable when the input is NETWORK. In this case, ER401 is returned.
2.39. SHIFT V
Hexadecimal 02h 56h 56h 50h
3Ah
*1 *3 *5 03h
Character V V P : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－64 －63 －62
Hexadecimal 2Dh 36h 34h 2Dh
36h 33h 2Dh
36h 32h
Character －6 4 －6 3 －6 2
62 63 64
Hexadecimal 30h 36h 32h 30h 36h 33h 30h 36h 34h
Character 0 6 2 0 6 3 0 6 4
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 56h 50h 3Ah *1 *3 *5 03h
Character V V P : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• This command is acceptable except when the input is NETWORK. Or, this command is acceptable when the
input is NETWORK and ASPECT is H-FIT (for FW300 series only). In other cases, ER401 is returned.
2.40. DOT CLOCK
Hexadecimal 02h 56h 44h 43h
3Ah
*1 *3 *5 03h
Character V D C : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－32 －31 －30
Hexadecimal 2Dh 33h 32h 2Dh
33h 31h 2Dh
33h 30h
Character －3 2 －3 1 －3 0
30 31 32
Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h
Character 0 3 0 0 3 1 0 3 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 44h 43h 3Ah *1 *3 *5 03h
Character V D C : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• Only when the input is COMPUTER1 or COMPUTER2, and still image is displayed, this command is acceptable.
In other cases, ER401 is returned.

14/49
2.41. CLOCK PHASE
Hexadecimal 02h 56h 43h 50h
3Ah
*1 *3 *5 03h
Character V C P : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－16 －15 －14
Hexadecimal 2Dh 31h 36h 2Dh
31h 35h 2Dh
31h 34h
Character －1 6 －1 5 －1 4
14 15 16
Hexadecimal 30h 31h 34h 30h 31h 35h 30h 31h 36h
Character 0 1 4 0 1 5 0 1 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 43h 50h 3Ah *1 *3 *5 03h
Character V C P : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• This command is acceptable only when the input is COMPUTER1 or COMPUTER2. In other cases, ER401 is
returned.
2.42. ASPECT
Hexadecimal 02h 56h 53h 31h
3Ah
*1 03h
Character V S 1 : *2
Parameters (*1, *2)
F300 series
AUTO
4:3 16:9 S4:3
THROUGH
Hexadecimal 30h 31h 32h 33h
34h
Character 0 1 2 3 4
FW300 series
AUTO
4:3 16:9 H-FIT
V-FIT
HV-FIT
THROUGH
Hexadecimal 30h 31h 32h 33h 34h 35h 36h
Character 0 1 2 3 4 5 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 53h 31h 3Ah *1 03h
Character V S 1 : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.43. FRAME LOCK
Hexadecimal 02h 56h 46h 4Ch
3Ah
*1 03h
Character V F L : *2
Parameters (*1, *2)
OFF ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 46h 4Ch 3Ah *1 03h
Character V F L : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○

15/49
2.44. LANGUAGE
Hexadecimal 02h 4Fh 4Ch 47h 3Ah
*1 *3 *5 03h
Character O L G : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6,)
English German French
Hexadecimal 45h 4Eh 47h 44h 45h 55h 46h 52h 41h
Character E N G D E U F R A
Spanish Italian Japanese
Hexadecimal 45h 53h 50h 49h 54h 4Ch
4Ah
50h 4Eh
Character E S P I T L J P N
Chinese Russian Korean
Hexadecimal 43h 48h 49h 52h 55h 53h 4Bh
4Fh 52h
Character C H I R U S K O R
Portuguese Swedish Norwegian
Hexadecimal 50h 4Fh 52h 53h 56h 45h 4Eh
4Fh 52h
Character P O R S V E N O R
Danish Polish Czech
Hexadecimal 44h 41h 4Eh
50h 4Fh 4Ch
43h 45h 53h
Character D A N P O L C E S
Hungarian Thai
Hexadecimal 4Dh
41h 47h 54h 48h 41h
Character M A G T H A
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Ch 47h 3Ah *1 *3 *5 03h
Character O L G : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○
2.45. INPUT GUIDE
Hexadecimal 02h 4Fh 49h 44h
3Ah
*1 03h
Character O I D : *2
Parameters (*1, *2)
OFF SIMPLE DETAILED
Hexadecimal 30h 31h 32h
Character 0 1 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 49h 44h 3Ah *1 03h
Character O I D : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○
2.46. STARTUP LOGO
Hexadecimal 02h 4Dh 4Ch 4Fh
3Ah
*1 03h
Character M L O : *2
Parameters (*1, *2)
OFF ON USER
Hexadecimal 30h 31h 32h
Character 0 1 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Dh 4Ch 4Fh 3Ah *1 03h
Character M L O : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○

