Panasonic CQ-LA1923L Building instructions

General
Power Supply DC 12V DC Negative ground
Test Voltage 13.2V
Current Consumption Less than 3.0A (at 0.5W)
Maximaum Power Output 12W×12W
AM Radio
Frequency Range 531-1,602kHz
Usable Sensitivity 23dB/µV (S/N 20dB)
Seek Sensitivity 40dB/µV
FM Stereo Radio
Frequency Range 87.5-108.0MHz
Usable Sensitivity 8dB/µV (S/N 30dB)
Seek Sensitivity 25dB/µV
©2001 Matsushita Communication Industrial Co.,
Ltd. All rights reserved. Unauthorized copying and
distribution is a violation of law.
AUDI
CQ-LA1923L
AM/FM/RDS RADIO with Stereo
Cassette Tape Player / CD Changer
Control
AUDI PART No. : 8L0 035 186A
VEHICLE : AUDI A3
DESTINATION : Europe
PRODUCED AFTER : Dec., 1999
Tape Player
Reproduction System 4-Track,2-Program Stereo
Tape Speed 4.76cm/sec
Dimensions** (W×H×D) 184×51.5×160mm
Weight** 1.6kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
“Dolby” and the double-D symbol are trade marks of Dolby
Laboratories Licensing Corporation.
AUTOMOTIVE ELECTRONICS
Specifications*
ORDER No. AED0109020

1 FEATURES 2
2 REAR VIEW AND CONNECTORS 2
3 FRONT VIEW AND FUNCTIONS 3
4 WIRING CONNECTION 3
5 BLOCK DIAGRAM 4
6 TERMINALS DESCRIPTION 6
7 PACKAGE AND IC BLOCK DIAGRAM 8
1 FEATURES
· Negative Displayed LCD (8-figures, 5×7 dots)
· Traffic Information Memory
· SEEK Up/Down, SCAN Up function
· CD Changer Contorol function
· Dolby B Noise Reduction
8 ALIGNMENT INSTRUCTIONS 11
9 ALIGNMENT POINTS 11
10 REPLACEMENT PARTS LIST 12
11 EXPLODED VIEW (Unit) 19
12 WIRING DIAGRAM 20
13 SCHEMATIC DIAGRAM -1 25
14 SCHEMATIC DIAGRAM -2 27
· Steering Remoto Control
· Untitheft System
· GALA System (Auto Volume Control for a car noise)
· Untitheft System (Code Number Memory)
· 3-Illumination Control Systems (Photo-sensor, Illumination
Control-1, Illumination Control-2)
· Illumination Color: Audi Red
CONTENTS
Page Page
2 REAR VIEW AND CONNECTORS
2
AUDI / CQ-LA1923L

3 FRONT VIEW AND FUNCTIONS
4 WIRING CONNECTION
3
AUDI / CQ-LA1923L

5 BLOCK DIAGRAM
5.1. Main Block
4
AUDI / CQ-LA1923L

5.2. AMP/Display Block
5
AUDI / CQ-LA1923L

6.1. MAIN BLOCK
IC601 C2BBGG000014
Pin
No.
Name Descripotion I/O VolT (V)
FM AM Tap
e
1 RES Reset Input I 4.9 4.9 4.9
2XTAL X-tal I 1.6 1.6 1.6
3EXTAL X-tal I 2.3 2.3 2.3
4 MD1 Connect to Vdd ─4.9 4.9 4.9
5 MD0 Connect to Vdd ─4.9 4.9 4.9
6 NMI Connect to Vdd ─4.9 4.9 4.9
7STBY Connect to Vdd ─4.9 4.9 4.9
8 VDD Power Supply (+5V) ─4.9 4.9 4.9
9 CD-CLK Clock Input (from CD
Changer)
I 0 0 0
10 CD-DATA Data Input (from CD Changer) I 0 0 0
11 CD-REMO Data Output (to CD Changer) O 4.9 4.9 4.9
12 GND Connect to Ground ─0 0 0
13 ANT-CONT F. Antenna Votage Contorol O 4.6 4.6 4.6
14 TIM MON
IN
TIM Memory status Input ─0 0 0
15 S CONT
ON/OFF
S. CONT status monitor I 0 0 0
16 T MUTE
ON/OFF
T. MUTE status monitor I 4.9 4.9 4.9
17 N CONT
ON/OFF
NAVI. MUTE status monitor I 4.9 4.9 4.9
18 BATT DET Low Votage detect I 4.9 4.9 4.9
19 CONT S.Cont T.Mute N.Cont Signals
Detect
I 4.9 4.9 4.9
20 P-ON POWER Switch ON/OFF
detect
I 0 0 0
21 LED CLK Clock Output (to LED) O 0 0 0
22 LED
DATA/LCD
SID
Data Output (to LED TIM
LCD)
I 4.9 4.9 4.9
23 VOL UP Volume Up Signal Input I 0 0 0
24 VOL DOWN Volume Down Signal Input I 4.9 4.9 4.9
25 LCD
SCLK/E2
CLK
Clock Output (to LCD E2 TIM) O 4.9 4.9 4.9
26 LCD CS LCD Chip Select O 4.9 4.9 0
27 R CLK R. Clock Output O 4.9 4.9 4.9
28 RDS CLK Clock Input (for RDS) I 2.5 0 2.5
29 VDD Power Supply (+5V) ─4.9 4.9 4.9
30 V CONT Signal Strength level Input I 0.4 0.4 0.4
31 MP Multi-path Signal Input I 0 0 0
32 NOISE Noise level Signal Input I 1.3 0 1.3
33 P SENSOR
IN
Photo Sensor Signal Input I 0 0 0
34 +B
MONITOR
+B Voltage Monitor I 3.4 3.4 3.4
35 SP-OUT R SP Output Input (for Self
Check function)
I 2.9 2.9 2.9
36 F-ANT ANT+ Shor detect (for Self
Check function)
I 1.5 1.5 1.5
37 SP-OUT L SP Output Input (for Self
Check function)
I 2.9 2.9 2.9
38 GND Connect to Ground ─0 0 0
39 RDS DATA Data Input (for RDS) I 2.5 0 2.5
40 LCD SOD Data Input (from LCD) I 4.9 4.9 4.9
41 LCD RESET Reset Output (to LCD) O 4.9 4.9 4.9
42 STANDBY Power Control Output (for
Audio Circuit)
O 4.9 4.9 4.9
43 RADIO ON RADIO ANT VAR ON Signal
Output
O 4.6 4.6 4.6
44 TIM ST Strobe Signal for TIM O 0 0 0
Pin
No.
Name Descripotion I/O VolT (V)
FM AM Tap
e
45 P-ON H LCD INDICATOR Illumination
ON Signal
O 4.9 4.9 4.9
46 WARNING
TONE(NC) ─ ─ ─ ─ ─
47 VDD Power Supply (+5V) ─4.9 4.9 4.9
48 E2 DI Data Output (to EEPROM) O 0 0 0
49 E2 CE Chip Enable Output (to
EEPROM)
O 0 0 0
50 GALA GALA Signal Input I 0 0 0
51 AF MUTE Audio Mute Signal Output O 4.9 4.9 4.9
52 MUTE Mute Signal Output (for Audio
Power Amp.)
O 4.9 4.9 4.9
53 E2 DO Data Input (from EEPROM) I 0 0 0
54 E-VOL
DATA
Data Output (to Main Volume
Control)
O 0 0 0
55 E-VOL CLK Clock Output (to Main Volume
Control)
O 0 0 0
56 GND Connect to Ground ─0 0 0
57 PLL DI Data Output (to PLL) O 0 0 0
58 PLL DO Data Input (from PLL) I 4.9 4.9 4.9
59 PLL CLK Clock Output (to PLL) O 0 0 0
60 PLL CE Chip Enable Output (to PLL) O 0 0 0
61 MON Tape Deck Powr ON control
Output
O 4.9 4.9 4.9
62 TMS Tape Music Sensor Signal
Input
I 0 0 0
63 A/B OUT Tape Play Side (A/B) Select
Signal Output
O 0 0 4.9
64 DOLBY Doby ON/OFF Signal Output O 0 0 4.9
65 PLAY SW Play SW Signal Input (from
Tape Deck)
I 0 0 0
66 DATA OUT Data Output (to Tape Deck) O 0 0 0
67 T MONITOR Thermal Sensor Input (from
Tape Deck)
I 4.9 4.9 4.9
68 DATA IN Data Input (from Tape Deck) I 4.9 4.9 4.9
69 T ENA Tape Deck Enable O 4.9 4.9 4.9
70 SV ST Strobe Output (to Sub Volume
Conttol)
O 0 0 0
71 SV CLK Clock Output (to Sub Volume
Conttol)
O 0 0 0
72 SV DATA Data Output (to Sub Volume
Conttol)
O 0 0 0
73 GND Connect to Ground ─0 0 0
74 S-uCOM
CLK
Clock Output (to Sub CPU) O 4.9 4.9 4.9
75 S-uCOM
DATA OUT
data Output (to Sub CPU) O 4.9 2.5 1.7
76 S-uCOM
DATA IN
Data Input (form Sub CPU) I 4.9 2 2
77 ESET OUT Reset Output (to Sub CPU) O 4.9 4.9 4.9
78 K-LINE OUT Serial Data Output (to Car
System)
O 4.9 4.9 4.9
79 K-LINE IN Serial Data Input (from Car
System)
I 4.9 4.9 4.9
80 CLK I/O Clock In/Out (for Tape Deck) I/O 4.9 4.9 4.9
6 TERMINALS DESCRIPTION
6
AUDI / CQ-LA1923L

