Raising the Ceiling on Performance
PT-L6600U/UL
PT-L6510U/UL
3600/4200 ANSI Lumens SXGA/XGA
LCD Projectors
1 BriteOptic™Dual Lamp System with four brightness settings to choose from
2 Digital Cinema Reality for excellent moving images
3 Easy setup and maintenance: Auto setup with digital keystone correction
BriteOptic™
Dual Lamp System
The difference is your image™
Presentation Products

Centered on Quality
Panasonic’s PT-L6600U/UL and
PT-L6510U/UL LCD projectors incorporate our
highly acclaimed BriteOptic™Dual Lamp system,
which delivers high-definition images with superb
brightness.
Aided by extensive user input, we began
by making key improvements to the system
engine, then devised a symmetrical design that
places the lens directly in the unit's center, for
easier image positioning. We also incorporated
the latest DSP technology to assure precise,
consistent performence.
The result: a series of projectors that
deliver ultra-bright, beautiful images while greatly
improving setup and maintenance ease.
See how brilliant your presentations look
when delivered through Panasonic
PT-L6600U/UL and PT-L6510U/UL projectors.
BriteOptic™
Dual Lamp System
Center-mounted lens

The PT-L6600UL and PT-L6510UL deliver the same superior
performance as the PT-L6600U and PT-L6510U, respective-
ly, but come with no lens. Combine them with an optional
lens to get the exact performance you need according to
usage and operating conditions.
Wide Variety: Choose the BriteOptic™Projector
that Best Meets Your Needs
PT-L6600U
SXGA Projector
• Ultrabright 3,600 ANSI lumens with 4-mode lamp operation
• BriteOptic™ technology and UHM™ lamps
• True SXGA (1,280 x 1,024), maximum UXGA (1,600 x 1,200)
resolution
• Intelligent Image Resizing for VGA/SVGA/SXGA/Mac
displays
• Multiple terminals, including digital video interface (DVI)
• Easy installation and maintenance
• Stackable for double brightness (up to 7,200 ANSI lumens)
PT-L6510U
XGA Projector
•Ultrabright 4,200 ANSI lumens with 4-mode lamp operation
•BriteOptic™technology and UHM™lamps
•True XGA (1,024 x 768), maximum UXGA (1,600 x 1,200)
resolution
•Intelligent Image Resizing for VGA/SVGA/SXGA/Mac
displays
•Multiple terminals, including digital video interface (DVI)
•Easy installation and maintenance
•Stackable for double brightness (up to 8,400 ANSI lumens)
PT-L6600UL/L6510UL

Ultrahigh Brightness and Contrast
Panasonic’s advanced BriteOptic™Dual Lamp
System delivers 3,600/4,200 ANSI lumens of
brightness and superior color reproducibility.
A corrective film is used to compensate for
phase shifts in the light incident to the LCD
panel, helping obtain a high contrast ratio. The
result is reproduction of crisp, clear, super-
bright images with outstanding depth.
Increased Reliability
These projectors have a long lamp life of
3,000 hours (at dual lamp operation in
standard mode). With the BriteOptic™Dual
Lamp System, even if one lamp burns out, the
remaining lamp provides sufficient brightness.
4-Mode Lamp Operation
Lamps can be set to 100%, 75%, 50%, or
25% ANSI lumens to achieve the desired
brightness. The four settings let you place the
priority on higher output, longer lamp life, or
fail-safe operation to match your usage
conditions.
High Resolution & Intelligent Image
Resizing
The PT-L6600U and PT-L6600UL offer true
SXGA resolution and the PT-L6510U and PT-
L6510UL provide true XGA resolution, allowing
display of detailed computer graphics and text.
When displaying images of other types, the
signals are expanded or compressed through
a digital processing system. This assures
smooth outlines and outstanding picture
definition with all types of images.
Flexible Connection
The PT-L6600U/UL and PT-L6510U/UL are
equipped with a digital video interface (DVI),
which lets you connect them with PCs for full
digital image processing. You can also input
signals from digital TV and DVD sources.
Installation Options
Two ceiling mount brackets are available, one
for high ceilings and one for lower ceilings. A
stacking mount bracket and a simpler version
are also available, for quick, easy, temporary
stacking of two units.
Easy Setup and Maintenance
The PT-L6600U/UL and PT-L6510U/ UL
feature a symmetrical design that places the
lens right at the center, making it easier to
position the projector and screen. Maintenance
is easier too, thanks to a design that lets you
replace a lamp without removing the projector
from the bracket in either the ceiling-mounted
or dual stacking configuration.
