CQ-C3503N / CQ-C3303N
MP3 CD Player/Receiver
SPECIFICATIONS
Specifications*
General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Current Consumption Less than 2.1A (CD mode ; 0.5W
4-channels)
Maximum Power Output 50W×4 (at 4 )
Power Output 22W×4 (DIN45 324, at 4 )
Tone Adjustment Range Bass ; ±12dB at 100Hz
Treble ; ±12dB at 10kHz
Speaker Impedance 4-8
Pre-Amp Output Voltage 2.5V (CD mode)
Pre-Amp Output Impedance 200
Front AUX Input
Input Impedance 10k
Allowable External Input 2.0V
Connector 3.5mm Stereo mini-pin
FM Stereo Radio
Frequency Range 87.5MHz - 108MHz
Usable Sensitivity 6dB/ V (S/N 30dB)
Stereo Separation 35dB (at 1kHz)
1

AM (MW) Radio
Frequency Range 531kHz - 1,602kHz
Usable Sensitivity 27dB/ V (S/N 20dB)
AM (LW) Radio
Frequency Range 153kHz - 279kHz
Usable Sensitivity 32dB/ V (S/N 20dB)
CD Player
Sampling Frequency 8 Times Oversampling
DA Converter 1bit DAC System
Pick-Up Type Astigma 3-beam
Light Source Semiconductor Laser
Wave Length 790nm
Frequency Response 20Hz to 20kHz (±1dB)
Signal to Noise Ratio 93dB
Total Harmonic Distortion 0.01% (1kHz)
Wow and Flutter Below measurable limits
Channel Separation 75dB
Dimensions** 178×50×160mm
Weight** 1.4kg
* Specifications and the design are subject to possible
modification without notice due to improvements.
** Dimensions and Weight shown are approximate.
-Above specifications comply with EIA standards.
2006 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
1. ABOUT LEAD FREE SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF stamp on the PCB.
Caution :
2

- Pb free solder has a higher melting point than standard solder; Typically
the melting point is 50 - 70°F (30 - 40°C) higher. Please use a soldering
iron with temperature control and adjust it to 700 ± 20°F (370 ± 10°C). In
case of using high temperature soldering iron, please be careful not to
heat too long.
- Pb free solder will tend to splash when heated too high (about 1100°F/
600°C)
- This lead free solder will be used for the products after serial No.
1,000,001.
2. LASER PRODUCTS
3. FEATUERS
- Large-sized volume control.
- SQ (Sound Quality).
- SRS TruBass [CQ-C3503N].
- The AUX input terminal is equipped on the front panel.
- This manual is for 2 models CQ-C3503N and CQ-C3303N. The following
table describes the differences between 2 models.
3

4. REPLACING THE FUSE
Use fuses of the same specified rating (15amps). Using different substitutes or fuses with higher
ratings, or connecting the product directly without a fuse, could cause fire or damage to the stereo unit.
5. MAINTENANCE
Your product is designed and manufactured to ensure a minimum of maintenance. Use a dry, a soft
cloth for routine exterior cleaning. Never use benzine, thinner or other solvents.
6. NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package block is necessary, it will be supplied already
aligned at the factory.
[CD DECK BLOCK]
This model has no servo alignment points because microcomputer controls the servo circuit.
7. DIMENSIONS
8. WIRING CONNECTION
4