IC604 C2ABDD000033
Pin
No.
Name Description I/O Vol.
(V)
1 (NC) ─ ─ ─
2 (NC) ─ ─ ─
3 P.
SENSOR
OUT
Photo Sensor ILL Output O 4.9
4 2ND DISP
ENA IN
Enable Input (from 2nd Display) I 0
5 2ND DISP
ENA OUT
Enable Output (to 2nd Display) O 4.9
6 2ND DISP
CLK
Clock Output (to 2nd Display) O 0
7 2ND DISP
DATA
Data Output (to 2nd Display) O 0
8-16 (NC) ─ ─ ─
17 VSS Ground ─0
18 XT1 Connect to Ground ─0
19 (NC) ─ ─ ─
20 RESET Reset Input I 4.7
21 XTAL (X1) Connect to X-tal I 2.3
22 XTAL (X2) Connect to X-tal I 2.5
23 S-
REMCON
Steering Remoto Control Input I 0
24 ILL 1 ILL1 (Button) Self Check Input I 4.9
25 ILL 2 ILL2 (LCD Indicator) Input I 0
26 AMP+ Self Check (AMP+) O 4.5
27 SP-OUT
CONT
SP Self Check Control Output O 0
28 (NC) ─ ─ ─
29 S-uCOM
DATA OUT
Data Input (from Main CPU) I 2.7
30 S-uCOM
DATA IN
Data Output (to Main CPU) O 2.0
31 S-uCOM
CLK
Clock Input (from Main CPU) I 4.9
32 INT4 Connect to Ground ─0
33 TI0 Connect to Ground ─0
34 (NC) ─ ─ ─
35 INT2 Connect to Ground ─0
36 INT1 Ground ─0
37 Ign. Ign. Signal Input I 0
38 (NC) ─ ─ ─
39 VDD Power Supply ─4.9
40 C NAVI/TEL Mix Control (C) O 0
41 B NAVI/TEL Mix Control (B) O 4.9
42 A NAVI/TEL Mix Control (A) O 4.9
43 BOSE/NOR
MAL
BOSE/NORMAL Select Output O 4.9
44 (NC) ─ ─ ─
6.2. DISPLAY BLOCK
IC601 YEAMH66720F2
Pin
No.
Name Descripotion I/O Vol.
(V)
1-24 SEG 24-S47 Segment Signal output O 1.0
25 SEG48 (NC) ─ ─ ─
26 SEG49 (NC) ─ ─ ─
27 SEG50 (NC) ─ ─ ─
28-34 COM1-7 Common Signal output O 1.0
35 COM8 (NC) ─ ─ ─
36 COMS Common Signal output
(for Icon Segment)
O 1.0
37 V1 Connect to Power Supply
(for LCD Drive) ─2.9
38 V2 Connect to Power Supply
(for LCD Drive) ─1.0
39 V3 Connect to Power Supply
(for LCD Drive) ─1.0
40 V4 Connect to Power Supply
(for LCD Drive) ─0
41 V5 Connect to Power Supply
(for LCD Drive) ─0
42 V5OUT3
(NC) ─ ─ ─
43 V5OUT2 Stepup Voltage output
(Vci ×2)
O 0
44 GND Connect to ground ─0
45 C1 Connect to Capacitor (for
Voltage Stepup) ─0
46 C2 Connect to Capacitor (for
Voltage Stepup) ─0.8
47 Vci Input Voltage for Voltage
Stepup Circuit
I 3.1
48 VCC Connect to Power Supply ─4.8
49 OSC1 Oscillator output I 2.4
50 OSC2 Oscillator Input O 2.5
51 CL1 (NC) ─ ─ ─
52 CL2 (NC) ─ ─ ─
53 D (NC) ─ ─ ─
54 M (NC) ─ ─ ─
55 CS Chip Select Input I 4.7
56 SCLK Serial Clock Input I 4.7
57 SID Serial Data Input I 0
58 SOD Serial Data Output O 4.7
59 NL Display Line Select Input ─0
60 RESET Reset Signal Input I 4.7
61 TEST2 Test Terminal 1 ─0
62 TEST1 Test Terminal 3 ─0
63 GND Connect to ground ─0
64 LED0 (NC) ─ ─ ─
65 LED1 (NC) ─ ─ ─
66 IRQ (NC) ─ ─ ─
67-71 KST0-4 Key Matrix Output O 3.9
72 KST5 (NC) ─ ─ ─
73-75 KIN0-2 Key Matrix Input I 4.6
76-77 KIN3-4 Key Matrix Input I 4.7
78-100 SEG1-23 Segment Signal output11 O 1.0
7
AUDI / CQ-LA1923L

7 PACKAGE AND IC BLOCK DIAGRAM
PA101 : YEP0PTA513B0
IC501 : YEAMS6789A
8
AUDI / CQ-LA1923L

IC1 : YEAMCX1980QK
IC281 : AN7190NKLC
IC603 : AN8065SE1
IC302 : YEAMM62419T1
IC353 : C1BA00000198
9
AUDI / CQ-LA1923L

IC503 : YEAM74HC595T
IC602 : YEAMS2922ADF
IC703 : YEAMDA7330BD
IC502 : YEAMS6684B
IC701 : YEAMLC72146T
10
AUDI / CQ-LA1923L

