Panasonic Press IT360 TY-CSP1 Operating instructions

Operating Instructions
Basic Guide
360 degree camera speakerphone
For business use
Model No.
TY-CSP1
• Please read these instructions before operating this product and retain
them for future reference.
•Be sure to read “Safety Precautions” (page 2 to 4) before use.
DPQX1636ZA/X1AV0522GU0 -FJ
Accessories 8
Operating precautions 5
Safety Precautions 2
Part Names 9
Operations with the buttons on the main unit 15
Connection 10
Configuring the applications on the PC 13
Video display modes 16
Indicator displays 19
Notes on the application 20
Installation 21
Specifications 22
English
Thank you for purchasing the Panasonic product.
Read this first.
Read the “Operating Instructions - Functional Manual” for detailed
descriptions about the product and how to use it.
Refer to the following URL for information about how to download the
“Operating Instructions - Functional Manual”:
https://panasonic.net/cns/prodisplays/

2 English
Safety Precautions
WARNING:
Stop using the product immediately when an
abnormality or malfunction occurs.
Remove the power plug in the case of an
abnormality.
• Smoke is emitted, or abnormal smell or sound occurs.
• Video or audio is not reproduced in some cases.
• Liquid such as water or a foreign object has entered
inside the product.
• The product is deformed or damaged.
Using the product in such states may cause a fire or
electric shock.
• Remove the power plug from the outlet and request
repair to the dealer where you purchased the product.
• It is necessary to remove the power plug to completely
turn off the power of this product.
• Do not repair the product by the customer since it is
dangerous.
• Use an outlet located at a position where the hand can
reach easily so that the power plug can be removed
quickly.
Do not insert foreign objects into the product.
Do not insert or drop metals or flammable items into the
inside the product.
Doing so may cause a fire or electric shock.
• Keep an eye on children in particular.
■About AC adaptor
Do not use an AC adaptor other than those supplied
with this product.
Using an AC adaptor other than those supplied may
cause an electric shock or fire due to short circuit or heat
generation.
Clean the power plug periodically to prevent dust
from accumulating.
Failure to do so may cause a fire or electric shock due
to moisture.
• Remove the power plug and wipe it with dry cloth.
Do not insert or remove the power plug with wet
hand.
Doing so may cause an electric shock.
Do not use the outlet or wiring devices exceeding
rated values or with currents other than 100 ‒ 240 V
AC.
Using them exceeding rated values by connecting too
many plugs in one outlet may cause a fire due to heat
generation.
Insert the power plug securely to the end.
Insufficient insertion may cause a fire due to an electric
shock or heat generation.
• Do not use the product with a damaged plug or loose
outlet.

3English
Do not damage the AC adaptor and power plug.
by damaging, modifying, forcibly bending, twisting,
pulling or bundling them, bringing them close to heat
appliances, placing heavy items on them, etc.
Doing so may cause a fire or electric shock due to short
circuit or disconnection.
• Request the dealer for repair of the AC adaptor or
power plug.
Do not use the product while touching it for a long
time.
Touching the hot parts of the product and AC adaptor for
a long time may cause a low-temperature burn*.
* Persons with poor bloodstream (due to vascular
impairment, poor blood circulation, diabetes or strong
compression) or poor skin sensitivity (elderly persons)
tend to get a low-temperature burn.
Do not touch the product and AC adaptor if it begins
to thunder.
Doing so may cause an electric shock.
Do not wet the product.
Doing so may cause a fire or electric shock.
Do not place the product on unstable locations.
Placing the product on a shaky table or an inclined location
may cause an injury due to falling over or dropping.
Do not try to disassemble or modify the product.
CAUTION:
Do not place the product at a high-temperature
location, humid or dusty location, or location subject
to oil smoke or steam (such as a cooking table and
humidifier).
Doing so may cause a fire or electric shock.
Do not drop the product or expose it to strong
impacts.
Doing so may cause injury or fire.
When the product has been mounted on a tripod, do
not move by holding this product.
The mounting parts can break due to the weight of the
tripod and injury can result.
When removing the connection cables, be sure to
hold the connector and pull it.
Pulling the cord may damage the cord, resulting in a fire
due to an electric shock or short circuit.
When transferring the product, remove the
connection cables of equipment beforehand.
Failure to do so may damage the cord or product,
resulting in a fire or electric shock.
When not using the product for a prolonged period,
remove the power plug from the outlet.
Dust may accumulate in the power plug, resulting in a
fire or electric shock.

