Panasonic HYBRID IP-PBX KX-TDA200 Owner's manual

Thank you for purchasing a Panasonic Hybrid IP-PBX.
Please read this manual carefully before using this product and save this manual for future use.
KX-TDA50: PSMPR Software File Version 5.0000 or later
KX-TDA100/KX-TDA200: PMPR Software File Version 5.0000 or later
KX-TDA600: PLMPR Software File Version 5.0000 or later
Document Version: 2008-11
Hybrid IP-PBX
PC Programming Manual
Model No. KX-TDA50/KX-TDA100
KX-TDA200/KX-TDA600

Introduction
About this Programming Manual
The PC Programming Manual is designed to serve as a system programming reference for the Panasonic
Hybrid IP-PBX. It explains how to program this PBX using the Maintenance Console software.
The PC Programming Manual is divided into the following sections:
Section 1, Overview
Provides an overview of programming the PBX.
Section 2, Introduction of Maintenance Console
Explains the layout and menus of the Maintenance Console.
Sections 3 – 13, Maintenance Console Operating Instructions
Serves as reference operating instructions when using the Maintenance Console software to program the PBX.
Section 14, Appendix
Provides a list of all related PC programming items for each feature as Feature Programming References.
References Found in the PC Programming Manual
Programming Manual References
Related sections of the PC Programming Manual are listed for your reference.
Feature Manual References
The Feature Manual explains what the PBX can do, as well as how to obtain the most of its many features and
facilities. Sections from the Feature Manual are listed throughout this manual for your reference.
Installation Manual References
The Installation Manual provides instructions detailing the installation and maintenance of the PBX.
Sections from the Installation Manual are listed throughout this manual for your reference.
Links to Other Pages and Manuals
If you are viewing this manual with a PC, certain items are linked to different sections of this and other PBX
manuals. Click on a link to jump to that section.
Linked items include:
•Installation Manual References
•PC Programming Manual References
•Feature Manual References
Safety Notices
Please observe the safety notices in this manual in order to avoid danger to users or other people, and prevent
damage to property.
The notices are classified as follows, according to the severity of injury or damage:
WARNING This notice means that misuse could result in death or serious injury.
2 PC Programming Manual Document Version 2008-11
Introduction

CAUTION This notice means that misuse could result in injury or damage to property.
WARNING
Unplug the PBX from the AC outlet if it emits smoke, an abnormal smell or makes unusual noise.
These conditions can cause fire or electric shock. Confirm that smoke has stopped and contact an
authorized Panasonic Factory Service Center.
CAUTION
Do not remove the SD Memory Card while power is supplied to the PBX. Doing so may cause the PBX to
fail to start when you try to restart the system.
Note
1. During a long programming session, it is highly recommended that you periodically save the system
data to the SD Memory Card. If the PBX undergoes a sudden power failure or if the system is reset for
some reason, all the system data in RAM will be lost. However, if system data has been saved to the
SD Memory Card, it can be easily restored.
To save the system data to the SD Memory Card, (1) click the "SD Memory Backup" icon before
resetting the PBX or turning off the power, or (2) exit the Maintenance Console so that the PBX
automatically saves the system data.
2. The PC will not perform any shutdown operation, or enter the power-saving system standby mode
while the Maintenance Console is connected to the PBX.
To perform either of the operations above, first close the connection to the PBX.
Trademarks
•Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
•All other trademarks identified herein are the property of their respective owners.
•Microsoft product screen shot(s) reprinted with permission from Microsoft Corporation.
NOTES
•The contents of this manual apply to PBXs with a certain software version, as indicated on the cover of
this manual. To confirm the software version of your PBX, see How do I confirm the software version
of the PBX or installed cards? in Maintenance Console Software in 2.7.1 Frequently Asked
Questions (FAQ).
•Some optional service cards, PTs, and features are not available in some areas. Additionally, some optional
service cards and features are not available for some PBX models. Please consult your certified Panasonic
dealer for more information.
•Product specifications are subject to change without notice.
In some cases, additional information, including updates to this and other manuals, is included in the
Maintenance Console’s Information before programming. Install the latest version of Maintenance
Console to view this information.
•In this manual, model number suffixes (e.g., KX-TDA50G) are omitted unless necessary.
Document Version 2008-11 PC Programming Manual 3
Introduction