A Wide Range of Uses
The PT-L6600U/UL and PT-L6510U/ UL
provide the quality and performance needed in
almost any application. Use them in meeting
rooms, theaters, museums, convention halls,
public spaces, schools, research labs—
anyplace where bright, beautiful images are a
plus. Also, the superb resolution made
possible by DVI input delivers images with
exceptional detail and accuracy. This makes
these projectors suitable for use as main
systems for monitoring traffic or electric power,
or in operation centers such as police, fire, air
traffic control, and space development centers.
One-Touch Auto Setup
This function automatically identifies the signal
mode of the input source and adjusts the
image accordingly. You get optimal viewing
A Host of Panasonic’s Leading Technologies
Options for More Flexible Installation
ET-PKL6500
Ceiling mount bracket for
high ceilings
ET-LAL6510
Replacement lamp unit
ET-DFL6500
Dual stacking mount
bracket for desk/ ceiling
mount
ET-DFL6500P
Dual stacking mount
bracket for desks
ET-LAL6510W
Replacement lamp units
(twin pack of ET-LAL6510
lamp units)
ET-SCDV03
DVI cable (3 m)
ET-PKL6500S
Ceiling mount bracket for
low ceilings
ET-RMRC1
Wireless remote receiver
ET-LE050
Fixed-focus short-
throw lens
•Screen size: 40˝to 60˝
•Throw ratio: 0.7:1
•Throw distance: Approx.
0.55 m to 0.86 m
ET-LE200
Medium-throw lens
•Screen size: 30˝to 300˝
•Throw ratio: 2.7–4.4:1
•Throw distance: Approx.
2.1 m to 26.7 m
ET-LE101
Short-throw lens
•Screen size: 30˝to 300˝
•Throw ratio: 1.3–1.8:1
•Throw distance: Approx.
1.1 m to 11.0 m
ET-LE150
Short-throw lens
•Screen size: 30˝to 300˝
•Throw ratio: 1.8–2.4:1
•Throw distance: Approx.
1.4 m to 14.6 m
ET-LE300
Long-throw lens
•Screen size: 30˝to 300˝
•Throw ratio: 4.5–6.0:1
•Throw distance: Approx.
3.6 m to 35.4 m
Lamps can be easily replaced.
Terminals

Projection setting example
L : Projection distance when mounted with the
ET-PKL6500. (Projection size is adjustable.)
H : Height from upper/lower edge of projected
image to center of lens.
(Position of projected image can be easily
adjusted by using lens shift function.)
Edge of projected image
Projected
H
H
L
PT-L6600U/L6510U
PT-L6600UL/L6510UL with the ET-LE050 fixed short-throw lens
PT-L6600UL/L6510UL with the ET-LE101 short-throw lens
Front view
Projection size
(W x H)
LH
40 inches (813 x 610 mm) 0.55 m (1´10˝) 0.305 m (1´)
50 inches (1,016 x 762 mm) 0.70 m (2´4˝) 0.381 m (1´3˝)
60 inches (1,219 x 914 mm) 0.86 m (2´10˝) 0.457 m (1´6˝)
* inches: diagonally
Projection size (W x H)LH
40 inches (813 x 610 mm) 1.4 –1.9 m (4´8˝–6´4˝) 0.030 –0.30 m (1-3/16˝–11-13/16˝)
60 inches (1,219 x 914 mm) 2.1 –2.9 m (6´11˝–9´8˝) 0.045 –0.45 m (1-3/4˝–1´16˝)
100 inches (2,032 x 1,524 mm) 3.6 –4.8 m (11´1˝–15´9˝) 0.076 –0.76 m (2˝–2´6˝)
160 inches (3,251 x 2,438 mm) 5.8 –7.8 m (19´–25´7˝) 0.121 –1.21 m (4-3/4˝–4´)
220 inches (4,470 x 3,353 mm) 8.1 –10.7 m (26´7˝–35´1˝) 0.167 –1.67 m (6-9/16˝–5´6˝)
300 inches (6,096 x 4,572 mm) 11.0 –14.6 m (36´1˝–47´11˝) 0.228 –2.28 m (9˝–7´6˝)
* inches: diagonally