16/49
2.47. COMPUTER2 SELECT
Hexadecimal 02h 4Fh 52h 49h 3Ah *1 *3 *5 03h
Character O R I : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
INPUT OUTPUT
Hexadecimal 32h 49h 4Eh 32h
4Fh
55h
Character 2 I N 2 O U
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 52h 49h 3Ah
*1 *3 *5 03h
Character O R I : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××○○○
Note:
• This command is not available when COMPUTER2 is selected.
2.48. NO SIGNAL SHUT-OFF
Hexadecimal 02h 4Fh 41h 46h 3Ah
*1 *3 03h
Character O A F : *2 *4
Parameters (*1, *2, *3, *4)
DISABLE 15 60
Hexadecimal 30h 30h 31h 35h 36h 30h
Character 0 0 1 5 6 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 41h 46h 3Ah *1 *3 03h
Character O A F : *2 *4
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○
2.49. INITIAL START UP
Hexadecimal 02h 4Fh 50h 59h
3Ah
*1 03h
Character O P Y : *2
Parameters (*1, *2)
STANDBY ON LAST MEMORY
Hexadecimal 30h 31h 32h
Character 0 1 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 50h 59h 3Ah *1 03h
Character C P Y : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××○○○
2.50. AUTO SETUP setting
Hexadecimal 02h 4Fh 53h 53h
3Ah
*1 03h
Character O S S : *2
Parameters (*1, *2)
BUTTON AUTO
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 53h 3Ah *1 03h
Character O S S : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○

17/49
2.51. SIGNAL SEARCH
Hexadecimal 02h 4Fh 53h 52h
3Ah
*1 03h
Character O S R : *2
Parameters (*1, *2)
OFF ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 52h 3Ah *1 03h
Character O S R : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○
2.52. INSTALLATION
Hexadecimal 02h 4Fh 49h 4Ch
3Ah
*1 03h
Character O I L : *2
Parameters (*1, *2)
FRONT/DESK REAR/DESK FRONT / CEILING REAR/CEILING
Hexadecimal 30h 31h 32h 33h
Character 0 1 2 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 49h 4Ch 3Ah *1 03h
Character O I L : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○×○
2.53. HIGH ALTITUDE MODE
Hexadecimal 02h 4Fh 46h 4Dh
3Ah
*1 03h
Character O F M : *2
Parameters (*1, *2)
OFF ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 46h 4Dh 3Ah *1 03h
Character O F M : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○
2.54. OSD DESIGN
Hexadecimal 02h 4Dh 4Fh 44h
3Ah
*1 03h
Character M O D : *2
Parameters (*1, *2)
TYPE1 TYPE2 TYPE3
Hexadecimal 30h 31h 32h
Character 0 1 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Dh 4Fh 44h 3Ah *1 03h
Character M O D : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○

18/49
2.55. SXGA MODE
Hexadecimal 02h 4Fh 53h 58h
3Ah
*1 03h
Character O S X : *2
Parameters (*1, *2)
SXGA SXGA+
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 58h 3Ah *1 03h
Character O S X : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.56. WIDE MODE
Hexadecimal 02h 4Fh 58h 47h
3Ah
*1 03h
Character O X G : *2
Parameters (*1, *2)
OFF ON AUTO
Hexadecimal 30h 31h 32h
Character 0 1 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 58h 47h 3Ah *1 03h
Character O X G : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
2.57. BACK COLOR
Hexadecimal 02h 4Fh 42h 43h
3Ah
*1 03h
Character O B C : *2
Parameters (*1, *2)
BLUE
BLACK
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 42h 43h 3Ah *1 03h
Character O B C : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○×○
2.58. VOLUME
Hexadecimal 02h 41h 56h 4Ch
3Ah
*1 *3 *5 03h
Character A V L : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
61 62 63
Hexadecimal 30h 36h 31h 30h 36h 32h 30h 36h 33h
Character 0 6 1 0 6 2 0 6 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 41h 56h 4Ch 3Ah *1 *3 *5 03h
Character A V L : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×△××○
Note:
• During STANDBY, this command is available only when IN STANDBY MODE is ON.