· Power Supply Voltage : DC13.2V
· Output Impedance : 4Ω
· Output Power : 0.5W
· Balance, Fader Control : center
· Bass, Treble Control : Center
· Dolby NR: OFF
8 ALIGNMENT INSTRUCTIONS
8.1. Alignment Conditions
Note :
Do not align the FM/AM package block. When the package block is necessary, it will be supplied already aligned at the
factory.
8.2. Dolby NR Alignment
Step Alignment Item Test Tape VTVM Connection Adjust Remarks
(1) DOLBY NR Rch RFKZ0038 TP7 VR201 Adjust for 388mV ±0.5dB
(2) DOLBY NR Lch RFKZ0038 TP6 VR301 Adjust for 388mV ±0.5dB
9 ALIGNMENT POINTS
11
AUDI / CQ-LA1923L

10 REPLACEMENT PARTS
LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
5. "MCC" marks in remarks column are indicated supply parts
of Matsushita Communication Industrial Corp. of America
(MCC).
Ref.
No.
Part No. Part Name & Description Remarks
[E6619F] Main Block
IC´s and TRANSISTORs
IC1 YEAMCX1980QK IC
IC51 YEAMPC78L05T IC
IC52 YEAMPC78M08A IC
IC101 AN6564NST1 IC
IC151 C0ABCB000032 IC
IC203 YEAMM5218AFE IC
IC204 YEAMTC4W53FT IC
IC205 C0ABCB000032 IC
IC251 YEAMPD4053E2 IC
IC281 AN7190NKLC IC
IC302 YEAMM62419T1 IC
IC335 C0ABCB000032 IC
IC351 YEAMPD4053E2 IC
IC352 YEAMM5218AFE IC
IC353 C1BA00000198 IC
IC354 C0ABCB000032 IC
IC501 YEAMS6789A IC
IC502 YEAMS6684B IC
IC503 YEAM74HC595T IC
IC601 C2BBGG000014 IC
IC602 YEAMS2922ADF IC
IC603 AN8065SE1 IC
IC604 C2ABDD000033 IC
IC605 C0JBAA000046 IC
IC606 YEAMC14584BE IC
IC607 YEAMPC78M08A IC
IC608 YEAMPC78N05H IC
IC701 YEAMLC72146T IC
IC703 YEAMDA7330BD IC
IC781 YEAMM5218AFE IC
PA101 YEP0PTA513B0 Electronic Tuner
Q51 B1ADJC000003 Transistor
Q52 YEANC114YKX Transistor
Q53 2SB1073TX Transistor
Q54 YEANC2412KTX Transistor
Q55 B1BBAC000007 Transistor
Q101 B1GBCFNN0004 Transistor
Q201 YEANC3661TA Transistor
Q202 YEANC3661TA Transistor
Q253 YEANC3661TA Transistor
Q254 YEANC3661TA Transistor
Ref.
No.
Part No. Part Name & Description Remarks
Q301 YEANC3661TA Transistor
Q302 YEANC3661TA Transistor
Q350 B1GBCFNN0004 Transistor
Q353 YEANC3661TA Transistor
Q354 YEANC3661TA Transistor
Q401 B1GBCFNN0004 Transistor
Q403 B1GDCFJJ0002 Transistor
Q501 B1GDCFNN0002 Transistor
Q502 B1GBCFNN0004 Transistor
Q600 YEANC2412KTX Transistor
Q601 YEANC114YKX Transistor
Q602 2SB1073TX Transistor
Q603 B1ADJC000003 Transistor
Q604 B1BBAC000007 Transistor
Q605 2SD1328STTX Transistor
Q606 2SD1280TX Transistor
Q607 B1GBCFNN0004 Transistor
Q608 B1BBAC000007 Transistor
Q671 2SD1328STTX Transistor
Q681 YEANC2412KTX Transistor
Q682 B1ADJC000003 Transistor
Q683 B1GBCFNN0004 Transistor
Q688 B1GDCFJN0004 Transistor
Q689 B1ABCF000042 Transistor
Q691 B1GDCFNN0002 Transistor
Q692 YEANC2412KTX Transistor
Q701 YEAN2SK536TB Transistor
Q702 2SB1073TX Transistor
Q703 YEANC114YKX Transistor
Q721 B1BBAC000007 Transistor
Q722 2SD1328STTX Transistor
Q723 B1ADJC000003 Transistor
Q724 YEANC114YKX Transistor
Q730 B1GDCFJN0004 Transistor
Q773 B1GBHBEA0004 Transistor
Q774 B1GBHBEA0004 Transistor
Q775 B1ABCF000044 Transistor
Q776 B1ABCF000044 Transistor
Q777 B1GBCFNN0004 Transistor
Q778 YEANFP1F3PT1 Transistor
Q801 B1ABCF000044 Transistor
Q901 YEANC2412KTX Transistor
Q902 YEANC2412KTX Transistor
Q903 B1ABCF000042 Transistor
Q904 B1GDCFNN0002 Transistor
Q905 B1GDCFNN0002 Transistor
Q906 YEANC3661TA Transistor
DIODEs
D51 YEADRD10M2T2 Diode
D52 YEADRD43M2T2 Diode
D151 MA153TX Diode
D152 MA153TX Diode
D156 MA152WKTX Diode
D401 MA3X152K0L Diode
D601 MA3X152K0L Diode
D602 YEADRD56M3T1 Diode
D603 MA3X152K0L Diode
D604 YEADRD56M2T1 Diode
D605 YEADRD56M3T1 Diode
D607 MA159TX Diode
D608 MA159TX Diode
D613 MA152WATX Diode
D615 MA152WATX Diode
D616 MA152WKTX Diode
D681 MA152WKTX Diode
D683 YEAD1SS355T1 Diode
D697 MA152WATX Diode
D701 B0BC5R000005 Diode
D702 MA3X152K0L Diode
D711 MA159TX Diode
D721 YEADRD82M2T2 Diode
12
AUDI / CQ-LA1923L