PT-L6600UL/L6510UL with the ET-LE150 short-throw lens
Projection size (W x H)LH
40 inches (813 x 610 mm) 1.4 –1.9 m (4´8˝–6´4˝) 0.030 –0.30 m (1-3/16˝–11-13/16˝)
60 inches (1,219 x 914 mm) 2.1 –2.9 m (6´11˝–9´8˝) 0.045 –0.45 m (1-3/4˝–1´16˝)
100 inches (2,032 x 1,524 mm) 3.6 –4.8 m (11´1˝–15´9˝) 0.076 –0.76 m (2˝–2´6˝)
160 inches (3,251 x 2,438 mm) 5.8 –7.8 m (19´–25´7˝) 0.121 –1.21 m (4-3/4˝–4´)
220 inches (4,470 x 3,353 mm) 8.1 –10.7 m (26´7˝–35´1˝) 0.167 –1.67 m (6-9/16˝–5´6˝)
300 inches (6,096 x 4,572 mm) 11.0 –14.6 m (36´1˝–47´11˝) 0.228 –2.28 m (9˝–7´6˝)
* inches: diagonally
Projection size (W x H)LH
40 inches (813 x 610 mm) 1.1 –1.4 m (3´7˝– 4´8˝) 0.030 –0.30 m (1-3/16˝–11-13/16˝)
60 inches (1,219 x 914 mm) 1.6 –2.1 m (5´2˝–7´) 0.045 –0.45 m (1-3/4˝–1´16˝)
100 inches (2,032 x 1,524 mm) 2.7 –3.6 m (8´11˝–11´11˝) 0.076 –0.76 m (2˝–2´6˝)
160 inches (3,251 x 2,438 mm) 4.4 –5.8 m (14´5˝–19´) 0.121 –1.21 m (4-3/4˝–4´)
220 inches (4,470 x 3,353 mm) 6.1 –8.1 m (20´–26´7˝) 0.167 –1.67 m (6-9/16˝–5´6˝)
300 inches (6,096 x 4,572 mm) 8.4 –11.0 m (27´7˝–36´1˝) 0.228 –2.28 m (9˝–7´6˝)
* inches: diagonally
PT-L6600UL/L6510UL with the ET-LE200 medium-throw lens
PT-L6600UL/L6510UL with the ET-LE300 long-throw lens
Projection size (W x H)LH
40 inches (813 x 610 mm) 2.1 –3.4 m (6´11˝–11´2˝) 0.030 –0.30 m (1-3/16˝–11-13/16˝)
60 inches (1,219 x 914 mm) 3.1 –5.2 m (10´3˝–17´) 0.045 –0.45 m (1-3/4˝–1´16˝)
100 inches (2,032 x 1,524 mm) 5.4 –8.7 m (17´9˝–28´7˝) 0.076 –0.76 m (2˝–2´6˝)
160 inches (3,251 x 2,438 mm) 8.6 –14.1 m (28´3˝–46.3´) 0.121 –1.21 m (4-3/4˝–4´)
220 inches (4,470 x 3,353 mm) 11.9 –19.5 m (39´–64´) 0.167 –1.67 m (6-9/16˝–5´6˝)
300 inches (6,096 x 4,572 mm) 16.3 –26.7 m (53´6˝–87´7˝) 0.228 –2.28 m (9˝–7´6˝)
* inches: diagonally
Projection size (W x H)LH
40 inches (813 x 610 mm) 3.6 –4.8 m (11´10˝–15´9˝) 0.030 –0.30 m (1-3/16˝–11-13/16˝)
60 inches (1,219 x 914 mm) 5.4 –7.1 m (17´8˝–23´3˝) 0.045 –0.45 m (1-3/4˝–1´16˝)
100 inches (2,032 x 1,524 mm) 8.9 –11.8 m (29´2˝–38´8˝) 0.076 –0.76 m (2˝–2´6˝)
160 inches (3,251 x 2,438 mm) 14.3 –18.9 m ((46´11˝–62´) 0.121 –1.21 m (4-3/4˝–4´)
220 inches (4,470 x 3,353 mm) 19.6 –26.0 m (64´4˝–85´4˝) 0.167 –1.67 m (6-9/16˝–5´6˝)
300 inches (6,096 x 4,572 mm) 26.7 –35.4 m (87´7˝–116´) 0.228 –2.28 m (9˝–7´6˝)
* inches: diagonally
quality, with no additional software, equipment
or manual adjustment necessary.
Lens Shift
Shift the projected image vertically even after
the projector is set in position. The PT-
L6600U and PT-L6510U have a wide
adjustment range, and the image remains
distortion free.
This offers you the peace of mind that comes
with the reliability of virtual-zero downtime.
Other Valuable Features
•Advanced shutter function: Minimizes
distracting light leakage, as well as noise
and power consumption, when the image is
muted.
•Digital zoom: Portions of the image can be
enlarged to 3x in steps of 0.1x.
•Freeze Frame: Moving pictures can be
frozen at any time and projected as still
pictures.
•Exhaust duct with noise cancel system
achieves quiet 36-dB operation (with lamp
power at Normal).