4 English
Safety Precautions Continued
Do not pull or hang the connection cables.
Doing so may cause the product to fall over or drop,
resulting in an injury.
• Keep an eye on children in particular.
■Maintenance
For maintenance, remove the power plug from the
outlet for safety.
Failure to do so may cause an electric shock.

5English
Operating precautions
■When transporting this product
Do not apply excessive vibrations or impacts during
transport.
Doing so may damage the internal parts, resulting in a
malfunction.
■To ensure a stable performance in the long
term
Using the unit for prolonged periods in locations where
the temperature and humidity levels are high will cause
its parts to deteriorate, resulting in a reduction of its
service life.
(Recommended temperature: Max. 35 °C (95 °F))
Ensure that a cooling unit or heating unit will not blow
any air directly toward the installation location.
■Operating temperature range
Avoid using the unit in cold locations where the
temperature drops below 0 °C (32 °F) or hot locations
where the temperature rises above 40 °C (104 °F) since
these temperatures downgrade the picture quality and
adversely affect the internal parts.
■When storing the unit
Store indoors in a dry location.
■When the unit is not in use
Turn off the unit’s power when it is not in use.
When the unit is no longer going to be used, do not leave
it lying around, but be absolutely sure to dispose of it
properly.
■Do not touch the optical system parts.
Under no circumstances must they be touched.
In the unlikely event that they have become dusty,
remove the dust by using a camera blower or by wiping
them gently with a lens cleaning paper.
■Do not point the camera at strong lights.
When parts of the MOS sensor
are exposed to spotlights or
other strong lights, blooming (a
phenomenon where the edges
of strong lights become blurred)
may occur.
Bright subject
Blooming

6 English
■What happens with high-brightness
subjects
Flare may occur if an extremely bright light source is
pointed at the lens. In a case like this, change the angle
or take some other remedial action.
■Note regarding image distortion
Edges of the image will be distorted due to the
characteristics of the lens.
■Do not point the camera directly at the sun
or a laser beam no matter whether it is
turned on or not.
Taking images of the sun, laser beams, or other brightly
lit subjects for prolonged periods of time may damage
the CCD.
■Keep the unit away from water.
Do not splash water onto the product. Otherwise,
problems may occur.
■Do not swing the main unit around.
■It is not recommended to install upside
down.
■Do not use at loud volumes over long
periods. Also check that the volume on the
PC is not too loud before connecting.
There is a danger of hearing damage. Furthermore, the
power turns on when you connect, and if a loud noise is
emitted, there is a danger of hearing damage.
■Cleaning and maintenance
Ensure that you unplug the AC adaptor from the
outlet, then disconnect the power supply cable and
the USB cable before proceeding.
Gently wipe the surface of the case by using a soft
cloth to remove dirt.
●To remove stubborn dirt or fingerprints, dampen a
cloth with diluted neutral detergent (1 part detergent to
100 parts water), wring out the cloth firmly, and then
wipe away the dirt. Finally, wipe away all the moisture
with a dry cloth.
●If water droplets get inside the unit, operating
problems may result.
Operating precautions Continued