Table of Contents
1Overview ...................................................................................................9
1.1 Introduction .....................................................................................................................10
1.1.1 Introduction .....................................................................................................................10
1.1.2 Entering Characters .......................................................................................................11
1.2 PC Programming .............................................................................................................12
1.2.1 Installing and Starting the Maintenance Console ...........................................................12
1.2.2 Password Security ..........................................................................................................14
2 Introduction of Maintenance Console ..................................................15
2.1 Introduction .....................................................................................................................16
2.1.1 Starting Maintenance Console and Software Modes .....................................................16
2.1.2 Access Levels ................................................................................................................18
2.1.3 Software Interface ..........................................................................................................22
2.1.4 Card Status ....................................................................................................................24
2.1.5 Display Options ..............................................................................................................25
2.1.6 Extension Number Setting ..............................................................................................25
2.2 Start Menu ........................................................................................................................27
2.2.1 Start Menu—New ...........................................................................................................27
2.2.2 Start Menu—Open .........................................................................................................27
2.2.3 Start Menu—Connect—RS-232C ..................................................................................27
2.2.4 Start Menu—Connect—USB ..........................................................................................28
2.2.5 Start Menu—Connect—LAN ..........................................................................................28
2.2.6 Start Menu—Connect—Modem .....................................................................................29
2.2.7 Start Menu—Connect—Profile Setup .............................................................................30
2.3 File ....................................................................................................................................32
2.3.1 File—Close .....................................................................................................................32
2.3.2 File—Save ......................................................................................................................32
2.3.3 File—Save As .................................................................................................................32
2.3.4 File—Exit ........................................................................................................................32
2.4 Disconnect .......................................................................................................................33
2.4.1 Disconnect—Disconnect ................................................................................................33
2.5 Tool ...................................................................................................................................34
2.5.1 Tool—SD memory backup .............................................................................................34
2.5.2 Tool—NDSS Link Data Clear .........................................................................................34
2.5.3 Tool—DXDP All OUS .....................................................................................................34
2.5.4 Tool—Simplified Voice Message—Delete All Recording ...............................................34
2.5.5 Tool—Simplified Voice Message—Check Current Usage .............................................34
2.5.6 Tool—Call Pickup for My Group .....................................................................................35
2.5.7 Tool—Extension List View ..............................................................................................35
2.5.8 Tool—Import ...................................................................................................................36
2.5.9 Tool—Export ..................................................................................................................38
2.5.10 Tool—Screen Customize—User Level/Administrator Level ...........................................39
2.6 Utility ................................................................................................................................40
2.6.1 Utility—Diagnosis ...........................................................................................................40
2.6.2 Utility—File Transfer PC to PBX (SD Card) ...................................................................43
2.6.3 Utility—File Transfer PBX (SD Card) to PC ...................................................................47
2.6.4 Utility—SD Card File View and Load ..............................................................................48
2.6.5 Utility—SD Card File Delete ...........................................................................................48
2.6.6 Utility—Message File Transfer PC to PBX .....................................................................49
2.6.7 Utility—Message File Transfer PBX to PC .....................................................................49
2.6.8 Utility—Error Log ............................................................................................................49
2.6.9 Utility—T1 Signaling Bit Monitor (KX-TDA100/KX-TDA200/KX-TDA600 only) ..............51
4 PC Programming Manual Document Version 2008-11
Table of Contents