•
extra brightness.
LCD panels with micro lens array (MLA) for
•Center-to-corner uniformity ratio (CCR) of
over 90%
•Wireless remote with mouse control
•Lightweight and durable
magnesium-alloy cabinet
•Power zoom/focus lens
capable of projecting a 30˝
to 300˝diagonal image
•Ceiling/desk, front/rear
projection capable
•RS-232C computer interface
and contact closure remote
terminal
•S-Video compatibility
•Motorized retractable lens for
lens protection
•Selectable 7-language on-
screen menu (English,
German, French, Spanish,
Italian, Chinese, Japanese)
•Indicators for lamp errors, thermal
warnings, and suggested replacement
•Universal AC power supply (auto-voltage:
100–120 V/220–240 V)
•Built-in stereo amplifier and speakers (3W
+ 3W) for true multimedia applications
BriteOptic™
Dual Lamp System
Wireless remote
control

PT-L6600U PT-L6510U PT-L6600UL PT-L6510UL
100–240 V AC, 50/60 Hz
600 W (during standby mode with fan stopped: Max. 10 W)
5.0 A
NTSC/M-NTSC/PAL/PAL-M/PAL-N/SECAM
1.3˝ (diagonal)w/MLA 1.3˝ (diagonal) w/MLA 1.3˝ (diagonal)w/MLA 1.3˝ (diagonal) w/MLA
Transparent LCD panels (x 3)
Active matrix
1,398,784 786,432 1,398,784 786,432
(1,366 x 1,024) x 3 (1,024 x 768) x 3 (1,366 x 1,024) x 3 (1,024 x 768) x 3
Stripe
Power zoom/focus lens (1:1–1:1.3) (option)
F 1.7–2.3, f 49.1–63.8 mm (option)
DC type 220 W UHM™ lamps (x 2)
Full color (16,777,216 colors)
3600 ANSI lumens 4200 ANSI lumens 3600 ANSI lumens 4200 ANSI lumens
90%
400:1 (full field) 600:1 (full field) 400:1 (full field) 600:1 (full field)
1366 x 1024 pixels 1024 x 768 pixels 1366 x 1024 pixels 1024 x 768 pixels
1000 TV lines 760 TV lines 1000 TV lines 760 TV lines
Horizontal: 15.75/15.63 kHz, Vertical: 50/60 Hz
Horizontal: 24–97 kHz, Vertical: 50–120 Hz
7.62–76.2 m (30–300 inches) diagonally (varies with optional lens)
1.4–14.6 m (4´8˝–47´11˝) (varies with optional lens)
10/10–1/19
Ceiling/desk, front/rear (menu selection)
7 x 4 cm (2-3/4˝ x 1-9/16˝) (x 2)
6 W (3 W + 3 W) (10% THD)
English, German, French, Spanish, Italian, Chinese, Japanese
D-sub HD 15-pin x 1, 5 BNC x 1
D-sub HD 15-pin x 1
DVI-D 24-pin x 1
DIV-D 24-pin x 1
Mini DIN 4-pin x 1
BNC x 1
BNC x 1
RCA jack (L, R) x 1
M3 (L, R) x 1
M3 (L, R) x 1
D-sub 9-pin x 1
D-sub 9-pin x 1
D-sub 9-pin x 1
Type B x 1 (up, for mouse)
Type A x 1 (down, for USB hub)
M3 x 1
M3 x 1
36 dB (at standard mode)
495 x 179 x 495 mm
(19-15/32˝ x 7-1/16˝ x 19-15/32˝)
13.8 kg (30.5 lbs.) 12.6 kg (27.8 lbs)
0°–40°C (32°–104°F)
20%–80% (no condensation)
UL1950, C-UL, FCC
3 V DC (AA-size battery x 2)
Approx. 7 m (23´) when operated from directly in front of the signal receptor
Approx. 102 g (0.225 lb.) (including batteries)
46 x 34 x 190 mm (1-13/16˝ x 1-11/32˝ x 7-15/32˝)
Wireless/wired remote control unit, Cable for remote control unit (15 m), Remote control adapter plug,
Batteries for remote control unit, Power cord, VGA cable, USB cable, Exhaust guide
Replacement lamp unit: ET-LAL6510 (single lamp), ET-LAL6510W (set of two lamps)
Ceiling mount bracket: ET-PKL6500 (for high ceilings), ET-PKL6500S (for low ceilings)
Fixed-focus short-throw lens: ET-LE050, Short-throw lens:ET-LE101, Short-throw lens:ET-LE150,
Medium-throw lens:ET-LE200, Long-throw lens: ET-LE300,
Dual stacking mount bracket:ET-DFL6500 (for desk/ceiling mount),
Dual stacking mount bracket:ET-DFL6500P (for desk mount),
DVI cable: ET-SCDV03, Wireless remote receiver: ET-RMRC1
Weights and dimensions shown are approximate. Specifications subject to change without
notice. This product may be subject to export control regulations. UHM is a trademark of
Matsushita Electric Industrial Co., Ltd. PS/2, VGA and XGA are trademarks of International
Business Machines Corporation. Macintosh is a registered trademark of Apple Computer, Inc.