5

9. TERMINALS DESCRIPTION
9.1. Main Block
IC601 : YESAM356
Pin
No.
Port Description I/O (V)
FM AM CD
1 XIN Crystal oscillator I 2.5 2.5 2.5
2 TEST2 Ground I 0 0 0
3 VREG Bypass condenser
connected.
O 2.9 2.9 2.9
4VSSCPUGround - 0 0 0
5 NC - - - - -
6 NC - - - - -
7 NC - - - - -
8 NC - - - - -
9 LCD
DO
LCD data output I 5 5 5
10 LCD DI LCD data input O 4.9 5 4.9
11 LCD
CLK
LCD clock O 5.1 5.1 5.1
12 LCD CE LCD chip enable
output
O 0 0 0.3
13 CD DO CD data output I 5.1 5.2 4
14 CD DI CD data input O 0 0 4.6
15 CD
CLK
CD clock O 4.9 49 4.9
16 CD CE CD chip enable O 0 0 1
17 CD LM
(+)
CD loading motor
control
O 0 0 0
18 CD LM
(-)
CD loading motor
control
O 0 0 0
19 CD S/L CD spindle motor
control
O 5.1 5.1 5.1
20 SUB
READY
Sub CPU ready
signal
I 0 0 5
21 CD
INSW1
CD insert SW input I 0 0 0
22 CD
SW2
CD mechanism
SW2
I 5.1 5.1 0
23 CD
LIMIT
SW
CD limit SW I 0.2 0.2 5.1
24 CD
MUTE
CD Mute signal I 5.1 5.1 5.1
25 CD RST CD reset O 5.1 5.1 5.1
26 CD
DMUTE
CD mute O 0 0 5.1
6

Pin
No.
Port Description I/O (V)
FM AM CD
27 LOW
BATT
Battery low level
detect
I 5.1 5.1 0
28 NC - - - - -
29 PANEL Panel detect switch I 0 0 0
30 NC - - - - -
31 NC - - - - -
32 NC - - - - -
33 NC - - - - -
34 NC - - - - -
35 TBASS TruBASS IC
contorol
O 0 0 0
36 NC - - - - -
37 NC - - - - -
38 NC - - - - -
39 VDD
PORT
Power supply (+5V) - 5.1 5.1 5.1
40 VSS
PORT
Ground - 0 0 0
41 NC - - - - -
42 NC - - - - -
43 NC - - - - -
44 NC - - - - -
45 NC - - - - -
46 NC - - - - -
47 NC - - - - -
48 NC - - - - -
49 PWR
CNT
Power on control O 4.9 5 5
50 AMP
CNT
Amp control signal O 5.1 5.1 5.1
51 AMP
MUTE
Power IC mute
signal
O 5.1 5.1 5.1
52 STBY Power IC standby
control
O 5.1 5.1 5.1
53 SSC Tuner search
sensitivity change
O 0 0 5.1
54 AF
MUTE
AF mute O 5.1 5.1 5.1
55 I2C
DATA
Electronic VOL
data
O 5.1 5.1 5.1
56 I2C
CLK
Electronic VOL
clock
O 5.1 5.1 5.1
57 NC - - - - -
58 POWER
LED
Power LED O 0 0 0
59 NC - - - - -
60 NC - - - - -
7

Pin
No.
Port Description I/O (V)
FM AM CD
61 NC - - - - -
62 NC - - - - -
63 OP/CL Panel open/close
signal
I - - -
64 EJECT Eject switch signal I 5.1 5.1 5.1
65 EJ ILL Eject LED drive
control
O 5.1 5.1 5.1
66 TEL
MUTE
Telephone mute
signal
I 5.1 5.1 5.1
67 BATT Battery detection I 5.1 5.1 5.1
68 MODE
B
Rotary encoder
input B
I 5 5 5
69 RDS
CLK
RDS clock I 2.4 2.4 2.4
70 RM
DATA
Remote control
data
I - - -
71 MODE
A
Rotary encoder
input A
I 5 5 5.1
72 NC - - - - -
73 NC - - - - -
74 MONO FM MONO signal O 0 0 0
75 AM
MODE
Radio AM mode
control
O 8.2 0 8.2
76 FM
MODE
Radio FM mode
control
O 0 8.2 0
77 LEVEL Audio signal input
for level meter
I 0 0 1.5
78 INIT C Initial setting port I 0 0 0
79 INIT B Initial setting port I 0 0 0
80 INIT A Initial setting port I - - -
81 VSSADCGround - 0 0 0
82 RDS
DATA
RDS data I 2.6 0 2.5
83 ST FM stereo signal I 5.1 5.2 5.2
84 SD FM/
AM
Radio signal
strength
I 0 0 0
85 NC Ground I 0 0 0
86 RESET Reset signal I 5 5 5
87 ACC ACC signal input I 5.3 5.3 5.3
88 NC Ground I 0 0 0
89 NC Ground I 0 0 0
90 FM/AM
IFC
FM/AM IF input I 1.4 1.3 1.3
91 NC - - - - -
92 NC - - - - -
93 VDDPLLPower supply of
PLL
- 5.1 5.1 5.1
8

