Panasonic PT-EX500U User manual

Operating Instructions
Functional Manual
LCD Projector Commercial Use
Model No.
PT-EZ570E PT-EZ570EL
PT-EW630E PT-EW630EL
PT-EW530E PT-EW530EL
PT-EX600E PT-EX600EL
PT-EX500E PT-EX500EL
ENGLISH
LV4A
Thank you for purchasing this Panasonic Product.
Before operating this product, please read the instructions carefully, and save this manual for future use.
J
Before using your projector, be sure to read “Read this rst!” (
JÆpages 2 to 8).
The information of these instructions are shared use with multiple models of EZ570 series, EW630 series,
EW530 series, EX600 series and EX500 series.
Lens is optional for the projectors that “L” follows in model number.
J

2- ENGLISH
Important
Information
Read this rst!
WARNING: THIS APPARATUS MUST BE EARTHED.
WARNING: To prevent damage which may result in re or shock hazard, do not expose this appliance to rain
or moisture.
Machine Noise Information Ordinance 3. GSGV, January 18, 1991: The sound pressure level at the operator
position is equal or less than 70 dB (A) according to ISO 7779.
WARNING:
1. Remove the plug from the mains socket when this unit is not in use for a prolonged period of time.
2. To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to
qualied service personnel.
3. Do not remove the earthing pin on the mains plug. This apparatus is equipped with a three prong earthing
type mains plug. This plug will only t an earthing-type mains socket. This is a safety feature. If you are
unable to insert the plug into the mains socket, contact an electrician. Do not defeat the purpose of the
earthing plug.
CAUTION: To assure continued compliance, follow the attached installation instructions, which includes using
the provided power cord and shielded interface cables when connecting to computer or peripheral
device. If you use serial port to connect PC for external control of projector, you must use optional
RS-232C serial interface cable with ferrite core. Any unauthorized changes or modications to
this equipment will void the user’s authority to operate.
WARNING:
TURN OFF THE UV LAMP BEFORE OPENING THE LAMP COVER.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
Power Supply: This Projector is designed to operate on 100 V - 240 V, 50 Hz/60 Hz AC, house current only.
WARNING: RISK OF ELECTRIC SHOCK, DO NOT OPEN.
The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufcient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
product.
Product information (for Turkey only)
EEE Yönetmeliğine Uygundur.
EEE Complies with Directive of Turkey.

Read this rst!
ENGLISH - 3
Important
Information
IMPORTANT: THE MOULDED PLUG (U.K. only)
FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.
This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 13 amp fuse
is tted in this plug. Should the fuse need to be replaced, please ensure that the replacement fuse has a rating
of13 amps and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover, you must ensure that it is retted when the fuse is replaced. If you
lose the fuse cover, the plug must not be used until a replacement cover is obtained. A replacement fuse cover
can be purchased from an Authorised Service Center.
If the tted moulded plug is unsuitable for the mains socket in your home, then the fuse should be
removed and the plug cut off and disposed of safely. There is a danger of severe electrical shock if the
cut off plug is inserted into any 13 amp socket.
If a new plug is to be tted, please observe the wiring code as shown below.
If in any doubt, please consult a qualied electrician.
WARNING: THIS APPLIANCE MUST BE EARTHED.
IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:
Green - and - Yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wire in the mains lead of this appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows.
The wire which is coloured GREEN - AND - YELLOW must be connected to the terminal in the
plug which is marked with the letter E or by the Earth symbol or coloured GREEN or GREEN -
AND - YELLOW.
The wire which is coloured BLUE must be connected to the terminal in the plug which is marked
with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in the plug which is
marked with the letter L or coloured RED.
How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse.
13A250V BS1363/A
HE-8
N
ASA
L

Read this rst!
4- ENGLISH
Important
Information
WARNING:
POWER

The wall outlet or the circuit breaker shall be installed near the equipment and shall be easily
accessible when problems occur. If the following problems occur, cut off the power supply
immediately.
Continued use of the projector in these conditions will result in re or electric shock.
If foreign objects or water get inside the projector, cut off the power supply.
z
If the projector is dropped or the cabinet is broken, cut off the power supply.
z
If you notice smoke, strange smells or noise coming from the projector, cut off the power supply.
z
Please contact an Authorized Service Center for repairs, and do not attempt to repair the projector yourself.
During a thunderstorm, do not touch the projector or the cable.
Electric shocks can result.
Do not do anything that might damage the power cord or the power plug.
If the power cord is used while damaged, electric shocks, short-circuits or re will result.
Do not damage the power cord, make any modications to it, place it near any hot objects, bend it
z
excessively, twist it, pull it, place heavy objects on top of it or wrap it into a bundle.
Ask an Authorized Service Center to carry out any repairs to the power cord that might be necessary.
Insert the power plug securely into the wall outlet.
If the plug is not inserted correctly, electric shocks or overheating will result.
Do not use anything other than the provided power cord.
z
Do not use the provided power cord for other electrical equipment.
z
Do not use plugs which are damaged or wall outlets which are coming loose from the wall.
z
Clean the power plug regularly to prevent it from becoming covered in dust.
Failure to observe this will cause a re.
If dust builds up on the power plug, the resulting humidity can damage the insulation.
z
If not using the projector for an extended period of time, pull the power plug out from the wall outlet.
z
Pull the power plug out from the wall outlet and wipe it with a dry cloth regularly.
Do not handle the power plug with wet hands.
Failure to observe this will result in electric shocks.
Do not overload the wall outlet.
If the power supply is overloaded (ex., by using too many adapters), overheating may occur and re will result.
ON USE/INSTALLATION