Ref.
No.
Part No. Part Name & Description Remarks
D722 B0BC5R000005 Diode
D730 MA741TX Diode
D731 B0BC5R000005 Diode
D732 MA3X152K0L Diode
D733 MA152WATX Diode
D734 MA152WKTX Diode
D741 MA3X152K0L Diode
D742 MA159TX Diode
D761 MA152WATX Diode
D771 YEAD11ES2T Diode
D772 YEAD11ES2T Diode
D773 MA159TX Diode
D782 YEADDSM3MA2T Diode
D783 YEADRB051L40 Diode
D784 MA721TX Diode
D785 YEADRB051L40 Diode
D786 MA8068MTX Diode
D801 MA152WKTX Diode
D802 B0BC5R000005 Diode
D901 MA152WATX Diode
D902 MA152WATX Diode
D903 MA3X152K0L Diode
D904 MA152WATX Diode
D905 MA152WATX Diode
D906 MA3X152K0L Diode
D908 MA3X152K0L Diode
CAPACITORs
C1 YECUS1H331JM Ceramic, 330PF 50WV
C2 YECUS1H331JM Ceramic, 330PF 50WV
C3 YECUS1H331JM Ceramic, 330PF 50WV
C4 YECUS1H331JM Ceramic, 330PF 50WV
C5 ECEA1AKA330I Electrolytic, 33µF 10WV
C6 YECUS1H103KX Ceramic, 0.01µF 50WV
C7 ECEA1HKAR22I Electrolytic, 0.22µF 50WV
C8 ECEA1CKA100I Electrolytic, 10µF 16WV
C9 YECUS1C104KX Ceramic, 0.1µF 16WV
C10 ECEA1AKA330I Electrolytic, 33µF 10WV
C11 YECUS1H103KX Ceramic, 0.01µF 50WV
C12 ECEA1HKAR22I Electrolytic, 0.22µF 50WV
C13 ECEA1AKA330I Electrolytic, 33µF 10WV
C14 YECUS1H103ZF Ceramic, 0.01µF 50WV
C15 YECUS1C104KX Ceramic, 0.1µF 16WV
C16 YECUS1E333KX Ceramic, 0.033µF 25WV
C17 ECEA1HKA010I Electrolytic, 1µF 50WV
C18 YECUS1H153KX Ceramic, 0.015µF 50WV
C19 ECEA1CKA100I Electrolytic, 10µF 16WV
C50 YECUS1H101JM Ceramic, 100PF 50WV
C51 YECUS1E104ZF Ceramic, 0.1µF 25WV
C52 YECUS1E104ZF Ceramic, 0.1µF 25WV
C53 ECEA1CKA100I Electrolytic, 10µF 16WV
C54 ECEA1HKA010I Electrolytic, 1µF 50WV
C55 YECUS1E104ZF Ceramic, 0.1µF 25WV
C56 ECEA1CKA100I Electrolytic, 10µF 16WV
C57 ECEA1CKA100I Electrolytic, 10µF 16WV
C58 ECEA1CKA100I Electrolytic, 10µF 16WV
C60 ECEA1CKA100I Electrolytic, 10µF 16WV
C102 YECUS1H102KX Ceramic, 1000PF 50WV
C103 YECUS1H103KX Ceramic, 0.01µF 50WV
C104 ECEA1AKA101I Electrolytic, 100µF 10WV
C105 YECUS1E223KX Ceramic, 0.022µF 25WV
C106 YECUS1H153KX Ceramic, 0.015µF 50WV
C107 YECUS1C154KX Ceramic, 0.15µF 16WV
C108 YECUS1H103KX Ceramic, 0.01µF 50WV
C109 YECUS1H183KX Ceramic, 0.018µF 50WV
C110 YECUS1C154KX Ceramic, 0.15µF 16WV
C111 YECUS1H103KX Ceramic, 0.01µF 50WV
C112 ECEA1CKA100I Electrolytic, 10µF 16WV
C113 YECUS1H103KX Ceramic, 0.01µF 50WV
C114 YECUS1H102KX Ceramic, 1000PF 50WV
C115 YECUS1H102KX Ceramic, 1000PF 50WV
C117 YECUS1H103ZF Ceramic, 0.01µF 50WV
Ref.
No.
Part No. Part Name & Description Remarks
C118 YECUS1H101JM Ceramic, 100PF 50WV
C119 YECUS1E223KX Ceramic, 0.022µF 25WV
C120 YECUS1H103ZF Ceramic, 0.01µF 50WV
C121 ECEA1AKA221I Electrolytic, 220µF 10WV
C150 F1J1C274A006 Ceramic, 0.27µF 16WV
C152 YECUS1H122KX Ceramic, 1200PF 50WV
C153 YECUS1H152KX Ceramic, 0.0015µF 50WV
C154 YECUS1H103KX Ceramic, 0.01µF 50WV
C155 YECUS1H151JM Ceramic, 150PF 50WV
C156 YECUS1H151JM Ceramic, 150PF 50WV
C157 YECUS1H151JM Ceramic, 150PF 50WV
C158 YECUS1H102KX Ceramic, 1000PF 50WV
C159 YECUS1H100DM Ceramic, 10PF 50WV
C160 YECUS1H102KX Ceramic, 1000PF 50WV
C161 YECUS1E223KX Ceramic, 0.022µF 25WV
C163 ECEA1CKA100I Electrolytic, 10µF 16WV
C164 YECUS1H151JM Ceramic, 150PF 50WV
C169 YECUS1H103ZF Ceramic, 0.01µF 50WV
C200 ECEA1CKA100I Electrolytic, 10µF 16WV
C201 ECEA1HKA010I Electrolytic, 1µF 50WV
C202 ECEA1AKA220I Electrolytic, 22µF 10WV
C203 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C211 YECUS1H153KX Ceramic, 0.015µF 50WV
C213 YECUS1C563KX Ceramic, 0.056µF 16WV
C214 YECUS1H562KX Ceramic, 5600PF 50WV
C215 YECUS1H562KX Ceramic, 5600PF 50WV
C216 YECUS1H153KX Ceramic, 0.015µF 50WV
C218 ECEA1CKA100I Electrolytic, 10µF 16WV
C219 YECUS1C104KX Ceramic, 0.1µF 16WV
C222 YECUS1H221JM Ceramic, 220PF 50WV
C223 YECUS1H680JM Ceramic, 68PF 50WV
C224 ECEA1EKA4R7I Electrolytic, 4.7µF 25WV
C225 ECEA1CKA100I Electrolytic, 10µF 16WV
C226 ECEA1CKA100I Electrolytic, 10µF 16WV
C227 ECEA1CKA100I Electrolytic, 10µF 16WV
C229 ECEA1CKA100I Electrolytic, 10µF 16WV
C230 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C231 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C241 YECUS1C154KX Ceramic, 0.15µF 16WV
C245 YECUS1C474KX Ceramic, 0.47µF 16WV
C246 ECEA1AKA220I Electrolytic, 22µF 10WV
C253 ECEA1HKA2R2B Electrolytic, 2.2µF 50WV
C254 ECEA1HKA2R2B Electrolytic, 2.2µF 50WV
C255 ECEA1AKA470I Electrolytic, 47µF 10WV
C256 ECEA1AKA470I Electrolytic, 47µF 10WV
C258 YECUS1H101JM Ceramic, 100PF 50WV
C259 YECUS1H101JM Ceramic, 100PF 50WV
C276 YECUS1H181JM Ceramic, 180PF 50WV
C281 YECUS1H471JM Ceramic, 470PF 50WV
C282 ECQV1H224JL2 Plastic Film, 0.22µF 50WV
C283 ECQV1H224JL2 Plastic Film, 0.22µF 50WV
C284 ECEA1CKA330B Electrolytic, 33µF 16WV
C292 ECEA1HKA010I Electrolytic, 1µF 50WV
C293 ECEA1CKA100I Electrolytic, 10µF 16WV
C294 ECEA1CKA100I Electrolytic, 10µF 16WV
C296 ECEA1HKA010I Electrolytic, 1µF 50WV
C297 YECUS1H222KX Ceramic, 2200PF 50WV
C298 YECUS1H222KX Ceramic, 2200PF 50WV
C300 ECEA1CKA100I Electrolytic, 10µF 16WV
C301 ECEA1HKA010I Electrolytic, 1µF 50WV
C303 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C311 YECUS1H153KX Ceramic, 0.015µF 50WV
C313 YECUS1C563KX Ceramic, 0.056µF 16WV
C314 YECUS1H562KX Ceramic, 5600PF 50WV
C315 YECUS1H562KX Ceramic, 5600PF 50WV
C316 YECUS1H153KX Ceramic, 0.015µF 50WV
C319 YECUS1C104KX Ceramic, 0.1µF 16WV
C321 ECEA1CKA100I Electrolytic, 10µF 16WV
C322 YECUS1H221JM Ceramic, 220PF 50WV
C323 YECUS1H680JM Ceramic, 68PF 50WV
C324 ECEA1EKA4R7I Electrolytic, 4.7µF 25WV
C325 ECEA1CKA100I Electrolytic, 10µF 16WV
C326 ECEA1CKA100I Electrolytic, 10µF 16WV
13
AUDI / CQ-LA1923L