Pin
No.
Port Description I/O (V)
FM AM CD
94 NC - - - - -
95 OSC
FM/AM
FM/AM osc input I 1.4 1.3 1.3
96 VSSPLL Ground - 0 0 0
97 NC - - - - -
98 EO1 PLL phase
comparison error
output
O 2.2 2.1 2.3
99 TEST1 Ground I 0 0 0
100 XOUT Crystal oscillator O 2.6 2.6 2.6
9.2. Display Block
IC901 : C0HBA0000195
Pin
No.
Port Description I/O (V)
1 GREEN
CNT
LED control (Green) O 0
2 RED CNT LED control (Red) O 4.9
3 -39 SEG3 -39 LCD segment data O 2.5
40 -43 COM1 -4 LCD common O 2.5
44, 45 SEG40,
41
LCD segment data O 2.5
46 -49 KS3-6 Key scan O 5.0
50 -54 Kl1-5 Key data I 0
55 TEST (Connecting to ground) - 0
56 VDD +5V power supply - 5.0
57 VDD1 VDD1 filter terminal - 3.3
58 VDD2 VDD2 filter terminal - 1.7
59 VSS Ground - 0
60 OSC Oscillator terminal - 3.8
61 DO Key data output O 5.0
62 CE LCD driver chip enable I 0.3
63 CLK LCD clock I 5.1
64 DI LCD data I 4.9
10. PACKAGE AND IC BLOCK DIAGRAM
10.1. Main Block
PA051 : YESAP403
9

IC201 : YESAM293
IC231 : YESAM320
IC501 : YESAM283
10

IC271 : C1EA00000041
IC802 : YESAM352
11

IC751 : YESAM349
12

10.2. Display Block
IC905 : YESAM264
11. REPLACEMENT PARTS LIST [CQ-C3503N]
Notes :
1. Be sure to make your orders of replacement parts according to this list.
2. Important safety notice: Components, identified by mark have
special characteristics important for safety. When replacing any of
these components, use only manufacturer's specified parts.
3. Location keys in the remarks column indicates the general location of
the parts shown in the exploded drawing, as in a road map.
4. The marking (RTL) indicates that Retention Time is limited for this item.
After the discontinuation of assembly in production, the item will
continue to be available for a specific period of time. The retention
period of availability is dependent on the type of assembly, and in
accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
13

- Order intake period is basically six months after the first shipment.
Ref. No. Part No. Part Name & Description Remarks
[7222-02-11] MAIN BLOCK
IC's and TRANSISTORs
IC201 YESAM293 IC
IC231 YESAM320 IC
IC271 C1EA00000041 IC
IC501 YESAM283 IC
IC601 YESAM356 IC
IC751 YESAM349 IC
IC801 YESAM351 IC
IC802 YESAM352 IC
PA051 YESAP403 Tuner Pack
Q052 YESAN117 Transistor
Q054 YESAN122 Transistor
Q055 YESAN117 Transistor
Q066 YESAN132 Transistor
Q261 YESAN121 Transistor
Q262 YESAN121 Transistor
Q265 YESAN125 Transistor
Q361 YESAN121 Transistor
Q362 YESAN121 Transistor
Q365 YESAN125 Transistor
Q401 B1CBGF000005 FET
Q660 YESAN128 Transistor
Q661 YESAN127 Transistor
Q671 YESAN120 Transistor
Q672 YESAN118 Transistor
Q701 YESAN126 Transistor
Q702 YESAN129 Transistor
Q704 YESAN123 Transistor
Q752 YESAN115 FET
Q770 YESAN087 Transistor
Q851 B1BCCF000017 Transistor
Q871 YESAN113 Transistor
DIODEs
D053 YESAD119 Zener Diode
D231 YESAD143 Diode
D232 YESAD144 Diode
D233 YESAD119 Zener Diode
D270 YESAD146 Diode
D271 YESAD146 Diode
D272 YESAD146 Diode
D273 YESAD146 Diode
D274 YESAD146 Diode
D275 YESAD146 Diode
D276 YESAD146 Diode
D277 YESAD146 Diode
D677 YESAD147 Zener Diode
D681 YESAD149 Diode
D691 YESAD155 Diode
D701 YESAD139 Diode
D702 YESAD153 Zener Diode
14