2.6.10 Utility—T1 Line Trace (KX-TDA100/KX-TDA200/KX-TDA600 only) ..............................52
2.6.11 Utility—ISDN/QSIG Protocol Trace ................................................................................52
2.6.12 Utility—Digital Trunk Error Report (KX-TDA100/KX-TDA200/KX-TDA600 only) ...........52
2.6.13 Utility—IP Extension Statistical Information ...................................................................53
2.6.14 Utility—CS Information ...................................................................................................54
2.6.15 Utility—PS Information ...................................................................................................55
2.6.16 Utility—Timed Update (KX-TDA100/KX-TDA200/KX-TDA600 only) ..............................55
2.6.17 Utility—System Reset—Reset by the Command ...........................................................56
2.6.18 Utility—Flash ROM ID Information .................................................................................58
2.7 Help ..................................................................................................................................59
2.7.1 Frequently Asked Questions (FAQ) ...............................................................................59
3 [1] Configuration ....................................................................................69
3.1 [1-1] Slot ...........................................................................................................................70
3.2 [1-1] Slot—Summary .......................................................................................................75
3.3 [1-1] Slot—Card Property - MPR ....................................................................................79
3.4 [1-1] Slot—Card Property - Extension Type .................................................................81
3.5 [1-1] Slot—Port Property - Extension Port ....................................................................87
3.6 [1-1] Slot—Port Property - Extension Port—Connection Command ..........................96
3.7 [1-1] Slot—Port Property - Extension Port—Port Type View ......................................97
3.8 [1-1] Slot—Port Property - CSI/F Port (KX-TDA100/KX-TDA200/KX-TDA600
only) ..................................................................................................................................99
3.9 [1-1] Slot—Port Property - CSI/F Port—Connection Command (KX-TDA100/
KX-TDA200/KX-TDA600 only) ......................................................................................102
3.10 [1-1] Slot—Card Property - LCO type ..........................................................................103
3.11 [1-1] Slot—Port Property - LCO Port ...........................................................................113
3.12 [1-1] Slot—Port Property - LCO Port—Connection Command .................................120
3.13 [1-1] Slot—Card Property - PRI type (KX-TDA100/KX-TDA200/KX-TDA600
only) ................................................................................................................................121
3.14 [1-1] Slot—Port Property - PRI Port (KX-TDA100/KX-TDA200/KX-TDA600
only) ................................................................................................................................137
3.15 [1-1] Slot—Port Property - PRI Port—Connection Command (KX-TDA100/
KX-TDA200/KX-TDA600 only) ......................................................................................160
3.16 [1-1] Slot—Card Property - T1 type (KX-TDA100/KX-TDA200/KX-TDA600
only) ................................................................................................................................161
3.17 [1-1] Slot—Port Property - T1 Port (KX-TDA100/KX-TDA200/KX-TDA600
only) ................................................................................................................................173
3.18 [1-1] Slot—Port Property - T1 Port—Connection Command (KX-TDA100/KX-TDA200/
KX-TDA600 only) ...........................................................................................................183
3.19 [1-1] Slot—Card Property - IP Gateway .......................................................................184
3.20 [1-1] Slot—Port Property - IP-GW Port ........................................................................187
3.21 [1-1] Slot—Port Property - IP-GW Port—Connection Command ..............................189
3.22 [1-1] Slot—Card Property - IP Extension ....................................................................190
3.23 [1-1] Slot—Card Property - IP Extension—Common Settings ..................................195
3.24 [1-1] Slot—Port Property - IP-Extension Port .............................................................197
3.25 [1-1] Slot—Card Property - SIP Gateway (KX-TDA50 only) .......................................204
3.26 [1-1] Slot—SIP-GW Port Property (KX-TDA50 only) ...................................................205
3.27 [1-1] Slot—OPB3 Card Property (KX-TDA100/KX-TDA200/KX-TDA600 only) ..........208
3.28 [1-1] Slot—OPB3 Card Property—Card Command (KX-TDA100/KX-TDA200/
KX-TDA600 only) ...........................................................................................................214
3.29 [1-1] Slot—OPB3 Option Card Setup (KX-TDA100/KX-TDA200/KX-TDA600
only) ................................................................................................................................217
3.30 [1-1] Slot—Card Property - CTILINK (KX-TDA100/KX-TDA200/KX-TDA600
only) ................................................................................................................................219
3.31 [1-1] Slot—Card Property - DPH type (KX-TDA50 only) .............................................222
Document Version 2008-11 PC Programming Manual 5
Table of Contents