7English
Usage of a chemical cloth
●Follow the instructions for the chemical cloth.
Avoid contact with volatile substances such as
insect sprays, solvents and thinner.
●This may cause damage to the case or cause peeling
of the paint. Furthermore, do not leave it in contact
with a rubber or PVC substance for a long time.
Note when using alcohol
●Soak a small amount of alcohol at a concentration of
60 % or less in a soft cloth and wipe the housing. Then
be sure to use a dry cloth to wipe it.
Note that wiping the housing with a hard cloth or
rubbing it strongly may cause damage. Also, do not
allow water droplets to enter the inside to prevent
malfunction. Do not directly spray alcohol.
●Do not use antiseptic solutions other than alcohol.
■Disposal
When disposing the product, ask your local authority
or dealer about the correct methods of disposal.
■Power for this product
There is no power switch on this product.
Turn off the power as follows:
●When supplying power with the USB Type-C to USB
Type-C cable
Hold the plug of the cable on the PC side to unplug first,
then hold the plug on the product side to unplug.
●When supplying power with the AC adaptor
Unplug the AC adaptor first from the outlet, then hold the
plug on the product side to unplug.

8 English
Accessories
Check that you have the accessories and items shown.
AC adaptor (DPVF4350ZA/X1) .................. 1
(including 3 conversion plugs)
USB Type-C to USB Type-C cable
(Approx. 1.0 m)
(DPVF4351ZA/X1) ........... 1
USB Type-C to USB Type-A cable
(Approx. 1.8 m)
(DPVF4352ZA/X1) ........... 1
Attention
• Store small parts in an appropriate manner, and keep
them away from young children.
• The part numbers of accessories are subject to
change without notice.
(The actual part number may differ from the ones
shown above.)
• In case you lost accessories, please purchase them
from your dealer. (Available from the customer service)
• Dispose the packaging materials appropriately after
taking out the items.
Note
• This product and the cables included do not support
output of images and audio using the Alternate Mode.

9English
Part Names
■
On the 360 degree camera speakerphone
1Microphone
2Cameras (4 facing 4 directions)
3Speaker
4Indicator
5Audio muting button
6Speaker volume [－] button
7Speaker volume [＋] button
8[Mode] button
9Camera mounting screw hole (screw:
1/4-20UNC)
Used when mounting on a tripod, etc.
10 Security slot
You can connect a security cable that is compatible
with Noble Wedge slots with mounting surfaces of
11mmɸorless.
11 USB-C terminal
Outputs video and audio to the PC. It also receives
power supplied from the Type-C interface of the Listed
PC (5 V/3 A).
12 Power input terminal
Connect the AC adaptor.
1
2
3
4
6 7
910 11 12
5 8

10 English
Connection
Carefully read the operating instructions of the PC to be
connected to this product before connecting.
Turn off the power of each device before connecting
cables.
Connections with this product
1Connect the PC and this product with the
supplied USB cable.
■When connecting via a USB Type-C port on a PC
capable of supplying 5 V/3 A power
• Only the supplied USB Type-C to USB Type-C
cable can be used.
USB Type-C to USB Type-C cable
Note
• When using only the USB Type-C to USB Type-C
cable, volume output is limited compared to when
the AC adaptor is used.
■When other connections are used
Use the AC adaptor to supply power.
<Get the AC adaptor ready>
Use by inserting the conversion plug into the
supplied AC adaptor.
Use the conversion plug that suits your outlet's
shape.
1
①Slide and press in the direction
indicated by the arrow until you hear
the click.

11English
<How to remove the conversion plug>
2
1
※
①While pressing the part marked ,
②Slide in the direction indicated by
the arrow to remove.
※
Note
• Do not attempt to separate the AC adaptor and the
conversion plug while plugged into the outlet.
• Do not plug the conversion plug into the outlet on
its own.
①Connect the DC plug of the AC adaptor to the
power input terminal on this product, then plug
the AC adaptor into the outlet.
②Connect the PC to this product using the
supplied USB cable.
USB Type-C to USB Type-C cable
or
USB Type-C to USB Type-A cable
AC adaptorDC plug
Note
• USB Type-C is labeled as “USB-C” on the main unit.