Do not place liquid containers on top of the projector.
If water spills onto the projector or gets inside it, re or electric shocks will result.
If any water gets inside the projector, contact an Authorized Service Center.
Do not place the projector on soft materials such as carpets or sponge mats.
Doing so will cause the projector to overheat, which can cause burns, re or damage to the projector.
Do not set up the projector in humid or dusty places or in places where the projector may come into
contact with oily smoke or steam, ex. a bathroom.
Using the projector under such conditions will result in re, electric shocks or components deterioration.
Components deterioration (such as ceiling mount brackets) may cause the projector which is mounted on the
ceiling to fall down.
Do not install this projector in a place which is not strong enough to take the full weight of the
projector or on top of a surface which is sloped or unstable.
Failure to observe this will cause projector to fall down or tip over the projector, and severe injury or damage
could result.
Do not place another projector or other heavy objects on top of the projector.
Failure to observe this will cause the projector to become unbalanced and fall, which could result in damage or
injury. The projector will be damaged or deformed.

Read this rst!
ENGLISH - 5
Important
Information
WARNING:
Installation work (such as ceiling mount bracket) should only be carried out by a qualied technician.
If installation is not carried out and secured correctly it can cause injury or accidents, such as electric shocks.
Do not use anything other than an authorized ceiling mount bracket.
z
Be sure to use the wire provided with the projector mount base for ceiling mount as an extra safety
z
measure to prevent the projector from falling down. (Install in a different location to the ceiling mount
bracket.)
Do not cover the air inlet port or the air outlet port.
Doing so will cause the projector to overheat, which can cause re or damage to the projector.
Do not place the projector in narrow, badly ventilated places.
z
Do not place the projector on cloth or papers, as these materials could be drawn into the air inlet port.
z
Do not place your hands or other objects close to the air outlet port.
Doing so will cause burns or damage your hands or other objects.
Heated air comes out of the air outlet port. Do not place your hands or face, or objects which cannot
z
withstand heat close to this port.
Do not look and place your skin into the lights emitted from the lens while the projector is being used.
Doing so can cause burns or loss of sight.
Strong light is emitted from the projector’s lens. Do not look or place your hands directly into this light.
z
Be especially careful not to let young children look into the lens. In addition, turn off the power and
z
disconnect the power plug when you are away from the projector.
Do not insert any foreign objects into the projector.
Doing so will cause re or electric shocks.
Do not insert any metal objects or ammable objects into the projector or drop them onto the projector.
z
Never attempt to remodel or disassemble the projector.
High voltages can cause re or electric shocks.
For any inspection, adjustment and repair work, please contact an Authorized Service Center.
z
Do not project an image with the lens cover attached.
Doing so can cause re.
Do not allow metal objects, ammable objects, or liquids to enter inside of the projector. Do not allow
the projector to get wet.
Doing so may cause short circuits or overheating, and result in re, electric shock, or malfunction of the
projector.
Do not place containers of liquid or metal objects near the projector.
z
If liquid enters inside of the projector, consult your dealer.
z
Particular attention must be paid to children.
z
Use the ceiling mount bracket specied by Panasonic.
Defects in the ceiling mount bracket will result in falling accidents.
Attach the supplied safety cable to the ceiling mount bracket to prevent the projector from falling down.
z