Ref.
No.
Part No. Part Name & Description Remarks
C327 ECEA1CKA100I Electrolytic, 10µF 16WV
C328 YECUS1E104ZF Ceramic, 0.1µF 25WV
C329 ECEA1CKA100I Electrolytic, 10µF 16WV
C330 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C331 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C338 YECUS1C224ZF Ceramic, 0.22µF 16WV
C345 YECUS1C474KX Ceramic, 0.47µF 16WV
C346 ECEA1AKA220I Electrolytic, 22µF 10WV
C350 YECUS1H103KX Ceramic, 0.01µF 50WV
C352 YECUS1H103ZF Ceramic, 0.01µF 50WV
C353 ECEA1HKA2R2B Electrolytic, 2.2µF 50WV
C354 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C355 ECEA1AKA470B Electrolytic, 47µF 10WV
C356 ECEA1AKA470I Electrolytic, 47µF 10WV
C358 YECUS1H101JM Ceramic, 100PF 50WV
C359 YECUS1H101JM Ceramic, 100PF 50WV
C360 YECUS1C124KX Ceramic, 0.12µF 16WV
C361 YECUS1C224ZF Ceramic, 0.22µF 16WV
C376 YECUS1H181JM Ceramic, 180PF 50WV
C381 YECUS1H471JM Ceramic, 470PF 50WV
C382 ECQV1H224JL2 Plastic Film, 0.22µF 50WV
C383 ECQV1H224JL2 Plastic Film, 0.22µF 50WV
C392 ECEA1HKA010I Electrolytic, 1µF 50WV
C393 ECEA1CKA100I Electrolytic, 10µF 16WV
C394 ECEA1CKA100I Electrolytic, 10µF 16WV
C397 YECUS1H222KX Ceramic, 2200PF 50WV
C398 YECUS1H222KX Ceramic, 2200PF 50WV
C401 YECUS1H101JM Ceramic, 100PF 50WV
C403 YECUS1H101JM Ceramic, 100PF 50WV
C404 YECUS1H101JM Ceramic, 100PF 50WV
C405 YECUS1H102KX Ceramic, 1000PF 50WV
C502 ECEA0JKA101I Electrolytic, 100µF 6.3WV
C503 YECUS1E104ZF Ceramic, 0.1µF 25WV
C504 YECUS1C104KX Ceramic, 0.1µF 16WV
C505 YECUS1H471JM Ceramic, 470PF 50WV
C506 YECUS1C224ZF Ceramic, 0.22µF 16WV
C507 ECEA1CKA100B Electrolytic, 10µF 16WV
C508 ECEA1CKA100B Electrolytic, 10µF 16WV
C509 YECUS1E104ZF Ceramic, 0.1µF 25WV
C510 YECUS1H471JM Ceramic, 470PF 50WV
C511 YECUS1E223KX Ceramic, 0.022µF 25WV
C512 YECUS1H103ZF Ceramic, 0.01µF 50WV
C514 YECUS1H103ZF Ceramic, 0.01µF 50WV
C600 YECUS1H103KX Ceramic, 0.01µF 50WV
C601 YECUS1H150JM Ceramic, 15PF 50WV
C602 YECUS1H150JM Ceramic, 15PF 50WV
C603 ECEA1CKA100I Electrolytic, 10µF 16WV
C604 YECUS1C104KX Ceramic, 0.1µF 16WV
C605 YECUS1H103KX Ceramic, 0.01µF 50WV
C606 ECEA0JKA221I Electrolytic, 220µF 6.3WV
C608 YECUS1C224ZF Ceramic, 0.22µF 16WV
C609 YECUS1H101JM Ceramic, 100PF 50WV
C610 YECUS1H101JM Ceramic, 100PF 50WV
C611 YECUS1H101JM Ceramic, 100PF 50WV
C613 YECUS1C104KX Ceramic, 0.1µF 16WV
C616 YECUS1H101JM Ceramic, 100PF 50WV
C617 YECUS1H103KX Ceramic, 0.01µF 50WV
C618 YECUS1C224ZF Ceramic, 0.22µF 16WV
C619 YECUS1C224ZF Ceramic, 0.22µF 16WV
C620 YECUS1H101JM Ceramic, 100PF 50WV
C624 YECUS1H101JM Ceramic, 100PF 50WV
C625 YECUS1H101JM Ceramic, 100PF 50WV
C626 YECUS1H101JM Ceramic, 100PF 50WV
C636 YECUS1H101JM Ceramic, 100PF 50WV
C637 YECUS1H101JM Ceramic, 100PF 50WV
C638 YECUS1H101JM Ceramic, 100PF 50WV
C647 YECUS1H101JM Ceramic, 100PF 50WV
C651 YECUS1H101JM Ceramic, 100PF 50WV
C652 YECUS1H101JM Ceramic, 100PF 50WV
C653 YECUS1H101JM Ceramic, 100PF 50WV
C654 YECUS1H101JM Ceramic, 100PF 50WV
C672 ECA1CKA221XI Electrolytic, 220µF 16WV
C688 ECEA1HKA010I Electrolytic, 1µF 50WV
Ref.
No.
Part No. Part Name & Description Remarks
C689 YECUS1H103ZF Ceramic, 0.01µF 50WV
C694 YECUS1E104ZF Ceramic, 0.1µF 25WV
C695 ECEA1CKA100I Electrolytic, 10µF 16WV
C696 YECUS1E104ZF Ceramic, 0.1µF 25WV
C697 YECUS1E104ZF Ceramic, 0.1µF 25WV
C700 YECUS1H103ZF Ceramic, 0.01µF 50WV
C701 YECUS1H100DM Ceramic, 10PF 50WV
C702 YECUS1H100DM Ceramic, 10PF 50WV
C704 YECUS1H101JM Ceramic, 100PF 50WV
C705 YECUS1H101JM Ceramic, 100PF 50WV
C706 YECUS1H101JM Ceramic, 100PF 50WV
C707 YECUS1H101JM Ceramic, 100PF 50WV
C708 ECEA0JKA470I Electrolytic, 47µF 6.3WV
C709 YECUS1C334KX Ceramic, 0.33µF 16WV
C711 YECUS1H222KX Ceramic, 2200PF 50WV
C712 YECUS1E393KX Ceramic, 0.039µF 25WV
C713 YECUS1H103ZF Ceramic, 0.01µF 50WV
C714 YECUS1H220JM Ceramic, 22PF 50WV
C715 YECUS1H220JM Ceramic, 22PF 50WV
C716 ECEA1AKA470I Electrolytic, 47µF 10WV
C717 YECUS1C224ZF Ceramic, 0.22µF 16WV
C718 F1J1H121A034 Ceramic, 120PF 50WV
C719 YECUS1H271JM Ceramic, 270PF 50WV
C720 ECEA1CKA100I Electrolytic, 10µF 16WV
C721 YECUS1H103KX Ceramic, 0.01µF 50WV
C722 YECUS1H103ZF Ceramic, 0.01µF 50WV
C723 YECUS1H101JM Ceramic, 100PF 50WV
C724 YECUS1H101JM Ceramic, 100PF 50WV
C725 YECUS1C224ZF Ceramic, 0.22µF 16WV
C727 ECEA1AKA470I Electrolytic, 47µF 10WV
C732 YECUS1C104KX Ceramic, 0.1µF 16WV
C734 ECEA1AKA101I Electrolytic, 100µF 10WV
C735 YECUS1H101JM Ceramic, 100PF 50WV
C736 YECUS1H101JM Ceramic, 100PF 50WV
C737 ECEA1CKA100I Electrolytic, 10µF 16WV
C738 ECEA1AKA220I Electrolytic, 22µF 10WV
C739 YECUS1C104KX Ceramic, 0.1µF 16WV
C740 YECUS1C104KX Ceramic, 0.1µF 16WV
C741 YECUS1C104KX Ceramic, 0.1µF 16WV
C742 YECUS1C104KX Ceramic, 0.1µF 16WV
C744 YECUS1H103ZF Ceramic, 0.01µF 50WV
C745 ECEA1CKA100I Electrolytic, 10µF 16WV
C747 ECEA1CKA101 Electrolytic, 100µF 16WV
C748 YECUS1E223KX Ceramic, 0.022µF 25WV
C749 YECUS1C474KX Ceramic, 0.47µF 16WV
C751 YECUS1E104ZF Ceramic, 0.1µF 25WV
C752 YECUS1E104ZF Ceramic, 0.1µF 25WV
C753 ECEA1CKA100I Electrolytic, 10µF 16WV
C754 YEECFS0H104Z Electrolytic, 0.1µF 5.5WV
C755 ECEA1CKA100I Electrolytic, 10µF 16WV
C756 ECEA1CKA100I Electrolytic, 10µF 16WV
C761 YECUS1H103KX Ceramic, 0.01µF 50WV
C771 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C772 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C773 F1K1C474A014 Ceramic, 0.47µF 16WV
C774 F1K1C474A014 Ceramic, 0.47µF 16WV
C775 F1K1C474A014 Ceramic, 0.47µF 16WV
C776 F1K1C474A014 Ceramic, 0.47µF 16WV
C781 ECA1CM102B Electrolytic, 1000µF 16WV
C782 YECUS1H103KX Ceramic, 0.01µF 50WV
C783 YECUS1H103KX Ceramic, 0.01µF 50WV
C784 ECA1CM102B Electrolytic, 1000µF 16WV
C785 YECUS1H103KX Ceramic, 0.01µF 50WV
C786 ECA1CM101I Electrolytic, 100µF 16WV
C787 YECUS1C474KX Ceramic, 0.47µF 16WV
C788 YECUS1H101JM Ceramic, 100PF 50WV
C789 YECUS1H101JM Ceramic, 100PF 50WV
C790 ECEA1CKA470B Electrolytic, 47µF 16WV
C791 YECUS1C224ZF Ceramic, 0.22µF 16WV
C792 YECUS1C224ZF Ceramic, 0.22µF 16WV
C797 ECA1CM101I Electrolytic, 100µF 16WV
C900 YECUS1H101JM Ceramic, 100PF 50WV
C901 YECUS1H300JM Ceramic, 30PF 50WV
14
AUDI / CQ-LA1923L

