Panasonic MC-CG881C-SC79 User manual

© 2008 Matsushita Electric Industrial Co.,Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
Order Number VCB0808014CE
Vacuum Cleaner
Model No. MC-CG881C-SC79
MC-CG881K-SP47
Product Color :Royal Silver
Destination :Europe
TABLE OF CONTENTS
PAGE PAGE
1 Specifications ----------------------------------------------------- 2
2 Location of Controls and Components ------------------- 3
3 Troubleshooting Guide ----------------------------------------- 5
4 Disassembly and Assembly Instructions ---------------- 6
4.1. Remove the Dust cover assy. -------------------------- 6
4.2. Remove the Rear cover unit, Switch cover,
and the Pedal cover.-------------------------------------- 6
4.3. Remove the Upper body unit and Lower body
unit.------------------------------------------------------------ 7
4.4. Remove the Cord reel partition unit. ------------------ 8
4.5. Remove the P.C.B. A Unit. ------------------------------ 9
4.6. Remove the Motor. ---------------------------------------10
5 Wiring Connection Diagram ---------------------------------12
6 Exploded View and Replacement Parts List -----------13
6.1. EXPLODED VIEW (ATTACHMENTS) --------------13
6.2. PARTS LIST (ATTACHMENTS) ----------------------14
6.3. EXPLODED VIEW (BODY UNIT) --------------------15
6.4. PARTS LIST (BODY UNIT) ----------------------------16
6.5. PACKING INSTRUCTIONS --------------------------- 18
6.6. PACKING LIST ------------------------------------------- 19

2
1 Specifications
Model No. MC-CG881C-SC79 MC-CG881K-SP47
Power source AC230V~50Hz AC230V~240V~50Hz
Input power (MAX) 1600W
Input power (IEC) 1300W 1250W~1300W
Power control O
Extension wand Metel telescopic
Nozzle assy O
Dimensions (WxLxH)mm 312×489×243
Cord length 6.5m
Net weight 6.5kg
Cleaning tools Crevice nozzle / Upholstery nozzle / Dusting brush

3
2 Location of Controls and Components

4

5
3 Troubleshooting Guide
CONDITION PARTS TO BE CHECKED CHECK METHOD REMEDY
The motor does not rotate. Power cord Check if the power cord is broken.
Inspect the cord in the cord reel
assy for continuity.
If the cord is broken, replace the
cord reel assy.
Fuse (FUSE1: 250V, 13A)
(on the P.C.B)
Visually check if the fuse has
blown.
• Check the cause of fusing.
1. Burnt motor or shorted coil
2. Shorted lead wire
3. Burnt P.C.B
etc.
If the fuse has blown, remove the
cause and replace the P.C.B assy.
Motor Inspect the continuity between the
motor terminals.
If there is no continuity, replace the
motor.
ON/OFF switch (on the P.C.B) Turn the switch on and off to check
the continuity.
If there is a problem, replace the
P. C . B a s s y.
P.C.B assy Check the internal components for
problems.
(Burnt, melted, broken, etc.)
If there is a problem, replace the
P. C . B a s s y.
Triac (in the P.C.B) Check the triac by conducting the
following inspection.
If there is a problem, replace the
P. C . B a s s y.
The motor rotates, but dust cannot
be picked up.
Dust cannot be picked up.
Dust bag (paper bag)
Filter
Check if the paper bag is full of
dust.
Check if the filter is clogged with
dust.
If the paper bag is full of dust,
replace it with a new one.
If the filter is clogged with dust, and
clean or replace it.
Hose, extension wand, floor
nozzle
Check if the part is clogged with an
obstruction.
If there is an obstruction, remove it.
Large vibration
Large noise
Motor fan Check for dust in the motor fan.
(If the dust leaks or if the filter is
missing, then dust will be able to
penetrate the motor.)
There is dust in the motor.
Check for dust leaks and filter sta-
tus, and replace the part if neces-
sary.
The motor output (suction power)
cannot be changed.
P.C.B assy Check if the resistance of the out-
put control switch connected to the
P.C.B assy changes using a tester.
(Lead wires Red-Black Red-White).
If there is a problem, replace the
P. C . B a s s y.