Read this rst!
6- ENGLISH
Important
Information
WARNING:
ACCESSORIES

Do not use or handle the batteries improperly, and refer to the following.
Failure to observe this will cause burns, batteries to leak, overheat, explode or catch re.
Use AAA/R03 or AAA/LR03 batteries.
z
Do not use unspecied batteries.
z
Do not disassemble dry cell batteries.
z
Do not heat the batteries or place them into water or re.
z
Do not allow the + and
z
-
terminals of the batteries to come into contact with metallic objects such as
necklaces or hairpins.
Do not store batteries together with metallic objects.
z
Store the batteries in a plastic bag and keep them away from metallic objects.
z
Make sure the polarities (+ and
z
-
) are correct when inserting the batteries.
Do not use a new battery together with an old battery or mix different types of batteries.
z
Do not use batteries with the outer cover peeling away or removed.
z
Remove the empty batteries from the remote control at once.
z
Insulate the battery using tape or something similar before disposal.
z
Do not allow children to reach the batteries (AAA/R03 or AAA/LR03 type) and the lens antitheft screw.
The battery and the lens antitheft screw can cause personal injury if swallowed.
z
If swallowed, seek medical advice immediately.
z
If the battery uid leaks, do not touch it with bare hands, and take the following measures if necessary.
Battery uid on your skin or clothing could result in skin inammation or injury.
z
Rinse with clean water and seek medical advice immediately.
Battery uid coming in contact with your eyes could result in loss of sight.
z
In this case, do not rub your eyes. Rinse with clean water and seek medical advice immediately.
Do not disassemble the lamp unit.
If the lamp breaks, it could cause injury.
Lamp replacement
The lamp has high internal pressure. If improperly handled, an explosion and severe injury or accidents will
result.
The lamp can easily explode if struck against hard objects or dropped.
z
Before replacing the lamp, be sure to disconnect the power plug from the wall outlet.
z
Electric shocks or explosions can result if this is not done.
When replacing the lamp, turn the power off and allow the lamp it to cool for at least 1 hour before handling
z
it otherwise it can cause burns.
Do not allow infants or pets to touch the remote control unit.
Keep the remote control unit out of the reach of infants and pets after using it.
z
Do not use the supplied power cord with devices other than this projector.
Using the supplied power cord with devices other than this projector may cause short circuits or
z
overheating, and result in electric shock or re.
Remove the depleted batteries from the remote control promptly.
Leaving them in the unit may result in uid leakage, overheating, or explosion of the batteries.
z

Read this rst!
ENGLISH - 7
Important
Information
To remove the battery
Remote Control Battery
1. Press the guide and lift the cover. 2. Remove the batteries.
CAUTION:
POWER

When disconnecting the power cord, be sure to hold the power plug and power connector.
If the power cord itself is pulled, the lead will become damaged, and re, short-circuits or serious electric
shocks will result.
When not using the projector for an extended period of time, disconnect the power plug from the wall
outlet and remove the batteries from the remote control.
Disconnect the power plug from the wall outlet before carrying out any cleaning and replacing the unit.
Electric shocks can result if this is not done.
ON USE/INSTALLATION

Do not put your weight on this projector.
You could fall or the projector could break, and injury will result.
Be especially careful not to let young children stand or sit on the projector.
z
Do not place the projector in extremely hot locations.
Doing so will cause the outer casing or internal components to deteriorate, or result in re.
Take particular care in locations exposed to direct sunlight or near stoves.
z
Always disconnect all cables before moving the projector.
Moving the projector with cables still attached can damage the cables, which will cause re or electric shocks
to occur.
Never plug headphones and earphones into AUDIO OUT jack.
Excessive sound pressure from earphones and headphones can cause hearing loss.
ACCESSORIES

Do not use the old lamp unit.
If used it could cause lamp explosion.
If the lamp has broken, ventilate the room immediately. Do not touch or bring your face close to the
broken pieces.
Failure to observe this will cause the user to absorb the gas which was released when the lamp broke and which
contains nearly the same amount of mercury as uorescent lamps, and the broken pieces will cause injury.
If you believe that you have absorbed the gas or that the gas has got into your eyes or mouth, seek
z
medical advice immediately.
Ask your dealer about replacing the lamp unit and check the inside of the projector.
z
Do not attach wet air lter.
Doing so may result in electric shocks or malfunctions.
After washing the air lter, dry it thoroughly before attaching to the projector.
z

Read this rst!
8- ENGLISH
Important
Information
Trademarks
HDMI, the HDMI logo and High-Denition Multimedia Interface is a trademark or registered trademark of HDMI
•
Licensing LLC.
PJLink™ is a trademark or pending trademark in Japan, the United States, and other countries and region.
•
RoomView and Crestron RoomView are registered trademarks of Crestron Electronics, Inc. Crestron Connected
•
and Fusion RV are the trademarks of Crestron Electronics, Inc.
Other names, company names or product names used in these operating instructions are the trademarks or
•
registered trademarks of their respective holders.
Please note that the operating instructions do not include the ®and TM symbols.
Illustrations in these operating instructions
Note that illustrations of the projector and screens may differ from the ones you actually see.
•
Page references
In these instructions, references to pages are indicated as: (
•Æpage 00).
Term
In these instructions, the “Wireless/Wired remote control unit” accessory is referred to as the “Remote control”.
•