Ref. No. Part No. Part Name & Description Remarks
D704 YESAD143 Diode
D705 YESAD146 Diode
D751 YESAD141 Diode
D770 YESAD123 Zener Diode
D791 B0ACCK000005 Diode
D792 B0ACCK000005 Diode
CAPACITORs
C61 YESCC527 Ceramic, 0.022 F 25WV
C62 YESCC527 Ceramic, 0.022 F 25WV
C051 YECUS1H470JC Ceramic, 47pF 50WV
C053 YESCC482 Ceramic, 0.01 F 50WV
C055 YESCC482 Ceramic, 0.01 F 50WV
C058 YESCC482 Ceramic, 0.01 F 50WV
C065 YESCC481 Ceramic, 0.001 F 50WV
C066 YESCC226 Ceramic, 470pF 50WV
C067 YESCC482 Ceramic, 0.01 F 50WV
C071 YESCC559 Ceramic, 0.012 F 50WV
C201 YESCC529 Ceramic, 0.22 F 16WV
C202 YESCC550 Electrolytic, 3.3 F 50WV
C204 YESCC452 Ceramic, 1 F 16WV
C206 YESCC549 Electrolytic, 2.2 F 50WV
C207 YESCC452 Ceramic, 1 F 16WV
C208 YESCC483 Ceramic, 0.1 F 50WV
C231 YESCC483 Ceramic, 0.1 F 50WV
C232 YESCC483 Ceramic, 0.1 F 50WV
C233 YESCC481 Ceramic, 0.001 F 50WV
C234 YESCC563 Ceramic, 2.2 F
C235 YESCC545 Electrolytic, 22 F 10WV
C236 YESCC563 Ceramic, 2.2 F
C251 YESCC226 Ceramic, 470pF 50WV
C261 YESCC372 Electrolytic, 4.7 F 25WV
C262 YESCC372 Electrolytic, 4.7 F 25WV
C263 YESCC487 Ceramic, 0.47 F 16WV
C267 YESCC487 Ceramic, 0.47 F 16WV
C268 YESCC487 Ceramic, 0.47 F 16WV
C269 YESCC487 Ceramic, 0.47 F 16WV
C271 YESCC486 Ceramic, 0.0047 F 50WV
C272 YESCC486 Ceramic, 0.0047 F 50WV
C276 YESCC548 Electrolytic, 47 F 16WV
C277 YESCC452 Ceramic, 1 F 16WV
C278 YESCC483 Ceramic, 0.1 F 50WV
C279 YESCC368 Electrolytic, 2200 F 16WV
15