3.32 [1-1] Slot—Card Property - DPH type—Connection Command (KX-TDA50
only) ................................................................................................................................225
3.33 [1-1] Slot—Card Property - ESVM Type (KX-TDA50 only) .........................................226
3.34 [1-2] Portable Station ....................................................................................................228
3.35 [1-3] Option ....................................................................................................................232
3.36 [1-4] Clock Priority (KX-TDA100/KX-TDA200/KX-TDA600) ........................................235
4 [2] System .............................................................................................237
4.1 [2-1] Date & Time/Daylight Saving ...............................................................................238
4.2 [2-1] Date & Time/Daylight Saving—Date & Time Setting .........................................240
4.3 [2-2] Operator & BGM ...................................................................................................241
4.4 [2-3] Timers & Counters ...............................................................................................244
4.5 [2-4] Week Table ............................................................................................................267
4.6 [2-4] Week Table—Time Setting ...................................................................................268
4.7 [2-5] Holiday Table ........................................................................................................271
4.8 [2-6-1] Numbering Plan—Main .....................................................................................274
4.9 [2-6-2] Numbering Plan—Quick Dial ............................................................................305
4.10 [2-6-3] Numbering Plan—B/NA DND Call Feature ......................................................307
4.11 [2-7-1] Class of Service—COS Settings ......................................................................311
4.12 [2-7-2] Class of Service—External Call Block ............................................................327
4.13 [2-7-3] Class of Service—Internal Call Block ..............................................................328
4.14 [2-8-1] Ring Tone Patterns—Call from CO ..................................................................329
4.15 [2-8-2] Ring Tone Patterns—Call from Doorphone ....................................................330
4.16 [2-8-3] Ring Tone Patterns—Call from Others ............................................................331
4.17 [2-9] System Options ....................................................................................................334
4.18 [2-10] Extension CID Settings ......................................................................................365
4.19 [2-11-1] Audio Gain—Paging/MOH ..............................................................................370
4.20 [2-11-2] Audio Gain—Card ...........................................................................................374
5 [3] Group ...............................................................................................375
5.1 [3-1-1] Trunk Group—TRG Settings ............................................................................376
5.2 [3-1-2] Trunk Group—Local Access Priority ..............................................................384
5.3 [3-1-3] Caller ID Modification ........................................................................................385
5.4 [3-1-4] Dialing Plan ........................................................................................................391
5.5 [3-1-4] Dialing Plan—Auto Assign ...............................................................................393
5.6 [3-2] Extension Group ...................................................................................................394
5.7 [3-3] Call Pickup Group ................................................................................................396
5.8 [3-3] Call Pickup Group—All Setting ...........................................................................398
5.9 [3-4] Paging Group ........................................................................................................400
5.10 [3-4] Paging Group—All Setting ..................................................................................402
5.11 [3-4] Paging Group—External Pager ...........................................................................404
5.12 [3-5-1] Incoming Call Distribution Group—Group Settings ......................................406
5.13 [3-5-1] Incoming Call Distribution Group—Group Settings—Member List .............424
5.14 [3-5-2] Incoming Call Distribution Group—Queuing Time Table ..............................427
5.15 [3-5-3] Incoming Call Distribution Group—Miscellaneous ........................................428
5.16 [3-6] Extension Hunting Group ....................................................................................431
5.17 [3-6] Extension Hunting Group—Member List ...........................................................433
5.18 [3-7-1] VM(DPT) Group—System Settings ..................................................................434
5.19 [3-7-2] VM(DPT) Group—Unit Settings ........................................................................436
5.20 [3-7-2] VM(DPT) Group—Unit Settings—Member List ...............................................438
5.21 [3-8-1] VM(DTMF) Group—System Settings ...............................................................442
5.22 [3-8-2] VM(DTMF) Group—Group Settings .................................................................453
5.23 [3-8-2] VM(DTMF) Group—Group Settings—Member List ........................................455
5.24 [3-9] PS Ring Group ......................................................................................................456
5.25 [3-9] PS Ring Group—Member List .............................................................................458
6 PC Programming Manual Document Version 2008-11
Table of Contents