6
4 Disassembly and Assembly Instructions
Precautions: Make sure to power off the vacuum cleaner before replacing the parts.
Disconnect the plug from the outlet.
Caution:
(1) When disassembling, check the component fitting state and wirings. After repairing, always restore them to the origi-
nal state.
(2) Carefully handle the removed components, packing, etc. If they are damaged, then replace them with new ones.
(3) After repairing, check that the components, etc., in the vicinity of the repaired sections are not damaged, the removed
components are in place, and the wirings are restored to the original state. Carry out the test run. Also check that the fol-
lowing requirements are met.
• Insulation resistance
Must be 5 MΩor more when a DC voltage of 500 V is applied across the power plug and the motor core for one second.
• Dielectric strength
Must withstand an AC voltage of 1,250 V applied across the power plug and the motor core for one minute.
(4) Do not alter the model, parts, or materials during repair.
(5) If a wiring unit is supplied as a repair part, replace the whole unit with the new one instead of repairing or reconnecting
the broken portions only.
(6) Insert/remove the fast-on terminals by pushing/pulling them straight out without jiggling them or applying unneces-
sary force.
4.1. Remove the Dust cover assy.
1. Open the Dust cover assy. Insert a slotted screwdriver
into the gap in the joint between the Upper body and the
Dust box lid unit. Remove the Dust cover by moving the
screwdriver in the direction of the arrow.
4.2. Remove the Rear cover unit,
Switch cover, and the Pedal
cover.
1. Remove the cap seal of the rear cover unit.
2. Remove the screw holding the Rear cover unit.
While pressing the tab of the Rear cover unit with the
screwdriver, remove the Unit by lifting its rear side
(screwed side).

7
3. Remove the Swivel cap.
4. Remove the two screws each from the Switch cover and
Pedal cover.
5. Remove the Brake pedal, Switch pedal, and Switch pedal
spring.
4.3. Remove the Upper body unit
and Lower body unit.
1. Remove the screw from the Handle of the Lower body.
2. Remove the 2 screws holding the Lower body.
3. Remove the 7 screws holding the Upper body.

8
4. Remove the Upper body.
5. Remove both Left and Right wheel supporters.
4.4. Remove the Cord reel partition
unit.
1. Remove the Cord reel partition unit from the Lower body.
2. Disconnect the terminals of the two Lead wires.
Note: Pull out the terminals while pressing the termi-
nal lock to release it.
3. Release the spare turns of the cord while holding down
the brake lever.

9
4. Remove the screw at the center of the Body partition.
5. Remove the Cord reel assy from the Body partition.
4.5. Remove the P.C.B. A Unit.
1. Remove the Motor Unit from the Lower body
2. Remove the Body lining upper.
3. Remove the Control connected to the P.C.B A Unit.
4. Remove the P.C.B Holder A unit.

10
Lead wire connection of the P.C.B A unit.
5. Remove the P.C.B A Unit from the Motor cover.
6. Disconnect the fast-on terminals of the two Lead wires
from the P.C.B A Unit.
Note:
Pull the fast-on terminals straight out without jiggling
them while pressing the lock to release it.
4.6. Remove the Motor.
1. Remove the Motor case lining and the Motor case rubber.
Note: Attach gasket F so that the lead wire will be
sandwiched by the slit of gasket F.
2. Remove the Motor case band around the Motor cover
and the Motor support rubber.
3. Remove the two pieces of Packing F between the Motor
cover and Motor case.
*Carefully remove it so that it can be reused for reas-
sembly if possible.

11
4. Remove the Motor cover and the Motor case.
5. Remove the thermal protector.
Note:
When assembling the motor, set the motor in the
motor case with the thermal protector located on the
lower side.
6. Remove the Motor case plate.
7. Remove the Motor support.
8. Remove the Motor support rubber (front).
9. Disconnect the two Lead wires of the Motor.