Ref. No. Part No. Part Name & Description Remarks
C280 YESCC563 Ceramic, 2.2 F
C281 YESCC563 Ceramic, 2.2 F
C292 YESCC482 Ceramic, 0.01 F 50WV
C301 YESCC529 Ceramic, 0.22 F 16WV
C302 YESCC550 Electrolytic, 3.3 F 50WV
C304 YESCC452 Ceramic, 1 F 16WV
C306 YESCC549 Electrolytic, 2.2 F 50WV
C307 YESCC546 Electrolytic, 10 F 16WV
C308 YESCC539 Electrolytic, 120 F 10WV
C351 YESCC226 Ceramic, 470pF 50WV
C361 YESCC372 Electrolytic, 4.7 F 25WV
C362 YESCC372 Electrolytic, 4.7 F 25WV
C363 YESCC487 Ceramic, 0.47 F 16WV
C367 YESCC487 Ceramic, 0.47 F 16WV
C368 YESCC487 Ceramic, 0.47 F 16WV
C369 YESCC487 Ceramic, 0.47 F 16WV
C371 YESCC486 Ceramic, 0.0047 F 50WV
C372 YESCC486 Ceramic, 0.0047 F 50WV
C375 YESCC404 Electrolytic, 10 F 16WV
C378 YESCC483 Ceramic, 0.1 F 50WV
C401 YESCC543 Electrolytic, 680 F 10WV
C402 ECQV1H683JL2 Plastic, 0.068 F 50WV
C403 YESCC562 Ceramic, 0.0068 F 50WV
C404 YESCC482 Ceramic, 0.01 F 50WV
C421 F1J1H101A667 Ceramic, 100pF 50WV
C430 YESCC313 Electrolytic, 220 F 10WV
C501 YESCC223 Ceramic, 27pF 50WV
C502 YESCC219 Ceramic, 10pF 50WV
C505 YESCC483 Ceramic, 0.1 F 50WV
C506 YESCC482 Ceramic, 0.01 F 50WV
C507 YESCC224 Ceramic, 270pF 50WV
C508 YESCC546 Electrolytic, 10 F 16WV
C509 YESCC545 Electrolytic, 22 F 10WV
C601 YECUS1H220JC Ceramic, 22pF 50WV
C602 YECUS1H220JC Ceramic, 22pF 50WV
C603 YESCC452 Ceramic, 1 F 16WV
C604 YESCC482 Ceramic, 0.01 F 50WV
C605 YESCC482 Ceramic, 0.01 F 50WV
C606 YESCC397 Electrolytic, 1000 F 6.3WV
C608 F1J1H101A667 Ceramic, 100pF 50WV
C609 YESCC452 Ceramic, 1 F 16WV
C610 YESCC482 Ceramic, 0.01 F 50WV
C611 YESCC482 Ceramic, 0.01 F 50WV
16

Ref. No. Part No. Part Name & Description Remarks
C612 YESCC482 Ceramic, 0.01 F 50WV
C642 YESCC487 Ceramic, 0.47 F 16WV
C660 YESCC549 Electrolytic, 2.2 F 50WV
C701 YESCC483 Ceramic, 0.1 F 50WV
C702 YESCC483 Ceramic, 0.1 F 50WV
C751 YESCC396 Electrolytic, 470 F 16WV
C752 YESCC483 Ceramic, 0.1 F 50WV
C753 YESCC539 Electrolytic, 120 F 10WV
C754 YESCC539 Electrolytic, 120 F 10WV
C755 YESCC482 Ceramic, 0.01 F 50WV
C756 YESCC482 Ceramic, 0.01 F 50WV
C757 YESCC482 Ceramic, 0.01 F 50WV
C758 YESCC483 Ceramic, 0.1 F 50WV
C759 YESCC482 Ceramic, 0.01 F 50WV
C760 YESCC482 Ceramic, 0.01 F 50WV
C770 YESCC547 Electrolytic, 100 F 16WV
C801 YESCC486 Ceramic, 0.0047 F 50WV
C802 YESCC482 Ceramic, 0.01 F 50WV
C803 YESCC560 Ceramic, 0.047 F 50WV
C804 YESCC561 Ceramic, 0.056 F 50WV
C805 YESCC482 Ceramic, 0.01 F 50WV
C806 YESCC481 Ceramic, 0.001 F 50WV
C807 YESCC561 Ceramic, 0.056 F 50WV
C808 YESCC482 Ceramic, 0.01 F 50WV
C809 YESCC483 Ceramic, 0.1 F 50WV
C810 YESCC424 Electrolytic, 100 F 6.3WV
C811 YESCC452 Ceramic, 1 F 16WV
C812 YESCC560 Ceramic, 0.047 F 50WV
C813 YESCC483 Ceramic, 0.1 F 50WV
C814 YESCC483 Ceramic, 0.1 F 50WV
C815 YESCC483 Ceramic, 0.1 F 50WV
C816 YESCC544 Electrolytic, 100 F 6.3WV
C817 YESCC483 Ceramic, 0.1 F 50WV
C818 YESCC544 Electrolytic, 100 F 6.3WV
C819 YESCC483 Ceramic, 0.1 F 50WV
C820 YESCC271 Ceramic, 68pF 50WV
C821 YESCC271 Ceramic, 68pF 50WV
C822 YESCC483 Ceramic, 0.1 F 50WV
C823 YESCC483 Ceramic, 0.1 F 50WV
C824 YESCC483 Ceramic, 0.1 F 50WV
C825 YESCC414 Electrolytic, 1 F 50WV
17