Ref.
No.
Part No. Part Name & Description Remarks
C902 YECUS1H300JM Ceramic, 30PF 50WV
C903 YECUS1H101JM Ceramic, 100PF 50WV
C904 YECUS1H101JM Ceramic, 100PF 50WV
C905 YECUS1H101JM Ceramic, 100PF 50WV
C906 YECUS1H101JM Ceramic, 100PF 50WV
C907 YECUS1H101JM Ceramic, 100PF 50WV
C908 YECUS1H101JM Ceramic, 100PF 50WV
C909 YECUS1H101JM Ceramic, 100PF 50WV
C910 YECUS1H101JM Ceramic, 100PF 50WV
C912 YECUS1E104ZF Ceramic, 0.1µF 25WV
C913 YECUS1C474KX Ceramic, 0.47µF 16WV
C914 YECUS1H101JM Ceramic, 100PF 50WV
C915 YECUS1H101JM Ceramic, 100PF 50WV
C916 YECUS1H101JM Ceramic, 100PF 50WV
C917 YECUS1H101JM Ceramic, 100PF 50WV
C918 YECUS1H101JM Ceramic, 100PF 50WV
RESISTORs
L102 ERDS2TC0T Carbon, 0Ω
ΩΩ
Ω1/4W
L301 ERDS2TC0T Carbon, 0Ω
ΩΩ
Ω1/4W
L610 ERDS2TC0T Carbon, 0Ω
ΩΩ
Ω1/4W
L703 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
L705 ERDS2TC0T Carbon, 0Ω
ΩΩ
Ω1/4W
L901 ERDS2TC0T Carbon, 0Ω
ΩΩ
Ω1/4W
R1 ERJ6GEYJ823 Chip, 82kΩ
ΩΩ
Ω1/10W
R2 ERJ6GEYJ823 Chip, 82kΩ
ΩΩ
Ω1/10W
R3 ERJ6GEYJ823 Chip, 82kΩ
ΩΩ
Ω1/10W
R4 ERJ6GEYJ823 Chip, 82kΩ
ΩΩ
Ω1/10W
R5 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R6 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R7 ERJ6GEYJ334 Chip, 330kΩ
ΩΩ
Ω1/10W
R8 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R9 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R10 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R11 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R12 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R51 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R52 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R53 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R54 ERJ6GEYJ153 Chip, 15kΩ
ΩΩ
Ω1/10W
R55 ERJ14YJ102H Chip, 1kΩ
ΩΩ
Ω1/4W
R56 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R57 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R58 ERJ6GEYJ1R0 Chip, 1.0Ω
ΩΩ
Ω1/10W
R101 ERJ6GEYJ392 Chip, 3.9kΩ
ΩΩ
Ω1/10W
R102 ERJ6GEYJ334 Chip, 330kΩ
ΩΩ
Ω1/10W
R103 ERJ6GEYJ153 Chip, 15kΩ
ΩΩ
Ω1/10W
R104 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R105 ERJ6GEYJ123 Chip, 12kΩ
ΩΩ
Ω1/10W
R106 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R107 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R108 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R109 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R111 ERJ6GEYJ563 Chip, 56kΩ
ΩΩ
Ω1/10W
R112 ERJ6GEYJ563 Chip, 56kΩ
ΩΩ
Ω1/10W
R113 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R114 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R115 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R116 ERJ8GEY0R00V Chip, 0Ω
ΩΩ
Ω1/8W
R117 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R118 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R132 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R153 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R154 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R155 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R156 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R157 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R158 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R159 ERJ6GEYJ393 Chip, 39kΩ
ΩΩ
Ω1/10W
R160 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R161 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R162 ERJ6GEYJ393 Chip, 39kΩ
ΩΩ
Ω1/10W
Ref.
No.
Part No. Part Name & Description Remarks
R163 ERJ6GEYJ393 Chip, 39kΩ
ΩΩ
Ω1/10W
R164 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R165 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R166 ERJ6GEYJ224 Chip, 220kΩ
ΩΩ
Ω1/10W
R167 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R168 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R169 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R201 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R202 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R205 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R206 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R210 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R212 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R213 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R214 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R217 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R220 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R221 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R222 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R223 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R224 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R225 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R227 ERJ6GEYJ153 Chip, 15kΩ
ΩΩ
Ω1/10W
R229 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R230 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R231 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R232 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R233 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R238 ERJ6GEYJ273 Chip, 27kΩ
ΩΩ
Ω1/10W
R241 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R242 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R243 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R245 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R253 ERJ6GEYJ100 Chip, 10Ω
ΩΩ
Ω1/10W
R255 ERJ6GEYJ4R7 Chip, 4.7Ω
ΩΩ
Ω1/10W
R256 ERJ6GEYJ4R7 Chip, 4.7Ω
ΩΩ
Ω1/10W
R257 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R258 ERJ6GEYJ182 Chip, 1.8kΩ
ΩΩ
Ω1/10W
R259 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R260 ERJ6GEYJ182 Chip, 1.8kΩ
ΩΩ
Ω1/10W
R263 ERJ6GEYJ154 Chip, 150kΩ
ΩΩ
Ω1/10W
R264 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R270 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R271 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R272 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R273 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R274 ERJ6GEYJ823 Chip, 82kΩ
ΩΩ
Ω1/10W
R275 ERJ6GEYJ823 Chip, 82kΩ
ΩΩ
Ω1/10W
R276 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R277 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R278 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R281 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R282 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R283 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R291 ERDS2TC0T Carbon, 0Ω
ΩΩ
Ω1/4W
R294 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R295 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R298 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R299 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R301 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R302 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R305 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R306 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R312 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R314 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R320 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R321 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R322 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R323 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R324 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R325 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R327 ERJ6GEYJ153 Chip, 15kΩ
ΩΩ
Ω1/10W
R329 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
15
AUDI / CQ-LA1923L