ENGLISH - 9
With the Direct Power Off function,
you can disconnect the power cord
from the wall outlet or turn off the
breaker even during projection.
The inclusion of an HDMI terminal
provides support for high quality
video and HDMI audio.
The digital zoom function allows
you to focus on the crucial
information during a presentation.
The projector is equipped with the
shutter that provides complete
blackness when the projected
image is not needed with keeping
the projector on. The shutter
management function allows you
to set the timer. It prevents from
keeping the projector on when the
shutter is closed for a long time.
*
This function is only for EZ570 series, EW630
series and EX600 series.
Direct Power Off Function
Improved connectivity
Useful Functions for Presentations
Shutter Function*
JQuick steps
For details, see the corresponding pages.
1. Set up your projector.
(Æpage 24)
2. Connect with other devices.
(Æpage 34)
3. Connect the power cord.
(Æpage 35)
4. Power on.
(Æpage 37)
5. Select the input signal.
(Æpage 40)
6. Adjust the image.
(Æpage 40)
Features of the Projector
J

10 - ENGLISH
Important
Information Preparation Getting Started Basic Operation Settings Maintenance Appendix
Contents Be sure to read “Read this rst!”. ( pages 2 to 8)
Important Information
Read this rst! ........................................... 2
Contents................................................... 10
Precautions for Use................................. 12
Cautions when transporting.......................................... 12
Cautions when handling the projector .......................... 12
Cautions when installing............................................... 12
Security ........................................................................ 14
Disposal........................................................................ 14
Cautions on use ........................................................... 14
Accessories .................................................................. 16
Optional accessories .................................................... 17
Preparation
About Your Projector .............................. 18
Remote control ............................................................. 18
Projector body .............................................................. 20
Side control and Indicators........................................... 21
Rear terminals .............................................................. 22
Using Remote control ............................. 23
Installing and Removing batteries ................................ 23
Setting Remote control ID numbers ............................. 23
Getting Started
Setting up................................................. 24
Projection method ........................................................ 24
Parts for ceiling mount (Optional)................................. 24
Removing and attaching the projection lens ................ 25
Screen size and throw distance ................................... 26
Adjusting front adjustable feet ...................................... 33
Connections............................................. 34
Before connecting to the projector ............................... 34
Connecting example..................................................... 34
Basic Operation
Powering ON/OFF.................................... 35
Connecting the power cord .......................................... 35
ON(G)/STANDBY(R) indicator...................................... 36
Turning On the Projector .............................................. 37
Enter a PIN code .......................................................... 38
Turning Off the Projector .............................................. 39
Projecting................................................. 40
Selecting the image...................................................... 40
Adjusting the image...................................................... 40
Basic operations by using the remote
control................................................... 41
Using the SHUTTER/ AV MUTE button ....................... 41
Switching the input signal............................................. 41
Using the MENU button................................................ 42
Using the AUTO PC ADJ button .................................. 42
Controlling the volume of the speaker.......................... 42
Using the IMAGE SELECT button ............................... 42
Using the MUTE button ................................................ 42
Using the IMAGE ADJUST button ............................... 42
Using the P-TIMER button ........................................... 43
Using the ECO button .................................................. 43
Using the SCREEN button ........................................... 43
Using the FREEZE function ......................................... 43
Using the D.ZOOM button............................................ 43
Using the LENS SHIFT button ..................................... 43
Using the KEYSTONE button....................................... 44
Using the ZOOM +/- buttons ........................................ 45
Using the FOCUS +/- buttons...................................... 45
Using the INFO button.................................................. 45
Using the P IN P button ................................................ 45
Settings
Menu Navigation...................................... 46
Navigating through the menu ....................................... 46
Main menu.................................................................... 47
Sub menu ..................................................................... 47
Input menu ............................................... 49
Input 1 .......................................................................... 49
Input 2 .......................................................................... 49
Input 3 .......................................................................... 49
AUTO PC adjust....................................... 51
Auto PC adj. ................................................................. 51
Manual PC adjust..................................... 52
Fine sync ...................................................................... 52
Total dots ...................................................................... 52
Position H ..................................................................... 52
Position V ..................................................................... 52
Current mode ............................................................... 53
Clamp ........................................................................... 53
Display area H.............................................................. 53
Display area V .............................................................. 53
Reset ............................................................................ 53
Mode free ..................................................................... 53
Store............................................................................. 53
Image select ............................................ 54
Dynamic ....................................................................... 54
Standard....................................................................... 54
Real .............................................................................. 54
Cinema ......................................................................... 54
Natural.......................................................................... 54