Ref. No. Part No. Part Name & Description Remarks
C826 YESCC483 Ceramic, 0.1 F 50WV
C827 YESCC424 Electrolytic, 100 F 6.3WV
C828 YESCC483 Ceramic, 0.1 F 50WV
C829 YESCC483 Ceramic, 0.1 F 50WV
C832 YESCC483 Ceramic, 0.1 F 50WV
C833 YESCC315 Electrolytic, 330 F 6.3WV
C834 YESCC483 Ceramic, 0.1 F 50WV
C835 YESCC560 Ceramic, 0.047 F 50WV
C851 YESCC482 Ceramic, 0.01 F 50WV
C852 YESCC547 Electrolytic, 100 F 16WV
C853 YESCC482 Ceramic, 0.01 F 50WV
C854 YESCC538 Electrolytic, 150 F 6.3WV
C855 YESCC547 Electrolytic, 100 F 16WV
C856 YESCC483 Ceramic, 0.1 F 50WV
C871 YESCC483 Ceramic, 0.1 F 50WV
C872 YESCC483 Ceramic, 0.1 F 50WV
C873 YESCC482 Ceramic, 0.01 F 50WV
C874 YESCC558 Electrolytic, 5.6 F 50WV
C875 YESCC483 Ceramic, 0.1 F 50WV
C876 YESCC538 Electrolytic, 150 F 6.3WV
C877 YESCC377 Electrolytic, 47 F 6.3WV
C878 YESCC483 Ceramic, 0.1 F 50WV
C879 YESCC483 Ceramic, 0.1 F 50WV
C880 YESCC544 Electrolytic, 100 F 6.3WV
C881 YESCC544 Electrolytic, 100 F 6.3WV
C891 YESCC481 Ceramic, 0.001 F 50WV
RESISTORs
J101 ERJ8GX0R00V Chip, 0 1/4W
J102 ERJ8GX0R00V Chip, 0 1/4W
J103 ERJ8GX0R00V Chip, 0 1/4W
J104 YESRG196 Chip, 0 1/8W
J105 ERJ8GX0R00V Chip, 0 1/4W
J106 YESRG132 Chip, 0 1/4W
J107 YESRG241 Chip, 0 1/8W
J108 YESRG132 Chip, 0 1/4W
J109 ERJ8GX0R00V Chip, 0 1/4W
J110 YESRG132 Chip, 0 1/4W
J111 YESRG196 Chip, 0 1/8W
J113 ERJ8GX0R00V Chip, 0 1/4W
J114 ERJ8GX0R00V Chip, 0 1/4W
J115 YESRG132 Chip, 0 1/4W
J116 YESRG132 Chip, 0 1/4W
18