Ref.
No.
Part No. Part Name & Description Remarks
R330 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R331 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R332 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R333 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R338 ERJ6GEYJ333 Chip, 33kΩ
ΩΩ
Ω1/10W
R341 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R342 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R343 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R345 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R350 ERJ6GEYJ753 Chip, 75kΩ
ΩΩ
Ω1/10W
R351 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R353 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R354 ERJ6GEYJ752 Chip, 7.5kΩ
ΩΩ
Ω1/10W
R355 ERJ6GEYJ4R7 Chip, 4.7Ω
ΩΩ
Ω1/10W
R356 ERJ6GEYJ4R7 Chip, 4.7Ω
ΩΩ
Ω1/10W
R357 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R358 ERJ6GEYJ182 Chip, 1.8kΩ
ΩΩ
Ω1/10W
R359 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R360 ERJ6GEYJ182 Chip, 1.8kΩ
ΩΩ
Ω1/10W
R363 ERJ6GEYJ154 Chip, 150kΩ
ΩΩ
Ω1/10W
R364 ERJ6GEYJ154 Chip, 150kΩ
ΩΩ
Ω1/10W
R370 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R371 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R372 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R373 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R374 ERJ6GEYJ823 Chip, 82kΩ
ΩΩ
Ω1/10W
R375 ERJ6GEYJ823 Chip, 82kΩ
ΩΩ
Ω1/10W
R376 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R377 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R378 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R381 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R382 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R383 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R394 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R395 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R398 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R399 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R401 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R402 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R404 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R405 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R406 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R500 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R501 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R502 ERJ6GEYJ224 Chip, 220kΩ
ΩΩ
Ω1/10W
R503 ERJ6GEYJ274 Chip, 270kΩ
ΩΩ
Ω1/10W
R504 ERJ6GEYJ224 Chip, 220kΩ
ΩΩ
Ω1/10W
R505 ERJ6GEYJ563 Chip, 56kΩ
ΩΩ
Ω1/10W
R506 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R601 ERJ6GEYJ563 Chip, 56kΩ
ΩΩ
Ω1/10W
R602 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R611 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R612 ERX1SJ6R8V Metal Film, 6.8Ω
ΩΩ
Ω1W
R613 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R614 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R615 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R616 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R617 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R618 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R619 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R620 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R621 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R634 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R636 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R663 ERJ6GEYJ105 Chip, 1M Ω
ΩΩ
Ω1/10W
R666 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R667 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R668 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R669 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R670 ERJ6GEYJ470 Chip, 47Ω
ΩΩ
Ω1/10W
R671 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R673 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R674 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
Ref.
No.
Part No. Part Name & Description Remarks
R675 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R676 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R677 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R678 ERJ6GEYJ392 Chip, 3.9kΩ
ΩΩ
Ω1/10W
R680 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R681 ERJ8GEYJ272V Chip, 2.7kΩ
ΩΩ
Ω1/8W
R682 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R683 ERJ6GEYJ333 Chip, 33kΩ
ΩΩ
Ω1/10W
R684 ERJ6GEYJ224 Chip, 220kΩ
ΩΩ
Ω1/10W
R685 ERJ6GEYJ562 Chip, 5.6kΩ
ΩΩ
Ω1/10W
R686 ERJ6GEYJ273 Chip, 27kΩ
ΩΩ
Ω1/10W
R687 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R688 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R689 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R690 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R691 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R695 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R696 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R697 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R698 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R699 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R700 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R701 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R702 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R703 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R704 ERJ6GEYJ392 Chip, 3.9kΩ
ΩΩ
Ω1/10W
R705 ERJ6GEYJ100 Chip, 10Ω
ΩΩ
Ω1/10W
R706 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R707 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R708 ERJ6GEYJ225V Chip, 2.2MΩ
ΩΩ
Ω1/10W
R709 ERJ14YJ221H Chip, 220Ω
ΩΩ
Ω1/4W
R710 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R712 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R713 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R714 ERJ12YJ681H Chip, 680 Ω
ΩΩ
Ω1/2W
R715 ERJ6GEYJ474 Chip, 470kΩ
ΩΩ
Ω1/10W
R718 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R719 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R720 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R721 ERJ8GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/8W
R722 ERJ8GEYJ6R8V Chip, 6.8Ω
ΩΩ
Ω1/8W
R723 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R724 ERJ6GEYJ151 Chip, 150Ω
ΩΩ
Ω1/10W
R725 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R727 ERJ6GEYJ100 Chip, 10Ω
ΩΩ
Ω1/10W
R728 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R729 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R730 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R731 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R732 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R733 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R734 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R735 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R736 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R739 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R740 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R741 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R742 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R743 ERJ6GEYJ392 Chip, 3.9kΩ
ΩΩ
Ω1/10W
R745 ERJ6GEYJ153 Chip, 15kΩ
ΩΩ
Ω1/10W
R746 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R747 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R748 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R749 ERJ6GEYJ153 Chip, 15kΩ
ΩΩ
Ω1/10W
R750 ERJ6GEYJ392 Chip, 3.9kΩ
ΩΩ
Ω1/10W
R751 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R752 ERJ12YJ330H Chip, 33 Ω
ΩΩ
Ω1/2W
R753 ERJ14YJ102H Chip, 1kΩ
ΩΩ
Ω1/4W
R754 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R755 ERJ8GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/8W
R756 ERJ6GEYJ151 Chip, 150Ω
ΩΩ
Ω1/10W
R757 ERJ8GEYJ6R8V Chip, 6.8Ω
ΩΩ
Ω1/8W
R758 ERJ6GEYJ123 Chip, 12kΩ
ΩΩ
Ω1/10W
16
AUDI / CQ-LA1923L