6 [4] Extension .........................................................................................461
6.1 [4-1-1] Wired Extension—Extension Settings ............................................................462
6.2 [4-1-1] Wired Extension—Extension Settings—CLIP Generate ................................524
6.3 [4-1-2] Wired Extension—FWD/DND ............................................................................527
6.4 [4-1-3] Wired Extension—Speed Dial ..........................................................................532
6.5 [4-1-4] Wired Extension—Flexible Button ...................................................................534
6.6 [4-1-4] Wired Extension—Flexible Button—Flexible button data copy ....................553
6.7 [4-1-5] Wired Extension—PF Button ...........................................................................554
6.8 [4-1-6] Wired Extension—NDSS Link Data - Send .....................................................555
6.9 [4-1-7] Wired Extension—Simplified Voice Message .................................................556
6.10 [4-2-1] Portable Station—Extension Settings .............................................................559
6.11 [4-2-1] Portable Station—Extension Settings—CLIP Generate ................................594
6.12 [4-2-2] Portable Station—FWD/DND ............................................................................597
6.13 [4-2-3] Portable Station—Flexible Button ...................................................................602
6.14 [4-2-3] Portable Station—Flexible Button—Flexible button data copy ....................617
6.15 [4-2-4] Portable Station—NDSS Link Data - Send ......................................................618
6.16 [4-2-5] Portable Station—Simplified Voice Message .................................................619
6.17 [4-3] DSS Console .........................................................................................................622
6.18 [4-3] DSS Console—DSS key data copy .....................................................................641
7 [5] Optional Device ...............................................................................643
7.1 [5-1] Doorphone ............................................................................................................644
7.2 [5-2] External Pager ......................................................................................................648
7.3 [5-3-1] Voice Message—DISA System .........................................................................650
7.4 [5-3-2] Voice Message—DISA Message ......................................................................659
7.5 [5-3-3] Voice Message—SVM .......................................................................................662
7.6 [5-4] External Relay .......................................................................................................667
7.7 [5-5] External Sensor ....................................................................................................671
8 [6] Feature .............................................................................................675
8.1 [6-1] System Speed Dial ...............................................................................................676
8.2 [6-2] Hotel .......................................................................................................................679
8.3 [6-3] Verification Code ..................................................................................................681
8.4 [6-4] Second Dial Tone .................................................................................................684
8.5 [6-5] Absent Message ...................................................................................................685
8.6 [6-6] Tenant ....................................................................................................................686
9 [7] TRS ...................................................................................................689
9.1 [7-1] Denied Code ..........................................................................................................690
9.2 [7-2] Exception Code ....................................................................................................691
9.3 [7-3] Special Carrier ......................................................................................................692
9.4 [7-4] Emergency Dial .....................................................................................................693
9.5 [7-5] Miscellaneous .......................................................................................................694
10 [8] ARS ..................................................................................................697
10.1 [8-1] System Setting ......................................................................................................698
10.2 [8-2] Leading Number ...................................................................................................700
10.3 [8-3] Routing Plan Time ................................................................................................702
10.4 [8-3] Routing Plan Time—Time Setting .......................................................................703
10.5 [8-4] Routing Plan Priority ............................................................................................704
10.6 [8-5] Carrier ....................................................................................................................705
10.7 [8-6] Leading Number Exception .................................................................................709
10.8 [8-7] Authorization Code for TRG ................................................................................710
Document Version 2008-11 PC Programming Manual 7
Table of Contents

11 [9] Private Network ...............................................................................711
11.1 [9-1] TIE Table ................................................................................................................712
11.2 [9-2] Network Data Transmission ................................................................................716
11.3 [9-3] Network Operator (VoIP) ......................................................................................720
11.4 [9-4] NDSS Key Table ....................................................................................................722
12 [10] CO & Incoming Call ......................................................................725
12.1 [10-1] CO Line Settings .................................................................................................726
12.2 [10-2] DIL Table & Port Settings ..................................................................................729
12.3 [10-3] DID Table .............................................................................................................741
12.4 [10-3] DID Table—Automatic Registration ..................................................................745
12.5 [10-3] DID Table—Name Generate ...............................................................................747
12.6 [10-4] Miscellaneous .....................................................................................................750
13 [11] Maintenance ..................................................................................753
13.1 [11-1] Main .....................................................................................................................754
13.2 [11-2] PT Programming Access ...................................................................................774
13.3 [11-3] Power Failure Transfer (KX-TDA100/KX-TDA200/KX-TDA600 only) ..............775
14 Appendix ...............................................................................................777
14.1 Revision History ............................................................................................................778
14.1.1 KX-TDA600 PLMPR Software File Version 5.0xxx ......................................................778
14.1.2 KX-TDA100/KX-TDA200 PMPR Software File Version 3.2xxx ....................................778
14.1.3 KX-TDA100/KX-TDA200 PMPR Software File Version 5.0xxx ....................................779
14.1.4 KX-TDA50 PSMPR Software File Version 4.0xxx ........................................................780
14.1.5 KX-TDA50 PSMPR Software File Version 5.0xxx ........................................................781
14.2 Feature Programming References ..............................................................................783
8 PC Programming Manual Document Version 2008-11
Table of Contents

Section 1
Overview
This section provides an overview of programming the
PBX.
Document Version 2008-11 PC Programming Manual 9

1.1 Introduction
1.1.1 Introduction
These programming instructions are designed to serve as an overall system programming reference for the
PBX. Each feature in the PBX has default settings that can be changed to customize the PBX to your
requirements. These settings control the functions of the PBX, and changing them is referred to as "system
programming".
Only one person can perform system programming at a time. Any other users trying to enter programming
mode will be denied access.
Ways to Program
There are two programming methods:
•PC (Personal Computer) Programming
All features and settings of the PBX can be programmed through PC programming with Maintenance
Console. Installing and starting the Maintenance Console is described in Section 1.2 PC Programming.
Individual PC programming items are described in Section 2 Introduction of Maintenance Console .
•PT (Proprietary Telephone) Programming
A subset of the features and settings of the PBX can be programmed using a PT. PT programming is
described in the PT Programming Manual.
10 PC Programming Manual Document Version 2008-11
1.1.1 Introduction