Ref. No. Part No. Part Name & Description Remarks
J117 YESRG132 Chip, 0 1/4W
J118 YESRG132 Chip, 0 1/4W
J119 YESRG132 Chip, 0 1/4W
J120 YESRG132 Chip, 0 1/4W
J122 YESRG132 Chip, 0 1/4W
J123 YESRG241 Chip, 0 1/8W
J124 YESRG132 Chip, 0 1/4W
J129 YESRG241 Chip, 0 1/8W
J130 ERJ8GX0R00V Chip, 0 1/4W
J131 YESRG241 Chip, 0 1/8W
J132 ERJ8GX0R00V Chip, 0 1/4W
J133 ERJ8GX0R00V Chip, 0 1/4W
J134 YESRG132 Chip, 0 1/4W
J135 YESRG132 Chip, 0 1/4W
J136 ERJ8GX0R00V Chip, 0 1/4W
J145 YESRG196 Chip, 0 1/8W
J151 ERJ8GX0R00V Chip, 0 1/4W
J152 YESRG241 Chip, 0 1/8W
J153 ERJ8GX0R00V Chip, 0 1/4W
J155 YESRG132 Chip, 0 1/4W
J157 YESRG132 Chip, 0 1/4W
J158 YESRG132 Chip, 0 1/4W
J159 YESRG196 Chip, 0 1/8W
J160 ERJ8GX0R00V Chip, 0 1/4W
J161 ERJ8GX0R00V Chip, 0 1/4W
J163 ERJ8GX0R00V Chip, 0 1/4W
J164 ERJ8GX0R00V Chip, 0 1/4W
J165 YESRG132 Chip, 0 1/4W
J166 YESRG132 Chip, 0 1/4W
J167 YESRG132 Chip, 0 1/4W
J168 ERJ8GX0R00V Chip, 0 1/4W
J169 ERJ8GX0R00V Chip, 0 1/4W
J171 YESRG241 Chip, 0 1/8W
J172 ERJ8GX0R00V Chip, 0 1/4W
J173 YESRG132 Chip, 0 1/4W
J174 YESRG241 Chip, 0 1/8W
J175 ERJ8GX0R00V Chip, 0 1/4W
J176 ERJ8GX0R00V Chip, 0 1/4W
J177 YESRG132 Chip, 0 1/4W
J178 YESRG132 Chip, 0 1/4W
J179 YESRG132 Chip, 0 1/4W
J180 YESRG132 Chip, 0 1/4W
J181 ERJ8GX0R00V Chip, 0 1/4W
J182 ERJ8GX0R00V Chip, 0 1/4W
J183 ERJ8GX0R00V Chip, 0 1/4W
J184 ERJ8GX0R00V Chip, 0 1/4W
J185 ERJ8GX0R00V Chip, 0 1/4W
19

Ref. No. Part No. Part Name & Description Remarks
J186 YESRG132 Chip, 0 1/4W
J187 YESRG132 Chip, 0 1/4W
J188 YESRG241 Chip, 0 1/8W
J189 ERJ8GX0R00V Chip, 0 1/4W
J190 ERJ8GX0R00V Chip, 0 1/4W
J191 YESRG132 Chip, 0 1/4W
J194 YESRG196 Chip, 0 1/8W
L290 YESRG241 Chip, 0 1/8W
L291 YESRG241 Chip, 0 1/8W
R050 YESRG399 Chip, 5.6k 1/8W
R052 YESRG189 Chip, 100 1/4W
R053 YESRG132 Chip, 0 1/4W
R058 YESRG241 Chip, 0 1/8W
R060 YESRG385 Chip, 33k 1/8W
R065 YESRG387 Chip, 39k 1/8W
R066 YESRG442 Chip, 330k 1/8W
R067 YESRG320 Chip, 2.2k 1/8W
R068 YESRG319 Chip, 1k 1/8W
R070 YESRG420 Carbon, 220 1/4W
R201 YESRG415 Chip, 18k 1/8W
R202 YESRG382 Chip, 27k 1/8W
R203 YESRG390 Chip, 4.7k 1/8W
R204 YESRG390 Chip, 4.7k 1/8W
R208 YESRG319 Chip, 1k 1/8W
R232 YESRG361 Chip, 100k 1/8W
R233 YESRG391 Chip, 47k 1/8W
R234 YESRG360 Chip, 10k 1/8W
R235 YESRG391 Chip, 47k 1/8W
R236 YESRG385 Chip, 33k 1/8W
R237 YESRG360 Chip, 10k 1/8W
R238 YESRG319 Chip, 1k 1/8W
R239 YESRG382 Chip, 27k 1/8W
R251 YESRG382 Chip, 27k 1/8W
R252 YESRG374 Chip, 20k 1/8W
R261 YESRG371 Chip, 180 1/8W
R262 YESRG371 Chip, 180 1/8W
R263 YESRG396 Chip, 560 1/8W
R265 YESRG360 Chip, 10k 1/8W
R266 YESRG360 Chip, 10k 1/8W
R267 YESRG396 Chip, 560 1/8W
R275 YESRG376 Chip, 22k 1/8W
R280 YESRG040 Chip, 130 1/4W
R290 YESRG241 Chip, 0 1/8W
R291 YESRG241 Chip, 0 1/8W
R299 YESRG431 Chip, 22 1/8W
R301 YESRG415 Chip, 18k 1/8W
R302 YESRG382 Chip, 27k 1/8W
20
