Panasonic ACE AB5 User manual

AB5
PRODUCT TYPES
SPECIFICATIONS
1. Contact rating
2. Characteristics
PUSH-BUTTON SWITCHES
ACE PUSH-BUTTON
SWITCHES (AB5)
Type Part No. Push-button color (Number replaces asterisk in part number.)
Black Red Green Yellow White Blue
Push type AB5∗2177F 123456
Lock type AB5∗2277F 123456
Kind of load AC rating DC rating
Resistive load (cos nearly equal 1.0) 15A 125V AC,15A 250V AC 0.6A 125V DC
Inductive load(cos nearly equal 0.4) 10A 125V AC,10A 250V AC 0.6A 125V DC
Expected life Mechanical Min. 107(60 cpm)
Electrical Min. 105(20 cpm) at rated load
Insulation resistance Min. 100 MΩ(at 500 V DC measured by insulation resistive meter)
Breakdown
voltage
Between non-continuous terminals 1000 Vrms for 1 min. (at detection current: 10mA)
Between each terminal and other exposed metal parts 1500 Vrms for 1 min. (at detection current: 10mA)
Between each terminal and ground 1500 Vrms for 1 min. (at detection current: 10mA)
Contact resistance Max. 50 mΩ(By voltage drop at 1 A, 6 to 8 V DC)
Allowable operation speed (No load) 0.1 to 1,000 mm/s
Max. switching frequency (No load) 600 cpm
Ambient temperature –25°C to +85 °C (Not freezing below 0 °C)
Contact material Movable: AgSnO2alloy; Fixed: AgZnO alloy
FEATURES
1. High performance and excellent
characteristics.
An AH7 snap action switch is used in the
switch body and since the installation
frame is made of molded plastic,
dimensional accuracy is now on a new
level.
2.Two series: push type and lock type
Lock type also available that locks when
rotated.
3. Six push-button colors
You can use colors in accordance with
sequence functions.
4.The switch body uses an AH7 snap
action switch (O.F. 3.92 N max. type).
Also, if dirt and water resistant
properties are required of the internal
switch, a V type turquoise switch
(sealed type snap action switch) can
be built in. Please inquire.
PRECAUTIONS WHEN
USING CADMIUM-FREE
CONTACT TYPE
Models with cadmium-free contacts have
been introduced in order to reduce
environmentally harmful substances. (“F”
is affixed to the end of the part number.)
We ask customers who are currently
using products with cadmium-containing
contacts (no “F” at the end of the part
number) to please make the switch to
models with cadmium-free contacts.
When switching, operating life may differ
depending on the load. Please be sure to
verify this by conducting an evaluation
using actual equipment.
Push type Lock type
12 dia.
RoHS Directive compatibility information
http://www.nais-e.com/
All Rights Reserved © COPYRIGHT Matsushita Electric Works, Ltd.

AB5
DIMENSIONS (mm) (General tolerance: ±0.4)
NOTES
Arrow to indicate rotation direction and ON indication
printed at top of push-button on lock types.
13.5
7.15
8.5
11.5
Keyway
R50
15 dia.
20.0
10
0.5
3.6
3.0
3.8
38.8
(22.2)
28.8
(10.3)
3.4
0.5
22.8
2NC
C
1
C
NO
3
Lock nut (15 dia.)
Spring washer
Hex nut (opposing sides: 14)
26.2 ±0.5
47.4 ±0.4
51.0 ±0.8
Movement until operation (P.T.)
1.6max
Full stroke during operation
Push type: 2.4
Lock type: 2.0
7.15
M12 P=1.0
2 fibers
2 rivets
14max1.6max
Lock rotation
angle 60°
Mounting dimensions
(Panel thickness: Max. 3 mm)
1.7 ±0.1
12.2 ±0.1
5.2 ±0.1
1. For panel installation, please
tighten with a torque of no more than
1.47 N·m.
2. For push-button installation, please
tighten with a torque of no more than
0.49 N·m.
3. Notch is provided on the operation
shaft and pushbutton to prevent the
push-button from falling off. After
using the notch, screw in a further 120
to 160°(3 or 4 threads).
4. Please note that the number
changes when the push-button is
replaced.