1.1.2 Entering Characters
The characters on a white background below can be used when storing a name, message, password or other
text entry data using a PC. The available characters vary according to the model of PBX.
Document Version 2008-11 PC Programming Manual 11
1.1.2 Entering Characters

1.2 PC Programming
1.2.1 Installing and Starting the Maintenance Console
System programming, diagnosis and administration can be performed with a PC using the Maintenance
Console.
This section briefly describes how to install and start the Maintenance Console when the PC and the PBX are
connected by USB cable.
System Requirements
Required Operating System
•Microsoft® Windows® XP or Windows Vista® Business operating system
Minimum Hardware Requirements
•HDD: 100 MB of available hard disk space
Recommended Display Settings
•Screen resolution: XGA (1024 ´ 768)
•DPI setting: Normal size (96 DPI)
Installing the Maintenance Console
Note
•To install or uninstall the software on a PC running Windows XP Professional, you must be logged in
as a user in either the "Administrators" or "Power Users" group.
•To install or uninstall the software on a PC running Windows Vista Business, you must be logged in
as a user in the "Administrators" group.
•To connect the PC to the PBX via USB, the KX-TDA USB driver must be installed. Follow the
instructions of the wizard to install the KX-TDA USB driver. When the PBX is first connected to the PC
via USB, you may be asked to select the appropriate USB driver. Browse for and select the KX-TDA
USB driver that was installed previously.
1. Copy the setup file of the Maintenance Console to your PC.
2. Double-click the setup file to run the installer.
3. Follow the on-screen instructions provided by the installation wizard.
Starting the Maintenance Console and Assigning the Basic Items (Quick
Setup)
When you start the Maintenance Console with the Installer Level Programmer Code and connect to the PBX
for the first time after initialization (with the factory default setting), Quick Setup will launch automatically. During
Quick Setup, you will set up the following basic items:
•Date and Time of the PBX. The date and time set to the PC’s clock will be used.
•System Password for installer for PC programming.
•Operator and manager settings. Operator extensions for all time modes (day/lunch/break/night) can be
assigned.
•Flexible Numbering plan to Type 1 or Type 2. If Type 1 (with ) is selected, " " must prefix all feature
numbers (except access numbers) when an extension user wants to use a feature.
•Operator call and Idle Line Access/ARS numbers.
•Remote Maintenance Dial Number. Enter the complete telephone number of the PBX. When necessary,
this number will be used to access the PBX from a remote location for maintenance purposes.
12 PC Programming Manual Document Version 2008-11
1.2.1 Installing and Starting the Maintenance Console

1. Connect the PC to the PBX with a USB cable.
2. Start Maintenance Console from the Start menu.
3. "Information before programming" appears.
a. Carefully read this important additional information,
which includes updates to this and other manuals.
b. Click OK to close this window.
4. Enter the Installer Level Programmer Code (default:
INSTALLER).
The Programmer Code authorizes different programming
levels, and the Quick Setup is only available when you start
the Maintenance Console with the Installer Level
Programmer Code.
Note
There are 2 other Programmer Codes with limited
authorization: Administrator Level (default: ADMIN),
and User Level (default: USER). (® 1.2.2 Password
Security)
5. Click Connect.
6. Select your PBX model from PBX Model.
7. a. Select the USB tab.
b. Enter the system password for installer (default: 1234).
c. Click Connect.
Note
To connect to the PBX via USB, the KX-TDA USB driver
must be installed on the PC, as explained above
in "Installing the Maintenance Console".
8. Follow the instructions of the Quick Setup wizard and
assign the basic items.
The system menu appears. You may now begin
programming the PBX.
Document Version 2008-11 PC Programming Manual 13
1.2.1 Installing and Starting the Maintenance Console