ENGLISH - 11
Important
Information
PreparationGetting StartedBasic OperationSettingsMaintenanceAppendix
Contents
Image 1-10 ................................................................... 54
Image adjust............................................. 55
Contrast........................................................................ 55
Brightness .................................................................... 55
Color............................................................................. 55
Tint .............................................................................. 55
Iris .............................................................................. 55
Color temp.................................................................... 56
Red .............................................................................. 56
Green ........................................................................... 56
Blue ............................................................................. 56
Offset............................................................................ 56
Daylight View................................................................ 56
Sharpness .................................................................... 57
Gamma......................................................................... 57
Noise reduction ............................................................ 57
Progressive .................................................................. 57
Reset ............................................................................ 57
Store............................................................................. 57
Screen ...................................................... 58
Normal.......................................................................... 58
Full .............................................................................. 58
Wide(16:9).................................................................... 58
Zoom ............................................................................ 58
True .............................................................................. 58
Natural wide ................................................................ 58
Custom ......................................................................... 58
Custom adj. .................................................................. 59
Digital zoom +............................................................... 59
Digital zoom - ............................................................... 59
Keystone ...................................................................... 59
Ceiling .......................................................................... 60
Rear.............................................................................. 60
Screen aspect .............................................................. 60
Reset ............................................................................ 60
Sound ....................................................... 61
Volume ......................................................................... 61
Built-in SP..................................................................... 61
Mute ............................................................................. 61
Setting ...................................................... 62
Language ..................................................................... 62
Menu/Menu position ..................................................... 62
Input button .................................................................. 62
Display.......................................................................... 63
Background .................................................................. 63
Logo ............................................................................. 63
Picture in Picture .......................................................... 64
HDMI setup .................................................................. 65
DVI signal level............................................................. 65
Lamp power.................................................................. 65
Fan control ................................................................... 65
Simple mode ................................................................ 66
Remote control ............................................................. 66
RC sensor .................................................................... 66
Eco management ......................................................... 66
Power management ..................................................... 67
Standby mode .............................................................. 67
Direct on ....................................................................... 67
P-timer.......................................................................... 67
Security ........................................................................ 68
Shutter.......................................................................... 68
Closed caption.............................................................. 69
Video delay control....................................................... 69
Filter counter ................................................................ 70
Test pattern................................................................... 70
Factory default.............................................................. 70
Information............................................... 71
Input Source Information Display ................................ 71
Network .................................................... 72
Projector name ............................................................. 72
Network setup .............................................................. 72
Network control ............................................................ 72
Network status.............................................................. 73
Network factory default................................................. 73
Network connections .................................................... 74
Accessing from the Web browser................................. 75
Maintenance
About indicator status ............................ 89
If an indicator turns on.................................................. 89
Maintenance/replacement....................... 93
Before cleaning/replacing the unit ................................ 93
Maintenance................................................................. 93
Replacing the unit......................................................... 95
Troubleshooting ...................................... 98
Appendix
Technical Information ........................... 100
PJLink protocol........................................................... 100
Control commands via LAN........................................ 101
Serial terminal ............................................................ 103
Other terminals........................................................... 106
List of Picture in Picture.............................................. 108
List of compatible signals ........................................... 109
Specications .........................................114
Dimensions..................................................................116
Ceiling mount bracket safeguards........116
Index ........................................................117

12 - ENGLISH
Important
Information
Precautions for Use
Cautions when transporting
When transporting the projector, hold it securely by its bottom and avoid
z
excessive vibration and impacts. Doing so may damage the internal parts
and result in malfunctions. You can also use the handle grip in the back of
the projector when transporting.
Do not transport the projector with the adjustable feet extended. Doing so
z
may damage the adjustable feet.
If you have purchased a projector with a standard projection lens, please
z
remove the lens cap on the lens before use, and keep it for later use. For
transportation, press and hold the <LENS> button or <LENS SHIFT>
button for more than 5 seconds to make the lens return to the central
position, and then attach the lens cap to protect the lens. If you have
purchased a projector without projection lens, please make the lens
return to the central position, and then attach the lens cover.
Use the handle grip when moving the projector.
z
Cautions when handling the projector
Do not hold the lens or the lens compartment tube when lifting or moving the projector. Doing so may cause
z
damage to the lens and the projector.
Care must be taken when handling the projector; do not drop, bump, subject it to strong forces, or put other
z
things on the cabinet.
Do not hold the lens and the peripheral part.
z
Cautions when installing
Do not set up the projector outdoors.
J
The projector is designed for indoor use only.
z
Do not use under the following conditions.
J
Places where vibration and impacts occur such as in a car or vehicle: Doing so may damage the internal parts
z
and result in malfunctions.
Near the exhaust of an air conditioner or near lights (studio lamps, etc.) where temperature changes greatly
z
(Operating environment Æpage 115): Doing so may shorten the life of the lamp or result in deformation of the
outer case and malfunctions.
Near high-voltage power lines or near motors: Doing so may interfere with the operation of the projector.
z
Be sure to ask authorized personnel or your supplier when mounting the
J
product to a ceiling.
This requires an optional ceiling mount bracket.
Model No.: ET-PKE200H (for high ceilings), ET-PKE200S (for low ceilings),
ET-PKE200B (Projector Mount Base).
Do not install the projector at elevations of 2 700 m (8 858 ft) or higher
J
above sea level.
Failure to do so may shorten the life of the internal parts and result in malfunctions.