19/49
2.59. BALANCE
Hexadecimal 02h 41h 42h 4Ch
3Ah
*1 *3 *5 03h
Character A B L : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
－16 －15 －14
Hexadecimal 2Dh 31h 36h 2Dh
31h 35h 2Dh
31h 34h
Character －1 6 －1 5 －1 4
14 15 16
Hexadecimal 30h 31h 34h 30h 31h 35h 30h 31h 36h
Character 0 1 4 0 1 5 0 1 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 41h 42h 4Ch 3Ah *1 *3 *5 03h
Character A B L : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×△××○
Note:
• During STANDBY, this command is available only when IN STANDBY MODE is ON.
2.60. AV MUTE setting
Hexadecimal 02h 41h 4Dh 54h
3Ah
*1 03h
Character A M T : *2
Parameters (*1, *2)
OFF ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 41h 4Dh 54h
3Ah
*1
03h
Character A M T : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×△××○
Note:
• During STANDBY, this command is available only when IN STANDBY MODE is ON.
2.61. WIRELESS LAN
Hexadecimal 02h 4Fh 4Eh 53h 3Ah
*1 *3 *5 03h
Character O N S : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6,)
OFF 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
3 4 USER1
Hexadecimal 30h 30h 33h 30h 30h 34h 30h 30h 35h
Character 0 0 3 0 0 4 0 0 5
USER2 USER3 S-MAP
Hexadecimal 30h 30h 36h 30h 30h 37h 30h 30h 38h
Character 0 0 6 0 0 7 0 0 8
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Eh 53h 3Ah *1 *3 *5 03h
Character O N S : *2 *4 *6
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××××○
Note:
• This command is available only for PT-FW300NT**/F300NT**.

20/49
2.62. Wireless LAN OFF
Hexadecimal 02h 4Fh 52h 43h
3Ah
*1 03h
Character O R C : *2
Parameters (*1, *2)
OFF
Hexadecimal 31h
Character 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 52h 43h 3Ah *1 03h
Character O R C : *2
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
××○×○
Note:
• This command is available only for PT-FW300NT**/F300NT**.
2.63. Set Date
Hexadecimal 02h 54h 53h 44h 3Ah
Character T S D :
Hexadecimal *y1 *y2 *y3 *y4 *m1
*m2
*d1 *d2 *w 03h
Character
Parameters
*y1 - *y4: Year (4 digits)
*m1, *m2: Month (2 digits)
*d1, *d2: Day (2 digits)
*w: Day of the week (Mon = 1, Tue = 2, Wed = 3, Thu = 4, Fri = 5, Sat = 6, Sun = 7)
Set it by UTC (Coordinated Universal Time).
Example: Tuesday, April 1, 2008
*y1 *y2 *y3 *y4 *m1 *m2 *d1 *d2 *w
Hexadecimal 32h 30h 30h 38h 30h 34h 30h 31h 32h
Character 2 0 0 8 0 4 0 1 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 54h 53h 44h 3Ah *y1 *y2
Character T S D :
Hexadecimal *y3 *y4 *m1 *m2 *d1 *d2 *w 03h
Character
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○
2.64. Set Time
Hexadecimal 02h 54h 53h 54h
3Ah
Character T S T :
Hexadecimal *h1 *h2 *m1 *m2
*s1 *s2 03h
Character
Parameters
*h1, *h2: Hour (2 digits)
*m1, *m2: Minute (2 digits)
*s1, *s2: Second (2 digits)
Set it by UTC (Coordinated Universal Time).
Example: 3 seconds at 3:45 p.m.
*h1 *h2 *m1
*m2
*s1 *s2
Hexadecimal 31h 35h 34h 35h 30h 33h
Character 1 5 4 5 0 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 54h 53h 54h 3Ah
Character T S T :
Hexadecimal *h1 *h2 *m1 *m2 *s1 *s2 03h
Character
Acceptability
SECURITY STANDBY NO SIGNAL
AV MUTE
REMOTE
×○○○○