1.2.2 Password Security
To maintain system security, system passwords are required to access certain programming functions of the
PBX. By giving different users access to different passwords, it is possible to control the amount of
programming that each user is able to perform.
The following types of system passwords are available:
Password Description Format
System Password for User Used with the user-level programmer code to access
user-level PC programming. The installer can specify
which system programming settings are available.
4 – 10
characters
System Password for
Administrator
Used with the administrator-level programmer code to
access administrator-level PC programming. The installer
can specify which system programming settings are
available.
System Password for
Installer
Used with the installer-level programmer code to access
installer-level PC programming. All system programming
settings are available.
The three programmer codes used for PC programming can be set through Maintenance Console.
For more information about programmer codes, see 2.1.2 Access Levels.
CAUTION
To the Administrator or Installer regarding the system password
1. Please provide all system passwords to the customer.
2. To avoid unauthorized access and possible abuse of the PBX, keep the passwords secret, and inform
the customer of the importance of the passwords, and the possible dangers if they become known to
others.
3. The PBX has default passwords preset. For security, change these passwords the first time that you
program the PBX.
4. Change the passwords periodically.
5. It is strongly recommended that passwords of 10 numbers or characters be used for maximum
protection against unauthorized access. For a list of numbers and characters that can be used in system
passwords, see 1.1.2 Entering Characters.
6. If a system password is forgotten, it can be found by loading a backup of the system data into a PC,
and checking the password using the Maintenance Console software. If you do not have a backup of
the system data, you must reset the PBX to its factory defaults and reprogram it. Therefore, we strongly
recommend maintaining a backup of the system data. For more information on how to back up the
system data, refer to the on-line help of the Maintenance Console.
However, as system passwords can be extracted from backup copies of the system data file, do not
allow unauthorized access to these files.
14 PC Programming Manual Document Version 2008-11
1.2.2 Password Security

Section 2
Introduction of Maintenance Console
This section serves as reference operating instructions
when using the Maintenance Console software to
program the PBX.
Document Version 2008-11 PC Programming Manual 15

2.1 Introduction
2.1.1 Starting Maintenance Console and Software Modes
Every time Maintenance Console is started, a dialog box will appear. From here, you can enter any of the 2
available software modes.
•Batch mode
Batch mode allows you to create new system data files, and make modifications to system data files stored
on your PC, without being connected to the PBX. When you connect to the PBX, the modified data will be
uploaded at one time.
•Interactive mode
Interactive mode allows you to directly modify the system data and settings stored in the PBX’s memory
from a PC that is connected to the PBX. This mode displays the system data that is currently being used
by the PBX, rather than the system data stored on the SD memory card. Data can be modified and results
displayed in real time.
To start Maintenance Console in Batch mode
1. Enter the relevant programmer code.
2. Click OK.
The start menu will appear.
3. Select an option.
•Select New to create a new system data file.
•Select Open to open an existing system data file.
To start Maintenance Console in Interactive mode
1. Enter the relevant programmer code.
2. Click OK.
The start menu will appear.
3. Click Connect.
Connection options will be displayed.
•Select a Profile Name if you want to use a pre-saved profile. This option is only available when one
or more profiles have been previously stored.
a. Select the profile to use from the drop-down list.
b. If the system password for the PBX has not been stored with the profile, enter it.
If the system password has been stored with the selected profile, it does not need to be entered.
•To enter the parameters manually, select the PBX Model and select the method of connecting to the
PBX.
a. Specify the settings as required. For more details, see the tables below.
b. Enter the system password for the PBX.
4. Click Connect.
Maintenance Console will start, and automatically connect to the PBX. If this is the first time that
Maintenance Console has connected to the PBX, and the date and time of the PBX have not yet been set,
the Quick Setup wizard will run. For more details, see Starting the Maintenance Console and Assigning
the Basic Items (Quick Setup).
16 PC Programming Manual Document Version 2008-11
2.1.1 Starting Maintenance Console and Software Modes

Connection Settings for RS-232C
Setting Values Explanation
Port COMx Specify the number of the COM
port assigned to the PC’s
RS-232C interface. Only
available COM ports are
displayed.
Baud Rate (bps) 2400, 4800, 9600, 19200, 38400,
57600, 115200
Specify the speed of data
transmission.
Connection Settings for Modem
Setting Values Explanation
Dial Number 1-9, 0, *, #, -, "," [comma], T, P,
W
Enter the telephone number to
be dialed to access the PBX.
T: Converts the Dial Type from
Pulse to Tone.
"," [comma], P, W: Inserts a
pause.
Dial Type Auto(Tone), Auto(Pulse),
Manual
Specify the outgoing dialing
method.
If Manual is chosen, dialing must
be done with a connected
telephone.
Comment Max. 40 characters Enter a comment to identify the
set of values.
Port COMx Specify the number of the COM
port assigned to the PC’s modem
interface.
Only available COM ports will be
displayed.
Baud Rate (bps) 1200, 2400, 4800, 9600, 19200,
38400
Specify the speed of data
transmission.
Modem Initialize – Enter the modem initialize
command, and click Initialize to
send the command to the
modem.
For more details, refer to your
modem’s instruction manual.
Document Version 2008-11 PC Programming Manual 17
2.1.1 Starting Maintenance Console and Software Modes