Precautions for Use
ENGLISH - 13
Important
Information
Cautions when setting the projectors
J
When installing and using the projector with a method other than the oor standing installation using the
z
adjustable feet, x the projector using the ve screw holes for ceiling mounting (shown in the gure).
(Screw diameter:M6, tapping depth inside the set:12mm, torque: 4 ± 0.5 N•m)
Do not stack the projectors.
z
Do not block the ventilation ports (intake and exhaust) of the projector.
z
Avoid heating and cooling air from the air conditioning system directly
z
blow to the ventilation ports (intake and exhaust) of the projector.
Do not place the projector in an conned space.
z
When it is necessary to install in a conned space, install the air conditioning or ventilating installation
separately. Exhaust heat may accumulate when the ventilation is not enough, triggering the protection circuit
of the projector.
Do not use the projector tilted at an angle that exceeds ± 10 degrees vertically.
z
In upward and downward projection, do not tilt the projector over 10 degrees right and left.
z
-10°
+10°
Screw holes for ceiling mount (M6)
°°
10° 10°
over 50 cm
(20")
over 1 m (40")
over 50 cm
(20")
over 1 m (40")

Precautions for Use
14 - ENGLISH
Important
Information
Security
Take safety measures against following incidents.
J
Personal information being leaked via this product.
z
Unauthorized operation of this product by a malicious third party.
z
Interfering or stopping of this product by a malicious third party.
z
Security instruction (
JÆpages 68, 86)
Make your password as difcult to guess as possible.
z
Change your password periodically.
z
Panasonic or its afliate company never inquires a password directly to a customer. Do not tell your password
z
in case you receive such an inquiry.
The connecting network must be secured by rewall or others.
z
Set a password for web control and restrict the users who can log in.
z
Disposal
When disposing of the product, ask your local authority or dealer about the correct methods of disposal.
The lamp contains mercury. When disposing of the used lamp unit, ask your nearest local authorities or dealer
about proper disposal of the unit.
Dispose of used batteries according to the instructions or your local disposal rule or guidelines.
Cautions on use
In order to get the picture quality
J
Draw curtains or blinds over windows and turn off any lights near the screen to prevent outside light or light
z
from indoor lamps from shining onto the screen.
Depending on where the projector is used, heated air from an exhaust port or warm or cold air from an air
z
conditioner can cause a shimmering effect on screen.
Avoid use in locations where exhaust or streams of air from projector, other devices and air conditioners ow
between the projector and the screen.
The lens of projector is affected by the heat from the luminous source. Because of this, the focusing may not
z
be stable right after the power is turned on. Focusing is stabled after projecting image for 30 minutes and
longer.
Do not touch the surface of the projector lens with your bare hand.
J
If the surface of the lens becomes dirty from ngerprints or anything else, this will be magnied and projected
onto the screen.
LCD Panel
J
The display unit of this projector comprises three LCD panels. Although an LCD panel is a product of high-
precision technology, some of the pixels on the projected image may be missing or constantly lit. Please note that
this is not a malfunction.
Displaying a still image for a longer time may result in an after-image on the LCD panels. If this happens, display
the all white screen in the test pattern for an hour or more.
Optical components
J
Operating the projector in an environment with high temperature or heavy exposure to dust or tobacco smoke
will reduce the service life of the optical components, such as the LCD panel and polarizing plate, and may
necessitate their replacement within less than one year of use. For details, consult your dealer.

Precautions for Use
ENGLISH - 15
Important
Information
Lamp
J
The luminous source of the projector is a mercury lamp with high internal pressure.
A high pressure mercury lamp has following characteristics.
The brightness of the lamp will decrease by duration of usage.
z
The lamp may burst with sound or shorten life by shock or chipping.
z
The life of the lamp varies greatly depending on individual specicities and usage conditions. In particular,
z
continuous use over 12 hours and frequent on/off switching of the power greatly deteriorate the lamp and
affect the lamp life.
In rare cases, the lamp burst shortly after the projection.
z
The risk of bursting increases when the lamp is used beyond its replacement cycle. Make sure to replace the
z
lamp unit consistently. (“When to replace the lamp unit” (Æpage 96))
If the lamp bursts, gas contained inside of the lamp is released in a form of smoke.
z
It is recommended to store replacement lamps for contingency.
z
It is recommended to have authorized engineer or your dealer replace the lamp unit.
z
Pursuant to at the directive 2004/108/EC, article 9(2)
Panasonic Testing Centre
Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, F.R. Germany