Ref.
No.
Part No. Part Name & Description Remarks
R759 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R760 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R761 ERG1SJ330V Metal Oxid, 33Ω
ΩΩ
Ω1W
R762 ERJ6GEYJ123 Chip, 12kΩ
ΩΩ
Ω1/10W
R763 ERG1SJ330V Metal Oxid, 33Ω
ΩΩ
Ω1W
R765 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R766 ERJ6GEYJ153 Chip, 15kΩ
ΩΩ
Ω1/10W
R767 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R769 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R773 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R780 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R781 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R782 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R784 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R785 ERJ6GEYJ153 Chip, 15kΩ
ΩΩ
Ω1/10W
R787 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R788 ERJ6GEYJ271 Chip, 270Ω
ΩΩ
Ω1/10W
R789 ERJ6GEYJ271 Chip, 270Ω
ΩΩ
Ω1/10W
R791 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R792 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R793 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R795 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R797 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R798 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R799 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R803 ERG1SJ270E Metal Oxid, 27Ω
ΩΩ
Ω1W
R804 ERG1SJ270E Metal Oxid, 27Ω
ΩΩ
Ω1W
R805 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R806 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R807 ERJ6GEYJ822 Chip, 8.2kΩ
ΩΩ
Ω1/10W
R808 ERJ6GEYJ822 Chip, 8.2kΩ
ΩΩ
Ω1/10W
R810 ERJ6GEYJ822 Chip, 8.2kΩ
ΩΩ
Ω1/10W
R811 ERJ6GEYJ822 Chip, 8.2kΩ
ΩΩ
Ω1/10W
R815 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R816 ERJ6GEYJ392 Chip, 3.9kΩ
ΩΩ
Ω1/10W
R817 ERJ6GEYJ392 Chip, 3.9kΩ
ΩΩ
Ω1/10W
R818 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R819 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R820 ERG1SJ331E Metal Oxid, 330Ω
ΩΩ
Ω1W
R901 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R902 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R903 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R904 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R905 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R906 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R907 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R908 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R909 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R910 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R911 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R912 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R913 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R914 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R915 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R916 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R918 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R919 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R920 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R921 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R922 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R923 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R924 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R925 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R926 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R927 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R931 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R933 ERJ6GEY0R00 Chip, 0Ω
ΩΩ
Ω1/10W
R934 ERJ8GEY0R00V Chip, 0Ω
ΩΩ
Ω1/8W
CONNECTORs
CN501 K1KA10B00162 Connector, 10P
CN602 K1KA18B00029 Connector, 18P
Ref.
No.
Part No. Part Name & Description Remarks
CN603 K1KA16B00077 Connector, 16P
CN781 YEAE012631A Connector
CP501 YEAETKCF10XE Connector, 10P
CP600 K1KA10B00162 Connector, 10P
CP601 K1KA10B00162 Connector, 10P
CP602 YEAETKCF18XS Connector, 18P
CP603 YEAETKCF16XS Connector, 16P
CP604 YEAE08SDA786 Connector, 8P
CP605 K1FB105A0003 Connector, 5P
COILs
L50 YELT03N4R7KT Coil
L51 ELER102KA Coil
L101 YELT02C1R8KT Coil
L401 YELT02C101KT Coil
L501 YELT02C101KT Coil
L601 YELT02C2R2KT Coil
L604 YELT02C2R2KT Coil
L606 YELT02C2R2KT Coil
L609 YELT02C101KT Coil
L701 ELEAR100KA Coil
L702 YELT02C2R2KT Coil
L704 YELT02C101KT Coil
L706 J0JCC0000012 Coil
L707 J0JCC0000012 Coil
L708 J0JCC0000012 Coil
L781 YETQ014T162 Coil
L902 YELT02C2R2KT Coil
CRYSTALs
XL501 YEXLCR838M5T Crystal
XL601 YEXL49U1601T Crystal
XL701 H0D720400003 Crystal
XL702 YEXL49U0433T Crystal
XL901 YEXLCSA419MG Crystal
LAMPs
Z101 J0LE00000002 ZNR
VARIABLE RESISTORs
VR201 EVNDXAA00B13 Variablr resistor
VR301 EVNDXAA00B13 Variablr resistor
NETWORK RESISTORs
RA1 EXBV8V102JV Network Resistor
RA2 EXBV8V102JV Network Resistor
RA3 EXBV8V102JV Network Resistor
RA4 EXBV8V102JV Network Resistor
RA5 EXBV8V102JV Network Resistor
RA6 EXBV8V102JV Network Resistor
RA7 EXBV8V102JV Network Resistor
RA8 EXBV8V102JV Network Resistor
RA9 EXBV8V102JV Network Resistor
RA10 EXBV8V102JV Network Resistor
RA11 EXBV8V102JV Network Resistor
RA12 EXBV8V102JV Network Resistor
RA13 EXBV8V102JV Network Resistor
RA14 EXBV8V102JV Network Resistor
THERMISTOR
R679 ERTD2FGL801S Thermistor
FILTER
CS781 YECCL55S222T Noise Filter
17
AUDI / CQ-LA1923L

Ref.
No.
Part No. Part Name & Description Remarks
[E8305A] Display Block
IC´s and TRANSISTORs
IC601 YEAMH66720F2 IC
IC602 YEAMBA823F IC
IC603 YEAMBA823F IC
Q671 YEANFP1F3PT1 Transistor
Q672 YEANC2412KTX Transistor
Q675 YEANC2412KTX Transistor
Q676 YEANFP1F3PT1 Transistor
Q677 YEANSFH320T Transistor
Q678 YEANC3661TA Transistor
DIODEs
D601-
616
YEADLST676T Diode
D621-
668
YEADLST676T Diode
CAPACITORs
C601 YECUS1E104ZF Ceramic, 0.1µF 25WV
C602 YECUS1E104ZF Ceramic, 0.1µF 25WV
C662 YECUS1C474KX Ceramic, 0.47µF 16WV
C663 YECUS1C474KX Ceramic, 0.47µF 16WV
C666 YECUS1C105ZF Ceramic, 1µF 16WV
C671 YECUS1C334KX Ceramic, 0.33µF 16WV
C675 YECUS1C474KX Ceramic, 0.47µF 16WV
RESISTORs
R602 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R605 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R608 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R611 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R614 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R617 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R620 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R623 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R631 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R632 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R633 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R634 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R635 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R636 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R637 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R638 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R639 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R640 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R641 ERJ8GEYJ101V Chip, 100Ω
ΩΩ
Ω1/8W
R642 ERJ8GEYJ101V Chip, 100Ω
ΩΩ
Ω1/8W
R643 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R644 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R645 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R646 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R647 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R648 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R653 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R654 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R655 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R656 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R657 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R658 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R661 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R662 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R663 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R664 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R665 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R666 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R671 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R672 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R673 ERJ6GEYJ105 Chip, 1M Ω
ΩΩ
Ω1/10W
Ref.
No.
Part No. Part Name & Description Remarks
CONNECTORs
CN600 YEAETKCF10XE Connector, 10P
CN601 YEAETKCF10XE Connector, 10P
CN603 YEAE5243530 Connector, 30P
CN604 YEAE5243530 Connector, 30P
LCD
LCD601 YEXDCM1195 LCD
VARIABLE RESISTOR
VR601 EVQWEA00115B Variable Resistor
Mechanical Parts
MISCELLANEOUS
ANT101 YEAA10087 Antenna Receplacle
F781 K5Y502200001 Fuse, 5A
TP1 YEAT03339 Terminal
1YEFA031527 Upper Cover
2YEFA05673 Bottom Cover
3YEFA07403 Front Plate
4YEFA08452 Rear Plate
5YEFA09555 Side Plate (L)
6YEFA09556AK Side Plate (R)
7YEFA131307 Cover, LCD
8YGFC026725 Escucheon Ass´y
9YEFF01882B Heat Sink
10 YEFJ05030 Color Rivet
11 YEFK06759 Holder, LCD
12 YEFR07091A Rubber Contact
13 YEFR07092A Rubber Contact
14 YEFR07093 Rubber Contact
15 YEFR07094 Rubber Contact
16 YEFS011440 Pad
17 YEFV011803 Insulator
18 YEFX0052186 Spring
19 YEFX0052187 Spring
20 YEFX0052188 Spring
21 YEFX0213797 Bracket, GND
22 YEFM03942 Sticker
23 YEP0PT6619Z9 PCB w/Component RTL
24 YEP0PT8305Z9 PCB w/Component RTL
30 XTB3+10FFX Screw, M3x10mm
31 XSN5+16FX Screw, M5x16mm
32 XSB26+6FX Screw, M2.6x6mm
33 XTB3+8JFX Tapping Screw, M3x8mm
34 YEJT03047 Tapping Screw,
35 XTB3+6FFX Tapping Screw, M3x6mm
36 XTB3+6JFX Tapping Screw, M3x6mm
37 XTB2+6GFX Tapping Screw, M2x6mm
38 XYN26+C10FX Screw, M2.6x10mm
18
AUDI / CQ-LA1923L

11 EXPLODED VIEW (Unit)
19
AUDI / CQ-LA1923L

13 SCHEMATIC DIAGRAM -1
13.1. AMP Block
25
AUDI / CQ-LA1923L