Connection Settings for LAN
Setting Values Explanation
IP Address 1.0.0.0–223.255.255.255 Specify the IP address of the PBX
on the LAN. Enter the same IP
address that was input in IP
Address of 3.30 [1-1] Slot—
Card Property - CTILINK
(KX-TDA100/KX-TDA200/
KX-TDA600 only).
Port Number 10000–65535 Specify the port number used to
access the PBX via LAN. Enter
the same port number that was
input in Maintenance Port
Number of 3.30 [1-1] Slot—
Card Property - CTILINK
(KX-TDA100/KX-TDA200/
KX-TDA600 only) or 3.19 [1-1]
Slot—Card Property - IP
Gateway (KX-TDA50 only).
2.1.2 Access Levels
There are three main levels of access to the Maintenance Console: User, Administrator and Installer. Each
level has its own Programmer Code, which must be entered to run the Maintenance Console. The allowed
format for each programmer code is as follows:
Item Length
User Level Programmer Code 0 – 16 characters
Administrator Level Programmer Code 4 – 16 characters
Installer Level Programmer Code 4 – 16 characters
Access to menu options within the Maintenance Console is restricted depending on the Programmer Code,
and the current software mode (see 2.1.1 Starting Maintenance Console and Software Modes). When a
menu option is limited to certain access levels, this is noted in this manual in the initial description of that menu
option, for example:
"This option is only available at Installer level."
If a sentence like this does not appear under the heading, the menu option is available at all levels.
The target users for each access level are as follows:
Access Level User
User For end users
Administrator For system administrators
Installer For dealers and system installers
The options available in each mode and access level are shown below.
The access levels are abbreviated as follows:
18 PC Programming Manual Document Version 2008-11
2.1.2 Access Levels

U: User; A: Administrator; I: Installer
A check mark indicates that the menu option is available for that access level.
Start Menu
Menu Option Batch Interactive
U A I U A I
New ü ü
Open üüüüüü
Connect—RS-232C üüüüüü
Connect—USB üüüüüü
Connect—LAN üüüüüü
Connect—Modem üüüüüü
Connect—Profile Setup üüüüüü
File
Menu Option Batch Interactive
U A I U A I
Close üüü
Save üüü
Save As üüü
Exit üüüüüü
Disconnect
Menu Option Batch Interactive
U A I U A I
Disconnect üüü
Tool
Menu Option Batch Interactive
U A I U A I
SD memory backup üüü
NDSS Link Data Clear ü
DXDP All OUS ü
Simplified Voice Message®Delete All Recording ü
Simplified Voice Message®Check Current Usage ü
Call Pickup for My Group ü ü
Document Version 2008-11 PC Programming Manual 19
2.1.2 Access Levels

Menu Option Batch Interactive
U A I U A I
Extension List View üüüüüü
Import®Feature - Speed Dial and Caller ID üüüüüü
Import®Incoming Call - DID Table ü
ü
Import®ARS - Leading Digit ü ü
Import®ARS - Except Code ü ü
Import®ARS - Routing Plan ü ü
Import®Wired Extension ü ü
Import®PS Extension ü ü
Import®Quick Dial (Basic) ü ü
Import®Quick Dial (MEC) ü ü
Export®Feature - Speed Dial and Caller ID üüüüüü
Export®Incoming Call - DID Table ü ü
Export®ARS - Leading Digit ü ü
Export®ARS - Except Code ü ü
Export®ARS - Routing Plan ü ü
Export®Wired Extension ü ü
Export®PS Extension ü ü
Export®Quick Dial (Basic) ü ü
Export®Quick Dial (MEC) ü ü
Screen Customize®User Level ü ü
Screen Customize®Administrator Level ü ü
Utility
Menu Option Batch Interactive
U A I U A I
Diagnosis üüü
File Transfer PC to PBX (SD Card) ü
File Transfer PBX (SD Card) to PC ü
SD Card File View and Load ü
SD Card File Delete ü
Message File Transfer PC to PBX ü
Message File Transfer PBX to PC ü
20 PC Programming Manual Document Version 2008-11
2.1.2 Access Levels