Precautions for Use
16 - ENGLISH
Important
Information
Accessories
Make sure the following accessories are provided with your projector. Numbers in the brackets ( ) show the
number of accessories.
Wireless/Wired remote control unit (x1)
ヱヰヸユン
ヰワ ヴヵモワュャヺ
ヮヶヵユ
ヰワ ヰョョ
ヷヰロヷヰロ
モヷチヮヶヵユ
リヮモヨユ
ヴユロユヤヵ
リヮモヨユ
チモュルヶヴヵ
ユヤヰ ヴヤンユユワ
ュハ ・ヰヰヮ
ヱノヵリヮユン
ョンユユ・ユ
ロユワヴチヴラリョヵ
レユヺヴヵヰワユ
リワヱヶヵチビ
リワヱヶヵチヒ
リワヱヶヵチピ
リワョヰ
ヒビピ
フブ
プ
ヘベ
パ
ペ
リワヱヶヵ
ユワヵユン
ヮユワヶ
ョヰヤヶヴ
ョヰヤヶヴ
・ヰヰヮ
・ヰヰヮ
モヶヵヰチヱヤ
モュル
EX600 series EW630 series
EZ570 series
EX500 series EW530 series
Power cord (x2)
(6103597768)
(6103597775)
CD-ROM (x1)
(6103615899)
Batteries (AAA/R03 or
AAA/LR03 type) (x2)
Computer cable (x1)
(6103580425)
(for remote control unit)
AC power cord holder
(x1) (6451052124)
Lens cap*1 (x1)
(6103543376)
Lens mount cover*2 (x1)
(6103468303)
Lens antitheft screw*3
(x1) (4112195500)
(Attached to the projector
at the time of purchase.) (Attached to the projector
at the time of purchase.)
Only for PT-EZ570E, PT-EW630E, PT-EW530E, PT-EX600E and PT-EX500E.*1 :
Only for PT-EZ570EL, PT-EW630EL, PT-EW530EL, PT-EX600EL and PT-EX500EL.*2 :
Be careful in the opening of projector when mounting the lens antitheft screw. It may cause such as electric shock,*3 :
heavy exposure to dust, deviation adjustment. Please contact an Authorized Service Center for mounting, and do not
attempt to mount the lens antitheft screw yourself. Dismounting the lens antitheft screw and replacing the lens, please
follow above instructions.
(6451055545) (6451055552) (6451055569) (6451055576)

Precautions for Use
ENGLISH - 17
Important
Information
Attention
After unpacking the projector, discard the power cord cap and packaging material properly.
z
For lost accessories, consult your dealer.
z
The part numbers of accessories and separately sold components are subject to change without notice.
z
Store small parts in an appropriate manner, and keep them away from young children.
z
Contents of
JCD-ROM
The following contents are stored on the supplied CD-ROM.
Instructions/List (PDF) Software
Operating Instructions – Functional Manual
Operation Manual Multi Projector Monitoring &
Control Software 2.6
 Operation Manual Logo Transfer Software 2.0
List of compatible projector models
This is a list of projectors that are compatible with
•
the software (refer to the right column), and their
restrictions.

Multi Projector Monitoring & Control
Software 2.6 (Windows)
This software allows you to monitor and control
•
multiple projectors connected to the LAN.
Logo Transfer Software 2.0 (Windows)
This software allows you to create original
•
images, such as company logos to be displayed
when projection starts, and transfer them to the
projector.
Optional accessories
Options Model No.
Ceiling Mount Bracket ET-PKE200H (for high ceilings), ET-PKE200S (for low ceilings)
Projector Mount Base ET-PKE200B
Replacement Lamp Unit ET-LAE200
Replacement Filter Unit ET-RFE200
Zoom lens ET-ELW21 (Fixed-focus Lens), ET-ELW20 (Short Zoom Lens),
ET-ELT20 (Long Zoom Lens), ET-ELT21 (Ultra Long Zoom Lens)