SVGA is a registered trademark of the Video Electronics Standards Association. Windows is a
registered trademark of Microsoft Corporation. All other trademarks are the property of their
respective trademark owners. Projection images simulated.
Panasonic is the brandname of Matsushita Electric.
Panasonic Broadcast & Television Systems Company
Presentation Systems Group
[phone]
www.panasonic.com/projectors
Headquarters
1 Panasonic Way, 4E-7
Secaucus, NJ 07094
[phone]
Canada
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga, Ontario
Canada L4W 2T3
[phone]
PT-L6600/L6510U1-02JUN20K Printed in Japan.
Specifications
Power supply:
Power consumption:
Max. amps:
Color system:
LCD panel:
Display method:
Drive method:
Pixels:
Pixel configuration:
Lens:
Lamp:
Colors:
Brightness:
CCR:
Contrast:
Resolution:
RGB:
Video:
Scanning frequency:
S-Video/Video:
RGB:
Screen size:
Throw distance:
Optical axis shift:
Installation:
Built-in speakers:
Size:
Output power:
On-screen display languages:
Terminals:
RGB/YUV in:
RGB out:
Digital RGB in:
Digital RGB out:
S-Video in:
Video in:
Video out:
Video audio in:
RGB audio in:
Audio monitor out:
RS-232C in:
RS-232C out:
Contact closure:
USB in:
USB out:
Wired remote in:
Wired remote out:
Noise level:
Dimensions
(W x H x D):
Weights:
Operating temperature:
Operating humidity:
Safety regulations:
Remote control unit
Power supply:
Operation range:
Weight:
Dimensions (W x H x D):
Supplied accessories:
Optional accessories:
Compatible graphic modes
fH: Horizontal frequency (kHz)
fV: Vertical frequency (Hz)
Italic: interlaced signals
Bold: For the PT-L6600U/L6600UL only
NOTE:
The display resolution of the PT-L6600U/L6600UL is 1366 x
1024 pixels. Input signals other than SXGA (1280 x 1024
pixels) will be converted to 1366 x 1024 pixels. When the
input signal is SXGA (1280 x 1024 pixels), it will be
projected as it is without being converted.
The display resolution of the PT-L6510U/L6510UL is 1024 x
768 pixels. If the display resolution indicated in the above
data does not match this resolution, the input signal will be
converted to 1024 x 768 pixels.
VGA400 fHfv
640 x 400 24.8 56.4
31.5 70.1
VGA480 fHfv
640 x 480 31.5 59.9
35.0 66.7
37.9 72.8
37.5 75.0
43.3 85.0
SVGA fHfv
800 x 600 32.1 51.0
35.2 56.3
37.9 60.3
48.1 72.1
46.9 75.0
53.7 85.1
XGA fHfv
1024 x 768 48.4 60.0
56.5 70.1
60.0 75.0
65.5 81.6
68.7 85.0
80.0 100.8
94.01200.0
1024 x 768i 35.5 86.8
MXGA fHfv
1152 x 864 63.9 70.0
67.5 75.0
77.1 85.0
1120 x 750 50.1 60.1
1120 x 750i 32.6 80.0
SXGA fHfv
1280 x 1024 52.4 50.0
64.0 60.0
72.4 66.3
78.2 71.7
80.0 75.0
91.2 85.0
1280 x 1024i 46.2 86.0
47.6 88.9
UXGA fHfv
1600 x 1200 75.0 60.0
87.5 70.0
93.8 75.0
Mac16˝fHfv
832 x 624 49.7 74.6
Mac21˝fHfv
1152 x 870 68.6 75.0
NTSC fHfv
768 x 480i 15.7 59.9
PAL fHfv
768 x 576i 15.6 50.0
480p fHfv
720 x 483 31.5 59.9
720p fHfv
1280 x 720 45.0 60.0
HDTV fHfv
1920 x 1035i 33.8 60.0
Control panel (Photo shows the
PT-L6600U/L6510U. Controls of the
PT-L6600UL/L6510UL are slightly different.)
