Panasonic KX-TA824 User manual

Advanced Hybrid System
User Guide
for KX-T77 Series
Model No. KX-TA824
Please read this guide before using and save for future reference.

Features List
Outside (CO) Line button Feature number
Talk
Off-hook On-hook *
"Location of Controls" is shown on page 9.
Desired Feature Operation
Calling
To store
personal speed dial no.
Redial
One-Touch
Dialing
Speed Dialing
(Personal)
To an extension To an external party
phone no.
extension no.
To program
To dial
phone no.
Calling an
operator
desired no.
To dial
personal speed dial no.
Programmable Feature button
Speed Dialing
(System)
system speed dial no.
To dial
Making Calls
Receiving Calls
– 2 –
While on-hook
Handsfree
answerback
(Other than
KX-T7750)
Picking up
a call Group
Directed
extension no.

Features List
Desired Feature Operation
To set
While hearing a busy tone
To call
If you hear callback ringing
Automatic
Callback Busy
When the Dialed Extension is Busy/No Answer
Receiver
Sender
To leave a notification
To cancel a notification
To call back
To clear all notifications
Message
Waiting
receiver's extension no.
– 3 –
Call Waiting
Set
Cancel
For outside calls
Set
Cancel
For intercom calls
Receiver
Sender
While hearing a busy tone
Wait for an answer.
To talk to the new party
Terminating a current status
While hearing the Call Waiting tone
Holding a current status

Features List
Desired Feature Operation
Wait for
an answer.
During a Conversation
Holding To retrieve a call at the holding extension
To retrieve an outside call from another extension
To retrieve a call on exclusive holdHolding
Screened
extension no.
To an extension
phone no.
To an external party
(System programming
is required.)
Announce.
Holding a call
Holding a call
exclusively
Transferring
a call Unscreened
to an extension
extension no.
– 4 –
Useful Features
Paging
Announce.
All extensions
Group
All external speakers
All extensions & external speakers
group no.
To answer an announced page
From a telephone speaker
From an external speaker
To page

Features List
Desired Feature Operation
Useful Features
third party's no.
Three-party
conference
Setting Absent
Message
parameter
(if required)
message no.
To set
To cancel
– 5 –
Log-In/Log-Out
For Log-In
For Log-Out
To an outside line
Cancel
Busy/No answer
All calls extension no.
extension no.
Follow Meyour extension no.
Cancel Follow Me
your extension no.
phone no.
line access
code
Busy/No answer
All calls
VPS extension No.
Forwarding
a call
To Voice Mail
VPS extension No.

Features List
Desired Feature Operation
Useful Features
lock code lock code
lock code
Lock
Unlock
Set
Cancel
Locking your
extension
Clearing the
setting
7 7
7 7 #
#
7 9 #
Do Not Disturb
(DND) #
(Lock code is 4 digits.)
#
– 6 –

Features List
Desired Feature Operation
To Make Use of Voice Mail Service
Listening
Message
From
someone
else's
extension
From your
Own
Extension
– 7 –
Extension No. of the VPS
Password
If you have no password, you can
skip the last step.
Extension No. of the VPS
Mailbox No.
Password
Listen to Message
KX-TVA series
Deliver Message
Mailbox Management
Automated Attendant
Message Notification
Other Features
End Call
Leaving
Message
Extension No. of the VPS
Mailbox No.
first 3 or 4 of name
Leave Message
During
Playback Repeat Voice Guidance
Exit Menu
If you have no password, you can
skip the last step.
Listen to Message
KX-TVS series
Deliver Message
Check Mailbox
Distribution
Automated Attendant
Mailbox Management
Other Features
End Call

Location of Controls
*The backlit display is only available on the KX-T7730/7731/7735/7736.
*The KX-T7750 does not have a microphone.
*The headset is an option. Recommended headsets are
KX-TCA91 and KX-TCA92.
1
2
3
4
6
7
8
9
10
5
Headset Jack
LCD (Liquid Crystal Display)
RINGER Volume Selector/
BACKLIGHT
Illumination Selector
13
14
18
16
15
17
11 12
Microphone
1PROGRAM: Used to enter and exit the
programming mode.
4
FWD/DND (Call Forwarding/Do Not
Disturb):
Used to perform Call Forwarding
or Do Not Disturb.
2CONF (Conference): Used to establish a
multiple party conversation.
3INTERCOM: Used to make or receive
intercom calls.
6AUTO ANS (Auto Answer)
(Other than KX-T7750): Used to receive an
incoming call in the hands-free mode.
MUTE (Other than KX-T7750): Used to
mute the microphone during a conversation.
VOICE CALL (KX-T7750 only): Used to
receive a notification via monitor in place of
ringing.
5FLASH/RECALL: Used for External Feature
Access or to disconnect the current call and
make another call without hanging up.
20
1
BACKLIGHT
– 8 –
7AUTO DIAL/STORE: Used for speed
dialing or storing program changes.
8REDIAL: Used to redial.
RINGER

TRANSFER: Used to transfer a call to
another party.
9DIALING BUTTONS WITH BACKLIGHT
(KX-T7731/36): Dialing buttons are backlit
when (1) you receive a call, (2) during a
conversation, or (3) when BGM is activated
at your phone.
10
11
HOLD: Used to place a call on hold.
12
SP-PHONE (Other than KX-T7750): Used
for the handsfree operation.
MONITOR (KX-T7750 only): Used for
handsfree dialing. You can monitor the
other party's voice handsfree.
13
NAVIGATOR KEY
(KX-T7730/7731/7735/7736):
Used to adjust the volume and the display
contrast, or select desired items.
VOLUME KEY (KX-T7720/7750): Used to
adjust the volume.
Programmable Feature (PF) Button:
Used as anOne-Touch Dialing button
(Button assignment is required).
14
16
PAUSE: Used to insert a pause during
dialing.
17
MESSAGE: Used to leave a message
waiting indication, or call back the party
who left the message waiting indication.
15
Flexible Outside (CO) Line Button:
Used to make or receive an outside call.
Pressing this button seizes an idle outside
line automatically. (Button assignment is
required.) Also used as feature buttons.
(Button assignment is required.)
Location of Controls
18
Message/Ringer Lamp: The Message/
Ringer lamp informs you visually that you
have a message or a call.
When you receive a call, the lamp
flashes depending on the ringing pattern.
When the ringing pattern is set to Single
(Slow flash), Double (Moderate flash), or
Triple (Rapid flash) in your PBX, the lamp
flashes. When the other ringing patterns
are set in your PBX, the lamp may not
flash. (e.g., S-Double, Call Waiting
Tone1).
When someone has left you a message,
the lamp is lit continuously.
– 9 –

Initial Settings
Speaker volume *
Press
SP-PHONE. Press Up or Down.
While on-hook or during a conversation
Handset/Headset volume *
Press Up or Down.
While using the handset or headset
Ringer volume /Backlight illumination
SPSP-PHONE
Display contrast *
Press Left or Right.
KX-T7730/7731/7735/7736
Slide the lever of the RINGER Volume Selector and
BACKLIGHT Illumination Selector to the desired setting.
RINGER
*The above settings may return to default
settings if the telephone line cord is
disconnected, or the main unit's power is
interrupted.
20
1
BACKLIGHT
– 10 –
BACKLIGHT SW POSITION 2 1 0
LCD backlight HIGH LOW OFF
DIALING BUTTONS backlight
AUTO: The backlight shines only during operation.
AUTO AUTO OFF