18 - ENGLISH
Preparation
About Your Projector
Remote control
(6)
(4)
(1) Remote control signal emitter
(2) <POWER ON> button
Turn the projector on. (Æpage 37)
(3) <SHUTTER>/<AV MUTE> button
* <SHUTTER> button (Only for EZ570 series,
EW630 series and EX600 series.)
Close and open up the built-in shutter.
* <AV MUTE> button (Only for EW530 series and
EX500 series.)
Temporarily turn off the image on the screen.
(4) <MENU> button
Open or close the On-Screen Menu. (Æpage 46)
(5) ▲▼◄► (MUTE, VOL-/+) buttons
Navigate the menu display.
z
Pan the image in Digital zoom + mode.
z
Adjust the volume level (with ◄► buttons) or
z
mute the sound (with ▼ button).
(6) <IMAGE SELECT> button
Operate the image selection function. (Æpage 42)
(7) Signal Emission indicator
Light red while a signal is being sent from the
remote control to the projector.
(8) <STANDBY> button
Turn the projector off. (Æpage 39)
(9) <INPUT> button
Select an input source. (Æpage 41)
(10) <AUTO PC ADJ> button
Automatically adjust the computer image to its
optimum setting. (Æpage 42)
(11) <ENTER> button
Execute the selected item.
(12) <IMAGE ADJUST> button
Operate the image adjustment function.
(Æpage 42)
(13) Number buttons
Act as number buttons. Use these buttons when
setting the remote control codes (Æpage 23) or
entering the PIN code numbers (Æpage 38).
Note
Available keys in the simple mode as the left picture
z
shown for different models.
Picture (1) is only for EZ570 series, EW630 series
and EW530 series.
Picture (2) is only for EX600 series and EX500
series.
(1)
(9)
(5)
(13)
(10)
(12)
(2)
(3)*
(8)
(7)
(11)
Picture (1) Picture (2)

About Your Projector
ENGLISH - 19
Preparation
(15) (23)
(20)*
(22)
(19)
(14)
(18)
(16)
(26)
(17)
(25)
(24)
(21)
(14) <ECO> button
Display the Eco management function.
(Æpage 43)
(15) <P-TIMER> button
Operate the P-timer function. (Æpage 43)
(16) <FREEZE > button
Pauses the projected image and sound
tentatively. (Æpage 43)
(17) <KEYSTONE> button
Correct keystone distortion. (Æpage 44)
(18) <LENS SHIFT> button
Select the Lens Shift function. (Æpage 43)
(19) <ZOOM +/-> button
Zoom in and out the images. (Æpage 45)
(20) <P IN P> button
Operate the Picture in Picture function.
(Æpage 45)
*Only for EZ570 series, EW630 series and
EW530 series.
(21) ON/OFF switch
When using the remote control, set this switch to
“ON”. Set it to “OFF” for power saving when it is
not in use.
(22) <SCREEN> button
Select a screen mode. (Æpage 43)
(23) <D.ZOOM> button
Select the Digital zoom +/- mode and resize the
image. (Æpage 43)
(24) Input Selection buttons: <INPUT 1>,
<INPUT 2>, <INPUT 3>
Select an input source (Input 1 – Input 3).
(25) <FOCUS +/-> button
Adjust the focus. (Æpage 45)
(26) <INFO> button
Operate the information function. (Æpage 45)
(27) Wired remote jack
Connect the M3 stereo mini-jack cable (not
supplied) to this jack when using as a wired
remote control.
Attention
Do not drop the remote control.
z
Avoid contact with liquids.
z
Do not attempt to modify or disassemble the remote
z
control.
Note
The remote control can be used within a distance of
z
about 5 m (16.4 ft) if pointed directly at the remote control
signal receiver. The remote control can control at angles
of up to ± 30 ° vertically and ± 30 ° horizontally, but the
effective control range may be reduced.
If there are any obstacles between the remote control
z
and the remote control signal receiver, the remote control
may not operate correctly.
You can operate the projector by reecting the remote
z
control signal on the screen. The operating range may
differ due to the loss of light caused by the properties of
the screen.
When the remote control signal receiver is lit with a
z
uorescent light or other strong light source, the projector
may become inoperative. Set the projector as far from
the luminous source as possible.
(27)

About Your Projector
20 - ENGLISH
Preparation
(1) Lens Release Button
(2) Indicators (Æpage 21)
(3) Ambient Luminance sensor (Æpage 56)
(4) Lamp cover (Æpage 97)
The lamp unit is located inside.
(5) Speaker
(6) Projection Lens
(for PT-EZ570E, PT-EW630E, PT-EW530E,
PT-EX600E and PT-EX500E)
(7) Remote control signal receiver (Front & Top)
(8) Side Control (Æpage 21)
(9) Air outlet port
Hot air is exhausted from the exhaust vent. Do
•
not put heat-sensitive objects near this side.
(10) Remote control signal receiver (Back)
(11) AC IN
(12) Terminals (Æpage 22)
(13) Security Chain Hook
(14) Air intake port / Air lter cover (Æpage 93)
(15) Hand Grip
(16) Adjustable feet
Adjusts the projection angle.
WARNING:
Keep your hands and other objects away from
J
the air exhaust port.
Keep your hand and face away.
z
Do not insert your nger.
z
Keep heat-sensitive articles away.
z
Heated air from the air exhaust port can cause burns
or external damage.
Projector body
(7)
(5)
(1) (2) (4)
(6) (8) (9)
(9) (11) (12) (14)
(15)
(16)
(3)
(10)
(13)