12 English
2Start the online meeting application or
camera application on your PC to show the
video and play the audio from this product.
• For details on how to use this product with your
online meeting application or camera application,
refer to the operating instructions for the
application.
Connection Continued

13English
This section describes how to configure the online
meeting application on your PC.
1Connect this product to a PC.
(→ page 10)
Configuring the applications on the PC
2In the application, set this product as the
camera, microphone, and speaker.
Example
configuration screen
for your application
*
Camera
Microphone
Speaker
■If this product does not appear as a choice
• Also connect the AC adaptor when connected only
to the USB-C terminal.
3Use the test feature of the application (if
there is one) to run a test of the product's
operations.
4Start using the application after you have
completed the test.

14 English
■If the functions did not work properly when tested
• If the camera images are not output, see whether
the camera muting function of the application is off.
• If sound is not output from the speaker, check
whether the speaker volume is correct and if the
speaker is on.
• If the microphone audio is not heard, see whether
the microphone muting function of the application
is off.
Configuring the applications on the PC Continued

15English
Operations with the buttons on the main unit
Muting the microphone
Muting is switched on or off each time you press
[ ].
This works in conjunction with the muting features of
some online meeting applications.
Adjusting speaker volume
[－]: Lowers the volume.
[＋]: Raises the volume.
This works in conjunction with the volume adjusting
features of some operating systems and online meeting
applications.
Changing the mode for displaying video
Press or press and hold [ ] to switch the video
mode. (→ page 16)
Configuring the applications on the PC Continued

16 English
Video display modes
Dual View
Use when you want to show the whole conference room,
while making sure the facial expressions and voice of the
speaker are clear.
Single View
Use when you want to show the face of the speaker at
the maximum when conducting online meetings, etc.,
even if each screen is small.
Multi View
Use when you want to enlarge the faces of the
participants.
Surround View
The 360 degree overall view is split into 2 screens of 180
degrees each.
Use when you want to show the expressions on
the faces of all participants and give a feel for the
atmosphere of the entire meeting room.

17English
Stable View
Use when you want to use the product as a web camera
with a fixed position.
• The video from only one of the four camera screens is
displayed. The video from the camera on the side with
the buttons on this product is displayed.

18 English
Video display modes Continued
Transition of the display modes
When you press the [Mode] button, the modes transition
intheorder“DualView”→“SingleView”→“MultiView”
→“SurroundView”.
When you press and hold the [Mode] button for
3 seconds or more, the mode transitions to the “Stable
View”.
Press the [Mode] button to cancel the “Stable View”.
Dual View
Single View
Multi View
Surround View
Stable View
Pressing the [Mode] button to switch modes
Pressing and holding
the [Mode] button for
3 seconds or more
Pressing the [Mode]
button

19English
Indicator displays
Preparing to start up
Red LED blinks
(Blinks about 10 times in
10 seconds)
Updating firmware
Red LED blinks slowly
(Blinks about 5 times in
10 seconds)
Device error
Red LED blinks rapidly
(Blinks about 20 times in
10 seconds)
Normal circumstances (camera
and microphone on)
Green LED
Camera off
White LED
Microphone is muted
Red LED
Camera off and microphone
is muted
(Red LED circulates)
The gradation of the green LED changes only in the direction of
the speaker's voice.
* This may not work in some modes.

20 English
Notes on the application
Operations available with the PC application
The application in this product can perform the following
tests and configurations, etc., when installed on a PC:
• Viewing the version on the main unit
• Displaying the video from the cameras
• Controlling the video (zooming in and out, moving up,
down, left, and right)
* This may not work in some modes.
• Adjusting video quality
• Testing camera and speaker operation
• Updating firmware of the main unit
Note
• For application details and usage instructions, refer to
the Operating Instructions - Functional Manual.
• The PC application is supported on the Microsoft
Windows (Windows 10/Windows 11), and macOS
operating systems.
Getting the installer
1When you connect the product to a PC,
“PressIT360” appears in the list of devices and
drives.
2When you open the PressIT360 drive, the installer
is saved to your PC.
3By running the installer, the PC application is
installed on your PC.
Note
• If there are cases where you are unable to access
the product as a USB memory device, such as due
to PC settings or security policies, etc., download the
application from the following location:
https://panasonic.net/cns/prodisplays/
